Sealey YKSG50 Safety Guard User Manual

SAFETY GUARD FOR PRESSES

MODEL NO’S: YKGS20, 30, 50, 75

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9  Regularlycheckguardforworn,loose,ordamagedparts.IfyoundanyoftheseconditionsDO NOT USE THE GUARD.

 Failuretodosomaycausesevereinjury!

9 Keeptheguardfreeofdirtanddebris.

8 DO NOTaddtoormodifyanypartoftheguard.Doingsowillvoidyourwarranty.

8 DO NOTusetheguardforpurposesotherthanthoseitwasdesignedfor.

9  Cleanguardwithwaterandmilddetergent.

9  Alwaysrefertothesafetyinstructionsprovidedinyouroorpressinstructionmanual.

 WARNING! Thewarnings,cautionsandinstructionsreferredtointhismanualcannotcoverallpossibleconditionsandsituationsthat

 mayoccur.Itmustbeunderstoodthatcommonsenseandcautionarefactorswhichcannotbebuiltintothisproduct,butmustbe

 appliedbytheoperator.

2. INTRODUCTION

Lightweightaluminiumframewithtoughsteelmesh.Adjustableguardprotectstheuserand/orpasserbyfrombeinginjuredifworkpieceis

accidentlydislodgedunderload.Boltsontoeithersideofthetableandfeaturesveheightincrements,allowingtheworkpiecetobeplacedonto

tablewithnoobstruction.One-wayspringloadedlockingclipsthenallowtheguardtobepulledupquicklyandsnapstraightintopositionforfull

protection.

3. SPECIFICATION

Model No: ................................................................YKSG20

Applications: ............................................ YK209F, YK20FFP

Model No: ................................................................YKSG30

Applications: .............................YK30F, YK30FAH, YK30FFP

Model No: ................................................................YKSG50

Applications: .........................YK509F, YK509FAH, YK50FFP

Model No: ................................................................YKGS75

Applications: ..........................................YK759F, YK759FAH

4. ASSEMBLY/ OPERATION

4.1.  Choosewhichsideoftheoorpresstottheguard,xtheguardsupportbracketstothe

 tableusingthepre-drilledholesandxingsprovided.Seegs.1&2.

 Ensurethebracketsarettedwiththelocksontheoutsideandthecorrectwayupasg.1.

Refer to

instruction

manual

YKSG20,30,50,75Issue:2(H,F)07/04/22

Original Language Version

©JackSealeyLimited

Guard Support Guard Support

BracketFixingsBracketFixings

Ensure The Correct Ensure The Correct

OrientationOfTheOrientationOfThe

LockingMechanismLockingMechanism

Rear Rear

ViewOfViewOf

BracketBracket

FixingsFixings

g.1

g.2

4.2.  Taketheguardandslideitintothebracketsfromabove;theguardhasastoponeithersideatthetopoftheframe,thisshouldbe

 uppermostandfacingtowardstheoperatorg.3.

4.3.  Pullthelocksbackoneithersideandlowertheguardallthewaydown.

CAUTION! Theguardwilldropfreelyuntilitreachesthestops.

4.4.  Toraisetheguardtooneoftheveheightincrements,pulluptheguardandthespringloadedlockingclipswillsnapintopositionat

 thedesiredheight.

Original Language Version

Guard Stops

Uppermost

fig.

YKSG20,30,50,75Issue:2(H,F)07/04/22

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
