WORKSAFE HALF MASK RESPIRATORS
AND FILTER CARTRIDGES
MODEL NOS: 9360, 9360/61, 9360/62, 9360/63, 9360/66
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure all Health and Safety, local authority, and general workshop practice regulations are strictly adhered to when
using this product.
IMPORTANT! NOT FOR USE WITH TOXIC PAINTS SUCH AS ISOCYANATE.
WARNING! DO NOT use in an oxygen decient atmosphere (below 19% by volume).
WARNING! DO NOT use in an oxygen enriched atmosphere (above 25% by volume).
9 Respirator selection must be undertaken by a competent person who is aware of the intended conditions of use. Only t the
respirator under the supervision of a competent person.
9 If in doubt as to suitability of the equipment for the work to be undertaken, consult your supplier.
9 Before use, check that the mask is clean and in good condition. If you detect deterioration of valve diaphragms, or other rubber
components, replace immediately.
9 Check that the correct cartridge is tted to suit the hazard and that all components are correctly assembled and in a clean condition.
9 Change the main lter cartridge frequently. The eective life of a main lter should be determined by a competent person who is
aware of the conditions of use.
9 Ensure you use recommended parts only, unauthorised parts may be dangerous and will invalidate any warranty.
9 Only when worn correctly tted will the mask provide the prescribed degree of protection.
9 Ensure the face-piece ts comfortably on the face.
WARNING! Mask may not t correctly if facial hair passes under the face-seal.
9 Upon leaving the contaminated area, remove excess contamination from clothes before removing the respirator.
9 After each working period, the respirator must be cleaned and prepared for the next period of use.
8 DO NOT use detergents, thinners, solvents or petroleum-based disinfectant to clean the respirator. Clean the unit with warm soapy
water only.
8 DO NOT allow water to get into the main lter.
9 Care must be taken to ensure the rubber seal on the inside of the lter holder is not damaged.
9 Ensure you keep records of respirator maintenance.
9 When not in use, store the cleaned respirator in a sealed plastic bag in a clean, dry atmosphere out of direct sunlight and out of the
reach of children. Keep unit away from chemicals, abrasive substances and such that it cannot be damaged by physical contact with
hard surfaces/items.
2. INTRODUCTION
Lightweight and dermatologically friendly made from soft thermoplastic elastomer. Built-in exhalation vent makes breathing out easy and
comfortable without letting harmful materials in. Threaded cartridges makes connecting lters easy and ecient. Adjustable straps in order to
optimize comfort and support. S
3. SPECIFICATION
MODEL NO: 9360......(Half Mask - No Cartridges)
MODEL NO: 9360/61 (Half Mask with A1P2R Filter Cartridges)
MODEL NO: 9360/62 (Half Mask with P3R Filter Cartridges)
MODEL NO: 9360/63 (Half Mask with ABEK1 P2R Filter Cartridges)
MODEL NO: 9360/66 (Half Mask with A2P3R Filter Cartridges)
FILTER OPTIONS:
9360, 9360/61, 9360/62, 9360/63, 9360/66 Issue 1 06/09/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Humidity to be
less that 80%
Store between
-5
o
C and 50
o
C
FILTER PART
NUMBER
RATING PROTECTION MAXIMUM USER
LEVELS
Qty.
9361 A1 P2R Organic Vapour and
Particulate Pre-Filter
1000 ppm or 10 x OEL
whichever is lower
2
9362 P3R Particle Filter 30 x OEL 2
9363 ABEK1 P2R OV/IO/AG/AM and
Particulate Pre-lter
1000 ppm or 10 x OEL
whichever is lower
2
9366 A2 P3R Organic Vapour and
Particulate
5000 ppm or 30 x OEL
whichever is lower
2
SPARES:
9364: Pre-lter for 9361 & 9363 (Pack of 10).
9365: Pre-lter xing ring for 9361 & 9363 (Pack of 2).
