1
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this
manual carefully paying particular attention to the
safety instructions. Failure to do so may result in
personal injury or damage to the product.
Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the product on
to any third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating instructions
before using this 8 in 1 Health Grill & Air Fryer.
• DO NOT touch hot surfaces. Use the handles provided.
• Always ensure that the voltage on the rating label corresponds
with the voltage in your home.
• Keep the appliance out of the reach of children.
• Keep the mains lead away from the body of the Health Grill &
Air Fryer.
• DO NOT leave the appliance unattended whilst operating.
• Disconnect the appliance from the mains after use.
• To disconnect the appliance grip and pull the mains plug.
• DO NOT pull the power cord.
• DO NOT wrap the power cord around the appliance in use or
during storage.
• Always disconnect the plug from the mains before cleaning.
Wipe clean only, do not immerse the unit, plug or cord in water
or any other liquid.
• Always allow the unit to cool before storage or cleaning.
• Retain the instruction manual for future use and reference.
There are no user serviceable parts, if the unit fails, consult a
3
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
qualified electrician, a repair centre or contact the supplier if
the unit is under warranty.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
• It is recommended that this appliance should not be operated
in conjunction with an electrical extension lead.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
• For indoor use only.
• Keep away from splashes of water or damp conditions.
• For domestic use only.
• Never place this appliance near to flammable material or high
pressure containers.
• DO NOT use accessories with this appliance other than those
recommended by the supplier.
• DO NOT use this product with an external programmer, timer,
separate remote control system or any other device.
• DO NOT touch hot surfaces. Accessible surfaces are liable to
get hot during use. Always use the handles.
• Oven gloves should be worn when using this appliance.
• Hot steam may be released when opening and closing the
appliance during use – Risk of scalding!
• WARNING! Avoid moving the appliance whilst it is still hot or
contains hot food or liquids. Turn the appliance off and
disconnect from the mains and let it cool sufficiently before
moving it.
• Always carry the appliance with both hands. Always use oven
gloves. Burn hazard!
4
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
THIS APPLIANCE MUST BE EARTHED
Additional Safety Information
• PLEASE NOTE: Before use, ensure that the Health Grill & Air
Fryer is used in an open, well ventilated area well away from
other appliances and other obstructions.
• Do not use the Health Grill & Air Fryer in front of, near or
below combustible materials such as plastics, curtains or
cupboards, etc.
• Do not place the appliance against a wall or against other
appliances. Leave at least 10cm minimum free space on the
back and sides and 10cm minimum free space above the
appliance.
• Do not place anything on top of the appliance.
The diagram above shows the rear of the
air fryer and the air vent outlets arrowed
Keep these areas free and clear from
obstructions as directed above
5
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk to
find your nearest recycling point.
WARNING!
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This Symbol indicates that the surface gets hot and care must be
taken.
Introduction
This household Health Grill & Air Fryer cooks using little or no oil, allowing
healthier cooking.
If a little oil is required for extra browning for example, use a moderate amount of
spray type cooking oil.
The Health Grill & Air Fryer will quickly cook your food using rapid cycling airflow
of hot air.
WARNING! DO NOT fill your Health Grill & Air Fryer with cooking oil as this
will cause a fire and scolding hazard.
This designates a hazard with moderate risk, which may result in
severe injury if not adhered to.
6
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Air outlet (Rear)
2. Air Filter
3. Hood
4. Handle
5. Control Panel
6. Non-Stick Crisper Basket
7. Silicone Food Tongs
8. Splatter Shield (Removable)
9. Non-Stick Grill Plate
10. Non-Stick Inner Pot
11. Cleaning Brush
DO NOT use metal cooking tools with this Health Grill & Air Fryer as damage may
occur to the non-stick coating. Only use wooden or plastic (nylon) tools with your
Health Grill & Air Fryer.
Description of Parts
Before the First Use of Your Health Grill & Air Fryer
• Remove all packing materials and discard responsibly.
