STEP2 Press and hold the [HOME]
key for 5 seconds until the
POWER LED will blink once
and stays on. Continue to
hold the [HOME] key and
press the number key
assigned to your brand in
the Quick Set-up Code Table
and release both [HOME]
key and the number key to
save the code. The POWER
LED will blink twice to
confirm that the code is
stored.
STEP3 Point the remote control at
the component.
STEP4 Press the power button. If it
turns off, it is programmed
for your component. If it
does not turn off, use the
Pre-Programmed 3-Digit
code Method or Scanning
Method.
B. Quick Set-up Code Tables
B. Quick Set-up Code Tables
C.
C.
Manual Programming
Manual Programming
The remote control can be programmed
by entering a three-digit code number
that corresponds to particular brands
and models of equipment. The three-
digit code numbers are listed in the
code tables sections of this instruction
manual.
STEP1 Turn on the equipment that
you want the remote con-
trol to operate TV.
STEP2 Press the [HOME] button
and the [OK/SEL] button
simultaneously for 3 seconds.
The POWER LED will turn
on indicating that it is ready
to be programmed. The LED
will remain on for 30
seconds. The next step
must be entered while the
LED is on.
STEP3 Point the remote control
toward the equipment and
enter the three-digit code
number assigned to your
brand from the code tables.
If there are more than one
three-digit number listed for
your brand, try one code
number at a time until your
equipment turns off.
*Note: You can verify that you have
selected the correct code by
pressing the [POWER] button.
The equipment should turn
back on. Then try all of the
functions on the remote
control (i.e. volume, mute,
etc.) to ensure you have the
correct code. If any of the
functions do not operate as
they should, repeat the
instructions from STEP 3
above using the next three
digit code number from the
brand list.
you have the correct code. If
any of the functions do not
operate as they should,
repeat the instructions from
STEP 3 above to continue
the Auto Search Method.
STEP4 Press the [HOME] button to
store the code. The POWER
LED will blink twice to
confirm that the code has
been stored.
E.
E.
The Learning Method
The Learning Method
STEP1 Press the [POWER] button
to be programmed and the
[
#
] buttons simultaneously for
3 seconds until the LED light
turns on.
STEP2 Point the remote at the other
remote, head-to-head, 1 or 2
inches apart.
STEP3 Press the button on the remote
that you want to teach a
command to. For example,
press the [MUTE] button to
learn a command to the [MUTE]
button.
STEP4 Press and hold the button on
the other remote that
corresponds to the command
you want to teach until the
LED light blinks twice.
*Note : The LED will blink 5 times if there
was an error in the learning
process. Repeat STEPS 3 and 4 if
this occurs. Continue learning
other buttons by repeating STEPS
3 and 4.
STEP5 Once you have completed
teaching the remote all
desired commands for the
STEP4 Store the three-digit code
by pressing the [HOME]
button once again. The
POWER LED will blink twice
to confirm that the code has
been stored.
D. Auto Search Method
D. Auto Search Method
If none of the three digit code numbers
assigned to your brand of equipment
works, or the code table does not list
your brand, you can use the Auto
Search Method to find the correct
three-digit code number for your
equipment by following steps:
STEP1 Turn on the equipment that
you want the remote control
to operate TV.
STEP2 Press the [HOME] button
and the [OK/SEL] button
simultaneously for 3 seconds.
The POWER LED will turn
on indicating that it is ready
to be programmed. The LED
will remain on for 30 seconds.
The next step must be enter-
ed while the LED is on.
STEP3 Press the [CH
5] or [CH6]
button one at a time or keep
it pressed. The remote will
emit a series of Power
ON/OFF code signals. Release
the [CH
5] or [CH6] button
as soon as the equipment
turns off.
*Note: You can verify that you have
selected the correct code by
pressing the [POWER]
button. The equipment
should turn back on. Then
try all of the functions on
the remote control (i.e.
volume, mute, etc.) to ensure
Button Functions
3
Programming the Remote Control
4
POWER
+ / -
ON DEMAND
Provides direct access
to On Demand channel.
LIGHT BUTTON
Press to backlight all keypad
buttons. Press again to turn
off (or simply wait 10 seconds
for automatic shut-off).
TRANSPORT
Selects items to control the
playback of what is being
viewed.
#
Changes the HD screen
viewing aspect ratio through
the Cable STB.
*
Reserved for future use.
Universal Remote Control, Inc.
www.universalremote.com
OCE-0082G REV 23 (03/21/23)
UR2L-R803
OperatingManual
ForEasyClicke r
This remote control is designed
to operate Cable boxes and
TVs.
Introduction
1
Replacing Batteries
2
Before you program or operate the
remote control, you must install
two new AAA alkaline batteries.
STEP1 Remove the battery com-
partment cover from the
back of your remote control.
STEP2 Check battery polarity
carefully, and install the
batteries as shown in the
illustration below.
STEP3
Replace the battery com-
partment cover.
A. Quick Set-Up Method
A. Quick Set-Up Method
(Refer to the Section B Quick Set-up table of codes)
STEP1 Turn on the component you want to program. To program your TV, turn on the TV.
0 SANYO
1 SONY
2 SAMSUNG
3 LG
4 TOSHIBA
5 PANASONIC
6 PHILIPS
7 HITACHI
8 SHARP
9 VIZIO
Quick Number
Manufacturer/Brand
TV
