PerfectAire 1PHCT22 1500/900W Ceramic Dual-Position User Manual

22" VERTICAL OR

HORIZONTAL

OSCILLATING

CERAMIC HEATER

FOR MODEL:

1PHCT22

Before using your heater please read

this manual carefully and keep it for

future reference, along with your receipt.

USER MANUAL

IMPORTANT INSTRUCTIONS

1. Read all instructions before usingtheheater.

2. This heater is hot when in use. To avoid burns, do not letbareskin touch thehot surfaces. If

provided,always use handleswhen moving this heater. Keep combustible materials suchas

furniture, pillows,bedding, papers, clothes and curtains atleast3 feet (1m) from the front of the

heater and keepthemawayfrom the sides and rear.

3. Extreme caution is necessary when any heater is operatedby,orusednear children or individuals

withreducedphysical,sensory,ormentalcapabilities, and whenever the heater is leftoperating

unattended.

4. Always unplug the heater when it'snot in use.

5. Do not operate any heater with a damaged cord or plug orafter the heater malfunctions, has been

dropped or damagedin any manner. Discard, or callcustomerservicebeforeyoureturnthe heater

toauthorizedservice facility for examinationor repair.

6. Do not use the heater outdoors.

7. This heater is not intended for use in bathrooms, laundryareas,or similar moist indoor locations.

Neverlocate theheaterwhereit may fall into a bathtub or other water container.

8. Do not run cord under carpeting, throwrugs, runners, orsimilar coverings. Do not runthecord

underfurniture orappliances. Arrange thecord away from hightrafficareaswhere it will not be

tripped over.

9. CAUTION: This appliance has a polarized plug (one blade iswider than the other). To reduce the

risk ofshock, this plugisintended to fit only one way into a polarized outlet. If theplugdoes not fit

fully into theoutlet, reverse the plug. If it stilldoesnot fit, contact a qualified electrician.DONOT

attempttobypassthissafetyfeature.Doingsocouldresultinanelectricshockhazard.

10. Thisheaterdraws12.5ampsduringoperation.Topreventoverloadingacircuit,donotplugthe

heaterintoacircuitwithotherworkingappliances.

11. CAUTION:Itisnormalfortheplugtofeelwarmtothetouch;however,aloosefitbetweentheplug

andoutletmaycauseoverheatinganddamagetotheplug.Contactaqualifiedelectricianto

replacelooseorbrokenoutlet.

12. Todisconnecttheheater,firstturnitoff,thenremovetheplugfromtheoutlet.Neverpullbythe

cord.

13. Donotinsertforeignobjects-orallowthemtoenter-intoanyventsorexhaustopenings,asthis

maycauseanelectricshock,fire,ordamagetotheheater.

14. Topreventapossiblefire,donotblockairventsinanymanner.Donotusetheheateronsoft

surfaces,likebedsorrugs,wheretheopeningsmaybecomeblocked.

15. Aheaterhashot,arcing,orsparkingpartsinside.Donotuseitintheareaswheregasoline,paint,

orflammableliquidsareeitherstoredorused.

16. Usethisheateronlyasdescribedinthismanual.Anyotherusenotrecommendedbythe

manufacturermaycausefire,electricshock,orpersonalinjury.

17. CAUTION:Alwaysplugheatersdirectlyintoa115~120Vwalloutlet.Neverusewithanextension

cord,adapter,orpowerstrip.

18. Theoutputofthisheatermayvaryanditstemperaturemaybecomeintenseenoughtoburn

exposedskin.Usingthisheaterisnotrecommendedforpeoplewithreducedsensitivitytoheator

aninabilitytoreacttoburnavoidance.

PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS

When using anyelectrical appliances,basic precautions should always be followed to

reduce the risk of fire,electric shock,andpersonal injury,including the following:

MODEL

LOW HIGH

POWERREGULATIONRANGE(W)

1PHCT22

900

1500

UNITSPECIFICATIONS

Powersupply:AC120V~60Hz

LOWSWING HIGHSWING

900

1500

SAVE THESE INSTRUCTIONSFORFUTUREREFERENCE

OPERATINGINSTRUCTIONS

Beforeturningontheheater:

1. Checkthepowercordandplugfordamage.Neveroperatetheunitwithadamagedcord.

2. Plugyourheaterintoagrounded115-120VACoutlet.Besurethevoltageandfrequencyarethe

sameasthevoltageandfrequencylistedontheratinglabel.Otherwise,contactaqualifiedelectrician

toreplaceit.

Grille

FrontCover

PARTSDIAGRAM

ControlPanel

REMOTECONTROL

HeaterOrientation

Thisheaterisdesignedtobeusedineitheraverticalorhorizontalpositionasdesired.Positiontheunit

onaflat,stablesurfaceduringoperation.

On/Off

PlugtheunitdirectlyintothewalloutletandpresstheON/OFFkey(orpresstheON/OFFkeyonthe

remotecontrol)tostarttheheater.Theunitautomaticallystartsinhighheatmodewiththedisplay

showingatemperatureof95°F(35°C).Pressingthebuttonagainwillreturntheunittostandbymode.

