AXISP3925-RNetworkCamera

UserManual

AXISP3925-RNetworkCamera

TableofContents

Aboutthismanual..........................................3

Getstarted................................................4

Chooselens....................................................4

Findthedeviceonthenetwork....................................4

Accessthedevice...............................................4

Webpageoverview..............................................5

Additionalsettings..........................................7

Adjusttheimage................................................7

Adjustthecameraview(PTZ)......................................11

Viewandrecordvideo............................................12

Setuprulesandalerts...........................................13

Cleaningrecommendations...................................17

Learnmore................................................18

Viewarea......................................................18

Capturemodes.................................................18

Privacymasks..................................................18

Overlays.......................................................19

Pan,tilt,andzoom(PTZ)..........................................19

Streamingandstorage...........................................19

Applications....................................................21

Troubleshooting............................................23

Resettofactorydefaultsettings...................................23

Firmwareoptions...............................................23

Checkthecurrentrmware.......................................

Upgradethermware............................................24

Technicalissues,cluesandsolutions................................

Performanceconsiderations.......................................

Contactsupport.................................................26

Specications..............................................27

Productoverview................................................

SDcardslot....................................................

Buttons.......................................................

Connectors....................................................

AXISP3925-RNetworkCamera

Aboutthismanual

Thisusermanualdescribesseveralproducts.Thismeansyoumayndinstructionsthataren’tapplicabletoyourproduct.

AXISP3925-RNetworkCamera

Getstarted

Chooselens

Thereismorethanonelensoptionforyourcamera.Whichlenstochoosedependsonthesurveillancerequirements.Thelenseshave

differentcapabilitieswhenitcomestolightsensitivityandeldofview.Seetheproduct’sdatasheetforlensalternatives.

Findthedeviceonthenetwork

TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPUtilityorAXISDeviceManager.Both

applicationsarefreeandcanbedownloadedfromaxis.com/support.

FormoreinformationabouthowtondandassignIPaddresses,seethedocumentHowtoassignanIPaddressandaccessyour

deviceonthedevicepageataxis.com.

Browsersupport

Youcanusethedevicewiththefollowingbrowsers:

Chrome

Firefox

Edge

Safari

Windows

recommended

macOS

recommended

Otheroperatingsystems

Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support.

Accessthedevice

1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.

IfyouhaveaMaccomputer(macOS),gotoSafari,clickBonjourandselectthedevicefromthedrop-downlist.Toadd

Bonjourasabrowserbookmark,gotoSafari>Preferences.

IfyoudonotknowtheIPaddress,useAXISIPUtilityorAXISDeviceManagertondthedeviceonthenetwork.

2.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta

newpasswordfortherootaccountonpage4.

3.Theliveviewpageopensinyourbrowser.

Verifythatnoonehastamperedwiththermware

TomakesurethatthedevicehasitsoriginalAxisrmware,ortotakefullcontrolofthedeviceafterasecurityattack:

1.Resettofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage23.

Afterthereset,securebootguaranteesthestateofthedevice.

2.Congureandinstallthedevice.

Setanewpasswordfortherootaccount

Important

Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.

AXISP3925-RNetworkCamera

Getstarted

1.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage5.

2.Retypethepasswordtoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

Securepasswords

Important

Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set

upasecureandencryptedHTTPSconnectionandthenchangethepassword.

Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey

maybeusedinvarioustypesofinstallations.

Toprotectyourdatawestronglyrecommendthatyou:

•Useapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.

•Don’texposethepassword.

•Changethepasswordatarecurringinterval,atleastonceayear.

Webpageoverview

Liveviewcontrolbar

Liveview

AXISP3925-RNetworkCamera

Getstarted

Productname

Userinformation,colorthemes,andhelp

Videocontrolbar

Settingstoggle

Settingstabs

AXISP3925-RNetworkCamera

Additionalsettings

Adjusttheimage

Ifyouwanttoknowmoreaboutdifferentimagesettings,seeLearnmoreonpage18.

Levelthecamera

Toadjusttheviewinrelationtoareferenceareaorobject,usethelevelingguideincombinationwithamechanicaladjustment

ofthecamera.

1.GotoSettings>System>Orientationandclick

2.Adjustthecameramechanicallyuntilthepositionofthereferenceareaorobject,isalignedwiththelevelingguide.

Selectsceneprole

Asceneproleisasetofpredenedimageappearancesettingsincludingcolorlevel,brightness,sharpness,contrastandlocal

contrast.Sceneprolesarepreconguredintheproductforquicksetuptoaspecicscenario,forexampleForensicwhichis

optimizedforsurveillanceconditions.Foradescriptionofeachavailablesetting,gotothehelpmenu

andclickHelp.

Youcanselectasceneproleduringtheinitialsetupofthecamera.Youcanalsoselectorchangesceneprolelater.

1.GotoSettings>System.

2.GotoPlaincong>Imagesourceandselectasceneprole.

