Smeg RF28KNZA 278L Single Door Freezers User Manual

Freezer / User ManualEN

RF28KNZA

Congelatore / Manuale per l’usoIT

Congélateur / Guide D’utilisationFR

EN - 2

Thank you for choosing this product.

This user manual contains important information on safety and instructions intended to

assist you in the operation and maintenance of your appliance.

Please take the time to read this user manual before using your appliance and keep this

book for future reference.

Icon Type Meaning

WARNING Serious injury or death risk

RISK OF ELECTRIC SHOCK Dangerous voltage risk

FIRE Warning; Risk of re / ammable materials

CAUTION Injury or property damage risk

IMPORTANT Operating the system correctly

EN - 3

CONTENTS

1 SAFETY INSTRUCTIONS ............................................................................... 4

1.1 General Safety Warnings ...............................................................................................4

1.2 Installation warnings .......................................................................................................8

1.3 During Usage..................................................................................................................8

2 DESCRIPTION OF THE APPLIANCE .......................................................... 10

2.1 Dimensions ................................................................................................................... 11

3 USING THE APPLIANCE ..............................................................................12

3.1 Information on No-Frost technology .............................................................................12

3.2 Display and Control Panel ............................................................................................13

3.3 Operating Your Freezer ................................................................................................13

3.3.1 Freezer Temperature Adjustment ..............................................................................13

3.3.2 Super Freeze Mode ...................................................................................................13

3.3.3 Economy Mode..........................................................................................................14

3.3.4 Drink Cool Mode ........................................................................................................14

3.3.5 Screen Saver Mode ...................................................................................................14

3.3.6 The Child Lock Function ............................................................................................15

3.3.7 Mute Mode.................................................................................................................15

3.3.8 Door Open Alarm Function ........................................................................................15

3.4 Temperature Settings Warnings ...................................................................................15

3.5 Accessories ..................................................................................................................15

3.5.1 Ice Tray (In some models) .......................................................................................15

3.5.2 The Icematic (In some models) ...............................................................................16

3.5.3 The Door-Icematic (In some models) ......................................................................16

4 FOOD STORAGE ........................................................................................... 17

5 CLEANING AND MAINTENANCE ................................................................ 20

5.1 Defrosting .....................................................................................................................20

6 SHIPMENT AND REPOSITIONING .............................................................. 21

6.1 Transportation and Changing Positioning ....................................................................21

6.2 Repositioning the Door .................................................................................................21

7 BEFORE CALLING AFTER-SALES SERVICE ........................................... 22

8 TIPS FOR SAVING ENERGY ........................................................................ 24

EN - 4

1 SAFETY INSTRUCTIONS

1.1 General Safety Warnings

Read this user manual carefully.

WARNING: Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear of

obstruction.

WARNING: Do not use mechanical devices or

other means to accelerate the defrosting process,

other than those recommended by the manufacturer.

WARNING: Do not use electrical appliances inside

the food storage compartments of the appliance,

unless they are of the type recommended by the

manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: When positioning the appliance,

ensure the supply cord is not trapped or damaged.

WARNING: Do not locate multiple portable socket-

outlets or portable power supplies at the rear of the

appliance.

WARNING: In order to avoid any hazards resulting

from the instability of the appliance, it must be xed in

accordance with the instructions.

If your appliance uses R600a as a refrigerant (this

information will be provided on the label of the cooler)

you should take care during transportation and

installation to prevent the cooler elements from being

damaged. R600a is an environmentally friendly and

EN - 5

natural gas, but it is explosive. In the event of a leak

due to damage of the cooler elements, move your

fridge away from open ames or heat sources and

ventilate the room where the appliance is located for a

few minutes.

• While carrying and positioning the fridge, do not

damage the cooler gas circuit.

• Do not store explosive substances such as aerosol

cans with a ammable propellant in this appliance.

• This appliance is intended to be used in household

and domestic applications such as:

– sta󰀨 kitchen areas in shops, o󰀩ces and other

working environments.

– farm houses and by clients in hotels, motels and

other residential type environments.

– bed and breakfast type environments;

– catering and similar non-retail applications.

• If the socket does not match the refrigerator plug,

it must be replaced by the manufacturer, a service

agent or similarly qualied persons in order to avoid

a hazard.

• A specially grounded plug has been connected

to the power cable of your refrigerator. This plug

should be used with a specially grounded socket

of 16 amperes. If there is no such socket in your

house, please have one installed by an authorised

electrician.

