Ts100 Installation Instructions
x2
x2
D - M8 washer X18
A - M6x25mm X3
B- M8x12mm X14
E - M8 nut X4 Also required: Pozi screwdriver
Assembly instructions for TS100
TV & Pulse Soundbar stand
TV Fixing KitAssembly Kit
Bx4
Ax3
Bx4
Cx4
Dx4
Dx4
5mm 5mm
5mm 5mm
x4
x4
Top view
Top view
C - M5x10mm X4
4a 4a
VESA 100 / 200 VESA 300 / 400 / 600x400 / 800x400
Universal 200mm x 200mm - 800mm x 400mm
J/K/L
x4
F/G/H/I
x4
M/N/O/P
x4
J/K/L
x4
F/G/H/I
x4
M/N/O/P
x4
4c
Ex4
Dx4
4b
Bx4
Dx4
M - M4x5mm X4
N - M5x5mm X4
O - M6x6mm X4
P - M8x6mm X4
J - M5 washer X4
K - M6 washer X4
L - M8 washer X4
F - M4x20mm X4
G - M5x20mm X4
H - M6x20mm X4
I - M8x20mm X4
!
!
Optional
Optional
5a 5b
Bx2
!
Dx2
6a
7a 7b 7c6b
x4
6a
x4
8
Ts100 Installation Instructions
Assembly instructions for TS100
TV & Pulse Soundbar stand
