Electric Log Splitter

HPS2600E

User Manual

[Revision 8.0 December 2023]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY

DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by

this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

Electric Log Splitter - HPS2600E

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

• Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

• Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory or

mental capabilities.

General Fuel Safety

• Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

• Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors and

vents.

General Equipment Use and Care

• The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

General Electrical Safety

• Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

• Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

• The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

LOG SPLITTER SAFETY

UNDERSTAND YOUR LOG SPLITTER. Read and understand the owner's manual and labels affixed to the log splitter. Learn its application and

limitations as well as the specific potential hazards peculiar to it

DRUGS, ALCOHOL AND MEDICATION. Do not operate the log splitter while under the influence of drugs, alcohol, or any medication that could

affect your ability to use it properly.

AVOID DANGEROUS CONDITIONS. Put the log splitter on a 60 - 75cm high, stable, flat, and level work bench where there is plenty of room for

handling, and help the operator stay alert. Bolt the log splitter to the work surface if it tends to slip, walk, or slide. Keep your work area clean and

well lighted. Cluttered areas invites injuries. Do not use the log splitter in wet or damp areas or expose it to rain. Do not use it in areas where fumes

from paint, solvents or flammable liquids pose a potential hazard.

INSPECT YOUR LOG SPLITTER. Check your log splitter before turning it on. Keep guards in place and in working order. Form a habit of checking

to see that keys and adjusting wrenches are removed from tool area before turning it on. Replace damaged, missing or failed parts before using it.

DRESS PROPERLY. Do not wear loose clothing, gloves, neckties or jewellery (rings, wristwatches). They can be caught in moving parts. Protective

electrically nonconductive gloves and non-skid footwear are recommended when working. Wear protective hair covering to contain long hair,

preventing it from get caught in machinery.

PROTECT YOUR EYES AND FACE. Any log splitter may throw foreign objects into the eyes. This can cause permanent eye damage. Always wear

safety goggles. Everyday eyeglasses have only impact resistant lenses. They are not safety glasses. Do not put the log splitter on the ground for

operations. This is awkward operating position that the operator has to bring his face close to the machine, and thus risks being struck by wood

chips or debris.

EXTENSION CORDS. Improper use of extension cords may cause inefficient operation of the log splitter which can result in overheating. Be sure

the extension cord is no longer than 1 Om and its section is no less than 2.5mm2 to allow enough current flow to the motor. Avoid use of free and

inadequately insulated connections. Connections must be made with protected material suitable for outdoor use.

AVOID ELECTRICAL SHOCK. Check that the electric circuit is adequately protected and that it corresponds with the power, voltage and frequency

of the motor. Check that there is a ground connection, and a regulation differential switch upstream. Ground the log splitter. Prevent body contact

with grounded surfaces: pipes, radiators, ranges, and refrigerator enclosures. Never open the pushbutton box on the motor. Should this be

necessary, contact a qualified electrician. Mark sure your fingers do not touch the plug's metal prongs when plugging or unplugging the log splitter.

KEEP VISITORS AND CHILDREN AWAY. The log splitter must always be operated by one person only. Other people should keep a safe distance

from the work area, especially when the log splitter is operating. Never ask other people to help you with freeing a jammed log.

INSPECT YOUR LOG. Make sure there are no nails or foreign objects in the logs to be split. The ends of the logs must be cut square. Branches

must be cut of flush with the trunk.

DON’T OVERREACH. Floor must not be slippery. Keep proper footing and balance at all times. Never stand on log splitter. Serious injury could

occur if the tool is tipped or if the cutting tools is unintentionally contacted. Do not store anything above or near the log splitter where anyone might

stand on the tool to reach them.

AVOID INJURY FROM UNEXPECTED ACCIDENT. Always pay full attention to the movement of the log pusher. Do not attempt to load the log on

until the log pusher has stopped. Keep hands out of the way of all moving parts.

PROTECT YOUR HANDS. Keep your hands away from splits and cracks which open in the log. They may close suddenly and crush or amputate

your hands. Do not remove jammed logs with your hands.

DON'T FORCE THE TOOL. It will do a better and safer job at its design rate. Never try to split logs larger than those indicated in the specifications

table. This could be dangerous and may damage the machine. Don’t use log splitter for a purpose for which it was not intended.

NEVER LEAVE TOOL RUNNING UNATTENDED. Don't leave tool until it has come to a complete stop.

