Crown Sound
Installation Guide
and Users Manual
Integrated with industry-defining technology, the ZLINE Bluetooth
Crown Moldings transform the seamless, elegant ceiling transition
into a Bluetooth sound system, creating the perfect entertainment
area for you and your guests.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
PRODUCT SPECIFICATIONS 2
CROWN SOUND INSTALLATION 3
TROUBLESHOOTING AND FAQ 5
WARRANTY AND DISCLAIMER
Warranty
Bluetooth crown moldings carry a one year parts warranty.
Replacement Speakers
Replacement speakers are available from ZLINE. Call 1-614-777-5004.
1
All electrical wiring must be properly installed, insulated, and grounded.
Use this unit only in the manner intended by the manufacturer. If you have any questions,
contact the vendor.
Important Safety Instructions
2
Product Specifications
Electric Power Rating
Frequency: 110V/50 Hz
Power: 10W
3
Step 1
Attach crown molding bracket to ceiling using hardware provided. Figure 1
Step 2
Attach ducting and electrical connections. Plug the speakers into an outlet behind the
chimney. When the connection is successful, a chime will sound. Figure 2
Figure 2
Crown Sound Installation
Figure 1
Installation Tutorial Video
4
Crown Sound Installation
Step 3
Extend the chimney up to the transformer. Slide the crown molding onto the crown
bracket and secure into place. The crown should cover the gap. Ensure that it installs
properly and is level. Figure 3
Step 4
Open the phone’s Bluetooth settings and find “ZLINE Audio.“ When the connection is
successful, a chime will sound. Figure 4
Figure 3
Figure 4
5
Troubleshooting and FAQ
How many devices can the Bluetooth speakers sync to at a time?
Only 1 device can sync at a time.
What is the decibel rating of the Bluetooth speakers?
Up to 100 decibels.
What is the range of the speakers? What’s the maximum
distance for the connection to work?
Up to 50 feet. If the connection is weak, move closer to the speakers or remove
obstacles that are between the device and the speakers.
“ZLINE Audio” won’t appear in the Bluetooth settings.
Check if the electrical connections are secure. A chime will sound if the connection
is successful. If “ZLINE Audio” still will not appear, call ZLINE at 1-614-5004 for a
replacement.
