Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the
instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the
separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired
operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K1T344 Series Face Recognion Terminal User Manual
i
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence.
L'exploitaon est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2)
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d'en compromere le fonconnement.
COMPLIANCE NOTICE
The thermal series products might be subject to export controls in various countries or regions,
including without
limitaon, the United States, European Union, United Kingdom and/or other
member countries of the Wassenaar Arrangement. Please consult your professional legal or
compliance expert or local government
authories for any necessary export license requirements if
you intend to transfer, export, re-export the thermal series products between dierent countries.
DS-K1T344 Series Face Recognion Terminal User Manual
ii
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The
precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●
Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or
re hazard.
●
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●
When the product is installed on wall or ceiling, the device shall be
rmly xed.
●
If smoke, odors or noise rise from the device, turn
o the power at once and unplug the power
cable, and then please contact the service center.
●
If the product does not work properly, please contact your dealer or the nearest service center.
Never
aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
An all-pole mains switch shall be incorporated in the electrical
installaon of the building.
●
The equipment has been designed, when required,
modied for connecon to an IT power
distribuon system.
●
1. Do not ingest
baery. Chemical burn hazard!
2. This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
3. Keep new and used
baeries away from children.
4. If the baery compartment does not close securely, stop using the product and keep it away
from children.
5. If you think
baeries might have been swallowed or placed inside any part of the body, seek
immediate medical
aenon.
6. CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
DS-K1T344 Series Face Recognion Terminal User Manual
iii
7. Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
8. Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
9. Do not leave the
baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of
ammable liquid or gas.
10. Do not subject the baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
11. Dispose of used
baeries according to the instrucons
●
This equipment is not suitable for use in
locaons where children are likely to be present.
●
This equipment is for use only with DS-K1T341 mounng plate, bracket. Use with other (carts,
stands, or carriers) may result in instability causing injury.
●
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Cauons:
●
No naked
ame sources, such as lighted candles, should be placed on the equipment The USB
port of the equipment is used for
connecng to a mouse, a keyboard, or a USB ash drive only.
●
The serial port of the equipment is used for debugging only.
●
Burned ngers when handling the back panel. Wait one-half hour aer switching o before
handling the parts.
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Install the equipment according to the
instrucons in this manual. To prevent injury, this
equipment must be securely
aached to the oor/wall in accordance with the installaon
instrucons.
●
Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
The device cover for indoor use shall be kept from rain and moisture.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause
re danger).
●
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a
malfuncon however), and aecng the endurance of sensor at the
same me.
●
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the
ngers may erode the surface coang of the device
cover.
●
Please use a
so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Please keep all wrappers
aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to
addional costs.
DS-K1T344 Series Face Recognion Terminal User Manual
iv
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●
Biometric
recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use
mulple authencaon modes.
●
Indoor and outdoor use. If installing the device indoors, the device should be at least 2 meters
away from the light, and at least 3 meters away from the window or the door. If installing the
device outdoors, you should apply Silicone sealant among the cable wiring area to keep the
raindrop from entering.
●
Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power
Source with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to
technical
specicaons for detailed informaon.
DS-K1T344 Series Face Recognion Terminal User Manual
v
Available Models
Product Name Model
Face Recognion Terminal DS-K1T344MBFWX-E1
DS-K1T344MFX-E1
DS-K1T344MBWX-E1
DS-K1T344MBWX-QRE1
DS-K1T344MX-E1
DS-K1T344EBFWX-E1
DS-K1T344EBWX-E1
DS-K1T344EBWX-QRE1
DS-K1T344EX-E1
DS-K1T344 Series Face Recognion Terminal User Manual
vi
Contents
Chapter 1 Appearance ................................................................................................................ 1
Chapter 2 Installaon Descripon .............................................................................................. 3
2.1 Installing Environment ........................................................................................................... 3
2.2 Flush Mounng with Gang Box .............................................................................................. 3
Chapter 3 Terminal and Wiring Descripon ................................................................................. 9
3.1 Wire Normal Device ............................................................................................................... 9
3.2 Wire Secure Door Control Unit ............................................................................................ 11
3.3 Typical Applicaon ............................................................................................................... 12
Chapter 4
Acvaon ................................................................................................................. 13
4.1 Acvate via Mobile Web ...................................................................................................... 13
4.2 Acvate via Device ............................................................................................................... 14
4.3
Acvate via Web Browser .................................................................................................... 16
4.4 Acvate via SADP ................................................................................................................. 17
4.5 Acvate Device via iVMS-4200 Client Soware ................................................................... 18
Chapter 5 Quick
Operaon ....................................................................................................... 20
5.1 Set Password Change Type ................................................................................................... 20
5.2 Set Network Parameters ...................................................................................................... 20
5.3 Access to
Plaorm ............................................................................................................... 22
5.4 Remote Operaon via APP ................................................................................................... 24
5.5 Privacy Sengs .................................................................................................................... 25
5.6 Set Administrator ................................................................................................................. 26
5.7
Authencaon Page Instrucons ......................................................................................... 28
Chapter 6 Basic Operaon ........................................................................................................ 31
6.1 Login .................................................................................................................................... 31
6.1.1 Login by
Acvaon Password ...................................................................................... 31
6.1.2 Login by Administrator ................................................................................................ 32
DS-K1T344 Series Face Recognion Terminal User Manual
vii
6.1.3 Forgot Password .......................................................................................................... 35
6.1.4 Change Device Password ............................................................................................ 35
6.2
Communicaon Sengs ...................................................................................................... 36
6.2.1 Set Wired Network Parameters .................................................................................. 36
6.2.2 Set Wi-Fi Parameters ................................................................................................... 38
6.2.3 Set RS-485 Parameters ................................................................................................ 40
6.2.4 Set Wiegand Parameters ............................................................................................. 41
6.2.5 Set ISUP Parameters .................................................................................................... 42
6.2.6 Plaorm Access ........................................................................................................... 43
6.2.7 Set AP Mode ............................................................................................................... 44
6.3 Person Management ............................................................................................................ 44
6.3.1 Add Administrator ....................................................................................................... 44
6.3.2 Import and Export Face and Person Data in Batch via Device .................................... 46
6.3.3 Add Face Picture ......................................................................................................... 48
6.3.4 Add Card ..................................................................................................................... 51
6.3.5 Add Fingerprint ........................................................................................................... 52
6.3.6 Add PIN ....................................................................................................................... 53
6.3.7 Set Person Type via Device .......................................................................................... 54
6.3.8 Set
Authencaon Mode ............................................................................................ 56
6.3.9 Search and Edit Person ............................................................................................... 57
6.4 Data Management ............................................................................................................... 57
6.4.1 Delete Data ................................................................................................................. 57
6.4.2 Import Data ................................................................................................................. 57
6.4.3 Export Data ................................................................................................................. 58
6.5 Person
Authencaon ......................................................................................................... 58
6.5.1
Authencate via Single Credenal .............................................................................. 59
6.5.2 Authencate via Mulple Credenal .......................................................................... 59
6.6 Basic
Sengs ....................................................................................................................... 60
DS-K1T344 Series Face Recognion Terminal User Manual
viii
6.6.1 Enable/Disable Voice Prompt via Device .................................................................... 62
6.6.2 Set Device Time via Device ......................................................................................... 62
6.6.3 Set Sleep
Duraon via Device ..................................................................................... 62
6.6.4 Select Language .......................................................................................................... 62
6.6.5 Set Device Number via Device .................................................................................... 62
6.6.6 Set Privacy Parameters via Device .............................................................................. 63
6.6.7 Set Video Standard ..................................................................................................... 63
6.6.8 Set Secure Door Control Unit Parameters ................................................................... 64
6.7 Set Face Parameters ............................................................................................................. 64
6.7.1 Set Face Liveness Level via Device .............................................................................. 65
6.7.2 Set Recognion Distance via Device ........................................................................... 66
6.7.3 Set Face Recognion Interval via Device ..................................................................... 66
6.7.4 Set Face 1:N Security Level via Device ........................................................................ 66
6.7.5 Set Face 1:1 Security Level via Device ......................................................................... 66
6.7.6 Enable/Disable ECO Mode via Device ......................................................................... 67
6.7.7 Enable/Disable Face Mask Detecon via Device ......................................................... 67
6.8 Access Control
Sengs ........................................................................................................ 68
6.8.1 Set Terminal Authencaon Mode via Device ............................................................ 69
6.8.2 Set Reader Authencaon Mode via Device .............................................................. 70
6.8.3 Enable/Disable NFC Card ............................................................................................ 70
6.8.4 Enable/Disable M1 Card ............................................................................................. 71
6.8.5 Set
Authencaon Interval via Device ........................................................................ 71
6.8.6 Set
Authencaon Result Display Duraon via Device ............................................... 71
6.8.7 Set Password Mode .................................................................................................... 71
6.8.8 Set Door Contact via Device ........................................................................................ 72
6.8.9 Set Open
Duraon via Device ..................................................................................... 72
6.9 Preference Sengs .............................................................................................................. 72
6.9.1 Set Shortcut Key via Device ......................................................................................... 73
DS-K1T344 Series Face Recognion Terminal User Manual
ix
6.9.2 Theme ......................................................................................................................... 74
6.10 System Maintenance .......................................................................................................... 75
6.10.1 View System
Informaon .......................................................................................... 75
6.10.2 View Device Capacity via Device ............................................................................... 76
6.10.3 Upgrade .................................................................................................................... 76
6.10.4 View User Manual ..................................................................................................... 77
6.10.5 Restore Sengs ........................................................................................................ 77
6.11 Video Intercom .................................................................................................................. 77
6.11.1 Call Client Soware from Device ............................................................................... 78
6.11.2 Call Center from Device ............................................................................................ 78
6.11.3 Call Device from Client Soware ............................................................................... 79
6.11.4 Call Room from Device .............................................................................................. 79
6.11.5 Call Mobile Client from Device .................................................................................. 80
Chapter 7 Congure Device via Mobile Web ............................................................................. 81
7.1 Login .................................................................................................................................... 81
7.2 Forget Password ................................................................................................................... 81
7.3 Account Security
Sengs ..................................................................................................... 81
7.4 Home ................................................................................................................................... 82
7.5 Conguraon ....................................................................................................................... 82
7.5.1 View Device
Informaon ............................................................................................. 82
7.5.2 Set Device Time ........................................................................................................... 83
7.5.3 User Management ...................................................................................................... 83
7.5.4 Network
Sengs ......................................................................................................... 84
7.5.5 Add Person .................................................................................................................. 88
7.5.6 Event Search ................................................................................................................ 90
7.5.7 Audio
Sengs ............................................................................................................. 90
7.5.8 Access Control Sengs ............................................................................................... 90
7.5.9 Video Intercom
Sengs .............................................................................................. 96
DS-K1T344 Series Face Recognion Terminal User Manual
x
7.5.10 Set Face Parameters .................................................................................................. 98
7.5.11 Enable/Disable Masl Detecon via Device ................................................................ 99
7.5.12 Set Privacy Parameters ............................................................................................ 100
7.5.13 Set PIN Mode .......................................................................................................... 101
7.5.14 System Upgrade & Maintenance ............................................................................ 101
7.5.15 View User Document .............................................................................................. 102
7.5.16 Open Source
Soware Licenses .............................................................................. 102
7.5.17 Log Out of Mobile Web ........................................................................................... 102
Chapter 8 Operaon via Web Browser .................................................................................... 103
8.1 Login .................................................................................................................................. 103
8.2 Forget Password ................................................................................................................. 103
8.3 Help .................................................................................................................................... 103
8.3.1 Open Source
Soware Licenses ................................................................................ 103
8.3.2 View Online Help Document ..................................................................................... 104
8.4 Logout ................................................................................................................................ 104
8.5 Quick
Operaon via Web Browser ..................................................................................... 104
8.5.1 Change Password ...................................................................................................... 104
8.5.2 Select Language ........................................................................................................ 105
8.5.3 Time
Sengs ............................................................................................................. 105
8.5.4 Privacy
Sengs ......................................................................................................... 105
8.5.5 Administrator Sengs .............................................................................................. 106
8.5.6 No. and System Network .......................................................................................... 107
8.6 Person Management .......................................................................................................... 108
8.7 Access Control Management ............................................................................................. 110
8.7.1 Overview ................................................................................................................... 110
8.7.2 Search Event .............................................................................................................. 112
8.7.3 Door Parameter
Conguraon .................................................................................. 113
8.7.4
Authencaon Sengs ............................................................................................. 116
DS-K1T344 Series Face Recognion Terminal User Manual
xi
8.7.5 Set Face Parameters .................................................................................................. 120
8.7.6 Card Sengs ............................................................................................................. 125
8.7.7 Linkage
Sengs ........................................................................................................ 126
8.7.8 Set Working Mode via PC Web ................................................................................. 127
8.7.9 Privacy Sengs ......................................................................................................... 128
8.8 Call Sengs ........................................................................................................................ 131
8.8.1 Device Management ................................................................................................. 131
8.8.2 Set Device No. via Web ............................................................................................. 131
8.8.3 Congure Video Intercom Network Parameters via Web Browser ........................... 133
8.8.4 Set Communicaon Time via PC Web ....................................................................... 134
8.8.5 Press Buon to Call via PC Web ................................................................................ 134
8.8.6 Number Sengs via PC Web .................................................................................... 135
8.9 System and Maintenance ................................................................................................... 135
8.9.1 View Device Informaon via PC Web ........................................................................ 135
8.9.2 Set Time .................................................................................................................... 135
8.9.3 Change Administrator's Password ............................................................................. 137
8.9.4 Account Security
Sengs via PC Web ....................................................................... 137
8.9.5 View Device Arming/Disarming Informaon via PC Web ......................................... 137
8.9.6 Network Sengs ....................................................................................................... 138
8.9.7 Set Video and Audio Parameters via PC Web ........................................................... 144
8.9.8 Image Parameter
Sengs ......................................................................................... 145
8.9.9 Alarm Sengs via PC Web ........................................................................................ 147
8.9.10 Access
Conguraon ............................................................................................... 147
8.10 Preference Sengs .......................................................................................................... 149
8.10.1 Set Standby Image via PC Web ............................................................................... 149
8.10.2 Set Sleep Time via PC Web ...................................................................................... 149
8.10.3 Customize
Authencaon Desk via PC Web ........................................................... 150
8.10.4 Set
Noce Publicaon via PC Web .......................................................................... 150
DS-K1T344 Series Face Recognion Terminal User Manual
xii
8.10.5 Set Prompt Schedule via PC Web ............................................................................ 151
8.10.6 Customize Prompt Voice via PC Web ...................................................................... 153
8.10.7 Set
Authencaon Result Text via PC Web ............................................................. 153
8.11 System and Maintenance ................................................................................................. 154
8.11.1 Reboot .................................................................................................................... 154
8.11.2 Upgrade .................................................................................................................. 154
8.11.3 Restoraon .............................................................................................................. 155
8.11.4 Export Device Parameters via PC Web .................................................................... 155
8.11.5 Import Device Parameters via PC Web ................................................................... 155
8.11.6 Device Debugging ................................................................................................... 156
8.11.7 View Log via PC Web ............................................................................................... 157
8.11.8 Advanced Sengs via PC Web ................................................................................ 157
8.11.9 Security Management ............................................................................................. 158
8.11.10 Cercate Management ....................................................................................... 158
Appendix A. Tips for Scanning Fingerprint ............................................................................... 160
Appendix B. Tips When Collecng/Comparing Face Picture .................................................... 162
Appendix C. Tips for
Installaon Environment ........................................................................ 164
Appendix D. Dimension .......................................................................................................... 165
Appendix E. Legal Informaon ................................................................................................ 166
Appendix F. Symbol
Convenons ............................................................................................ 168
DS-K1T344 Series Face Recognion Terminal User Manual
xiii
Chapter 1 Appearance
Figure 1-1 Appearance Descripon (Unit: mm)
Note
Parts of models support ngerprint funcon, refers to the actual product.
DS-K1T344 Series Face Recognion Terminal User Manual
1
Figure 1-2 Other Types
Note
For dierent device models, the device will support ngerprint, QR code, and keypad. Refers to
actual products for details.
DS-K1T344 Series Face Recognion Terminal User Manual
2
Chapter 2 Installaon Descripon
2.1 Installing Environment
Avoid backlight, direct sunlight, and indirect sunlight. For beer recognion, there should be light
source in or near the installaon environment.
If you have to install the device outdoors, you should install a protecve shield (oponal) for the
device.
Note
For details about installaon environment, see Tips for Installaon Environment .
2.2 Flush Mounng with Gang Box
Steps
Note
The gang box is oponal. You should purchase it separately.
1.
Make sure the gang box is installed on the wall.
DS-K1T344 Series Face Recognion Terminal User Manual
3
Figure 2-1 Gang Box is on Wall
2.
Align the mounng plate holes with gang box holes, using 2 screws (KA4×25) to secure the
mounng plate on the gang box.
DS-K1T344 Series Face Recognion Terminal User Manual
4
Figure 2-2 Secure Mounng Template
3.
Complete wiring. For details, see the wiring diagram.
DS-K1T344 Series Face Recognion Terminal User Manual
5
Figure 2-3 Wiring
4.
Remove screws on the back sheet, and remove the back sheet.
Figure 2-4 Remove Back Sheet
5.
Insert the terminals in the device. For details, see wiring diagram. Use 1 screw (KM3×8) to
secure the device on the
mounng plate.
DS-K1T344 Series Face Recognion Terminal User Manual
6
Figure 2-5 Install Device
6.
Arrange the cables and install the back sheet back. Apply silicone sealant among the cable wiring
area to keep the raindrop from entering.
Figure 2-6 Apply Silicone Sealant
DS-K1T344 Series Face Recognion Terminal User Manual
7
7.
Complete installaon.
Figure 2-7 Complete Installaon
DS-K1T344 Series Face Recognion Terminal User Manual
8
Chapter 3 Terminal and Wiring Descripon
You can connect to RS-485 card reader, door lock, exit buon, door contact, alarm device, etc. via
the terminals.
You can connect the RS-485 terminal with the RS-485 card reader, connect the LOCK terminal with
the door lock, connect the SEN and GND terminal with the door contact, the BTN/GND terminal
with the exit
buon, and connect the Wiegand terminal with the access controller.
If connect the WIEGAND terminal with the access controller, the face recognion terminal can
transmit the
authencaon informaon to the access controller and the access controller can
judge whether to open the door or not.
Pay aenons when wiring:
●
If cable size is 18 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 20 m.
●
If the cable size is 15 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 30 m.
●
If the cable size is 12 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 40 m.
Note
The external card reader, door lock, exit buon, and door contact need individual power supply.
3.1 Wire Normal Device
The wiring diagram is as follows:
DS-K1T344 Series Face Recognion Terminal User Manual
9
Figure 3-1 Terminal and Wiring Descripon
Note
●
The wiegand interface shown in the gure is wiegand input interface, which can be connected to
the wiegand card reader, and you need to set the wiegand transmission direcon as “input”. If
the device connects to the access controller, the wiegand interface is wiegand output interface,
and you need to set the transmission
direcon as “output”. For more informaon about seng
transmission direcon, refer to Set Wiegand Parameters in Communicaon Sengs secon.