Selectexposuremode

Therearedifferentexposuremodeoptionsinthecamerathatadjustsaperture,shutterspeed,andgaintoimproveimagequalityfor

specicsurveillancescenes.GotoSettings>Image>Exposureandselectbetweenthefollowingexposuremodes:

•Formostusecases,selectAutomaticexposure.

•Forenvironmentswithcertainarticiallighting,forexampleuorescentlighting,selectFlicker-free.

Selectthesamefrequencyasthepowerlinefrequency.

•Forenvironmentswithcertainarticiallightandbrightlight,forexampleoutdoorswithuorescentlightingatnightand

sunduringdaytime,selectFlicker-reduced.

Selectthesamefrequencyasthepowerlinefrequency.

•Tolockthecurrentexposuresettings,selectHoldcurrent.

BenetfromIRlightinlow-lightconditionsusingnightmode

Yourcamerausesvisiblelighttodelivercolorimagesduringtheday.Astheavailablelightdiminishes,youcansetthecamerato

automaticallyshifttonightmode,inwhichthecamerausesbothvisiblelightandnear-infraredlighttodeliverblack-and-white

images.Sincethecamerausesmoreoftheavailablelightitcandeliverbrighter,moredetailed,images.

1.GotoSettings>Image>Dayandnight,andmakesurethattheIRcutlterissettoAuto.

2.Todetermineatwhatlightlevelyouwantthecameratoshifttonightmode,movetheThresholdslidertowardBright

orDark.

3.EnableAllowIRilluminationandSynchronizeIRilluminationtousethecamera’sIRlightwhennightmodeisactivated.

AXISP3925-RNetworkCamera

Additionalsettings

Note

Ifyousettheshifttonightmodetooccurwhenit’sbrighter,theimageremainssharperastherewillbelesslow-light

noise.Ifyousettheshifttooccurwhenit’sdarker,theimagecolorsaremaintainedforlonger,buttherewillbemore

imageblurduetolow-lightnoise.

Reducenoiseinlow-lightconditions

Toreducenoiseinlow-lightconditions,youcanadjustoneormoreofthefollowingsettings:

•Adjustthetrade-offbetweennoiseandmotionblur.GotoSettings>Image>ExposureandmovetheBlur-noise

trade-offslidertowardLownoise.

•Settheexposuremodetoautomatic.

Note

Ahighmaxshuttervaluecanresultinmotionblur.

•Toslowdowntheshutterspeed,setmaxshuttertothehighestpossiblevalue.

•Reducesharpnessintheimage.

Note

Whenyoureducethemaxgain,theimagecanbecomedarker.

•Setthemaxgaintoalowervalue.

•Opentheaperture.

Reducemotionblurinlow-lightconditions

Toreducemotionblurinlow-lightconditions,adjustoneormoreofthefollowingsettingsinSettings>Image>Exposure:

•MovetheBlur-noisetrade-offslidertowardLowmotionblur.

Note

Whenyouincreasethegain,imagenoisealsoincreases.

•SetMaxshuttertoashortertime,andMaxgaintoahighervalue.

Ifyoustillhaveproblemswithmotionblur:

•Increasethelightlevelinthescene.

•Mountthecamerasothatobjectsmovetowarditorawayfromitratherthansideways.

Note

Ifyouusealenswithalargeraperture,thedepthofeldgetsshallower.

•Changetoalenswithalargeraperture.

Handlesceneswithstrongbacklight

Dynamicrangeisthedifferenceinlightlevelsinanimage.Insomecasesthedifferencebetweenthedarkestandthebrightest

areascanbesignicant.Theresultisoftenanimagewhereeitherthedarkorthebrightareasarevisible.Widedynamicrange

(WDR)makesbothdarkandbrightareasoftheimagevisible.

AXISP3925-RNetworkCamera

Additionalsettings

ImagewithoutWDR.

ImagewithWDR.

Note

WDRmightcauseartifactsintheimage.

1.GotoSettings>Image>Widedynamicrange.

2.TurnonWDR.

3.UsetheLocalcontrastslidertoadjusttheamountofWDR.

4.UsetheTonemappingslidertoadjusttheamountofWDR.

5.Ifyoustillhaveproblems,gotoExposureandadjusttheExposurezonetocovertheareaofinterest.

FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr.

StabilizeashakyimagewithElectronicImageStabilization(EIS)

ElectronicImageStabilization(EIS)canbeusedinenvironmentswheretheproductismountedinanexposedlocationandsubjectto

vibrations,forexample,windorpassingtrafc.TurnonEIStogetasmootherandsteadierimagewithoutblur.

EISalsoreducesthelesizeofthecompressedimageandlowersthebitrateofthevideostream.

Note

WhenEISisturnedontheimageiscroppedslightly,loweringthemaximumresolution.

1.GotoSettings>Image>Imagecorrection.

2.TurnonEIS.

Monitorlongandnarrowareas

Usecorridorformattobetterutilizethefulleldofviewinalongandnarrowarea,forexampleastaircase,hallway,road,ortunnel.

