ATM347W
Refrigerator
User manual
EN
5774451064/AA
Please read this user manual rst!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most meticulous
quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as a reference. If you handover
the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.Differences between models will be
identied in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.
CONTENTS
1.Your Refrigerator 1
2.Important Safety warning 1
Intended use............................................................ 1
General safety.......................................................... 1
For products with a water dispenser.............. 2
Child safety............................................................... 2
Compliance with WEEE Directive and
Disposing of the Waste Product....................... 2
Package information............................................. 2
HC warning............................................................... 3
Recommendations for the fresh food
compartment........................................................... 3
Things to be done for energy saving.............. 3
3.Installation 3
Points to be paid attention to when the
relocation of the refrigerator............................. 3
Electrical connection............................................. 3
Disposing of the packaging............................... 3
Disposing of your old refrigerator.................... 3
Placing and Installation........................................ 3
Door Open Warning.............................................. 4
Adjusting the legs.................................................. 4
Changing the illumination lamp...................... 4
4.Preparation 4
5.Using your refrigerator 5
Indicator panel........................................................ 5
Freezing fresh food................................................ 5
Recommendations for preservation of
frozen food............................................................... 6
Defrosting................................................................. 6
Placing the food...................................................... 6
Deep-freeze information..................................... 6
Ice box........................................................................ 6
Crisper........................................................................ 6
Fan............................................................................... 6
6.Maintenance and cleaning 7
Protection of plastic surfaces............................. 7
7.Troubleshooting 8
Figures that take place in this instruction manual are schematic and may not correspond exactly with
your product. If the subject parts are not included in the product you have purchased, then it is valid
for other models.
1 Your Refrigerator
2 Important Safety Warnings
Please review the following information.
Failure to observe this information may cause njuries
ior material damage.
Otherwise, all warranty
and reliability commitments will become invalid.
The service life of your product is 10 years.
During this period, original spare parts will be
available to operate the product properly.
Intended use
This product is intended to be used
indoors and in closed areas such as homes;
in closed working environments such as
stores and ofces;
in closed accommodation areas such as farm
houses, hotels, pensions.
It should not be used outdoors.
General safety
When you want to
dispose/scrap the
product, we recommend you to consult the
authorized service
in order to learn the required
information and authorized bodies.
Consult your authorized
service for all your
questions and problems
related to the refrigerator.
Do not intervene or let someone intervene to the
refrigerator without notifying the authorised services.
For products with a freezer compartment;
Do not eat cone ice cream and ice cubes immediately
after you take them out of the freezer compartment!
(This may cause frostbite in your mouth.)
For products with a freezer compartment;
Do not put bottled and canned liquid beverages in the
freezer compartment. Otherwise, these may burst.
Do not touch frozen food by hand; they may sick
to your hand.Unplug your refrigerator before
Vapor and vaporized cleaning materials should never
be used in cleaning and defrosting processes of your
refrigerator. In such cases, the vapor may get in contact
with theelectrical parts and cause short circuit or
electric shock.
Never use the parts on your refrigerator such as
the door as a means of support or step.
Do not use electrical devices inside the refrigerator.
Do not damage the parts, where the refrigerant is
circulating, with drilling or cutting
that might blow out when the gas channels of the
evaporator, pipe extensions or surface causes skin
irritations and eye injuries.
Do not cover or block the ventilation holes on your
refrigerator with any material.
Electrical devices must be repaired by only authorised
authorised persons. Repairs performed by
in competent persons create a risk for the user.
In case of any failure or during a maintenance or repair
work, disconnect your refrigerator’s mains supply
by either turning off the relevant fuse or unplugging
your appliance.
Do not pull by the cable when pulling off the plug.
Ensure highly alcoholic beverages are stored
securely with the lid fastened and placed upright.
Never store spray cans containing ammable and
explosive substances in the refrigerator.
Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
cleaning or defrosting.
This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are attended by
a person who will be responsible for their safety or
safety or who will instruct them accordingly for use
of the product
13
14
1
1
2
3
4 4
5
6
9
8
11
7
7
12 12
1. Freezer - compartment door shelf
2. Egg Section
3. Fridge door shelf
4. Fridge door shelf
5. Bottle shelf
6 . Fridge door shelf
7. Fridge compartment glass shelf
8. Crisper
9. Freezer compartment glass shelf
10. Icebox
11. Temperature setting button
12. Adjustable feet
13. Freezer compartment
14. Fridge compartment
EN
1
10
7
Do not operate a damaged refrigerator.