●
Alarm input devices are usually sensors, and alarm output devices are usually alarms and lights.
●
Connect the wires according to the actual needs, and power cable must be connected.
●
There is no need to connect external power supply when using PoE power supply.
●
Use 12 VDC power supply with 12 W power.
●
Do not directly connect the device to 220 V electric supply.
●
When using the PoE power supply, the lock power supply (equipped) can be used to power the
lock. The lock power interface will contain power when connect PoE power supply.
●
If the device do not support PoE, do not connect the lock power terminal. And instead, you
should wire an external power for the door lock.
DS-K1T344 Series Face Recognion Terminal User Manual
10
Figure 3-2 Connect the Terminals to the Interfaces
Note
●
Connect the cables according to the actual needs, and power cable must be connected.
●
Supports PoE network interface, and it can be powered by PoE power supply.
●
There is no need to connect external power supply when using PoE power supply.
●
The debugging port is for debugging only.
3.2 Wire Secure Door Control Unit
You can connect the terminal with the secure door control unit.
Figure 3-3 Secure Door Control Unit Wiring
DS-K1T344 Series Face Recognion Terminal User Manual
11
Note
●
The secure door control unit should connect to an external power supply separately. The
suggested external power supply is 12 V, 0.5 A.
●
For scenarios with high safety requirement, use the secure door control unit wiring rst. You can
ask the technical support to purchase for the secure door control unit separately.
●
The picture here are parts of the wiring. For details, see the secure door control unit’s user
manual.
3.3 Typical Applicaon
Typical Applicaon 1
Scene: Aer installaon and wiring, you can add face and other informaon for the person. And
the person can authencate on the device.
1. Finish installaon and wiring. For details, refers to Installaon Descripon and Terminal and
Wiring Descripon .
2. Finish device acvaon. For details, see Acvaon .
3. Finish quick operaon on the device. For details, see Quick Operaon .
4. Add face and permission. For details, see
Add Face Picture and Set Authencaon Mode .
5. Person authencaon. For details, see Person Authencaon .
Typical
Applicaon 2
Scene: Call door staon via the device.
1. Finish installaon and wiring. For details, refers to Installaon Descripon and Terminal and
Wiring Descripon .
2. Set the device No. For details, refers to Set Device Number via Device and Congure Video
Intercom Network Parameters via Web Browser .
3. Add indoor staon or sub door staon. For details, see Device Management .
4. Set private intercom server IP address (SIP server IP). The IP address would be the main
staon’s
IP. For details, see Congure Video Intercom Network Parameters via Web Browser .
5. Set the indoor
staon No. or sub door staon No. and set the SIP server IP address (the same as
the device). For details, see the indoor staon and the door staon's user manual.
6. Call indoor staon from the device. For details, see Call Room from Device .
DS-K1T344 Series Face Recognion Terminal User Manual
12
Chapter 4 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
●
The default IP address: 192.0.0.64
●
The default port No.: 8000
●
The default user name: admin
4.1
Acvate via Mobile Web
You can acvate the device via mobile web.
Steps
1.
Connect to the device hotspot with your mobile phone by entering the hotspot password.
Note
●
For inacve devices, hotspot is enabled by default.
●
The hotspot name and the default hotspot password is the device serial number.
●
Aer the device is acvated, the hotspot password will change to the acvaon password
(admin password).
The login page will pop up.
2.
Create a new password (admin password) and conrm the password.
Cauon
●
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at
least three kinds of following categories: upper case leers, lower case leers, numbers, and
special characters) in order to increase the security of your product. And we recommend you
change your password regularly, especially in the high security system, changing the password
monthly or weekly can
beer protect your product.
●
Proper
conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
●
Do not contain following characters in the password: the user name, 123, admin (case-
insensive), 4 or more connuously increasing or decreasing digits, or 4 or more consecuvely
repeated characters.
●
Password cannot contain words such as hik, hkws, and hikvision (case
insensive).
3.
Click Acvate.
DS-K1T344 Series Face Recognion Terminal User Manual
13
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client soware.
4.2 Acvate via Device
If the device is not acvated, you can select to acvate on the device aer it is powered on.
On the Remote Cong. page, tap Switch to Local Acvaon create a password and conrm the
password. Tap Next and the device will
acvated.
DS-K1T344 Series Face Recognion Terminal User Manual
14
Figure 4-1 Acvaon Page
Cauon
●
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
DS-K1T344 Series Face Recognion Terminal User Manual
15
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
●
Proper
conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
●
Do not contain following characters in the password: the user name, 123, admin
(case-
insensive), 4 or more connuously increasing or decreasing digits, or 4 or more consecuvely
repeated characters.
●
Password cannot contain words such as hik, hkws, and hikvision (case insensive).
4.3 Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press
Enter.
Note
Make sure the device IP address and the computer's should be in the same IP segment.
2.
Create a new password (admin password) and conrm the password.
Cauon
●
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at
least three kinds of following categories: upper case leers, lower case leers, numbers, and
special characters) in order to increase the security of your product. And we recommend you
change your password regularly, especially in the high security system, changing the password
monthly or weekly can
beer protect your product.
●
Proper
conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
●
Do not contain following characters in the password: the user name, 123, admin (case-
insensive), 4 or more connuously increasing or decreasing digits, or 4 or more consecuvely
repeated characters.
●
Password cannot contain words such as hik, hkws, and hikvision (case
insensive).
3.
Click Acvate.
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client soware.
DS-K1T344 Series Face Recognion Terminal User Manual
16
4.4 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
●
The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP
soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and
conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
4.
Click Acvate to start acvaon.
DS-K1T344 Series Face Recognion Terminal User Manual
17
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to
acvate your IP address modicaon.
4.5
Acvate Device via iVMS-4200 Client Soware
For some devices, you are required to create the password to acvate them before they can be
added to the iVMS-4200
soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and select an
inacve device.
5.
Click
Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the password.
DS-K1T344 Series Face Recognion Terminal User Manual
18
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
7.
Click OK to acvate the device.
DS-K1T344 Series Face Recognion Terminal User Manual
19
Chapter 5 Quick Operaon
5.1 Set Password Change Type
You can set the password change type as reserved email address or security quesons. Once you
forgot the device password, you can change the password via the selected change type.
Change Password via Email Address
If you need to change password via reserved email, you can enter an email address, and tap Next.
Change via Security
Quesons
If you need to change password via security quesons, you can tap Change to Security Quesons
on the right corner. Select the security quesons and enter the answers. Tap Next.
Note
You can only select one type to change password. If you need, you can enter the web page to set
both of the changing types.
5.2 Set Network Parameters
You can set the network for the device.
Steps
Note
Parts of the device models supports wi- funcon. Refers to the actual device for details.
1.
When you enter the Select Network page, tap Wired Network or Wi-Fi for your actual needs.
DS-K1T344 Series Face Recognion Terminal User Manual
20
Figure 5-1 Select Network
Note
Disconnect the wired network before connecng a Wi-Fi.
2.
Tap Next.
Wired Network
DS-K1T344 Series Face Recognion Terminal User Manual
21
Note
Make sure the device has connected to a network.
If enable DHCP, the system will assign the IP address and other parameters automacally.
If disable DHCP, you should set the IP address, the subnet mask, and the gateway.
Wi-Fi
Select a Wi-Fi and enter the Wi-Fi's password to get connected.
Or tap Add Wi-Fi and enter the Wi-Fi's name and the password to get connected.
3.
Oponal: Tap Skip to skip network sengs.
5.3 Access to
Plaorm
Enable the funcon and the device can communicate via Hik-Connect. You can add the device to
Hik-Connect mobile client and so on.
Steps
Note
Parts of the device models supports funcon. Refers to the actual device for details.
1.
Enable Access to Hik-Connect, and set the server IP and vericaon code.
DS-K1T344 Series Face Recognion Terminal User Manual
22
Figure 5-2 Access to Hik-Connect
2.
Tap Next.
3.
Oponal: Tap Skip to skip the step.
4.
Oponal: Tap Previous to go to the previous page.
DS-K1T344 Series Face Recognion Terminal User Manual
23
Note
If you tap Previous to return to the Wi-Fi conguraon page, you need to tap the connected Wi-
Fi or connect another Wi-Fi to enter the plaorm page again.
5.4 Remote Operaon via APP
You can add the device to your mobile client for remote operaon.
Download Hik-Connect to your mobile client and run the APP. Scan the QR Code in the following
picture to add the device to your mobile client for remote operaon.
Following the instrucon in your mobile client to add the device.
DS-K1T344 Series Face Recognion Terminal User Manual
24
Figure 5-3 Operate Remotely via APP
5.5 Privacy
Sengs
You should set the privacy parameters, including the picture uploading and storage.
Select parameters according to your actual needs.
Upload Pic. When Auth. (Upload Captured Picture When
Authencang)
DS-K1T344 Series Face Recognion Terminal User Manual
25
Upload the pictures captured when authencang to the plaorm automacally.
Save Pic. When Auth. (Save Captured Picture When Authencang)
If you enable this funcon, you can save the picture when Authencang to the device.
Save Registered Pic. (Save Registered Picture)
The registered face picture will be saved to the system if you enable the
funcon.
Upload Pic. Aer Linked Capture (Upload Picture Aer Linked Capture)
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pic. Aer Linked Capture (Save Pictures Aer Linked Capture)
If you enable this funcon, you can save the picture captured by linked camera to the device.
Tap Next to complete the sengs.
5.6 Set Administrator
Aer device acvaon, you can add an administrator to manage the device parameters.
Before You Start
Acvate the device and select an applicaon mode.
Steps
1.
Oponal: Tap Skip to skip adding administrator if required.
2.
Enter the administrator's name (oponal) and tap Next.
DS-K1T344 Series Face Recognion Terminal User Manual
26
Figure 5-4 Add Administrator Page
3.
Select a credenal to add.
Note
Up to one credenal should be added.
DS-K1T344 Series Face Recognion Terminal User Manual
27
-
: Face forward at the camera. Make sure the face is in the face recognion area. Click to
capture and click to conrm.
-
: Press your nger according to the instrucons on the device screen. Click to conrm.
-
: Enter the card No. or present card on the card presenng area. Click OK.
Note
Only devices connected to the external ngerprint module support ngerprint funcon.
4.
Click OK.
You will enter the authencaon page.
5.7 Authencaon Page Instrucons
Introduce the authencaon page.
DS-K1T344 Series Face Recognion Terminal User Manual
28
Figure 5-5 Authencaon Page
Status Bar Instrucons
/
The device is armed/not armed.
/ /
DS-K1T344 Series Face Recognion Terminal User Manual
29
Wi-Fi is connected and signal is strong/Wi-Fi is enabled but not connected/Wi-Fi IP conicts.
/ /
Network is connected/not connected/connecon error.
/ /
SIP server is registered/registering failed/registered to door staon but not to main staon.
Authencaon Page Icon
Note
The displayed icon on the authencaon page can be controlled. For details, see shortcut key
sengs in .
Show QR code to the camera and you can authencate via the QR code.
Note
The QR code is generated and applied from plaorm for visitors or is converted from card
No.
●
Enter the room No., and tap OK to call.
●
Tap
to call the center.
Note
The device should be added to the center, or the calling operaon will be failed.
Enable this funcon and you can enter the PIN to authencate. Tap the buon on the
authencaon page to verify.
DS-K1T344 Series Face Recognion Terminal User Manual
30
Chapter 6 Basic Operaon
6.1 Login
Login the device to set the device basic parameters.
6.1.1 Login by Acvaon Password
You should login the system before other device operaons. If you do not congure an
administrator, you should follow the
instrucons below to login.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
password entering page.
2.
Enter the password.
-
If you have added an administrator for the device, tap and enter the password.
-
If you haven't added an administrator for the device, enter the password.
3.
Tap OK to enter the home page.
Note
The device will be locked for 30 minutes aer 5 failed password aempts.
DS-K1T344 Series Face Recognion Terminal User Manual
31
Figure 6-1 Home Page
6.1.2 Login by Administrator
If you have added an administrator for the device, only the administrator can login the device for
device
operaon.
DS-K1T344 Series Face Recognion Terminal User Manual
32
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
the admin login page.
Figure 6-2 Admin Login
2.
Authencate the administrator's face, ngerprint or card to enter the home page.
DS-K1T344 Series Face Recognion Terminal User Manual
33
Figure 6-3 Home Page
Note
The device will be locked for 30 minutes aer 5 failed ngerprint or card aempts.
3.
Oponal: Tap and you can enter the device acvaon password for login.
4.
Oponal: Tap and you can exit the admin login page.
DS-K1T344 Series Face Recognion Terminal User Manual
34
6.1.3 Forgot Password
If you forget the password during authencaon, you can change the password.
Steps
1.
Hold the inial page for 3 s and slide to the le/right by following the gesture and log in the
page.
2.
Oponal: If you have set an administrator, tap in the pop-up admin authencaon page.
3.
Tap Forgot Password.
4.
Select a password change type from the list.
Note
If you have only set 1 password change type, you will go to the corresponded password change
page for further sengs.
5.
Answer the security quesons or change the password according to email address.
-
Security Quesons: Answer the security quesons that congured when acvaon.
-
Email Address
Note
Make sure the device has added to the Hik-Connect account.
a. Download Hik-Connect app.
b. Go to More → Reset Device Password .
c. Scan the QR code on the device and a vericaon code will be popped up.
Note
Tap the QR code to get a larger picture.
d. Enter the vericaon code on the device page.
6.
Create a new password and conrm it.
7.
Tap OK.
6.1.4 Change Device Password
You can change the device password by entering the old password.
Steps
1.
Long tap on the inial page for 3 s and login the home page. Tap System → Password .
2.
Tap Change Device Password.
3.
Enter the device old password.
Note
If you forget your password, you can tap Forgot Password and change the password. For details,
see Forgot Password .
DS-K1T344 Series Face Recognion Terminal User Manual
35
4.
Enter new password and conrm the password.
Cauon
●
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at
least three kinds of following categories: upper case leers, lower case leers, numbers, and
special characters) in order to increase the security of your product. And we recommend you
change your password regularly, especially in the high security system, changing the password
monthly or weekly can
beer protect your product.
●
Proper
conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
●
Do not contain following characters in the password: the user name, 123, admin (case-
insensive), 4 or more connuously increasing or decreasing digits, or 4 or more consecuvely
repeated characters.
●
Password cannot contain words such as hik, hkws, and hikvision (case
insensive).
5.
Tap OK.
6.2
Communicaon Sengs
6.2.1 Set Wired Network Parameters
You can set the device wired network parameters, including the IP address, the subnet mask, the
gateway, and DNS parameters.
Steps
1.
Tap System
Sengs → Comm. (Communicaon Sengs) on the Home page to enter the
Communicaon Sengs page.
2.
On the
Communicaon Sengs page, tap Wired Network.
DS-K1T344 Series Face Recognion Terminal User Manual
36
Figure 6-4 Wired Network Sengs
3.
Set IP Address, Subnet Mask, and Gateway.
-
Enable DHCP, and the system will assign IP address, subnet mask, and gateway automacally.
-
Disable DHCP, and you should set the IP address, subnet mask, and gateway manually.
DS-K1T344 Series Face Recognion Terminal User Manual
37
Note
The device's IP address and the computer IP address should be in the same IP segment.
4.
Set the DNS parameters. You can enable Auto Obtain DNS, set the preferred DNS server and the
alternate DNS server.
6.2.2 Set Wi-Fi Parameters
You can enable the Wi-Fi funcon and set the Wi-Fi related parameters.
Steps
Note
The funcon should be supported by the device.
1.
Tap System Sengs → Comm. (Communicaon Sengs) on the Home page to enter the
Communicaon Sengs page.
2.
On the Communicaon Sengs page, tap.
DS-K1T344 Series Face Recognion Terminal User Manual
38
Figure 6-5 Wi-Fi Sengs
3.
Enable the Wi-Fi funcon.
4.
Congure the Wi-Fi parameters.
-
Select a Wi-Fi from the list, and enter the Wi-Fi's password. Tap OK.
-
If the target Wi-Fi is not in the list,tap Add Wi-Fi. Enter the Wi-Fi's name and password. And
tap OK.
DS-K1T344 Series Face Recognion Terminal User Manual
39
Note
Only digits, leers, and special characters are allowed in the password.
5.
Set the Wi-Fi's parameters.
-
By default, DHCP is enable. The system will allocate the IP address, the subnet mask, and the
gateway automacally.
-
If disable DHCP, you should enter the IP address, the subnet mask, and the gateway manually.
6.
Tap OK to save the sengs and go back to the Wi-Fi tab.
7.
Tap
to save the network parameters.
6.2.3 Set RS-485 Parameters
The face recognion terminal can connect external access controller, secure door control unit, card
reader, or QR code scanner via the RS-485 terminal.
Steps
1.
Tap System
Sengs → Comm. (Communicaon Sengs) on the Home page to enter the
Communicaon Sengs page.
2.
On the Communicaon Sengs page, tap RS-485 to enter the RS-485 tab.
Figure 6-6 Set RS-485 Parameters
3.
Select an peripheral type according to your actual needs.
DS-K1T344 Series Face Recognion Terminal User Manual
40
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
4.
Tap the back icon at the upper le corner and you should reboot the device if you change the
parameters.
6.2.4 Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
1.
Tap System
Sengs → Comm. (Communicaon Sengs) on the Home page to enter the
Communicaon Sengs page.
2.
On the Communicaon Sengs page, tap Wiegand to enter the Wiegand tab.
Figure 6-7 Wiegand Sengs
3.
Enable the Wiegand funcon.
4.
Select a Wiegand mode.
●
Output: A face recognion terminal can connect an external access controller. And the two
devices will transmit the card No. via Wiegand 26 or Wiegand 34.
5.
Tap
to save the network parameters.
Note
If you change the external device, and aer you save the device parameters, the device will
reboot automacally.
DS-K1T344 Series Face Recognion Terminal User Manual
41
6.2.5 Set ISUP Parameters
Set ISUP parameters and the device can upload data via ISUP protocol.
Before You Start
Make sure your device has connect to a network.
Steps
1.
Tap System → Comm. → ISUP
(Communicaon Sengs) on the Home page to enter the sengs
page.
Figure 6-8 ISUP Sengs
2.
Enable the ISUP funcon and set the ISUP server parameters.
ISUP Version
Set the ISUP version according to your actual needs.
Central Group
Enable central group and the data will be uploaded to the center group.
Main Channel
Support N1 or None.
ISUP
Enable ISUP funcon and the data will be uploaded via ISUP protocol.
DS-K1T344 Series Face Recognion Terminal User Manual
42
Address Type
Select an address type according to your actual needs.
IP Address
Set the ISUP server's IP address.
Port No.
Set the ISUP server's port No.
Note
Port No. Range: 0 to 65535.
Device ID
Set device serial no.
Password
If you choose V5.0, you should create an account and ISUP key. If you choose other version,
you should create an ISUP account only.