EN - 6

• This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the

appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made

by children without supervision.

• Children aged from 3 to 8 years are allowed to load

and unload refrigerating appliances. Children are not

expected to perform cleaning or user maintenance

of the appliance, very young children (0-3 years old)

are not expected to use appliances, young children

(3-8 years old) are not expected to use appliances

safely unless continuous supervision is given, older

children (8-14 years old) and vulnerable people can

use appliances safely after they have been given

appropriate supervision or instruction concerning

use of the appliance. Very vulnerable people are

not expected to use appliances safely unless

continuous supervision is given.

• If the supply cord is damaged, it must be replaced

by the manufacturer, an authorised service agent or

similar qualied persons, in order to avoid a hazard.

• This appliance is not intended for use at altitudes

exceeding 2000 m.

EN - 7

To avoid contamination of food, please respect the

following instructions:

• Opening the door for long periods can cause

a signicant increase of the temperature in the

compartments of the appliance.

• Clean regularly surfaces that can come in contact

with food and accessible drainage systems

• Store raw meat and sh in suitable containers in the

refrigerator, so that it is not in contact with or drip

onto other food.

• Two-star frozen-food compartments are suitable for

storing pre-frozen food, storing or making ice cream

and making ice cubes.

• One-, two- and three-star compartments are not

suitable for the freezing of fresh food.

• If the refrigerating appliance is left empty for long

periods, switch o󰀨, defrost, clean, dry, and leave the

door open to prevent mould developing within the

appliance.

EN - 8

1.2 Installation warnings

Before using your freezer for the rst time,

please pay attention to the following points:

• The operating voltage for your freezer is

220-240 V at 50Hz.

• The plug must be accessible after

installation.

• Your freezer may have an odour when

it is operated for the rst time. This is

normal and the odour will fade when your

freezer starts to cool.

• Before connecting your freezer, ensure

that the information on the data plate

(voltage and connected load) matches

that of the mains electricity supply. If in

doubt, consult a qualied electrician.

• Insert the plug into a socket with an

e󰀩cient ground connection. If the socket

has no ground contact or the plug does

not match, we recommend you consult a

qualied electrician for assistance.

• The appliance must be connected

with a properly installed fused socket.

The power supply (AC) and voltage at

the operating point must match with

the details on the name plate of the

appliance (the name plate is located on

the inside left of the appliance).

• We do not accept responsibility for any

damages that occur due to ungrounded

usage.

• Place your freezer where it will not be

exposed to direct sunlight.

• Your freezer must never be used

outdoors or exposed to rain.

• Your appliance must be at least 50 cm

away from stoves, gas ovens and heater

cores, and at least 5 cm away from

electrical ovens.

• If your freezer is placed next to a deep

freezer, there must be at least 2 cm

between them to prevent humidity

forming on the outer surface.

• Do not cover the body or top of freezer

with lace. This will a󰀨ect the performance

of your freezer.

• Clearance of at least 150 mm is required

at the top of your appliance. Do not place

anything on top of your appliance.

• Do not place heavy items on the

appliance.

• Clean the appliance thoroughly before

use (see Cleaning and Maintenance).

• Before using your freezer, wipe all parts

with a solution of warm water and a

teaspoon of sodium bicarbonate. Then,

rinse with clean water and dry. Return all

parts to the freezer after cleaning.

• Use the adjustable front legs to make

sure your appliance is level and stable.

You can adjust the legs by turning them

in either direction. This must be done

before placing food in the appliance.

• Install the plastic distance guide(s) on the

condenser (black vanes

at the rear of the

appliance) by turning it

90° (as shown in the

gure) to prevent the

condenser from touching

the wall.

• The distance between the appliance and

back wall must be a maximum of 75 mm.

1.3 During Usage

• Do not connect your freezer to the mains

electricity supply using an extension lead.

• Do not use damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• Do not use plug adapter.

• This appliance is designed for use by

adults. Do not allow children to play with

the appliance or hang o󰀨 the door.

• Never touch the power cord/plug with wet

hands. This may cause a short circuit or

electric shock.

• Do not place glass bottles or cans in

your freezer as they will burst when the

contents freeze.

• Do not place explosive or ammable

material in your freezer.

• When removing ice from the ice-making

compartment, do not touch it. Ice may

cause frost burns and/or cuts.

