Ceiling Fan
Installation Instructions
Model No.: 7801m
SAFETY RULES
of
pushed up carefully
INSTALL THE FAN
NOTE: Hanger after the installation must be able to withstand the weight of 45 kgs or more
01.take out the hanging plate
and screws from the box
03.Connect the power supply 04.The fan is screwed to the
hanging plate
02.fix the hanging plate on
the ceiling with screws
Hanging plate installation
BEFORE INSTALLATION
Unpack your fan and check the contents. You should have followings:
Installation kit Installation kit
Instructions manualLamp body
ON OFF
+
-
K- K+
Remote Control ( Esmitter ) Operation
If emitter can not control the fan
① ②
③
AAA 1.5V
1. IMPORTANT: Using a full range dimmer
switch(not included) to control fan speed will
damage the fan. To reduce the risk of fire or
electrical shock, do not use a full range
dimmer switch to control the fan speed.
(Figure 1)
2. Restore electrical power to the outlet box
by turning the electricity on at the main
fuse box. (Figure 2)
!
Check to see that all connections are tight,
including ground, and that no bare wire is
visible at the wire connectors, except for the
ground wire.
WARNING
!
Do not operate this fan with a variable
(Rheostat) wall controller or dimmer switch.
Doing so could result in damage to the ceil-
ing fan's remote control unit.
1.Please check whether the battery
is installed correctly and whether it
is charged.if necessary, replace the
remote control battery
2.Please check if there are similar
remote control products working
nearby. because remote control
products of the same frequency will
interfere with each other.
WARNING
How to operate your ceiling fan
Figure 1
Figure 2
main fuse box
for illustrative purpose only-not
intended to cober all types of controls
ON OFF
+
-
K- K+
How to operate your ceiling fan
Figure 3
3. To make fan operational, install
AAA/1.5V battery (not included) in
hand-held remote. Store the remote
away from excessive heat or humidly.
4. Remote functions: (Figure 3)
Wind speed control
Movable
Switch light
Brightness and
color temperature control
Fan Stops After 2 Hour
Turn off the fan
Do not use water when cleaning your
ceiling fan. It could damage the motor or
the finish and create the possibility of
electrical shock.
CAUTION
Maintenance
1. Periodic cleaning of your new ceiling
fan is the only maintenance that is
needed. When cleaning, use only a soft
brush or lint free cloth to avoid scratch-
ing the finish. Abrasive cleaning agents
are not required and should be avoided
to prevent damage to finish.
ON
OFF
+
-
K- K+
ON OFF
+
-
K- K+
Warranty
Dear Customer:
This product is free from defects in materials and workmanship for a period of 1 years
from the day of purchase. If the product has been misused, damaged by accident or in
any other way of improper use, this warranty becomes void.
