1360MM MODULAR 7 DRAWER FLOOR
CABINET, 680MM 2 DOOR MODULAR WALL
CABINET, 1360MM MODULAR WALL CABINET
MODEL NO: APMS64, APMS65,APMS68
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
storage system.
9 Locate in a suitable work area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use storage on level and solid ground, preferably concrete.
9 Keep the storage system clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT use the storage system for any purpose other than that for which it is designed.
8 DO NOT use the storage system outdoors.
8 DO NOT place the storage system in a damp or wet location or an area where there is condensation.
8 DO NOT clean the storage system with any solvents which may damage the surfaces or the protective coating.
8 DO NOT move the storage system when there are items placed inside.
8 DO NOT step on the shelves.
8 DO NOT overload the storage system.
2. INTRODUCTION
APMS64/APMS68
Modular storage system ideal for any garage or workshop. Durable construction that will last for years. Easily adjusts to specic needs.
Purchase a simple base cabinet or create a full workshop storage system. All pieces are fully welded except Model No’s APMS55 and APMS56
Floor Cabinets which require simple assembly.
APMS65
For use with Model No’s APMS51, APMS52, APMS57, APMS59, APMS64 Floor Cabinets. Supplied with appropriate xings to make integral
self-supporting unit, or use in conjunction with Model No. APMS50BP Back Panel and upright supports if part of a larger modular system. Two
door cabinet with a high quality lock supplied with two keys. Aluminium handles.
3. SPECIFICATION
Model No:................................................................APMS64
Overall Size: .........................................1360 x 460 x 910mm
Small Draw (x5): .......................................800 x 400 x 55mm
Medium Draw (x1): ..................................800 x 400 x 135mm
Large Draw (x1): .....................................1250 x 400 x 85mm
Cupboard: ...............................................510 x 620 x 420mm
Model No:............................................................... APMS65
Overall Size (W x D x H): ........................680 x 280 x 350mm
Model No:................................................................APMS68
Overall Size: .........................................1360 x 280 x 350mm
4. ASSEMBLY
APMS64, APMS65, APMS68 Issue 1 21/12/2021
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
g.1
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
g.2
g.3
g.4
Original Language Version
© Jack Sealey Limited
APMS64, APMS65, APMS68 Issue 1 21/12/2021
APMS68