EN - 9

• Do not touch frozen goods with wet

hands. Do not eat ice-cream or ice cubes

immediately after they are removed from

the ice-making compartment.

• Do not re-freeze thawed frozen food. This

may cause health issues such as food

poisoning.

When the door of the freezer is closed, a

vacuum seal will form. Wait for 1 minute

before reopening it.

This application is optional for easy opening

of the door. With this application, a little

condensation may occur around this area

and you may remove it.

Old and Out-of-order Fridges

• If your old fridge or freezer has a

lock, break or remove the lock before

discarding it, because children may

get trapped inside it and may cause an

accident.

• Old fridges and freezers contain

isolation material and refrigerant with

CFC. Therefore, take care not to harm

environment when you are discarding

your old fridges.

CE Declaration of conformity

We declare that our products meet the

applicable European Directives, Decisions

and Regulations and the requirements

listed in the standards referenced.

Disposal of your old appliance

The symbol on the product or on

its packaging indicates that this

product may not be treated as

household waste. Instead it shall

be handed over to the applicable

collection point for the recycling of electrical

and electronic equipment. By ensuring

this product is disposed of correctly,

you will help prevent potential negative

consequences for the environment and

human health, which could otherwise be

caused by inappropriate waste handling

of this product. For more detailed

information about recycling of this product,

please contact your local city o󰀩ce, your

household waste disposal service or the

shop where you purchased the product.

Packaging and the Environment

Packaging materials protect

your machine from damage that

may occur during transportation.

The packaging materials are

environmentally friendly as they are

recyclable. The use of recycled material

reduces raw material consumption and

therefore decreases waste production.

Notes:

• Please read the instruction manual

carefully before installing and using your

appliance. We are not responsible for the

damage occurred due to misuse.

• Follow all instructions on your appliance

and instruction manual, and keep this

manual in a safe place to resolve the

problems that may occur in the future.

• This appliance is produced to be used

in homes and it can only be used in

domestic environments and for the

specied purposes. It is not suitable for

commercial or common use. Such use

will cause the guarantee of the appliance

to be cancelled and our company will not

be responsible for any losses incurred.

• This appliance is produced to be used

in houses and it is only suitable for

cooling / storing foods. It is not suitable

for commercial or common use and/or

for storing substances except for food.

Our company is not responsible for any

losses incurred by inappropriate usage of

the appliance.

EN - 10

2 DESCRIPTION OF THE

APPLIANCE

This appliance is not intended to be used

as a built-in appliance.

This presentation is only for

information about the parts of the

appliance. Parts may vary according to the

appliance model.

1. Control panel

2. Freezer shelves

3. Freezer drawers

4. Freezer bottom drawer

5. Freezer big drawer

6. Freezer door shelves

7. Ice tray (In some models)

General notes:

Freezer Compartment (Freezer): Most

E󰀩cient use of energy is ensured in the

conguration with the drawers and bins are

on stock position.

EN - 11

2.1 Dimensions

Space required in use

H2 mm 2010

W2 mm 695

D2 mm 752,5

the height, width and depth of the

appliance including the handle,

plus the space necessary for free

circulation of the cooling air.

Overall space required in use

W3 mm 710,6

D3 mm 1243,5

the height, width and depth of the

appliance including the handle,

plus the space necessary for free

circulation of the cooling air, plus

the space necessary to allow door

opening to the minimum angle

permitting removal of all internal

equipment.

Overall dimensions

H1 mm 1860

W1 mm 595

D1 mm 650

the height, width and depth of the

appliance without the handle.

EN - 12

3 USING THE APPLIANCE

3.1 Information on No-Frost technology

No-frost freezers di󰀨er from other static

freezers in their operating principle.

In normal freezers, the humidity entering

the freezer due to opening the door and

the humidity inherent in the food causes

freezing in the freezer compartment. To

defrost the frost and ice in the freezer

compartment, you are periodically required

to turn o󰀨 the freezer, place the food that

needs to be kept frozen in a separately

cooled container and remove the ice

gathered in the freezer compartment.

The situation is completely di󰀨erent in no-

frost freezers. Dry and cold air is blown into

the freezer compartment homogeneously

and evenly from several points via a blower

fan. Cold air dispersed homogeneously

and evenly between the shelves cools all

of your food equally and uniformly, thus

preventing humidity and freezing.

Therefore your no-frost freezer allows you

ease of use, in addition to its huge capacity

and stylish appearance.