Consult with the service agent if you have any concerns.
Electrical safety of your refrigerator shall be guaranteed
only if the earth system in your house complies with
standards.
Exposing the product to rain, snow, sun and wind is
dangerous with respect to electrical safety.
Contact authorized service when there is a power cable
damage to avoid danger.
Never plug the refrigerator into the wall outlet during
installation.Otherwise, risk of death or serious
injury may arise.
This refrigerator is intended for only storing food items.
It must not be used for any other purpose.
Label of technical specications is located on the
left wall inside the refrigerator.
Never connect your refrigerator to electricity saving
systems; they may damage the refrigerator.
If there is a blue light on the refrigerator, do not
look at the blue light with optical tools.
For manually controlled refrigerators, wait for at least
5 minutes to startthe refrigerator afterpower failure.
This operation manual should be handed in to the new
owner of the product when it is given to others.
Avoid causing damage on power cable when
transporting the refrigerator. Bending refrigerator
Bending cable may cause re. Never place heavy
objects on power cable.Do not touch the plug with wet
hands when plugging the product
Do not plug the refrigerator if the wall outlet is loose.
Water should not be sprayed on inner or outer
parts of the product for safety purposes.
Do not spray substances containing inammable gases
such as propane gas near the refrigerator to avoid re
and explosion risk.
Never place containers lled with water on top of the
refrigerator; in the event of spillages, this may cause
electric shock or re.
Do not overload the refrigerator with food. If overloaded,
the food items may fall down and hurt you and damage
refrigerator when you open the door.
Never place objects on top of the refrigerator;
otherwise, these objects may fall down when
you open or close the refrigerator’s door.
As they require a precise temperature, vaccines,
heat-sensitive medicine and scientic materials and
etc. should not be kept in the refrigerator.
If not to be used for a long time, refrigerator should
be unplugged. A possible problem in power cable
may cause re.
The plug’s tip should be cleaned regularly with a
dry cloth; otherwise, it may cause re.
Refrigerator may move if adjustable legs are not
properly secured on the oor. Properly securing
adjustable legs on the oor can prevent the
refrigerator to move.
When carrying the refrigerator, do not hold it from
it from door handle. Otherwise, it may be snapped.
When you have to place your product next to
another refrigerator or freezer, the distance between
devices should be at least 8 cm. Otherwise, adjacent
side walls may be humidied.
The product shall never be used while the
compartment which is located at the top or back of
your product and in which electronic boards are
available (electronic board box cover) (1) is open.
For products with a water dispenser
Pressure for cold water inlet shall be maximum 90 psi
(6.2 bar). If your water pressure exceeds 80 psi (5.5 bar),
use a pressure limiting valve in your mains system. If
you do not know how to check your water pressure
ask for the help of a professional plumber.
If there is risk of water hammer effect in your
installation, always use a water hammer prevention
equipment in your installation. Consult Professional
plumbers is you are not sure that there is no water
hammer effect in your installation.
Do not install on the hot water inlet. Take precautions
against of the risk of freezing of the hoses. Water
temperature operating interval shall be 33°F (0.6°C)
minimum and 100°F (38°C) maximum
Use only potable water.
Child safety
If the door has a lock, the key should be kept away from
reach of children.
Children must be
supervised to prevent them from
tampering with the product.
Compliance with WEEE Directive and
Disposing of the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product bears
a classication symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with high
quality parts and materials which can be reused and
are suitable for recycling. Therefore, do not dispose
the product with normal domestic waste at the end of
its service life. Take it to a collection point for the
recycling of electrical and electronic equipment.
Please consult your local authorities to learn the
nearest collection point. Help protect the environment
and natural resources by recycling used products.
For children’s safety, cut the power cable and break
will be non-functional before
disposing of the product.
the locking mechanism of the door, if any, so that it
Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our
National Environment Regulations. Do not dispose
of the packaging materials together with the domestic
or other wastes. Take them to the packaging material
collection points designated by the local authorities.
