CUSTOMER SERVICE
Our customer service team is always ready to assist you
if you have any issues or concerns.
IMPORTANT1
Please follow the further recommendations to avoid personal
injury or product damage.
WARNING/ATTENTION
WARNING
Please read the important safeguards carefully before using this
appliance.
ATTENTION
It reminds us that misusing or mishandling may cause hurt.
FORBID
The operation cannot be performedor
forbidden.
FORCE
A certain operation should be
performed (mandatory).
IMPORTANT2
WARNING
Please supervise your children and avoid them from
touching or using appliances.
Do not handle the plug with wet hands.It may cause
electrical shock.
Do not disassemble, repair, or reconstruct the
appliance. It may cause an electric shock, fire
hazard, or getting an injury. Contact the authorized
retailer for item repairing.
Check if the voltage indicated on the appliance
corresponds to the local power voltage before you
connect the appliance. Other electric appliances
used simultaneously may cause the socket to be
hot or cause the fire.
PRODUCT INTRODUCTION3
Dear customer, thank you for choosing AMEIFU air purifier. Please read
this manual carefully before first use.
This product is a small desktop air purifier. The unique appearance design
provides users with an aesthetic experience. Air circulation and purification
are improved by having all sides' air intake and an air output on the top
surface. The unit is compact enough to fit on a desktop and has no
negative impact on the workplace. It absorbs, dissolves, or converts
various air pollutants, thus improving air quality. AMEIFU air purifier
provides consumers with clean and safe air. Small yet powerful!
PRODUCT OVERVIEW4
Top air outlet
Aromatherapy
Fuselage housing
Four air
intakes sides
control panel
Built-in
composite filter
Specifications:
The product name：
Product size：
Packing size:
Gross weight
Adapter length:
Filter Lifespan:
Air purifier
8.6x8.6x13in/ 22x22x33cm
9.8x9.8x14.1/ 25x25x36cm
2. 36KG
1.8m
6 months
Mode of operation:
Adapter input voltage:
Power Supply:
Input current:
Noise Level:
Wind Speed：
Touch Screen
100-240V AC 50/60Hz
24V DC,
1 A
54dB(A)
Three Level
BEFORE USE 5
1. Open the package
2. Take out the unit and the filter.
3. Remove the new filter protective bag before installation.
4. Align the filter locking notches and tighten the filter buckle in the right
direction.
5. Do not block the air inlet and outlet, e.g. by placing items on the airoutlet
or in front of the air inlets closer than 20cm.
6. Check if the voltage indicated on the appliance corresponds to the local
power voltage before you connect the appliance.
7. Please insert the plug into the power socket firmly. After switching the
power on, the indicator light will flash.
Control Panel uses6
Time indicator
Air quality indication
Wind speed indicator
On/Off Button
Auto Mode/Ambient
Light button
Filter alert LED
Wind speed button
Timer/Filter Reset Button
How to use the button
1. ON/OFF Button: Plug in and tap to turn on the air purifier, the air quality
display will light up and the fan will start on level ll.
2. Auto Mode: Tapping the button while the air purifier is in other mode will
exit auto mode, and AUTO indicators light up. Under auto mode, fan speeds will
be selected automatically according to the air quality tested by sensor. Long
press for 3 seconds can turn on/off ambient light.
3. Manual Mode: The air purifier will exit manual mode when not in auto or
sleeping mode. Press to adjust wind speed (1-3 speed).
4. Timer/Filter Reset Button: Press button to enter timer function. Machine
will turn off automatically according to your setting (2,4,8 hours), countdown
timer will be displayed. Long press for 3 seconds can reset the filter. Filter
indicator turning off indicates reset finished.
Overview of filter elements
Rotate the bottom
Composite Filter
ESSENTIAL OIL TRAY
Lift the tray
Add some essential
oil drops and cover it
How to replace the filter element7
Flip the air purifier
over and remove the filter.
Rotate the twist handle
counterclockwise to unlock.
Remove the filter protective
bag before installation.
Place the filter into the air purifier and
install the base cover properly. Tighten the
filter buckle until it clicks into place.
CARE AND MAINTENANCE8
Switch off and unplug the appliance if you are cleaning the appliance or when it is
not in use for a long time.
Reference for the filter cleaning and maintenance frequency: ~ once a month.
Never use abrasive objects which could damage your appliance's appearance.
Clean the appliance with a soft, dry cloth.
Never use abrasive cleaning agents, scourers, acetone or petrol to clean the
appliance.
Switch off the appliance and unplug it from the wall outlet before cleaning.
Never immerse the motor base in water or place it under running water to avoid
the risk of electric shock.
The filter is easily damaged and deformed. Please do not press or pull it forcefully
during cleaning.
If it is damaged, replace the filter with a new one.
1.Replace the filter every 3-6 months. It varies depending on the area and ambient
air quality. The filter replacement cycle may be reduced in heavily polluted areas,
smoking areas, and etc. When the filtering effect is poor, please replace the filter.
2.Cleaning: Wipe the outer surface, the air inlet and outlet with a wrungsoft cloth.
Do not clean the surface with abrasive cleaning agents.
3.When not in use for a long period: unplug the power adapter, clean the outer
surface and filter. Put it in a plastic bag and store in a low humidity level area.
IMPORTANT9
1. Do not wash or spill this product with liquid.
2. Keep your hands and fingers away from the high-speed wheel component
rotating in the purifier. Avoid foreign objects entering the unit air vent, it may cause
heat or damage to the unit.
3. Do not block the air inlets and outlets. There should be a certain space around
the air purifier.
4. Children shall not play with the air purifier. This appliance can be used by
children.
5. In order to improve the purification effect, close the doors and windows when
using the unit (to avoid carbon monoxide poisoning, properly ventilate when using
a combustion unit).
6. Please do not use any other power adapter than the one provided with the air
purifier.
7. Do not use the appliance in wet, moist areas such as bathrooms, steamy
kitchens, or near swimming pools, otherwise, it may cause an electric shock.
TROUBLESHOOTING10
PROBLEM
The air purifier
produces a strange
smell
No airflow out
of air purifier
Can't feel the effect
POSSIBLE REASON AND SOLUTIONS
The motor is not running-check the power supply,
replace the power adapter or contact the customer
support team.
1.Filter failure-replace the filter.
2.Use in inappropriate places (excessive are
1.The filter is too dirty and has not been replaced for a
long time-replace the filter.
2.Water has entered the filter or the machine has been
used in a humid environment-replace the filter.
3.Reuse after sealed for a period of time-clean the filter,
if it cannot be solved replace the filter.
4.If there is a burning smell-stop using it immediately,
unplug the power supply and contact customer support
team.
EPA. Est.No:101169-CHN-1
