Save these instructions
For household use only
ETL Listed
Power: 120V~ 60Hz
Model: AF06D02-M
DIGITAL AIR FRYER
OPERATION INSTRUCTIONS
USC
TABLE OF CONTENTS
TABLE OF CONTENTS
01
BASIC SPECIFICATIONS ············ 02
12 PRESETS ······························ 11
PARTS & ACCESSORIES ············ 06
INSTRUCTIONS ························· 07
CLEANING & MAINTENANCE····· 12
TROUBLESHOOT GUIDE ············ 13
TO OBTAIN SERVICE ·················· 14
IMPORTANT SAFEGUARDS ········ 03
Electrical and environmental parameters
Technical specification
PRODUCT SIZE
ITEM
NAME SPECIFICATION
SPECIFICATION
1
Working Voltage
and Frequency
AC100V-120V~60Hz
2
Standby power
<1W
3
Rated Voltage
and power
120V/1600W
4 Motor
120V/60Hz
5
Max working
humidity
RH95%
6
Working ambient
temperature range
-4℉～185℉
7
Storage ambient
temperature range
Temperature adjust range
-13℉～185℉
105℉~400℉
Time adjust range
1~60min/1h
Time control error
±2%
Temperature accuracy error
±5%
N.W.
270*350*323mm 4.45KG
PACKAGE SIZE G.W.
390*315*366mm
5.5KG
BASIC SPECIFICATION
02
BASIC SPECIFICATIONS
HOUSEHOLD USE ONLY •
READ ALL INSTRUCTIONS BEFORE USE
When using electrical appliances, basic safety precautions
should always be followed including the following:
1. A short power-supply cord is provided to reduce risk.
2. DO NOT touch hot surfaces. Use handles or knobs.
3. Close supervision is necessary when any appliance is used
by or near children.
4. Ensure the appliance and all parts are clean and dry before
each use.
5. DO NOT place on or near a hot gas or electric burner, or in a
heated oven.
6. Use only on a clean, stable, dry and level surface.
7. Only after the Air Fryer has completely cooled down should
you attempt to move or handle it.
8. DO NOT operate any appliance with a damaged cord or plug
or after the appliance malfunctions or has been damaged in
any manner.
9. The use of accessory attachments NOT recommended by
the manufacturer may cause injuries.
10. DO NOT use outdoors.
IMPORTANT SAFEGUARDS
03
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
04
1. Remove all packaging stickers and labels from the air fryer,
including the tape securing the basket to the unit.
2. To pull out the basket for cleaning, remove the tape securing
it into place. Secure the unit with one hand and pull the
handle straight back with the other hand.
3. Thoroughly clean the basket and crisper tray with hot water,
dish-washing liquid, and a non-abrasive sponge.
4. Wipe the inside chamber and outside of the air fryer with a
moist cloth.
5. Discard the protective plastic covering the power plug before
use.
BEFORE FIRST USE
1. Use extreme caution when operating the Air Fryer or any
other appliance.
2. Make sure the Air Fryer is always clean prior to cooking.
3. NEVER leave the Air Fryer unattended during use.
4. DO NOT move the Air Fryer while in operation.
5. DO NOT let cord hang over edge of table or counter, or touch
hot surfaces.
6. Amount of ingredients placed in the Air Fryer should comply
with directions listed under “Instructions”.
7. Use extreme caution when removing tray or disposing of hot
grease.
8.Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
9.To disconnect, turn any control to off, then remove plug from
wall outlet.
USING YOUR AIR FRYER
DO NOT USE THE AIR FRYER FOR ANYTHING OTHER
THAN ITS INTENDED USE.
Note:
This appliance is intended for normal household use. It is not
intended to be used in environments such as staff kitchens/
cafeterias of shops, offices, farms, or other work environments,
nor is it intended to be used by clients in hotels, motels, bed and
breakfasts, and non-residential environments.
NOTICE:
FAILURE TO FOLLOW ANY OF THE IMPORTANT SAFEGUARDS,
ADDITIONAL SAFEGUARDS, OR THE INSTRUCTIONS FOR SAFE
USE IS A MISUSE OFTHE SMART AIR FRYER THAT CAN VOID
THE WARRANTY AND CREATE THE RISK OF SERIOU INJURY.
