OWNER’S MANUAL
Washing Machine
Read This Manual
Use all instructions and explanations of
the installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
application is sold or passed on then ensure
that the new owner always receives those
operation instructions.
MFE70-S1202/A07-EU(A2)
MFE80-S1202/A07-EU(A3)
1
CONTENTS
SAFETY INSTRUCTIONS
Safety Instructions ..................................................
INSTALLATION
Product Description ................................................
Installation ...........................................................
OPERATIONS
Quick Start .............................................................
Before Each Wash ...................................................
Detergent Dispenser ...............................................
Control Panel .........................................................
Option....................................................................
Other Functions ......................................................
Programmes............................................................
Washing Programmes Table .....................................
MAINTENANCE
Cleaning And Care .................................................
Troubleshooting .....................................................
Technical Specifications .........................................
2
7
8
11
12
13
14
15
15
17
18
19
22
24
Safety Instructions
For your safety,the information in this manual must be followed
to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, personal injury or loss of life.
Explanation of the symbols:
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• If the supply cord is damaged, it must be replaced by the
The electric shock!
2
SAFETY INSTRUCTIONS
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
Warning!
！
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
Note!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Caution!
Warning!
！
3
• The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
• Before any maintenance to the device, unplug the
appliance from the mains.
• Always unplug the machine and turn off the water
supply after use. The max inlet water pressure is 1MPa.
The min inlet water pressure is 0.05MPa.
• To ensure your safety, power plug must be inserted into
an earthed three-pole socket. Check carefully and make
sure that your socket is properly and reliably earthed.
• Make sure that the water and electrical devices must
be connected by a qualified technician in accordance
with the manufacturer's instructions and local safety
regulations.
Risk to children!
from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
•
• Children of less than 3 years should be supervised to
ensure that they do not play with appliance.
• Animals and children may climb into the machine. Check
the machine before every operation.
• Kids should be supervised that they do not play with
the appliance.
The appliance can be used by children aged
SAFETY INSTRUCTIONS
4
• Remove all packaging and transport bolts before using
the appliance. Otherwise, serious damage may result.
• Glass door may be very hot during the operation. Keep
kids and pets far away from the machine during the
operation.
• Plug must be accessible after installation.
Risk of explosion!
•
•
Do not wash or dry articles that have been cleaned in, washed
in, soaked in, or dabbed with combustible or explosive
substances(such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene, etc.) This may result in
fire or explosion.
Before machine wash, rinse/wash item of clothing
thoroughly by hand.
• This washing machine is for indoor use only.
• This unit is not intended to be built-in.
• The openings must not be obstructed by a carpet.
• Washing machine shall not be installed in a bathroom or
very wet rooms as well as in rooms with explosive
substances.
• The washing machine with single inlet valve only can be
connected to the cold water supply.
• Plug must be accessible after installation.
Installing the product!
SAFETY INSTRUCTIONS
Caution!
5
• Remove all packaging and transport bolts before using
the appliance. Otherwise, serious damage may result.
Risk of damaging appliance!
• Your product is only for home use and is only designed
for the textiles suitable for machine washing.
• Do not climb up and sit on top cover of the machine.
• Do not lean against machine door.
• Cautions during Handling Machine:
1.Transport bolts shall be reinstalled to the machine by
a specialized person.
2.The accumulated water shall be drained out of the
machine.
3.Handle the machine carefully. Never hold each protruded
part on the machine while lifting. Machine door can
not be used as the handle during the conveyance.
4.This appliance is heavy. Transport with care.
• Please do not close the door with excessive forces. If it
is found difficult to close the door, please check if the
clothes are put in or distributed well.
• It is forbidden to wash carpets.
Operating the appliance!
• Before washing clothes for the first time, it is recommended
to do a self clean.
• Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc. shall not be used as detergents.
Please only select the detergents suitable for machine
washing, especially for drum.
