Please read the manual carefully before use and keep it well for further reference.
Air Compression Leg Massager
FT-058A
User Manual
- 1 -
01-01
02-03
03-03
03-03
04-04
04-05
05-05
05-05
06-06
06-06
06-06
Safety precautions ......................................................................................................................
FAQs ............................................................................................................................................
Specifications ...............................................................................................................................
Troubleshooting ..........................................................................................................................
Names of Components .................................................................................................................
Usage ...........................................................................................................................................
Cleaning .......................................................................................................................................
Storage ........................................................................................................................................
Disposal .......................................................................................................................................
Package includes..........................................................................................................................
Contact Us ....................................................................................................................................
Warnings
Safety Precautions
Contents
Cautions
1. Those with any of the following conditions or persons who are receiving medical treatment should
consult the doctor before using the machine:
1) Using pacemaker or other medical devices which are susceptible to electrical interference;
2) Suffering from malignant tumors;
3) Suffering from cardiac diseases;
4) Having serious peripheral neuropathy dysfunction or sensory disturbance caused by diabetes;
5) Being unsuitable to do the massage because of traumas on the body;
2. Keep it out of the reach of infants, children and people without the ability to use it independently.
3. Don't use other power adapter but the original one.
4. Don't scratch, damage, process, excessively bend, pull or twist the power cord of power adapter.
Otherwise, it may cause fire or electric shock.
5. It is not allowed to use when the power adapter dysfunctions or the plug is loose.
6. Don't plug or unplug the power adapter with wet hands.
7. Don't put the controller in the quilt or use the machine in high temperature condition.
8. It is forbidden to remodel, disassemble or repair the machine without permission.
1. Stop using it immediately if you feel unwell. Don't use it again before consult the doctor.
2. Don't use it in bathroom or other humid places.
3. Unplug the power adapter from the socket before you clean and maintain it.
4. Unplug the power adapter when you are not using it.
5. Don't walk around when you are using this item or wearing the wraps.
- 2 -
FAQs
Q1: How does this product massage?
A1: The wraps will be inflated and deflated in airbags to simulate kneading and stroking of tissues like
human hands. It can relax our muscles, increase circulation and relieve pain.
Q3: What should I do if I feel the massage strength is too light or too tight?
A3: There are 3 levels of massage strength selectable via the controller, please select the intensity
which is fit for you. You can also adjust the strength via changing the tightness of Velcro on the wraps.
Q4: How long should we use it?
A4: It is recommended to use it once a day (20 minutes), up to 2 times (40 minutes)
Q5: How do I know when I need to recharge it?
A5: The battery indicator light will flash in red if it runs out of battery, the device will stop working and
you need to recharge it.
Q6: How should I charge it?
A6: It comes with a Type-C charging cable and can be charge via any USB devices. The battery
indicator light will keep flashing until fully charged.
Q2: How many massage modes, and what's the difference?
A2: There are 3 massage modes,
Mode 2: Circulation Mode
In this mode, the air inflated from lower to upper and then deflated, lower inflated- upper inflated
-deflated runs in repeat.
Mode 3: Combination Mode
In this mode, Mode 1 and Mode 2 runs alternately.
Mode 1: Sequence Mode
In this mode, the air inflated and deflated from lower to upper, lower inflated- deflated- upper inflated
- all deflated runs in repeat.
Q7: Can I use the device while charging?
A7: Surely you can, the massager is battery powered but you can also use while charging.
Q8: Why does the controller get hot?
A8: As we suggested, you can use it 20 minutes per time normally. If it keeps working too long, the
controller will get hot, that’s a normal phenomenon.
Q9: Why does the controller make sound?
A9: The sound comes from the working air pump in the controller, providing air continuously to the
airbags in the wraps, that’s normal phenomenon.