Note
●
Remember the ISUP account and ISUP key. You should enter the account name or the key
when the device should communicate with other plaorms via ISUP protocol.
●
ISUP key range: 8 to 32 characters.
6.2.6 Plaorm Access
You can change the device vericaon code and set the server address before you add the device
to the Hik-Connect mobile client.
Before You Start
Make sure your device has connected to a network.
Steps
Note
Parts of the device models supports funcon. Refers to the actual device for details.
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap Access to Hik-Connect.
3.
Enable Access to Hik-Connect
4.
Enter Server IP.
5.
Create the
Vericaon Code, and you need to enter the vericaon code when you manage the
devices via Hik-Connect.
DS-K1T344 Series Face Recognion Terminal User Manual
43
6.2.7 Set AP Mode
You can enable AP mode, and add the device to Hik-Connect to set network.
Steps
1.
Tap System Sengs → Comm. (Communicaon Sengs) on the Home page to enter the
Communicaon Sengs page.
2.
Tap AP Mode to enter the sengs page.
3.
Enable AP mode. and use the phone's Wi-Fi
funcon to connect the device hotspot.
Note
●
Hotspot Name: Device serial No.
●
Hotspot Password: Admin password.
●
The device Wi-Fi will be disabled when the AP mode is enabled.
4.
Oponal: If the Wi-Fi adding page is not go to the web browser automacally aer you connect
to the device hotspot, you can enter www.acsvis.com manually in the phone's browser address
bar to enter the mobile web login page.
6.3 Person Management
On the person management interface, you can add, edit, delete and search the person.
6.3.1 Add Administrator
The administrator can log in the device backend and congure the device parameters.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and enter
the device backend.
2.
Tap Person → + to enter the Add Person page.
DS-K1T344 Series Face Recognion Terminal User Manual
44
3.
Edit the employee ID.
DS-K1T344 Series Face Recognion Terminal User Manual
45
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the person name on the so keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the
person name.
●
Up to 32 characters are allowed in the person name.
5.
Oponal: Add a face picture, ngerprints, cards, PIN for the administrator.
Note
●
For details about adding a face picture, see Add Face Picture .
●
For details about adding a ngerprint, see Add Fingerprint .
●
For details about adding a card, see Add Card .
●
For details about adding a password, see
Add PIN .
6.
Oponal: Set the administrator's authencaon type.
Note
For details about seng the authencaon type, see Set Authencaon Mode .
7.
Enable the Administrator Permission funcon.
Enable Administrator Permission
The person is the administrator. Except for the normal aendance funcon, the person can
also enter the Home page to operate aer authencang the permission.
8.
Set Door Permission.
9.
Tap
to save the sengs.
6.3.2 Import and Export Face and Person Data in Batch via Device
You can use the import and export funcon to import the data from device A to device B by USB
ash drive.
Before You Start
●
Login Device A (The device that you need to export data). For details, see Login .
●
Insert an USB
ash drive to Device A.
DS-K1T344 Series Face Recognion Terminal User Manual
46
Note
○
The supported USB ash drive format is FAT32 or exFAT.
○
The system supports the USB ash drive with the storage of 1 G to 256 G. Make sure the free
space of the USB ash drive is more than 512 M.
Steps
1.
On Device A menu, tap Data and enter the Data page.
Figure 6-9 Data Management Page
DS-K1T344 Series Face Recognion Terminal User Manual
47
2.
Tap Export Data in the Data Management page.
3.
Select Person Data or Face Data.
4.
Oponal: Create a password for exporng. When you import those data to another device, you
should enter the password.
Note
●
The password cannot be empty. If you do not set a password, you can view the exported data
in your PC.
●
If you set a password, you cannot view the exported data in your PC.
●
The exported person data is a DB
le, which cannot be edited.
5.
Insert the USB ash drive to Device B that need to import face and person data.
Note
Make sure the two device are of the same device type.
6.
On Device B menu, tap Dataand enter the Data page.
7.
Tap Import Data.
8.
Select Person Data or Face Data.
9.
Enter the created password when you exported the data. If you do not create a password when
you exported the data, leave a blank in the input box and tap OK. The data will be imported
from USB
ash drive.
Note
●
If you need to import pictures manually, you should save the pictures in the root directory
(enroll_pic) of the USB ash drive. The picture's name should be follow the rule below: Card
No._Name_Department_Employee ID_Gender.jpg For gender, 3 refers to male, 6 refers to
female, and 0 refers to none. The employee ID should be less than 32 characters. The name
should be less than 20 characters, and the card No. should be less than 20 characters.
●
Up to 10,000 pictures can be saved in the Enroll_pic folder. If the folder enroll_pic cannot save
all imported pictures, you can create another folders, named enroll_pic1, enroll_pic2,
enroll_pic3, enroll_pic4, under the root directory. Up to 10 folders can be added. The picture
name should follow the picture naming rule.
●
Requirements of face picture should follow the rules below: It should be taken in full-face
view, directly facing the camera. Do not wear a hat or head covering when taking the face
picture. The format should be JPEG or JPG. The
resoluon should be 640 × 480 pixel or more
than of 640 × 480 pixel. The picture size should be between 60 KB and 200 KB.
6.3.3 Add Face Picture
Add person's face picture to the device. And the person can use the face picture to authencate.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
DS-K1T344 Series Face Recognion Terminal User Manual
48
2.
Tap Person → + to enter the Add Person page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the person name on the so keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the
person name.
●
The suggested person name should be within 32 characters.
5.
Tap the Face Picture eld to enter the face picture adding page.
DS-K1T344 Series Face Recognion Terminal User Manual
49
Figure 6-10 Add Face Picture
6.
Look at the camera.
DS-K1T344 Series Face Recognion Terminal User Manual
50
Note
●
Make sure your face picture is in the face picture outline when adding the face picture.
●
Make sure the captured face picture is in good quality and is accurate.
●
For details about the instrucons of adding face pictures, see Tips When Collecng/
Comparing Face Picture .
Aer completely adding the face picture, a captured face picture will be displayed at the upper
right corner of the page.
7.
Tap Save to save the face picture.
8.
Oponal: Tap Try Again and adjust your face posion to add the face picture again.
9.
Set the person type.
Basic Person
The person is the normal person. The person can only
authencate or take aendance on the
inial page. You can also set the basic person as an Administrator by enable the
administrator funcon.
Visitor
The person is a visitor.
Person in Blocklist
The person is in the blocklist. When the person starts authencaon, an event will be upload.
Custom Type
Set the custom person type.
10.
Tap
to save the sengs.
6.3.4 Add Card
Add a card for the person and the person can authencate via the added card.
Steps
Note
Each person can add up to 50 cards.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap person → + to enter the Add Person page.
3.
Connect an external card reader according to the wiring diagram.
4.
Tap the Employee ID.
eld and edit the employee ID.
DS-K1T344 Series Face Recognion Terminal User Manual
51
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
5.
Tap the Name eld and input the person name on the so keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the
person name.
●
The suggested person name should be within 32 characters.
6.
Tap the Card eld and tap +.
7.
Congure the card No.
-
Enter the card No. manually.
-
Present the card over the card
presenng area to get the card No.
Note
●
The card No. cannot be empty.
●
Up to 20 characters are allowed in the card No.
●
The card No. cannot be duplicated.
8.
Congure the card type.
9.
Tap to save the sengs.
6.3.5 Add Fingerprint
Add a ngerprint for the person and the person can authencate via the added ngerprint.
Steps
Note
The funcon should be supported by the device.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and enter
the device backend.
2.
Tap Person → + to enter the Add Person page.
3.
Tap the Employee ID.
eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not start with 0 and should not be duplicated.
4.
Tap the Name eld and input the person name on the so keyboard.
DS-K1T344 Series Face Recognion Terminal User Manual
52
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the
person name.
●
The suggested person name should be within 32 characters.
5.
Tap the Fingerprint eld to enter the Add Fingerprint page.
6.
Follow the instrucons to add a ngerprint.
Note
●
The same ngerprint cannot be repeatedly added.
●
Up to 10 ngerprints can be added for one person.
●
You can also use the client soware or the ngerprint recorder to record ngerprints.
For details about the instrucons of scanning ngerprints, see Tips for Scanning Fingerprint .
7.
Tap to save the sengs.
6.3.6 Add PIN
Add a PIN for the user and the user can authencate via the PIN.
Before You Start
Note
Make sure the password mode is Device-Set Personal PIN or Plaorm-Applied Personal PIN. If you
select Device-Set Personal PIN, you can add PIN on the device or Web. If you select Plaorm-
Applied Personal PIN, you cannot add PIN on the device or Web, instead, you should add PIN on
the
plaorm. For details about seng the password mode, see Set Password Mode .
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID.
eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard and select department.
DS-K1T344 Series Face Recognion Terminal User Manual
53
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the PIN code and create a PIN for the user.
Note
Make sure the password mode is Device-Set Personal PIN, or the PIN area cannot be eded.
6.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
7.
Tap
to save the sengs.
6.3.7 Set Person Type via Device
Set the person type as basic person, visitor, person in blocklist, or custom type.
Before You Start
Login the device. For details, see .
Steps
1.
Tap Person → +.
DS-K1T344 Series Face Recognion Terminal User Manual
54
Figure 6-11 Add Person
2.
Tap Employee ID and you can edit the Employee ID.
DS-K1T344 Series Face Recognion Terminal User Manual
55
Note
The employee ID cannot be more than 32 characters. It can be a combinaon of upper case
leers, lower case leers, and digits.
3.
Tap Name and create a name. Enter the person’s name according to the pop-up keyboard.
Note
●
The name supports digits, upper case leers, lower case leers, and special characters.
●
The name should be within 128 characters.
4.
Set the face, card or ngerprint.
Note
●
Refers to , , and to add face, card, and ngerprint.
●
Only device with ngerprint module supports the ngerprint funcons.
5.
Tap Person Type and set the type as Basic Person, Visitor, Person in Blocklist or Custom Type.
Note
●
When seng the person to visitor, administrator cannot be set. If set the person as person in
blocklist, you cannot congure the door permission for the person.
●
Set the custom type’s name in PC web. Aer sengs, the custom type will change to the
congured name. For web sengs, see .
6.
Tap to save the sengs.
6.3.8 Set
Authencaon Mode
Aer adding the person's face picture, password, or other credenals, you should set the
authencaon mode and the person can authencate his/her identy via the congured
authencaon
mode.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap Person → Add Person/Edit Person → Authencaon Mode .
3.
Select Device or Custom as the
authencaon mode.
Device
If you want to select device mode, you should set the terminal authencaon mode in Access
Control
Sengs page rst. For details see Seng Access Control Parameters.
Custom
You can combine dierent authencaon modes together according to your actual needs.
4.
Tap to save the sengs.
DS-K1T344 Series Face Recognion Terminal User Manual
56
6.3.9 Search and Edit Person
Aer adding the person, you can search the person and edit it.
Search Person
On the Person Management page, Tap the search area to enter the Search Person page. Tap Card
on the
le of the page and select a search type from the drop-down list. Enter the employee ID,
card No., or the person name for search. Tap to search.
Edit Person
On the Person Management page, select a person from the person list to enter the Edit Person
page. Follow the steps in
Person Management to edit the person parameters. Tap to save the
sengs.
Note
The employee ID cannot be edited.
6.4 Data Management
You can delete data, import data, and export data.
6.4.1 Delete Data
Delete person data.
On the Home page, tap Data → Delete Data → Person Data . All person data added in the device
will be deleted.
6.4.2 Import Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, tap Data → Import Data .
3.
Tap Person Data, Face Data or Access Control Parameters .
Note
The imported access control parameters are conguraon les of the device.
4.
Enter the created password when you exported the data. If you do not create a password when
you exported the data, leave a blank in the input box and tap OK immediately.
DS-K1T344 Series Face Recognion Terminal User Manual
57
Note
●
If you want to transfer all person informaon from one device (Device A) to another (Device
B), you should export the informaon from Device A to the USB ash drive and then import
from the USB ash drive to Device B. In this case, you should import the person data before
imporng the prole photo.
●
The supported USB
ash drive format is FAT32.
●
The imported pictures should be saved in the folder (named enroll_pic) of the root directory
and the picture's name should be follow the rule below:
Card No._Name_Department_Employee ID_Gender.jpg
●
If the folder enroll_pic cannot save all imported pictures, you can create another folders,
named enroll_pic1, enroll_pic2, enroll_pic3, enroll_pic4, under the root directory.
●
The employee ID should be less than 32 characters. It can be a combinaon of lower leers,
upper leers, and numbers. It should not be duplicated, and should not start with 0.
●
Requirements of face picture should follow the rules below: It should be taken in full-face
view, directly facing the camera. Do not wear a hat or head covering when taking the face
picture. The format should be JPEG or JPG. The resoluon should be 640 × 480 pixel or more
than of 640 × 480 pixel. The picture size should be between 60 KB and 200 KB.
6.4.3 Export Data
Steps
1.
Plug a USB
ash drive in the device.
2.
On the Home page, tap Data → Export Data .
3.
Tap Face Data, Event Data, Person Data, or Access Control Parameters.
Note
The exported access control parameters are conguraon les of the device.
4.
Oponal: Create a password for exporng. When you import those data to another device, you
should enter the password.
Note
●
The supported USB ash drive format is DB.
●
The system supports the USB ash drive with the storage of 1 G to 256 G. Make sure the free
space of the USB ash drive is more than 512M.
●
The exported person data is a DB
le, which cannot be edited.
6.5 Person Authencaon
Aer network conguraon, system parameters conguraon and user conguraon, you can go
back to the
inial page for authencaon. The system will authencate person according to the
congured authencaon mode.
DS-K1T344 Series Face Recognion Terminal User Manual
58
6.5.1 Authencate via Single Credenal
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Note
The funcon are dierent according to dierent device models, refers to actual products.
Face
Face forward at the camera and start authencaon via face.
Fingerprint
Place the enrolled
ngerprint on the ngerprint module and start authencaon via ngerprint.
Card
Present the card on the card presenng area and start authencaon via card.
Note
The card can be normal IC card, or encrypted card.
QR Code
Put the QR code in front of the device camera to
authencate via QR code.
Note
●
Authencaon via QR code should be supported by the device.
●
You should enable QR code funcon in Preference Sengs .
PIN
Enter the PIN to authencate via PIN.
If authencaon completed, a prompt "Authencated" will pop up.
6.5.2
Authencate via Mulple Credenal
Before You Start
Set the user
authencaon type before authencaon. For details, see Set Authencaon Mode .
Steps
1.
If the authencaon mode is Card and Face, Password and Face, Card and Password, Card and
Face and Fingerprint, authencate any credenal according to the instrucons on the live view
page.
DS-K1T344 Series Face Recognion Terminal User Manual
59
Note
●
The card can be normal IC card, or encrypted card.
●
If the QR Code Scanning funcon is enabled, you can put the QR code in front of the device
camera to authencate via QR code.
2.
Aer the previous credenal is authencated, connue authencate other credenals.
Note
●
For detailed informaon about scanning ngerprint, see Tips for Scanning Fingerprint.
●
For detailed informaon about authencang face, see Tips When Collecng/Comparing Face
Picture.
If authencaon succeeded, the prompt "Authencated" will pop up.
6.6 Basic
Sengs
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
device home page. Tap System → Basic .
DS-K1T344 Series Face Recognion Terminal User Manual
60
Figure 6-12 Basic Sengs Page
DS-K1T344 Series Face Recognion Terminal User Manual
61
6.6.1 Enable/Disable Voice Prompt via Device
You can enable/disable the voice prompt funcon and adjust the voice volume.
Login the device. For details, see
Login .
Tap System Sengs → Basic → Sound Sengs.
You can enable Voice Prompt funcon and adjust the voice volume. Enable the voice prompt
funcon and you can set the voice volume.
6.6.2 Set Device Time via Device
Set the device me.
Login the device. For details, see Login .
Tap System Sengs → Basic → Time Sengs.
Set the device
me zone, current me, and DST.
6.6.3 Set Sleep
Duraon via Device
Set the device sleeping waing me.
Login the device. For details, see Login .
Tap System Sengs → Basic. And Set Sleep Duraon.
When you are on the
inial page and if you set the sleeping me to 30 s, the device will sleep aer
30 s without any operaon.
Note
If you set the sleeping me to 0, the device will not enter sleeping mode. The congurable sleep
me is between 20 and 999s.
6.6.4 Select Language
Login the device. For details, see Login .
Tap System Sengs → Basic . And tap Select Language to change the device language.
The device will reboot
aer changing the language.
6.6.5 Set Device Number via Device
The device can be used as access control device, door staon, or outer door staon. You can set
the device number for video intercom.
Login the device. For details, see
Login .
DS-K1T344 Series Face Recognion Terminal User Manual
62
Tap System Sengs → Basic. And set Community No., Building No., and Unit No.
6.6.6 Set Privacy Parameters via Device
Set the picture uploading parameters.
Note
Dierent device models support dierent funcons. Refers to actual model.
Login the device. For details, see .
Tap System → Basic → Privacy.
Authencaon
Sengs
Name / Employee ID / Face Picture
You can choose to display/not display name, employ ID, or face picture when authencang.
You can choose to desensize name and Employ ID when authencang.
Picture Uploading and Storage
Set picture uploading and storage parameters.
Save Registered Pic.
The registered face picture will be saved to the system if you enable the funcon.
Save Pic. Aer Linked Capture
If you enable this funcon, the captured pictures will be saved to the device automacally.
Upload Picture Aer Linked Capture
Upload the pictures captured aer linked capture.
Save Pic When Auth.
If you enable this
funcon, you can save the picture when authencang to the device.
Upload Pic. When Auth.
If you enable this funcon, you can save the picture when authencang to the device.
6.6.7 Set Video Standard
Set video standard for the live view.
Login the device. For details, see
Login .
Go to System → Basic → Video Standard。
Set the video frame rate when performing live view remotely.
Aer changing the standard, you
should reboot the device to take eect.
PAL (50HZ)
DS-K1T344 Series Face Recognion Terminal User Manual
63
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC (60HZ)
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
6.6.8 Set Secure Door Control Unit Parameters
You can wire peripherals according to the secure door control unit. You can set to use door 1 or
door 2 to control the secure door control unit.
Before You Start
Device is wiring the secure door control unit by RS-485. For detailed wiring method, see .
Steps
1.
Login the device. For details, see
Login .
2.
Go to System → Basic → Secure Door Control Unit.
3.
Select Door 1 or Door 2 as door No.
Note
Door 1 means that the door will be controlled by secure door control unit. The same goes to the
selecon of door 2.
6.7 Set Face Parameters
You can customize the face parameters to improve the face recognion performance.
Long tap on the
inial page for 3 s and login the home page. Tap System Sengs → Biometrics .
DS-K1T344 Series Face Recognion Terminal User Manual
64
Figure 6-13 Face Sengs
6.7.1 Set Face Liveness Level via Device
Aer enabling face an-spoong funcon, you can set the matching security level when
performing live face
authencaon.
DS-K1T344 Series Face Recognion Terminal User Manual
65
Login the device. For details, see .