IMPORTANT SAFEGUARDS
05
10. DO NOT place plastic or rubber containers in the unit. Avoid
using containers made of any other material other than
ceramic, glass, or metal in the unit.
11. Always put the ingredients to be cooked on the appropriate
baking sheet (DO NOT overfill) and DO NOT allow food to come
into direct contact with the heating components.
12. Make sure foil does NOT touch heating elements, to prevent
fire.
13. DO NOT overfill the Air fryer such that contents are touching
heating elements or blocking the fan.
14. DO NOT attempt to use the Air Fryer to deep-fry any food as
this is NOT its intended use and may create a fire hazard.
15. DO NOT cover the intake air vents or exhaust vents while the
Air Fryer is operating.
16. Keep manual handy for future reference.
Control panel
PARTS & ACCESSORLES
06
PARTS & ACCESSORLES
1
Non-stick coating frying rack
4
Handle cover
6 Non-stick Coating frying tray7
Basket cover
5
Main body
2
Air inlet
3
1
2
3
5
6
7
4
WARNING
Never use the Air Fryer with loose,
damaged, or missing parts.
1. To cook evenly, do not overfill the basket. Suggest that you
can shake once or more halfway through cooking.
2. To make cakes, pies, or any food with filling or batter, place
food in a heat-safe container before placing in the baskets.
3. To make food crispier, you can spray of brush a small amount
of oil.
4. Liquid-marinated foods create splatter and excess smoke.
Pat
these foods dry before cooking.
FOOD TIPS
INSTRUCTIONS
07
INSTRUCTIONS
Air Fry
Bake
Active Paused
F
888 88:88
Standby
Keep
Warm
Reheat
Temp
-
+
Time
Cancel
DIYSound
ON
OFF
ITEM
ICON
OPERATION INSTRUCTION
ON
OFF
ON
OFF
1
Plug in. At any time, press to turn
on/off the air fryer display.
INSTRUCTIONS
08
Cancel
Cancel
Sound
Sound
Plug in. Press . The air fryer will clear
all settings and go into standby. Display all
bright (Except for Active, Paused)
■Rotate the knob to switch eight menus.
Press it to start to Active
/ Paused state.
■Rotate the knob to adjust time &
temperature. Press it to confirm the set
time/temperature.
2
3
Plug in. The icon sound is on by default.
Press
to turn off / on the icon sound of
the air fryer at any state. The buzzer
cannot be turned off by default.
■One buzzer for power-on / Turn-off
(1 sound in 0.1 seconds)
■
Every time press a valid Icon in the open
state, the buzzer buzzes 1 sound
(1 sound in 0.1 seconds)
Plug in. Press . The fries Icon flashing
display. Directly press the to enter the
Active state. The other menu is the same
procedure.
4
5
ITEM ICON OPERATION INSTRUCTION
INSTRUCTIONS
09
Time
Time
Air Fry
Air Fry
Bake
Keep
Warm
Reheat
Plug in. Press .The menu Icon flashing
display. Directly press the to enter
the Active state. mode.The other function
is the same procedure.
Plug in. Pres
Time
s . The time is adjustable
at any time. The time display is flashing.
Rotate to adjust the time to match your
desired setting. Press or to confirm
it. (No operation within 5 seconds, the time
will be confirmed) Press again enter
the active state. (1-60minutes. Rotation in
1-minute steps)
6
7
Temp
8
OPERATION INSTRUCTIONITEM ICON
Plug in. Pres
p
s
Tem
. The temperature is
adjustable at any time. The temp display is
flashing. Rotate to adjust the
temperature to match your desired setting.
Pres
p Tem
s or to confirm it. (Nooperation
within 5 seconds,the temperature will be
confirmed) Press again enter the active
state. (105°-400°F. Rotation in 5°F steps)
INSTRUCTIONS
10
Active
Paused
Standby
OPEN
Time
DIY
DIY
Plug in. Press . The menu Icon flashing
display. At this time, press or , to
enter the time or temperature settings.
Directly press the to enter the Active
state. The function will remember the last
DIY setting.
9
10
OFF
Steady on in working state: the selected
function lights up display.
Steady on in the paused state: the selected
function flashing display.
