Outdoor Parking Camera User Manual
i
control, selecng a suitable network environment (the Internet or Intranet) where video
products are connected, establishing and constantly opmizing network security.
●
Video products have made great contribuons to the improvement of social security around the
world, and we believe that these products will also play an
acve role in more aspects of social
life. Any abuse of video products in
violaon of human rights or leading to criminal acvies are
contrary to the original intent of technological
innovaon and product development. Therefore,
each user shall establish an evaluaon and tracking mechanism of their product applicaon to
ensure that every product is used in a proper and reasonable manner and with good faith.
Outdoor Parking Camera User Manual
ii
Legal Informaon
©2023 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in
supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Outdoor Parking Camera User Manual
iii
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Outdoor Parking Camera User Manual
iv
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Outdoor Parking Camera User Manual
v
Contents
Chapter 1 Introducon ............................................................................................................... 1
1.1 Introducon ........................................................................................................................... 1
1.2 Key Feature ............................................................................................................................ 1
Chapter 2 Acvaon and Login ................................................................................................... 2
2.1 Acvaon ............................................................................................................................... 2
2.1.1 Default Informaon ...................................................................................................... 2
2.1.2 Acvate via SADP .......................................................................................................... 2
2.1.3 Acvate via Web Browser ............................................................................................. 3
2.2 Login ...................................................................................................................................... 4
Chapter 3 Capture
Conguraon ................................................................................................ 5
3.1 Set Trigger Mode .................................................................................................................... 5
3.1.1 Set Parking Space Mode ............................................................................................... 5
3.1.2 Set Area Mode .............................................................................................................. 7
3.2 Set Capture Parameters ......................................................................................................... 8
3.2.1 Set License Plate
Recognion Parameters .................................................................... 8
3.2.2 Set Supplement Light Parameters ................................................................................. 8
3.2.3 Set Capture Overlay ...................................................................................................... 9
3.2.4 Set Image Encoding Parameters .................................................................................. 10
3.3 View Real-Time Picture ........................................................................................................ 10
Chapter 4 Live View and Local
Conguraon ............................................................................ 12
4.1 Live View .............................................................................................................................. 12
4.1.1 Start/Stop Live View .................................................................................................... 12
4.1.2 Select Image Display Mode ......................................................................................... 12
4.1.3 Select Window Division Mode .................................................................................... 12
4.1.4 Select Stream Type ...................................................................................................... 12
4.1.5 Capture Picture Manually ........................................................................................... 12
Outdoor Parking Camera User Manual
vi
4.1.6 Record Manually ......................................................................................................... 13
4.1.7 Enable Digital Zoom .................................................................................................... 13
4.1.8 Select Video Mode ...................................................................................................... 13
4.2 PTZ
Operaon ...................................................................................................................... 13
4.3 Local Conguraon .............................................................................................................. 15
Chapter 5 Storage ..................................................................................................................... 18
5.1 Set FTP ................................................................................................................................. 18
5.2 Set Listening Host ................................................................................................................. 19
5.3 Set Arm Host ........................................................................................................................ 20
5.4 Set ISAPI Listening ................................................................................................................ 20
5.5 Set Cloud Storage ................................................................................................................. 21
Chapter 6 Encoding and Display ................................................................................................ 23
6.1 Set Video Encoding Parameters ........................................................................................... 23
6.2 Set Image Parameters .......................................................................................................... 24
6.3 Set ROI ................................................................................................................................. 27
6.4 Enable Regional Exposure .................................................................................................... 28
6.5 Set OSD ................................................................................................................................ 28
Chapter 7 Network
Conguraon ............................................................................................. 30
7.1 Set IP Address ...................................................................................................................... 30
7.2 Connect to ISUP
Plaorm .................................................................................................... 32
7.3 Set DDNS .............................................................................................................................. 33
7.4 Set Port ................................................................................................................................ 34
Chapter 8 Serial Port
Conguraon ........................................................................................... 36
8.1 Set RS-485 ............................................................................................................................ 36
8.2 Set RS-232 ............................................................................................................................ 36
Chapter 9 Safety Management ................................................................................................. 38
9.1 Manage User ........................................................................................................................ 38
9.2 Enable User Lock .................................................................................................................. 38
Outdoor Parking Camera User Manual
vii
9.3 Set HTTPS ............................................................................................................................. 39
9.3.1 Create and Install Self-signed Cercate .................................................................... 39
9.3.2 Install Authorized
Cercate ....................................................................................... 39
9.4 Excepon Alarm ................................................................................................................... 40
9.5 Set SSH ................................................................................................................................. 40
9.6 Set RTSP Authencaon ...................................................................................................... 40
9.7 Set IP Address Filtering ........................................................................................................ 40
9.8 Set Timeout Logout .............................................................................................................. 41
9.9 Set Password Validity Period ................................................................................................ 41
Chapter 10 Maintenance .......................................................................................................... 42
10.1 View Device Informaon .................................................................................................... 42
10.2 Enable System Log Service ................................................................................................. 42
10.3 Search Log .......................................................................................................................... 42
10.4 Upgrade ............................................................................................................................. 43
10.5 Reboot ............................................................................................................................... 43
10.6 Restore Parameters ............................................................................................................ 43
10.7 Synchronize Time ............................................................................................................... 44
10.8 Debug Device ..................................................................................................................... 45
10.9 Set DST ............................................................................................................................... 45
10.10 Export Parameters ........................................................................................................... 45
10.11 Import
Conguraon File ................................................................................................. 45
10.12 Export Diagnosis Informaon .......................................................................................... 46
10.13 Export Debug File ............................................................................................................. 46
Outdoor Parking Camera User Manual
viii
Chapter 1 Introducon
1.1 Introducon
The outdoor parking camera (hereinaer referred to as "device") is applied in the parking guidance
system to detect the parking status and parking space status. Integrated with the camera and the
supplement light, the device can be widely applied in the outdoor parking lot, community
dedicated lane, 4S automove dealership, outdoor dedicated parking spaces, etc.
