BELT DRIVE DRUM FAN
MODELS: 1PAFDRUMBLT36, 1PAFDRUMBLT42
OWNER’S MANUAL
2
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
RULES FOR SAFE OPERATION
READ AND SAVE THESE INSTRUCTIONS
CAUTION
Read and follow all instructions before operating fan.
Do not use fan if any part is damaged or missing.
WARNING
• Toreducetheriskofreorelectricalshock,donotexposetowaterorrain.
• Toreducetheriskofreorelectricalshock,donotusethisfanwithany
solid state speed control device.
• Automatically operated device - To reduce the risk of injury, disconnect from
power supply before servicing.
• Ifthepowersupplycordisdamaged,contactyourlocalservicecenteroraqualied
electrician to install an appropriate replacement cord to prevent any injury or damage.
• The appliance does not apply to be used in locations where special conditions prevail,
suchasthepresenceofacorrosiveorexplosiveatmosphere(dust,vapororgas).
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengiven
supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
RULES FOR SAFE OPERATION:
1
Neverinsertngersoranyotherobjectsthroughthegrillguardwhenfanisinoperation.
2
Disconnect the fan from its power source when moving from one location to another.
3
Disconnect the fan from its power source when removing guards for cleaning.
4
Besurefanisonastable,atsurfacewheninoperation.
5
Do not use fan in windows. Rain and moisture may create electrical hazard.
6
Close supervision is necessary when this fan is used near children, the elderly and pets.
7
Donotplacethefannearanopename,cookingorheatingappliance,orhotsurface.
8
This fan should not be operated outside.
CAUTION
Do not alter the fan’s assembly.
WARNING
Be sure that both front and rear guard screws
are completely tightened in locking position before operation.
3
ASSEMBLY, OPERATING & CLEANING INSTRUCTIONS
OPERATING INSTRUCTIONS
SPEED CONTROL:
SelectairspeedbysettingswitchtoeitherHIGH(2)-LOW(1)-OFF(0).
It is normal for the motor to feel warm to touch after continuous operation.
Thisfanfeaturesathermostatthatwillautomaticallyshutoshoulditoverheatforanyreason.
If this happens, immediately unplug the fan from the outlet.
WHEEL ASSEMBLY INSTRUCTIONS:
1
Insertaxleshaftthroughtheframe.Aligntheholesintheframetothescrewsintheaxle.
SecurewashersandHexagonnutswithawrenchasshown.
2
SlideineachwheeloverendofeachaxleshaftandsecurewithHexagonboltsandwashers.
3
TightenHexagonbolts.
CLEANING
WARNING
Unplug from electrical supply source before cleaning.
Machine will need more frequent cleaning if being used in an environment with high particle pollution.
1
Use soft damp cloth to clean, then wipe with dry cloth.
2
Do not use a cleaning solution that is harmful to paints or plastics.
3
Do not bend the blades.
IMPORTANT:Surgesinelectricalpowerorexcessiveheatmaycausethefantoturno.
Waitapproximately15minutesforthefantoresumeoperation.
RATING:
1PAFDRUMBLT36:120V~60Hz,5.0A,560W
1PAFDRUMBLT42:120V~60Hz,6.5A,735W
READ AND SAVE THESE INSTRUCTIONS
CAUTION: Read and follow all instructions before operating fan.
Do not use fan if any part is damaged or missing.
WARNING:
- To reduce the risk of fire or electrical shock, do not expose to water or rain.
- To reduce the risk of fire or electrical shock, do not use this fan with any solid state
speed control device.
- Automatically operated device - To reduce the risk of injury, disconnect from power
supply before servicing.
- If the power supply cord is damaged, contact your local service centre or a qualified
electrician to install an appropriate replacement cord to prevent any injury or damage.
- The appliance does not apply to be used in locations where special conditions prevail,
such as the presence of a corrosive or explosive atmosphere ( dust, vapour or gas ).
- This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
RULES FOR SAFE OPERATION:
1. Never insert fingers or any other objects through the grill guard when fan is in
operation.
2. Disconnect the fan from its power source when moving from one location to another.
3. Disconnect the fan from its power source when removing guards for cleaning.
4. Be sure fan is on a stable, flat surface when in operation.
5. Do not use fan in windows. Rain and moisture may create electrical hazard.
6. Close supervision is necessary when this fan is used near children, the elderly and
pets.
OWNER'S MANUAL
CLEANING
WARNING: Unplug from electrical supply source before cleaning.
1. Use soft damp cloth to clean, then wipe with dry cloth.
2. Do not use a cleaning solution that is harmful to paints or plastics.
3. Do not bend the blades.
IMPORTANT: Surges in electrical power or excessive heat may cause the fan to turn off.
Wait approximately 15 minutes for the fan to resume operation.
RATING
FE-90D5fOL(H) / 1PAFDRUMBLT36: 120V~ 60Hz, 5.0A, 560W
FE-105D5fOL(H) / 1PAFDRUMBLT42: 120V~ 60Hz, 6.5A, 735W
7. Do not place the fan near an open flame, cooking or heating appliance, or hot surface.
8. This fan should not be operated outside.
CAUTION: Do not alter the fan's assembly.
WARNING: Be sure that both front and rear guard screws are completely tightened in
locking position before operation.
OPERATING INSTRUCTIONS
SPEED CONTROL:
Select air speed by setting switch to either HIGH(2) - LOW(1) - OFF(0).
It is normal for the motor to feel warm to touch after continuous operation.
This fan features a thermostat that will automatically shut off should it overheat for any
reason. If this happens, immediately unplug the fan from the outlet.
WHEEL ASSEMBLY INSTRUCTIONS:
1. Insert axle shaft through the frame. Align the holes in the frame to the screws in the
axle. Secure washers and Hexagon nuts with a wrench as shown.
2. Slide in each wheel over end of each axle shaft and secure with Hexagon bolts and
washers.
3. Tighten Hexagon bolts.
Shaft
Wheel Hexagon bolts & washers
Axle
Frame
Hexagon nuts
& washers
BELT DRIVE DRUM FAN
Models:
FE-90D5fOL(H)
Item: 1PAFDRUMBLT36
FE-105D5fOL(H)
Item: 1PAFDRUMBLT42