Tap System → Biometrics.
Select a face liveness level.
You can select from general, advanced, and professional. The higher the level, the fault acceptance
rate will be lower and the false rejecon rate will be higher.
6.7.2 Set Recognion Distance via Device
Set the valid distance between the user and the camera when authencang.
Login the device. For details, see .
Tap System → Biometrics → Recognion Distance.
Set the
recognion distance.
6.7.3 Set Face
Recognion Interval via Device
The me interval between two connuous face recognions when authencang.
Login the device. For details, see .
Tap System → Biometrics → Face Recognion Interval (sec).
Set the face recognion interval.
Note
Please enter a number between 1 and 10.
6.7.4 Set Face 1:N Security Level via Device
Set the matching threshold when authencang via 1:N matching mode.
Login the device. For details, see .
Tap System → Biometrics → Face 1: N Security Level.
Set the matching threshold when
authencang via 1:N matching mode.
The larger the value, the smaller the false accept rate and the larger the false
rejecon rate. The
maximum value is 100.
6.7.5 Set Face 1:1 Security Level via Device
Set the matching threshold when
authencang via 1:1 matching mode.
Login the device. For details, see .
Tap System → Biometrics → Face 1: 1 Security Level.
DS-K1T344 Series Face Recognion Terminal User Manual
66
Set the matching threshold when authencang via 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the false rejecon rate. The
maximum value is 100.
6.7.6 Enable/Disable ECO Mode via Device
If the ECO mode is enabled, you can authencate faces in the low light or dark environment with IR
camera.
Login the device. For details, see .
Tap System → Biometrics → ECO Mode Sengs.
If the ECO mode is enabled, you can
authencate faces in the low light or dark environment with IR
camera. You can set the ECO mode threshold, ECO mode (1:N), and ECO mode (1:1).
ECO Mode Threshold
When enabling the ECO mode, you can set the ECO mode’s threshold. The larger the value, the
easier the device entering the ECO mode. The threshold has
relaonship with the illuminaon.
ECO Mode (1:1)
Set the matching threshold when authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false
rejecon rate. The maximum
value is 100.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false
rejecon rate. The maximum
value is 100.
6.7.7 Enable/Disable Face Mask
Detecon via Device
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture.
Login the device. For details, see .
Tap System → Biometrics → Mask
Sengs.
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture. You can set Face with Mask & Face (1:1)、Face with Mask & Face (1:N)、ECO Mode (1:1)
Threshold、ECO Mode (1:N) Threshold, and Prompt Method.
Face with Mask & Face (1:1)
Set face with mask 1:1 matching threshold. The larger the value, the smaller the false accept
rate and the larger the false
rejecon rate. The maximum value is 100.
Face with Mask & Face (1:N)
DS-K1T344 Series Face Recognion Terminal User Manual
67
Set face with mask 1:N matching threshold. The larger the value, the smaller the false accept
rate and the larger the false rejecon rate. The maximum value is 100.
ECO Mode (1:1) Threshold
Aer enabling the ECO mode, you can set the face with mask funcon. You can set the
threshold.
Set the matching threshold when authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false
rejecon rate. The maximum
value is 100.
ECO Mode (1:N) Threshold
Aer enabling the ECO mode, you can set the face with mask funcon. You can set the
threshold.
Set the matching threshold when
authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate. The maximum
value is 100.
Prompt Method
Set None、Reminder of Wearing, and Must Wear.
None
If the person do not wear a face mask when
authencang, the device will not prompt a
nocaon.
Reminder of Wearing Face Mask
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door keeps closed.
6.8 Access Control
Sengs
You can set the access control permissions.
On the Home page, tap ACS to enter the
Sengs page.
DS-K1T344 Series Face Recognion Terminal User Manual
68
Figure 6-14 Access Control Sengs
6.8.1 Set Terminal
Authencaon Mode via Device
Select the face recognion terminal's authencaon mode. You can select dierent combinaon to
authencate.
Login the device. For details, see Login .
Tap ACS → Terminal Auth. Mode .
Select person
authencaon type and method and save the sengs.
DS-K1T344 Series Face Recognion Terminal User Manual
69
If all persons on the device’s authencaon mode is Device Mode, all persons on the device will
use the device authencaon mode. For detail about person authencaon mode sengs, see Set
Authencaon Mode .
Note
Device with ngerprint module supports ngerprint funcon.
Cauon
Biometric recognion products are not completely applicable to an-spoong environments. If you
require a higher security level, use mulple authencaon modes.
6.8.2 Set Reader Authencaon Mode via Device
Set the person authencaon type on the wired external reader. You can select dierent
combinaon to authencate.
Login the device. For details, see Login .
Tap ACS → Reader Auth. Mode .
Select person authencaon type and save the sengs.
Select person authencaon type and method and save the sengs.
If all persons on the device’s authencaon mode is Device Mode, all persons on the device will
use the device
authencaon mode. For detail about person authencaon mode sengs, see Set
Authencaon Mode .
Note
Device with ngerprint module supports ngerprint funcon.
Cauon
Biometric recognion products are not completely applicable to an-spoong environments. If you
require a higher security level, use mulple authencaon modes.
6.8.3 Enable/Disable NFC Card
Enable/disable NFC card funcon.
Aer login, tap ACS.
Tap Enable NFC.
Aer enabling, the device can read NFC card.
DS-K1T344 Series Face Recognion Terminal User Manual
70
6.8.4 Enable/Disable M1 Card
Enable or disable M1 card funcon.
Login the device. For details, see Login .
Aer login, tap ACS.
Tap Enable M1 Card, and the device can read M1 card.
Enable M1 Card
Aer enabling, the device can read M1 card.
M1 Card Encrypon
Aer enabling M1 Card Encrypon, the device will verify the M1 card sector. Go to the plaorm
to set the M1 card’s encrypon sector.
6.8.5 Set
Authencaon Interval via Device
Login the device. For details, see Login .
Tap ACS, and set Authencaon Interval and save.
You can set the
authencaon interval of the same person when authencang. The same person
can only authencate once in the congured interval. A second authencaon will be failed.
Available
authencaon interval range: 0 to 65535.
6.8.6 Set
Authencaon Result Display Duraon via Device
Set the authencaon result display duraon when authencang.
Login the device. For details, see Login .
Tap ACS, and set Authencaon Result Display Duraon and save.
6.8.7 Set Password Mode
You can set the password mode and choose whether to edit password on device / PC web, or
plaorm.
Steps
1.
Login the device. For details, see Login .
2.
Tap ACS.
3.
Tap Password Mode and set the mode.
Plaorm-Applied Personal PIN
The PIN is managed and distributed by the plaorm aer the device accesses the plaorm.
Device-Set Personal PIN
DS-K1T344 Series Face Recognion Terminal User Manual
71
The PIN is set on the device or PC Web.
4.
Go back to the previous page to save the sengs.
6.8.8 Set Door Contact via Device
Select door contact status according to the door contact’s wiring method.
Login the device. For details, see Login .
Tap ACS.
You can select Remain Open or Remain Closed according to your actual needs. By default, it is
Remain Closed.
6.8.9 Set Open
Duraon via Device
Set the door unlocking duraon.
Login the device. For details, see Login .
Tap ACS.
Set the door unlocking
duraon. If the door is not opened for the set me, the door will be locked.
Available door locked me range: 1 to 255s.
6.9 Preference
Sengs
You can congure preference sengs parameters.
Steps
1.
Tap System → Preference to enter the preference sengs page.
DS-K1T344 Series Face Recognion Terminal User Manual
72
Figure 6-15 Preference Sengs
6.9.1 Set Shortcut Key via Device
Choose the shortcut key that displayed on the authencaon page, including the QR code
funcon, the call funcon, call type, and the password entering funcon.
Login the device. For details, see .
Tap System → Preference → Shortcut Key.
Choose the shortcut key that displayed on the authencaon page, including the QR code
funcon, the call funcon, call type, and the password entering funcon.
DS-K1T344 Series Face Recognion Terminal User Manual
73
Figure 6-16 Shortcut Key Sengs
Password
Enable this funcon and you can enter the password to authencate via password. Tap on
the
authencaon page to verify.
QR Code
You can use the QR code scanning funcon on the authencaon interface. The device will
upload the informaon associated with the obtained QR code to the plaorm. Tap on the
authencaon page to verify.
Call
You can select call types from Call Room, Call Center, Call
Specied Room, or Call APP. If you
select Call Specied Room, you should enter the room No.
Tap on the authencaon page to call.
6.9.2 Theme
Select dierent theme and the authencaon page will show dierent contents.
DS-K1T344 Series Face Recognion Terminal User Manual
74
Login the device. For details, see .
Tap System → Preference → Theme Mode.
Select a theme mode.
Authencaon
The live view will be displayed in authencaon, and in the meanwhile, the person's name,
employee ID, face pictures will all displayed as well.
Simple Mode
Aer selecng this mode, the live view of the authencaon page will be disabled. The person's
name, employee ID, face pictures will be hidden aer authencaon.
6.10 System Maintenance
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint.
6.10.1 View System
Informaon
View the device system informaon.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → System Info. .
You can view the device model, serial No., versions, address,
producon data, QR code, and open
source code license.
Note
The page may vary according to dierent device models. Refers to the actual page for details.
Long tap on the right corner to enter the advanced sengs page. You can set Face parameters
and view the device Version
Informaon.
Face
Custom An-Spoong Detecon
You can set Face Liveness Level, An-Spoong Detecon Threshold, and An-Spoong
Detecon
Threshold of Face with Mask.
Note
You can set the value between 1 and 100. The smaller the value, the larger the false accept
rate and the smaller the false rejecon rate. The larger the value, the smaller the false accept
rate and the larger the false rejecon rate.
Lock Face for An-Spoong Protecon
DS-K1T344 Series Face Recognion Terminal User Manual
75
Aer enabling this funcon, the device will lock automacally when an-spoong detecon
failed.
Locking Duraon
Set the lock duraon aer enabling Lock Face for An-Spoong Protecon when an-
spoong detecon failed.
Version Informaon
You can view the device version.
6.10.2 View Device Capacity via Device
You can view the device capacity.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → Capacity.
You can view the capacity of person, face picture, card, ngerprint and event.
Note
Only device installed with ngerprint module supports display ngerprint capacity.
6.10.3 Upgrade
Online Upgrade
You can online upgrade the device.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → Device Upgrade.
If the device is connected to the network and added to Hik-Connect App, you can tap Device
Upgrade → Online Upgradeon device for upgrading when there is an updated version in Hik-
Connect App.
Local Upgrade
You can upgrade the device locally.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → Device Upgrade.
Insert an USB
ash drive. Tap Device Upgrade → Update vi USB, and the device will read the
digicap.dav le in the USB ash drive to start upgrading.
DS-K1T344 Series Face Recognion Terminal User Manual
76
6.10.4 View User Manual
You can view the QR code of the user manual.
Tap System Maintenance → User Manual , scan the QR code to view the user manual.
6.10.5 Restore Sengs
Restore to Factory Sengs via Device
All parameters will be restored to the factory sengs.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → Restore to Factory Sengs. The system will reboot to take eect.
Restore to Default
Sengs via Device
All parameters, except for the communicaon sengs, remotely imported user informaon, will
be restored to the default sengs.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → Restore to Default Sengs. The system will reboot to take eect.
All parameters, except for the communicaon sengs, remotely imported user informaon, will
be restored System default sengs. System will reboot aer restoring the default sengs.
Device Reboot
You can reboot the device manually.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
home page. Tap Maint. → Reboot.
6.11 Video Intercom
Aer adding the device to the client soware, you can call the device from the client soware, call
the main staon from the device, call the client soware from the device, or call the indoor staon
from the device.
DS-K1T344 Series Face Recognion Terminal User Manual
77
6.11.1 Call Client Soware from Device
Steps
1.
Get the client
soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the device to the client
soware.
Note
For details about adding device, see Add Device.
5.
Call the client soware.
1) Tap on the device inial page.
2) Enter 0 in the pop-up window.
3) Tap
to call the client soware.
6.
Tap Answer on the pop-up page of the client soware and you can start two-way audio between
the device and the client
soware.
Note
If the device is added to mulple client sowares and when the device is calling the client
soware, only the rst client soware added the device will pop up the call receiving window.
6.11.2 Call Center from Device
Steps
1.
Get the client soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the main
staon and the device to the client soware.
Note
For details about adding device, see Add Device.
5.
Set the main staon's IP address and SIP address in the remote conguraon page.
Note
For details about the operaon, see the user manual of the main staon.
6.
Call the center.
-
If you have congured to call center in the Basic Sengs , you can tap to call the center.
-
If you have not
congured to call center in the Basic Sengs , you should tap → to call
the center
7.
Answers the call via the main
staon and starts two-way audio.
DS-K1T344 Series Face Recognion Terminal User Manual
78
Note
The device will call the main staon in priority.
6.11.3 Call Device from Client Soware
Steps
1.
Get the client soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management page.
4.
Add the device to the client
soware.
Note
For details about adding device, see Add Device.
5.
Enter the Live View page and double-click the added device to start live view.
Note
For details about operaons in the Live View page, see Live View in the user manual of the client
soware.
6.
Right click the live view image to open the right-click menu.
7.
Click Start Two-Way Audio to start two-way audio between the device and the client soware.
6.11.4 Call Room from Device
Steps
1.
Get the client
soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the indoor
staon and the device to the client soware.
Note
For details about adding device, see Add Device.
5.
Link a user to an indoor staon and set a room No. for the indoor staon.
6.
Call the room.
-
If you have
congured a specied room No. in the Basic Sengs , you can tap to call the
room.
-
If you have not congured a specied room No. in the Basic Sengs , you should tap on
the
authencaon page of the device. Enter the room No. on the dial page and tap to call
the room.
7.
Aer the indoor staon answers the call, you can start two-way audio with the indoor staon.
DS-K1T344 Series Face Recognion Terminal User Manual
79
6.11.5 Call Mobile Client from Device
Steps
1.
Get the mobile mobile client from the supplied disk or the
ocial website, and install the
soware according to the prompts.
2.
Run the mobile client and add the device to the mobile client.
Note
For details, see the user manual of the mobile client.
3.
Enter Basic Sengs → Shortcut Key and enable Call APP.
4.
Go back to the
inial page and call the mobile client.
1) Tap on the device inial page.
2) Tap to call the mobile client.
DS-K1T344 Series Face Recognion Terminal User Manual
80
Chapter 7 Congure Device via Mobile Web
7.1 Login
You can login via mobile browser.
Note
●
Make sure the device is acvated. For details, see .
●
Enable the device Wi-Fi funcon and set an IP for the device. Make sure the device and the
mobile phone are in the same Wi-Fi. For details, see .
Enter the device IP address in the address bar of the mobile browser and press Enter to enter the
login page.
Or aer enabling the device hotspot, you can search the device hotspot in the phone Wi-Fi sengs
page, enter the device acvaon password to enter the login page. For details, see Set Device
Hotspot .
Enter user name and device password, and tap Login.
7.2 Forget Password
If you forget the password when logging in, you can change the password by security quesons.
Steps
1.
On the login page, tap Forget Password.
2.
Select
Vericaon Mode.
Security Queson Vericaon
If you have set security quesons on the device or mobile web, you can enter the answers to
reset the password. Tap Security
Queson Vericaon, and tap Next.
3.
Enter the answer of the security queson, and tap Next.
4.
Enter the new password and
conrm it.
5.
Tap Next.
7.3 Account Security
Sengs
Change the reserved phone No. and when you forgot the password, you can use the phone No. to
change the login password.
DS-K1T344 Series Face Recognion Terminal User Manual
81
Steps
Note
Only the device and the phone are in the same LAN, can you see the sengs.
1.
Tap → User Management → → Account Security Sengs.
2.
Select a password reset method and start to edit.
-
Security Queson: Edit the answer of the quesons. When you forget your password, you can
use the answers to change the password.
-
E-mail Address: Download mobile app and go to More -> Reset Device Password. Scan the QR
code on the device and a vericaon code will be popped up. When you forget your login
password, you can enter the phone No. to change the password.
3.
Tap Save.
7.4 Home
You can view the door status, enter the conguraon page via shortcut entry, view the network
status, and view basic
informaon.
Door Status
You can view the door status. And control the door status.
Shortcut Entry
Tap the conguraon funcon name and enter the page.
Network Status
You can view the network connecon status.
Basic
Informaon
You can view the device model, serial No., and version, or enter the basic informaon page.
7.5
Conguraon
7.5.1 View Device Informaon
View the device name, language, model, serial No., version, number of channels, IO input number,
local RS-485 number, register No., Mac address, factory informaon and device capacity, etc.
On the home page, tap
→ System Sengs → Basic Informaon.
View the device name, language, model, serial No., version, number of channels, IO input number,
local RS-485 number, register No., Mac address, factory
informaon and device capacity, etc.
Tap Save.
DS-K1T344 Series Face Recognion Terminal User Manual
82
7.5.2 Set Device Time
Set the me zone of the device and the device current me.
Tap → System Sengs → Time Sengs.
Figure 7-1 Time Sengs
Time Zone
Tap to select a me zone for the device.
Time Sync. Mode
Manual
By default, manually synchronizaon is checked, you can set the device me manually.
NTP
You should Set the NTP server’s IP address, NTP port, and interval.
Tap Save.
7.5.3 User Management
Changed the user’s password.
On the home page, tap → User Management.
Tap the user, enter the old password, create a new password and conrm the password. Tap Save.
DS-K1T344 Series Face Recognion Terminal User Manual
83
7.5.4 Network Sengs
Set Wired Network Parameters
Set wired network parameters of the device.
Before You Start
The device is connected to a wired network.
Steps
1.
On the home page, tap
→ Communicaon Sengs → TCP/IP .
2.
Set the wired network parameters.
NIC Type
Select a NIC type from the drop-down list. By default, it is
self-adapve.
DHCP
If disable the funcon, you should manually set IPv4 address, IPv4 subnet mask. IPv4 default
gateway, MTU, and Mac address.
If enabled the funcon, the system wil allocate IPv4 address, IPv4 subnet mask, IPv4 default
gateway, and MTU.
Preferred DNS Server and Alternate DNS Server
Set the DNS server IP.
3.
Tap Save.
Set Wi-Fi
Sengs
Set the Wi-Fi parameters of the device.
Before You Start
Aer the device is added to the App, you can enabled the device Wi-Fi funcon. And then you can
set eh Wi-Fi parameters in the mobile web.
Steps
1.
On the home page, tap → Communicaon Sengs → Wi-Fi.
2.
Enable Wi-Fi.
3.
Select a Wi-Fi in the list and enter the password to connect.
4.
Oponal: Add a Wi-Fi.
1) Slide the page to the end and tap Add Network.
2) Enter Wi-Fi Name, and select the Wi-Fi’s
Encrypon Type.
3) Tap OK.
5.
Oponal: Set WLAN.
1) Set the connected Wi-Fi’s name, and view the network details.
DS-K1T344 Series Face Recognion Terminal User Manual
84
2) Tap WLAN Sengs.
3) Set the WLAN parameters.
