Installation Guide
Gigabit Desktop PoE+ Switch
© 2023 TP-Link 7106510517 REV1.0.1
Switches Explanation
O: Ports run at 10/100/1000 Mbps and support PoE power supply up to 100 m away.
On: Ports run at 10 Mbps and support PoE power supply up to 250 m away.
Extend (For LS105GP/LS108GP/LS1210GP)
Connection
Note: For simplicity, we will take LS1210GP for example throughout the Guide.
PC
Router
LAN Port WAN Port
Internet
DC Power Adapter
AC Power Cord
Note:
PoE ports can also connect to non-PoE devices, but only transmit data.
LS1210GP has two uplink ports, which typically connect to uplink devices like routers.
The SFP slot of LS1210GP needs to work with a gigabit SFP module.
O: The PoE Auto Recovery function is disabled.
On: The switch will constantly detect the working status of a PoE powered device (PD).
When the switch nds that the PD works abnormally, the switch will reboot it.
Recovery (For LS105GP/LS108GP/LS1210GP)
Note: The numbers in brackets indicate the ports where the feature takes eect. For example, when Extend (Port 1-4) is toggled to On, the Extend mode will be enabled for ports 1-4.
O: Ports can transmit data with each other.
On: Specic ports cannot transmit data with other downlink ports. They can transmit data
only with the uplink ports.
Isolation (For LS1210GP)
PoE Ports (1-8)
IP Camera AP IP Phone
PoE Devices
1.
2.
3.
LS105GP/LS108GP/LS1210GP
LS1210GP
LED Explanation
PoE Status
On: Providing PoE power
Flashing: Current-overload/Short-circuit
O: Not providing PoE power
Power
On: Power on
O: Power o
Link/Act; Uplink 1, Uplink 2
On:
Running at 10/100/1000 Mbps, but no activity.
Flashing:
Running at 10/100/1000 Mbps and is
transmitting or receiving data.
O:
No device is linked to the corresponding port.
PoE Max
For LS105GP:
On: 58 W≤Total power supply < 65 W
Flashing: Total power supply ≥ 65 W
O: Total power supply < 58 W
For LS108GP:
On: 55 W≤Total power supply < 62 W
Flashing: Total power supply ≥ 62 W
O: Total power supply < 55 W
For LS1210GP:
On: 54 W≤Total power supply < 61 W
Flashing: Total power supply ≥ 61 W
O: Total power supply < 54 W