AXISP3925-RNetworkCamera

Additionalsettings

1.Dependingonyourdevice,turnthecameraorthe3-axislensinthecamera90°or270°.

Note

MakesuretoaimIRLEDsawayfromwallsorweathershields.

2.Ifthedevicedoesn’thaveautomaticrotationoftheview,logintothewebpageandgotoSettings>System>Orientation.

3.Click

4.Rotatetheview90°or270°.

Findoutmoreataxis.com/axis-corridor-format.

Improvefacialrecognition

Tobetterrecognizethefaceofapersonpassingbythecamera,youcansettheoptimalpixelresolutionwiththecamera’spixel

counter.

1.GotoSettings>System>Orientationandclick.

2.Inthecamera’sliveview,adjustthesizeandplacementoftherectanglearoundtheareaofinterest,forexample,where

thefacesofpassingpersonsareexpectedtoappear.Youcanthenseethenumberofpixelsrepresentedbythesidesof

therectangle.

AXISP3925-RNetworkCamera

Additionalsettings

Note

Youcanuseanobjectofaknownsizeintheviewasareferencetodecidehowmuchresolutionisneededforrecognition.

Hidepartsoftheimagewithprivacymasks

Youcancreateoneorseveralprivacymaskstohidepartsoftheimage.

1.GotoSettings>Privacymask.

2.ClickNew.

3.Adjustthesize,color,andnameoftheprivacymaskaccordingtoyourneeds.

Showanimageoverlay

Toaddanimageasanoverlayinthevideostream:

1.GotoSettings>Overlay.

2.ClickImagelist.

3.UploadanimageandclickDone.

4.ClickCreateoverlay.

5.SelectImageandclickCreate.

6.SelectImageandclickOk.

7.SelectImportanduploadanimage.

8.Selecttheimagefromthedrop-downlist.

9.Topositiontheimageoverlay,chooseCustomoroneofthepresets.

10.ClickCreate.

Adjustthecameraview(PTZ)

Tolearnmoreaboutdifferentpan,tilt,andzoomsettings,seePan,tilt,andzoom(PTZ)onpage19.

Createaguardtourwithpresetpositions

Aguardtourdisplaysthevideostreamfromdifferentpresetpositionseitherinapredeterminedorrandomorder,andforcongurable

periodsoftime.

1.GotoSettings>PTZ>Guardtours.

2.Click+.

3.Toedittheguardtour’sproperties,click.

4.Typeanamefortheguardtourandspecifythepauselengthinminutesbetweeneachtour.

5.Ifyouwanttheguardtourtogotothepresetpositionsinarandomorder,turnonShufe.

6.ClickDone.

7.ClickAddtoaddthepresetpositionsthatyouwantinyourguardtour.

8.ClickDonetoexittheguardtoursettings.

AXISP3925-RNetworkCamera

Additionalsettings

9.Toscheduletheguardtour,gotoSystem>Events.

Viewandrecordvideo

Tolearnmoreaboutsettingsforviewingandrecordingvideo,seeStreamingandstorageonpage19.

Reducebandwidthandstorage

Important

Ifyoureducethebandwidthitcanresultinlossofdetailsinthepicture.

1.GotoliveviewandselectH.264.

2.GotoSettings>Stream.

3.Dooneormoreofthefollowing:

-TurnontheZipstreamfunctionalityandselectthedesiredlevel.

Note

ThezipstreamsettingsareusedforbothH.264andH.265.

-TurnondynamicGOPandsetahighGOPlengthvalue.

-Increasethecompression.

-TurnondynamicFPS.

Note

WebbrowsersdonotsupportH.265decoding.UseavideomanagementsystemorapplicationsupportingH.265decoding.

Setupnetworkstorage

Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:

1.GotoSettings>System>Storage.

2.ClickSetupunderNetworkstorage.

3.EntertheIPaddressofthehostserver.

4.Enterthenameofthesharedlocationonthehostserver.

5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.

6.ClickConnect.

Recordandwatchvideo

Torecordvideoyoumustrstsetupnetworkstorage,seeSetupnetworkstorageonpage12,orhaveanSDcardinstalled.

Recordvideo

1.Gototheliveview.

2.Tostartarecording,clickRecord.Clickagaintostoptherecording.

Watchvideo

1.ClickStorage>Gotorecordings.

AXISP3925-RNetworkCamera

Additionalsettings

2.Selectyourrecordinginthelistanditwillplayautomatically.

Setuprulesandalerts

Youcancreaterulestomakeyourdeviceperformanactionwhencertaineventsoccur.Aruleconsistsofconditionsandactions.

Theconditionscanbeusedtotriggertheactions.Forexample,thedevicecanstartarecordingorsendanemailwhenitdetects

motion,orshowanoverlaytextwhenitrecords.

Triggeranaction

1.GotoSettings>System>Eventstosetuparule.Theruledeneswhenthedevicewillperformcertainactions.Rules

canbesetupasscheduled,recurring,orforexample,triggeredbymotiondetection.