Model FT-058A
Name Air Compression Leg Massager
Battery Capacity 2500 mAh
Timing 20 Minutes
Specifications
Charging voltage AC Input: 100~240 Volts, AC 50/60Hz, DC Output: 5V 2A
Troubleshooting
Causes & SolutionsProblems
1. Press the power button,
but not work.
2. Break off during
operation
1. Battery runs out, recharge it or connect power adapter to power it to use.
2. Need to press the power button for 3 seconds to turn in on.
.
1. Battery runs out, recharge it or connect the power adapter to power it for use.
2. It will shut off automatically after 20 minutes using, you can restart it.
3. Too light or tight.
1. There are three massage levels for you to choose;
2. You can adjust the width of the wrap to make the strength suitable;
3. Turn off the machine if you cannot bear the strength.
It may take 2.5~3.5 hours to fully charge, and can runs for 3.5~4.5 hours
between charges.
4. Low battery.
5. The charging cable
is broken.
It’s an universal Type-C charging cable, you can replace it with the other one.
- 3 -
Usage
Note: please charge for 3~4 hours before using for the first time.
1. Find the wraps for Left and Right Leg, make sure the controller is upward.
2. Wear the wraps on calves , adjust the position and tightness, don’t wrap too tight.
Left Leg
Left Leg
Right Leg
Right Leg
Midline Position
Tag
Power Button
Mode Button
Mode Indicator
Intensity Button
Intensity Indicator
Battery Indicator
01 L1
Conrol Panel
Controller
Massage Wraps
- 4 -
Midline Position
Tag
3. Long press the power button to start, it will start with Mode 1/Low intensity level by default.
4. Press “Mode Button” to switch to different massage mode.
There are 3 massage modes optional, see the difference in FAQS A2 session.
5. Press “Intensity Button” to adjust air pressure intensity, 3 levels available.
We suggest you start with low intensity for the first use, gradually increase after you
get used to it.
Note: The device will automatically shut off after 20 minutes operation, if you wanna enjoy more
or end the massage earlier, press the power button to turn it on / off.
1. Keep it out of the reach of children.
2. Don't dissemble the machine by yourself.
3. Don't place it in high temperature and humidity condition.
4. Don't place heavy stuff on it.
5. Do not make any sharp kinks in the wraps.
6. After use, put the wraps in original package.
7. Store the machine in a cool, well-ventilated place.
8. Do not expose the device to direct sunlight and protect it against dirt and moisture.
Cleaning
Storage
Make sure to cut off the power before you clean the machine.
1. If dirty, please wipe the controller and wraps with a soft cloth moistened by soap solution.
2. Don’t use gasoline, alcohol, diluent and other irritating liquid to wipe the machine in case
it causes malfunction or the components are damaged or discolored.
3. Not to clean the device during treatment, be sure that the device is turned off before cleaning.
4. Toothpicks can be used to remove the hair or chippings attached on the Velcros.
5. Do not hold the device under running water, do not submerge it in water or other liquids.
6. Ensure that no water penetrates into the machine. If this should ever happen, stop using until it’s
completely dry.
- 5 -
Please adhere to the local regulations when you dispose of the wasted
2 x Massager Wraps
1 x Charger/ DC5V 2A
1 x User Manual
1 x Quick-Start Guide
1 x Portable Storage Bag
•
•
•
•
•
Package includes
Send Email
Follow Us
@FitKingWellness
If you have any questions during using of this product, please feel free to contact us.
1. E-mail: service@ifitking.com
Note: Please tell us your order number along with the problems you meet in the email. Pictures or
videos are welcomed for faster and better service.
2. If you want to follow up our new products and latest promotional information, please visit our
official website or Facebook page.
@FitKingWellness
www.ifitking.com
- 6 -
service@ifitking.com
SHENZHEN FIT KING HEALTH TECH.CO.,LTD
501-C, Building 5, Baimenqian Industrial Zone,
Nanwan Street, Longgang District,
Shenzhen, China
www.ifitking.com