Enable DHCP
Enable DHCP to Auto DNS, the device will allocate the IP and DNS automacally.
Disable DHCP
Manually set the IP and DNS server.
4) Tap Save.
Result
Aer Wi-Fi and WLAN sengs, you can enter the WLAN IP address in the mobile browser to login
the device.
Device Hotspot
Aer enabling the device hotspot, you can use the mobile phone to connect the hotspot and set.
Note
You can set the parameters only when you connect the device by hotspot. If you login the device
by IP address, the funcon is not supported.
On the home page, tap → Network Sengs → Device Hotspot.
Enable Device Hotspot and tap Save.
The device will in hotspot mode. The indicator will
ash green.
If disable the
funcon, the indicator will remain green.
Set Port
You can set HTTP Port, RTSP Port, HTTPS Port, and Server Port. When accessing the device through
the network, you can set the corresponding port according to your needs.
On the home page, tap
→ Network Service → HTTP(S).
HTTP Port
When you log in with a browser, you need to add the
modied port number aer the address.
For example, when the HTTP port number is changed to 81, you need to enter hp://
192.0.0.65
：81 when you log in with a browser.
HTTPS Port
Set the HTTPS port for vising browser. But cercaon is required.
DS-K1T344 Series Face Recognion Terminal User Manual
85
Cloud Service Accessing
The device can communicate via cloud service. You can add the device to mobile client and
operate.
Steps
1.
Tap
→ Device Access → Hik-Connect → Guarding Vision .
2.
Check Enable.
3.
Oponal: You can enable Custom and edit the server IP address.
4.
Oponal: View the network connecon status.
5.
Oponal: You can select to enable video encrypon, and set the video encrypon password.
Note
Aer the device adding to the mobile App, if you need to start live view, you should enter the
video encrypon password.
6.
Oponal: Tap Link with Account and view the device QR code. Use the App to scan the QR code
to add the device.
7.
Tap Save.
Set ISUP Parameters
Set the ISUP parameters for transming logs via ISUP protocol.
Tap
→ Device Access → ISUP.
Slide Enable to enable ISUP.
Set the server address and port.
Note
The protocol version is 5.0, you should set the encrypon key.
Tap Save.
DS-K1T344 Series Face Recognion Terminal User Manual
86
Figure 7-2 ISUP Sengs Page
Set OTAP Protocol
You can access the device to the maintenance plaorm by OTAP protocol to realize searching and
gaining device informaon, uploading device running status and excepons, reboong and
upgrading.
Steps
1.
Tap
→ Device Access → OTAP .
DS-K1T344 Series Face Recognion Terminal User Manual
87
Figure 7-3 OTAP
2.
Slide Enable.
3.
Set server address, port, device ID and encrypon key.
4.
Tap Test, and make sure the device can connect to the server and
registraon completed.
5.
Tap Save.
Result
Refresh the web page or reboot the device to make sure the OTAP’s Register Status turns to online.
VoIP
Sengs
Devices in dierent network segments can communicate with each other via the server. If not
registered to the VoIP, the terminals can only communicate with each other in the same network
segment.
Aer registering to the VoIP server completed, terminals can call each other via by
entering VoIP ID.
Steps
1.
Tap → Device Access → VoIP .
2.
Enable VOIP.
3.
Enter Registered User Name and
Registraon Password of the VoIP server.
4.
Set VoIP server’s Server IP Address and Server Port.
5.
Oponal: Set Expiry Time and view the Register Status.
6.
Create a Number and Display User Name.
7.
Tap Save.
7.5.5 Add Person
Add Person Basic Informaon
Tap → Person Management → +.
DS-K1T344 Series Face Recognion Terminal User Manual
88
Create person employee ID, name, oor No., and room No.
Tap Save.
Set Person Permission
Tap → Person Management → +.
Enable Long-Term Eecve User and set the start me and end me of the person.
Tap Save.
Set Administrator
Tap → Person Management.
Enable Administrator and the person can use the
credenal to login the device.
Tap Save.
Select User Role.
Tap → Person Management → +.
Tap User Role and set the type as Normal User, Visitor, Person in Blocklist or Custom Type.
Note
●
When seng the person to visitor, administrator cannot be set. If set the person as person in
blocklist, you cannot congure the door permission for the person.
●
Set the custom type’s name in PC web. Aer sengs, the custom type will change to the
congured name. For web sengs, see .
Add Face Picture
Tap → Person Management → + → Face.
Tap Camera to add a face picture. Or tap Choose from Album to select a face picture from the
phone photo library.
Tap Add.
Add Fingerprint
Tap → Person Management → + → Fingerprint.
Tap + and put your
nger on nger recognion module.
Add Card
Tap → Person Management → + → Card.
Tap +, enter the card No. and select a card property (type).
Tap Save.
Add PIN
Note
Before conguring passwords, it is necessary to clarify whether the password is a device-set
personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created
DS-K1T344 Series Face Recognion Terminal User Manual
89
or edited on the device or on the web, and cannot be set on other plaorms; If it is a plaorm-
applied personal PIN, it can be created or edited on the plaorm, and issued to the device before it
can be used. It cannot be set on the device or on the web.
Tap → Person Management → +.
Enter PIN in the PIN entering area.
7.5.6 Event Search
Tap → Event Search.
Enter the search condions, including the employee ID, the name, the card No., the start me, and
the end
me, and tap Search.
Note
Support searching for names within 32 digits.
The result will display in the list.
7.5.7 Audio
Sengs
You can enable or adjust the audio.
Tap
→ Audio.
Enable Enable Voice Prompt according to actual needs. The device will prompt voice instrucons.
You can also adjust the audio volume.
7.5.8 Access Control
Sengs
Set Authencaon Parameters
Set authencaon parameters.
Steps
1.
Tap → Access Control → Authencaon Sengs.
2.
Aer sengs, tap Save.
If select Terminal as Main Card Reader.
Terminal
Select terminal for
sengs.
Terminal Type
Display the terminal’s type. Read only.
Terminal Model
DS-K1T344 Series Face Recognion Terminal User Manual
90
When the terminal is online, it will display the terminal's model, or it will display oine.
(Read-only)
Enable Authencaon Device
If enable the funcon, you can authencate credenal on the terminal; or you cannot use
credenal to authencate.
Authencaon Mode
Select an authencaon mode according to your actual needs from the drop-down list.
Connuous Face Recognion Interval
Set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, the same person can only recognized once.
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only
authencate once in the congured interval. A second authencaon will be
failed. If there is another person authencate in the congured interval, the person can
authencate again.
Alarm of Max. Failed Aempts/Max. Authencaon Failed Aempts
Enable Alarm of Max. Failed Aempts and you can set the max. authencaon failed
aempts. When the authencaon aempts reach the set value, the authencaon will be
failed and report to center.
Home Page Mode
You can set the device home page as
Authencaon Mode or Simple.
Authencaon Mode
If select Authencaon Mode, the authencaon page will display the live view page
only.
Simple
Aer selecng this mode, the live view of the authencaon page will be disabled. The
person's name, employee ID, face pictures will be hidden aer authencaon.
Enable Tampering Detecon
Aer enabling the funcon, when the card reader is removed, an alarm will be triggered. If
the
funcon is disabled, the alarm will not be triggered.
Enable Card No. Reversing
The card No. will be in reverse sequence aer enabling the funcon.
If select Terminal as Sub Card Reader.
Terminal
Select terminal for sengs.
Terminal Type
Display the terminal’s type. Read only.
DS-K1T344 Series Face Recognion Terminal User Manual
91
Terminal Model
When the terminal is online, it will display the terminal's model, or it will display oine.
(Read-only)
Enable Authencaon Device
If enable the funcon, you can authencate credenal on the terminal; or you cannot use
credenal to authencate.
Authencaon Mode
Select an
authencaon mode according to your actual needs from the drop-down list.
Connuous Face Recognion Interval
Set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, the same person can only recognized once.
Alarm of Max. Failed Aempts/Max. Authencaon Failed Aempts
Enable Alarm of Max. Failed Aempts and you can set the max. authencaon failed
aempts. When the authencaon aempts reach the set value, the authencaon will be
failed and report to center.
Home Page Mode
You can set the device home page as Authencaon Mode or Simple.
Authencaon Mode
If select Authencaon Mode, the authencaon page will display the live view page
only.
Simple
Aer selecng this mode, the live view of the authencaon page will be disabled. The
person's name, employee ID, face pictures will be hidden
aer authencaon.
Communicaon with Controller Every
If the card reader cannot communicate with the controller within the congured me
duraon, the card reader will be regarded as oine.
Max. Interval When Entering Password
Set the maximum interval of entering 2 characters of the PIN. Aer entering one character, if
the next character is not entered within the set interval, the entered characters will all be
automacally cleared.
OK LED Polarity/Error LED Polarity
Select anode or cathode of the main board.
Enable Tampering Detecon
Aer enabling the funcon, when the card reader is removed, an alarm will be triggered. If
the
funcon is disabled, the alarm will not be triggered.
DS-K1T344 Series Face Recognion Terminal User Manual
92
Set Door Parameters
Set door parameters, including door name, open duraon, exit buon type, door remain open
duraon with rst person, door open meout alarm, door contact, extended open duraon, duress
code, super password.
Tap → Access Control → Door Parameters.
Aer sengs, tap Save.
Name
Create a name for the door.
Open
Duraon
Set the door unlocking duraon aer swiping the card.
Exit Buon Type
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Door Remain Open
Duraon with First Person
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Door Opening Timeout Alarm Threshold
If the door is not closed aer reaching the lock acon me, the access control point will sound
an alarm. When set as 0, alarm will not be enabled.
Door Contact
You can set the door contact as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Closed.
Door Lock Powering
O
You can set the door lock status when the door lock is powering o. By default, it is Remain
Closed.
Extended Open
Duraon
The door contact can be enabled with appropriate delay aer person with extended access
needs swipes her/his card.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
Administrator or designated person can enter the super password to open the door.
Note
Duress code and super password can’t be duplicated, usually consisng of 4 to 8 digits.
DS-K1T344 Series Face Recognion Terminal User Manual
93
Set Terminal Parameters
You can set terminal parameters for accessing.
Tap
→ Access Control → Terminal Parameters.
Working Mode
You can set Working Mode as Access Control Mode.
Access Control Mode
The access control mode is the device normal mode. You should
authencate your credenal
for accessing.
Tap Save.
Set RS-485 Parameters
You can connect to access controller ,extension module, or card reader via RS-485. Set the RS-485
parameters and connect to other devices.
Tap → Access Control → RS-485 .
Aer sengs, tap Save.
Peripheral Type
Select a peripheral from the drop-down list according the actual situaon. You can select from
Card Reader, Extension Module or Access Controller.
Note
Aer changing the device type, when you save the parameters, the device will reboot.
RS-485 Address
Set the RS-485 address.
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
Baud Rate
The baud rate when the devices are communicang via the RS-485 protocol.
Data Bit
The data bit when the devices are communicang via the RS-485 protocol.
Parity/Flow Ctrl/Communicaon Mode
Enabled by default.
Output Type
DS-K1T344 Series Face Recognion Terminal User Manual
94
Set the output type according to your actual needs.
Set Card Security
Set the device card parameters.
在手机网页端主页点页
→ 门禁配置 → 卡片安全。
配置卡片相关参数，点页保存。
Enable NFC Card
The device can read NFC card. If the data of access control devices is obtained by mobile
devices, the
situaon of unauthencated access may occur. To prevent this situaon, you can
disable NFC funcon. 通页启用 NFC 功能，使页禁页页页页受保页。
启用 M1 卡
Aer enabling, the device can recognize M1 card and users can swipe M1 card via the device.
M1 Card Encrypon
Enable M1 Card Encrypon can improve the security level of the entrance card. Therefore, the
entrance card will be harder to be copied. Set the sector No.
Sector
Aer enabling M1 Card Encrypon, you will need to set the encrypted sector.
Note
You are advised to encrypt sector 13.
Enable EM Card
Aer enabling, the device can recognize EM card and users can swipe EM card via the device.
Note
If the peripheral card reader which can read EM card is connected, aer enabling this funcon,
you can also swipe EM card via this card reader.
Enable CPU Card
Aer enabling, the device can recognize CPU card and users can swipe CPU card via the device.
CPU Card Read Content
Aer enabling, the device can read content from CPU card.
Enable ID Card
启用身份页后，页页可页页身份页，用页可在页页上刷身份页。
DS-K1T344 Series Face Recognion Terminal User Manual
95
7.5.9 Video Intercom Sengs
Set Device No. via Mobile Web
The device can be used as access control device, door staon, or outer door staon. You can set
the device number for video intercom.
Tap → Intercom → Device ID Sengs.
Tap Save.
If select the device type as Door
Staon or Access Control Device, you can set the device period
No., building No., unit No., oor No., and door staon No.
Device Type
The device can used as door
staon. You can select other device type from the drop-down list.
Community No.
Enter the device community No. (period No.)
Building No.
Enter the device building No.
No.
Customize device No.
Note
●
If the device type is Door Staon or Access Control Device, the No. should be between 0 and
99.
●
Aer changing the device type or No., you should reboot the device to take eect.
Unit No.
Enter the device unit No.
Floor No.
Enter the device oor No.
If select the device type as Outer Door Staon , you can set the device period No., and outer door
staon No.
Device Type
The device can used as out door staon. You can select other device type from the drop-down
list.
Community No.
Enter the device community No. (period No.)
No.
DS-K1T344 Series Face Recognion Terminal User Manual
96
Customize device No.
Note
●
If the device type is Outer Door Staon, the No. should be between 1 and 99.
●
Aer changing the device type or No., you should reboot the device to take eect.
Note
Aer changing the device type or No., you should reboot the device to take eect.
Session Sengs
You can set the registraon password, main staon IP and private server IP, and you can enable
protocol 1.0 according to your actual needs.
Tap
→ Intercom → Session Sengs.
Registraon Password
Set the registraon password of the main staon for communicaon. Set the registraon
password of the main staon for communicaon.
Main Staon IP
Enter the main staon’s IP address that used for communicaon.
Private Server IP
Refers to the SIP server IP. Enter the main staon’s IP address that used for communicaon. At
this me the main staon is used as a SIP server. Other intercom devices should registered to
this server address to realize communicaon.
Aer
conguraon, you can achieve communicaon between access control devices and video
intercom door staon, indoor staon, main staon, plaorms, etc.
Tap Save.
Call
Sengs
you can set Max. communicaon duraon between the main staon and other devices.
Tap
→ Intercom → Call Sengs.
Max. Communicaon Time
The Maximum communicaon me when the main staon and the other devices are in the call.
When the communicaon me exceeds the congured me, the communicaon will stop. The
Max.
communicaon me range is 90 s to 120 s.
DS-K1T344 Series Face Recognion Terminal User Manual
97
Number Sengs
Set SIP number for the room. The rooms can communicate with each other via SIP number.
Steps
1.
Tap → Intercom → Number Sengs.
2.
Enter Room No. and SIP Number1.
3.
Tap Save.
4.
Oponal: Tap the congured room No., edit or tap +Add to add another SIP number.
5.
Oponal: Tap Delete to delete room number.
Press
Buon to Call via Mobile Web
You can press the buon to call.
Steps
1.
Tap → Intercom → Press Buon to Call.
2.
Tap 1 to enter the page.
Note
●
When you check Call Specied Indoor Staon, you should set the linked room’s No.
●
By default, you can press the buon to call indoor staon, and hold the buon to call center.
3.
Select the item that the buon linked to. When select Call Specied Indoor Staon, you should
set the room’s No.
4.
Tap Save.
7.5.10 Set Face Parameters
Set face recognion parameters.
Tap → Smart → Access Control Parameters.
The
funcons vary according to dierent models. Refers to the actual device for details.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not. You can select from general, advanced, and
professional. The higher the level, the fault acceptance rate will be lower and the false
rejecon
rate will be higher.
Face 1:1 Security Level
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate. The maximum value is
100.
DS-K1T344 Series Face Recognion Terminal User Manual
98
Face 1:N Security Level
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false
rejecon rate. The maximum value is
100.
Face Recognion Timeout Value
Congure the meout period for face recognion. If the face recognion me exceeds the
congured value, the device will prompt the face recognion meout.
Tap Save.
7.5.11 Enable/Disable Masl Detecon via Device
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture.
Tap
→ Smart → Face Mask Detecon Parameters.
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture. You can set Face with Mask&Face (1:1)、Face with Mask 1:N Matching Threshold, Face
with Mask&Face (1:1 ECO), Face with Mask 1:N Matching Threshold (ECO Mode), and Face
without Mask Strategy.
Tap Save.
Face with Mask&Face (1:1)
Set face with mask 1:1 matching threshold. The larger the value, the smaller the false accept
rate and the larger the false
rejecon rate. The maximum value is 100.
Face with Mask 1:N Matching Threshold
Set face with mask 1:N matching threshold. The larger the value, the smaller the false accept
rate and the larger the false rejecon rate. The maximum value is 100.
Face with Mask 1:1 Match Threshold (ECO)
Aer enabling the ECO mode, you can set the face with mask funcon. You can set the
threshold.
Set the matching threshold when
authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false
rejecon rate. The maximum
value is 100.
Face with Mask 1:N Match Threshold (ECO)
Aer enabling the ECO mode, you can set the face with mask funcon. You can set the
threshold.
Set the matching threshold when
authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false
rejecon rate. The maximum
value is 100.
Face without Mask Strategy
DS-K1T344 Series Face Recognion Terminal User Manual
99
Set None、Reminder of Wearing, and Must Wear.
None
If the person do not wear a face mask when authencang, the device will not prompt a
nocaon.
Reminder of Wearing Face Mask
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door will open.
Must Wear Face Mask
If the person do not wear a face mask when
authencang, the device prompts a
nocaon and the door keeps closed.
7.5.12 Set Privacy Parameters
Set the display parameters, picture upload and storage parameters.
Tap → Security → Privacy Sengs.
Authencaon
Sengs
Picture Display/Name Display/Employee ID Display
Check the displayed contents in the authencaon result, such as picture, name, and employee
ID.
Name/ID
De-idencaon
You can choose to desensize the name and Employee ID when authencang. Aer de-
idencaon, the name and the ID will display parts of contents.
Picture Uploading and Storage
Set picture uploading and storage parameters.
Save Registered Picture
The registered face picture will be saved to the system if you enable the
funcon.
Save Picture When Auth.
If you enable this funcon, you can save the picture when authencang to the device.
Upload Captured Picture When Authencang
If you enable this funcon, you can save the picture when authencang to the device.
Save Pictures Aer Linked Capture
If you enable this funcon, the captured pictures will be saved to the device automacally.
Upload Picture Aer Linked Capture
Upload the pictures captured aer linked capture.
DS-K1T344 Series Face Recognion Terminal User Manual
100
7.5.13 Set PIN Mode
Make sure the PIN is plaorm-applied personal PIN or device-set personal PIN before sengs. If it
is a device-set personal PIN, it can be created or edited on the device or on the web, and cannot be
set on other
plaorms; If it is a plaorm-applied personal PIN, it can be created or edited on the
plaorm, and issued to the device before it can be used. It cannot be set on the device or on the
web.
