INSTRUCTIONS FOR:

RATCHET REPAIR KITS

The Sealey Ratchet Repair Kit that has been supplied to you will be one of the following three types:

Gear to Gear

Lever Change

The head can be opened up to access the ratchet mechanism either by releasing the circlip using a

 pairofinternalcirclippliers(g.1)orremovingthesecuringscrews(gs.2,3&4).

g.1

g.3g.2

 Thiswillreveal:

Gear to Gear

Lever Change

 ●Removeoriginalcomponents,notingcarefullytheorderinwhichtheywereremoved. 

 ●Cleaninsidetheratchetheadtoremoveanydirtorswarfandreplacethecomponentswiththe

 contentsoftherepairkit,ensuringthattheoriginalorderisrepeated.

 ●PleasenotethattheratchetpawlsintheLeverChangekitaremarked‘L’and‘R’andshouldbe

 replacedinthesamepositionastheoriginals.

 ●WhenrebuildingtheGeartoGearhead,itmaybeusefultoemployapairoftweezerstoholdthe

 ballinplacebetweenthespringandpawl.

 ●Withallinternalcomponentsinplaceapplyasmallamountofgrease,closetheheadbackup

 andresecure.

Environmental Protection.

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted, 

  takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.