Do not forget
Any recycled substance is anindispensable matter for
nature and our national asset wealth. If you want to
contribute to re-evaluation of the packaging materials
you can consult to your environmentalist organizations
or the municipalities where you are located.
EN
2
1
HC warning
If your product's cooling system contains R600
This gas is ammable. Therefore, pay attention to
not damaging the cooling system and piping during
usage and transportation. In the event of damage,
keep your product away from potential re sources
that can cause the product catch a re and ventilate
the room in which the unit is placed.
Ignore this warning if your product's
cooling system contains R134a.
Type of gas used in the product is stated in the type
label which is on the left wall inside the refrigerator.
Never throw the product in re fordisposal.
Recommendations for the fresh food compartment
*optional
Do not allow the food to touch the temperature
sensor in fresh foodcompartment. To allow the fresh food
compartment keep its ideal storage temperature
sensor must not be hindered by food.
Do not place hot foods in the product.
Things to be done for energy saving
Do not leave the doors of your refrigerator open for a long time.
Do not put hot food or drinks in your refrigerator.
Do not overload your refrigerator so that the air
circulation inside of it is not prevented.
Do not install your refrigerator under direct sunlight or near heat
emitting appliances such as ovens, dishwashers or radiators.
Keep your
refrigerator at least 30cm away from heat
emitting sources and at least 5cm from electrical ovens.
Pay attention to keep your food in closed containers.
For products with a freezer compartment You can store
when you remove the shelf or drawer of the freezer.
Energy consumption value stated for yourrefrigerator
has been determined has been determined by removing
freezer shelf or drawer and under maximum load.
There is no harm to use a shelf or drawer according to
the shapes and size of food to be frozen.
maximum amount of food items in the freezer
Thawing frozen food in fridge compartment will both
provide energy saving and preserve the food quality.
3 Installation
In case the information which are given in the user
manual are not taken into account, manufacturer will
not assume any liability for this.
Points to be paid attention to when the
relocation of therefrigerator
1. Your refrigerator should be unplugged.Before
transportation of your refrigerator, it should be
emptied and cleaned.
2. Before it is re-packaged,shelves, accessories, crisper, etc.
inside your refrigerator should bexed with adhesive
tape and secured against impacts. Package should
be bound with a thick tape or sound ropes and the
transportation rules on the package should be
strictly observed.
3. Original packaging and foammaterials should be
kept for future transportations or moving. Before
you start the refrigerator,
Check the following before you start to use
your refrigerator:
1. Clean the interior of therefrigerator as recommended in the
“Maintenance and cleaning” section.
2. Connect the plug of therefrigerator to the wall socket. When
the fridge door is opened, fridge internal lamp will turn on.
3. When the compressor starts tooperate, a sound will
be heard. The liquid and gases sealed with in the
refrigeration system may also give rise to noise, even
the compressor is not running and this is quite normal.
4. Front edges and both sides ofthe refrigerator may
feel warm. This is normal. These areas are designed
to be warm to avoid condensation.
Electrical connection
Connect your product to a grounded socket which is
being protected by a fuse with the appropriate capacity.
Important:
The connection must be in compliance with national regulations.
The power plug must be easilyaccessible after installation.
Electrical safety of your refrigeratorshall be guaranteed only
if the earthsystem in your house complies with standards.
The voltage stated on the label located at left inner side
of your product should be equal to your network voltage.
Extension cables and multi plugs must not be used for
connection.
A damaged power cable must be replaced by a qualied electrician.
Product must not be operated beforei t is repaired!
There is the risk of electric shock!
Disposing of the packaging
The packing materials may be dangerous for children.
Keep the packing materials out of the reach of children
or dispose of them by
classifying them in accordance
with the waste instructions stated by your local
authorities. Do not throw away with regular house
waste, throw away on packaging pick up spots
designated by the local authorities.The packing of
your refrigerator is produced from recyclable materials.
Disposing of your old refrigerator
Dispose of your old refrigerator without giving any
harm to the environment.
You may consult your authorizeddealer or waste collection
center of your municipality about the disposalof your refrigerator.
Before disposing of your refrigerator, cut out the electric
plug and, if there are any locks on the door, make them
inoperable in order to protect childrenagainst any danger.