Tap
→ Security → PIN Mode.
Plaorm-Applied Personal PIN
You can create the person PIN on the plaorm. You should apply the PIN to the device. You
cannot create or edit the PIN on the device or PC Web.
Device-Set Personal PIN
You can create or edit the PIN on the device or PC Web. You cannot set the PIN on the plaorm.
Tap Save.
7.5.14 System Upgrade & Maintenance
Restart device, restore device and upgrade device.
Restart Device
Tap .
Tap Restart to restart the device.
Restore Parameters
Tap → Default to enter the sengs page.
Restore to Default
Sengs
All data will be cleared except the network parameters and user account.
Restore to Factory Sengs
All funcons and parameters will be restored to factory sengs. You should acvate the device
again to use.
Upgrade Device
On home page, tap → Upgrade.
Click Upgrade to upgrade the device.
Note
The upgrading process will take 1 to 10 minutes. Do not power o. The device will restart
automacally aer upgrading.
DS-K1T344 Series Face Recognion Terminal User Manual
101
7.5.15 View User Document
View the user document.
Note
Only when you enter the mobile web by IP address, can you view the user document. Login by hot
spot does not support the funcon.
Tap to enter the page.
Tap View Online Document to view the user manual.
7.5.16 Open Source
Soware Licenses
You can view the open source soware licenses.
Tap
to enter the page.
Tap Open Source Soware Licenses.
7.5.17 Log Out of Mobile Web
Log out of the conguraon page on the mobile web.
On the home page, tap → Log Out , and tap OK to log out of the web.
If you need to go to the
conguraon page, please enter user name and password again.
DS-K1T344 Series Face Recognion Terminal User Manual
102
Chapter 8 Operaon via Web Browser
8.1 Login
You can login via the web browser or the remote conguraon of the client soware.
Note
Make sure the device is acvated. For detailed informaon about acvaon, see Acvate via Web
Browser .
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
Note
5 failed password enterings will lock the device. You should try again aer 30 min.
8.2 Forget Password
If you forget the password when logging in, you can change the password by email address or
security
quesons.
On the login page, click Forget Password.
Select Vericaon Mode.
Security
Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the vericaon code into the vericaon code eld to verify your idencaon.
Click Next, create a new password and conrm it.
8.3 Help
8.3.1 Open Source Soware Licenses
You can view open source soware licenses.
Click
→ Open Source Soware Statement on the upper-right corner to view the licenses.
DS-K1T344 Series Face Recognion Terminal User Manual
103
8.3.2 View Online Help Document
You can view the help document for Web conguraon.
Click → Online Document on the upper right of the Web page to view the document.
8.4 Logout
Log out the account.
Click admin → Logout → OK to logout.
8.5 Quick
Operaon via Web Browser
8.5.1 Change Password
You can change the device password.
Click
on the top right of the web page to enter the Change Password page. You can set security
quesons from the drop-down list and ll in the answers.
Figure 8-1 Change Password
Click Next to complete the sengs. Or click Skip to skip the step.
DS-K1T344 Series Face Recognion Terminal User Manual
104
8.5.2 Select Language
You can select a language for the device system.
Click
in the top right of the web page to enter the Device Language Sengs page. You can
select a language for the device system from the drop-down list.
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
8.5.3 Time Sengs
Click in the top right of the web page to enter the wizard page. Aer seng device language,
you can click Next to enter the Time Sengs page.
Time Zone
Select the device located
me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's
me.
Server Address/NTP Port/Interval
You can set the server address, NTP port, and interval.
DST
You can view the DST start me, end me and bias me.
Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.
8.5.4 Privacy
Sengs
Set the picture uploading and storage parameters.
Click in the top right of the web page to enter the wizard page.
DS-K1T344 Series Face Recognion Terminal User Manual
105
Figure 8-2 Privacy Sengs
Picture Uploading and Storage
Save Picture When Authencang
Save picture when authencang automacally.
Upload Picture When Authencang
Upload the pictures when authencang to the plaorm automacally.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Click Next to save the sengs and go to the next parameter. Or click Skip to skip privacy sengs.
8.5.5 Administrator
Sengs
Steps
1.
Click in the top right of the web page to enter the wizard page.
2.
Enter the employee ID and name of the administrator.
3.
Select a
credenal to add.
Note
You should select at least one credenal.
1) Click Add Face to upload a face picture from local storage.
DS-K1T344 Series Face Recognion Terminal User Manual
106
Note
The uploaded picture should be within 200 K, in JPG、JPEG、PNG format.
2) Click Add Card to enter the Card No. and select the property of the card.
Note
Up to 5 cards can be supported.
3) Click Add Fingerprint to add
ngerprints.
Note
Up to 10 ngerprints are allowed.
Click Complete to complete the sengs.
8.5.6 No. and System Network
Steps
1.
Click in the top right of the web page to enter the wizard page. Aer previous sengs, you
can click Next to enter the No. and Network System Network
sengs page.
2.
Set the device type.
Note
●
If set the device type as Door Staon, you can set the Floor No., Door Staon No.,
Community No., Building No., Unit No., Floor No., and Door Staon No..
●
If set the device type as Outer Door Staon, you can set Outer Door Staon No., and
Community No.
Device Type
The device can be used as a door staon or outer door staon. Select a device type from the
drop-down list.
Community No.
Set the device community No.
Building No.
Set the device building No.
Unit No.
Set the device unit No.
Floor No.
Set the device installed oor No.
Door Staon No.
Set the device installed door staon No.
DS-K1T344 Series Face Recognion Terminal User Manual
107
Note
The main door staon No. is 0, and the sub door staon No. ranges from 1 to 16.
Outer Door Staon No.
Set the device installed outer door staon No.
Note
The No. ranges from 1 to 99.
3.
Set the video intercom network parameters.
Registraon Password
Set the registraon password of the main staon for communicaon. Set the registraon
password of the main staon for communicaon.
Main Staon IP
Enter the main staon’s IP address that used for communicaon.
Private Server IP
Refers to the SIP server IP. Enter the main staon’s IP address that used for communicaon.
At this me the main staon is used as a SIP server. Other intercom devices should registered
to this server address to realize communicaon.
Enable Protocol 1.0
If enabled, the door staon can be registered to the main staon by old protocol version. If
disabled, the door
staon can be registered to the main staon by new protocol version.
4.
Click Complete to save the sengs aer the conguraon.
8.6 Person Management
Add the person's informaon, including the basic informaon, cercate, authencaon and
sengs.
Add Basic
Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, gender, and
person type.
If you select Visitor as the person type, you can set the visit
mes.
If you select Person in Blocklist, when the person starts authencate, the system will report an
event.
If you select Custom Type, you can edit the name. The changed name will be applied to the device.
Click Save to save the
sengs.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
DS-K1T344 Series Face Recognion Terminal User Manual
108
Enable Long-Term Eecve User, or set Long-Term Eecve User, and the person can only has the
permission within the congured me period according to your actual needs.
Set the door permission.
Click Save to save the
sengs.
Add Face Picture
Click Person Management → Add to enter the Add Person page.
Click Add from Device and you can take a face picture via the device.
Or click Upload to upload a face picture from the local PC.
Note
The picture format should be JPG or JPEG or PNG, and the size should be less than 200 kb.
Click Save to save the sengs.
Add Card
Click Person Management → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Click Save to save the
sengs.
Add Fingerprint
Note
Only devices supporng the ngerprint funcon can add the ngerprint.
Click Person Management → Add to enter the Add Person page.
Click Add Fingerprint, and press your nger on the ngerprint module of the device to add your
ngerprint.
Click Save to save the sengs.
Add PIN
Before conguring PIN, it is necessary to clarify whether the PIN is a device-set personal PIN or a
plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created or edited on the
device or on the web, and cannot be set on other plaorms; If it is a plaorm-applied personal
PIN, it can be created or edited on the plaorm, and issued to the device before it can be used. It
cannot be set on the device or on the web.
Make sure you have already set the PIN mode as Device-Set Personal PIN in . Click PIN Mode on
the page to go to
congure.
Click Person Management → Add to enter the Add Person page.
Set the PIN. Or click Auto Generate to generate a PIN
automacally.
Click Add to save the sengs.
Click Save and Congure to save the sengs and connue to add next person.
DS-K1T344 Series Face Recognion Terminal User Manual
109
Authencaon Sengs
Click Person Management → Add to enter the Add Person page.
Set the authencaon type.
Click Save to save the
sengs.
Delete Person
On the person management page, check the person need to delete and click Delete.
Click Clear All to clear all person.
Edit Person
On the person management page, check the person need to edit. Click
to edit the person
informaon.
Filter
On the person management page, enter Employee ID / Name / Card No.. Select Credenal Status,
and click Filter to lter the person. Click Reset to clear all condions.
8.7 Access Control Management
8.7.1 Overview
You can view the live video of the device, linked device, person informaon, network status, basic
informaon, and device capacity.
DS-K1T344 Series Face Recognion Terminal User Manual
110
Figure 8-3 Live View Page
Funcon Descripons:
Door Status
Click on the video to view the device live video.
Set the volume when starng live view.
Note
If you adjust the volume when starng two-way audio, you may hear a repeated sounds.
You can capture image when starng live view.
/ / /
The door status is open/closed/remaining open/remaining closed.
You can record when starng live view.
DS-K1T344 Series Face Recognion Terminal User Manual
111
Select the streaming type when starng live view. You can select from the main stream, sub
stream or third stream.
Full screen view.
Controlled Status
You can control the door to be opened, closed, remaining open or remaining closed
according to your actual needs.
Real-Time Event
You can view the event Employee ID, Name, Card No., Event Type, Time, and
Operaon. You can
also click View More to enter the page of Event Search. You can select event types, enter the
employee ID, the name, the card No., the start me, and the end me, and click Search. The
results will be displayed on the right panel.
Link Device
You can view the
quanty and status of linked devices.
Note
You can click View More to go to .
Person Informaon
You can view the added and not added informaon of person credenals.
Network Status
You can view the connected and registered status of wired network, wireless network, Hik-
Connect, ISUP, OTAP, and VoIP.
Basic
Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, face, ngerprint, card, and event capacity.
Note
Only device installed ngerprint module can display the ngerprint capacity.
8.7.2 Search Event
Click Access Control → Event Search to enter the page.
DS-K1T344 Series Face Recognion Terminal User Manual
112
Figure 8-4 Search Event
Enter the search condions, including the event type, the employee ID, the name, the card No., the
start me, and the end me, and click Search.
The results will be displayed on the right panel.
8.7.3 Door Parameter
Conguraon
Congure parameters for unlocking doors.
View Device Online Status
View and refresh the device status.
Click Access Control → Parameter
Sengs → Door Parameters to enter the sengs page.
You can view the online status of the device. Click Refresh to refresh the status of the device.
Set Door Name
Create door name.
Click Access Control → Parameter Sengs → Door Parameters to enter the sengs page.
Set Door Name and click Save.
Set Open
Duraon via PC Web
You can set the me for the door lock to open aer swiping the card.
DS-K1T344 Series Face Recognion Terminal User Manual
113
Click Access Control → Parameter Sengs → Door Parameters to enter the sengs page.
Set the open duraon, that is the acon me aer the door is unlocked. If the door is not opened
within the set me, the door will automacally lock. Congurable me: 1 to 255 seconds.
Click Save.
Set Door Open Timeout Alarm via PC Web
If the door is not closed aer reaching the lock acon me, the access control point will sound an
alarm.
Click Access Control → Parameter
Sengs → Door Parameters to enter the sengs page.
Set Door Open Timeout Alarm. If the door is not closed aer reaching the lock acon me, the
access control point will sound an alarm. When set as 0, alarm will not be enabled.
Click Save.
Set Door Lock Status via Web Page
Select door contact's status according to the door contact’s wiring method.
Click Access Control → Parameter Sengs → Door Parameters.
You can select Remain Open or Remain Closed according to your actual needs. By default, it is
Remain Closed.
Click Save.
Set Exit
Buon via PC Web
Set the exit buon as remain open or remain closed according to the actual wiring method.
Click Access Control → Parameter Sengs → Door Parameters to enter the sengs page.
Set Exit
Buon Type. By default, it is Remain Open (excluding special needs).
Click Save.
Set Door Lock Powering
O Status via PC Web
You can set the door lock status when the door lock is powering o.
Click Access Control → Parameter Sengs → Door Parameters to enter the sengs page.
Set Door Lock Powering
O Status. By default, it is remain closed.
Click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
114
Set Extended Open Duraon via PC Web
The door contact can be enabled with appropriate delay aer person with extended access needs
swipes her/his card.
Click Access Control → Parameter
Sengs → Door Parameters to enter the sengs page.
Set Extended Open Duraon. The door contact can be enabled with appropriate delay aer person
with extended access needs swipes her/his card.
Click Save.
Set Door Remain Open Duraon with First Person via PC Web
Aer the rst person is authorized, it allows mulple persons access the door or other
authencaon acons.
Click Access Control → Parameter Sengs → Door Parameters to enter the sengs page.
Set the door open duraon when rst person is in and click Save.
Set Duress Code via PC Web
Aer conguring duress code, when encountering duress, enter the code to open the door. At the
same me, the access control system will report duress events.
Click Access Control → Parameter
Sengs → Door Parameters to enter the sengs page.
Set duress code, and click Save.
Note
Duress code and super password can’t be duplicated, usually consisng of 4 to 8 digits.
Set Super Password via PC Web
Administrator or designated person can enter the super password to open the door.
Click Access Control → Parameter
Sengs → Door Parameters to enter the sengs page.
Set Super Password, the designated person can enter the super password to open the door.
Click Save.
Note
Duress code and super password can’t be duplicated, usually consisng of 4 to 8 digits.
DS-K1T344 Series Face Recognion Terminal User Manual
115
8.7.4 Authencaon Sengs
Figure 8-5 Authencaon Sengs
Select Main or Sub Card Reader via PC Web
Set the terminal for person authencaon.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
Select the terminal as main or sub card reader.
Set other parameters and click Save.
View Terminal Type and Model via PC Web
You can view terminal type and model.
Click Access Control → Parameter
Sengs → Authencaon Sengs to enter the sengs page.
View Terminal Type and Terminal Model.
DS-K1T344 Series Face Recognion Terminal User Manual
116
Enable Authencaon Device via PC Web
Aer enabling, the authencaon terminal can be used for card swiping.
Steps
1.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs
page.
2.
Enable Authencaon Device. Aer enabling, the terminal can be used for card swiping
normally.
3.
Click Save.
Set
Authencaon Mode via PC Web
Set authencaon credenal for device authencaon .
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
If select the terminal as Main or Sub, you can select an authencaon mode from the drop-down
list.
Click Save.
Set
Recognion Interval via PC Web
Set the me interval between two connuous face recognions when authencang.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
When you select the terminal as main or sub card reader, set
recognion interval, and click Save.
Note
Please enter a number between 1 and 10.
Set Authencaon Interval via PC Web
You can set the authencaon interval of the same person when authencang. The same person
can only authencate once in the congured interval. A second authencaon will be failed. If
other person
authencate in the congured interval, the person can authencate again.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
When you select the terminal as main card reader, set
Authencaon Interval, and click Save.
Enable Alarm of Max. Failed
Aempts via PC Web
Enable to report alarm when the card reading aempts reach the set value.
DS-K1T344 Series Face Recognion Terminal User Manual
117
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
When you select the terminal as main or sub card reader, slide to enable Alarm of Max. Failed
Aempts, and set Max. Authencaon Failed Aempts.
Click Save.
Enable/Disable Tampering Detecon via PC Web
You can enable tampering detecon, the device will automacally generate tampering events
when the card reader is removed or taken away.
Click Access Control → Parameter
Sengs → Authencaon Sengs to enter the sengs page.
Enable or disable Tampering Detecon according to your actual needs. Aer enabling the funcon,
the device will automacally generate tampering events when the card reader is removed or taken
away. If the funcon is disabled, no alarm events will be generated.
Click Save.
Enable/Disable Card No. Reversing via PC Web
You can enable or disable the card No. reversing funcon.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
Enable Card No. Reversing, the read card No. will be in reverse sequence.
Click Save.
Set Sub Card Reader
Posion
You can choose the posion for the sub card reader.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
When Sub Card Reader is selected as the Terminal, you can select the
posion of sub card reader
as Dierent Side from Main Card ReaderorSame Side as Main Card Reader. ClickSave.
Set
Communicaon with Controller Every via PC Web
You can set communicaon with controller every of sub card reader. If the card reader can’t
connect with the access controller in the set me, the card reader is oine.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
When you select the terminal as sub card reader, set Communicaon with Controller Every, and
click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
118
Set Timeout Duraon of Entering Password via Web Client
Set the maximum interval of entering two characters of the password. Aer entering one
character, if the next character is not entered within the set interval, the entered characters will all
be
automacally cleared.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs page.
When
selecng the sub card reader as the Terminal, you can set Max. Interval When Entering
Password and clickSave.
Set OK LED Polarity and Error LED Polarity via PC Web
Select the polarity of the diodes for OK and ERR interfaces according to actual wiring, with a
default posive polarity.
Click Access Control → Parameter
Sengs → Authencaon Sengs to enter the sengs page.
When you select the terminal as sub card reader, set OK LED Polarity and Error LED Polarity, and
click Save.
Enable/Disable Bluetooth via PC Web
You can enable device bluetooth to connect a bluetooth sound.
Steps
1.
Click Access Control → Parameter Sengs → Authencaon Sengs to enter the sengs
page.
2.
In the bluetooth parameter conguraon secon, enable Enable Bluetooth.
3.
Enter the external sound in the Device Name.
Aer the bluetooth is connected, click Save.
4.
Enable Open Door via Bluetooth, you can control the door remotely.
Note
You should add the device to mobile App before operaon.
DS-K1T344 Series Face Recognion Terminal User Manual
119
8.7.5 Set Face Parameters
Figure 8-6 Set Face Parameters
Enable/Disable Face
An-spoong via Web Browser
When enabled, the device can recognize whether the person is a live one or not.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Enable Face An-spoong and click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
120
Enable or disable the live face detecon funcon. When enabled, the device can recognize
whether the person is a live one or not. If the face is not a live one, authencaon will fail.
Set An-Spoong Detecon Level via PC Web
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Select the
an-spoong detecon level and click Save.
You can choose from general, advanced and professional. The higher the level, the lower the fake
recognion rate and the higher the rejecon rate.
Set
Recognion Distance via PC Web
You can set the distance between the authencang user and the device camera.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Select the
recognion distance, and click Save.
Set Pitch Angle via PC Web
You can set the pitch angle of the lens during face recognion and authencaon.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Note
Dierent models may support dierent parameters, please refer to the actual page.
Set Pitch Angle and click Save.
Set Yaw Angle via PC Web
You can set the yaw angle of the lens during face recognion and authencaon.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Note
Dierent models may support dierent parameters, please refer to the actual page.
Set yaw angle, and click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
121
Set Face Picture Quality Grade for Applying via PC Web
The grade for face authencaon needs to be higher than the threshold to be successful.
