2/3-LEVEL COMPOSITE HEAVY-DUTY
TROLLEY
MODEL NO: CX202, CX203
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Only use on firm, level, unobstructed surfaces which are capable of supporting the trolley plus load.
8 DO NOT overload.
9 Always load evenly with the centre of gravity of the load as near the centre as possible.
9 Apply the brakes before commencing work.
8 DO NOT stand/ride on the trolley, or allow others to do so.
9 Replace or repair damaged parts. Use only recommended parts. Unauthorised parts may be dangerous and will invalidate the warranty.
WARNING! Failure to comply with these instructions may result in loss of load, damage to the stand or other property and/or personal
injury.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
2. INTRODUCTION
Heavy-duty garage and workshop trolley with a massive 113kg (CX202) 83kg (CX203) capacity per shelf. Manufactured from extra-strong impact
resistant plastic. Ideal for a wide variety of applications. Features deep wall shelves and tool storage compartments built into the contoured
handle. Fitted with four large rubber wheels, two xed and two swivel castors.
3. SPECIFICATION
Model No ............................. .......................................CX202
Overall (W x D x H) .................. .............1000 x 440 x 850mm
Shelf Size .................. ..............................790 x 435 x 110mm
Capacity............................................. ................. 113kg/Level
4. CONTENTS CX202
Refer to
instructions
Model No ............................. .......................................CX203
Overall (W x D x H) .................. .............1000 x 440 x 850mm
Shelf Size .................. ..............................790 x 435 x 110mm
Capacity............................................. ...................83kg/Level
No. Description Quantity
1 N/A -
2 N/A -
3 Shelf 2
4 Screw 8
5 Handle 1
6 N/A -
7 Leg 2
8 Leg 2
9 Swivel castor frame 2
10 Nut 4
11 Castor 4
12 Screw 4
13 Fixed castor frame 2
14 N/A -
15 Washer 16
16 Wheel 4
17 Screw 16
CX202, CX203 | Issue 1 28/01/20
Original Language Version
© Jack Sealey Limited
5. CONTENTS CX203
6. ASSEMBLY CX202
CX202, CX203 | Issue 1 28/01/20
Original Language Version
© Jack Sealey Limited
No. Description Quantity
1 N/A -
2 N/A -
3 Shelf 3
4 Screw 8
5 Handle 1
6 N/A -
7 Leg 2
8 Leg 2
9 Swivel castor frame 2
10 Nut 4
11 Castor 4
12 Screw 4
13 Fixed castor frame 2
14 N/A -
15 Washer 16
16 Wheel 4
17 Screw 16
7. ASSEMBLY CX203
CX202, CX203 | Issue 1 28/01/20
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