EN
3
1. Install your refrigerator to aplace that allows ease of use.
2. Keep your refrigerator awayfrom heat sources, humid
places and direct sunlight.
3. There must be appropriate air ventilation around your
refrigerator in order to achieve an efcient operation.
If the refrigerator is to be placed in a recess in the wall,
there must be at least 5 cm distance with the ceiling
and at least 5 cm with the wall. Do notplace your
product on the materials such as rug or carpet.
4. Place your refrigerator on aneven oor surface to
prevent jolts.
Adjusting the legs
If your refrigerator is unbalanced; You can balance
your refrigerator by turning its front legs as illustrated
in the gure. The corner where the leg exists is lowered
when you turn in the direction of black arrow and
raised when you turn in the opposite direction.
Taking help from someone to slightly lift the
refrigerator will facilitate this process.
Changing the illumination lamp
To change the Bulb/LED used for illumination of your
refrigerator, call your AuthorisedService. The lamp(s)
used in this appliance is not suitable for house hold
room illumination. The intended purpose ofthis lamp
is to assist the user to place foodstuffs in the refrigerator
foodstuffs in the refrigerator/freezer in a safe and
comfortable way. The lamps used in this appliance have
to withstand extreme physical conditions such as
temperatures below -20 °C. (only chest and upright freezer)
Door Open Warning (This feature is optional)
Audio warning signal and ashing illumination will
be given when the door of your product is left
open for at least 1 minute. This warning will be
muted when the door is closed or any of the
display buttons (if any) are pressed.
4 Preparation
Your cooler/freezer should be installed at least 30 cm
away from heat sources such as hobs, ovens, central heater
and stoves and at least5 cm away from electrical ovens
and should not be located under direct sunlight.
Please make sure that the interior of your
cooler/freezer is cleaned thoroughly.
If two coolers are to be installed side by side, there
should be at least 2 cm distance between them.
When you operate your cooler/freezer for the rst time, please
observe the following instructions during the initialsix hours.
Its door should not be opened frequently.
It must be operated empty without placing any food in it.
Do not unplug your cooler/freezer. If a power failure
occurs out of your control, please see the warnings in the
“Recommended solutions for the problems” section.
The baskets/drawers that are provided with the chill
compartment must always be in use for low energy
consumption and for better storage conditions.
Food contact with the temperature sensor in the freezer
compartment may increase energy consumption of appliance.
Thus any contact with the sensor(s) must be avoided.
This product has been designed to function at
ambient temperatures up to 43°C (90 SDgr F). Even if
theambient temperature falls to -15 °C, frozen food
If the ambient temperature is below 0°C, the food in fridge
compartment will freeze. Therefore, we recommend not using
the fridge compartment in such low ambient temperatures.
You may continue to use the freezer compartment as usual.
In some models, the instrument panel automatically turns
off 5 minutes after the door has closed. It will be reactivated
when the door has opened or pressed on any key.
Due to temperature change as a result of opening/closing
the product door during operation, condensationon the
door/body shelves and the glass containers is normal.
Electronic Temperature Control System. For the rst
installation, the
product should NOT be placed underlow
ambient temperatures. This is because the freezer cannot go
down to standard operation temperature. When reaching
continuous operation, the product can be moved to another
place. Thus, later you can place your product in the garage or
in the freezer does not thaw thanks to its Advanced
Placing and Installation
If the entrance door of the room where the refrigerator
will be installed isnot wide enough for the refrigerator to
pass through, then call the authorized service to have
them remove the doors of your refrigerator and pass it
sideways through the door.
EN
4
an unheated room without the concern of causing frozen food
to get rotten. However, it is likely that above mentioned low
temperatures may cause the freezing of the food in the fridge
compartment; thus, please consume the food items in the fridge
in a controlled way as needed. When ambient temperature goes
back to normal, you may change button setting according to
your need.
‘ B ’
50 mm
100 mm
50 mm
50 mm
‘ C ’
‘ A ’
‘ D ’
130 (’ E ‘ )
o
Model
ATM347W
“A”
700
“B”
1660
“C”
660
“D”
1168
“E”
130
Use the quick freeze fucntion when you
want to quickly freeze the food palced
in fridge compartment. If you want to
freeze large amounts of fresh food,
activate this fuction before putting the
food into the product.
