Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Ohio 44136-0019.
PRINTED IN U.S.A
READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
IMPORTANT
EDGER — Model 554
OPERATOR’S MANUAL
Safety • Assembly • Operation • Maintenance • Troubleshooting • Parts Lists • Warranty
Troy-Bilt LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
FORM NO. 769-02162A
01/2006
2
1. Safety Labels .................................................. 3
2. Safe Operation Practices ............................ 4-5
3. Assembling Your New Edger ......................... 6
4. Know Your Edger ............................................ 7
5. Operation and Adjustment .......................8-10
Table of Contents
6. Maintaining & Servicing Your Edger ........... 11
7. Off-Season Storage ...................................... 12
8. Troubleshooting ............................................ 13
9. Parts List .................................................. 14-15
10. Warranty ...................................... Back Cover
BEFORE YOU START ASSEMBLING YOUR NEW EQUIPMENT,
please locate the model plate on the equipment and copy the
information to the sample model plate provided to the right. You
can locate the model plate by standing at the operating position
and looking down at the rear of the Edger/Trencher.
This information will be necessary to use the manufacturer’s
web site and/or help from the Customer Support Department
or an authorized service dealer.
Finding and Recording Model Number
This Operator’s Manual is an important part of your new Edger. It will help you assemble, prepare
and maintain the unit for best performance. Please read and understand what it says.
Model Number Serial Number
www.troybilt.com
TROY-BILT LLC
P.O. BOX 361131
CLEVELAND, OHIO 44136-0019
330-558-7220
1-866-840-6483
Please do
NOT
return the unit to the retailer from which it was purchased, without first
contacting Customer Support.
Customer Support
If you have difficulty assembling this product or have any questions regarding control, operation, or maintenance, you can seek
help from the experts. Choose from the options below:
• Visit www.troybilt.com
• Phone a Customer Support Representative at 1-866-840-6483.
• The engine manufacturer is responsible for all engine-related issues with regard to performance, power-rating, specifications,
warranty, and service. Please refer to the engine manufacturer’s Owner’s/Operator’s Manual, packed separately with your
unit, for more information.
3
Your Troy-Bilt Safety Labels
Please take a moment to review your safety labels.
1
Safety
Labels
WARNING
This symbol points
out important safety
instructions which, if
not followed, could
endanger the personal
safety and/or property
of yourself and others.
Read and follow all
instructions in this man-
ual before attempting to
operate this machine.
Failure to comply with
these instructions may
result in personal injury.
When you see this
symbol.
HEED ITS WARNING
Your
Responsibility
Restrict the use
of this power machine
to persons who read,
understand
and follow the warnings
and instructions
in this manual
and on the machine.
4
2
Safe
Operation
Practices
Children
Tragic accidents can occur if operator is not alert to presence
of children. Children are often attracted to power equipment
such as lawn edgers. They do not understand the dangers.
Never assume that children will remain where you last saw
them.
1. Keep children out of the mowing area and under watchful
care of a responsible adult other than the operator.
2. Be alert and turn lawn edger off if a child enters the area.
3. Before and while moving backwards, look behind and down
for small children.
4. Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may obscure
your vision of a child who may run into the lawn edger.
5. Keep children away from hot or running engines. They can
suffer burns from a hot muffler.
6. Never allow children under 14 years old to operate an
edger. Children 14 years old and over should read and
understand operation instructions and safety rules in this
manual and should be trained and supervised by a parent.
Operation
Safe Handling Of Gasoline:
1. To avoid personal injury or property damage use
extreme care in handling gasoline. Gasoline is extremely
flammable and the vapors are explosive. Serious personal
injury can occur when gasoline is spilled on yourself or
your clothes which can ignite.
2. Wash your skin and change clothes immediately.
3. Use only an approved gasoline container.
4. Never fill containers inside a vehicle or on a truck or trailer
bed with a plastic liner. Always place containers on the
ground away from your vehicle before filling.
5. Remove gas-powered equipment from the truck or
trailer and refuel it on the ground. If this is not possible,
then refuel such equipment on a trailer with a portable
container, rather than from a gasoline dispenser nozzle.
6. Keep the nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete. Do
not use a nozzle lock-open device.
7. Extinguish all cigarettes, cigars, pipes and other sources
of ignition.
8. Never fuel machine indoors because flammable vapors
will accumulate in the area.
9. Never remove gas cap or add fuel while engine is hot or
running. Allow engine to cool at least two minutes before
refueling.
10. Never over fill fuel tank. Fill tank to no more than ½ inch
below bottom of filler neck to provide for fuel expansion.
11. Replace gasoline cap and tighten securely.
12. If gasoline is spilled, wipe it off the engine and equipment.
Move unit to another area. Wait 5 minutes before starting
engine.
13. Never store the machine or fuel container near an open
flame, spark or pilot light as on a water heater, space heater,
furnace, clothes dryer or other gas appliances.
