Refrigerator
use & care
A28067201 (March 2024)
Introduction .......................................................2
Important Safety information.....................3
Features .............................................................5
Installation .........................................................6
Door Reversal ...................................................8
Water Supply Connection .......................... 10
Ice Maker .......................................................... 12
Controls and Settings ................................. 13
Storage Features ........................................... 14
Care and Cleaning ........................................ 15
Troubleshooting ........................................... 17
Limited Warranty .......................................... 18
2
INTRODUCTION
Doors
Refrigerator door seals completely
to cabinet on all sides
Freezer door is level from side to
side across the top
Leveling
Refrigerator is level side-to-side and
tilted ¼" (6 mm) front-to-back
Cabinet is set solid on all corners
Anti-tip bracket set in front (both sides)
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker (optional accessory)
House water supply connected
to refrigerator (Warning: Potable
water supply only.)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Final Checks
Shipping material removed
Refrigerator and freezer tempera-
tures set to recommended setting
Crisper humidity controls set
Registration card sent in
Installation Checklist
Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number ____________________
Serial Number ____________________
Purchase Date ____________________
FPO
Serial location
Serial Number Location
3
WARNING
WARNING indicates a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Definitions
This is the safety alert symbol. It is used
to alert of potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
flammability and other hazards.
• DO NOT operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
with other appliances or furniture.
WARNING
Please read all instructions before using
this appliance.
Child Safety
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after you unpack the
refrigerator. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
IMPORTANT SAFETY INFORMATION
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be re-
paired only by trained service person-
nel. Use only manufacturer-authorized
service parts. Any repair equipment
used must be designed for flammable
refrigerants. Follow all manufacturer
repair instructions. Do not puncture
refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion. Dispose
of refrigerator properly in accordance with
the applicable federal or local regulations.
Flammable refrigerant used.
CAUTION Risk of fire or explosion due
to puncture of refrigerant tubing. Follow
handling instructions carefully. Flammable
refrigerant used.
4
IMPORTANT SAFETY INFORMATION
Proper Disposal of your Appliance
Risk of child entrapment
Child entrapment and suocation are
not problems of the past. Junked or
abandoned appliances are still dangerous
– even if they will sit for “just a few days”.
If you are getting rid of your old unit,
please follow the instructions below to
help prevent accidents.
We strongly encourage responsible
appliance recycling/disposal methods.
Check with your utility company or visit
energystar.gov/recycle for more informa-
tion on recycling your old appliance.
Before you throw
away your old unit:
• Remove doors.
• Leave shelves in
place so children
may not easily
climb inside.
• Have refrigerant removed by a
qualified service technician.
WARNING
Follow these guidelines to ensure
safety mechanisms in this appliance
will operate properly.
Electrical information
• Plug the unit into its own dedicated 115
Volt, 60 Hz., 15 Amp, AC only elec-
trical outlet. The power cord of the
appliance is equipped with a 3-prong
grounding plug for your protection
against electrical shock hazards. Plug
it directly into a properly grounded
3-prong receptacle. You must install
the receptacle in accordance with local
codes and ordinances. Consult a qual-
ified electrician. Avoid connecting the
unit to a Ground Fault Interrupter (GFI)
circuit. Do not use an extension cord
or adapter plug.
• If the power cord is damaged, an
authorized service technician should
replace it to prevent any risk.
• Never unplug the refrigerator by pull-
ing on the power cord. Always grip the
plug firmly, and pull it straight out from
the receptacle to prevent damaging
the power cord.
• Unplug the appliance before cleaning
and before replacing the AC LED light
bulb to avoid electrical shock. Use only
a 5-watt or less AC LED light bulb.
• Performance may be aected if the
voltage varies by 10% or more. Oper-
ating the refrigerator with insucient
power can damage the compressor.
Such damage is not covered under
your warranty.
• Do not plug the unit into an electri-
cal outlet controlled by a wall switch
or pull cord to prevent the unit from
being turned o accidentally.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
IMPORTANT
CFC/HCFC Disposal
Your old refrigerator may have a cooling
system that used CFCs or HCFCs (chlo-
rofluorocarbons or hydrochlorofluoro-
carbons). CFCs and HCFCs are believed
to harm stratospheric ozone if released
to the atmosphere. Other refrigerants
may also cause harm to the environ-
ment if released to the atmosphere.