If you do not cancel it, Quick freeze will
cancel itself automatically after 24 hours
or when the fridge compartment
reaches to the required temperature.
This function is not recalled when
power restores after a power failure.
Indicator panel
Indicator panels may vary according to the product
model. Audio – visual functions on the indicator
panel helps you in using your product.
5 Using your refrigerator
1 2 3 4
5
6
*7
8
Figures that take place in this instruction manual
are shematic may not correcspond exactly with
your product. If the subject parts are not included
in the product you have purchased, then it is valid
for other models.
Use quick cooling function when you
want to quickly cool compartment. If
you want to the food placed in the
fridge cool large amounts of fresh
Food, activate this function before
putting the food into the product.
If you do not canel it, quick cooling will
cancel itself automatically after 1 hours
or when the fridge compartment
reaches to the required temperature.
If you press the quick cooling button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
This function is not recalled when
power restores after a power failure.
1. Quick Freezer button
Selection button Press “Quick Freeze”. Selection button
to setting freezer compartment.
2. E
rror status indicator
If your refrigerator does not per form enough cooling
of in case of a sensor fault, this indicator is activated.
3.
Freezer compartment selection button
This function allows you to set the temperature of
freezer compartment. Press this button to set the
temperature of the freezer compartment to -16 , -18,
-20 and -24 respectively.
4.
Freezer compartment temperature indicator
Temperature of the freezer compartment -24 , -20,
-18, and -16.
5.
Quick Fridge button
Selection button : Press “Quick Cool”. Selection button
to setting fridge compartment.
• Foodstu must be divided into portions according to
the family’s daily or meal based consumption needs.
• The foodstu must be packaged in an airtight manner
to prevent themfrom drying even if they are going
tofrom drying even if they are going to be kept for a
short time.
• Materials to be used for packagingmust be tear-proof
and resistant tocold, humidity, odor, oils and acids and
they must also be airtight. Moreover, they must be well
closed and they must be made from easyto use
materials that are suitable for deep freeze usage.
• Frozen food must be used immediately after they are
thawed and they should never be re-frozen.
• Please observe the following instructions to obtain the
best results.
EN
5
6.
Fridge compartment selection button
This function allows you to set the temperature of
fridge compartment. Press this button to set the
temperature of the fridge compartment to 8, 6, 4,
and 2, respectively.
7.
Vacation function indicator (optional)
When the vacation function light.It is not suitable to
keep the food in the fridge compartment when this
function is activated.
8.
Fridge compartment temperature indicator
Temperature of the fridge compartment 2, 4, 6 and 8.
Freezing fresh food
• It must be preferred to wrap or cover the food
before
placing them in the refrigerator.
• Hot food must cool down to the room temperature
before putting them in the refrigerator.
• The foodstu that you want freeze must be fresh
and in good quality.
Freezer
compartment
shelves
Various frozen food such as
meat,sh, ice cream,
vegetables and etc.
Egg tray
Egg
Fridge
compartment
shelves
Food in pans, covered plates
andclosed containers
Fridge
compartment
door shelves
Small and packaged food or
drinks (suchas milk,
fruit juice andbeer)
Crisper
Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese,butter, salami and etc.)
Food must be frozen as rapidly as possible when
they are put in a refrigerator in order to keep them
in good quality.
It is possible to keep the food for a long time only
at -18°C or lower temperatures.
Deep-freeze information
You can keep the freshness of food for many months
(at -18°C or lower temperatures in the deep freeze).
WARNING!
1. Do not freeze too large quantities of food at one time.
The quality of the food is best preserved when it is
frozen right through to the core as quickly as possible.
2. Placing warm food into the freezer compartment
causes the cooling system to operate continuously
until the food is frozen solid.
3. Take special care not to mix already frozen food and
fresh food.
Recommendations for preservation of frozen food
• Prepacked commercially frozen food should be stored
in accordance with the frozen food manufacturer's
instructions for a ( 4 star)frozen food storage
compartment.
• To ensure that the high quality achieved by the frozen
food manufacturer and the food retailer is maintained,
the following should be remembered:
1. Put packages in the freezer as quickly as possible
after purchase.