• Ensure all parts are present see Description of Parts above.
• Check that there is no damage to the mains cable or product.
• Ensure that you clean your Health Grill & Air Fryer before first and every use.
Whilst using your Health Grill & Air Fryer for the first time you may notice a little
smoke and odour; this is normal and simply the grease used during manufacture
and will soon pass.
1
2
3
4
5
6
7
8
9
10
11
7
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
12. LED Display
13. Additional Functions for Recipes
14. Grill Functions
15. Start/Stop Button
16. Pre-Set Cooking Functions
17. Temperature Settings
18. Time Settings
19. Power On/Off Button
Description of Parts – Control Panel (5)
Explanation of Control Panel (5)
Power Button
Once the Air Fryer is plugged into the mains supply, press the Power On/Off Button
(19) to turn on the Health Grill & Air Fryer. It will then enter into ‘Standby Mode’,
the LED on the Power On/Off Button (19) will illuminate and the LED Display (12)
will turn on. Whilst the Health Grill & Air Fryer is in use pressing the Power On/Off
Button (19) will stop the current mode and will turn off the unit.
Once the cooking process has completed, the Health Grill & Air Fryer will ‘beep’ 5
times and the LED Display (12) will show “END”, only the LED of the Power On/Off
Button (19) will illuminate. The Heating element will cease, however the fan motor
will continue to operate for approximately 60 seconds before the unit will enter into
‘Switch Off’ mode.
Time Settings
Using the left/right arrows of the Time Settings (18) to manually adjust the cooking
time in any of the pre-set cooking functions, Left arrow will decrease the time and
the Right arrow will increase the time in increments of 1 minute accordingly
dependent on the function mode. Press and hold the left/right arrows down for
more than 2 seconds to decrease/increase the temperature in increments of 5
minutes accordingly dependent on the function mode.
12
13
14
15
16
17
18
19
8
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Temperature Settings
Using the left/right arrows of the Temperature Settings (17) to manually adjust the
cooking temperature in any of the pre-set cooking functions, Left arrow will
decrease the temperature and the Right arrow will increase the temperature in
increments of 5°C accordingly dependent on the function mode. Press and hold the
left/right arrows down for more than 2 seconds to decrease/increase the
temperature in increments of 10°C accordingly dependent on the function mode.
When using the ‘Grill’ function mode there are 4 temperature pre-sets (Low, Med,
High, Max) pressing the left/right arrows will cycle through the temperature pre-
sets.
Start/Stop Button
After selecting the desired temperature and time for your chosen recipe or
following the pre-set cooking function, press the Start/Stop Button (15) to begin
the cooking process. During the cooking process pressing the Start/Stop Button
(15) will pause the Health Grill & Air Fryer, the LED Display (12) will show “----“.
Press the Start/Stop Button (15) to commence cooking. To change function during
either preheat or cooking process, press the Start/Stop Button (15) and then
select the correct function from the Pre-Set Cooking Functions (16) below.
Standby Mode
The Health Grill & Air Fryer will automatically go into ‘Standby Mode’ after a
period of inactivity, if no function is selected or if not partway through
preheat/cooking process for a period of 1 minute approximately. The Health Grill
& Air Fryer will also automatically go into ‘Standby Mode’ after a period of
inactivity, or if no interaction is made with the control panel for a period of 5
minutes approximately. To wake the Health Grill & Air Fryer at any point simply
press any button or function on the Control Panel (5).
To adjust the LED Display (12) to display °C or °F, whilst in ‘Standby Mode’
press both the right arrow of the Temperature Settings (17) and the ‘Broil’
function from the Pre-Set Cooking Functions (16) simultaneously. LED Display
(12) will show either “F” or “C”, to confirm continue to press and hold for
approximately 3 seconds.
During the preheat and cooking process, the temperature can be adjusted in
the same way as per the above.