EN - 13

3.2 Display and Control Panel

1 8 7 6a 5 10

2 9 6b 4

11 12 3

Using the Control Panel

1. Freezer set button (FS)

2. Mode button (M)

3. Drink cool button

4. Mute button

5. Freezer set value display

6a / 6b. Super freeze symbol

7. Economy mode symbol

8. Low voltage symbol

9. Child lock symbol

10. Alarm (SR) symbol

11. Sound o󰀨 symbol

12. Drink cool value display*

*Active symbol may change according

to language (Min-Dk.)

3.3 Operating Your Freezer

Lighting (If available)

When the product is plugged in for the

rst time, the interior lights may turn on 1

minute late due to opening tests.

3.3.1 Freezer Temperature Adjustment

• The initial temperature value for the

freezer compartment is -18°C.

• Press the TEMPERATURE SET button to

adjust the temperature value.

• The value for the freezer compartment

will change to a lower temperature each

time this button is pressed while the

indicator is ashing.

• ( -16 °C, -17 °C, -18 °C, -19 °C, -20 °C,

-21 °C, -22 °C, -23 °C, -24 °C)

• After reaching the desired temperature,

wait for 5 seconds without pressing any

buttons. Your freezer will now operate

at that temperature.

• If you continue to press the button after

the value for the freezer compartment

reaches -24 °C (maximum cold

position), the temperature values will

start again from -16 °C.

Recommended Temperature Values

for Freezer

When to adjust

Inner

Temperature

For minimum freezing capacity -16

C, -17

In normal usage

-18

C, -19

-20

C or -21

For maximum freezing capacity

-22

C, -23

C or

-24

3.3.2 Super Freeze Mode

Purpose:

• To freeze large amounts of food

• To freeze ready foods

• To freeze food more quickly

• To store seasonal foods for a long time.

How To Use?

• Press the MODE button until the Super

Freeze mode is selected, 'SF' will show

on the display.

• While the Super Freeze Mode indicator

is ashing, do not press any buttons for

5 seconds. A beep will sound to conrm

Super Freeze mode is active.

• While the Super Freeze mode is active,

EN - 14

'SF' will be displayed.

Super freeze mode will automatically

cancel after 24 hours, depending on

the environmental temperature or when the

freezer sensor reaches a su󰀩ciently low

temperature.

3.3.3 Economy Mode

The optimum condition for your freezer is at

-18 °C as it will consume minimum energy.

Purpose:

• To operate your freezer more

economically.

How To Use?

• Press the MODE button until a circle

appears around the Economy symbol.

• If no button is pressed for 1 second,

Economy mode will be set. The circle will

blink three times and an alarm will sound.

• While Economy mode is active, 'E' will be

displayed.

To cancel, you will just need to press

on mode button.

3.3.4 Drink Cool Mode

How To Use?

Press the DRINK COOL button to activate

Drink Cool mode. Each press of the

button will increase the time by 5 minutes

starting from 0 up to 30 minutes, then will

start again from 0. The time will show on

the Drink Cool Value display. An alarm

will sound when the Drink Cool mode is

complete.

Important: This is a timer, not a

cooling process.

Adjust the time according to the

temperature of the bottles before they

are placed in the freezer. For example, you

may initially set the time as 5 minutes in the

beginning, then, if the bottle is not cool

enough after this time, you might set a

further 5 or 10 minutes.

Regularly check the temperature of the

bottles while this mode is active. When

the drinks are cool enough, you must take

them out of the appliance.

If the bottles are left in the appliance for too

long while the Drink Cool mode is active,

they can burst.

3.3.5 Screen Saver Mode

Purpose

This mode saves energy by switching o󰀨 all

control panel lighting when the panel is left

inactive.

How To Use?

• Screen saver mode will be activated

automatically after 30 seconds.

• If you press any key while the lighting

of the control panel is o󰀨, the current

machine settings will reappear on the

display to let you make any change you

wish.

• If you do not cancel the screen saving

mode or press any key for 30 seconds,

control panel will remain o󰀨.

To deactivate the screen saving mode,

• To cancel the screen saving mode, rst of

all, you need to press any key to activate

the keys and then press and hold the

MUTE button for 3 seconds.

• To reactivate screen saving mode, press

and hold the MUTE button for 3 seconds.

• While Screen Saver mode is active, Child

Lock can also be activated.

