Axis HDTV and megapixel network cameras
See what you’ve been missing.
HDTV and megapixel network cameras
HDTV and megapixel network cameras have an important role to play in video surveillance
applications. They can provide images that are more useful, with more image detail and with
wider scene coverage than standard resolution cameras. Depending on your requirements,
Axis network cameras can bring the advantages of HDTV, megapixel and network technology
to your surveillance application.
What do you need to see?
General overview
In a shopping mall, for instance, the primary goal of a
camera installation may be to watch for the presence
of people and view their movements — not the identi-
cation of individuals. For this kind of overview appli-
cation, sucient resolution and coverage of a scene
may be achieved with either a number of non-mega-
pixel network cameras or a single HDTV or megapixel
network camera.
High detail
These are the really demanding situations where you
need to be able to identify persons or objects in a
scene. This could be point-of-sales monitoring where it
is necessary to clearly see every item a customer is
purchasing. Using an HDTV or a megapixel network
camera will provide higher resolution images with
more details than a non-megapixel network camera.
This higher resolution enables the operator to choose
either to zoom in or to maintain a wider eld of view
without compromising the ability to see and discover
ne details in the image. Furthermore, the full frame
rate provided by an HDTV network camera creates a
rich viewing experience also when following moving
objects or capturing activity in a scene.
The variation of requirements within video surveillance is enormous. The most fundamental question, however, is
generally a choice between two dierent priorities:
With an HDTV or a megapixel net-
work camera, the resolution is at
least three times better than an
analog CCTV camera. It boils down
to a simple truth: HDTV and mega-
pixel means higher resolution.
Higher resolution means more de-
tail. More detail means better pos-
sibilities for identication. In addi-
tion, a true HDTV network camera
provides full frame rate and ex-
tended color delity, for an even
better viewing experience.
When every detail matters
HDTV/Megapixel network camera resolution
Analog camera resolution
HDTV/Megapixel network cameras
can cover larger scenes than analog
cameras at a given number of pixels
per area. For example, if four ana-
log cameras provide a good cover-
age of your monitored scene, one
2.0 megapixel network camera will
cover an even larger area, with no
loss of image resolution.
Same number of cameras - more coverage
HDTV/Megapixel network camera view
Analog camera view
Conventional TV monitors display
images with an aspect ratio of 4:3
only. HDTV/Megapixel network cam-
eras oer the same aspect ratio, as
well as a variety of others. A much
preferred ratio is 16:9, which is also
the one specied in HDTV standards,
because it includes important details
that are omitted from the left and
right sides of a conventional sized
image.
Dierent aspect ratios for more
ecient surveillance
Analog camera view
Analog camera view Analog camera view
4:3 ratio
16:9 ratio
AXIS M1054
Small and smart HDTV camera.
AXIS M1054 oers 1 megapixel or HDTV 720p
resolution. Smart functions such as a PIR sen-
sor, illumination LED, I/O ports and two-way
audio with built-in microphone and speaker
make it ideal for residences and small busi-
ness.
Complete HDTV and megapixel portfolio
Axis has a comprehensive portfolio of HDTV and megapixel network
cameras that deliver crisp and clear video images, perfect for the iden-
tication of objects and persons. Axis HDTV network cameras comply
with key parts of the SMPTE HDTV standard, delivering excellent image
quality. Our complete range includes indoor and outdoor-ready, xed,
pan/tilt/zoom, dome and thermal network cameras. In addition to high
image quality, Axis network cameras oer easy installation features,
intelligent video functionalities and reliable operation in a wide range of
environments. In short, they give you the exibility to design and imple-
ment an eective video surveillance system. All of the following models
support H.264 video compression.
AXIS M1104
AXIS M1114
Compact and affordable HDTV
cameras.
AXIS M1104 with CS-mount, xed iris and
AXIS M1114 with CS-mount, varifocal and
DC-iris lens provide 1 megapixel or HDTV
720p resolution. Both models are suitable
for a wide range of indoor surveillance ap-
plications.
AXIS P1347/-E
Exceptional surveillance with
5-megapixel cameras.