14. To reduce fire hazard, keep lawn edger free of grass,
leaves, or other debris build-up. Clean up oil or fuel spillage
and remove any fuel soaked debris.
15. Allow a lawn edger to cool at least 5 minutes before storing.
General Operation:
1. Read this operator’s manual carefully in its entirety before
attempting to assemble this machine. Read, understand,
and follow all instructions on the machine and in the
manual(s) before operation. Be completely familiar with
the controls and the proper use of this machine before
operating it. Keep this manual in a safe place for future and
regular reference and for ordering replacement parts.
2. This machine is a precision piece of power equipment, not a
plaything. Therefore, exercise extreme caution at all times.
Your unit has been designed to perform one job: to edge
lawn. Do not use it for any other purpose.
3. Never allow children under 14 years old to operate this
machine. Children 14 years old and over should read and
understand the instructions in this manual and should
be trained and supervised by a parent. Only responsible
individuals who are familiar with these rules of safe opera-
tion should be allowed to use this machine.
4. To help avoid blade contact or a thrown object injury, stay in
operator zone behind handles and keep children, bystand-
ers, helpers and pets at least 75 feet from lawn edger while
it is in operation. Stop machine if anyone enters area.
5. Thoroughly inspect the area where the equipment is to be
used. Remove all stones, sticks, wire, bones, toys and other
foreign objects which could be tripped over or picked up
and thrown by the blade. Thrown objects can cause serious
personal injury.
6. Always wear safety glasses or safety goggles during opera-
tion and while performing an adjustment or repair to protect
your eyes. Thrown objects which ricochet can cause serious
injury to the eyes.
7. Wear sturdy, rough-soled work shoes and close-fitting
slacks and shirts. Shirts and pants that cover the arms and
legs and steel-toed shoes are recommended. Never operate
this machine in bare feet, sandals, slippery or light weight
(e.g. canvas) shoes.
8. Never attempt to make any adjustments while the engine
is running, except where specifically recommended in the
operator’s manual.
9. To avoid personal injury or property damage use extreme
care in handling gasoline. Gasoline is extremely flammable
and the vapors are explosive. Serious personal injury can
occur when gasoline is spilled on yourself or your clothes
WARNING: Engine Exhaust, some of its constituents, and certain vehicle compo-
nents contain or emit chemicals known to State of California to cause cancer and
birth defects or other reproductive harm.
WARNING
This symbol points
out important safety
instructions which, if
not followed, could
endanger the personal
safety and/or property
of yourself and others.
Read and follow all
instructions in this man-
ual before attempting to
operate this machine.
Failure to comply with
these instructions may
result in personal injury.
When you see this
symbol.
HEED ITS WARNING
Your
Responsibility
Restrict the use
of this power machine
to persons who read,
understand
and follow the warnings
and instructions
in this manual
and on the machine.
DANGER: This machine was built to be operated according to the rules for safe operation in this
manual. As with any type of power equipment, carelessness or error on the part of the operator can
result in serious injury. This machine is capable of amputating hands and feet and throwing objects.
Failure to observe the following safety instructions could result in serious injury or death.
5
which can ignite. Washer your skin and change clothes
immediately.
10. Do not put hands or feet near rotating parts. Contact with
the rotating blade can amputate hands and feet.
11. The blade control handle is a safety device. Never bypass
its operation. Doing so, makes the machine unsafe and may
cause personal injury.
12. Never operate without blade guard, debris shield and blade
control handle in place and working.
13. Never operate with damaged safety devices. Failure to do
so, can result in personal injury.
14. Never run an engine indoors or in a poorly ventilated area.
Engine exhaust contains carbon monoxide, an odorless and
deadly gas.
15. Do not operate machine while under the influence of alcohol
or drugs.
16. Muffler and engine become hot and can cause a burn. Do
not touch.
17. Never operate this machine without good visibility or light.
Always be sure of your footing and keep a firm hold on the
handles. Walk, never run.
18. Do not operate this machine if it has been dropped or dam-
aged. Return machine to your nearest authorized servicing
dealer for examination and repair.
29. Do not operate this machine with a damaged or excessively
worn cutting blade.
20. Never attempt to clear material from the blade guard while
the engine is running. Shut the engine off, disconnect the
spark plug wire and ground against the engine to prevent
unintended starting.
21. Do not overload machine capacity by attempting to edge at
too fast of a rate.
22. Stay alert for uneven sidewalks, terrain etc. Always push
slowly over rough surfaces. Do not use this machine on
gravel surfaces.
23. Do not operate machine in rain or wet soil conditions.
Always operate machine from behind the handles and
position yourself where the direct line of sight to cutting
blade is blocked by guards.
24. Always stop engine when edging or trimming is delayed or
when transporting machine from one location to another.
Never leave a running machine unattended. Stop the
engine, disconnect spark plug wire and ground against the
engine to prevent unintended starting.
25. Only use parts and accessories made for this machine by
the manufacturer. Failure to do so, can result in personal
injury.
