1
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Additional Safety Information
7 Explanation of Symbols
7 Introduction
8 Description of Parts – Overview
8 Description of Parts – Control Panel
9 Description of Parts – Accessories
9 Control Descriptions
10 Preset Cooking Chart
11 Before First Use of Your Air Fryer
11 Cooking with Your Rotisserie Air Fryer
12 Using the Mesh Trays
13 Using the Rotisserie Basket
15 Using the Rotisserie Skewer
16 Cleaning and Maintenance
17 Cooking Timings, Temperatures and Quantity
17 Degrees Centigrade to Fahrenheit
18 Troubleshooting Guide
19 Technical Specification
19 Plug Wiring Information
19 Recycling Information
20 Customer Support
21 Recipes for You to Try
Back Page Warranty Information
3
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this
manual carefully paying particular attention to the
safety instructions. Failure to do so may result in
personal injury or damage to the product.
Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the product on
to any third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Air Fryer.
• Before plugging your unit into the mains, visually check
that it is intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other such device.
• DO NOT immerse this appliance in water or any other
liquids.
• Cooking appliances should be positioned in a stable
situation with the handles (if any) positioned to avoid
spillage of liquids.
• DO NOT touch hot surfaces. Accessible surfaces
are liable to get hot during use. Always use the
handles provided.
• Oven gloves should be used whilst using this appliance.
• Close supervision is required when using this appliance
near children.
4
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Never leave this appliance within reach of children.
• This appliance shall not be used by children from 0 to 8
years.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years.
• Cleaning and user maintenance shall not be made by
children.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Regular, periodic checks should be carried out on the
supply cord to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the supply cord is damaged it is to be replaced by a
qualified person in order to avoid a hazard.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or
5
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any other
type of hob.
WARNING! Do not attempt to move the air fryer whilst
it is hot or contains hot food or liquids. Turn the
appliance off and disconnect from the mains and let it
cool sufficiently before moving it.
WARNING! Hot steam may be released when opening
and closing the appliance during use. Risk of scalding!
WARNING! Always carry the appliance with both
hands. Always use oven gloves. Burn hazard!
THIS APPLIANCE MUST BE EARTHED
6
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Additional Safety Information
• PLEASE NOTE: Before use, ensure that the Air Fryer is
used in an open, well ventilated area well away from
other appliances and other obstructions.
• Do not use the Air Fryer in front of, near or below
combustible materials such as plastics, curtains or
cupboards, etc.
• Do not place the appliance against a wall or against other
appliances. Leave at least 10cm minimum free space on
the back and sides and 10cm minimum free space above
the appliance.
• Do not place anything on top of the appliance.
The diagram left shows the rear of the air
fryer and the air vent outlets arrowed.
Keep these areas free and clear from
obstructions and any flammable materials
or materials that may be affected by high
temperatures as directed above.
The vent should be at least 230mm (9
inches) away from any obstruction that
may restrict the free flow of air.
Please note that during normal use hot air
will be expelled from the air vent outlet.
7
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk to
find your nearest recycling point.
WARNING!
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface is gets hot and care must
be taken.
Introduction
This Rotisserie Air Fryer cooks using very little or no cooking oil for healthier
cooking.
If a little oil is required for extra browning for example, use a moderate amount of
spray type cooking oil.
WARNING! DO NOT fill your Air Fryer with cooking oil as this will cause a
fire and scolding hazard.
The Air Fryer will quickly cook your food using rapid cycling airflow of hot air.
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
8
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts - Overview
Description of Parts – Control Panel
6
8
2
4
5
7
3
1
9
10
11
12
13
1. Air Inlet
2. Control Panel
3. Air Vent Outlet (rear)
4. Door
5. Viewing Window
6. Non-Slip Feet
7. LED Display
8. Timer Controls
9. Cooking Pre-sets
10. Rotisserie Start/Stop
11. Power/Start/Stop
12. Internal Light On/Off
13. Temperature Controls
14. Heat Indicator
14
9
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts – Accessories
Control Descriptions
LED Digital Display (7)
The display will alternate between temperature and the remaining cooking time.
Timer Controls (8)
• The timer can be set in 1 minute increments up to 90 minutes.
• In dehydrating mode, the Timer can be set in 30 minute increments from 2-24
hours.
• Press the or buttons to increase or decrease the cooking time in 1 or 30
minute increments.
Temperature Controls (13)
• The temperature can be set in 5°C increments from 80°C to 200°C.