SAFETY INSTRUCTIONS
6
• Make sure that all pockets are emptied. Sharp and rigid
items such as coin, brooch, nail, screw or stone etc. may
cause serious damages to this machine.
• Please check whether the water inside the drum has
been drained before opening its door.Please do not open
the door if there is any water visible.
• Be careful of burning when the product drains hot
washing water.
• Never refill the water by hand during washing.
• After the program is completed, please wait for two
minutes to open the door.
This marking indicates that this product should not be
disposed with other household wastes.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,recycle
it responsibly to promote the sustainable reuse of
material resources.To return your used device, please use
the collection systems or contact the retailer where the
product was purchased. They return and can take this
product for environmental safe recycling.
Packaging/Old appliance
SAFETY INSTRUCTIONS
7
Product Description
• The product line chart is for reference only, please refer to real product as
standard.
Note!
Drum
Power supply cord
Control panel
Detergent dispenser
Service filter
Door
Water supply hose
Top cover
Drain hose
INSTALLATION
Installation
Before installing the machine, the location characterized
follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0℃
5.Keep far away from the heat resources such as coal or gas.
as
Unpacking the washing machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Make sure the small triangle
foam is removed with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
Please take the following steps to remove the bolts:
1.Loosen 4 bolts with spanner and then remove them.
2.Stop the holes with transport hole plugs.
3.Keep the transport bolts in a safe place for future use.
Remove transport bolts
•
•
Stability is important to prevent the product from
wandering!
Make sure that the product should not stand on
the power cord.
Warning!
！
•
•
Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
There is a risk of suffocation ! Keep all packaging
well away from children.
Warning!
！
•
• product
you
You must remove the transport bolts from the backside before using the product.
You’ll need the transport bolts again if you move the , so make sure
keep them in a safe place.
Warning!
！
8
INSTALLATION
w
w
W> 20mm
Installation area
1.Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions tighten the nuts.
2.Loosen the lock nut turn the feet until it closely contacts with the floor.
3.Adjust the legs and lock them with a spanner, make sure the machine is steady.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Connect Water Supply Hose
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1.Connection between ordinary tap and inlet hose.
• To prevent leakage or water damage, follow the instructions in this chapter
Do not kink, crush, modify or sever .
!
• water inlet hose
• Energy consumption will decrease automatically for some program.
2
3
4
1
Raise
Lower
Lock nut
foot
Warning!
！
Warning!
！
9
9
INSTALLATION
Loosen clamp nut and
four bolts
Tighten clamp nut Press slide bushing,
insert inlet hose into
connecting base
slide bushing
2
3
41
Connection finished
clamp nut
Tap with threads and inlet hose
Special tap for washing machine
2.Connection between screw tap and inlet hose.
slide bushing
10
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
Mi
n.
6
0c
m
1
0
0c
m
Max
.
Warning!
！
Warning!
！
10
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
Before washing, please make sure it’s installed properly.
.
•
• It is recommended that you "Drum Clean" before washing for the first time
1. Before Washing
The door lock and the [Start / Pause ] lights flash with the buzzer beeping or two small
points flash on the digital screen.
Open tap
Load
Close door
Plug in
Add detergent
Quick Start
3. After Washing
• Detergent need to be added in "case I “after selecting pre-wash for machines
with this function.
1 2 3 4 5
2. Washing
Select function or
default
•
• 2.The function button line chart is for reference only, please refer to real product
as standard.
If default is selected, step 2 can be skipped.
Note!
Note!
Caution!
10
11
OPERATIONS
Select Programme
Start up
1 2 3
Main
wash
Prewash
Softener
10
12
Knot long strings, Zip zippers
or button up buttons
• When washing a single clothing item, it may easily cause great eccentricity and give
alarm due to great unbalance. Therefore it is suggested to add one or two
more items clothes to be washed together so that draining can be done smoothly.
• Don't wash the clothes touching with kerosene, gasoline, alcohol and
other flammable materials.