26. If situations occur which are not covered in this manual,
use care and good judgment. Contact your dealer for
assistance. Telephone 1-866-520-5520 to locate the dealer
nearest you.
Service
1. Never run an engine indoors or in a poorly ventilated area.
Engine exhaust contains carbon monoxide, an odorless and
deadly gas.
2. Before cleaning, repairing, or inspecting, make certain the
blade and all moving parts have stopped. Disconnect the
spark plug wire and ground against the engine to prevent
unintended starting.
3. Check the blade and engine mounting bolts at frequent
intervals for proper tightness. Also, visually inspect blade
for damage (e.g., bent, cracked, worn) Replace blade with
the original equipment manufacture’s (O.E.M.) blade only,
listed in this manual. “Use of parts which do not meet the
original equipment specifications may lead to improper
performance and compromise safety!”
4. Lawn edger blades are sharp and can cut. Wrap the blade
or wear gloves, and use extra caution when servicing them.
5. Keep all nuts, bolts, and screws tight to be sure the equip-
ment is in safe working condition.
6. Never tamper with safety devices. Check their proper
operation regularly.
7. After striking a foreign object, stop the engine, discon-
nect the spark plug wire and ground against the engine.
Thoroughly inspect the lawn edger for any damage. Repair
the damage before starting and operating the lawn edger.
8. Never attempt to make a wheel or cutting height adjust-
ment while the engine is running.
9. Many components on your new edger can wear with
continued use. For safety protection, frequently check
all edger components and replace immediately with
original equipment manufacturer’s (O.E.M.) parts only,
listed in this manual. “Use of parts which do not meet the
original equipment specifications may lead to improper
performance and compromise safety!”
10. Do not change the engine governor setting or overspeed
the engine. The governor controls the maximum safe
operating speed of the engine.
11. Maintain or replace safety labels, as necessary.
12. Observe proper disposal laws and regulations. Improper
disposal of fluids and materials can harm the environment.
2
Safe
Operation
Practices
WARNING
This symbol points
out important safety
instructions which, if
not followed, could
endanger the personal
safety and/or property
of yourself and others.
Read and follow all
instructions in this man-
ual before attempting to
operate this machine.
Failure to comply with
these instructions may
result in personal injury.
When you see this
symbol.
HEED ITS WARNING
Your
Responsibility
Restrict the use
of this power machine
to persons who read,
understand
and follow the warnings
and instructions
in this manual
and on the machine.
6
3
Assembling
Your New
Edger
Securing the Handle
IMPORTANT: This unit is shipped WITHOUT GASOLINE.
After setting up the unit, service engine with gasoline as
instructed in the separate engine manual packed with your
unit. Be sure to service engine with the oil enclosed with
this unit as instructed in the separate engine manual.
NOTE: Reference to right or left hand side of the edger is
observed from the operating position.
Positioning the Edger Handles
Remove and discard any packaging cardboard that
may be present between the upper handle and the lower
handle.
1. Depress the blade control at the top of the upper
handle and pivot the upper handle upward until it
snaps into place. See Figure 1.
2. Tighten the hand knobs, which are located on both the
left and right sides of the handle.
Attaching the Starter Rope
1. Locate the rope guide found on the right side of the
upper handle. Loosen, but do NOT remove, the wing
knob which secures the rope guide to the upper
handle. See Figure 2.
2. Stand behind the unit and hold the blade control
against the upper handle.
3. Gently pull the starter rope out of the engine.
WARNING: The edger blade WILL
rotate when the starter rope is pulled.
NOTE: The starter rope will not pull out of the engine
unless the blade control (refer to Figure 2) is depressed
against the upper handle.
4. Slip the starter rope through the top of the rope guide.
Retighten the wing knob which secures the rope guide
to the upper handle.
Figure 2
The edger blade
WILL rotate when the
starter rope is pulled.
Figure 1
IMPORTANT:
This unit is shipped
WITHOUT GASOLINE.
After setting up the
unit, service engine
with gasoline as in-
structed in the separate
engine manual packed
with your unit. Be sure
to service engine with
the oil enclosed with
this unit as instructed
in the separate engine
manual.
WARNING
1
2
2
4
1
3
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
7
Figure 3
WARNING: Be familiar with all controls
and their proper operation. Know how
to stop the machine and disengage
them quickly.
NOTE: Refer to the Engine Manual packed with your
edger for a detailed description of all engine-related
controls and components.
Starter Rope / Recoil Starter
The starter rope/recoil starter is used to start the engine.
Primer
The primer is used to pump gas into the carburetor and
aid in starting the engine. Use it to start a cold engine,
but do not use it to restart a warm engine after a short
shutdown.
NOTE: Refer to the Engine Manual packed with your
edger for a detailed description of all engine-related
controls and components.
Blade Control
Located on the upper handle, the blade control must be
depressed against the upper handle in order to operate
the unit. Releasing the blade control stops the engine
and the edger blade. See Figure 3.
Blade Depth Control Lever
The blade depth control lever is located on the right side
of the upper handle. It is used to control the depth of the
cut. The further forward the blade depth control lever is
moved, the deeper into the soil the edger blade will cut.