Click Access Control → Parameter
Sengs → Smart to enter the sengs page.
Note
Dierent models may support dierent parameters, please refer to the actual page.
Set Face Picture Quality Grade for Applying , the grade for face authencaon needs to be higher
than the threshold to be successful.
Click Save.
Set 1:1 Face Grade Threshold via PC Web
Set 1:1 face grade threshold.
Go to Access Control → Parameters
Sengs → Smart .
Set 1:1 Face Picture Grade Threshold, and click Save.
The higher the threshold, the higher the requirements for the quality of the captured images of the
front camera, and the easier to prompt
authencaon failure.
Set Face 1:1 Matching Threshold via PC Web
Set face 1:1 matching threshold.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Set face 1:1 matching threshold and click Save.
The larger the value of the threshold, the fault acceptance rate will be lower and the false
rejecon
rate will be higher when authencang via face. The maxium value is 100.
Set 1:N Matching Threshold via PC Web
You can set the matching threshold for face 1:N matching.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Set the 1:N matching threshold and click Save.
The larger the value, the smaller the false accept rate and the larger the false
rejecon rate. The
maximum value is 100.
DS-K1T344 Series Face Recognion Terminal User Manual
122
Set Face Recognion Timeout Value
Congure the meout period for face recognion. If the face recognion me exceeds the
congured value, the device will prompt the face recognion meout.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Congure the meout duraon for face recognion.
Set Face Recognion Area via Web Browser
You can set the recognion area of the lens during face recognion and authencaon.
Click Access Control → Parameter Sengs → Area Conguraon to enter the sengs page.
Drag the border of the yellow box in the preview screen to adjust the eecve area for face
recognion on the le, right, up, and down sides.
Or drag the block or enter the number to set the
eecve area.
Click Save.
Click , , or to capture, record, or go to full screen view.
Set Fingerprint Parameters via PC Web
You can set the ngerprint parameters of the device.
Click Access Control → Parameter
Sengs → Smart to enter the sengs page.
Select Fingerprint Security Level. The higher the level, the lower the fake recognion rate and the
higher the rejecon rate.
Click Save.
Enable/Disable ECO Mode via PC Web
If the ECO mode is enabled, you can authencate faces in the low light or dark environment with IR
camera.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
If the ECO mode is enabled, you can
authencate faces in the low light or dark environment with IR
camera. You can set the ECO mode (1:N) threshold and ECO mode (1:1) threshold .
ECO Mode (1:1) Threshold
Set the matching threshold when
authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate. The maximum
value is 100.
ECO Mode (1:N) Threshold
DS-K1T344 Series Face Recognion Terminal User Manual
123
Set the matching threshold when authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate. The maximum
value is 100.
Click Save.
Enable/Disable Face with Mask Detecon via PC Web
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture or not.
Click Access Control → Parameter Sengs → Smart to enter the sengs page.
Aer enabling the face with mask detecon, you can set Face without Mask Strategy, Face with
Mask&Face (1:1), Face with Mask 1:N Match Threshold (ECO), Face with Mask 1:1 Match
Threshold and Face with Mask 1:N Match Threshold (ECO).
Face without Mask Strategy
You can select None, Reminder of Wearing Face Mask and Must Wear Face Mask.
Reminder of Wearing Face Mask
If the person do not wear the face mask when
authencang, the device will pop up a
prompt and the door will open.
Must Wear Face Mask
If the person do not wear the face mask when authencang, the device will pop up a
prompt and the door will keep closed.
Face with Mask&Face (1:1)
Set the matching value when
authencang with face mask via 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate. The maximum
value is 100.
Face with Mask&Face (1:N)
Set the matching threshold when
authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate. The
maximum value is 100.
Face with Mask 1:1 Match Threshold (ECO)
Set the matching value when
authencang with face mask via ECO mode 1:1 matching mode.
The larger the threshold, the lower the
recognion error rate and the higher the rejecon rate
when authencang faces. The maximum value is 100.
Face with Mask 1:N Match Threshold (ECO)
Set the matching value when authencang with face mask via ECO mode 1:N matching mode.
The larger the threshold, the lower the recognion error rate and the higher the rejecon rate
when
authencang faces. The maximum value is 100.
Click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
124
8.7.6 Card Sengs
Enable/Disable NFC Protecon via PC Web
Aer enabling, the device can read NFC card.
Click Access Control → Parameter Sengs → Card Sengs to enter the sengs page.
Click to Enable NFC Card and click Save. Aer enabling, the device can read NFC card. If the data of
access control devices is obtained by mobile devices, the
situaon of unauthencated access may
occur. To prevent this situaon, you can disable NFC funcon.
Enable/Disable M1 Card via Web Client
Aer enabling, the device can recognize M1 card and users can swipe M1 card via the device.
Click Access Control → Parameter Sengs → Card Sengs to enter the sengs page.
Click to Enable M1 Card.
M1 Card
Encrypon
Enable M1 Card Encrypon can improve the security level of the entrance card. Therefore, the
entrance card will be harder to be copied.
Sector
Aer enabling M1 Card Encrypon, you will need to set the encrypted sector.
Note
You are advised to encrypt sector 13.
Click Save.
Enable/Disable EM Card via Web Client
Aer enabling, the device can recognize EM card and users can swipe EM card via the device.
Click Access Control → Parameter
Sengs → Card Sengs to enter the sengs page.
Click to Enable EM Card and click Save.
Note
If the peripheral card reader which can read EM card is connected, aer enabling this funcon, you
can also swipe EM card via this card reader.
DS-K1T344 Series Face Recognion Terminal User Manual
125
Enable/Disable CPU Card via Web Client
Aer enabling, the device can recognize CPU card and users can swipe CPU card via the device.
Click Access Control → Parameter
Sengs → Card Sengs to enter the sengs page.
Click to Enable CPU Card.
Click to Enable CPU Card Read Content. Aer enabling, the device can read content from CPU
card.
Click Save.
Set Card No. Authencaon Parameters via Web
Set the card reading content when authencate via card on the device.
Go to Access Control → Parameter Sengs → Card Sengs .
Select a card
authencaon mode and click Save.
Full Card No.
All card No. will be read.
3 bytes
The device will read card via read 3 bytes.
4 bytes
The device will read card via 4 bytes.
8.7.7 Linkage
Sengs
When the congured event is triggered, upload the event informaon to the central plaorm
according to the congured method.
Steps
1.
Click Access Control → Parameter
Sengs → Linkage Sengs to enter the sengs page.
DS-K1T344 Series Face Recognion Terminal User Manual
126
Figure 8-7 Linkage Sengs
2.
Click + .
3.
Set event source. Select the linkage type as Event Linkage, Card Linkage or Link Employee ID.
-
Select Linkage Type as Event Linkage, you can select event types according to your actual
needs.
-
Select Linkage Type as Card Linkage, enter Card No. and select Card reader.
-
Select Linkage Type as Link Employee ID, enter Employee ID and select Card reader.
4.
Set linkage
acon.
1) Enable Door Linkage, check and select door acon.
2) Enable Linked Alarm Output, check and select alarm output acon.
3) Enable Linked Capture.
4) Enable Link Recording, click General Linkage Sengs to set pre-record me and recording
delay, and enable record audio when recording video. Click Save.
Note
To use the recording funcon, you need to prepare the SD card. Aer recording, you can click
Event Search to view recordings. For details, see Search Event
5.
ClickSave to enable the sengs.
8.7.8 Set Working Mode via PC Web
You can set terminal parameters for accessing.
Note
Only some models support this funcon, please refer to the specic device.
Go to Access Control → Parameter Sengs → Terminal Parameters.
ClickSave
aer parameters are congured.
Working Mode
DS-K1T344 Series Face Recognion Terminal User Manual
127
You can set the working mode as access control mode.
Access Control Mode
The access control mode is the device normal mode. You should authencate your credenal
for accessing.
8.7.9 Privacy Sengs
Figure 8-8 Privacy Sengs
DS-K1T344 Series Face Recognion Terminal User Manual
128
Set Event Storage Type via PC Web Browser
You can congure the event storage type.
Click Access Control → Parameter
Sengs → Privacy Sengs to enter the sengs page.
You can select Event Storage Type as Delete Old Events Periodically, Delete Old Events by
Specied Time or Overwring.
Delete Old Events Periodically
Drag the block or enter number to set the period for event
deleng. All events will be deleted
according to the congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Click Save.
Set
Authencaon Result via PC Web
Set authencaon result contents, such as picture, name, employee ID, and temperature.
Click Access Control → Access Control → Parameter
Sengs → Privacy Sengs .
Check the displayed contents in the authencaon result, such as picture, name, employee ID.
Check Name
De-idencaon and ID De-idencaon according to actual needs. Aer de-
idencaon, the name and the ID will display parts of contents.
Set
Authencaon Result Display Duraon and the authencaon result will display the
congured me duraon.
Click Save.
Set Picture Uploading and Storage Parameters
Set picture uploading and storage parameters.
Click Access Control → Parameter
Sengs → Privacy Sengs.
Enable the funcon as you need.
Save Picture When Auth.
If you enable this funcon, you can save the picture when authencang to the device.
Upload Picture When Auth.
If you enable this funcon, you can save the picture when authencang to the device.
DS-K1T344 Series Face Recognion Terminal User Manual
129
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Save Pic. Aer Linked Capture
If you enable this funcon, the captured pictures will be saved to the device automacally.
Upload Picture Aer Linked Capture
Upload the pictures captured aer linked capture.
Tap Save.
Clear Device Pictures via PC Web
You can clear all registered, authencated or captured face pictures.
Click Access Control → Parameter Sengs → Privacy Sengs to enter the sengs page.
Click Clear to clear all registered,
authencated or captured face pictures.
Set PIN Mode via PC Web
Make sure the PIN is plaorm-applied personal PIN or device-set personal PIN before sengs. If
the PIN is device-set personal PIN, you can edit the PIN on the device or PC Web, but not set it on
the
plaorm. If the PIN is plaorm-applied personal PIN, you should set the PIN on the plaorm,
but not on the device or PC Web.
Go to Access Control → Parameter Sengs → Privacy Sengs.
In the PIN Mode module, you can set the following parameters. Click Save aer parameters
sengs.
Plaorm-Applied Personal PIN
You can create the person PIN on the plaorm. You should apply the PIN to the device. You
cannot create or edit the PIN on the device or PC Web.
Device-Set Personal PIN
You can create or edit the PIN on the device or PC Web. You cannot set the PIN on the
plaorm.
Click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
130
8.8 Call Sengs
8.8.1 Device Management
You can view the device No., type, IP, serial No., model, version, oor No., room No., No., arming
status, user name, network status and operaon. You can also add indoor staon and sub door
staon on the device management page, and manage, upgrade or delete devices.
Steps
1.
Click Device Management.
2.
Click Add.
3.
Select Device Type, enter Device Password,
Registraon Password, Serial No., IP Address, IPv4
Subnet Mask, IPv4 Default Gateway, Port, Floor No. (not needed to enter Floor No., and No. for
indoor
staon.
4.
Click Save.
5.
Oponal: You can also perform the following operaons.
Delete Device Check devices need to delete, and click Delete.
Import Device Plug the USB ash drive (containing device informaon) to the device, click
Import to import the device informaon.
Export Device Click Export to export the device informaon les to the USB ash drive.
8.8.2 Set Device No. via Web
The device can be used as a door staon or outer door staon. You should set the device No.
before usage.
Click Access Control → Call Sengs → Device No. .
DS-K1T344 Series Face Recognion Terminal User Manual
131
Figure 8-9 Device No. Sengs
If set the device type as Door Staon, you can set the Floor No., Door Staon No., Community
No., Building No., and Unit No.
Device Type
The device can be used as a door
staon or outer door staon. Select a device type from the
drop-down list.
Note
If you change the device type, you should reboot the device.
Floor No.
Set the device installed oor No.
Door Staon No.
Set the device installed oor No.
Note
●
If you change the No., you should reboot the device.
●
The main door staon No. is 0, and the sub door staon No. ranges from 1 to 16.
Community No.
Set the device community No.
Building No.
Set the device building No.
Unit No.
Set the device unit No.
DS-K1T344 Series Face Recognion Terminal User Manual
132
Note
If you change the No., you should reboot the device.
Click Save to save the sengs aer the conguraon.
If set the device type as Outer Door Staon, you can set outer door staon No., and community
No.
Outer Door
Staon No.
If you select outer door staon as the device type, you should enter a number between 1 and
99.
Note
If you change the No., you should reboot the device.
Community No.
Set the device community No.
8.8.3
Congure Video Intercom Network Parameters via Web Browser
You can set the registraon password, main staon IP and private server IP, and you can enable
protocol 1.0 according to your actual needs.
Click Call Sengs → Video Intercom Network to enter the sengs page.
Registraon Password
Set the registraon password of the main staon for communicaon. Set the registraon
password of the main staon for communicaon.
Main Staon IP
Enter the main staon’s IP address that used for communicaon.
Private Server IP
Refers to the SIP server IP. Enter the main staon’s IP address that used for communicaon. At
this me the main staon is used as a SIP server. Other intercom devices should registered to
this server address to realize communicaon.
Enable Protocol 1.0
If enabled, the door staon can be registered to the main staon by old protocol version. If
disabled, the door staon can be registered to the main staon by new protocol version.
DS-K1T344 Series Face Recognion Terminal User Manual
133
Figure 8-10 Video Intercom Network
Aer conguraon, you can achieve communicaon between access control devices and video
intercom door staon, indoor staon, main staon, plaorms, etc.
Click Save.
8.8.4 Set
Communicaon Time via PC Web
Set the max. communicaon me.
Go to Access Control → Call Sengs → Call Sengs .
Enter the Max.
Communicaon Time. Click Save.
Note
The Max. Communicaon me range is 90 s to 120 s.
8.8.5 Press Buon to Call via PC Web
Steps
1.
Click Access Control → Call Sengs → Press Buon to Call to enter the sengs page.
Figure 8-11 Press
Buon to Call
2.
Select Call Specied Indoor Staon, Call Management Center, Call Indoor Staon or APP at
your needs.
Note
If you select Call Specied Indoor Staon, you need to enter the Room No. of the indoor
staon.
DS-K1T344 Series Face Recognion Terminal User Manual
134
3.
Enable Link Authencaon to Call according to your needs. Aer enabled, when person passes
authencaon, the door will be remotely opened by the target that is congured with buon for
automac calling.
4.
Click Save.
8.8.6 Number Sengs via PC Web
Set SIP number for the room. The rooms can communicate with each other via SIP number.
Steps
1.
Go to Access Control → Call Sengs → Number Sengs.
Figure 8-12 Number Sengs
2.
Click Add, and enter Room No. and SIP1 phone number.
3.
Oponal: Click Add to add the SIP number or click to delete the number.
4.
ClickSave.
5.
Oponal: You can click Delete to delete room number and its SIP number.
8.9 System and Maintenance
8.9.1 View Device Informaon via PC Web
View the device name, device No., language, model, serial No., version, number of channels, IO
input, IO output, lock, alarm input, alarm output, and device capacity, etc.
Click System and Maintenance → System
Conguraon → System → System Sengs → Basic
Informaon to enter the conguraon page.
You can view the device name, device No., language, model, serial No., version, number of
channels, IO input, IO output, lock, alarm input, alarm output, and device capacity, etc.
Click Upgrade in the Firmware Version, you can go to the upgrade page to upgrade the device.
8.9.2 Set Time
Set the device's me zone, synchronizaon mode, server address, NTP port, and interval.
DS-K1T344 Series Face Recognion Terminal User Manual
135
Click System and Maintenance → System Conguraon → System → System Sengs → Time
Sengs .
Figure 8-13 Time Sengs
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server Address Type/Server Address/NTP Port/Interval
You can set the server address type, server address, NTP port, and interval.
DS-K1T344 Series Face Recognion Terminal User Manual
136
8.9.3 Change Administrator's Password
Steps
1.
Click System and Maintenance → System
Conguraon → System → User Management →
User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
8.9.4 Account Security Sengs via PC Web
You can change the security quesons and answers, or the email address for the device. Aer
change the sengs, once you forgot the device password, you should answer the new quesons or
use the new email address to reset the device password.
Steps
1.
Click System and Maintenance → System
Conguraon → System → User Management →
User Management → Account Security Sengs .
2.
Change the security
quesons or email address according your actual needs.
3.
Enter the device password and click OK to conrm changing.
8.9.5 View Device Arming/Disarming
Informaon via PC Web
View device arming type and arming IP address.
Go to System and Maintenance → System Conguraon → System → User Management →
Arming/Disarming Informaon .
You can view the device arming/disarming
informaon. Click Refresh to refresh the page.
DS-K1T344 Series Face Recognion Terminal User Manual
137
8.9.6 Network Sengs
Set Basic Network Parameters via PC Web
Click System and Maintenance → System Conguraon → Network → Network Sengs →
TCP/IP .
Figure 8-14 TCP/IP Sengs Page
Set the parameters and click Save to save the sengs.
NIC Type
Select a NIC type from the drop-down list. By default, it is Auto.
DS-K1T344 Series Face Recognion Terminal User Manual
138
DHCP
If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, Mac address, and MTU.
If you check the
funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4
default gateway automacally.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Click System and Maintenance → System Conguraon → Network → Network Sengs → Wi-
Fi .
Figure 8-15 Wi-Fi Sengs Page
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click of a Wi-Fi in the list and enter the Wi-Fi password.
-
Click Add and enter a Wi-Fi's name, password, and
encrypon type. Click Connect. When the
Wi-Fi is connected, click OK.
4.
Oponal: Set the WLAN parameters.
1) Set the IP address, subnet mask, and default gateway. Or enable DHCP and the system will
allocate the IP address, subnet mask, and default gateway
automacally.
DS-K1T344 Series Face Recognion Terminal User Manual
139
5.
Click Save.
Set Device Hotspot
Aer enabling the device hotspot, you can use the mobile phone to connect the hotspot and set.
Go to System and Maintenance → System Conguraon → Network → Network Sengs →
Device Hotspot.
Slide Enable Device Hotspot and you can use the mobile phone to connect the hotspot and set.
Click Save.
Note
Hotspot and Wi-Fi cannot be enabled at the same me.
Set Port via PC Web
Go to System and Maintenance → System Conguraon → Network → Network Service .
Enable/Disable HTTP
Enable the HTTP funcon to improve the broswer's vising security.
Go to System and Maintenance → System
Conguraon → Network → Network Service →
HTTP(S) .
ClickSave
aer parameters are congured.
HTTP Port
When you log in with a browser, you need to add the modied port number aer the address.
For example, when the HTTP port number is changed to 81, you need to enter hp://
192.0.0.65
：81 when you log in with a browser.
HTTPS Port
Set the HTTPS port for vising browser. But cercaon is required.
HTTP Listening
The device will send the alarm informaon to the desnaon IP or domain name by HTTP
protocol. The
desnaon IP or domain name should support HTTP protocol. Enter the
desnaon IP or domain name, URL and port. And select the protocol type.