9
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Preheat Indicator
When using the Pre-Set Cooking Functions (16) below, all functions with the
exception of both the ‘Dehydrate’ and ‘Broil’ will automatically preheat prior to
addition of ingredients and cooking process. During the ‘Preheat’ stage the
Preheat indicator will illuminate, time and temperature cannot be adjusted
during this process.
Preheating will take around 5 minutes approximately depending on function
and temperature selected.
If preheat process is not required, simply press the chosen function again to
cancel and the ‘Add Food’ Indicator should now illuminate to indicate
ingredients can be added and cooking process can begin.
Add food Indicator
When using the Pre-Set Cooking Functions (16) below, the Health Grill & Air
Fryer will ‘beep’ 5 times and the ‘Add Food’ Indicator will illuminate to show
that ingredients can be added to the Health Grill & Air Fryer and cooking process
can begin. Open the Hood (3) and place the ingredients to be cooked onto the
chosen cooking plate for that function and close the Hood (3). Once closed
cooking process will begin and the timer will count down from selected time.
During the cooking process if the Hood (3) is lifted the Health Grill & Air Fryer
will pause the chosen function until Hood (3) is replaced.
If the Hood (3) is not lifted to add food when above indicator illuminates, the
Health Grill & Air Fryer will continue to preheat.
If after 30 minutes the Hood (3) has not been lifted to add food, the Health
Grill & Air Fryer will automatically switch off.
10
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Pre-Set Cooking Functions
Grill
1. Place the Non-Stick Inner Pot (10) into the unit with
the indent on the pot aligned with the rear bump on
the main unit.
2. Place the Non-Stick Grill Plate (9) into the Non-Stick
Inner Pot (10).
3. Press the ‘Grill’ function from the Pre-Set Cooking
Functions (16) on the Control Panel (5).
The default temperature is High & 205°C and default
cooking time is 20 minutes.
1. To adjust the temperature for chosen recipe, either press the
‘Grill’ again from the Pre-Set Cooking Functions (16) or the
Temperature Settings (17) to cycle through the 4 temperature
settings, Low (150°C), Med (175°C), High (205°C), and Max
(230°C).
2. To adjust the time press the Time Settings (18) to adjust the
cooking time from 1 minute to 30 minutes in 1minute increments.
3. Press the Start/Stop Button (15) to begin preheating.
The ‘Preheat’ will illuminate whilst the Health Grill & Air Fryer preheats.
4. When preheating is complete, the light will turn off and ‘beep’ 5 times.
5. The ‘Add Food’ on the Additional Functions for Recipes (13) will
illuminate.
6. Lift the Hood (3) and place ingredients to be cooked onto the Non-Stick Grill
Plate (9), once the Hood (3) is closed the cooking process will begin and the
timer will begin counting down on the LED Display (12).
During cooking you can lift the Hood (3) to check on contents, the timer will
pause and then will automatically resume once the Hood (3) has been closed.
7. When the cooking time has completed, the Health Grill & Air Fryer will ‘beep’
5 times and the LED Display (12) will show ‘END’.
Keep the Hood (3) open when cooked food has been removed to allow the
unit to cool down.
+
-
+
-
11
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Grill Control
When using Grill Functions (14) you will need to select the temperature settings.
Below are the recommended temperatures and suggested ingredients.
LOW 150⁰C /300⁰F
MED 175⁰C /350⁰F
HIGH 205⁰C /400⁰F
MAX 230⁰C /450⁰F
Bacon, Sausages
Frozen Meals
Steaks
Fruit
Calzone
Marinated sauce
meat
Chicken wings
Frozen Seafood
Whole Chicken
Kebab
Hot Dog
When cooking steak, use the below temperature guide to cook to your desired
consistency.
Air Crisp
1. Place the Non-Stick Inner Pot (10) in the Health Grill &
Air Fryer and place Non-Stick Crisper Basket (6) on top
and close the Hood (3).
2. Press the ‘Air Crisp’ function from the Pre-Set Cooking
Functions (16) on the Control Panel (5).