2.SelecttheConditionthatmustbemettotriggertheaction.Ifyouspecifymorethanoneconditionfortherule,allofthe

conditionsmustbemettotriggertheaction.

3.SelectwhichActionthedeviceshouldperformwhentheconditionsaremet.

Note

Ifyoumakechangestoanactiverule,thentheruleneedstoberestartedforthechangestotakeeffect.

Note

Ifyouchangethedenitionofastreamprolethatisusedinarule,thenyouneedtorestartalltherulesthatusethat

streamprole.

Recordvideowhenthecameradetectsmotion

ThisexampleexplainshowtosetupthecameratostartrecordingtotheSDcardvesecondsbeforeitdetectsmotionandto

stoponeminuteafter.

MakesurethatAXISVideoMotionDetectionisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Createarule:

1.GotoSettings>System>Eventsandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,underApplication,selectAXISVideoMotionDetection(VMD).

4.Inthelistofactions,underRecordings,selectRecordvideowhiletheruleisactive.

5.Selectanexistingstreamproleorcreateanewone.

6.Settheprebuffertimeto5seconds.

7.Setthepostbuffertimeto60seconds.

8.Inthelistofstorageoptions,selectSDcard.

9.ClickSave.

Showatextoverlayinthevideostreamwhenthedevicedetectsmotion

Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthedevicedetectsmotion:

AXISP3925-RNetworkCamera

Additionalsettings

MakesurethatAXISVideoMotionDetectionisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Addtheoverlaytext:

4.GotoSettings>Overlay.

5.SelectCreateoverlayandselectTextoverlay.

6.Enter#Dinthetexteld.

7.Choosetextsizeandappearance.

8.Topositionthetextoverlay,chooseCustomoroneofthepresets.

Createarule:

9.GotoSystem>Events>Rulesandaddarule.

10.Typeanamefortherule.

11.Inthelistofconditions,selectAXISVideoMotionDetection.

12.Inthelistofactions,selectUseoverlaytext.

13.Selectaviewarea.

14.Type“Motiondetected”.

15.Settheduration.

16.ClickSave.

Note

Ifyouupdatetheoverlaytextitwillbeautomaticallyupdatedonallvideostreamsdynamically.

Directthecameratoapresetpositionwhenthecameradetectsmotion

Thisexampleexplainshowtosetupthecameratogotoapresetpositionwhenitdetectsmotionintheimage.

MakesurethatAXISVideoMotionDetectionisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Addapresetposition:

GotoSettings>PTZandsetwhereyouwantthecameratobedirectedbycreatingapresetposition.

Createarule:

1.GotoSettings>System>Events>Rulesandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,selectavideomotiondetectionconditionunderApplication.

AXISP3925-RNetworkCamera

Additionalsettings

4.Fromthelistofactions,selectGotopresetposition.

5.Selectthepresetpositionyouwantthecameratogoto.

6.ClickSave.

Recordvideowhenthecameradetectsimpact

Shockdetectionallowsthecameratodetecttamperingcausedbyvibrationsorshock.Vibrationsduetotheenvironmentortoan

objectcantriggeranactiondependingontheshocksensitivityrange,whichcanbesetfrom0to100.Inthisscenario,someoneis

throwingrocksatthecameraafterhoursandyouwouldliketogetavideoclipoftheevent.

Turnonshockdetection:

1.GotoSettings>System>Detectors.

2.Turnonshockdetection,andsetavaluefortheshocksensitivity.

Createarule:

1.GotoSettings>System>Eventsandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,underDevicestatus,selectShockdetected.

4.Click+toaddasecondcondition.

5.Inthelistofconditions,underScheduledandrecurring,selectScheduledevent.

6.Inthelistofschedules,selectAfterhours.

7.Inthelistofactions,underRecordings,selectRecordvideowhiletheruleisactive.

8.SelectaCamera.

9.Settheprebuffertimeto5seconds.

10.Setthepostbuffertimeto60seconds.

11.Selectwheretosavetherecordings.

12.ClickSave.

Providevisualindicationofanongoingevent

YouhavetheoptiontoconnecttheAXISI/OIndicationLEDtoyournetworkcamera.ThisLEDcanbeconguredtoturnonwhenever

certaineventsoccurinthecamera.Forexample,toletpeopleknowthatvideorecordingisinprogress.

Requiredhardware

•AXISI/OIndicationLED

•AnAxisnetworkvideocamera

Note

AXISI/OIndicationLEDshouldbeconnectedtoanoutputport.

Note

ForinstructionsonhowtoconnecttheAXISI/OIndicationLED,seetheinstallationguideprovidedwiththeproduct.

ThefollowingexampleshowshowtocongurearulethatturnsontheAXISI/OIndicationLEDtoindicatethatcameraisrecording.

AXISP3925-RNetworkCamera

Additionalsettings

1.GotoSettings>System>I/OPorts.