See Figure 3.
Bevel Adjustment Lever
The bevel adjustment lever is located on the front, left
portion of the edger, behind the edger blade. It is used to
vary the angle of the edger blade between one of three
positions for edging/trenching or beveled edging. See
Figure 3.
Curb Height Adjustment Lever
The curb height adjustment lever is found on the rear
portion of the edger. When placed in an applicable notch,
it aids in stabilizing the edger while edging grass along a
curb. See Figure 3.
IMPORTANT: Become familiar with all the controls
before operating the edger.
Starter Rope / Recoil Starter
Curb Height Adjustment Lever
Blade Control
Blade Depth Control Lever
(Transport Position Shown)
Bevel Adjustment Lever
Belt Guard
Primer
Be familiar with all
controls and their
proper operation.
Know how to stop
the machine and
disengage them
quickly.
4
Know Your
Edger
WARNING:
NOTE: Refer to the
Engine Manual packed
with your edger for a
detailed description of all
engine-related controls
and components.
IMPORTANT:
Become familiar with all the
controls before operating
the edger.
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
8
The operation of any edger can result
in foreign objects being thrown into the
eyes, which can result in severe eye
damage. Always wear safety glasses or
eye shields. We recommend wide vision
safety mask for over spectacles or
standard safety glasses.
WARNING: Do not lower blade if blade
is over concrete, asphalt, rocks or the
like. The blade can strike the supporting
surface, resulting in personal injury or
property damage.
Adding Gasoline And Oil
Service the engine with gasoline and oil as instructed
in the Engine Manual packed with your edger. Read
instructions carefully.
WARNING: Never fill fuel tank indoors,
with engine running or until the engine
has been allowed to cool for at least two
minutes after running.
Starting The Engine
NOTE: Refer to the Engine Manual packed with your
edger for a detailed description of all engine-related
controls and components.
To start the edger’s engine, proceed as follows:
1. Attach the spark plug wire to the spark plug. Make
certain the metal cap on the end of the spark plug
wire is fastened securely over the metal tip on the
spark plug.
2. Move the blade depth control lever back to the
START position in the adjacent (top) notch.
3. Depress the primer bulb three times, pausing two to
three seconds between each push. In cold weather
(below 50°F /19°C), it may be necessary to depress
the primer bulb four or five times.
IMPORTANT: Using the primer to restart a warm engine
after a short shutdown is usually not necessary. Doing so
may result in a flooded engine.
4. Standing behind the unit, depress the blade control and
hold it against the upper handle with your left hand.
WARNING: This control mechanism
is a safety device. Never attempt to
bypass its operation.
5. With your right hand, grasp the recoil starter handle and
slowly pull the rope outward until engine reaches the
start of its compression cycle (the rope will pull slightly
harder at this point).
6. After slowly allowing the rope to recoil, pull the rope
with a rapid, continuous, full arm stroke. Keep a firm
grip on starter handle throughout the entire stroke.
7. Allow the starter handle to slowly return to the eyebolt.
NOTE: If the engine fails to start after three pulls,
depress the primer an additional two times before pulling
the starter rope again.
Stopping The Engine
To stop the edger’s engine, release the blade control.
NOTE: See your engine manual packed with your unit for
more detailed instructions.
Edging
To begin edging, proceed as follows:
1. Move the unit over to the area to be edged, making
sure that the left rear wheel is on a hard surface and
the blade is over the area to be cut. See Figure 4.
2. Move the blade depth control lever to the left and place
into the next lower notch. Then make a pass along the
area to be edged before proceeding to the next notch.
The further forward the blade depth control lever is
moved, the deeper or lower the blade will cut into the
ground. Several passes may be necessary to obtain
the desired depth of cut. Do not lower the blade more
than one depth notch at a time without making a pass.
3. For best results, proceed slowly along the path being
edged, slowly moving the edger back and forth through
the cutting area, again making sure to keep the left rear
wheel on the hard surface and the blade in the cutting
path, close to but not touching the edge of the hard
surface.
4. Once you have reached the end of your cutting path,
raise the blade control lever back into the START posi-
tion, move to the next area to be edged, and proceed
again from step 1.
Bevel Adjustment
The angle of the edger blade can be adjusted by placing
the bevel adjustment in one of three positions for edging/
trenching or beveled edging. See Figure 5.
WARNING: Rotating cutting blade may
throw objects causing personal injury.
Keep area clear of bystanders and do
not operate without guards in place.
5
Operation
And
Adjustment
WARNING
Do not lower blade
if blade is over
concrete, asphalt,
rocks or the like. The
blade can strike the
supporting surface,
resulting in personal
injury or property
damage.
Never fill fuel tank
indoors, with engine
running or until the
engine has been
allowed to cool for
at least two minutes
after running.
The “Blade Control”
is a safety device.
Never attempt to
bypass its operation.
Rotating cutting
blade may throw
objects causing
personal injury.