1.2 Key Feature
●
Supports parking space status detecon, parking space occupaon detecon, and parking over
line detecon.
●
Built-in HD camera provides high quality imaging.
●
Low
illuminaon enables clear imaging at night.
●
Built-in supplement light reduces
construcon and wiring costs.
●
Supports to connect peripheral alarm devices.
Outdoor Parking Camera User Manual
1
Chapter 2 Acvaon and Login
2.1 Acvaon
For the rst-me access, you need to acvate the device by seng an admin password. No
operaon is allowed before acvaon. The device supports mulple acvaon methods, such as
acvaon via SADP soware, web browser, and iVMS-4200 Client.
Note
Refer to the user manual of iVMS-4200 Client for the acvaon via client soware.
2.1.1 Default Informaon
Device default informaon are as follows.
●
Default IP address: 192.168.1.64
●
Default user name: admin
2.1.2
Acvate via SADP
SADP is a tool to detect, acvate, and modify the IP address of the devices over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website ( hps://
www.hikvision.com/ ), and install it according to the prompts.
●
The device and the computer that runs the SADP tool should belong to the same network
segment.
The following steps show how to
acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Enter a new password (admin password) and
conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click Acvate to start acvaon.
Outdoor Parking Camera User Manual
2
Figure 2-1 Acvate via SADP
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same network segment as your computer by either
modifying the IP address manually or checking Enable DHCP.
3) Enter the admin password and click Modify to
acvate your IP address modicaon.
2.1.3
Acvate via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP
soware or client soware to acvate the device.
Before You Start
Ensure the device and the computer connect to the same LAN.
Steps
1.
Change the IP address of your computer to the same network segment as the device.
2.
Open the web browser, and enter the default IP address of the device to enter the acvaon
interface.
3.
Create and conrm the admin password.
Outdoor Parking Camera User Manual
3
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click OK to complete acvaon.
5.
Go to the network sengs interface to modify IP address of the device.
2.2 Login
You can log in to the device via web browser for further operaons such as live view and local
conguraon.
Before You Start
Connect the device to the network directly, or via a switch or a router.
Steps
1.
Open the web browser, and enter the IP address of the device to enter the login interface.
2.
Enter User Name and Password.
3.
Click Login.
4.
Download and install appropriate plug-in for your web browser. Follow the
installaon prompts
to install the plug-in.
5.
Reopen the web browser
aer the installaon of the plug-in and repeat steps 1 to 3 to login.
6.
Oponal: Click Logout on the upper right corner of the interface to log out of the device.
Outdoor Parking Camera User Manual
4
Chapter 3 Capture Conguraon
3.1 Set Trigger Mode
Aer seng trigger mode, the device will capture pictures if the parking space status changes (a
vehicle enters or exits), and the informaon will be uploaded with the captured pictures as well.
3.1.1 Set Parking Space Mode
Set parking space mode to detect the parking space occupaon status.
Steps
1.
Go to Conguraon → Capture → Applicaon Mode → Trigger Mode .
Figure 3-1 Set Parking Space Mode
2.
Select Scene as Parking Space Mode.
3.
Draw parking spaces.
1) Click Draw LPR Area.
2) Click Mark Parking Space and drag the parking space frame to the middle of the parking
space.
Outdoor Parking Camera User Manual
5
Figure 3-2 Mark Parking Spaces
3) Click OK.
4)
Oponal: Repeat the above steps to mark parking spaces that you want to detect.
4.
Oponal: You can also do the following operaons.
Set Parking Space No.
Select Parking Space No. and enter the parking space tag.
Cancel All Delete all the set parking space frames.
Cancel One Delete the latest set parking space frame.
5.
Click Save.
Result
On the live view page, you can view the parking space status. If the parking space is available, the
parking space frame will be green. If the parking space is occupied, the parking space frame will be
red.
Outdoor Parking Camera User Manual
6
3.1.2 Set Area Mode
You can set detecon area in the outdoor parking lot, community dedicated lane, outdoor
dedicated parking spaces, and other scenes to detect the number of parked vehicles and parking
space status.
Steps
1.
Go to
Conguraon → Capture → Applicaon Mode → Trigger Mode .
Figure 3-3 Set Area Mode
2.
Select Scene as Area Mode.
3.
Select Outdoor Parking Detecon Area.
4.
Oponal: Check Parking over Line Detecon and set Sensivity.
Note
The higher the sensivity is, the more easily the parking over line will be detected. But if it is too
high, false detecon would occur. Please set the sensivity according to the actual needs.
If the vehicle is parked over line, the device will capture pictures, and the informaon of parking
over line will be uploaded with the captured pictures as well.
5.
Draw the
detecon area.
1) Click Draw LPR Area.
2) Select Area Type and adjust the
detecon area frame to match the actual detecon area.
3) Select Parking Space Type according to the actual scene.
Note
Click Redraw Area to delete the exisng area.
4) Click OK.
6.
Click Save.
Outdoor Parking Camera User Manual
7
3.2 Set Capture Parameters
3.2.1 Set License Plate Recognion Parameters
Select the belonged country/region of the license plates.
Steps
1.
Go to Conguraon → Device Conguraon → Capture Parameters → License Parameters .
Figure 3-4 Set License Plate Recognion Parameters
2.
Select Country/Region.
3.
Click Save.
3.2.2 Set Supplement Light Parameters
The supplement light can enhance the image stabilizaon and adjust the brightness and color
temperature. You can use the supplement light to supplement light at night or when the light is
dim.
