COSTWAY BC10046US 2-in-1 Convertible Baby Stroller User Manual

Please give us a chance to make it right and do better !

Contact our friendly customer service department for help first.

Replacements for missing or damaged parts will be shipped ASAP !

Do NOT return this item.

Baby Stroller

BC10046US

USER’S MANUAL

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

US:cs.us@costway.com

UK:cs.uk@costway.com

AU:[email protected]

US office: Fontana UK office: Ipswich AU office: Truganina

02 03

Before You Start

General Warnings:

Danger! Keep all small parts and packaging materials for this product away from

babies and children, otherwise they may pose a choking hazard.

The product must be installed and used under the supervision of an adult.

Read through each step carefully and follow the proper order.

Remove all Packaging, separate and count all parts and hardware before

installation.

Please ensure that all parts are correctly installed, incorrect installation can lead to

a danger.

We recommend that, where possible, all items are assembled near the area in

which they will be placed in use, to avoid moving the product unnecessarily once

assembled.

Ensure a secure surface during installation, and place the product always on a flat,

steady and stable surface.

Please read all instructions carefully and keep it for future reference.

Read these instructions carefully before use and keep them for future

reference. Your child's safety may be affected if you do not follow these

instructions. When you unpack the stroller from the carton box, please remove

all plastic bags and small accessories and keep them away from children.

02 03

Before You Start

General Warnings:

Danger! Keep all small parts and packaging materials for this product away from

babies and children, otherwise they may pose a choking hazard.

The product must be installed and used under the supervision of an adult.

Read through each step carefully and follow the proper order.

Remove all Packaging, separate and count all parts and hardware before

installation.

Please ensure that all parts are correctly installed, incorrect installation can lead to

a danger.

We recommend that, where possible, all items are assembled near the area in

which they will be placed in use, to avoid moving the product unnecessarily once

assembled.

Ensure a secure surface during installation, and place the product always on a flat,

steady and stable surface.

Please read all instructions carefully and keep it for future reference.

Read these instructions carefully before use and keep them for future

reference. Your child's safety may be affected if you do not follow these

instructions. When you unpack the stroller from the carton box, please remove

all plastic bags and small accessories and keep them away from children.

04 05

Unfold The Stroller

Assembly

of Front Wheel

Open the folding hook,

unfold as the picture showed until frame is opened completely.

Insert the metal part

into the front wheel.

When you hear “click”

sound, the front wheels

are assembled. press the

side metal button to

release front wheel.

Release of front wheel.

slide the button

to lock and unlock

front wheel.

Caution: Ensure that all locks are in lock up

position before pulling up and pushing the baby stroller.

Components

Parts

Please read the instruction book carefully before using,it will tell you the

correct operation method and installation procedures. Avoid any

possibility of stroller damage or baby hurt because of incorrect operation.

Please keep this instruction book well, and put it in the place easy to get.

1. Handle

2. Canopy

3. Armrest

4. Carrycot

5. Footrest

6. Front wheel

7. Rear wheel

8. Folding button

04 05

Unfold The Stroller

Assembly

of Front Wheel

Open the folding hook,

unfold as the picture showed until frame is opened completely.

Insert the metal part

into the front wheel.

When you hear “click”

sound, the front wheels

are assembled. press the

side metal button to

release front wheel.

Release of front wheel.

slide the button

to lock and unlock

front wheel.

Caution: Ensure that all locks are in lock up

position before pulling up and pushing the baby stroller.

Components

Parts

Please read the instruction book carefully before using,it will tell you the

correct operation method and installation procedures. Avoid any

possibility of stroller damage or baby hurt because of incorrect operation.

Please keep this instruction book well, and put it in the place easy to get.

1. Handle

2. Canopy

3. Armrest

4. Carrycot

5. Footrest

6. Front wheel

7. Rear wheel

8. Folding button

ASSEMBLE AND

DISASSEMBLE

THE CARRYCOT

As shown in the Figure 1:

The carrycot can be assembled by

inserting the plastic adapter on the

frame of the stroller into the

adapter of the carrycot on both

sides.

As shown in the Figure 2:

Press the disassembly button of the

carrycot on both sides inwards, and

lift it up to disasssemble the carrycot.

Assembly and release

of rear wheel

Safety Belt

Insert the bolt

and tighten

Insert the axle of

brakes and tires

Follow the left picture: Press down the button to open the safety buckle.

Follow the right picture: Insert the buckle to the socket, when hear click

sound. then it is locked.

Cover cover sheet, and insert

whole stroller frame into the

rear wheel frame. When hearing

the “click” sound, the rear

wheels are assembled.Press

down rear wheel release button

to remove back wheel.

Caution

: Please always use the safety harness for safety.

Put the crotch strap between baby' s legs and clasp the buckle.

06 07

ASSEMBLE AND

DISASSEMBLE

THE CARRYCOT

As shown in the Figure 1:

The carrycot can be assembled by

inserting the plastic adapter on the

frame of the stroller into the

adapter of the carrycot on both

sides.

As shown in the Figure 2:

Press the disassembly button of the

carrycot on both sides inwards, and

lift it up to disasssemble the carrycot.

Assembly and release

of rear wheel

Safety Belt

Insert the bolt

and tighten

Insert the axle of

brakes and tires

Follow the left picture: Press down the button to open the safety buckle.

Follow the right picture: Insert the buckle to the socket, when hear click

sound. then it is locked.

Cover cover sheet, and insert

whole stroller frame into the

rear wheel frame. When hearing

the “click” sound, the rear

wheels are assembled.Press

down rear wheel release button

to remove back wheel.

Caution

: Please always use the safety harness for safety.

Put the crotch strap between baby' s legs and clasp the buckle.

06 07

08 09

CARRYCOT

ADJUSTMENT

CANOPY

ASSEMBLY

Linked Brake

of the Rear Wheels

Pull up the adjustment

button to adjust the angle

of the carrycot.

Press linked brake button with foot to

stop stroller as picture showed. Press

back to unlock brake.

Linked brake

Just adjust the canopy

adapting clip to the

carrycot tube.

Caution: Adjust the carrycot carefully while the baby is

in it in order to prevent the danger that may be caused

by a sudden position change of the seat.

Caution: Please press the brake lever when stopping the

stroller to avoid moving of the stroller. Push the stroller to

check whether the locks are in lock up position.

REMOVABLE ARMREST

FOLDING OF THE STROLLER

Removable

Front Armrest

1. Remove the carrycot.

2. Press the folding button and push down the handle at the same time.

3. Push down the handle until the lock lever can lock the stroller.

Caution: Please pull the front armarest to make sure

that the installation is firm.
