LOCKING WHEEL NUT KEY SET 23PC-VAG
MODEL NO: SX210.V2
1. SAFETY
WARNING! DO NOT use the tool if damaged or thought to be faulty.
WARNING! Ensure that Health & Safety, Local Authority Regulations and
general workshop practice Regulations are adhered to when using tools.
WARNING! If jacking up a vehicle refer to manufacturer’s instructions for
vehicle and jack.
8 DO NOT use the tool for a task it is not designed to perform.
8 DO NOT use worn, or damaged sockets.
8 DO NOT use the tool unless you have been instructed in its use by a
qualied person.
8 DO NOT operate the tool if you are tired or under the inuence of alcohol,
drugs or intoxicating medication.
9 Maintain the tool in good condition.
9 Follow all workshop safety rules, regulations and conditions.
9 Maintain correct balance and footing. Ensure the oor is not slippery and
wear non-slip shoes.
9 Keep children and non essential persons away from the working area.
2. INTRODUCTION
Set of 22 keys for the removal of spline and security ribe locking wheel nuts
on VAG vehicles. Includes 17mm wheel nut socket with 1/2”Sq drive. For
distribution to bona de vehicle dealers and repair centres only.
3. CONTENTS
Component Description Component Description
SX210.01 Locking Wheel Nut Socket 1/2” Dr. VAG SX210.13 Locking Wheel Nut Key. (62/17PT)
SX210.02 Locking Wheel Nut Key. (51/6PT) SX210.14 Locking Wheel Nut Key. (ABC0/10PT)
SX210.03 Locking Wheel Nut Key. (52/7PT) SX210.15 Locking Wheel Nut Key. (ABC1/11PT)
SX210.04 Locking Wheel Nut Key. (53/8PT) SX210.16 Locking Wheel Nut Key. (ABC2/13PT)
SX210.05 Locking Wheel Nut Key. (54/9PT) SX210.17 Locking Wheel Nut Key. (ABC3/14PT)
SX210.06 Locking Wheel Nut Key. (55/10PT) SX210.18 Locking Wheel Nut Key. (ABC4/15PT)
SX210.07 Locking Wheel Nut Key. (56/11PT) SX210.19 Locking Wheel Nut Key. (ABC5/16PT)
SX210.08 Locking Wheel Nut Key. (57/12PT) SX210.20 Locking Wheel Nut Key. (ABC6/17PT)
SX210.09 Locking Wheel Nut Key. (58/13PT) SX210.21 Locking Wheel Nut Key. (ABC7/19PT)
SX210.10 Locking Wheel Nut Key. (59/14PT) SX210.22 Locking Wheel Nut Key. (ABC8/20PT)
SX210.11 Locking Wheel Nut Key. (60/15PT) SX210.23 Locking Wheel Nut Key. (ABC9/21PT)
SX210.12 Locking Wheel Nut Key. (61/16PT)
Refer to
Instructions
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
SX210.V2 Issue 2 (H,2,F) 15/06/23Original Language Version
© Jack Sealey Limited
4. OPERATION
4.1. Choose correct locking wheel nut key for vehicle, and push into socket.
4.2. Place the key over the wheel nut/bolt and rotate until the key slots into the wheel bolt/nut.
4.3. Attach a 1/2” drive socket to the key socket and turn anti-clockwise to remove wheel bolt/nut.
4.4. Replace key and socket in carry case after use.
4.5. To replace bolt/nut reverse removal operation. Use torque wrench to tighten.
5. MAINTENANCE
5.1. Keep keys and adaptor clean and store in case provided.
SX210.V2 Issue 2 (H,2,F) 15/06/23Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