2. Ensure that contents are labeled and dated.
3. Do not exceed "Use By", "Best Before" dates on the
packaging.
Defrosting
The freezer compartment defrosts automatically.
Placing the food
• Foodstu must be divided into portions according
to the family’s daily or meal based consumption
needs.
• Foodstu must be packaged in an airtight manner
to prevent them from drying even if they are going
to be kept for a short time.
• Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging the foodstu
must be tear-proof andresistant to cold, humidity,
odor, oils and acids.
Foodstu to be frozen should not be allowed to
come in contact with thepreviously frozen items to
prevent their partial thawing.
Frozen food must be used immediatelyafter they
are thawed and they should never be re-frozen.
Crisper
Crisper of the product is designed specially to keep
the vegetables fresh without loosing their humidity.
For this purpose, cool air circulationis intensied
around the crisper in general.
Fan
Fan is designed to ensure homogeneous distribution
and circulation ofthe cold air inside your refrigerator.
Operation time of the fan may vary .depending on
the properties of yourproduct.
While the fan works only with the compressor in
some products, the controlsystem determines its
operation time in some products in accordance with
the cooling requirement.
• Remove the ice container from the freezer compartment.
• Fill the ice container with water.
• Place the ice container in the freezercompartment.
About two hours later, the ice is ready.
• Remove the ice container from the freezer compartment
and bend it over the service plate. Ice cubes will easilyfall
down to the service plate.
Icebox
EN
6
6 Maintenance and cleaning
Never use gasoline, benzene or similar substances for
cleaning purposes.
We recommend that you unplug the appliance before
cleaning.
Never use any sharp abrasive instrument, soap, house
hold cleaner, detergent and wax polish for cleaning.
Use lukewarm water to clean thecabinet of your
refrigerator and wipe it dry.
Use a damp cloth wrung out in a solution of one
teaspoon of bicarbonate of soda to one pint of water
to clean the interior and wipe it dry.
Make sure that no water enters thelamp housing and
other electrical items.
If your refrigerator is not going to be used for a long
period of time, unplugthe power cable, remove all
food, clean it and leave the door ajar.
Check door seals regularly to ensure they are clean and
free from food particles.
Never use cleaning agents or water that contain
chlorine to clean the outer surfaces and chromium
coatedparts of the product. Chlorine causes
corrosion on such metal surfaces.
Do not use sharp, abrasive tools, soap, household
cleaning agents, detergents, kerosene, fuel oil,
varnish etc. to prevent removal and deformation of
the prints on the plastic part. Use lukewarm water
and a soft cloth for cleaning and then wipe it dry.
Protection of plastic surfaces
Do not put the liquid oils or oil-cooked meals in
your refrigerator in unsealed containers as they
damage the plastic surfaces of your refrigerator.
In case of spilling or smearing oil on the plastic
surfaces, clean and rinse the relevant part of the
surface at once with warm water.
To remove door racks, remove all the contents and
then simply push the door rack upwards from the
base.
EN
7
7 Troubleshooting
Please review this list before calling the service. It will save your time andmoney. This list includes
frequent complaints that are not arising from defective workmanship or material usage. Some of the
features described here may notexist in your product.
The refrigerator does not operate.
The plug is not inserted into the socket correctly. >>>Insert the plug into the socket securely.
The fuse of the socket which your refrigerator is connected to or the main fusehave blown out. >>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL CONTROL and FLEXI ZONE).
Door has been opened frequently. >>>Do not open and close the door of refrigerator frequently.
Ambient is very humid. >>>Do not install your refrigerator into highly humid places.
Food containing liquid is stored in open containers. >>>Do not store food with liquid content in open containers.
Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
Compressor is not running
Protective thermic of the compressor will blow out during sudden power failures or plug-out plug-ins as the refrigerant
pressure in the cooling system of the refrigerator has not been balanced yet. The refrigeratorwill start running
approximately after 6 minutes. Please call the service if the refrigerator does notstartup at the end of this period.
The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting refrigerator. Defrosting cycle occurs periodically.
The refrigerator is not plugged into the socket. >>>Make sure that the plug is t into the socket.
Temperature settings are not made correctly. >>>Select the suitable temperature value.