• If no buttons are pressed for ve seconds

after activating Child Lock, the control

panel lights will switch o󰀨.

• Press any button to view the previous

settings and whether Child Lock is

active. Child Lock can also be cancelled

while Screen Saver mode is active, as

described in the Child Lock Function

section.

EN - 15

3.3.6 The Child Lock Function

Purpose:

To prevent unintentional or accidental

changes being made to settings.

Activating Child Lock:

Press and hold the DRINK COOL and

MODE buttons simultaneously for 5

seconds.

Use the same method to deactivate Child

Lock.

Child Lock will also deactivate if the

electricity is interrupted or the freezer

is unplugged.

3.3.7 Mute Mode

Press the MUTE button to activate this

mode. While this mode is active, there will

be no button or alarm sounds.

To cancel this mode, press the MUTE

button again.

3.3.8 Door Open Alarm Function

If freezer door is opened more than 2

minutes, appliance sounds ‘beep beep’.

3.4 Temperature Settings Warnings

• Your appliance is designed to operate in

the ambient temperature ranges stated

in the standards, according to the climate

class stated in the information label. It

is not recommended that your fridge is

operated in the environments which are

outside of the stated temperature ranges.

This will reduce the cooling e󰀩ciency of

the appliance.

• Temperature adjustments should be

made according to the frequency of

door openings, the quantity of food kept

inside the appliance and the ambient

temperature in the location of your

appliance.

• When the appliance is rst switched on,

allow it to run for 24 hours in order to

reach operating temperature. During this

time, do not open the door and do not

keep a large quantity of food inside.

• A 5 minute delay function is applied

to prevent damage to the compressor

of your appliance when connecting

or disconnecting to mains, or when

an energy breakdown occurs. Your

appliance will begin to operate normally

after 5 minutes.

Climate class and meaning:

T (tropical): This refrigerating appliance

is intended to be used at ambient

temperatures ranging from 16 °C to 43 °C.

ST (subtropical): This refrigerating

appliance is intended to be used at ambient

temperatures ranging from 16 °C to 38 °C.

N (temperate): This refrigerating appliance

is intended to be used at ambient

temperatures ranging from 16 °C to 32 °C.

SN (extended temperate): This

refrigerating appliance is intended to be

used at ambient temperatures ranging from

10 °C to 32 °C.

Important installation instructions

This appliance is designed to work in

di󰀩cult climate conditions and is powered

with ‘Freezer Shield’ technology which

ensures that the frozen food in the

freezer will not defrost even if the ambient

temperature falls as low as -15 °C. So

you may then install your appliance in an

unheated room without having to worry

about frozen food in the freezer being

spoilt. When the ambient temperature

returns to normal, you may continue using

the appliance as usual.

3.5 Accessories

Visual and text descriptions in the

accessories section may vary according

to the model of your appliance.

3.5.1 Ice Tray (In some models)

• Fill the ice tray with water and place in

the freezer compartment.

EN - 16

• After the water has completely frozen,

you can twist the tray as shown below to

remove the ice cubes.

3.5.2 The Icematic (In some models)

(The images are representative)

• Pull the lever towards you and remove

the ice maker tray

• Fill with water to the marked level

• Hold the left end of the lever and set the

ice-tray on the icebox

• When ice cubes have formed, twist

the lever to drop the ice cubes into the

icebox.

Do not ll the icebox with water in

order to make ice. It will break.

3.5.3 The Door-Icematic (In some

models)

(The images are representative)

• Pull the lever towards you and remove

the ice maker tray

• Fill with water to the marked level

• Hold the lever and set the ice-tray above

the icebox .

• When ice cubes have formed, twist

the lever to drop the ice cubes into the

icebox.

• Reach the ice cubes with rotating icebox.

• Icebox can be pulled out from door-

icematic after rotation motion

Do not ll the icebox with water in

order to make ice. It will break.

Visual and text descriptions in

the accessories section may vary

according to the model of your

appliance.

EN - 17

4 FOOD STORAGE

For normal operating conditions, set the

temperature of the freezer compartment to

-18 or -20

• The freezer is used for storing frozen

food, freezing fresh food, and making ice

cubes.

• Food in liquid form should be frozen

in plastic cups and other food should

be frozen in plastic folios or bags.For

freezing fresh food; wrap and seal fresh

food properly, that is the packaging

should be air tight and shouldn’t leak.

