20V CORDLESS SMD LED 1800LM WORK
LIGHT - BODY ONLY
MODEL NO: CP20VCL
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
I
MP
PO
R
RTA
TA
NT:
PLEA
S
E READ THE
S
E IN
S
TRU
C
TI
O
N
S
C
AREFULLY. N
O
TE THE
S
AFE
O
PERATI
O
NAL RE
Q
UIREMENT
S
, WARNIN
GS
&
C
AUTI
O
N
S
. U
S
E
TH
HE
P
PR
O
ODU
C
T
CO
RRE
C
TLY AND WITH
C
ARE F
O
R THE P
U
RP
OS
E F
O
R WHI
C
H IT I
S
INTENDED. FAIL
U
RE T
O
D
O
SO
MAY
C
A
US
E DAMA
G
E AND
/O
R
PE
ER
S
SON
N
AL IN
JU
RY AND WILL INVALIDATE THE WARRANTY. KEEP TH
ESE
IN
STR
UCT
ION
S S
AFE
FO
R F
U
T
U
RE
USE
.
1. SAFETY
Ensure the work light is switched off before installing the battery pack.
Ensure the battery pack (sold separately) is correctly inserted into the work light and latched in place before attempting to switch
on.
Maintain the work light in good condition.
Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
DO NOT shine directly into your, another person’s or animal’s eyes.
DO NOT allow children to use the lamp.
DO NOT cover or block the lens during use.
DO NOT get the work light wet or use in damp or wet locations or in areas where there is condensation.
Store the work light in the original box, in a safe, dry, childproof area.
2. INTRODUCTION
Cordless clip work light useful in any workspace. Robust design with integrated carry handle and 360° movement. SMD LED Technology
for ultra-bright illumination with 70 SMD LED lights producing 1800 lumens. Simple on/off switch with four levels of brightness. IP20 Rated.
Powered by 20V Lithium-ion battery (not included).
3. SPECIFICATION
Model No: .............................................................. CP20VCL
Battery: ......................... 20V 2Ah - Lithium-ion (not included)
Options: .................................................................................
2Ah: ..................................................................... CP20VBP2
4Ah: ..................................................................... CP20VBP4
6Ah: ..................................................................... CP20VBP6
IP Rating: ........................................................................IP20
IK Rating: ........................................................................IK07
LED Qty: ............................................................................ 70
LED type: .................................................... SMD LED 6500K
Lumen output: ........... 1800lm Max with 4 levels of brightness
.................................................. (25%, 50%, 75% and 100%)
Operating time: ......................................................................
2Ah CP20VBP2: ..................................................2hrs 30mins
4Ah CP20VBP4: .............................................................. 5hrs
6Ah CP20VBP6: ..................................................7hrs 30mins
Power: .............................................................................15W
4. OPERATION
Unpack the product and check contents. Should there be any damaged or missing parts contact your supplier immediately.
4.1. BATTERY INSTALLATION
4.1.1. To insert the battery align the tongues on the battery cartridge with the grooves on the rear of the work light, and slide into place.
Insert the battery all the way until it locks into place.
4.2. BATTERY REMOVAL
4.2.1. Hold the work light fi rmly and push the battery latch button, then slide and remove the battery.
4.3. TURNING THE WORK LIGHT ON AND OFF
4.3.1. The ON/OFF switch is located on the rear of the work light (fi g 1). Press once for 25% brightness, through to four times for 100%
brightness. Then press once to turn the work light off .
4.4. ROTATING THE WORK LIGHT
4.4.1. Firmly hold the base/handle and rotate the work light, through 360º, to the required angle (fi g 2).
CP20VCL Issue 1 05/10/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Warning: Do not
look directly into
the light
4.5. CLAMPING THE WORK LIGHT
4.5.1. Using both hands compress the clamps together and clamp the work light in a suitable position, pushing the clamps fully onto the
clamping surface. Orientate the work light to suit (fi g 2).
NOTE: Ensure the clamping surface is capable of supporting the weight of the work light and the battery. Ensure that there is
adequate space for the work light to function properly.
5. MAINTENANCE
5.1. Clean with a clean cloth.
DO NOT use solvents to clean the work light.
CP20VCL Issue 1 05/10/21
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
