Dierential to Single Ended
Video Converter / Video Noise Filter
RPA-VA1
The RPA-VA1 is a dierential to single ended video converter. It is designed for use when installing an aftermarket
radio into a vehicle that uses a dierential camera. The RPA-VA1 can also be used as a video noise lter in cases
where the camera ground is on a dierent plane than the aftermarket radio, by eliminating the ground loop and xing
distortion such as horizontal lines in the video.
Introduction & Features
Important Notes
1. It is very important that you connect the RPA-VA1 ground wire to the aftermarket radio's ground wire. These two
components sharing the same ground is critical to the noise lter feature.
2. The video input connector has 2 independent wires for when you are connecting to a factory reverse camera. The RCA
end can be cut o and the harness wires connected directly to the vehicle.
Wiring Connection Chart
Black (Ground -)
Red (Acc 12v+)
Video In
Yellow (Video +)
Black (Video -)
Video Out
RPA-VA1
