COLLAPSIBLE FOLD UP PVC GARDEN/
HYDROPONICS WATER BUTT 100LTR
MODEL NO: DG8
Thank you for purchasing a Dellonda product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Regularly inspect the water butt and it’s fittings for damage or wear. If necessary, immediately repair or replace damaged parts.
9 Place water butt on level and solid ground, preferably concrete to ensure it is well balanced and unlikely to topple.
8 DO NOT modify water butt in any way. DO NOT use the water butt for any other purpose other than that for which it was designed.
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations that
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
2. INTRODUCTION
100LCapacitywaterbarrelforcollectingrainwaterfromarooftopgutter.DurablecorrosionandUVresistantPVCcover.Includesve
standingpoles,ttedwithadjustablefeettoprovidegoodstability.Eortlessinstallationwithnotoolsneeded.Zippedlidttedatthe
toptokeepthewatercleanaftercollection.Installedwithanoverowpipewhichcanaccommodateahosetodirecttheoverow.Will
foldatintoacompactsizewhennotinusemakingitcosteectiveforbothshippingandstorage.Easiertotransport,thecollapsible
waterbuttwillalsotintospacesandthroughdoorwaysthatrigiddesignswillnot.Watertankisttedwithadraintap,threadlter,
3/4”ABSoutletvalve,1/2”threadinsert,threadplugandoverow/inletttingandcanprovidewatertoareasthatwouldotherwisehave
tobeservicedbyahosepipe.Overalltanksize:Ø40x78cm.Lidcollectionlter:Ø75mm.
3. SPECIFICATION
Model no: .......................................................................DG8
Capacity ............................................................... 100ltrmax.
Size(DiaxHeight) ............................................ 40cmx78cm
Material ............................................ Corrosion resistant PVC
4. CONTENTS
DG8Issue2(2)04/06/2019
Original Language Version
© Dellonda Limited
Refer to
instruction
manual
fig.
1
fig.
2
fig.
3
fig.
4
fig.
5
fig.
6
5. ASSEMBLY
5.1. LOWER DRAIN
5.1.1. Screwhoseconnector(g.5)intodrainbody(g.2)
5.1.2. Screwdrainlter(g.6)intootherendofdrainbodywiththeltersectioninnermostandusearubberwasher(g.3)betweenmating
faces.
5.1.3. Passdrainltermalethreadedsection(g.6)throughlowerholeintobuttandsecureinplaceusinganinternallter(g.7).Userubber
washers(g.3)eithersideofthebuttwalltoensurealeakproofseal.
5.2. TAP FITTING
5.2.1. Passmalethreadedspigotoftap(g.1)throughbuttsidewallholeandsecureinplaceusinganinternallter(g.7).Userubber
washers(g.3)eithersideofthebuttwalltoensurealeakproofseal.
5.3. OVERFLOW
5.3.1. Passmalethreadedspigotofoverow(g.8)throughbuttsidewallholeandsecureinplaceusinganinternallter(g.7).Userubber
washers(3)eithersideofthebuttwalltoensurealeakproofseal.
5.4. SUPPORTS
5.5. Pushfeet(g.4)ontotubularlegs(g.9)andslideintopocketsontheoutsideofwaterbuttfromthebottomup.Ensurefulllength
engagement.
6. OPERATION
6.1. Ifrequired,thoseontotheoverowtting(g.8)anddirectoutputasrequired(hosenotsupplied).
6.2. Once a suitable location for the butt is determined pour a small amount of water into it in order to stabilise it.
7. MAINTENANCE
7.1. Dry thoroughly before storing for any period of time.
7.2. Checkttingsandmaterialsregularlyforanyleaksordamage.
7.3. Store in frost free environment.
Original Language Version
DG8Issue2(2)04/06/2019
Dellonda, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
fig.
