WIRELESS HANDHELD MICROPHONE SYSTEM SPECIFICATION
Please read carefully before use and keep for future reference.
TRANSMITTER
1. Power switch
2. Display screen
3. Frequency selective buttons
4. Battery case
www.PyleUSA.com
1
www.PyleUSA.com
2
RECEIVER
Front Panel
Back Panel
1. Antenna for B channel
2. DC12V Power supply
3. 6.35 Mixed output port
4. Right channel 6.35 output port
1. Mic C/6.35 Input port
2. Mic D/6.35 Input port
3. Volume adjustment for channel C
4. Volume adjustment for channel D
5. Volume adjustment for channel A
6. Volume adjustment for channel B
7. Echo adjustment
8. Music Volume adjustment
9. USB 2.1 input port
10. MP3 module display
11. Switch button (Bluetooth/MP3)
12. Power switch
13. Multi function button
(Pause/Play/Next/Last)
14. Recording Button
5. The left Channel 6.35 output port
6. Stereo 3.5mm Audio intput port
7. Stereo 3.5mm Audio output port
8. Antenna for A channel