DISCONNECT POWER. Unplug when not in use, before making adjustments, changing parts, cleaning, or working on the log splitter; Consult

technical manual before servicing.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

PROTECT THE ENVIRONMENT. Take used oil to an authorized collection point or follow the stipulations in the country where the log splitter is

used. Do not discharge into drains, soil or water.

MAINTAIN YOUR LOG SPLITTER WITH CARE. Keep the log splitter clean for best and safest performance.

MAKE THE WORKSHOP CHILDPROOF. Lock the shop. Disconnect master switches. Store the log splitter away from children and others not

qualified to use it.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Table of Contents

Safety ............................................................................................................................................................. 2

Safety Symbols ........................................................................................................................................................... 5

Parts Identification ....................................................................................................................................... 8

Controls and Features ................................................................................................................................................ 8

Parts Drawing and Parts List ...................................................................................................................................... 9

Assembly ..................................................................................................................................................... 12

Operation ..................................................................................................................................................... 13

General Operation .................................................................................................................................................... 13

Freeing a Jammed Log ............................................................................................................................................. 14

Maintenance ................................................................................................................................................ 16

Replacing the Hydraulic Oil ...................................................................................................................................... 16

Sharpening the Wedge ............................................................................................................................................. 16

Troubleshooting ......................................................................................................................................... 17

Specifications ............................................................................................................................................. 18

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Parts Identification

Controls and Features

No. Name No. Name No. Name

1

Log pusher

6

Log-retaining plates

11

Hydraulic control lever

2

Worktable

7

Switch

12

Control lever guard

3 Wedge 8 Motor 13 Bleed screw

4 Lift handle 9 Push button control box 14 Oil drain bolt w/ dipstick

5 Support leg 10 Wheels (for minor moving only) 15 Max. pressure limiting screw

Spare parts available

for purchase, scan QR

code below:

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Parts Drawing and Parts List

NO. NAME NO. NAME

1 Lever Mount Nut 53 Flat Washer

2 Nut Cap 54 Screw

3 Lever 55 Wheel cover

4 Lever Knob 56 R clip

5 Guard Plate 57 Wheel

6 Nut 58 Washer

7 Copper Gasket 59 Wheel shelf

8 Screw 60 Bolt

9 O-ring 61 Spring Washer

10 Snap Washer 62 Washer

11 Valve Retract Spring 63 Gear Pump Cover

12 O-ring 64 O-ring

13 Valve Core Rod 65 Gear Housing Plate

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

NO. NAME NO. NAME

14 Sliding Pressure Sensor Sleeve 66 Circlip

15 Sliding Pressure Sensor Sleeve Spring 67 Gear Shaft

16 Aluminium Cover (Rear) 68 Steel Ball

17 O-ring 69 Gear

18 Piston 70 Pin

19 Piston Ring 71 Washer

20 O-ring 72 Bolt

21 Spring 73 Motor Cover

22 Stud 74 Seal

23 Hydraulic Cylinder 75 Nut

24 Aluminium Cover (Front) 76 Screw

25 Piston Rod Seal 77 Motor

26 O-ring 78 cooler

27 Wing Bolt 79 Block turn

28 washer groupware 80 cool cover

29 Dipstick 81 Spring Washer

30 Piston Rod 82 Cross headed Screw

31 Lift Handle 83 Leg groupware

32 Screw 84 Nut

33 Frame Tube 85 Bolt

34 Lead plank 86 Pin

35 Spring Washer 87 Nut

36 Screw 88 prevent out

37 Nut 89 Abnormity Bolt

38 Flat Washer 90 Screw

39 Nut 91 Switch Box cover

40 Nut Plug 92 Airproof underlay

41 washer groupware 93 Connection Terminal

42 Valve Sleeve 94 Capacitor

43 O-ring 95 Switch

44 Adjusting Screw 96 Switch Box

45 Steel Ball 97 Waterproof underlay

46 Pressure Limited Valve Spring 98 Motor Support Left Shoe

47 Adjusting Screw 99 Motor Support Right Shoe

48 Log Pusher Connection Weldment 100 Pin

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

NO. NAME NO. NAME

49 Plastic Insert 1 101 O-ring

50 Plastic Insert 2 102 Sliding Sleeve

51 Log Pusher 103 Bolt

52 Nut 105 Flat washer

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Assembly

Contents supplied:

•

Frame assembly

•

R clip x 2

•

Wheel x 2

•

Flat washer x 2

•

Wheel cover x 2

Wheel Assembly

1. Slide the wheel followed with a flat washer onto the wheel

axle, then install the R clip. Using pliers, bend the ends of the

R clip to secure the wheel in place. Insert wheel cover by

pressing into wheel until it is secured.