Keep area clear of
bystanders and do
not operate without
guards in place.
Figure 4
9
Beveling
In order to achieve a bevelled edge, set the bevel
adjustment lever (refer to Figure 5) in the first (left hand)
or third (right hand) notch to place the edger blade in
position for beveling (See figure 6).
Trenching (Optional)
In order to create a wider cutting path for such things as
laying wire for landscape lighting or invisible fences, you
can utilize the edger’s optional trenching feature.
WARNING: Disconnect the spark plug
wire and ground against the engine
before performing the following steps.
WARNING: The edger blade is sharp.
Wear leather work gloves to protect
your hands when working around the
edger blade.
1. Working in front of the edger, loosen the flange lock
nut on top of frame, allowing the idler pulley assembly
to pivot slightly out from the frame.
2. With your other hand, carefully reach under the
rear of the unit and remove the belt from around the
engine flywheel pulley. See Figure 7.
5
Operation
And
Adjustment
WARNING
Disconnect the
spark plug wire and
ground against the
Disconnect the spark
plug wire and ground
against the engine
before performing the
following steps.
The edger blade is
sharp. Wear leather
work gloves to protect
your hands when
working around the
edger blade.
3. Remove the belt guard by removing the two self-
tapping screws which secure it to the blade plate
assembly. See Figure 8.
4. Use two wrenches (one wrench to prevent the hex
bolt head from spinning and the other to unthread the
flange nut) to remove the flange nut that secures the
edger blade, leaving the edger blade in place. See
Figure 9.
5. Install the Tri-star edger blade (part no. 781-0748),
and the flat washer (part no. 736-04088). See
Figure 10.
Figure 6
Beveling Positions
Figure 7
Engine
Flywheel Pulley
Flange Lock Nut
Belt Guard
Bevel Adjustment
Lever
Edging/Trenching
Position Shown
Figure 5
Bevel Left &
Right Positions
Blade Plate Assembly
Belt Guard
Hex Screws
Figure 8
Figure 9
Hex Bolt Head
Flange Nut
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
10
Edging Along A Curb
The right, rear wheel of the edger can be lowered into one
of five positions to ease the task of edging along a curb.
To adjust the height of the curb wheel, proceed as follows:
1. Lower the right, rear wheel by moving the curb height
adjustment lever slightly to the left. See Figure 12.
2. Pivot the right, rear wheel into an applicable position in
relation to the height of the curb to be edged along.
3. Release the curb height adjustment lever to lock the
wheel in position. See Figure 12.
NOTE: Several passes may be necessary to obtain the
desired depth of cut. Do not lower blade more than one
depth notch at a time.
6. Secure with the flange nut removed earlier.
IMPORTANT: Use a torque wrench to tighten the flange
nut to between 37 foot-lbs. and 50 foot-lbs.
7. Reinstall the spindle belt guard with the self tapping
screws removed earlier.
8. Carefully place the drive belt back onto the engine
flywheel pulley, and retighten the flange lock nut on
the top of the frame.
IMPORTANT: Make certain that the drive belt is
seated correctly on the blade spindle and that it is riding
smoothly on the spindle sheaves and is not pinched
between them. Repeat the first three steps if the belt is
pinched.
9. Set the bevel adjustment lever (refer to Figure 5) in
the center notch to place the edger blade in a 90°
position (see Figure 11) and place the blade depth
control lever in the lowest position.
IMPORTANT: For best results, proceed slowly along
the path being trenched, slowly moving the edger back
and forth through the cutting area.
5
Operation
And
Adjustment
IMPORTANT: Use
a torque wrench to
tighten the flange nut
to between 37 foot-
lbs. and 50 foot-lbs.
IMPORTANT: Make
certain that the drive
belt is seated cor-
rectly on the blade
spindle and that it is
riding smoothly on
the spindle sheaves
and is not pinched
between them. Repeat
the first three steps if
the belt is pinched.
IMPORTANT: For
best results, proceed
slowly along the
path being trenched,
slowly moving the
edger back and forth
through the cutting
area.
90
°
Edging / Trenching Position
Figure 11
Edger Blade
Tri-star Blade
Flat Washer
Flange Nut
Figure 10
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
Lowered Position
Figure 13
Curb Height
Adjustment Lever
Curb Height
Adjustment
Lever
Figure 12
1
2
3
11
6
Maintaining
& Servicing
Your Edger
WARNING
Disconnect the spark
plug wire and ground
against the engine
before performing
any adjustment,
repairs or mainte-
nance.
The edger blade
is sharp. Wear
leather work gloves
to protect your hands
when working around
the edger blade.
Disconnect the spark
plug wire and ground
against engine
before performing the
following steps.
WARNING: Disconnect the spark
plug wire and ground against the
engine before performing any adjust-
ment, repairs or maintenance.
Lubrication
Engine
Refer to the Engine Manual packed with your edger for a
detailed description of all engine-related service specifications.