2.MakesurethattheportyouconnectedtheAXISI/OIndicationLEDtoissettoOutput.SetthenormalstatetoOpen

circuit(NO).

3.GotoSettings>System>Events.

4.Createanewrule.

5.SelecttheConditionthatmustbemettotriggerthecameratostartrecording.Itcan,forexample,beatimescheduleor

motiondetection.

6.Inthelistofactions,selectRecordvideo.Selectastreamproleorcreateanew.AlsosetthePrebufferandPostbuffer

asrequired.

7.Savetherule.

8.CreateasecondruleandselectthesameConditionasintherstrule.

9.Inthelistofactions,selectToggleI/Owhiletheruleisactive,andthenselecttheporttheAXISI/OIndicationLEDis

connectedto.SetthestatetoActive.

10.Savetherule.

OtherscenarioswhereAXISI/OIndicationLEDcanbeusedareforexample:

•ConguretheLEDtoturnonwhenthecamerastarts,toindicatethepresenceofthecamera.SelectSystemreadyas

acondition.

•ConguretheLEDtoturnonwhenlivestreamisactivetoindicatethatapersonoraprogramisaccessingastreamfrom

thecamera.SelectLivestreamaccessedasacondition.

Sendanemailautomaticallyifsomeonespraypaintsthelens

1.GotoSettings>System>Detectors.

2.TurnonTriggerondarkimages.Thiswilltriggeranalarmifthelensissprayed,covered,orrenderedseverelyoutoffocus.

3.SetadurationforTriggerafter.Thevalueindicatesthetimethatmustpassbeforeanemailissent.

Createarule:

1.GotoSettings>System>Events>Rulesandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,selectTampering.

4.Inthelistofactions,selectSendnoticationtoemail.

5.SelectarecipientfromthelistorgotoRecipientstocreateanewrecipient.

Tocreateanewrecipient,click

.Tocopyanexistingrecipient,click.

6.Typeasubjectandamessagefortheemail.

7.ClickSave.

AXISP3925-RNetworkCamera

Cleaningrecommendations

NO NO

TICE TICE

TICE

Neveruseharshdetergent,forexamplegasoline,benzene,oracetone.

1.Useacanofcompressedairtoremoveanydustorloosedirtfromthedevice.

2.Ifnecessary,cleanthelenswithasoftclothdampenedwithlukewarmwater.

Note

Avoidcleaningindirectsunlightoratelevatedtemperatures,asthismaycausestainswhenthewaterdropletsdry.

AXISP3925-RNetworkCamera

Learnmore

Viewarea

Aviewareaisacroppedpartofthefullview.Youcanstreamandstoreviewareasinsteadofthefullviewtominimizebandwidth

andstorageneeds.IfyouenablePTZforaviewarea,youcanpan,tiltandzoomwithinit.Byusingviewareasyoucanremoveparts

ofthefullview,forexample,thesky.

Whenyousetupaviewarea,werecommendyoutosetthevideostreamresolutiontothesamesizeasorsmallerthantheviewarea

size.Ifyousetthevideostreamresolutionlargerthantheviewareasizeitimpliesdigitallyscaledupvideoaftersensorcapture,

whichrequiresmorebandwidthwithoutaddingimageinformation.

Capturemodes

Acapturemodeconsistsofaresolutionandthecorrespondingframerateavailableintheproduct.Thecapturemodesetting

affectsthecamera’seldofviewandaspectratio.

Thelowerresolutioncapturemodeiscroppedoutfromthehighestresolution.

Theimageshowshowtheeldofviewandaspectratiocanchangebetweentwodifferentcapturemodes.

Whichcapturemodetochoosedependsontherequirementsofframerateandresolutionforthespecicsurveillancesetup.For

specicationsaboutavailablecapturemodes,seetheproduct’sdatasheetataxis.com.

Privacymasks

Aprivacymaskisauser-denedareathatpreventsusersfromviewingapartofthemonitoredarea.Inthevideostream,privacy

masksappearasblocksofsolidcolor.

Aprivacymaskisauser-denedareathatcoversapartofthemonitoredarea.Inthevideostream,privacymasksappeareitheras

blocksofsolidcolororwithamosaicpattern.

You’llseetheprivacymaskonallsnapshots,recordedvideo,andlivestreams.

YoucanusetheVAPIX®applicationprogramminginterface(API)toturnofftheprivacymasks.

Important

Ifyouusemultipleprivacymasksitmayaffecttheproduct’sperformance.

AXISP3925-RNetworkCamera

Learnmore

Overlays

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,

orduringproductinstallationandconguration.Youcanaddeithertextoranimage.

Thevideostreamingindicatorisanothertypeofoverlay.Itshowsyouthattheliveviewvideostreamislive.

Pan,tilt,andzoom(PTZ)

Guardtours

Aguardtourdisplaysthevideostreamfromdifferentpresetpositionseitherinapredeterminedorrandomorder,andforcongurable

periodsoftime.Oncestarted,aguardtourcontinuestorununtilstopped,evenwhentherearenoclients(webbrowsers)viewingthe

images.

