15W / 27W / 48W LED SQUARE WORK LIGHT
WITH MOUNTING BRACKET
MODEL NO: LED2S / LED3S / LED5S
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator to read, understand and comply
with the following: You must check all electrical products, before use, to ensure that they are safe. You
must inspect power cables, plugs, sockets and any other connectors for wear or damage.
1.1.1. Ensure that cables are always protected against short circuit and overload.
1.1.2. Regularly inspect power supply cables check all connections to ensure that none are loose.
IMPORTANT: Ensure that the voltage marked on the appliance matches the power supply to be
used and that the circuit is fitted with the correct fuse. If in doubt, consult a qualified technician to
connect the floodlight to a fused and switched DC supply.
8 DO NOT pull or carry the floodlight by the power cable.
8 DO NOT use worn or damaged cables, plugs or connectors.
9 Immediately have any faulty item repaired or replaced by a qualified technician.
2. INTRODUCTION
Model No. LED2S
5 x 3W Epistar™ high power LEDs. Produces up to 1200 lumens output. Operating voltage of 10-30V DC.
Waterproof rating of IP68. ECE R10 Certied and E-Marked. Suitable replacement for traditional halogen work
lights. Powder coated die-cast aluminium housing. Adjustable grade 201 shock-resistant stainless steel bracket.
Model No. LED3S
9 x 3W Epistar™ high power LEDs. Produces up to 2160 lumens output. Operating voltage of 10-30V DC.
Waterproof rating of IP68. ECE R10 Certied and E-Marked. Suitable replacement for traditional halogen work
lights. Powder coated die casting aluminium housing. Adjustable grade 201 shock-resistant stainless steel bracket.
Model No. LED5S
16 x 3W Epistar™ high power LEDs. Produces up to 3840 lumens output. Operating voltage of 10-30V DC.
Waterproof rating of IP68. ECE R10 Certied and E-Marked. Suitable replacement for traditional halogen work
lights. Powder coated die-cast aluminium housing. Adjustable grade 201 shock-resistant stainless steel bracket.
3. SPECIFICATION
Model No: ................ LED2S ................... LED3S ...................LED5S
Lumen Output: ............. 1200lm ...................2160lm ...................3840lm
Power: ......................15W ..................... 27W .....................48W
Supply: ............... 10-30V DC ................10-30V DC ................10-30V DC
Size (W x H): ...........83 x 83mm ..............108 x 108mm ..............108 x 108mm
Nett Weight: . . . . . . . . . . . . . . . 0.32kg ....................0.42kg ...................0.59kg
LED2S / LED3S / LED5S | Issue 1 13/03/19
Original Language Version
© Jack Sealey Limited
Refer to
instructions
LED2S
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
LED3S
LED5S
