20V CORDLESS SMD LED 4000LM WORK
LIGHT - BODY ONLY
MODEL NO: CP20VWL
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT attempt to open, disassemble, modify or service the unit.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 40°C (104°F).
9 Replace only with the battery packs designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with
cool water and seek immediate medical attention.
2. INTRODUCTION
Cordless work light useful in any workspace with integrated AC and DC power. 360° Movement with SMD LED technology for ultra-bright
illumination. 96 SMD LED Lights producing up to 4000 lumens. Robust design with integrated carry handle and side lights to illuminate the
darkest spaces. Simple on/o switch with two levels of brightness depending on power supply. Powered by either 20V Lithium-ion battery (not
included) or 230V 50Hz 1.5m mains cable with British standard plug.
3. SPECIFICATION
Model No:............................................................. CP20VWL
Charging Time: ..................See Battery Details (not included)
Electrical Class: ..........................................................Class1
Electrical Fuse Rating: .....................................................13A
Electrical Plug Type: ................................................3-Pin BS
IP Rating: .......................................IP20 at Lamp Body, IK07
LED Qty: ............................................................................96
LED Type: ...................................................SMD LED 6500K
Lumen Output: 2700lm using 20V battery pack (not supplied)
.....................................................4250lm using mains cable.
Power: .......25W using battery pack - 45W using mains cable
CONSUMABLES:
Batteries (not included):
CP20VBP2 - 2Ah Battery, CP20VBP4 - 4Ah Battery
CP20VBP6 - 6Ah
Battery Charger (not included):
CP20VMC
4. OPERATION
WARNING! Ensure that you read, fully understand, and apply the safety instructions before use.
4.1. USING THE LIGHT
4.1.1. Operate the worklight using the three position rocker switch on the top surface of the unit.
4.1.2. The light has three settings, these are: O = o, I = mains power, II = battery power.
4.1.3. Adjust the position of the lamp surfaces to suit the environment.
4.2. MOUNTING THE LIGHT
4.2.1. The light may be wall mounted by suspending it on two xings (not supplied) that are positioned at 150 mm centres to suit the size
of the keyhole slots in two of the unit’s feet.
Refer to
instructions
CP20VWL Issue: 2 (2) 22/10/21
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
WARNING! Always disconnect from power source before carrying out any cleaning.
9 Clean the casing externally (not the glass) with a moist cloth.
8 DO NOT use solvents or abrasives.
9 If necessary clean the glass with alcohol and a soft cloth.
9 When not in use, store in clean, moisture free environment.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