Wheels
Lubricate the wheels and bearings at least once a
season with a light oil. Also if the wheels are removed
for any reason, lubricate the surface of the axle bolt and
the inner surface of the wheel with light oil.
Pivot Points
Lubricate the pivot points on the blade control bail, blade
depth control lever, and if applicable, the blade adjust-
ment lever, and curb height adjustment lever with light oil
at least once a season.
Bearing Block
Lubricate the bearing block every 25 hours or at least
once a season. Simply apply oil at each end of the cover
plate. See Figure 14.
Replacing the Edger Blade
WARNING: The edger blade is sharp.
Wear leather work gloves to protect
your hands when working around the
edger blade.
WARNING: Disconnect the spark
plug wire and ground against engine
before performing the following
steps.
1. Working in front of the edger, loosen the flange lock
nut on top of frame, allowing the idler pulley assem-
bly to pivot slightly out from the frame. See Figure 15.
2. With your other hand, carefully reach under the rear of
the unit and remove the belt from around the engine
flywheel pulley.
3. Remove the spindle sheaves belt guard by removing
the two self-tapping screws which secure it to the
blade plate assembly. See Figure 8.
4. Use two wrenches (one wrench to prevent the hex bolt
head from spinning and the other to remove the flange
nut) to remove the edger blade. Refer to Figure 9.
5. Remove and discard the edger blade but retain the
flange nut.
6. Install the replacement edger blade and the flange nut
removed earlier.
IMPORTANT: Use a torque wrench to tighten the flange
nut to between 37 foot-lbs. and 50 foot-lbs.
7. Reinstall the spindle belt guard with the self tapping
screws removed earlier.
8. Carefully place the drive belt back onto the engine
flywheel pulley, and retighten the flange lock nut on the
top of the frame.
IMPORTANT: Make certain that the drive belt is seated
correctly on the blade spindle and that it is riding smoothly
on the spindle sheaves and is not pinched between them.
Repeat the first three steps if the belt is pinched.
Replacing the Drive Belt
IMPORTANT: To aid in reassembly, note the orientation
of the drive belt on the two idler pulleys and the engine
flywheel pulley prior to performing the following steps.
Refer to Figure 15.
The edger drive belt is subject to wear and should be
replaced if any signs of cracking, shredding or rotting are
present. To replace the belt, proceed as follows:
1. Working in front of the edger, loosen the flange lock nut
on top of frame, allowing the idler pulley assembly to
pivot slightly out from the frame. See Figure 15.
2. With your other hand, carefully reach under the rear of
the unit and remove the belt from around the engine
flywheel pulley.
3. Remove the spindle sheaves belt guard by removing
the two self-tapping screws which secure it to the
blade plate assembly. See Figure 8.
Engine
Flywheel
Pulley
Flat Side
of Belt
Idler Pulley
Assembly
“V” Side
of Belt
Belt
Guard
Flange Lock Nut
Figure 15
Lubricate
Figure 14
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
12
6. Reinstall the spindle sheaves belt guard with the self
tapping screws removed earlier.
7. Make certain that the drive belt is on the engine
flywheel pulley and idler pulleys, and retighten the
flange lock nut on the top of the frame.
IMPORTANT: Make certain that the drive belt is seated
correctly and that it is riding smoothly on the spindle
sheaves and is not pinched between them. Repeat the
first three steps if the belt is pinched.
WARNING: Never operate the edger
without the spindle sheaves belt guard
in place.
7
Off-Season
Storage
WARNING
Never operate the
edger without the
spindle sheaves belt
guard in place.
4. Carefully remove the belt from off of the pulleys,
again making sure to note the orientation of the belt.
Discard the belt.
Install the replacement belt (Part No. 754-04032B) in the
same configuration that the original belt was routed as
follows:
5. Working from the front of the edger, place the
belt onto the spindle sheaves, route it back
onto the two idler pulleys, and then place it
onto the engine flywheel pulley.
IMPORTANT: Make certain that the “V” side of the belt
is seated into the top pulley and the flat side of the belt is
seated into the bottom pulley. See Figure 15.
Off-Season Storage
Observe the following when preparing the edger for
long-term storage:
1. Clean and lubricate unit thoroughly as instructed on
page 11 of this manual.
2. Refer to the Engine Manual packed separately with
the edger for engine manufacturers’s storage instruc-
tions.
3. Coat the edger blade with chassis grease to prevent
rusting and corrosion.
4. Store the edger in a dry, clean area. Do not store next
to any corrosive materials, such as lawn fertilizer.
5. Coat the edger, especially any springs and bearings
with a light oil or silicone spray.
IMPORTANT: When storing any type of power equip-
ment in an poorly ventilated or metal storage shed, care
should be taken to rustproof the equipment.
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
13
8
Troubleshooting
Guide
Problem
Engine fails to start
Engine runs erratic
Engine Overheats
Corrective Action
Refer to the Engine Manual packed with your unit.
Push primer bulb two or three times.
Fill tank with clean, fresh gasoline.