• The working condition of the washer should be(0-40)°C.If used under 0°C,the
inlet valve and draining system may be damaged. If the machine is placed under
condition of 0°C or less, then it should be transferred to normal ambient
temperature to ensure the water supply hose and drain hose are not frozen
before use.
• Please check the labels and the explanation of using detergent before wash. Use
non-foaming or less-foaming detergent suitable for machine washing properly.
Take out the items out of
the pockets
Put small clothes into the
pillow slip
Check the label
Before Each Wash
Turn easy-pilling and
long-pile fabric inside out
Separate clothes with
different textures or colors
Warning!
！
OPERATIONS
Detergent Dispenser
Prewash detergent
Main wash detergent
Softener
II
I
Pull out the dispenser
Liquid detergent
Powder detergent
Caution!
• Detergent only need to be added in "case I “after selecting pre-washing
for machines with this function.
10
13
OPERATIONS
Dam-board
Dam-board
Means must ○ Means optional
Programme
Cotton Eco 40 °C
Cotton Eco 60 °C
Cotton
Cotton 20 °C
Cotton 30 °C
Cotton 40 °C
Cotton 60 °C
Cotton 90 °C
Synthetic
Synthetic 40 °C
Synthetic 60 °C
Drum Clean
Cold Wash
Cold Wash 20 °C
Programme
Spin Only
Drain Only
Rinse&Spin
Delicate 30 °C
Delicate
Ends in 9H
Ends in 6H
Ends in 3H
Daily Wash 45'/Quick Wash 45'
Daily Wash 30'/Quick Wash 30'
Daily Wash 15'/Quick Wash 15'
ECO 40-60
Cotton Intensive 40 °C
Cotton Intensive 60 °C
Press 3 se c.
Press 3 se c.
Drum Clean
Control Panel
10
14
OPERATIONS
3
1
1
1
2
4
Off
Product is switched off.
Start/Pause
Press the button to start or pause the
washing cycle.
Programmes
Available according to the laundry type.
Option
This allows you to select an additional
function and will light when selected.
1
1
3
1
2
4
Note!
The chart is for reference only, Please refer to real product as standard.•
Prewash: The Prewash function can get an extra wash before main wash,it is suitable for washing as
the dust rises to surface of the clothes;You need to put detergent into the Case (I) when select it.
Extra Rinse: The laundry will undergo extra rinse once after you select it.
No Spin: It will not spin if you choose this function.
Option
OPERATIONS
Programme Option
Cotton Eco 40 °C
Cotton Eco 60 °C
Cotton/Normal
Cotton/Normal 20 °C
Cotton/Normal 30 °C
Cotton/Normal 40 °C
Cotton/Normal 60 °C
Cotton/Normal 90 °C
Synthetic
Synthetic 40 °C
Synthetic 60 °C
Drum Clean
Cotton Intensive 40°C
Cotton Intensive 60°C
Programme Option
Drain Only
Rinse&Spin
Delicate 30 °C
Delicate
Ends in 9H
Ends in 6H
Ends in 3H
Daily Wash 45'/Quick Wash 45'
Daily Wash 30'/Quick Wash 30'
Daily Wash 15'/Quick Wash 15'
Spin Only
Cold Wash
Cold Wash 20 °C
ECO 40-60
Prewash Extra Rinse
Prewash Extra Rinse
Delay:
Delay function can be set with this button, the delaying time is 0-24H.
It can be set the spin speed to press the button repeatedly
Spin Speed:
10
15
○ Means optional
User choose this function to run “Mix 40°1000rpm 59min" program directly .
M-wash/Easy-wash:
Other Functions
Press the [Prewash]/ button for 3sec.the buzzer is mute.[Delay]
Mute the buzzer
Prewash
To activate the buzzer function, press the button again for 3 seconds. The setting until
the next reset.
will be kept
Press 3 sec.