The default temperatures settings is 205⁰C and default
time is 18 min.
3. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 230°C.
4. To adjust the time press the Time Settings (18) to adjust the cooking time from
1 minute to 60 minutes in 1minute increments.
5. Press the Start/Stop Button (15) to begin preheating.
The ‘Preheat’ will illuminate whilst the Health Grill & Air Fryer preheats.
6. When preheating is complete, the light will turn off and ‘beep’ 5 times.
7. The ‘Add Food’ on the Additional Functions for Recipes (13) will illuminate.
LOW
MED
HIGH
MAX
Medium Rare
Medium
Medium Well
Well Done
12
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
8. Lift the Hood (3) and place ingredients to be cooked onto the Non-Stick Grill
Plate (9), once the Hood (3) is closed the cooking process will begin and the
timer will begin counting down on the LED Display (12).
For best results we recommend shaking ingredients frequently, use the
Silicone Food Tongs (7) when tossing your food or oven gloves to shake the
Non-Stick Crisper Basket (6). The timer will pause when the Hood (3) is
opened and then automatically resume after it is closed.
Roast
1. Place the Non-Stick Inner Pot (10) in the Health Grill &
Air Fryer and place Non-Stick Crisper Basket (6) on top
and close the Hood (3).
2. Press the ‘Roast’ function from the Pre-Set Cooking
Functions (16) on the Control Panel (5).
The default temperatures settings is 205⁰C and default
time is 25 min.
3. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 220°C.
4. To adjust the time press the Time Settings (18) to adjust the cooking time from
1 minute to 240 minutes in 1minute increments.
5. Press the Start/Stop Button (15) to begin preheating.
The ‘Preheat’ will illuminate whilst the Health Grill & Air Fryer preheats.
6. When preheating is complete, the light will turn off and ‘beep’ 5 times.
7. The ‘Add Food’ on the Additional Functions for Recipes (13) will illuminate.
8. Lift the Hood (3) and place ingredients to be cooked onto the Non-Stick Grill
Plate (9), once the Hood (3) is closed the cooking process will begin and the
timer will begin counting down on the LED Display (12).
13
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Bake
1. Place the Non-Stick Inner Pot (10) in the Health Grill
& Air Fryer.
2. Press the ‘Bake’ function from the Pre-Set Cooking
Functions (16) on the Control Panel (5).
The default temperatures settings is 175⁰C and
default time is 25 min.
3. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 205°C.
4. To adjust the time press the Time Settings (18) to adjust the cooking time from
1 minute to 120 minutes in 1minute increments.
5. Press the Start/Stop Button (15) to begin preheating.
The ‘Preheat’ will illuminate whilst the Health Grill & Air Fryer preheats.
6. When preheating is complete, the light will turn off and ‘beep’ 5 times.
7. The ‘Add Food’ on the Additional Functions for Recipes (13) will illuminate.
8. Lift the Hood (3) and place ingredients to be cooked onto the Non-Stick Inner
Pot (10), once the Hood (3) is closed the cooking process will begin and the
timer will begin counting down on the LED Display (12).
Dehydrate
1. Place the Non-Stick Inner Pot (10) in the Health
Grill & Air Fryer.
2. Press the ‘Dehydrate’ function from the Pre-Set
Cooking Functions (16) on the Control Panel (5).
The default temperatures settings is 50⁰C and
default time is 360 min.
3. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 90°C.
4. To adjust the time press the Time Settings (18) to adjust the cooking time from
30 minutes to 24 hours in 1minute increments.
5. Press the Start/Stop Button (15) to begin dehydration cooking process.
The Health Grill & Air Fryer does not preheat in ‘Dehydrate’ function.
14
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Pizza
1. Place the Non-Stick Inner Pot (10) in the Health Grill
& Air Fryer.
2. Place the Non-Stick Grill Plate (9) into the Non-Stick
Inner Pot (10).
3. Press the ‘Pizza’ function from the Pre-Set Cooking
Functions (16) on the Control Panel (5).