Steady on in standby state: plug in or after
the work is done.
11
12
13
14
Temp
OPERATION INSTRUCTIONITEM ICON
If the display shows , the basket is not
correctly placed in the Air Fryer at this
time. After the basket is correctly placed,
the Air Fryer will restore the previous
working state.
After the work is done, the buzzer will
sound 5 times (sound 0.5 seconds, interval
1 second).The display is fully lit and shows
. (Except for Active，Paused)
12 PRESETS
11
PRESETS CHART:
12 PRESETS
ICON FUNCTION
175-400
105-180
175-400
175-400
175-400
150-200
105-400
Fries 400 20
Bread 380 5
Vegetable 360 10
Steak 400 10
Drumstick 380 20
Fish 380 20
Shrimp 365 10
Thaw 140 35
Air Fry
Air Fry 400 20
Bake
Bake 320 35
Keep
Warm
Keep Warm 170 60
Reheat
Reheat 360 15
DIY
DIY
Custom Custom
1~60
TEMPERATURE
Default/℉ Range/℉
Default
/ Min
Range
/ Min
TIME
CLEANING & MAINTENANCE
12
CLEANING & MAINTENANCE
1. To protect against electrical shock DO NOT immerse cord.
plugs, or (state specific part or parts in question) in water or
other liquids.
2. Unplug from outlet when NOT in use and before cleaning.
3. Always unplug the air fryer from the electrical outlet. NEVER
clean the unit while it is plugged in.
4. Allow the unit to cool completely before cleaning.
5. Always unplug power cord by pulling on plug, NOT the cord.
6. DO NOT use metal to clean machine components, pieces can
break of the pad and touch electrical parts. Create a risk of
electric.
7. NEVER use steel wool pads, etc., on interior or exterior of air
fryer.
8. NEVER use harsh abrasive or corrosive product cleaners, as
they may damage the finish or air fryer surface.
9. Apply the cleaning agent directly to a cloth towel, NOT directly
to the unit, before cleaning.
10. To clean interior, use a damp cloth, mild liquid soap solution,
and a clean cloth towel.
11. Your appliance is virtually maintenance free. lt contains no user
serviceable parts and no lubrication is needed.
12. WARNING: lf any malfunction occurs, DO NOT attempt to repair.
This appliance has no user-serviceable parts.
The air fryer was engineered with an automatic shut-off feature
to prevent overheating during use. If the air fryer shuts off to
cool itself down, an odor may be detected. Unplug the unit and
wait for it to completely cool down. To prevent the air fryer from
overheating, do not cook foods at higher temperatures or longer
times than.
CLEANING & MAINTENANCE
13
TROUBLESHOOT GUIDE
1. The air fryer is not plugged in. Did not press “ON”.
2. Insert the plug into an appropriate grounded power socket.
Press “ON”.
The AIR FRYER does not work.
If the basket is not properly placed, the screen will display
OPEN, and you can take it out and play it again.
The basket of the AIR FRYER will not close completely
Check the entire cooking process. Turn or flip as needed
Make sure it cooks evenly. (Especially when cooking in sync)
The food is cooked unevenly.
1. The Air Fryer overheated and has shut itself down. No
action was taken after certain stages of cooking and unit
shut down. Control Panel not working correctly.
2. Unplug the Air Fryer and allow the unit to completely cool.
Plug back in and see if it is working.
The LED screen is blank.
TROUBLESHOOT GUIDE
14
TO OBTAIN SERVICE
The owner shall have the obligation and responsibility to: pay for
all services and parts not covered by the warranty; prepay the
freight to and from Service Department for any part or system
returned under this warranty; and carefully package the product
using adequate padding material to prevent damage in transit.
The original container is ideal for this purpose. Include in the
package the owner’s name, address, daytime telephone number,
a detailed description of the problem, and your “RGA number.”
Provide the cooking system model & serial number and proof of
date of purchase (a copy of the receipt) when making claims
under this warranty.
1. Unit is unplugged. The Air Fryer has overheated. Heating
elements are not working.
2. Make sure the Air Fryer is plugged in. Make sure the unit is
has completely cooled. Plug in and see if unit comes up to
correct temperature.
The Air Fryer is not heating.