• Press the or buttons to increase or decrease the cooking temperature.
Cooking Presets (9)
• Select one of the 10 presets cooking programs from the Preset Cooking Chart
below. The pre-programmed time and temperature will be automatically set.
• Cooking will start 5 seconds after a pre-set has been selected, alternatively,
press the Power/Start/Stop (11) button to start cooking immediately.
• The pre-set cooking programs can be overridden by increasing or decreasing the
Time and Temperature Controls (8 & 13) accordingly.
Rotisserie Start/Stop (10)
Press the Rotisserie Start/Stop (10) button to start and stop the Rotisserie Basket
(c) rotating. This function can be used with any of the Cooking Pre-sets (9).
The rotisserie icon (10) will flash during use.
a
b
c
d
e
a. Mesh Trays x3
b. Rotisserie Basket/Skewer
Tongs
c. Rotisserie Basket
d. Rotisserie Skewer
e. Drip Tray
10
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Power/Start/Stop (11)
After inserting the mains plug into the socket, the Power/Start/Stop (11) icon will
illuminate.
Press the Power/Start/Stop (11) button once and the Control Panel (2) will
illuminate.
Press the Power/Start/Stop (11) for a second time will start the cooking process at
a default temperature of 185°C and a cooking time of 15 minutes.
Pressing the Power/Start/Stop (11) at any time during the cooking process will
stop the appliance, causing the display to switch off immediately.
After use the fan will continue running for 20 seconds to cool the appliance down.
Internal Light (12)
Press the Internal Light (12) button to operate the internal light to help check the
cooking progress through the Viewing Window (5).
The light indicator will keep flashing whilst the Internal Light (12) is on.
After 2 minutes, the Internal Light will go out, however, the indicator will stop
flashing and stay on.
Opening the Door (4) during the cooking process will pause the selection and
also switch on the internal light.
Heat indicator (14)
The Heat Indicator (14) will flash whilst the air fryer is heating.
The indicator will stop flashing and stay on when the temperature has been
reached. This will process will continue during cooking and quite normal.
Preset Cooking Chart
Pre-set (9)
Temperature
Cooking Time
Chips/French Fries
200°C
15 minutes
Steak/Chops
175°C
25 minutes
Fish
165°C
15 minutes
Shrimp
160°C
12 minutes
Pizza
180°C
15 minutes
Chicken
185°C
40 minutes
Baking
160°C
30 minutes
Rotisserie
195°C
30 minutes
Dehydrator
30°C
120 minutes (2 Hours)
Reheat
115°C
12 minutes
11
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking times for meats will vary according to size, weight and personal
preference. Always check the internal temperature of chicken and meats
before eating.
Before the First Use of Your Air Fryer
• Remove all packing materials and discard responsibly.
• Ensure all parts are present see Description of Parts above.
• Check that there is no damage to the mains cable or product.
• Ensure that you clean your Air Fryer before first and every use with a damp cloth
and dry thoroughly.
• Wash all the accessories (a – e) in warm soapy then rinse and dry thoroughly.
• Whilst using your Air Fryer for the first time you may notice a little smoke and
odour; this is normal and is simply the grease used during manufacture and will
soon pass.
Cooking with Your Rotisserie Air Fryer
Place the air fryer on a solid, level, heat resistant surface clear of all obstructions
as described above.
Insert the mains plug into an outlet socket.
12
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using the Mesh Trays (a)
1. Right: Place the Drip Tray (e) at the
bottom of the air fryer to catch any
drips, etc.
2. Left: Place the food to be cooked onto the
Mesh Trays (a) and slide them into the air
fryer. The Mesh Trays (a) are generally for
cooking larger foods such as sausages,
chops, potatoes, vegetables, Falafel,
Chicken pieces, Battered or Breaded Fish,
etc.
3. Close the Air Fryer Door (4). Press the Power/Start/Stop (11) button once to
power the unit up.
4. Select one of the Cooking Presets (9) for the food type to be cooked using the
Preset Cooking Chart above. Cooking will start 5 seconds after a pre-set has
been selected, alternatively, press the Power/Start/Stop (11) button to start
cooking immediately.
5. Alternatively, the pre-set cooking programs can be overridden by increasing or
decreasing the Time and Temperature Controls (8 & 13) accordingly.
Manual Cooking Using the Mesh Trays
1. If the Preset cooking programs are not required, Press the Power/Start/Stop
(11) button once to power the unit up.