Note

Thepausebetweensuccessiveguardtoursisatleast10minutes,andthexedminimumviewingtimeis10seconds.

Streamingandstorage

Videocompressionformats

Decidewhichcompressionmethodtousebasedonyourviewingrequirements,andonthepropertiesofyournetwork.The

availableoptionsare:

MotionJPEG

Note

ToensuresupportfortheOpusaudiocodec,theMotionJPEGstreamisalwayssentoverRTP.

MotionJPEG,orMJPEG,isadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen

displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion

videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage

containedinthestream.

H.264orMPEG-4Part10/AVC

Note

H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Toinstalladditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion

JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace

arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.

H.265orMPEG-HPart2/HEVC

Note

H.265islicensedtechnology.TheAxisproductincludesoneH.265viewingclientlicense.Toinstalladditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

HowdoImage,Stream,andStreamprolesettingsrelatetoeachother?

TheImagetabcontainscamerasettingsthataffectallvideostreamsfromtheproduct.Ifyouchangesomethinginthistab,it

immediatelyaffectsallvideostreamsandrecordings.

AXISP3925-RNetworkCamera

Learnmore

TheStreamtabcontainssettingsforvideostreams.Yougetthesesettingsifyourequestavideostreamfromtheproductanddon’t

specifyforexampleresolution,orframerate.WhenyouchangethesettingsintheStreamtab,itdoesn’taffectongoingstreams,but

itwilltakeeffectwhenyoustartanewstream.

TheStreamprolessettingsoverridethesettingsfromtheStreamtab.Ifyourequestastreamwithaspecicstreamprole,the

streamcontainsthesettingsofthatprole.Ifyourequestastreamwithoutspecifyingastreamprole,orrequestastreamprole

thatdoesn'texistintheproduct,thestreamcontainsthesettingsfromtheStreamtab.

Bitratecontrol

Withbitratecontrol,youcanmanagethebandwidthconsumptionofyourvideostream.

Variablebitrate(VBR)

Withvariablebitrate,thebandwidthconsumptionvariesbasedonthelevelofactivityinthescene.Themoreactivityinthescene,

themorebandwidthyouneed.Youareguaranteedconstantimagequalitybutitrequiresstoragemargins.

Maximumbitrate(MBR)

Withmaximumbitrate,youcansetatargetbitratetohandlebitratelimitationsinyoursystem.Youmayseeadeclineinimage

qualityorframeratewhentheinstantaneousbitrateiskeptbelowthespeciedtargetbitrate.Youcanchoosetoeitherprioritize

imagequalityorframerate.Werecommendthatyoucongurethetargetbitratetoahighervaluethantheexpectedbitrate.This

givesyouamarginforadditionalcomplexitythatneedstobecaptured.

Targetbitrate

Averagebitrate(ABR)

Withaveragebitrate,thebitrateisautomaticallyadjustedoveralongertimescale.Thisissoyoucanmeetthespeciedtargetand

providethebestvideoqualitybasedonyouravailablestorage.Bitrateishigherinsceneswithalotofactivity,comparedtostatic

scenes.Youaremorelikelytogetbetterimagequalitywhenneededwhenusingtheaveragebitrateoption.Youcandenethetotal

storagerequiredtostorethevideostreamforaspeciedamountoftime(retentiontime)whenimagequalityisadjustedtomeetthe

speciedtargetbitrate.Specifytheaveragebitratesettingsinoneofthefollowingways:

AXISP3925-RNetworkCamera

Learnmore

•Tocalculatetheestimatedstorageneed,setthetargetbitrateandtheretentiontime.

•Tocalculatetheaveragebitrate,basedonavailablestorageandrequiredretentiontime,usethetargetbitratecalculator.

kbit/s

Targetbitrate

Actualaveragebitrate

Youcanalsoturnonmaximumbitrateandspecifyatargetbitratewithintheaveragebitrateoption.

kbit/s

Targetbitrate

Actualaveragebitrate

Applications

AXISCameraApplicationPlatform(ACAP)isanopenplatformthatenablesthirdpartiestodevelopanalyticsandotherapplications

forAxisproducts.Tondoutmoreaboutavailableapplications,downloads,trialsandlicenses,gotoaxis.com/applications.

TondtheusermanualsforAxisapplications,gotoaxis.com.

AXISBlockedViewDetection

AXISBlockedViewDetectionisanapplicationthattriggersanalarmiftamperingofthecameraisdetected,forexample,ifthe

lensiscoveredorsprayed.

Foroptimalperformance,werecommendthatthecameraviewcontainsobjects,patternsorlinesthatcanbedetected.

AXISP3925-RNetworkCamera

Learnmore

Idealscene

Avoidlargeareasofoor,wallsandceilingwithfewobjects.

Notidealscene

Youcansetthetriggerlevelbyadjustingthesensitivityandchangeratioofthetamperingdetection.