4. OPERATION
4.1. CHANGING THE FILTER
NOTE: If you unscrew and remove either of the lters and put
them back on, check the seal has not been damaged.
4.2. DURING USE.
4.2.1. In the interest of safety, change the lter frequently.
4.2.2. The eective life of the lter should be determined by a
competent person who is aware of the conditions of use.
4.2.3. Upon leaving the contaminated area, remove excess
contamination from clothes before removing the respirator.
4.3. ASSEMBLY AND FITTING
4.3.1. Screw lter body into the face-mask housing (g.2).
4.3.2. Fit Pre-lter (9361 / 9363) and Pre-lter xing Ring (9365)
to lter body (g.3).
4.3.3. Place head straps over the back of the head and
above the ears (g.4).
4.3.4. Fasten the elastic strap on the back of the neck (g.5).
4.3.5. Pull the ends of the elastic strap evenly until the face mask ts tightly against the user’s face (g.6).
4.3.6. When not in use, store the unit in accordance with instructions section 5.3 (g.7).
5. MAINTENANCE
NOTE: All components have a shelf life of 5 years from date of purchase.
5.1. The lifetime of a lter depends on many factors including the work rate, the airow and the concentration of the contaminant in the
atmosphere. A gas lter should be changed immediately when chemical breakthrough of a contaminant is detected by smell, taste
or any other means. A dust lter should be changed when breathing becomes impaired. The exterior of the lter can be cleaned
with the use of a damp cloth. Solvents must not be used and care should be taken to ensure no water enters the lter. Cleaning of
the lter does not extend its life.
5.2. CLEANING THE RESPIRATOR.
After each work period (shift, or working day, etc.) the respirator must be cleaned and prepared for the next period of use. When the
lter is being replaced it is a good opportunity to disassemble the respirator and thoroughly clean it. No special tools are required to
remove any of the components from the face-piece.
5.2.1. The outer surfaces of the respirator may be cleaned using a cloth dampened with warm soapy water, then dried using a dry cloth.
5.2.2. DO NOT ALLOW WATER TO GET INTO THE FILTER.
5.2.3. Clean the respirator components using warm soapy water.
8 DO NOT USE DETERGENTS, THINNERS, SOLVENTS OR PETROLEUM-BASED DISINFECTANTS. TAKE GREAT CARE NOT
TO DAMAGE THE RUBBER SEAL ON THE INSIDE OF THE FILTER HOLDER WHILST CLEANING.
5.2.4. Inhalation and exhalation valves must be cleaned carefully. DO NOT stretch or distort the valves as this may cause incorrect
sealing. Wipe the inside surface of the mask using a mild antiseptic solution, and dry with a clean cloth.
IF ANY DETERIORATION OF COMPONENTS IS VISIBLE, REPLACE IMMEDIATELY.
5.2.5. Rinse in clean, cool water, shake o any surplus water, wipe with a clean dry cloth and allow to dry naturally.
5.2.6. Once the components are clean and dry, re-assemble the respirator in correct order.
5.2.7. Fit the correct new lter (see Section 3).
g.2 g.3 g.4
g.5
g.6
g.7
g.1
Original Language Version
© Jack Sealey Limited
9360, 9360/61, 9360/62, 9360/63, 9360/66 Issue 1 06/09/21
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
5.3. STORAGE
5.3.1. When not in use or during transportation, this lter should be stored in a sealed container such that it is out of direct sunlight, away
from chemicals, abrasive substances and cannot be damaged by physical contact with hard surfaces/items.
5.3.2. Filters should be stored in a dry, cool environment away from direct sunlight and contamination.
NOTE: Humidity value of storage area to be less than 80%.
NOTE: Storage area temperature to be between -5
o
C to 50
o
C.
5.4. MATERIALS
Part Material
Face Seal Thermoplastic Elastomer (TPE) / Silicon
Head Harness Polyethylene
Head Strap Polyester / Cotton / Polyisoprene
Inhalation Valve Silicon Rubber
Exhalation Valve Silicon Rubber