2. Set the required cooking time and temperature by increasing or decreasing the
Time and Temperature Controls (8 & 13) accordingly.
3. Once the desired time and temperature are set, press the Power/Start/Stop
(11) button once to start cooking.
The Door (4) can be opened at any point in the cooking process to check the
progress and where necessary turn or shake the ingredients.
The use of Oven gloves is recommended whilst handling the Mesh Trays (a) and
the Drip Tray (e).
After cooking the fan will continue running for 20 seconds to cool the appliance
down, this is quite normal.
e
a
13
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using the Rotisserie Basket (c)
1. Lift the catch and open the door in the end
of the Rotisserie Basket (c) and place the
food to be cooked inside.
2. Do not overfill the basket, fill it a little over
halfway to allow enough room for the food
to tumble and cook efficiently.
3. Place the Rotisserie Basket (c) into the Air
Fryer using the Rotisserie Basket/Skewer
Tongs (b) provided. Ensure that the end of
the Rotisserie Basket mark ‘L’ is on the left.
Follow the below steps to install the
Rotisserie Basket in the Air Fryer:
4. First, tilt the basket up
on the right and insert
the left square shaped
spindle (marked ‘L’ on
the side of the of the
Rotisserie Basket) into
the square drive socket
on the left hand side of
the air fryer, arrowed
right:
5. Secondly, lower the
right spindle (marked
‘R’ on the side of the
of the Rotisserie
Basket) down onto the
bracket on the right
hand side of the air
fryer – ensure the
notch in the spindle
locates in the bracket.
b
L
R
14
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. Once the Rotisserie Basket (c) is installed,
place the Drip Tray (e) at the bottom of the
air fryer to catch any drips, etc, close the Air
Fryer Door (4).
7. Press the Power/Start/Stop (11) button
once to power the unit up.
8. Select one of the Cooking Presets (9) for the
food to be cooked using the Preset Cooking
Chart above.
9. Start the Rotisserie Basket (c) rotating by
pressing the Rotisserie Start/Stop (10)
button. Ensure that the Rotisserie Basket (c)
is rotating freely, if not check that it is
installed correctly – see points 3-5 above.
10. Alternatively, the pre-set cooking programs can be overridden by increasing or
decreasing the Time and Temperature Controls (8 & 13) accordingly.
11. Once the cooking is completed, remove the Rotisserie Basket (c) using the
Rotisserie Basket/Skewer Tongs (b).
Manual Cooking
1. If the Preset cooking programs are not required, Press the Power/Start/Stop
(11) button once to power the unit up.
2. Set the required cooking time and temperature by increasing or decreasing the
Time and Temperature Controls (8 & 13) accordingly.
3. Once the desired time and temperature are set, press the Power/Start/Stop
(11) button once to start cooking.
4. Once the cooking is completed, remove the Rotisserie Basket (c) using the
Rotisserie Basket/Skewer Tongs (b).
The Door (4) can be opened at any point to check on cooking progress.
The use of Oven gloves is recommended whilst handling the Rotisserie Basket
(c) and Rotisserie Basket/Skewer Tongs (b).
After cooking the fan will continue running for 20 seconds to cool the appliance
down, this is quite normal.
NB the Rotisserie Basket (c) is intended for cooking smaller foods such as Chips
(French Fries), Chicken Nuggets, smaller breaded foods (i.e., Fish fingers), etc.
15
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using the Rotisserie Skewer (d)
Attached the Rotisserie Skewer (d) to the Chicken, Joint of meat, etc, by pushing
bar of the Skewer through the food so that it protrudes at either end and the food
is positioned centrally on the bar.
Push the Fork onto the end of the bar, slide the Fork along the bar and push it into
the food so that the food is gripped by the Fork. Once the Fork is in place, tighten
the screw.
Repeat the above process again for the other Fork at the other end of the bar so
that the food is securely mounted centrally between the Forks on the Rotisserie
Skewer (d) as shown above.
Insert the Rotisserie Skewer (d) into the Air Fryer as per the Rotisserie Basket (c)
above except the Rotisserie Skewer (d) can be inserted either way round as it
does not have a Left and Right hand side.
bar
Fork
Fork
Screws
Fork
Screw
Left: Example to show
how a Chicken is
mounted on the
Rotisserie Skewer.
Left: Parts of the
Rotisserie Skewer and
the skewer assembled.