AXISP3925-RNetworkCamera

Troubleshooting

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionataxis.com/support.

Resettofactorydefaultsettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultresetsallsettings,includingtheIPaddress,to

thefactorydefaultvalues.

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonwhilereconnectingpower.SeeProductoverviewonpage27.

3.Keepthecontrolbuttonpressedfor15–30secondsuntilthestatusLEDindicatorashesamber.

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset

tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90.

5.UsetheinstallationandmanagementsoftwaretoolstoassignanIPaddress,setthepassword,andaccessthevideostream.

Theinstallationandmanagementsoftwaretoolsareavailablefromthesupportpagesonaxis.com/support.

Itisalsopossibletoresetparameterstofactorydefaultthroughthewebinterface.GotoSettings>System>Maintenanceand

clickDefault.

Firmwareoptions

Axisoffersproductrmwaremanagementaccordingtoeithertheactivetrackorthelong-termsupport(LTS)tracks.Beingonthe

activetrackmeanscontinuouslygettingaccesstoallthelatestproductfeatures,whiletheLTStracksprovideaxedplatformwith

periodicreleasesfocusedmainlyonbugxesandsecurityupdates.

Usingrmwarefromtheactivetrackisrecommendedifyouwanttoaccessthenewestfeatures,orifyouuseAxisend-to-endsystem

offerings.TheLTStracksarerecommendedifyouusethird-partyintegrations,whicharenotcontinuouslyvalidatedagainstthelatest

activetrack.WithLTS,theproductscanmaintaincybersecuritywithoutintroducinganysignicantfunctionalchangesoraffecting

anyexistingintegrations.FormoredetailedinformationaboutAxisproductrmwarestrategy,gotoaxis.com/support/rmware.

Checkthecurrentrmware

Firmwareisthesoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootinga

problemshouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticular

problem.

Tocheckthecurrentrmware:

1.Gototheproduct’swebpage.

2.Clickonthehelpmenu

3.ClickAbout.

AXISP3925-RNetworkCamera

Troubleshooting

Upgradethermware

Important

Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providedthatthefeaturesareavailablein

thenewrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

Important

Makesuretheproductremainsconnectedtothepowersourcethroughouttheupgradeprocess.

Note

Whenyouupgradetheproductwiththelatestrmwareintheactivetrack,theproductreceivesthelatestfunctionality

available.Alwaysreadtheupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgradingthe

rmware.Tondthelatestrmwareandthereleasenotes,gotoaxis.com/support/rmware.

1.Downloadthermwareletoyourcomputer,availablefreeofchargeataxis.com/support/rmware.

2.Logintotheproductasanadministrator.

3.GotoSettings>System>Maintenance.Followtheinstructionsonthepage.Whentheupgradehasnished,the

productrestartsautomatically.

AXISDeviceManagercanbeusedformultipleupgrades.Findoutmoreataxis.com/products/axis-device-manager.

Technicalissues,cluesandsolutions

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionataxis.com/support.

Problemsupgradingthermware

FirmwareupgradefailureIfthermwareupgradefails,thedevicereloadsthepreviousrmware.Themostcommonreason

isthatthewrongrmwarelehasbeenuploaded.Checkthatthenameofthermwarele

correspondstoyourdeviceandtryagain.

Problemsafterrmware

upgrade

Ifyouexperienceproblemsafterarmwareupgrade,rollbacktothepreviouslyinstalledversion

fromtheMaintenancepage.

ProblemssettingtheIPaddress

Thedeviceislocatedona

differentsubnet

IftheIPaddressintendedforthedeviceandtheIPaddressofthecomputerusedtoaccessthe

devicearelocatedondifferentsubnets,youcannotsettheIPaddress.Contactyournetwork

administratortoobtainanIPaddress.

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisdevicefromthenetwork.Runthepingcommand(inaCommand/DOSwindow,

typepingandtheIPaddressofthedevice):

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstallthedevice.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisdevice.Checkallcablingandreinstallthedevice.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet

ThestaticIPaddressintheAxisdeviceisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingthedevice.

AXISP3925-RNetworkCamera

Troubleshooting

Thedevicecannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,thedevicemustberesettothefactorydefaultsettings.

SeeResettofactorydefaultsettingsonpage23.

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshasbeen

changed,useAXISIPUtilityorAXISDeviceManagertolocatethedeviceonthenetwork.Identify

thedeviceusingitsmodelorserialnumber,orbytheDNSname(ifthenamehasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,gotoaxis.com/support.

Certicateerrorwhenusing

IEEE802.1X

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisdevicemustbe

synchronizedwithanNTPserver.GotoSettings>System>Dateandtime.

Thedeviceisaccessiblelocallybutnotexternally

Toaccessthedeviceexternally,werecommendusingoneofthefollowingapplicationsforWindows

•AXISCompanion:freeofcharge,idealforsmallsystemswithbasicsurveillanceneeds.

•AXISCameraStation:30-daytrialversionfreeofcharge,idealforsmalltomid-sizesystems.