2. Repeat for the second wheel.

Log Splitter Assembly

1. Bolt the Support Leg to the Log Splitter, lift the log splitter by the handles at both ends and place it on a 60 -

75cm high, stable, flat and level work surface.

2. Familiarise yourself with the controls and features of this log splitter in the Parts Identification section.

IMPORTANT!  Before operating the log splitter, the Bleed

Screw should be loosened by some rotations until air can go in

and out of the oil tank smoothly.  Air flow thru the Bleed Screw hole

should be detectable during the log splitter is under operations.  Before

moving the log splitter, make sure the Bleed Screw is tightened to avoid

oil leaking from this point.

FAILURE TO LOOSEN THE BLEED SCREW WILL KEEP THE

SEALED AIR IN HYDRAULIC SYSTEM BEING COMPRESSED

AFTER BEING DECOMPRESSED. SUCH CONTINUOUS AIR

COMPRESSION AND DECOMPRESSION WILL BLOW OUT THE

SEALS OF THE HYDRAULIC SYSTEM AND CAUSE PERMANT

DAMAGE TO THE LOG SPLITTER. DO NOT ADJUST THE MAX

PRESSURE LIMITING SCREW!

Max. pressure was set beforehand and the max. pressure limiting screw

is sealed with glue to ensure the log splitter works under pressure no

more than 8 tons. The setting was done by a qualified mechanic with

professional instruments. Unauthorised resetting will cause the hydraulic pump to fail to output enough splitting

pressure or RESULT IN SERIOUS INJURY AS WELL AS DAMAGE TO THE MACHINE.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Operation

NOTE: This log splitter is a home use model. It is designed for operating under ambient temperatures

between +5°C and 40°C and for installation at altitudes no more than 1000m above M.S.L. The

surrounding humidity should less than 50% at 40°C. It can be stored or transported under ambient temperatures

between -25°C and 55°C.

General Operation

This log splitter is equipped with a “ZHB” control system that needs to be operated by both hands of the user -

one hand controls the hydraulic control lever while the other hand controls the push-button switch. The log

splitter will stop operating upon absence of either hand. Only upon both hands releasing the controls will the log

pusher start to return backward to its starting position.

Trigger type lock-out device is adopted to avoid accidental Hydraulic Control Lever pushdown. To operate the

Hydraulic Control Lever, draw the Trigger backward with the index finger before pushing the Hydraulic Control

Lever forward.

WARNING! Never force the log splitter for more than 5 seconds by keeping pressure on it to split

excessively hard wood.

After this time interval, the oil under pressure will be overheated and the machine could be damaged. For

extremely hard logs, rotate it by 90° to see whether it can be split in a different direction. In any case, if you are

not able to split the log, this means that its hardness exceeds the capacity of the machine and thus that log

should be discarded to protect the log splitter.

IMPORTANT! Always set logs firmly on the log-retaining plates and worktable. Make sure logs

will not twist, rock or slip while being split. Do not force the blade by splitting the log on the

upper part. This will break the blade or damage the machine.

Break log in the direction of its growing grain. Do not place log across the log splitter for splitting. It may be

dangerous and may seriously damage the machine.

Do not attempt to split 2 pieces of logs at the same time. One of them may fly up and hit you!

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Freeing a Jammed Log

1. Release both controls.

2. After the log pusher moves back and completely stops at its starting position, insert a wedge wood under the

jammed log.

3. Start the log splitter to push the wedge wood to go completely under the jammed one.

4. Repeat above procedure with sharper slope wedge woods until the log is completely freed.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

DO NOT ATTEMPT TO KNOCK THE JAMMED LOG OFF. ATTEMPTING TO KNOCK IT OFF WILL DAMAGE

THE MACHINE OR MAY LAUNCH THE LOG AND CAUSE AN ACCIDENT.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Maintenance

Replacing the Hydraulic Oil

Replace the Hydraulic oil in the log splitter after every 150 hours of use.

Follow these steps to replace it.