Right: The image right
shows how the Rotisserie
Skewer (d) is mounted in
the air fryer.
16
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Once the Rotisserie Skewer (d) is installed, place the Drip Tray (e) at the bottom
of the air fryer to catch any drips, etc. Close the Air Fryer Door (4).
2. Press the Power/Start/Stop (11) button once to power the unit up.
3. Select one of the Cooking Presets (9) for the food to be cooked using the Preset
Cooking Chart above.
4. Start the Rotisserie Skewer (d) rotating by pressing the Rotisserie Start/Stop
(10) button. Ensure that the Rotisserie Skewer (d) is rotating freely, if not check
that it is installed correctly.
5. Alternatively, the pre-set cooking programs can be overridden by increasing or
decreasing the Time and Temperature Controls (8 & 13) accordingly.
Manual Cooking
1. If the Preset cooking programs are not required, Press the Power/Start/Stop
(11) button once to power the unit up.
2. Set the required cooking time and temperature by increasing or decreasing the
Time and Temperature Controls (8 & 13) accordingly.
3. Once the desired time and temperature are set, press the Power/Start/Stop
(11) button once to start cooking.
The Air Fryer Door (4) can be opened at any point to check on cooking progress.
The use of Oven gloves is recommended whilst handling the Rotisserie Skewer
(d) and Rotisserie Basket/Skewer Tongs (b).
After cooking the fan will continue running for 20 seconds to cool the appliance
down, this is quite normal.
WARNING! Take care whilst handling the Rotisserie Basket, Skewer or
Mesh Baskets. Place on a heat proof surface.
Cleaning and Maintenance of Your Air Fryer
• Always unplug the Air Fryer from the mains supply and allow to cool before
cleaning.
• DO NOT submerge any part of the main body, the mains cable or mains plug in
water or any other liquids.
• Clean the appliance after each use. The rotisserie basket and other accessories
are made of a durable stainless steel and are dishwasher safe.
• Never clean any part of the Air Fryer with harsh or abrasive cleaners.
• Stubborn food should be soaked in warm soapy water, rinse and dry thoroughly.
• Wipe the main body and Viewing Window of the Air Fryer clean using a soft,
damp cloth.
• Clean the inside of the appliance with hot water, a mild detergent and a non-
abrasive sponge.
• After cleaning, allow the product to thoroughly dry before re-use.
17
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking Timings, Temperatures and Quantity
Food Product
Min-Max
Amount (g)
Time
(min)
Temperature
(C)
Shake/
Turn
Additional Information
Chips & Potatoes
Thin Frozen
Chips (French Fries)
200-400
15-20
200
Shake
Thick Frozen
Chips
200-400
20
200
Shake
Home-made
Chips (8x8mm)
200-350
18-25
180
Shake
Add ½ tbsp. of oil
Home-made
Potato Wedges
200-350
18-22
180
Shake
Add ½ tbsp. of oil
Home-made
Potato Cubes
200-400
12-18
180
Shake
Add ½ tbsp. of oil
Rosti
200
15-18
180
Turn
Potato Gratin
500
18-22
180
Meat & Poultry
Steak
100-300
8-14
180
Turn
Pork Chops
100-300
10-14
180
Turn
Hamburger
100-300
7-14
180
Turn
Sausage Roll
100-300
13-15
180
Turn
Chicken
Drumsticks
100-400
18-22
180
Turn
Chicken Breast
100-400
10-15
180
Turn
Frozen Chicken
Nuggets
100-300
6-10
200
Shake
Use oven ready
Snacks
Spring Rolls
100-300
8-10
200
Shake
Use oven ready
Stuffed Vegetables
100-300
10
160
Frozen
Breadcrumbed
Cheese Snacks
100-300
8-10
180
Turn
Use oven ready
Fish
Frozen Fish
Fingers
100-300
6-10
200
Turn
Use oven ready
Degrees Centigrade to Fahrenheit
To change the LED Display (7) to show degrees Centigrade or Fahrenheit, press
and hold the and Temperature Controls (13) and the Timer Control (8)
buttons for 5 seconds as shown below:
18
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Food is
Overcooked/Burnt
Cooking Temperature is
set too high.
Check cooking
temperature and lower
accordingly using the
Temperature Controls
(13).
Cooking time is too long.
Check cooking time and
reduce the cooking time
accordingly using Timer
Controls (8).