The indoor AXIS P1347 and outdoor-ready
AXIS P1347-E are 5-megapixel xed network
cameras that also support HDTV 1080p full
frame rate video. They are ideal for any ap-
plication that requires coverage of a large
area or extremely high image detail for iden-
tifying people and objects.
AXIS M3014
Ultra discreet, recessed-mount.
AXIS M3014 is a 1 megapixel network camera
with progressive scan. It is designed for easy
installation in recessed ceilings.
AXIS P3344/-V/-VE
HDTV with remote focus and zoom.
AXIS P3344 oers 1 megapixel or HDTV 720p
with day and night functionality, remote zoom
and remote focus. AXIS P3344-V has a van-
dal-resistant casing, whereas AXIS P3344-VE
is also adapted for harsh outdoor environ-
ment.
AXIS P3304/-V
Discreet HDTV video surveillance.
AXIS P3304/-V provide 1 megapixel or HDTV
720p resolution. They oer two-way audio,
I/O ports, pixel counter and digital PTZ.
AXIS P3304-V is also vandal-resistant.
AXIS P1344/-E
AXIS P1346/-E
Superb HDTV quality.
The indoor AXIS P1344 and outdoor-ready
AXIS P1344-E deliver superb HDTV 720p video
in all lighting conditions. AXIS P1346/-E cam-
eras feature P-Iris control and provide HDTV
1080p or 3-megapixel resolution. The cameras
oer the remote back focus functionality and
are ideal for professional video applications.
AXIS Q1755/-E
HDTV camera with zoom.
The indoor AXIS Q1755 and the outdoor-
ready AXIS Q1755-E deliver HDTV 1080i or
720p resolution and enable 10x optical zoom
with autofocus. They are designed for secur-
ing areas where high-quality identication is
needed.
AXIS M3114-R
Compact, rugged HDTV camera.
AXIS M3114-R provides rich, full frame rate 1
megapixel or HDTV 720p video. It is designed
for use in onboard surveillance solutions
such as buses, trains and emergency vehicles.
AXIS M3204/-V
Discreet and affordable HDTV
fixed dome.
AXIS M3204/-V provide 1 megapixel or HDTV
720p resolution. The discreet, cost-eective
xed domes are suitable for a wide range of
indoor surveillance applications. AXIS M3204-V
is also vandal-resistant.
AXIS P5534
HDTV PTZ camera with 18x zoom.
AXIS P5534 provides HDTV 720p with 18x
optical zoom, 360° pan and support for High
Power over Ethernet. It is ideal for demanding
surveillance applications.
AXIS Q6034/-E
High-speed, HDTV surveillance.
The indoor AXIS Q6034 and outdoor-ready
AXIS Q6034-E provide a rich viewing experi-
ence with HDTV 720p and 18x optical zoom, in
addition to high-speed panning/tilting, a 220°
tilt, Active Gatekeeper, auto-tracking and
support for High Power over Ethernet. They
are perfect for applications that need to cover
a large area and zoom in for clear details.
HDTV and megapixel network cameras in action
High security premises
Casinos and airports, together with passport controls,
banks and similar high security premises, are areas
where the requirements on the surveillance cameras
often include high image quality and detail as well as
full frame rate, making HDTV network cameras the
natural choice.
Transportation
Security and safety for both passengers and sta are
highly prioritized issues for public transportation author-
ities around the world. HDTV and megapixel cameras at
stations, terminals and airports as well as onboard buses
and trains, provide valid evidence in the event of criminal
incidents, vandalism and insurance claims.
Retail
In retail, theft and shrinkage can be drastically reduced
through eective video surveillance. HDTV and mega-
pixel network cameras have an important role to play,
for example by giving an overview – without any blind
spots – of stores.
City surveillance
HDTV and megapixel network cameras are typically
used in city surveillance situations to provide high-
resolution video streams from locations where there is
a need to clearly identify people and objects, or get a
larger overview, either while viewing live or recorded
video. Full frame rate, which is a requirement in HDTV
standards, makes it easier to monitor intense and fast
moving trac.
