Automatic Foaming Soap Dispenser
User Manual
Please read this user manual carefully before use and
keep it for future reference.
1
Cautions
• DO NOT immerse the dispenser in water or rinse it directly with
water, or it will cause a short circuit.
• DO NOT use viscous liquids containing granules, powders,
emulsions, etc.
• DO NOT tilt or squeeze the liquid bottle when installing the
dispenser or replacing the hand soap. However, it is normal for a
small amount of soap to come out, and it can be used normally
after wiping clean.
• DO NOT invert the dispenser.
• DO NOT block the foam outlet with your hands or foreign objects.
• DO NOT use a charger that does not match this dispenser;
otherwise, it will cause the battery to catch fire or explode.
• DO NOT pull the silicone plug too hard when trying to charge the
dispenser, as the plug may be damaged and, as a result, will not
protect the charging port.
• There is no need to turn the dispenser off if you will continue to use
it. It will automatically go into standby when not in use.
• Children should use it under adult supervision to avoid spraying the
liquid soap into the eyes or accidental ingestion.
2
Product Description
Liquid Viewing
Window
Filter
Touch Switch / Indicator
Foam Outlet
Sensing Area
Pipette
Liquid Bottle
Anti-Slip Bottom
Accessory
Type-C Cable ×1
Waterproof Plug
Type-C
Charging Port
Dispenser Body
Compatible Soap Type
1
. It is recommended to use foaming hand soap directly.
3
2
. Liquid soap needs to be diluted with water in a ratio of 1:3. Fill the
bottle with the solution and stir evenly.
1 3：
Note:
1. Liquid soap must be diluted and mixed evenly before use;
otherwise, it will be too thick and will not foam.
2. Do not use soap with solid particles, as it will block the filter.
Operating Instructions
1. Charge with the Type-C cable
until the white light stays on.
2. Rotate and lift up the top cover.
3. Fill the liquid bottle with 10
fl oz/300 ml of foam hand
sanitizer.
4. Rotate and lock the top cover.
4
5. Touch the switch for 2 seconds;
the white light flashes mean
to turn it on, and the red light
flashes to turn it off.
6. Reach towards the sensing area
to get the rich foam. Closer
to the sensor will result in a
small amount of foam with the
green light on. Further away
will result in more foam with
the white light on.
7. L
ather and rub your hands
together thoroughly.
8. Rinse your hands with water.
Note:
1. The sensitivity of the touch switch may be affected when there is
water on it. Therefore, please wipe and clean it before operating.
2. When the power is low, the red indicator light will flash three
times after sensing, reminding you to charge it.
3. When a foreign object blocks the sensing area for more than 5
seconds, the red light will flash continuously. Please turn off the
dispenser, wipe the sensing area, and restart it.
Self-Cleaning Function
Quickly press the switch twice when the dispenser is turned on. The
blue indicator will flash, and the dispenser will pump continuously for
20 seconds. Pressing the button again will exit the self-cleaning mode.
5
Cleaning and Maintenance
1. Turn off the dispenser and wipe it with a damp towel when
cleaning the casing.
2. It is recommended to use the dispenser frequently to achieve the
best state. Let the sensor induce at least once every half month.
3. If you leave the dispenser out for a long time without using it,
please clean the tube using the Self-Cleaning Function to avoid
blockages:
• Turn off the dispenser, pour the hand soap from the liquid bottle
into a cup and save it for later use.
• Clean the liquid bottle completely, add warm water (no more
than 50
℃
), and install the dispenser.
• Turn on the dispenser, double-press the switch to enter self-
cleaning mode, then pour out the remaining water when it is
finished.
4. Keep this product in a cool, dry place to avoid humidity and
exposure to sunlight and heat.
6
Troubleshooting
Issue Possible Cause Solution
It does not turn
on.
Low battery power.
Charge the dispenser for
2-3 hours.
The indicator does
not light up.
It is not turned on.
Press and hold the switch
for 2 seconds to turn it
on.
It does not foam.
The hand soap is
depleted.
Refill the liquid bottle.
The tube is blocked.
Please check the foam
outlet and tube and
unclog the tube using the
matching soft bottle.
Interference from
light.
Move the dispenser to
another location to see if
the light interferes with
the sensor.
Breakdown of the
machine.
Contact the seller.
The red light will
not stop flashing.
Countertop reflection.
Put a black rubber pad
under the dispenser.
Something has
blocked the sensing
area.
Wipe the sensing area,
restart the dispenser, and
try again.
7
Specifications
Model: 1-JU58NA01
Capacity: 10 fl oz/300 ml
Sensing Distance: 0-7 cm
Rated Voltage: DC 3.7 V 0.65A
Rated Power: 2.4 W
Charging Voltage: DC 5 V 0.8A
Waterproof Level: IPX5
Single Liquid Output: 1 gram (high-grade) / 0.6 grams (low-grade)
Soap Type: Foam hand soap and diluted liquid soap with three times
the water.
Note: Design and specifications are subject to change without notice.
This product’s packaging is made from environmentally friendly
material and can be disposed of at your local recycling plant.
8
Customer Service
UNITED STATES
Phone: +1 909-391-3888
(Mon-Fri 9:00am - 5:00pm PST)
Email: ushelp@1byonebros.com
CANADA Email: cahelp@1byonebros.com
UNITED KINGDOM
Phone: +44 158 241 2681
(Mon-Fri 9:00am - 6:00pm UTC)
Email: [email protected]
GERMANY/
FRANCE
ITALY/SPAIN
Email: euhelp@1byonebros.com
BRAND OWNER
1byone Products Inc.
1230 E Belmont Street, Ontario, CA, USA 91761
Customer Service: +1 909-391-3888
www.1byonebros.com