Special freezer bags, aluminum foil

polythene bags and plastic containers

are ideal.

• Do not store fresh food next to frozen

food as it can thaw the frozen food.

• Before freezing fresh food, divide it into

portions that can be consumed in one

sitting.

• Consume thawed frozen food within a

short period of time after defrosting

• Always follow the manufacturer's

instructions on food packaging when

storing frozen food. If no information is

provided food, should not be stored for

more than 3 months from the date of

purchase.

• When purchasing frozen food, make sure

that it has been stored under appropriate

conditions and that the packaging is not

damaged.

• Frozen food should be transported in

appropriate containers and placed in the

freezer as soon as possible.

• Do not purchase frozen food if the

packaging shows signs of humidity

and abnormal swelling. It is probable

that it has been stored at an unsuitable

temperature and that the contents have

deteriorated.

• The storage life of frozen food depends

on the room temperature, the thermostat

setting, how often the door is opened,

the type of food, and the length of time

required to transport the product from

the shop to your home. Always follow the

instructions printed on the packaging and

never exceed the maximum storage life

indicated.

• If the freezer door has been left open for

a long time or not closed properly, frost

will form and can prevent e󰀩cient air

circulation. To resolve this, unplug the

freezer and wait for it to defrost. Clean

the freezer once it has fully defrosted.

• The freezer volume stated on the label is

the volume without baskets, covers, and

so on.

• Do not refreeze thawed food. It may

pose a danger to your health and cause

problems such as food poisoning.

NOTE: If you attempt to open the freezer

door immediately after closing it, you

will nd that it will not open easily. This

is normal. Once equilibrium has been

reached, the door will open easily.

If you would use maximum freezing

capacity of your freezer:

• While freezing fresh foods, the maximum

amount of fresh food (in kg) that can be

frozen in 24 hours is indicated on the

appliance label.

• For optimum appliance performance

to reach maximum freezing capacity,

activate Super Freeze (SF) mode 24

hours before placing fresh food into the

freezer.

• After placing fresh food into the freezer,

24 hours is generally su󰀩cient for

freezing. ”Super Freeze” mode will be

deactivated automatically in 2-3 days to

save energy.

If you would freeze a small amount (up

to 3 kg) in your freezer:

• Place your food without touching already

frozen food and activate “Fast Freezing”

mode. You can put your food next to

other frozen food after it is completely

frozen (after minimum 24 hours).

• Do not re-freeze frozen food after it has

thawed. This may cause health issues,

such as food poisoning.

EN - 18

• Allow hot food to completely cool down

before placing it in the freezer.

• When buying frozen food ensure that

these have been frozen at suitable

temperatures and that the packing is

intact.

• Use the fast freezing shelf to freeze

home cooking (and any other food

which needs to be frozen quickly) more

quickly because of the freezing shelf’s

greater freezing power. Fast freezing

shelf is the bottom drawer of the freezer

compartment.

• To use the maximum capacity of the

freezer compartment, use the glass

shelves for the upper and middle section,

and use the lower basket for the bottom

section.

EN - 19

The table below is a quick guide to show you the most e󰀩cient way to store the major

food groups in your freezer compartment.

Meat and sh Preparation

Maximum storage time

(months)

Steak Wrap in foil 6 - 8

Lamb meat Wrap in foil 6 - 8

Veal roast Wrap in foil 6 - 8

Veal cubes In small pieces 6 - 8

Lamb cubes In pieces 4 - 8

Minced meat In packaging without using spices 1 - 3

Giblets (pieces) In pieces 1 - 3

Bologna sausage/salami Should be kept packaged even if it has a membrane 1 - 3

Chicken and turkey Wrap in foil 4 - 6

Goose and duck Wrap in foil 4 - 6

Deer, rabbit, wild boar In 2.5 kg portions or as llets 6 - 8

Freshwater sh

(Salmon, Carp, Crane,

Catsh)

After cleaning the bowels and scales of the sh,

wash and dry it. If necessary, remove the tail and

head.

Lean sh (Bass, Turbot,

Flounder)

Fatty shes (Tuna,

Mackerel, Bluesh,

Anchovy)

2 - 4

Shellsh Clean and in a bag 4 - 6

Caviar

In its packaging, or in an aluminium or plastic

container

2 - 3

Snails In salty water, or in an aluminium or plastic container 3

NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it

must not be re-frozen.