Steps
Note
Only when the constant light is connected, can the set parameters take eect.
1.
Go to Conguraon → Capture → Capture Parameters → Supplement Light Parameters .
Figure 3-5 Set Supplement Light Parameters
2.
Select the I/O output mode as Constant Light Mode.
3.
Set the supplement light parameters according to actual
condions.
Enable Mode
Default
Outdoor Parking Camera User Manual
8
The usage of the supplement light is determined based on the license plate brightness in
the scene.
Time Schedule
In this mode, Begin Time and End Time need to be set. The device enables the
supplement light only during the set me range.
Environment Brightness
In this mode, Threshold needs to be set. When the brightness of the image reaches the
set threshold, the supplement light is enabled
automacally.
Constant Light Brightness
Set the brightness value according to actual needs.
4.
Click Save.
3.2.3 Set Capture Overlay
If you want to overlay informaon on the captured pictures, set capture overlay.
Steps
1.
Go to Conguraon → Capture → Capture Parameters → Text Overlay .
2.
Check Capture Picture Overlay.
Figure 3-6 Set Capture Overlay
3.
Set the capture overlay parameters.
Percentage
It is the percentage that the overlaid
informaon occupies on the picture.
4.
Select the overlay informaon from the list.
Note
The overlay informaon may vary with dierent models. The actual device prevails.
5.
Set the overlay informaon.
Type
You can edit the type.
Outdoor Parking Camera User Manual
9
Overlay Informaon For some informaon types, you can edit the detailed informaon.
Overlay Posion Check it, and the current informaon will be displayed on a new line.
Space Edit the number of spaces between the current informaon and the
next one from 0 to 255. 0 means there is no space.
Line Break
Characters
Edit the number of characters from 0 to 100 between the current
informaon line and the previous informaon line. 0 means no line
break.
/ Adjust the display sequence of the overlay informaon.
6.
Click Save.
3.2.4 Set Image Encoding Parameters
If the captured pictures are not clear, set the resoluon of the captured pictures and the picture
size.
Steps
1.
Go to Conguraon → Capture → Capture Parameters → Picture Encoding and Composion .
Figure 3-7 Set Image Encoding Parameters
2.
Select Capture Resoluon .
3.
Enter JPEG Picture Size.
4.
Click Save.
3.3 View Real-Time Picture
You can view the
real-me captured pictures and license plate informaon.
Steps
1.
Go to Live View → Real-Time Capture .
2.
Click Arming.
3.
Select an item from the list, and you can view the capture scene picture and recognized license
plate
informaon.
Outdoor Parking Camera User Manual
10
Figure 3-8 Real-Time Picture
4.
Oponal: You can also do the following operaons.
/
/
●
Level 1 Arming can only connect one client or web. The uploaded pictures will
not be stored in the storage card. The pictures in the storage card will be
uploaded to the level 1 arming.
●
Level 2 Arming can connect three clients or webs. The pictures will be
uploaded to the client/web, and stored in the storage card.
●
Disarming is to cancel the alarm status or real-me picture.
Click it to measure the license plate pixel. Click it again to disable the
measurement.
Click it to enable the ruler to measure the license plate.
Click it to enable manual capture.
Click it to set connuous capture parameters and the device will capture
pictures according to the set interval.
●
Capture Times: Up to ve pictures can be captured per connuous capture.
●
Interval: Up to four intervals can be set, and the default interval is 100 ms.
Display the images in full screen mode.
Open
Folder
Open the saving path of captured pictures.
Outdoor Parking Camera User Manual
11
Chapter 4 Live View and Local Conguraon
4.1 Live View
4.1.1 Start/Stop Live View
Click to start live view. Click to stop live view.
4.1.2 Select Image Display Mode
Click to select an image display mode.
4.1.3 Select Window Division Mode
Click to select a window division mode.
Note
For the dual-lens camera, you can select the 2 × 2 mode to show the images of both lens.
4.1.4 Select Stream Type
Click to select the stream type. It is recommended to select the main stream to get the high-
quality image when the network
condion is good, and select the sub-stream to get the uent
image when the network condion is not good enough. The third stream is the custom stream.
Note
The supported stream types vary with dierent models. The actual device prevails.
4.1.5 Capture Picture Manually
You can capture pictures manually on the live view image and save them to the computer.
Steps
1.
Click to capture a picture.
2.
Oponal: Click Conguraon → Local → Picture and Clip Sengs to view the saving path of
snapshots in live view.
Outdoor Parking Camera User Manual
12
4.1.6 Record Manually
You can record videos manually on the live view image and save them to the computer.
Steps
1.
Click to start live view.
2.
Click
to start recording.
3.
Click to stop recording.
4.
Oponal: Click Conguraon → Local → Record File Sengs to view the saving path of record
les.
4.1.7 Enable Digital Zoom
You can enable digital zoom to zoom in a certain part of the live view image.
Steps
1.
Click to start live view.
2.
Click to enable digital zoom.
3.
Place the cursor on the live view image posion which needs to be zoomed in. Drag the mouse
rightwards and downwards to draw an area.
The area will be zoomed in.
4.
Click any
posion of the image to restore to normal image.
5.
Click to disable digital zoom.
4.1.8 Select Video Mode
Set the video mode when adjusng the device focus during construcon.
Click and select when the device is running normally.
4.2 PTZ
Operaon
Click Live View. Click and click to show the PTZ control panel.
Note
●
The PTZ supports power-o memory. When the device is suddenly cut o power or restarted
normally, it can automacally return to the posion before the power cut or reboot.
●
The PTZ funcon varies with dierent models. The actual device prevails.
●
Other
unmenoned buons are reserved buons.