View RTSP Port via PC Web
The RTSP port is the port of real-me streaming protocol.
Go to System and Maintenance → System Conguraon → Network → Network Service → RTSP .
DS-K1T344 Series Face Recognion Terminal User Manual
140
View the Port.
Set WebSocket(s) via PC Web
View WebSocket and WebSockets port.
Go to System and Maintenance → System
Conguraon → Network → Network Service →
WebSocket(s) .
View WebSocket and WebSockets port.
Set ISUP Parameters via PC Web
Set the ISUP parameters for accessing device via ISUP protocol.
Steps
Note
The funcon should be supported by the device.
1.
Click System and Maintenance → System Conguraon → Network → Device Access → ISUP .
2.
Check Enable.
3.
Set the ISUP version, server address, device ID, and the ISUP status.
Note
If you select 5.0 as the version, you should set the encrypon key as well.
4.
Set the ISUP listening parameters, including ISUP alarm center IP address/domain name, ISUP
alarm center URL, and ISUP alarm center port.
5.
Click Save.
Set OTAP via PC Web
Connect the device to the plaorm through the OTAP protocol to obtain device informaon,
upload operaon status and alarm informaon, restart and upgrade the device.
Steps
1.
Click System and Maintenance → System
Conguraon → Network → Device Access → OTAP .
DS-K1T344 Series Face Recognion Terminal User Manual
141
Figure 8-16 Set OTAP
2.
Click to Enable OTAP.
3.
Set Server IP Address, Port, Device ID and
Encrypon Key.
4.
Click Test to ensure the device can connect to the server and register successfully. Refresh the
page or restart the device to see the Register Status.
5.
Click More to view the network type and access priority. Drag the
operaon icon upward or
downward to adjust the network priority.
6.
Click Save.
Plaorm
Access via PC Web
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click System and Maintenance → System
Conguraon → Network → Device Access → Hik-
Connect to enter the sengs page.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
2.
Check Enable to enable the funcon.
3.
Oponal: Check the checkbox of Custom, and you can set the server address by yourself.
4.
Enter the
vericaon code.
5.
Click View to view device QR code. Scan the QR code to bind the account.
DS-K1T344 Series Face Recognion Terminal User Manual
142
Note
8 to 32 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
6.
Click Save to enable the sengs.
VoIP Account Sengs
You can realize voice call by network.
Steps
1.
Go to System and Maintenance → System
Conguraon → Network → Device Access → VoIP.
2.
Enable VoIP Gateway.
3.
Set Register User Name、
Registraon Password、Server IP Address、Server Port、Expiry
Time、Register Status、Number、Display User Name.
Figure 8-17 VoIP Account Sengs
Registraon Password
Enter the registraon password for communicaon via SIP server. The registraon password
for the SIP server is congured usually in the main staon’s SIP sengs.
Server IP Address
Enter the main staon’s IP address that used for VoIP communicaon. At this me the main
staon is used as a SIP server. Other intercom devices should registered to this server address
to realize communicaon.
Number / Display User Name
DS-K1T344 Series Face Recognion Terminal User Manual
143
The device displayed call number and user name.
4.
Click Save.
8.9.7 Set Video and Audio Parameters via PC Web
Congure Video Parameters via Web Browser
You can set quality, resoluon and other parameters of device camera.
Click System and Maintenance → System Conguraon → Video/Audio → Video to enter the
sengs page.
Set camera name, stream type, video type,
resoluon, bit rate type, video quality, frame rate, Max.
bitrate, video encoding and I frame interval.
Click Save.
Congure
Audio Parameters via PC Web
You can set device volume.
Go to System and Maintenance → System Conguraon → Video/Audio → Audio.
Figure 8-18 Audio
Set stream type and audio encoding according to your actual needs. Slide to set input and output
volume.
Slide to enable Voice Prompt.
Tap Save.
DS-K1T344 Series Face Recognion Terminal User Manual
144
8.9.8 Image Parameter Sengs
Figure 8-19 Display Sengs
Figure 8-20 OSD Sengs
DS-K1T344 Series Face Recognion Terminal User Manual
145
Set Brightness/Contrast/Saturaon/Sharpness via PC Web
You can set picture informaon such as brightness, contrast, saturaon and sharpness of live view
page.
Click System and Maintenance → System
Conguraon → Image → Display Sengs to enter the
sengs page.
Image Adjustment
Drag the block or enter numbers to set brightness, contrast,
saturaon and sharpness.
Click Restore Default Sengs to restore the to the default.
Set LED Light via PC Web
You can adjust the brightness of the supplement light.
Steps
1.
Click System and Maintenance → System Conguraon → Image → Display Sengs to enter
the sengs page.
2.
Set the type, mode and brightness of the supplement light.
3.
Oponal: Click Restore Default Sengs to restore the to the default.
Set Video Standard via PC Web
You can set the video standard of live view page.
Click System and Maintenance → System Conguraon → Image → Display Sengs to enter the
sengs page.
Video Adjustment
Set the video frame rate during remote preview. You need to reboot the device to make the
new
sengs eecve.
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
Click Restore Default
Sengs to restore the to the default.
DS-K1T344 Series Face Recognion Terminal User Manual
146
8.9.9 Alarm Sengs via PC Web
Set the alarm output parameters.
Steps
1.
Click System and Maintenance → System Conguraon → Event → Alarm Sengs → Alarm
Output .
2.
Set Alarm Name and mode of Alarm
Duraon.
Figure 8-21 Alarm Sengs
Connuous Alarm
When the alarm is triggered, it will alarm connuously.
Custom Alarm Duraon
You can set Alarm Duraon for the device when the alarm is triggered.
8.9.10 Access
Conguraon
Set RS-485 Parameters via PC Web
You can set the RS-485 parameters including the peripheral, address, baud rate, etc.
Click System and Maintenance → System
Conguraon → Access Conguraon → RS-485 .
Check Enable RS-485, and set the parameters.
Click Save to save the
sengs aer the conguraon.
No.
Set the RS-485 No.
Peripheral Type
Select a peripheral from the drop-down list according the actual situaon. You can select from
Card Reader, Extension Module, Access Controller, or Disable.
DS-K1T344 Series Face Recognion Terminal User Manual
147
Note
Aer the peripheral is changed and saved, the device will reboot automacally.
RS-485 Address
Set the RS-485 Address according to your actual needs.
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
Baud Rate
The baud rate when the devices are communicang via the RS-485 protocol.
Set Wiegand Parameters via PC Web
You can set the Wiegand transmission direcon.
Steps
Note
Some device models do not support this funcon. Refer to the actual products when conguraon.
1.
Click System and Maintenance → System Conguraon → Access Conguraon → Wiegand
Sengs .
Figure 8-22 Wiegand Page
2.
Check Wiegand to enable the Wiegand funcon.
3.
Set a transmission direcon.
Input
The device can connect a Wiegand card reader.
4.
Set the me interval and pulse width if you need.
5.
Click Save to save the
sengs.
DS-K1T344 Series Face Recognion Terminal User Manual
148
Note
If you change the peripheral, and aer you save the device parameters, the device will reboot
automacally.
8.10 Preference Sengs
8.10.1 Set Standby Image via PC Web
Set the standby image parameters, including the me to enter standby, and sleep me.
Go to System and Maintenance → Preference → Screen Display.
Figure 8-23 Standby Time Sengs
Click Save aer parameters are congured.
Time to Enter Standby
The device will show the standby image aer the congured me duraon.
8.10.2 Set Sleep Time via PC Web
The device will in sleep mode aer the congured me duraon. The funcon can reduce power
consumpon.
Go to System and Maintenance → Preference → Screen Display .
Figure 8-24 Sleep Sengs
Slide Sleep and set the sleep me.
Click Save.
DS-K1T344 Series Face Recognion Terminal User Manual
149
8.10.3 Customize Authencaon Desk via PC Web
Customize the modules on the authencaon page/desk.
Steps
1.
Go to System and Maintenance → Preference → Custom Home Page.
2.
Select
Applicaon Mode.
Figure 8-25 Select Applicaon Mode
Authencaon Mode
The live view will be displayed in authencaon, and in the meanwhile, the person's name,
employee ID, face pictures will all displayed as well.
Simple Mode
Aer selecng this mode, the authencaon page will not display the live view image. The
person's name, employee ID, face pictures will all be hidden aer authencaon.
3.
Click Apply.
8.10.4 Set
Noce Publicaon via PC Web
You can set the noce publicaon for the device.
Go to System and Maintenance → Preference →
Noce Publicaon .
DS-K1T344 Series Face Recognion Terminal User Manual
150
Figure 8-26 Noce Publicaon
Material Management
You can click + Add Theme, and set Theme Name and Theme Type.
Click Upload, and click + to upload the picture or video from the local PC.
Note
By now, there is only one theme can be added.
Add Program
You can set the program name and select program type.
If you select picture, you can click + to add picture.
Play Schedule
Aer you have created a theme, you can select the theme and draw a schedule on the me line.
Select the drawn schedule, and you can edit the exact start and end me.
Select the drawn schedule and you can click Delete or Delete All to delete the schedule.
Slide Show Interval
Drag the block or enter the number to set the slide show interval. The picture and video will be
changed according to the interval.
8.10.5 Set Prompt Schedule via PC Web
Customize the output audio content when authencaon succeeded and failed.
Steps
1.
Go to System and Maintenance → Preference → Prompt Schedule .
DS-K1T344 Series Face Recognion Terminal User Manual
151
Figure 8-27 Prompt Schedule
2.
Enable the funcon.
3.
Set the appellaon.
4.
Select me schedule.
5.
Set the me period when authencaon succeeded.
1) Click Add Time Duraon.
2) Set the
me duraon.
Note
If authencaon is succeeded in the congured me duraon, the device will broadcast the
congured content.
3) Set the audio prompt content.
4)
Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
6.
Set the me duraon when authencaon failed.
1) Click Add Time Duraon.
2) Set the
me duraon.
DS-K1T344 Series Face Recognion Terminal User Manual
152
Note
If authencaon is failed in the congured me duraon, the device will broadcast the
congured content.
3) Set the audio content.
4)
Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
7.
Click Save to save the sengs.
8.10.6 Customize Prompt Voice via PC Web
You can customize prompt voices for the device.
Steps
1.
Go to System and Maintenance → Preference → Custom Prompt .
Figure 8-28 Custom Prompt
2.
Click → and import audio le from local PC according to your actual needs.
Note
The uploaded audio le should be less than 512 kb, in WAV format.
8.10.7 Set Authencaon Result Text via PC Web
Steps
1.
Go to System and Maintenance → Preference →
Authencaon Result Text .
DS-K1T344 Series Face Recognion Terminal User Manual
153
Figure 8-29 Authencaon Result Text
2.
Enable Customize Authencaon Result Text.
3.
Enter custom texts.
4.
Click Save.
8.11 System and Maintenance
8.11.1 Reboot
You can reboot the device.
Click System and Maintenance → Maintenance → Restart to enter the
sengs page.
Click Restart to reboot the device.
8.11.2 Upgrade
Upgrade Locally via PC Web
You can upgrade the device locally.
Click System and Maintenance → Maintenance → Upgrade to enter the sengs page.
Select an upgrade type from the drop-down list. Click
and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
Online Upgrading via PC Web
You can upgrade the device online.
Click System and Maintenance → Maintenance → Upgarde to enter the sengs page.
ClickCheck for Updatesto check whether there is updated versions.
DS-K1T344 Series Face Recognion Terminal User Manual
154
If the device is connected to the network and added to Hik-Connect App, you can tap Device
Upgrade → Online Upgrade on device for upgrading when there is an updated version in Hik-
Connect App.
8.11.3 Restoraon
Restore to Factory Sengs via Web Browser
You can restore device to factory sengs.
Click System and Maintenance → Maintenance → Backup and Reset to enter the sengs page.
Click Restore All, all parameters will be restored to the factory sengs. You should acvate the
device before usage.
Restore to Default
Sengs via PC Web
You can restore device to default sengs.
Click System and Maintenance → Maintenance → Backup and Reset to enter the sengs page.
Click Restore, the device will restore to the default sengs, except for the device IP address and
the user
informaon.
8.11.4 Export Device Parameters via PC Web
Export device parameters.
Go to System and Maintenance → Maintenance → Backup and Reset .
Backup
Click Export to export device parameters.
Note
Export device parameters and import those parameters to other devices.
8.11.5 Import Device Parameters via PC Web
Import the conguraon parameters.
Go to System and Maintenance → Maintenance → Backup and Reset .
Import
Cong File
Click and select a le from local PC. Click Import.
DS-K1T344 Series Face Recognion Terminal User Manual
155
8.11.6 Device Debugging
You can set device debugging parameters.
Enable/Disable SSH via Web Browser
You can enable SSH to perform remote debugging.
Click System and Maintenance → Maintenance → Device Debugging → Log for Debugging.
Enable SSH
SSH is used for remote debugging. When you don’t need to use this service, it’s recommended
to disable SSH to improve security.
Print Device Log via PC Web
You can print out the device log.
Click System and Maintenance → Maintenance → Log to enter the sengs page.
ClickExport to print out the device log.
Capture Network Packet via PC Web
Set the capture packet duraon and size and start caputre. You can view the log and debug
according to the capture result.
Go to System and Maintenance → Maintenance → Device Debugging → Log for Debugging .
Set Capture Packet
Duraon,Capture Packet Size, and click Start Capture.
Test Protocol via PC Web
Select a protocol address, and enter the protocol to test. You can debug the device according to
the response header and returned value.
Go to System and Maintenance → Maintenance → Device Debugging → Protocol
Tesng .
DS-K1T344 Series Face Recognion Terminal User Manual
156
Figure 8-30 Protocol Tesng
Select a protocol address, and enter the protocol. Click Execute.
Debug the device according to the response header and returned value.
8.11.7 View Log via PC Web
You can search and view the device logs.
Go to System and Maintenance → Maintenance → Log .
Set the major and minor type of the log type. Set the start
me and end me for searching, and
click Search.
The results will be displayed below, which including the No.,
me, the major type the minor type,
the channel No., the local/remote user informaon, the remote host IP, etc.
8.11.8 Advanced
Sengs via PC Web
You can congure face parameters and view version informaon.
Go to System and Maintenance → Maintenance → Advanced Sengs .
Enter the device
acvaon password and click Enter.
Face Parameter
Enable Custom An-Spoong Detecon and you can set the An-Spoong Detecon Threshold
1:1, An-Spoong Detecon Threshold 1:N.
DS-K1T344 Series Face Recognion Terminal User Manual
157
Enable Lock Face for Authencaon, and set Lock Duraon. The face will be locked for the set lock
duraon aer the failed aempt limit of an-spoong detecon has been reached.
Click Save.
Version Informaon
You can view the dierent version informaon here.
8.11.9 Security Management
Set security level when login the PC web.
Go to System and Maintenance → Safe → Security Service .
Security Mode
High security level when logging in and verify user informaon.
Compable Mode
Compable with old user vericaon method.
Click Save.
8.11.10
Cercate Management
It helps to manage the server/client cercates and CA cercate.
Note
The funcon is only supported by certain device models.
Create and Import Self-signed Cercate
Steps
1.
Go to System and Maintenance → Safe → Cercate Management .
2.
In the
Cercate Files area, select a Cercate Type from the drop-down list.
3.
Click Create.
4.
Input cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The
cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking
le to a cercaon authority for signature.
8.
Import the signed cercate.
1) Select a cercate type in the Import Key area, and select a cercate from the local, and
click Import.
DS-K1T344 Series Face Recognion Terminal User Manual
158
2) Select a cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Import.
Import Other Authorized Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to System and Maintenance → Safe →
Cercate Management .
2.
In the Import Key and Import Communicaon Cercate areas, select cercate type and
upload cercate.
3.
Click Import.
Import CA
Cercate
Before You Start
Prepare a CA
cercate in advance.
Steps
1.
Go to System and Maintenance → Safe → Cercate Management .
2.
Create an ID in the Import CA Cercate area.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Import.
DS-K1T344 Series Face Recognion Terminal User Manual
159
Appendix A. Tips for Scanning Fingerprint
Recommended Finger
Forenger, middle nger or the third nger.
Correct Scanning
The gure displayed below is the correct way to scan your nger:
You should press your nger on the scanner horizontally. The center of your scanned nger should
align with the scanner center.
Incorrect Scanning
The gures of scanning ngerprint displayed below are incorrect:
DS-K1T344 Series Face Recognion Terminal User Manual
160
Environment
The scanner should avoid direct sun light, high temperature, humid condions and rain.
When it is dry, the scanner may not recognize your
ngerprint successfully. You can blow your
nger and scan again.
Others
If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other
authencaon methods.
If you have injuries on the scanned nger, the scanner may not recognize. You can change another
nger and try again.
DS-K1T344 Series Face Recognion Terminal User Manual
161
Appendix B. Tips When Collecng/Comparing Face
The
posion when collecng or comparing face picture is as below:
Posions (Recommended Distance: 0.5 m)
Expression
●
Keep your expression naturally when
collecng or comparing face pictures, just like the
expression in the picture below.
●
Do not wear hat, sunglasses, or other accessories that can
aect the facial recognion funcon.
●
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
Posture
In order to get a good quality and accurate face picture, posion your face looking at the camera
when
collecng or comparing face pictures.
DS-K1T344 Series Face Recognion Terminal User Manual
162
Size
Make sure your face is in the middle of the collecng window.
DS-K1T344 Series Face Recognion Terminal User Manual
163
Appendix C. Tips for Installaon Environment
1. Light Source Illuminaon Reference Value
Candle: 10Lux
Bulb: 100~850Lux
Sunlight: More than 1200Lux
2. Avoid backlight, direct and indirect sunlight
DS-K1T344 Series Face Recognion Terminal User Manual
164
Appendix D. Dimension
Figure D-1 Dimension (Unit: mm)
DS-K1T344 Series Face Recognion Terminal User Manual
165
Appendix E. Legal Informaon
About this Document
●
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other
informaon hereinaer are for descripon and explanaon only.
●
The
informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
●
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
●
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
●
If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
●
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
●
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without
wrien permission.
●
and other Hikvision's trademarks and logos are the properes of Hikvision in
various
jurisdicons.
●
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
●
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
DS-K1T344 Series Face Recognion Terminal User Manual
166
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
Data
Protecon
●
To protect data, the development of Hikvision Products incorporates privacy by design
principles. For example, for Products with facial
recognion features, biometrics data is stored in
your Products with encrypon method; for ngerprint Products, only ngerprint template will be
saved, which is impossible to reconstruct a
ngerprint image.
●
As a data controller/processor, you may process personal data, including collecon, storage, use,
processing, disclosure,
deleon, etc. You are advised to pay aenon to and comply with
applicable laws and regulaons related to the protecon of personal data, including without
limitaon, conducng security controls to safeguard personal data, such as, implemenng
reasonable administrave and physical security controls, conduct periodic reviews and the
assessments of the
eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
DS-K1T344 Series Face Recognion Terminal User Manual
167
Appendix F. Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-K1T344 Series Face Recognion Terminal User Manual
168
UD37803B