1. Make sure all moving parts come to a complete stop and the log

splitter is unplugged from the main power source.

2. Unscrew the Oil Drain Bolt with the Dipstick to remove it.

3. Turn the log splitter on its Support Leg side over its container to drain

off the hydraulic oil.

4. Turn the log splitter on its motor side.

5. Refill with fresh hydraulic oil with the recommended volume.

6. Clean the surface of the Dipstick on the Oil Drain Bolt and put it back

into the oil tank while keeping the log splitter positioned vertically.

7. Make sure the level of the refilled oil is just between 2 grooves

around the Dipstick.

8. Clean the Oil Drain Bolt before threading it back. Make sure it’s

securely fastened to avoid leakage before placing the log splitter

horizontally.

Periodically check the oil level to ensure it is between 2 grooves

around the Dipstick. Oil refilling is required if it goes below this

level.

Recommended Hydraulic Oils:

•

SHELL Tellus 22

•

MOBIL DTE 11

•

ARAL Vitam GF 22

•

BP Energol HLP-HM 22

Sharpening the Wedge

After using the log splitter for some time, you should sharpen the wedge of the log splitter using a fine-tooth file

and smooth out any burrs or crushed areas along its cutting edge.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Troubleshooting

PROBLEM PROBABLE CAUSE REMEDY SUGGESTED

Fails to split logs

Log is improperly positioned.

Refer to Operation section for

proper log loading.

The size or hardness of the log exceeds the

capacity of the machine.

Reduce the log’s size before

splitting it on the log splitter.

Wedge cutting edge is blunt.

Refer to Sharpening Wedge

section to sharpen its cutting

edge.

Oil leaks.

Locate the leak(s) and contact the

dealer.

Unauthorised adjustment was made on the

Max. Pressure Limiting Screw. Lower max.

pressure rating was set.

Contact the dealer.

Log splitter moves jerkily, emits

unfamiliar noise or excessively

vibrates

Lack of hydraulic oil and excessive air in the

hydraulic system.

Check oil level for possible oil

refilling. Contact the dealer.

Oil leaks around cylinder ram or

from other points

Air sealed in hydraulic system while operating.

Loosen Bleed Screw by 3 - 4

rotations before operating the log

splitter.

Bleed Screw is not tightened securely before

moving the log splitter.

Tighten the Bleed Screw securely

before moving the log splitter.

Oil Drain Bolt with Dipstick is not tightly

secured.

Securely tighten the Oil Drain Bolt

with Dipstick.

Hydraulic Control Valve Assembly and/or

seal(s) are worn out.

Contact the dealer.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Electric Log Splitter - HPS2600E

Specifications

Voltage (V/HZ)

240V / 50Hz

Power

2200 w

Max splitting force (ton)

8 Ton

Number of Speed mode

one

Max ram travel (mm)

370mm

Log diameter (mm)

50-250mm diameter

Max log length (mm)

520mm long

Length of bed (mm)

520mm long

Feed time(s)

9

Retract time(s)

6

Cycle Time(s)

16

Protection degree

IP54

Size of wheels

6”

Type of wheels

Solid Wheels

Hydraulic Pressure

20MPa

Hydraulic cylinder size (mm)

55mm

Hydraulic Oil Types

SHELL Tellus 22

MOBIL DTE 11

ARAL Vitam GF 22

BP Energol HLP-HM 22

Hydraulic Oil Capacity (L)

3.2L

Hydraulic Seal

O-ring, Sealant

Safety System

2 hand control

(NOTE: (Dual Redundancy, you need to keep both

hands away from the splitting head to activate it)

Plug

SAA Plug

Frame Material

Metal

Base Material

Metal

Emergency stop

Yes, just release your hands

Noise level (dB(a))

LWA: 80.8 dB(A) w/ load

ZHB System

Yes

Trigger type lock-out device

Yes

Ultra-reinforced drive system

Yes

Carry handle

Yes

Fan

Yes

For more information about selecting the right log splitter view the Buying Guide.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business

or employee, or financially affect the user, business or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement or service by a technician

may cause financial loss, loss of employee time or an

inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

diagrams or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

BAUMR-AG LGSELEBMRA2M6 8 Ton Hydraulic Electric Wood Log Splitter

Product's Documents

Product manual

Specifications

BAUMR-AG LGSELEBMRA2M6 Questions and Answers
