1. SAFETY
WARNING! Ensure Health & Safety, local authority, and
general workshop practice regulations are adhered to when
using this cabinet.
WARNING! Use caution when handling and assembling the
metal components. The metal may have sharp edges or corners,
the use of protective gloves is recommended.
9 Keep the work area clean, uncluttered and ensure there is
adequate lighting.
9 Keep children and unauthorised persons away from the
working area.
8 DO NOT use the cabinet for any purpose other than that for
which it is designed.
WARNING! The warnings, cautions and instructions referred
to in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that
common sense and caution are factors which cannot be built
into this product, but must be applied by the operator.
2. INTRODUCTION
Manufactured from heavy gauge steel. Supplied flat-packed
saving on high freight cost. Quick and easy to assemble
with all nuts and bolts hidden from view once unit is built up.
Enamel finish helps prevent corrosion. Features a cylindrical
lock for added security. Suitable for site, workshop and home
use.
3. SPECIFICATION
4. ASSEMBLY
FIXED SCREW
4.1.
ATTACH BACK PANEL TO
BASE USING FIXED
SCREWS AS A GUIDE. DO
NOT OVERTIGHTEN
STEEL STORAGE CHEST
MODEL NO'S: SB565, SB765 & SB1200
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY
AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and
properly maintained, give you years of trouble free performance.
Refer to
instruction
manual
SB565, SB765, SB1200 Issue: 6 (3) 23/09/23
Original Language Version
© Jack Sealey Limited
SB565 SB765 SB1200
Width: 565mm 765mm 1200mm
Depth: 350mm 350mm 450mm
Height: 320mm 320mm 360mm
CONTENTS
BACK
BASE
FRONT
LID
SIDES X 2
LOCK CONTENTS
4 X PVC PLUGS
18 X LOCK NUTS
26 X LOCK NUTS
ASSEMBLY TOOL
4.2.
ATTACH FRONT TO BASE USING FIXED SCREWS AS A GUIDE. DO
NOT OVERTIGHTEN
4.4.
ATTACH LID USING FIXED SCREWS AS A GUIDE. DO NOT
OVERTIGHTEN
4.5.
ONCE BOX IS
ASSEMBLED INSERT
PVC PLUGS INTO
EACH OF THE CORNER
HOLES
STEP 2
INSERT LOCK INTO HOLE PROVIDED
STEP 3
ATTACH RETENTION CLIP TO REAR OF LOCK
STEP 4
SCREW LATCH ONTO LOCK BARREL
4.6. LOCK ASSEMBLY. STEP 1
DISASSEMBLE LOCK (UNSCREW)
4.3.
ATTACH BOTH SIDES USING FIXED SCREWS AS A GUIDE. DO
NOT OVERTIGHTEN
Environmental Protection
Recycle unwanted materials instead of disposing of
them as waste. All tools, accessories and packaging
should be sorted, taken to a recycling centre and
disposed of in a manner which is compatible with the
environment.
When the product becomes completely unserviceable
and requires disposal,
dispose of the product according
to local regulations.
SB565, SB765, SB1200 Issue: 6 (3) 23/09/23
Original Language Version
© Jack Sealey Limited
Parts support is available for this product. To obtain a parts listing
and/or diagram, please log on to www.sealey.co.uk, email:
sales@sealey.co.uk or telephone 01284 757500.
SB565, SB765, SB1200 Issue: 6 (3) 23/09/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 24 months from purchase date, proof of which is required for any claim.