The default temperatures settings is 195⁰C and
default time is 25 min.
4. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 205°C.
5. To adjust the time press the Time Settings (18) to adjust the cooking time from
1 minute to 90 minutes in 1minute increments.
6. Press the Start/Stop Button (15) to begin preheating.
The ‘Preheat’ will illuminate whilst the Health Grill & Air Fryer preheats.
7. When preheating is complete, the light will turn off and ‘beep’ 5 times.
8. The ‘Add Food’ on the Additional Functions for Recipes (13) will illuminate.
9. Lift the Hood (3) and place ingredients to be cooked onto the Non-Stick Inner
Pot (10), once the Hood (3) is closed the cooking process will begin and the
timer will begin counting down on the LED Display (12).
Broil
1. Place the Non-Stick Inner Pot (10) in the Health Grill
& Air Fryer.
2. Press the ‘Broil’ function from the Pre-Set Cooking
Functions (16) on the Control Panel (5).
The default temperatures settings is 205⁰C and
default time is 10 min.
3. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 230°C.
4. To adjust the time press the Time Settings (18) to adjust the cooking time from
1 minute to 60 minutes in 1minute increments.
5. Press the Start/Stop Button (15) to begin preheating.
The Health Grill & Air Fryer does not preheat in ‘Broil’ function.
15
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Manual
1. Place the Non-Stick Inner Pot (10), Non-Stick Crisper Basket (6) and/or Non-
Stick Grill Plate (9) in the Health Grill & Air Fryer.
2. Press the ‘Manual’ function from the Pre-Set Cooking Functions (16) on the
Control Panel (5).
The default temperatures settings is 50⁰C and default time is 1 min.
3. To adjust the temperature for chosen recipe, press the Temperature Settings
(17) to adjust the temperature setting from 50°C to 230°C.
4. To adjust the time press the Time Settings (18) to adjust the cooking time from
1 minute to 120 minutes in 1minute increments.
5. Press the Start/Stop Button (15) to begin preheating.
The ‘Preheat’ will illuminate whilst the Health Grill & Air Fryer preheats.
6. When preheating is complete, the light will turn off and ‘beep’ 5 times.
7. The ‘Add Food’ on the Additional Functions for Recipes (13) will illuminate.
8. Lift the Hood (3) and place ingredients to be cooked onto the Non-Stick Inner
Pot (10), once the Hood (3) is closed the cooking process will begin and the
timer will begin counting down on the LED Display (12).
16
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Instructions for use
1. Place the Health Grill & Air Fryer on a solid, level, heat resistant surface clear of
all obstructions as described above.
2. Insert the mains plug into a suitable socket outlet.
WARNING! Take care whilst handling the Crisper Basket, Grill Plate,
Inner Pot the use of Oven Gloves are recommended.
3. Ensure that the Splatter Shield (8) is securely in place
on the underside of the Hood (3).
The Splatter Shield (8) keeps the heating element
clean. Failure to use it will result in oil build-up on the
heating element and can cause smoking.
To remove the Splatter Shield (8), to clean;
• Pull Locking System (arrow 1)
• Release Splatter Shield (8) (arrow 2)
To install the Splatter Shield (8);
• Gently push the Splatter Shield (8) into the
underside of the Hood (3).
• Insert the back of the Splatter Shield (8) into the
tab on the Hood (3).
• Push the Splatter Shield (8) upwards, until it clicks
into place.
Cleaning and Maintenance of your Health Grill & Air Fryer
• Always unplug the Health Grill & Air Fryer from the mains supply and allow to
cool before cleaning.
• DO NOT clean any part of the Health Grill & Air Fryer in a dishwasher – NOT
dishwasher safe.
• DO NOT submerge any part of the main body, the mains cable or mains plug in
water or any other liquids.
• Wipe excess oil from the Cooking Accessories with kitchen roll or similar.