Outdoor Parking Camera User Manual
13
Figure 4-1 Control Panel
Table 4-1 Buon Descripon
Buon Descripon
Adjust the PTZ speed.
/ Zoom + and Zoom -
●
Hold to zoom in the scene.
●
Hold to zoom out the scene.
/ Focus + and Focus -
●
Hold under the manual focus mode to make near objects
become clear and distant objects become vague.
●
Hold
to make distant objects become clear and near
objects become vague.
/ Iris + and Iris –
●
Hold to increase the iris diameter when in a dark
environment.
●
Hold
to decrease the iris diameter when in a bright
environment.
Lens Inializaon
It is applicable to devices with motorized lenses. You can use this
funcon when overcoming image blurs caused by overme
zooming or focusing.
Auxiliary Focus
Outdoor Parking Camera User Manual
14
Buon Descripon
It is applicable to devices with motorized lenses. Use this
funcon to focus the lens automacally and make images
become clear.
4.3 Local Conguraon
Go to Conguraon → Local to set the live view parameters and change the saving paths of videos,
captured pictures, downloaded pictures, etc.
Figure 4-2 Local Conguraon
Protocol Type
Select the network transmission protocol according to the actual needs.
TCP
Outdoor Parking Camera User Manual
15
Ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected.
UDP
Provides real-me audio and video streams.
HTTP
Gets streams from the device by a third party client.
HTTPS
Gets streams in
hps format.
Stream Type
Main Stream
Select it to get the high-quality image when the network condion is good.
Sub-Stream
Select it to get the uent image when the network condion is not good enough.
Live View Performance
Shortest Delay
The video is real-me, but its uency may be aected.
Balanced
Balanced mode considers both the real me and uency of the video.
Fluency
When the network condion is good, the video is uent.
Decoding Type
Soware Decoding
Decode via
soware. It takes up more CPU resources but provides images with beer quality
when it compares to the hardware decoding.
Hardware Decoding
Decode via GPU. It takes up less CPU resources but provides images with worse quality when
it compares to the
soware decoding.
Rules Informaon
If you enable the rule informaon, tracking frames will be displayed on the live view interface
when there are vehicles passing.
Feature Informaon
Enable it to display feature informaon of the target in the live view image.
Image Size
The display rao of live view.
Image Format
Outdoor Parking Camera User Manual
16
The saving format of manually captured images.
Record File Size
Select the packed size of the manually recorded video les. Aer the selecon, the max. record
le size is the value you selected.
Save record
les to
Set the saving path for the manually recorded video les.
Save downloaded les to
Set the saving path for the download les.
Save snapshots in live view to
Set the saving path for the manually captured pictures in live view mode.
Save downloaded pictures to
Set the saving path for the downloaded pictures.
Save scene picture to
Set the saving path of the captured pictures in Live View → Real-Time Capture .
Save snapshots when playback to
Set the saving path for the manually captured pictures in playback mode.
Save clips when playback to
Set the saving path for the clips in playback.
Outdoor Parking Camera User Manual
17
Chapter 5 Storage
5.1 Set FTP
Set FTP parameters if you want to upload the captured pictures to the FTP server.
Before You Start
Set the FTP server, and ensure the device can communicate normally with the server.
Steps
Note
The supported parameters vary with the device model. The actual device prevails.
1.
Go to Conguraon → Network → Data Connecon → FTP .
Figure 5-1 Set FTP
2.
Check Enable FTP.
3.
Select Number of Enabled FTP.
Note
You can only enable one FTP.
4.
Set FTP Parameters.
1) Select Sever Address Type and enter corresponding
informaon.
2) Enter Port.
3) Enter User Name, Password, and
conrm the password.
4) Select Protocol Type.
5) Select Directory Structure.
Note
You can customize the directory structure according to your needs.
5.
Select Path/Picture Name Encoding Mode.
Outdoor Parking Camera User Manual
18
GB2312
Chinese characters encoding.
UTF-8
UNICODE encoding.
6.
Oponal: Enable upload funcons.
Not Upload Plate Close-up
The close-up pictures of a license plate will not be uploaded.
Upload
Addional Informaon to FTP
Add related informaon when uploading data to the FTP server.
7.
Oponal: Click FTP Test to check the FTP server.
8.
Set naming rules and separators according to the actual needs.
9.
Oponal: Edit OSD informaon which can be uploaded to the FTP server with the pictures to
make it convenient to view and
disnguish the data.
10.
Click Save.
5.2 Set Listening Host
The SDK listening can be used to receive the uploaded informaon and pictures of the device
arming alarm.
Before You Start
The listening service has been enabled for the SDK listening, and the network communicaon with
the device is normal.
Steps
1.
Go to
Conguraon → Network → Data Connecon → SDK Listening .
Figure 5-2 Set SDK Listening
2.
Set IP Address/Domain and Port if you need to upload the alarm informaon and pictures.
3.
Oponal: Enable the picture uploading listening if you need to upload image informaon.
Outdoor Parking Camera User Manual
19
4.
Oponal: If you want to save the alarm informaon and pictures to the cloud storage, click to
set Cloud Storage. Refer to Set Cloud Storage for details.
5.
Click Save.
5.3 Set Arm Host
The device can upload the captured pictures via the arm host.
Steps
Note
For level 1 arm, the pictures can be uploaded normally. If uploading failed, the device will upload
again. For level 2 arm, the pictures will be uploaded once. No more upload if uploading failed. For
level 3 arm, pictures will not be uploaded.
1.
Go to Conguraon → Network → Data Connecon → Arm Upload .
Figure 5-3 Set Arm Host
2.
Click to set Cloud Storage. Refer to Set Cloud Storage for details.
3.
Click Save.