Forinstructionsanddownload,gotoaxis.com/vms.

Problemswithstreaming

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

deviceneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisdevice

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

PoorrenderingofH.264

images

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Gototheadapter’sdocumentationformore

information.

Lowerframeratethan

expected

•SeePerformanceconsiderationsonpage25.

•Reducethenumberofapplicationsrunningontheclientcomputer.

•Limitthenumberofsimultaneousviewers.

•Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

•Lowertheimageresolution.

•Logintothedevice’swebpageandsetacapturemodethatprioritizesframerate.

Changingthecapturemodetoprioritizeframeratemightlowerthemaximum

resolutiondependingonthedeviceusedandcapturemodesavailable.

•Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)

oftheAxisdevice.

Can'tselectH.265encoding

inliveview

WebbrowsersdonotsupportH.265decoding.Useavideomanagementsystemorapplication

supportingH.265decoding.

Performanceconsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationsaffecttheperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thisalsoaffectstheframerate.

Thefollowingfactorsarethemostimportanttoconsider:

AXISP3925-RNetworkCamera

Troubleshooting

•Highimageresolutionorlowercompressionlevelsresultinimagescontainingmoredatawhichinturnaffectsthe

bandwidth.

•RotatingtheimageintheGUIwillincreasetheproduct'sCPUload.

•AccessbylargenumbersofMotionJPEGorunicastH.264clientsaffectsthebandwidth.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclientsaffectsbothframerateand

bandwidth.

Useidenticalstreamswhereverpossibletomaintainahighframerate.Streamprolescanbeusedtoensurethat

streamsareidentical.

•AccessingMotionJPEGandH.264videostreamssimultaneouslyaffectsbothframerateandbandwidth.

•Heavyusageofeventsettingsaffectstheproduct’sCPUloadwhichinturnaffectstheframerate.

•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.

•Heavynetworkutilizationduetopoorinfrastructureaffectsthebandwidth.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformanceandaffectsframerate.

•RunningmultipleAXISCameraApplicationPlatform(ACAP)applicationssimultaneouslymayaffecttheframerateand

thegeneralperformance.

Contactsupport

Contactsupportataxis.com/support.

AXISP3925-RNetworkCamera

Speciﬁcations

Tondthelatestversionoftheproduct’sdatasheet,gototheproductpageataxis.comandlocateSupport&Documentation.

Productoverview

Audioconnector(AXISP3935–LR)

Networkconnector:M12orRJ45

I/Oconnector(AXISP3935–LR)

IRillumination(AXISP3935–LR)

Lightsensor(AXISP3935–LR)

AXISP3925-RNetworkCamera

Speciﬁcations

Microphone(AXISP3935–LR)

SDcardslot

Controlbutton

StatusLED

SDcardslot

NO NO

TICE TICE

TICE

•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe

SDcard.Useyourngerstoinsertandremovethecard.

•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard

fromtheproduct’swebpagebeforeremoval.

ThisproductsupportsmicroSD/microSDHC/microSDXCcards.

ForSDcardrecommendations,seeaxis.com.

microSD,microSDHC,andmicroSDXCLogosaretrademarksofSD-3CLLC.microSD,microSDHC,microSDXCare

trademarksorregisteredtrademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage23.

•ConnectingtoanAXISVideoHostingSystemservice.Toconnect,pressandholdthebuttonforabout3secondsuntilthe

statusLEDashesgreen.

Connectors

Networkconnector

TheAxisproductisavailableintwovariantswithdifferentnetworkconnectors:

D-codedM12connectorwithPoweroverEthernet(PoE).

I/Oconnector

UsetheI/Oconnectorwithexternaldevicesincombinationwith,forexample,motiondetection,eventtriggering,andalarm

notications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

Digitalinput-Forconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,door/window

contacts,andglassbreakdetectors.

Digitaloutput-ForconnectingexternaldevicessuchasrelaysandLEDs.ConnecteddevicescanbeactivatedbytheVAPIX®

ApplicationProgrammingInterfaceorfromtheproduct’swebpage.

4-pinterminalblock

AXISP3925-RNetworkCamera

Speciﬁcations

FunctionPinNotes

Specications

DCground

0VDC

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=25mA

DigitalInput

Connecttopin1toactivate,orleaveoating(unconnected)

todeactivate.

0tomax30VDC

DigitalOutput

Internallyconnectedtopin1(DCground)whenactive,

andoating(unconnected)wheninactive.Ifusedwithan

inductiveload,e.g.,arelay,connectadiodeinparallelwith

theload,toprotectagainstvoltagetransients.

0tomax30VDC,opendrain,

100mA

Example

DCground

DCoutput12V,max25mA

Digitalinput

Digitaloutput

UserManualVer.M1.2

AXISP3925-RNetworkCameraDate:October2020

PartNo.T10158521

Axis P3925-R 2MP Onboard Network Dome Camera M12 Connection

Product's Documents

User Manual

Specifications

Axis P3925-R Questions and Answers
