POLYESTER WEBBING CAM BUCKLE STRAP
WITH S HOOKS
MODEL NO: TD2525CS, TD2550CS, TD05025CS
TD05050CS
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 In selecting and using web lashings, consideration shall be given to the required lashing capacity, taking into account the mode
of use and the nature of the load to be secured. The size, shape and weight of the load, together with the intended method of use,
transportenvironmentandthenatureoftheloadwillaectthecorrectselection.
9 For stability reasons free-standing units of load have to be secured with a minimum of one pair of web lashings for frictional lashing
and two pairs of web lashing for diagonal lashing.
9 The selected web lashings shall both be strong enough and of the correct length for the mode of use. Basic lashing rules:
•Planthettingandremovaloperationsoflashingbeforestartingajourney;
•Keepinmindthatduringjourneyspartsoftheloadmayhavetobeunloaded;
• Calculate the number of web lashings according to EN 12195-1.
•OnlythoseweblashingsdesignedforfrictionallashingwithSTFonthelabelaretobeusedforfrictionallashing;
•Checkthetensionforceperiodically,especiallyshortlyafterstartingthejourney.
9 Becauseofdierentbehaviourandelongationunderloadconditions,dierentlashingequipment(e.g.lashingchainandweb
lashings)shallnotbeusedtolashthesameload.Considerationshallalsobegiventoancillaryttings(components)andlashing
devices in the load restraint assembly are compatible with the web lashing.
9 Duringuseathooksshallengageoverthecompletewidthofthebearingsurfaceofthehook.
9 Release of the web lashing: Care should be taken to ensure that the stability of the load is independent of the lashing equipment and
thatthereleaseoftheweblashingshallnotcausetheloadtofallothevehicle,thusendangeringthepersonnel.Ifnecessaryattach
lifting equipment for further transport to the load before releasing the tensioning device in order to prevent accidental falling and/or
tilting of the load. This applies as well when using tensioning devices which allow controlled removal.
9 Before attempting to unload a unit of load its web lashings shall be released so that it can be lifted freely from the load platform.
9 During loading and unloading attention has to be paid to proximity of any low overhead power lines.
9 The materials from which web lashings are manufactured have a selective resistance to chemical attack. Seek the advice of the
manufacturerorsupplierifexposuretochemicalsisanticipated.Itshouldbenotedthattheeectsofchemicalsmayincreasewith
risingtemperature.Theresistanceofman-madebrestochemicalsissummarizedbelow.
9 Polyamidesarevirtuallyimmunetotheeectsofalkalis.However,theyareattackedbymineralacids.
9 Polyester is resistant to mineral acids but is attacked by alkalis.
9 Polypropyleneislittleaectedbyacidsandalkalisandissuitableforapplicationswherehighresistancetochemicals(otherthan
certain organic solvents) is required.
9 Solutionsofacidsoralkaliswhichareharmlessmaybecomesucientlyconcentratedbyevaporationtocausedamage.Take
contaminated webbings out of service at once, thoroughly soak them in cold water, and dry naturally.
9 Web lashings complying with this Part of EN 12195 are suitable for use in the following temperature ranges:
-40°Cto+80°Cforpolypropylene(PP);
-40°Cto+100°Cforpolyamide(PA);
-40°Cto+120°Cforpolyester(PES).
9 These ranges may vary in a chemical environment. In that case the advice of the manufacturer or supplier shall be sought.
9 Changingtheenvironmentaltemperatureduringtransportmayaecttheforcesintheweblashing.Checkthetensionforceafter
entering warm areas.
9 Weblashingsshallberejectedorreturnedtothemanufacturerforrepairiftheyshowanysignsofdamage.
9 The following criteria are considered to be signs of damage:
•Onlyweblashingsbearingidenticationlabelsshallberepaired;
• If there is any accidental contact with chemical products, a web lashing shall be removed from service and the manufacturer or
suppliershallbeconsulted;
•forweblashings(toberejected):tears,cuts,nicksandbreaksinloadbearingbresandretainingstitches;deformationsresulting
fromexposuretoheat;
•forendttingsandtensioningdevices:deformations,splits,pronouncedsignsofwear,signsofcorrosion.
9 Careshouldbetakenthattheweblashingisnotdamagedbythesharpedgesoftheloadonwhichitisused.Avisualinspection
before and after each use is recommended.
9 Only legibly marked and labelled web lashings shall be used.
9 Weblashingsshallnotbeoverloaded:Onlythemaximumhandforceof500N(50daNonthelabel;1daN=1kg)shallbeapplied.
Mechanical aids such as levers, bars etc. as extensions are not to be used unless they are part of the tensioning device.
9 Web lashings shall never be used when knotted.
TD2525CS, TD2550CS, TD05025CS, TD05050CS Issue: 2 04/04/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
9 Damage to labels shall be prevented by keeping them away from sharp edges of the load and, if possible, from the load.
9 The webbing shall be protected against friction, abrasion and damage from loads with sharp edges by using protective sleeves and/
or corner protectors.
2. INTRODUCTION
Manufactured from polyester webbing with stitched reinforcement around hooks. Suitable for securing loads and tarpaulins onto
atbedsortrailersandforgeneralloadrestraint.Simplecambucklefastenertensionsthewebbingtoprovidesuperiorloadrestraint
3. SPECIFICATION
4. OPERATION
NOTE: If unsure of requirements for specic application of Tie Down, seek professional advice.
4.1. INSTALLING STRAP
4.1.1. Depressthecambucklelever(g.1)andfeedwebbingbetweentheleverandthebucklebody.
4.1.2. Manually pull the webbing through to remove as much slack as possible before releasing the lever to clamp the webbing.
4.2. RELEASING THE STRAP
4.2.1. Depressthecambucklelever(g.1)andloosen/removethewebbingfrom
the buckle body.
NOTE: For additional information see the Sealey YouTube channel.
5. MAINTENANCE
5.1. Afteruse,thoroughlywipedownthestrapandthebucklebodyusinga
soft,clean and dry cloth.
5.2. Store the unit in a clean and dry environment.
Original Language Version
© Jack Sealey Limited
Part No. Breaking
Strain
Hook Maximum
Tension
Webbing
Length
Webbing
Width
Quantity
TD2525CS 250 kg S-Type 125 kg 2.5 m 25 mm 2
TD2550CS 250 kg S-Type 125 kg 5 m 25 mm 2
TD05025CS 500 kg S-Type 250 kg 2.5 m 25 mm 2
TD05050CS 500 kg S-Type 250 kg 5 m 25 mm 2
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
g.1