5.4 Set ISAPI Listening
ISAPI listening and SDK listening are mutually exclusive protocols. If you enable the picture
uploading listening, the device will transmit images via the SDK listening. If not, the device will
upload images via ISAPI protocol
aer the ISAPI parameters are set.
Before You Start
The listening service has been enabled for the ISAPI host, and the network communicaon with
the device is normal.
Steps
1.
Go to
Conguraon → Network → Data Connecon → ISAPI Listening .
Outdoor Parking Camera User Manual
20
Figure 5-4 Set ISAPI Listening
2.
Set ANPR IP/Domain, ANPR Port, and Host URL.
3.
Oponal: If you want to save the alarm informaon and pictures to the cloud storage, click to
set Cloud Storage. Refer to
Set Cloud Storage for details.
4.
Click Save.
5.5 Set Cloud Storage
Cloud storage is a kind of network storage. It can be used as the extended storage to save the
captured pictures.
Before You Start
●
Arrange the cloud storage server.
●
You have enabled level 1 arm in Live View → Live
Trac Stascs .
Steps
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
Outdoor Parking Camera User Manual
21
Figure 5-5 Set Cloud Storage
2.
Check Enable.
3.
Select Version.
V1.0
a. Enter IP Address and Port
b. Enter User Name and Password.
c. Enter Cloud Storage ID and Violaon Cloud Storage ID according to the server
storage area No.
V2.0 a. Enter IP Address and Port
b. Enter accessKey and secretKey.
c. Enter Resource Pool ID according to the server storage area No. of uploading
pictures.
4.
Click Save.
Outdoor Parking Camera User Manual
22
Chapter 6 Encoding and Display
6.1 Set Video Encoding Parameters
Set video encoding parameters to adjust the live view and recording eect.
●
When the network signal is good and the speed is fast, you can set high resoluon and bitrate to
raise the image quality.
●
When the network signal is bad and the speed is slow, you can set low resoluon, bitrate, and
frame rate to guarantee the image uency.
●
When the network signal is bad, but the resoluon should be guaranteed, you can set low
bitrate and frame rate to guarantee the image uency.
●
Main stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission. Sub-stream
usually
oers comparavely low resoluon opons, which consumes less bandwidth and storage
space. Third stream is oered for customized usage.
Steps
Note
The supported parameters vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Video → Video Encoding → Video Encoding .
2.
Set the parameters for dierent streams.
Stream Type
Select the stream type according to your needs.
Note
The supported stream types vary with dierent models. The actual device prevails.
Bitrate
Select relavely large bitrate if you need good image quality and eect, but more storage
spaces will be consumed. Select
relavely small bitrate if storage requirement is in priority.
Frame Rate
It is to describe the frequency at which the video stream is updated and it is measured by
frames per second (fps). A higher frame rate is advantageous when there is movement in the
video stream, as it maintains image quality throughout.
Resoluon
The higher the resoluon is, the clearer the image will be. Meanwhile, the network
bandwidth requirement is higher.
Outdoor Parking Camera User Manual
23
SVC
Scalable Video Coding (SVC) is an extension of the H.264/AVC and H.265 standard. Enable the
funcon and the device will automacally extract frames from the original video when the
network bandwidth is insucient.
Bitrate Type
Select the bitrate type to constant or variable.
Video Quality
When bitrate type is variable, 6 levels of video quality are selectable. The higher the video
quality is, the higher requirements of the network bandwidth.
Prole
When you select H.264 or H.265 as video encoding, you can set the prole. Selectable
proles vary according to device models.
I Frame Interval
It refers to the number of frames between two key frames. The larger the I frame interval is,
the smaller the stream uctuaon is, but the image quality is not that good.
Video Encoding
The device supports mulple video encoding types, such as H.264, H.265, and MJPEG.
Supported encoding types for
dierent stream types may dier. H.265 is a new encoding
technology. Compared with H.264, it reduces the transmission bitrate under the same
resoluon, frame rate, and image quality.
3.
Click Save.
6.2 Set Image Parameters
You can adjust the image parameters to get clearer images.
Steps
Note
The supported parameters may vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Video → Camera Parameter → Camera Parameter .
Outdoor Parking Camera User Manual
24
Figure 6-1 Set General Parameter
2.
Set the parameters.
General Parameter
Saturaon
It refers to the colorfulness of the image color.
Sharpness
It refers to the edge contrast of the image.
White Balance
It is the white
rendion funcon of the device used to adjust the color temperature
according to the environment.
WDR Mode
Wide Dynamic Range (WDR) can be used when there is a high contrast of the bright area
and the dark area of the scene.
In this mode, select WDR Switch and set corresponding parameters according to your
needs.
On
Set WDR Level. The higher the level is, the higher the WDR strength is.
Time
Enable WDR according to the
me.
Brightness
Set Light Threshold. When the brightness reaches the threshold, WDR will be enabled.
Iris Mode
Only manual iris mode is supported.
Brightness Enhancement at Night
Outdoor Parking Camera User Manual
25
The scene brightness will be enhanced at night automacally.
Enable Defog
Enable defog to get a clear image in foggy days.
Enable Gamma Correcon
The higher the gamma correcon value is, the stronger the correcon strength is.
Video
Brightness
It refers to the max. brightness of the image.
Contrast
It refers to the contrast of the image. Set it to adjust the levels and permeability of the
image.
Shuer
If the shuer speed is quick, the details of the moving objects can be displayed beer. If
the shuer speed is slow, the outline of the moving objects will be fuzzy and trailing will
appear.
Gain
It refers to the upper limit value of liming image signal amplicaon. It is recommended
to set a high gain if the
illuminaon is not enough, and set a low gain if the illuminaon is
enough.
Hue Range
Select the range to adapt to the display.
3D DNR
Digital Noise Reducon (DNR) reduces the noise in the video stream.