Dierent industry segments put dierent requirements on video surveillance solutions, but one shared challenge is
getting enough image quality to ensure reliable identication of people and objects. HDTV and megapixel network
cameras are used in a number of key industry segments to solve this challenge, including:
Pixels per meter -
a best practice
In the surveillance industry, the best practice for an
overview image is to ensure that a scene has 70 to
100 pixels per meter (20-30 per foot), whereas with
face identification, as much as 500 pixels per meter
(150 per foot) may be required. This means, for ex-
ample, that if you want to be able to accurately
identify people passing through an area that is two
meters wide and two meters high, the camera needs
to provide a resolution of more than 1 megapixel
(1280x1024 pixels).
The Society of Motion Picture and Television Engineers,
SMPTE, has defined the two most important standards:
SMPTE 296M and SMPTE 274M. In short, SMPTE 296M
defines a resolution of 1280x720 pixels using progres-
sive scanning, while SMPTE 274M defines a resolution
of 1920x1080 pixels using either interlaced or progres-
sive scanning. Axis HDTV network cameras comply
with key parts of the SMPTE HDTV standard, which is a
unique property of Axis’ products. A network camera
that follows the HDTV standards is guaranteed to pro-
vide high resolution, 16x9 aspect ratio, full frame rate
and extended color fidelity, thereby ensuring an overall
superb image quality.
International HDTV
standards
The network video advantage
Live video at anytime, from anywhere
With network video you can see what’s going on, in
real time, 24 hours a day, without having to be physi-
cally present onsite. You have access from any online
computer – even hand-held models. Everything your
network cameras pick up you can view and/or record
wherever you are. And you have the same remote ac-
cess to all of the intelligent functions provided by net-
work video systems. All in a secured way.
Superior image quality
Axis network video systems deliver crystal-clear im-
ages and high-quality recordings. This makes it easy to
track and review situations, identify people and get a
clear view of activities. The image quality remains con-
stant over time, and over long distances.
Easy to use
Standard IT technology and computers can be used,
which saves money and lowers the total cost of owner-
ship. And, of course, you can restrict access to only
authorized personnel.
High video quality in reduced le size
H.264 video compression technology allows the size of a
digital video le to be reduced, without compromising
image quality, by more than 80% compared with the
more conventional Motion JPEG format and as much as
50% more than with the MPEG-4 standard. When it
comes to HDTV and megapixel network cameras, the
advantage of H.264 is that full resolution video can be
transmitted with a minimum use of bandwidth and
recorded with a minimum use of storage space.
Lower costs
Network video lets you utilize existing investments
while giving you a future-proof, scalable system that
can grow with your needs. Additional cameras and stor-
age capacity, even new technologies, are all easily add-
ed, thanks to open industry standards. Maintenance and
installation costs are minimal. Power over Ethernet
technology delivers power to the camera via the net-
work cable, thereby reducing energy consumption as
well as the need for cabling and power outlets.
Intelligence where you need it
Advanced network cameras have built-in video motion
detection and alarm management, so the camera knows
when to send video, and at what frame rate and resolu-
tion. Event-driven surveillance can eliminate wasted
time and eort by reducing the need for sta to actively
monitor surveillance video.
Easy integration with other vital systems
Axis network cameras are based on open IT standards.
This makes them easy to integrate with systems such as
cash registers, access control systems and building
maintenance systems – taking video surveillance to a
whole new level of functionality.
Get the Axis picture. Stay one step ahead.
Network video oers many benets: remote accessibility, easy and future-proof integration, scalability and exi-
bility, distributed intelligence, and more cost-eective installation and maintenance. Combining HDTV and mega-
pixel network cameras with a selection of non-megapixel network cameras that are optimized for other needs –
such as powerful optical zoom, extreme light sensitivity, thermal imaging or low cost – creates video surveillance
installations that are eective, reliable and cost-ecient.
www.axis.com
39200/EN/R2/1008
About Axis Communications
Axis is an IT company oering network video solutions
for professional installations. The company is the global
market leader in network video, driving the ongoing
shift from analog to digital video surveillance. Axis
products and solutions focus on security surveillance
and remote monitoring, and are based on innovative,
open technology platforms.
Axis is a Swedish-based company, operating worldwide
with oces in more than 20 countries and cooperating
with partners in more than 70 countries. Founded in 1984,
Axis is listed on the NASDAQ OMX Stockholm under the
ticker AXIS. For more information about Axis, please visit
our website at www.axis.com.
©2010 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modications without notice.