Drain gasoline and refill tank with clean, fresh gasoline.
Connect the spark plug wire to the spark plug.
Clean, adjust gap or replace spark plug.
Refer to the Engine Manual packed with your unit.
Connect and tighten spark plug wire.
Drain gasoline & refill tank with clean, fresh gasoline.
Clear vent of any debris.
Drain fuel tank. Refill with fresh fuel.
Refer to the Engine Manual packed with your unit.
Refer to the Engine Manual packed with your unit.
Fill crankcase with proper oil.
Clean the area around the engine’s cooling fins.
Replace the engine’s air filter.
Refer to the Engine Manual packed with your unit.
Possible Cause(s)
Dirty air cleaner
Engine needs to be primed
Fuel tank empty
Stale fuel in gasoline tank
Spark plug wire disconnected.
Spark plug fouled
Engine flooded
Spark plug wire loose
Stale fuel in gasoline tank
Vent in gas cap plugged
Water or dirt in fuel system
Dirty air cleaner
Carburetor out of adjustment
Engine oil level low
Air flow restricted
Dirty air filter
Carburetor not adjusted properly
Excessive Vibration
Replace edger blade.
Contact an authorized MTD service dealer.
Edger blade bent or damaged
Blade spindle bent or damaged
Drivebelt Slips
Replace drive belt.Belt worn or stretched
Troubleshooting Guide
For parts and/or
accessories please
call 1-800-520-5520,
or 1-330-558-7220
or log onto
www.troybilt.com
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
14
9
Part List:
Spindle Assembly
Model 554
V-BELTS are specially designed to engage and disen-
gage safely. A substitute (non-OEM) V-Belt can
be dangerous by not disengaging completely.
For parts and/or
accessories please
call 1-866-840-6483,
or 1-330-558-7220.
www.troybilt.com
† Optional
Ref. Part No. Description
1 687-02126 Blade Plate Assembly
2 710-04389 Hex Screw, 5/16-18
3 710-0599 Self-tapping Screw, 1/4-20
4 710-1143A Hex Screw, 5/8-18
5 712-0417A Flange Nut, 5/8-18
6 714-3010 Clevis Pin 3/32 x .625
7 718-04012 Bearing Cup
8 731-04207 Bearing Block
9 731-05064 Blade Guard
10 732-0188A Double Torsion Spring
11 732-04169 Compression Spring
12 736-04088 Flat Washer .635x1.24x.181
Ref. Part No. Description
13 738-0706C Shoulder Screw
14 741-0524 Bearing, .625 ID x 1.57 OD
15 747-04110 Blade Adjustment Rod
16 750-04105 Spacer, .63 x 1.12 x 1.06
17 750-0547 Spacer, .64 x.88 x .50
18 754-04032B Belt
19 756-0449 Sheave
20 781-0427 Belt Guard
21 787-01081A Cover Plate
22 781-0080 Edger Blade
23 736-04088 Flat Washer †
24 781-0748 Tri-Star Blade (Trencher) †
23
24
Tri-Star Trencher Blade &
Flat Washer
8
11
1
7
1
4
1
9
3
1
8
1
9
1
6
1
4
7
1
2
1
3
9
2
0
A
2
5
22
10
6
15
21
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
15
9
Part List:
Handle/Frame/
Wheel Assembly
Model 554
14
11
3
9
6
1
2
8
8
6
34
7
13
12
18
17
11
21
20
24
5
10
16
4
23
26
15
25
22
19
A
29
32
41
40
31
36
38
43
35
30
42
33
43
44
39
32
28
37
27
For parts and/or
accessories please
call 1-866-840-6483,
or 1-330-558-7220.
www.troybilt.com
Ref. Part No. Description
1 710-0191 Screw 3/8-24
2 710-0411 Screw 3/8-16
3 710-0654A Screw, 3/8-16
4 712-04065 Flange Lock Nut, 3/8-16
5 731-05063 Debris Guard
6 736-0452 Bell Washer,.396 x 1.140
7 750-04142 Pulley Mount Spacer
8 756-04148 Flat Idler Pulley, 2.5 OD
9 756-1150A Combination Flywheel Pulley
10 787-01304 Frame
11 710-0726 Hex Screw, 5/16-12
12 710-1174 Carriage Bolt, 5/16-18
13 710-1205 Rope Guide (Eye Bolt)
14 710-3180 Hex Screw, 5/16-18
15 712-04063 Lock Flange Nut, 5/16-18
16 720-0142 Grip
17 720-0279 Wing Nut
18 720-04072 Hand Knob
19 732-0369 Compression Spring
20 746-04035 Control Cable (Briggs & Stratton)
21 746-04036 Wheel Adjustment Cable
22 747-0976A Bail Handle
23 749-04183 Upper Handle
Ref. Part No. Description
24 749-04234 Lower Handle
25 781-0741A Depth Index Bracket
26 781-0742 Depth Index Lever
27 687-02022 Curb Height Adjustment Lever
28 687-02125 Curb Height Adjuster Plate
29 710-0870 Hex Screw 5/16-18
30 711-04361 Axle Shaft .50x6.65
31 711-04440 Frame Spacer .50x9.25
32 712-04065 Flange Nut 3/8-16
33 726-0299 Push Cap 1/2” rod
34 732-04045 Torsion Spring
35 734-1264 Wheel 7 x 1.75 T-Tread †
734-1988 Spoke Bar Wheel 7 x 1.8
36 734-1268 Wheel 8 x 1.75 T-Tread †
734-1987 Spoke Bar Wheel 8 x 1.8
37 736-0234 Flat Washer, .385 x 1.5 x .075
38 738-04149 Shoulder Screw, 3/8-16
39 738-0929 Shoulder Screw, 3/8-16
40 750-04129 Spacer
41 787-01239 Dual Wheel Bracket
42 736-0179 Flat Washer 1/2 x 1.25 x .10 †
43 736-0232 Wave Washer .531 x .781 x .013 †
44 736-0258 Flat Washer .385 x 1.0 x .135 †
† Optional
NOTE: Specifications are
subject to change without
notification or obligation.