Choose the Programme
/
Delay
Press 3 sec.
• MuAfter ting the buzzer function, the sounds will not be activated any more.
Caution!
OPERATIONS
Programme Default Speed(rpm)
Cotton Eco 40 °C
Cotton Eco 60 °C
Cotton/Normal
Cotton/Normal 20 °C
Cotton/Normal 30 °C
Cotton/Normal 40 °C
Cotton/Normal 60 °C
Cotton/Normal 90 °C
Synthetic
Synthetic 40 °C
Synthetic 60 °C
Drum Clean
Cold Wash
Cotton Intensive 40 °C
Programme
Default Speed(rpm)
Spin Only
Drain Only
Rinse&Spin
Delicate 30 °C
Delicate
Ends in 9H/Mix 60 °C
Ends in 6H/Mix 40 °C
Ends in 3H/Mix
Daily Wash 45'/Quick Wash 45'
Daily Wash 30'/Quick Wash 30'
Daily Wash 15'/Quick Wash 15'
ECO 40-60
Cold Wash 20 °C
800 1000 1200/1300
800
800
800
800
800
800
800
800
800
800
800
400
800
800
1000
1000
1000
1000
1000
800
800
800
1000
1000
1000
400
1000
1000
1000
-
1000
600
600
1000
1000
1000
800
800
800
1000
1000
1000
1200/1300
1200/1300
1200
1200
1200
1200
1200
1200
1000
1000
1000
400
1200
-
1200
600
600
1000
1000
1000
800
800
800
800
-
800
600
600
800
800
800
800
800
800
800
800
800
800 1000 1200/1300
Child Lock
To avoid mis operation by children.
Start
Press [Extra Rinse] and [No Spin]/
/ 3 sec. till buzzer beep.[Spin Speed] [Prewash]
Extra
Rinse
No
Spin
Temp.
s: ,The temperature i Cold,20 30 , 40 ,60 ,90°C °C °C °C °C
Speed
:The speed is
800: 0-400-600-800 1000: 0-400-600-800-1000 1200: 0-400-600-800-1000-1200
Choose the
Programme
Spin
speed
/
Cut off the power supply , the Child Lock protection is to be released.
• Press the two buttons for 3 sec. also to be release the function.
• The “Child Lock” will lock all buttons except [OFF ].
•
• If you want to change the program on child lock condition, you should unlock
the child lock first, then rotate the knob to OFF position, finally choose the
program you want.
Caution!
16
1300: 0-400-600-800-1000-1200-1300
Cotton Intensive 60 °C
Pre
wash
/
OPERATIONS
Programmes
Cotton/
Normal
Synthetic
Daily Wash
Cotton Eco
Ends in
Delicate
Drum Clean
Spin Only
Rinse&Spin
Drain Only
Hard-wearing textiles, heat-resistant textiles made of cotton or
linen.
Wash synthetic articles, for example: shirts, coats, blending.
While washing the knitting textiles, detergent quantity shall be
reduced due to its loose string construction and easily forming
bubbles.
It is suitable for washing few and not very dirty clothes quickly.
To increase the washing effects, washing time is increased.
The function can be set with this programme,the total time
including washing time and delaying time is 3h,6h or 9h.
For delicate, washable textiles, e.g. made of silk, satin, synthetic
fibres or blended fabrics.
It applys 90 °C high temperature sterilization to make the
clothes washing more green. When this procedure is performed,
the clothes or other washing cannot be added. When proper
amount of chlorine bleaching agent is put in,the barrel cleaning
effect will be better. The customer can use this programme
regularly according to the need.
Extra spin
Extra rinse with spin.
Drain off the water.
Programmes are available according to the laundry type.
Programmes
Mix You can select this procedure wash the tough clothes, that need much
more time and strength .It is used for the daily clothes of cotton,such
as sheets, chains, pillowcases bathrobe and underwear.