Vegetables and Fruits Preparation

Maximum storage time

(months)

String beans and beans Wash, cut into small pieces and boil in water 10 - 13

Beans Hull, wash and boil in water 12

Cabbage Clean and boil in water 6 - 8

Carrot Clean, cut into slices and boil in water 12

Pepper

Cut the stem, cut into two pieces, remove the core

and boil in water

8 - 10

Spinach Wash and boil in water 6 - 9

Cauliower

Remove the leaves, cut the heart into pieces and

leave it in water with a little lemon juice for a while

10 - 12

Eggplant Cut into pieces of 2cm after washing 10 - 12

Corn Clean and pack with its stem or as sweet corn 12

Apple and pear Peel and slice 8 - 10

Apricot and Peach Cut into two pieces and remove the stone 4 - 6

EN - 20

Vegetables and Fruits Preparation

Maximum storage time

(months)

Strawberry and

Blackberry

Wash and hull 8 - 12

Cooked fruits Add 10 % of sugar to the container 12

Plum, cherry, sourberry Wash and hull the stems 8 - 12

Maximum storage time

(months)

Thawing time at room

temperature (hours)

Thawing time in oven

(minutes)

Bread 4 - 6 2 - 3 4-5 (220-225 °C)

Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)

Pastry 1 - 3 2 - 3 5-10 (200-225 °C)

Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)

Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)

Pizza 2 - 3 2 - 4 15-20 (200 °C)

Dairy products Preparation

Maximum storage time

(months)

Storage conditions

Packet (Homogenized)

Milk

In its own packet 2 - 3 Pure Milk – in its own packet

Cheese - excluding

white cheese

In slices 6 - 8

Original packaging may be

used for short-term storage.

Keep wrapped in foil for

longer periods.

Butter, margarine In its packaging 6

5 CLEANING AND

MAINTENANCE

Disconnect the unit from the power

supply before cleaning.

Do not wash your appliance by

pouring water on it.

Do not use abrasive products,

detergents or soaps for cleaning the

appliance. After washing, rinse with clean

water and dry carefully. When you have

nished cleaning, reconnect the plug to the

mains supply with dry hands.

• Make sure that no water enters the lamp

housing and other electrical components.

• The appliance should be cleaned

regularly using a solution of bicarbonate

of soda and lukewarm water.

• Clean the accessories separately by

hand with soap and water. Do not wash

accessories in a dish washer.

• Clean the condenser with a brush at least

twice a year. This will help you to save on

energy costs and increase productivity.

The power supply must be

disconnected during cleaning.

5.1 Defrosting

water tray

• Your appliance performs automatic

defrosting. The water formed as a result

of defrosting passes through the water

collection spout, ows into the water tray

behind your appliance and evaporates

there.

• Make sure you have disconnected the

EN - 21

plug of your appliance before cleaning

the water tray.

• Remove the water tray from its position

by removing the screws (if it has screws).

Clean it with soapy water at specic time

intervals. This will prevent odours from

forming.

Replacing LED Lighting

To replace any of the LEDs, please contact

the nearest Authorised Service Centre.

Note: The numbers and location of the

LED strips may change according to

the model.

If product equipped with LED lamp

This product contains a light source of

energy e󰀩ciency class <E>.

If product equipped with LED Strip(s) or

LED card(s)

This product contains a light source of

energy e󰀩ciency class <F>.

6 SHIPMENT AND

REPOSITIONING

6.1 Transportation and Changing

Positioning

• The original packaging and foam may be

kept for re-transportation (optional).

• Fasten your appliance with thick

packaging, bands or strong cords and

follow the instructions for transportation

on the packaging.

• Remove all movable parts or x them

into the appliance against shocks

using bands when re-positioning or

transporting.

Always carry your appliance in the

upright position.

6.2 Repositioning the Door

• It is not possible to change the opening

direction of your appliance door if door

handles are installed on the front surface

of the appliance door.

• It is possible to change the opening

direction of the door on models with

handle on the side of the door or without

handles.

• If the door-opening direction of your

appliance can be changed, contact the

nearest Authorised Service Centre to

change the opening direction.

EN - 22

7 BEFORE CALLING AFTER-SALES SERVICE

Errors

Your freezer will warn you if the temperature of the freezer is at an improper level or if a

problem occurs with the appliance. Warning codes are displayed in the freezer Indicators.

ERROR TYPE MEANING WHY WHAT TO DO

E01 Sensor warning