Modecontrol

RepeatedlypressingtheModekeyswitchestheheatermodes,inorderfrom:highheat,lowheat,fan

only,ECOmode,thenbacktohighheat.

Temperaturecontrol

Pressing+or-whiletheheaterisonchangesthetemperature,withintherangeof

40-95°F(4-35°C).Whentheroomtemperaturematchesthesettemperature,thedisplayflashesfor10S,

theunitstopsworking,remaininginstandby.Whentheroomtemperaturedropsbelowtheset

temperature,theheaterwillstartagain.

Timerfunction

Thetimercanbesettorunbetween1and24hours.

TimerOff:

Whentheheaterisinoperation,pressTIMERandthenpress+or-keystoincreaseor

decreasethetimerin1hourincrements.TheunitwillturnOFFafterthesetnumberofhours.

TimerOn:

Whentheheaterisinstandbymode,pressTIMERandthenpress+or-keystoincreaseor

decreasethetimerin1hourincrements.TheunitwillturnONafterthesetnumberofhours.

Oscillationfunction

PressingtheOscillationkeywhiletheheaterisonstartstheoscillationfunction;pressingthisbuttonagain

turnstheoscillationfunctionoff.Oscillationstopswhentheunitturnsoff,aswell.

ON/OFF

Mode

IncreaseHeat

DecreaseHeat

Timer

Oscillate

Memory function

Aslongasnopoweroutagesoccur,theunitwillrestartwiththesamesettingitwasinwhenitwasturned

off.Intheeventofapoweroutage,theheaterwillreturnto the factory settings: Startinginthehigh

settingwitha default temperatureof95°F(35°C).

Off screen function

Whentheheaterisinoperation, the screen automatically goes blankafter1minute,

keepingonly the heating logo illuminated. Holding the and buttonsatthesametime for 2 secondsturns

thisfunctionoff. Holding them foranother 2 secondswill turn the Offscreen functionbackonagain.

Short circuitprotection function

Ifatemperaturesensorshortcircuits,anE1orE2errorwillflashonthedigitaldisplayscreenandtheunit

willbeep10times.Thecontrolpanelandremotecontrolkeyswillnotwork.Unplugtheunitandcontact

customerserviceat1-844-472-2473(1-844-4PA-AIRE).

Overheat protection

Thisunitfeaturesathermalshutoffprotectiontopreventoverheating.If the room temperature is above

122°F(50°C), theunitwillstopoperatingandthe displaywillflash 75 times,oncepersecond;the

controlpanelandremotekeys will not work. Toreset,unplugtheheater;waitafewminutesbeforeplugging

itbackinandturningiton.

ECO energy saving Mode

Selecting the modeoption, allowstheheatertoautomaticallyadjusttheheatandpowersettlingsfor

themostcomfortwhileincreasingenergyefficiency. Theunitmayswitchtheheatandfanseveraltimesin

anhourtoreduceenergyconsumption.Themaximumtemperatureinthissettingis79°F(26°C).

Remote control

The remote control key functions are basically the same as the control panelontheunit.

TROUBLESHOOTING

If the heater does notoperate- properly or at all, first check the following list. If the reason the heater

does not operate or does not operate properly is not on the list, it may have failed. Contact customer

serviceat1-844-472-2473(1-844-4PA-AIRE)forfurtherassistance.

Issue



PossibleCause Solution

Theheatermaynotbeplugged

incorrectly.

Makesuretheheateris

pluggedfirmlyintotheoutlet.

Theunitsuddenlystops

workingduringheating.



Thetemperatureexceededthe

threshold for the thermal cut-

oﬀprotection.

Unplugtheheater:allowtheunit

tocoolbeforeturningitbackon.

Aftertheheateristurnedon,it

doesnotwork.

CLEANINGANDSTORAGE

Foroptimalperformance,werecommendcleaningtheheateratleastonceamonth,aswellas

beforestoringfortheoff-season.

TurntheheaterOFFandunplugit.Allowittocool.

Useadryclothtocleantheoutersurfacesoftheheater.

DONOTUSEWATER,WAX,POLISH,ORANYCHEMICALSOLUTION.

Cleanyourheaterusingtheabove-mentionedsteps,thenpacktheheaterinitsoriginalcontainer

beforestoringitinacool,dryplace.

Thisheaterhasnouserserviceablepartsandcannotbedisassembled.

Themotorisfactorylubricatedforlifeandwillrequirenofurtherlubrication.

READANDSAVETHESEINSTRUCTIONS

Perfect Aire, LLC

5401 Dansher Rd.

Countryside, IL 60525

DISTRIBUTED BY:

844-4PA-AIRE | 844-472-2473

www.perfectaire.us

Speciﬁcation and performance data is subject to change without notice.

PA/User_1PHCT22/05042020