There is a power outage. >>>Refrigerator returns to normal operation when the power restores.
The operation noise increases when the refrigerator is running.
The operating performance of the refrigerator may change due to the changes in the ambient
temperature. It is normal and not a fault.
The refrigerator is running frequently or for a long time.
New product may be wider than the previous one. Larger refrigerators operate for a longer period of time.
The room temperature may be high. >>>It is normal that the product operates for longer periods in hot ambient.
The refrigerator might be plugged in recently or might be loaded with food. >>>When the refrigerator is
plugged in or loaded with food recently, it will take longer for it to attain the set temperature. This is normal.
Large amounts of hot food might be put in the refrigerator recently. >>>Do notput hot food into the refrigerator.
Doors might be opened frequently or left ajar for a long time. >>>The warm air that has entered into the
refrigerator causes the refrigerator to run for longer periods. Do not open the doors frequently.
Freezer or fridge compartment door might be left ajar. >>>Check if the doors are closed completely.
The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator temperature to a warmer
degree and wait until the temperature is achieved.
Door seal of the fridge or freezer may be soiled, worn out, broken or not properly seated. >>>Clean or
replace the seal. Damaged/broken seal causes the refrigerator to run for a longer period of time in order
to maintain the current temperature.
Freezer temperature is very low while the fridge temperature is sufcient.
The freezer temperature is adjusted to a very low value. >>>Adjust the freezer temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufcient.
The fridge temperature is adjusted to a very low value. >>>Adjust the fridge temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
The fridge temperature is adjusted to a very high value. >>>Adjust the fridge temperature to a lower
value and check.
EN
8
Bad odour inside the refrigerator.
No regular cleaning is performed. >>>Clean the inside of the refrigerator regularly with a sponge,
lukewarm water or carbonate dissolved in water.
Some containers or package materials may cause the smell. >>>Use a different container or different brand
packaging material.
Food is put into the refrigerator in uncovered containers. >>>Keep the food in closed containers.
Microorganisms spreading out from uncovered containers can cause unpleasant odours.
Remove the foods that have expired best before dates and spoiled from the refrigerator.
The door is not closing.
Food packages are preventing the door from closing. >>>Replace the packages that are obstructing the door.
The refrigerator is not completely even on the oor. >>>Adjust the feet tobalance the refrigerator.
The oor is not level or strong. >>>Make sure that the oor is level and capable to carry the refrigerator.
Crispers are stuck.
The food is touching the ceiling of the drawer. >>>Rearrange food in the drawer.
Humidity occurs on the outside of the refrigerator or between the doors.
There might be humidity in the air; this is quite normal in humid weather. When the humidity is less, condensation will disappear.
The fridge temperature is adjusted to a very high value. >>>Fridge compartmenttemperature setting
has an effect on the temperature of the freezer. Change the temperatures of the fridge or freezer and wait
until the relevant compartments attain a sufcient temperature.
Doors are opened frequently or left ajar for a long time. >>>Do not open the doors frequently.
Door is ajar. >>> Close the door completely.
The refrigerator is plugged in or loaded with food recently. >>>This is normal.When the refrigerator is
plugged in or loaded with food recently, it will take longer for it to attain the set temperature.
Large amounts of hot food might be put in the refrigerator recently. >>>Do not put hot food into the refrigerator.
Vibrations or noise.
The oor is not level or stable. >>> If the refrigerator rocks when moved slowly, balance it by adjusting its
feet. Also make sure that the oor is strong enough to carry the refrigerator, and level.
The items put onto the refrigerator may cause noise. >>>Remove the items on top of the refrigerator.
There are noises coming from the refrigerator like liquid owing, spraying, etc.
Liquid and gas ows occur in accordance with the operating principles of your refrigerator. It is normal and not a fault.
Whistle comes from the refrigerator.
Fans are used in order to cool the refrigerator. It is normal and not a fault.
Condensation on the inner walls of refrigerator.
Hot and humid weather increases icing and condensation. It is normal and not a fault.
Doors are opened frequently or left ajar for a long time. Do not open the doors frequently. Close them if they are open.
Door is ajar. >>>Close the door completely.
The refrigerator is running frequently or for a long time.
EN
9