Quick Wash
To increase the washing effects, washing time is increased.
ECO 40-60 Default 40℃,not selectable,suitabale for laundry washing at about
40℃-60℃.
Cold Wash Cold water to wash clothes
It is suitable for washing few and not very dirty clothes quickly.
Cotton Intensive
10
17
• The EU energy efficiency class is A++ for 7kg,A+++ for 8kg
Energy test program: Cotton Eco 60°C/40°C.Speed: the highest speed; Other as the default.
Half load for 7.0/8.0Kg machine:3.5/4.0Kg.
“Cotton Eco 60°C/40°C ” is the standard washing programs to which the information in the label and
the fiche relates,
• The AR energy efficiency class is A
Energy test program: Cotton ECO 40°C.Speed: the highest speed; Other as the default.
and they are suitable to clean normally soiled cotton laundry and that they are the
most efficient programmes in terms of combined energy and water consumptions for washing that
type of cotton laundry,that the actual water temperature may differ from the declared cycle temperature.
• The parameters in this table are only for user's reference. The actual parameters may be
different with the parameters in above mentioned table.
Note!
OPERATIONS
Programme
Load(kg) Default Time
Washing Programmes Table
Cotton Eco 40 °C
Cotton Eco 60 °C
Cotton
Cotton 20 °C
Cotton 30 °C
Cotton 40 °C
Cotton 60 °C
Cotton 90 °C
Synthetic
Synthetic 40 °C
Synthetic 60 °C
Drum Clean
Spin Only
Drain Only
Rinse&Spin
Delicate 30 °C
Delicate
Ends in 9H
Ends in 6H
Ends in 3H
Daily Wash 45'
Daily Wash 30'
Daily Wash 15'
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
7.0
3.5
3.5
3.5
-
7.0
-
7.0
2.5
2.5
7.0
7.0
7.0
2.0
2.0
2.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
4.0
4.0
4.0
-
8.0
-
8.0
2.5
2.5
8.0
8.0
8.0
2.0
2.0
2.0
8.0
Default
Temp.(°C)
40
60
Cold
20
30
40
60
90
Cold
40
60
90
-
-
-
30
Cold
40
40
40
30
20
Cold
8.0
1200
3:50
3:20
1:35
1:19
1:20
1:40
1:45
2:40
1:18
1:33
1:43
1:21
0:12
0:01
0:31
1:00
0:55
1:13
1:13
1:13
0:45
0:30
0:15
7.0
1200
3:45
3:23
1:35
1:19
1:20
1:40
1:45
2:40
1:18
1:33
1:43
1:21
0:12
0:01
0:31
1:00
0:55
1:13
1:13
1:13
0:45
0:30
0:15
7.0(AR)
1200
3:28
3:23
1:35
1:19
1:20
1:40
1:45
2:40
1:18
1:33
1:43
1:21
0:12
0:01
0:31
1:00
0:55
1:13
1:13
1:13
0:45
0:30
0:15
8.0(AR)
1200
3:30
3:20
1:35
1:19
1:20
1:40
1:45
2:40
1:18
1:33
1:43
1:21
0:12
0:01
0:31
1:00
0:55
1:13
1:13
1:13
0:45
0:30
0:15
10
18
• Before your maintenance starts, please unplug the machine and close the tap.
Cleaning The Cabinet
Cleaning The Drum
Formic acid and its diluted solvents or equivalent are forbidden, such as
solvents or chemical products,etc.
•
alcohol,
• Don’t put laundry in the washing machine during the drum cleaning.
Cleaning The Door Seal And Glass
Warning!
！
Note!
Note!
Cleaning And Care
The rusts left inside the drum by the metal articles shall be removed immediately
with chlorine-free detergents.
Never use steel wool.
Proper maintenance on the washing machine can extend its
working life. The surface can be cleaned with diluted
non-abrasive neutral detergents when necessary. If there is
any water overflow, use the wet cloth to wipe it off immediately.
