PRODUCT ASSEMBLY
USER'S MANUAL
Patio Deck Cooler Rolling Outdoor
OP2226
TIPS：
Your suggestions and comments for Costway are really important to us!
We sincerely solicit you to go back to our shop and leave a good rating in just a
simple click. It would be quite encouraging if you could kindly do so like below:
February 24, 2018
Great product so far. Fast delivery, easy setup, and working without any issues.
Great products so far
With your inspiring rating, Costway will be more consistent to offer you
EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
UNITED STATES
CANADA
UNITED KINGDOM
GERMANY
FRANCE
ITALY
SPAIN
JAPAN
RUSSIA
AUSTRALIA
US office:Fontana
UK office:Ipswich
ITEM:OP2226
ASSEMBLY INSTRUCTIONS:
Please read the cooler manual carefully and assemble according to following steps.
1.
Please make sure all parts are accounted for before beginning assembly.
2.
Place main basin up-side down on clean soft surface.
3. Attach the 4 legs (part 11)to basin using the 12 M6*16 Bolts (part 10).
4. Place the bottom tray (part 12) over each leg and then screw each caster (parts 13 &15) into the legs with
an open end wrench.
5. Turn over entire assembly right side-up. Press caster brake lever to lock casters (part
13) and attach left
handle (part 4) to main basin using 6 each M6*16 screws (part 10) tighten with wrench. Repeat for right
handle.
6. Attach bottle-cap catcher (part 9) to main basin by sliding it down over 2 pre-installed bolts(part 6).
7. Attach bottle opener (part7) to main basin using 2 each M6*16 screws tighten with the M6 Allen wrench.
8. Attach 2 each lid handles (part 1) to cooler lid (part 2) with 2 each M5*35 screws (part 3) tighten with a
Philips screw driver.
) 9. Clean inside of cool
er completely with soft dry towel. Place cooler lid (part 2) on top of main basin (part 8
your cooler is now ready for use.
Item
Description
Qty
1
Lid Handle
2
2
Lid
1
3
M5*35 Screws
2
4
Handle
2
5
M6*16 Bolts
12
6
M6*16 Bolts
4
7
Bottle Opener
1
8
Basin
1
9
Bottle-cap Catcher
1
10
M6*16 Bolts
12
11
Legs
4
12
Bottom Tray
1
13
Casters with Lock
2
14
M6 Allen Wrench
1
15
Casters without Lock
2