Food is not evenly
cooked
Certain foods require
turning or or shaking part
way through cooking
Turn or shake the food as
required
Food is undercooked.
Cooking Temperature is
set too low.
Check cooking
temperature and increase
the Temperature
accordingly using the
Temperature Controls
(13).
Cooking time is too
short.
Check cooking time and
increase the cooking time
using Timer Controls (8).
Unit does not power up
Power/Start/Stop (11)
button has not been
selected.
Press the
Power/Start/Stop (11)
button.
No power to the Air
Fryer.
Check that the mains plug
is inserted into the socket
and the socket is switched
on (if applicable).
The accessory is not
inserted or not pushed
fully home
Ensure the accessory is
inserted and pushed fully
home.
Burning smell from unit
Previous food remains
on Rotisserie Basket,
Mesh Baskets or other
accessories
Ensure all cooking
accessories are cleaned
after each use.
Temperature on the
display has changed
from Celsius to
Fahrenheit
Temperature selection
has been triggered
accidentally.
Press and hold the plus
and minus Temperature
Controls (13) and the
minus Timer Control (8)
buttons on the Control
Panel (2) for 5 seconds.
19
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Rated Voltage
220-240V~ 50/60Hz
Rated Power
1800W
Model Number
SDA1551
Protection Class
I (This appliance must be earthed)
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug-DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk to find your nearest recycling point.
20
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
21
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recipes for You to Try……
• Place the potato strips into the Rotisserie Basket and insert into the Air fryer and set the timer for 15-20 minutes
- depending on the number of fries or until the fries are golden brown.
• Place the chicken wings onto the Mesh Trays, set the time for 15-20 minutes and the temperature for 200 degrees.
1. Asian Spicy Fries
Potato x4 / 600g
Oi 2 teaspoons
Salt 1 teaspoon
Pepper powder 1 teaspoon
Shallot powder 1 teaspoon
Red chili powder ½ teaspoon
● Peel potatoes and cut into strips;
● Soak potato strips in salt water for at
least 20mins, and then dry with kitchen
paper.
● Mix shallot, salt and pepper, garlic
powder/ garlic oil, red chili powder, stir in
the potato strips.
● Set temperature to 180 degrees and time
to 5 minutes to preheat the air fryer.
2. Golden Chicken Wings
Chicken wings 500g
Garlic x2
Ginger powder 2 teaspoon
Cumin powder 1 teaspoon
Black pepper powder 1 teaspoon
Sweet chili sauce 100 mg
● Set temperature to 200 degrees and timer
to 5 minutes to preheat the air fryer.
● Stir garlic, ginger powder, cumin powder,
spicy black pepper and a little salt together,
and then coat the chicken wings.
● Allow the chicken wings to stand for 20
minutes.
22
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Fried chicken nuggets
Fresh chicken nuggets 500g
Eggs x3
Flour 1 cup
Olive oil 1 spoon
White pepper powder 1 teaspoon
● Set the temperature to 200 degrees
and the time to 5 minutes to preheat the
air fryer.
● Stir eggs, flour, olive oil, white pepper
and a little salt together, and then coat
the chicken nuggets.
● Allow the nuggets to stand for 20
minutes.
4. Fried squid
Squid (Frozen) 500g
Oil 2 tablespoon
Salt 1 teaspoon
Cumin powder 1 teaspoon
Chicken powder 1 teaspoon
Pepper powder 1 teaspoon
● Set the temperature to 200 degrees
and the timer to 5 minutes to preheat
the air fryer.
● Stir seasoning together, and then coat
the squid and allow to stand for 20
minutes.
• Place the chicken nuggets into the Rotisserie Basket, set the time for 15-20 minutes and the temperature to 200
degrees.
• Place the squid onto the Mesh Trays, set the temperature for 200 degrees and the time for 12-15 minutes or until
golden brown.
23
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Apply a thin layer of salad oil to the prawns, place the prawns onto the Mesh Trays, set the temperature for 200
degrees and the time for 5-8 minutes or until a golden crunchy layer has formed.
5. Spicy Shrimp
Unfrozen prawns x10
Oil 2 tsp
Garlic finely chopped x1
Black pepper 1 tsp
Chili powder 1 tsp
Sweet chili sauce 100mg
● Set the temperature to 200 degrees
and timer to 5 minutes to preheat the
air fryer.
● Rinse the prawns.
24
Rotisserie Air Fryer
Model No. SDA1551
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