• Wipe the main body of the Health Grill & Air Fryer clean using a soft, damp
cloth.
• The Cooking Accessories can be washed in warm soapy water, rinse and dry
thoroughly before reusing.
• Never clean any part of the Health Grill & Air Fryer with harsh or abrasive
cleaners.
1
2
17
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• After cleaning, allow the product to thoroughly dry before re-use.
• For burnt on food or stubborn marks you can use the Cleaning Brush (11)
supplied.
Technical Specification
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician. If you need to remove the plug-
DISCONNECT FROM THE MAINS- and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk to find
your nearest recycling point.
Rated Voltage
220-240V~ 50-60Hz
Rated Power
1500-1700W
Model Number
SDA2479
Protection Class
I (This appliance must be earthed)
18
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Place the potato strips into the Fryer Drawer, insert the drawer back into the Air fryer and set the
timer for 20-25 minutes - depending on the number of fries or until the fries are golden brown.
For best results, turn the fries by shaking the Fryer Drawer in the middle of cooking.
Recipes for You to Try……
1. Asian Spicy Fries
Potato x4 / 600g
Oil 2 teaspoons
Salt 1 teaspoon
Pepper powder 1 teaspoon
Shallot powder 1 teaspoon
Red chili powder ½ teaspoon
● Peel potatoes and cut into strips;
● Soak potato strips in salt water for at
least 20mins, and then dry with kitchen
paper.
● Mix shallot, salt and pepper, garlic
powder/ garlic oil, red chili powder, stir in
the potato strips.
● Set temperature to 180 degrees and
time to 5 minutes to preheat the air fryer.
2. Golden Chicken Wings
Chicken wings 500g
Garlic x2
Ginger powder 2 teaspoon
Cumin powder 1 teaspoon
Black pepper powder 1 teaspoon
Sweet chili sauce 100 mg
● Set temperature to 200 degrees and
timer to 5 minutes to preheat the air fryer.
● Stir garlic, ginger powder, cumin powder,
spicy black pepper and a little salt together,
and then coat the chicken wings.
● Allow the chicken wings to stand for 20
minutes.
• Place the chicken wings into the fryer drawer evenly, set the time for 18-22 minutes and the
temperature for 200 degrees.
19
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Fried chicken nuggets
Fresh chicken nuggets 500g
Eggs x3
Flour 1 cup
Olive oil 1 spoon
White pepper powder 1 teaspoon
● Set the temperature to 200 degrees and
the time to 5 minutes to preheat the air
fryer.
● Pat the chicken for 5 minutes with a knife
blade.
● Stir eggs, flour, olive oil, white pepper
and a little salt together, and then coat the
chicken nuggets.
● Allow the nuggets to stand for 20
minutes.
• Place the chicken nuggets into the fryer drawer evenly, set the time for 15-20 minutes and
the temperature for 200 degrees.
4. Fried squid
Squid (Frozen) 500g
Oil 2 tablespoon
Salt 1 teaspoon
Cumin powder 1 teaspoon
Chicken powder 1 teaspoon
Pepper powder 1 teaspoon
● Set the temperature to 200 degrees
and the timer to 5 minutes to preheat
the air fryer.
● Stir seasoning together, and then coat
the squid and allow to stand for 20
minutes.
• Place the squid into the fryer drawer, set the temperature for 200 degrees and the time for
12-15 minutes or until golden brown.
20
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Spicy Shrimp
Unfrozen prawns x10
Oil 2 tsp
Garlic finely chopped x1
Black pepper 1 tsp
Chili powder 1 tsp
Sweet chili sauce 100mg
● Set the temperature to 200 degrees and
timer to 5 minutes to preheat the air fryer.
● Rinse the prawns.
• Apply a thin layer of salad oil to the prawns, place the prawns into the fryer drawer, set the
temperature for 200 degrees and the time for 5-8 minutes or until a golden crunchy layer has
formed.
21
Health Grill & Air Fryer
Model No. SDA2479
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within
28 days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