In Normal Mode, the higher the 3D DNR Level is, the stronger the noise will be reduced.
But if it is too high, the image may become fuzzy.
In Expert Mode, set
Spaal Intensity and Time Intensity. If the special intensity is too
high, the outline of the image may become fuzzy and the details may lose. If the me
intensity is too high, trailing may appear.
2D DNR
The higher the 2D DNR Level is, the stronger the noise will be reduced. But if it is too high,
the image may become fuzzy.
Video Standard
Select the video standard according to the actual power supply frequency.
Outdoor Parking Camera User Manual
26
6.3 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resources to the region of
interest, thus to increase the quality of the ROI whereas the background informaon is less
focused.
Before You Start
Please check the video encoding type. ROI is supported when the video encoding type is H.264 or
H.265.
Steps
1.
Go to
Conguraon → Video → Video Encoding → ROI .
Figure 6-2 Set ROI
2.
Select Stream Type.
3.
Set ROI region.
1) Check Enable.
2) Select Area Code.
3) Click Draw Area.
4) Drag the mouse on the live view image to draw a
xed area.
5) Select the xed area that needs to be adjusted and drag the mouse to adjust its posion.
4.
Select ROI Level and enter Area Name.
Note
The higher the ROI level is, the clearer the image of the detected area is.
5.
Click Save.
6.
Oponal: Select other area codes and repeat the steps above if you need to draw mulple xed
areas.
Outdoor Parking Camera User Manual
27
6.4 Enable Regional Exposure
Enable regional exposure to expose paral area of the live view image.
Steps
1.
Go to
Conguraon → Video → Video Encoding → Regional Exposure .
2.
Check Enable.
3.
Drag the cursor to draw an area.
The drawn area will be exposed.
Figure 6-3 Enable Regional Exposure
4.
Click Save.
6.5 Set OSD
You can customize OSD informaon on the live view.
Steps
1.
Go to Conguraon → Video → Text Overlay on Video → Text Overlay on Video .
Note
The supported funcons vary with dierent models. The actual device prevails.
Outdoor Parking Camera User Manual
28
Figure 6-4 Set OSD
2.
Oponal: Select a channel.
3.
Set display contents.
1) Check Display Name.
2) Enter Display Name.
3) Check Display Date, and set the
me and date format.
4) Enable Display Week or Millisecond according to your needs.
4.
Oponal: Click Add and enter informaon if you want to add custom informaon.
Note
Up to 6 items of custom informaon can be added.
5.
Set display properes (font, color, etc.).
6.
Select Alignment.
Note
If you select Align Le or Align Right, set Min. Horizontal Margin and Min. Vercal Margin.
7.
Drag the red frames on the live view image to adjust their posions.
8.
Click Save.
Result
The set OSD will be displayed in live view image and recorded videos.
Outdoor Parking Camera User Manual
29
Chapter 7 Network Conguraon
7.1 Set IP Address
IP address must be properly congured before you operate the device over network. IPv4 and IPv6
are both supported. Both versions can be congured simultaneously without conicng to each
other.
Go to Conguraon → Network → Network Parameters → Network Interface .
Figure 7-1 Set IP Address
Outdoor Parking Camera User Manual
30
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two modes are available.
DHCP
The device
automacally gets the IP parameters from the network if you check DHCP. The
device IP address is changed
aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IP parameters manually. Enter IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway.
IPv6
Three IPv6 modes are available.
Route
Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Enter IPv6 Address, IPv6 Subnet Mask, and IPv6 Gateway. Consult the network administrator
for required
informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
Mulcast Address
Mulcast is group communicaon where data transmission is addressed to a group of
desnaon devices simultaneously. Aer seng the IP address of the mulcast host, you can
send the source data eciently to mulple receivers.
Outdoor Parking Camera User Manual
31
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some
applicaons (e.g., sending email). Set Preferred DNS
Address properly if needed.
7.2 Connect to ISUP Plaorm
ISUP (EHome) is a plaorm access protocol. The device can be remotely accessed via this plaorm.
Before You Start
●
Create the device ID on ISUP
plaorm.
●
Ensure the device can communicate with the plaorm normally.
Steps
1.
Go to Conguraon → Network → Data Connecon → ISUP .
Figure 7-2 Connect to ISUP Plaorm
2.
Check Enable.
3.
Select Protocol Version.
4.
Select Address Type.
5.
Enter Sever IP Address, Server Port, and Device ID.
Note
You need to enter Key if you select Protocol Version as v5.0.
6.
Click Save.
7.
Oponal: View Register Status.
Outdoor Parking Camera User Manual
32
What to do next
When the registraon status shows online, you can add or manage the device via the plaorm
soware. Refer to its corresponding manual for details.
7.3 Set DDNS
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
●
Register the domain name on the DDNS server.
●
Set the LAN IP address, subnet mask, gateway, and DNS server parameters. Refer to for details.
●
Complete port mapping. The default ports are 80, 8000, and 554.
Steps
1.
Go to
Conguraon → Network → Network Parameters → DDNS .
Figure 7-3 Set DDNS
2.
Check Enable DDNS.
3.
Enter the server address and other
informaon.
4.
Click Save.
5.
Access the device.
By Browsers
Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client soware
manual for specic adding methods.
Outdoor Parking Camera User Manual
33
7.4 Set Port
The device port can be modied when the device cannot access the network due to port conicts.
Go to Conguraon → Network → Network Parameters → Port for port sengs.
Figure 7-4 Set Port
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
HTTPS Port
Set the HTTPS for accessing the browser. Cercate is required when accessing.
RTSP Port
It refers to the port of real-me streaming protocol.
Server Port
It refers to the port through which the client adds the device.
SADP Port
It refers to the port through which the SADP soware searches the device.