Images my not reflect your
exact model and are for
reference purposes only.
The limited warranty set forth below is given by Troy-Bilt LLC with respect
to new merchandise purchased and used in the United States, its posses-
sions and territories.
“Troy-Bilt” warrants this product against defects in material and workman-
ship for a period of two (2) years commencing on the date of original
purchase and will, at its option, repair or replace, free of charge, any part
found to be defective in materials or workmanship. This limited warranty
shall only apply if this product has been operated and maintained in
accordance with the Operator’s Manual furnished with the product, and
has not been subject to misuse, abuse, commercial use, neglect, accident,
improper maintenance, alteration, vandalism, theft, fire, water, or damage
because of other peril or natural disaster. Damage resulting from the
installation or use of any part, accessory or attachment not approved by
Troy-Bilt for use with the product(s) covered by this manual will void your
warranty as to any resulting damage.
Normal wear parts are warranted to be free from defects in material and
workmanship for a period of thirty (30) days from the date of purchase.
Normal wear parts include, but are not limited to items such as: batteries,
belts, blades, blade adapters, grass bags, rider deck wheels, seats, snow
thrower skid shoes, shave plates, auger spiral rubber and tires.
HOW TO OBTAIN SERVICE: Warranty service is available, WITH
PROOF OF PURCHASE, through your local authorized service
dealer. To locate the dealer in your area, check your Yellow Pages,
or contact Troy-Bilt LLC at P.O. Box 361131, Cleveland, Ohio 44136-
0019, or call 1-866-840-6483 or 1-330-558-7220, or log on to our
Web site at www.troybilt.com.
This limited warranty does not provide coverage in the following cases:
a. The engine or component parts thereof. These items may
carry a separate manufacturer’s warranty. Refer to applicable
manufacturer’s warranty for terms and conditions.
b. Log splitter pumps, valves, and cylinders have a separate one
year warranty.
c. Routine maintenance items such as lubricants, filters, blade
sharpening, tune-ups, brake adjustments, clutch adjustments,
deck adjustments, and normal deterioration of the exterior finish
due to use or exposure.
d. Service completed by someone other than an authorized service
dealer.
e. Troy-Bilt does not extend any warranty for products sold or
exported outside of the United States, its possessions and
territories, except those sold through Troy-Bilt’s authorized
channels of export distribution.
f. Replacement parts that are not genuine Troy-Bilt parts.
g. Transportation charges and service calls.
No implied warranty, including any implied warranty of merchant-
ability of fitness for a particular purpose, applies after the applicable
period of express written warranty above as to the parts as identi-
fied. No other express warranty, whether written or oral, except as
mentioned above, given by any person or entity, including a dealer or
retailer, with respect to any product, shall bind Troy-Bilt. During the
period of the warranty, the exclusive remedy is repair or replacement
of the product as set forth above.
The provisions as set forth in this warranty provide the sole and
exclusive remedy arising from the sale. Troy-Bilt shall not be liable
for incidental or consequential loss or damage including, without
limitation, expenses incurred for substitute or replacement lawn care
services or for rental expenses to temporarily replace a warranted
product.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied warranty
lasts, so the above exclusions or limitations may not apply to you.
In no event shall recovery of any kind be greater than the amount of the
purchase price of the product sold. Alteration of safety features of the
product shall void this warranty. You assume the risk and liability for
loss, damage, or injury to you and your property and/or to others and their
property arising out of the misuse or inability to use the product.
This limited warranty shall not extend to anyone other than the original
purchaser or to the person for whom it was purchased as a gift.
HOW STATE LAW RELATES TO THIS WARRANTY: This limited war-
ranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
IMPORTANT: Owner must present Original Proof of Purchase to obtain
warranty coverage.
TROYBILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019; Phone: 1(866) 840-6483, 1-330-558-7220
MANUFACTURER’S LIMITED WARRANTY FOR