No sharp items are allowed.
Wipe the glass and seal after each wash
to remove lint and stains. If lint builds up it
can cause leaks.
Remove any coins, buttons and other objects
from the seal after each wash.
MAINTENANCE
10
19
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1
2
3
4
Note!
Note!
Note!
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCE
10
20
• Make sure that valve cap and emergency drain hose are reinstalled properly, cap
plates should be inserted aligning to hole plates otherwise water may leak;
• Some machines don’t have emergency drain hose, rotate lower cover cap directly
to make water run into basin.
• When the appliance is in use and depending on the programme selected there can
be hot water in the pump. Never remove the pump cover during a wash cycle, always
wait until the appliance has finished the cycle, and is empty. When replacing the
cover, ensure it is securely re-tightened.
Cleaning The Drain Pump Filter
Be careful of the hot water!
Allow detergent solution to cool down.
•
•
• Unplug the machine to avoid electrical shock before washing.
• Drain pump filter can filter the yarns and small foreign matters from the
washing.
• Clean the filter periodically to ensure the normal operation of washing
machine.
Warning!
！
Caution!
MAINTENANCE
Open the Service filter
Open the filter by turning
to the counter clockwise
Remove extraneous
matter
1
Close the lower cover cap
3
。
2
4
21
Troubleshooting
The start of the appliance does not work or it stops during operation.
First try to find a solution to the problem, If not, contact the service centre.
Description
Reason
Solution
Restart after the door is closed
Check if the clothes are stuck
Door is not closed properly
Door can’t be
opened
Washer's safety
protection design is working
Disconnect the power, restart
the product
Water leakage
The connection between inlet
pipe or outlet hose is not tight
Check and fasten water pipes
Clean up outlet hose
Clean and wipe the detergent
box
Abnormal noise
Check if the fixing (bolts) have
been removed
it’s installed on a solid
and level floor
Check
Indicator or display
does not light
Disconnect the power
PC board or harness has
connection problem
Check if the power is shut
down and the power plug is
connected correctly
Washing machine
cannot start up
Detergent residues
in the box
Detergent is dampened
or agglomerated
MAINTENANCE
Description
Reason
Solution
Check if the water pressure is
too low
Straighten the water pipe
Check if the inlet valve filter is blocked
Check if the drain hose is blocked
Water injecting
problem while
washing
Overtime water draining
Please try again first, call up
service line if there are still troubles
Others
Water overflow
Restart the washer
Restart after the door is closed
Check if the clothes is stuck
Door is not closed properly
10
24
1022
Off
Off
Flash
Flash
Off
Off
Off
Off
Off
Flash
Off
Off
Off
Off
Off
Flash
Off
Off
Prewash
Extra Rinse
No Spin
Pause/Start
Flash
Off
Off
Off
Off
Off
MAINTENANCE
• After the check, activate the appliance. If the problem occurs again,
contact the service.
Note!
Description
Reason
Solution
Check if the water pressure is
too low
Straighten the water pipe
Check if the inlet valve filter is blocked
Check if the drain hose is blocked
Water injecting
problem while
washing
Overtime water draining
Please try again first, call up service line if there are still troubles
Water overflow
Restart the washer
Restart after the door is closed
Check if the clothes is stuck
Door is not closed properly
E10
E21
Others
E12
E30
10
23
Technical Specifications
MAX.Current
Standard Water Pressure
Power Supply
10A
0.05MPa~1MPa
220-240V~,50Hz
595*495*850
MFE70-S1202/A07-EU(A2)
Dimension
(W*D*Hmm)
7.0kg
Rated PowerNet WeightWashing
Capacity
Model
61kg
1950W
850m
m
5
9
5
mm
D
MAINTENANCE
10
24
595*565*850
MFE80-S1202/A07-EU(A3)-S
8.0kg 68kg 2000W
https://mideasouthafrica.com/