Outdoor Parking Camera User Manual
34
Note
●
Aer eding the port, access to the device via new port.
●
Reboot the device to take the new sengs into eect.
●
The supported ports vary with dierent models. The actual device prevails.
Outdoor Parking Camera User Manual
35
Chapter 8 Serial Port Conguraon
8.1 Set RS-485
Set RS-485 parameters if the device needs to be connected to other peripheral devices controlled
by RS-485 serial port.
Before You Start
The corresponding device has been connected via the RS-485 serial port.
Steps
Note
The number of available RS-485 serial port varies with dierent models.
1.
Go to Conguraon → System → System Sengs → Serial Port → RS-485 .
Figure 8-1 Set RS-485
2.
Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
3.
Set Work Mode.
Applicaon Trigger
Select it when the signal trigger devices (such as radar) are connected to the RS-485 serial
port of the device.
Transparent Channel
Select it when the other peripheral devices are connected to the RS-485 serial port of the
device for
communicaon transmission.
4.
Click Save.
8.2 Set RS-232
Set RS-232 parameters if you need to debug the device via RS-232 serial port.
Before You Start
The debugging device has been connected via the RS-232 serial port.
Outdoor Parking Camera User Manual
36
Steps
1.
Go to Conguraon → System → System Sengs → Serial Port → RS-232 .
Figure 8-2 Set RS-232
2.
Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
3.
Select Work Mode.
Console
Select it when you need to debug the device via RS-232 serial port.
Transparent Channel
Select it, and the network command can be transmied to RS-232 control command via the
RS-232 serial port.
Narrow Bandwidth Transmission
Reserved.
4.
Click Save.
Outdoor Parking Camera User Manual
37
Chapter 9 Safety Management
9.1 Manage User
The administrator can add, modify, or delete other accounts, and grant dierent permissions to
dierent user levels.
Steps
1.
Go to Conguraon → System → User Management → User List .
2.
Select Password Level.
The password level of the added user should conform to the selected level.
3.
Add a user.
1) Click Add.
2) Enter User Name and select Type.
3) Enter Admin Password, New Password, and
conrm the password.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is
used in high-risk environment, it is recommended that the password should be changed every
month or week.
4) Assign remote permission to users based on needs.
User
Users can be assigned permission of viewing live video and changing their own passwords,
but no permission for other
operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
5) Click OK.
4.
Oponal: You can do the following operaons.
Change the password and permission
Click to change the password and permission.
Delete the user Click to delete the user.
9.2 Enable User Lock
To raise the data security, you are recommended to lock the current IP address.
Steps
1.
Go to Conguraon → System → Security → Security Service → Soware .
2.
Enable the user lock
funcon.
Outdoor Parking Camera User Manual
38
3.
Click Save.
Result
When the
mes you entered incorrect passwords have reached the limit, the current IP address
will be locked
automacally.
9.3 Set HTTPS
9.3.1 Create and Install Self-signed Cercate
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1.
Go to
Conguraon → Network → Network Parameters → HTTPS .
2.
Select Create Self-signed Cercate.
3.
Click Create.
4.
Follow the prompt to enter Country/Region, Domain/IP, Validity, and other parameters.
5.
Click OK.
Result
The device will install the self-signed cercate by default.
9.3.2 Install Authorized
Cercate
If the demand for external access security is high, you can create and install authorized cercate
via HTTPS protocol to ensure the data transmission security.
Steps
1.
Go to Conguraon → Network → Network Parameters → HTTPS .
2.
Select Create
cercate request rst and connue the installaon.
3.
Click Create.
4.
Follow the prompt to enter Country/Region, Domain/IP, Validity, and other parameters.
5.
Click Download to download the
cercate request and submit it to the trusted authority for
signature.
6.
Import
cercate to the device.
-
Select Signed
cercate is available, start the installaon directly. Click Browse and Install to
import the
cercate to the device.
-
Select Create the
cercate request rst and connue the installaon. Click Browse and
Install to import the
cercate to the device.
7.
Click Save.
Outdoor Parking Camera User Manual
39
9.4 Excepon Alarm
Set excepon alarm when the network is disconnected, the IP address is conicted, etc.
Steps
Note
The supported excepon types vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Event → Alarm Linkage → Excepon Event .
2.
Select the excepon type(s) and the linkage method.
3.
Click Save.
9.5 Set SSH
To raise network security, disable SSH service. The conguraon is only used to debug the device
for the professionals.
Steps
1.
Go to
Conguraon → System → Security → Security Service → Soware .
2.
Disable SSH Service.
3.
Click Save.
9.6 Set RTSP
Authencaon
You can improve network access security by seng RTSP authencaon.
Steps
1.
Go to Conguraon → System → Security → Security Sengs .
2.
Select RTSP Authencaon.
digest
The device only supports digest
authencaon.
digest/basic
The device supports digest or basic authencaon.
3.
Click Save.
9.7 Set IP Address Filtering
You can set the IP addresses allowable and not allowable to access the device.
Steps
1.
Go to
Conguraon → System → Security → Security Sengs .
Outdoor Parking Camera User Manual
40
2.
Check Enable IP Address Filtering.
3.
Set Filtering Mode.
Blocklist Mode
The added IP addresses are not allowed to access the device.
Allowlist Mode
The added IP addresses are allowed to access the device.
4.
Click Add, enter the IP address, and click OK.
Note
The IP address only refers to the IPv4 address.
5.
Oponal: Edit, delete, or clear the added IP addresses.
6.
Click Save.
9.8 Set Timeout Logout
You can improve network access security by seng meout logout.
Steps
1.
Go to
Conguraon → System → Security → Security Service → Timeout Logout .
2.
Enable meout logout for stac page.
3.
Set Max. Timeout.
4.
Click Save.
Result
When the page
stac me exceeds the set me, the device will automacally log out.
9.9 Set Password Validity Period
You can improve network access security by seng password validity period.
Steps
1.
Go to Conguraon → System → Security → Security Service → Password Validity Period .
2.
Select Validity Type.
-
Select Permanent. The password will be permanently valid.
-
Select Daily and set Password Expiry Time. It will prompt you that the password is expired
according to the set password expiry
me, and you need to set the new password.
3.
Click Save.
Outdoor Parking Camera User Manual
41
Chapter 10 Maintenance
10.1 View Device Informaon
Basic Informaon and Algorithms Library Version
Go to Conguraon → System → System Sengs → Basic Informaon to view the basic
informaon and algorithms library version of the device.
You can edit Device Name and Device No. The device No. is used to control the device. It is
recommended to reserve the default value.
Device Status
Go to Conguraon → System → System Sengs → Device Status to view the device status and
live view and arming status.
10.2 Enable System Log Service
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you are recommended to save the logs on a log
server.
Steps
1.
Go to
Conguraon → System → Security → Security Service → Log Audit Service .
2.
Enable system log service.
3.
Enter IP Address and Port of the log server.
4.
Click Save.
Result
The device will upload the security audit logs to the log server regularly.
10.3 Search Log
Log helps to locate and troubleshoot problems.
Steps
1.
Go to Conguraon → System → Maintenance → Log Search .
2.
Set search condions.
3.
Click Search.
The matched log les will be displayed on the log list.
Outdoor Parking Camera User Manual
42
4.
Oponal: Click Export to save the log les to your computer.
10.4 Upgrade
Upgrade the system when you need to update the device version.
Before You Start
Prepare the upgrade le. If the upgrade le is a compressed package, it needs to be decompressed
into the .dav format.
Steps
1.
Go to
Conguraon → System → Maintenance → Upgrade & Maintenance → Upgrade .
2.
Click Browse to select the upgrade le.
3.
Click Upgrade.
4.
Click OK in the popup window.
Note
The upgrade process will take 1 to 10 minutes. Do not cut o the power supply.
Result
The device will reboot automacally aer upgrade.
10.5 Reboot
When the device needs to be rebooted, reboot it via the soware instead of cung o the power
directly.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance → Device
Maintenance .
2.
Click Reboot.
3.
Click OK to reboot the device.
Note
You can also click Reboot on the upper right corner of the page to reboot the device.
10.6 Restore Parameters
When the device is abnormal caused by the incorrect set parameters, you can restore the
parameters.
Outdoor Parking Camera User Manual
43
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance → Device
Maintenance .
2.
Select the
restoraon mode.
-
Click Restore, and click OK. Then the parameters except the IP parameters and user
parameters will be restored to the default sengs.
-
Click Restore Factory Sengs and click OK to restore all the parameters to the factory
sengs.
10.7 Synchronize Time
Synchronize the device
me when it is inconsistent with the actual me.
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Select Sync Mode.
NTP
Synchronizaon
Select it to synchronize the device me with that of the NTP server. Set Server IP, NTP Port,
and Interval. Click NTP Test to test if the
connecon between the device and the server is
normal.
Manual Synchronizaon
Select it to synchronize the device me with that of the computer. Set me manually, or
check Sync. with computer
me.
SDK
If the remote host has been set for the device, select it to synchronize me via the remote
host.
ONVIF
Select it to synchronize me via the third-party device.
No
Select it to disable me synchronizaon.
All
Select it, and you can select any mode above.
Note
The me synchronizaon modes vary with dierent models. The actual device prevails.
4.
Click Save.
Outdoor Parking Camera User Manual
44
10.8 Debug Device
You can enable the funcon to debug the device.
Steps
1.
Go to
Conguraon → Capture → Advanced → System Service .
2.
Check the debug informaon according to your needs.
Enable Algorithm POS
Informaon Debug
The algorithm POS informaon will be overlaid on the image.
3.
Click Save.
10.9 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to
Conguraon → System → System Sengs → DST .
2.
Check Enable DST.
3.
Set Start Time, End Time, and DST Bias.
4.
Click Save.
10.10 Export Parameters
You can export the parameters of one device, and import them to another device to set the two
devices with the same parameters.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance → Data Export .
2.
Click Export
aer Conguring Parameters.
3.
Set an encrypon password, conrm the password, and click OK.
Note
The password is used for imporng the conguraon le of the current device to other devices.
4.
Select the saving path, and enter the le name.
5.
Click Save.
10.11 Import
Conguraon File
Import the conguraon le of another device to the current device to set the same parameters.
Outdoor Parking Camera User Manual
45
Before You Start
Save the conguraon le to the computer.
Steps
Cauon
Imporng conguraon le is only available to the devices of the same model and same version.
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance → Advanced
Sengs → Data Import .
2.
Select Imporng Method.
Note
If you select Import Part, check the parameters to be imported.
3.
Click Browse to select the conguraon le.
4.
Click Import.
5.
Enter the password which is set when the conguraon le is exported, and click OK.
6.
Click OK on the popup window.
Result
The parameters will be imported, and the device will reboot.
10.12 Export Diagnosis
Informaon
The technicians can export the diagnosis informaon to troubleshoot and maintain the device.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance → Data Export .
2.
Click Export aer Diagnosis Informaon.
3.
Select the saving path, and enter the
le name.
4.
Click Save.
10.13 Export Debug File
The technicians can export the debug le to troubleshoot and maintain the device.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance → Data Export .
2.
Click Export
aer Debug File.
3.
Select the saving path, and enter the le name.
4.
Click Save.
Outdoor Parking Camera User Manual
46
UD29198B