If you are throwing away your old
refrigerator, make sure the refrigerant
is removed for proper disposal by a
qualified technician. If you intentionally
release refrigerant, you may be subject
to fines and imprisonment under provi-
sions of environmental legislation.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
5
FEATURES
A Crisper
B Refrigerator Glass Shelves
C Appliance Controls
D Freezer Glass Shelf
E Freezer Door Bins
F Refrigerator Door Bins
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.
A
B
C
D
E
F
B
E
F
6
INSTALLATION
IMPORTANT
Cleaning your Refrigerator
Remove tape and glue residue from
surfaces before turning the refriger-
ator on. Rub a small amount of liquid
dish soap over the adhesive with your
fingers. Rinse with warm water and dry
with a soft cloth.
Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These
products can damage the surface of
your refrigerator.
After you remove all of the package ma-
terials, clean the inside of your refriger-
ator before using it. See the CARE AND
CLEANING section in this manual.
IMPORTANT
Moving your Refrigerator
Your refrigerator is heavy. When moving
the refrigerator for cleaning or service,
raise the leveling feet (see To level the
cabinet using the front leveling feet).
Also be sure to cover the floor with card-
board or hardboard to avoid floor dam-
age. Always pull the refrigerator straight
out when moving it. Do not wiggle or
“walk” the refrigerator when trying to
move it as you could damage the floor.
This Use & Care Manual provides general
operating instructions for your model. Use
the appliance only as instructed in this
Use & Care Manual. Before starting the
unit, follow these important first steps.
Location
• Choose a place that is near a grounded
electrical outlet. Do Not use an exten-
sion cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher or other heat sources.
• Install the refrigerator on a floor that is
level and strong enough to support a
fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic ice
maker. If you do not hook up water to
the refrigerator, remember to turn the
ice maker o.
WARNING
This appliance is intended for use
in residential household and similar
interior applications such as:
• Kitchen / Kitchenette
• Pantry Room
• Basement
• Enclosed Garage
• Other interior
residential-type environments
7
NOTE
If you place your refrigerator with the
door hinge side against a wall, you may
have to allow additional space for the
handle so you can open the door wider.
Guidelines for final positioning of
your refrigerator:
• Rest all 4 corners of the cabinet
firmly on the floor.
• The cabinet should be level at the
front and rear.
• The sides should tilt ¼" (6 mm) from
front to back (to ensure that doors
close and seal properly).
• Doors should align with each other
and be level.
CAUTION
Do not install the refrigerator where
the temperature will drop below 55°F
(12.8°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside
the refrigerator.
Do not block the lower front of your
refrigerator. Sucient air circulation is
essential for the proper operation of
your refrigerator.
INSTALLATION
WARNING
Installation clearances
Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides, Top 3.93" (100 mm)
Back 2.95" (75 mm)
To level the cabinet using the front
leveling feet:
• Lower the leveling feet on each side
clockwise until they contact the floor.
Lower Raise
• Use the leveling feet (located on the
front) ensuring all 4 corners of the
unit are resting firmly on a solid floor.
Turn the leveling feet clockwise to
retract the feet and counterclockwise
to extend the feet. Ensure the floor
is strong enough to support a fully
loaded unit.
Top View
>100mm
>100mm
>100mm
<75mm
>100mm
>100mm
65 " (1649 mm)
28" (700 mm)
29" (731 mm)
43" (1085 mm)
52" (1310 mm)
135°
26"
(650 mm)
65 " (1649 mm)
8
DOOR REVERSAL
1. Unplug your refrigerator and remove
all food from it.
2. Remove the top hinge cover, screws
and upper hinge on the top of the
cabinet and the cover plate on the
left. Lift up the freezer door.
3. a. Remove the hinge screws and
the hinge plug from the center
hinge on the right side.
b. Remove the center screw
and cap and the plug pins
from the left side. Lift up the
refrigerator door.
Lay the refrigerator down on a
protected surface.
Phillips Screwdriver Allen Wrench
Flat Head Screwdriver
or Putty Knife
5/16" socket
and ratchet
Required Tools
4. Unscrew the lower hinge screws on
the right side and adjusting feet on
both sides.
A
B
5. Remove the hinge pin from the
lower hinge, and reinstall it into the
hole on the opposite side of the
hinge.
6. I
nstall the lower hinge on the left side
and tighten the screws. Install the two
adjusting feet on both sides, and place
the refrigerator upright.
9
DOOR REVERSAL
7. a. Unscrew and remove the right
hinge sleeves, stoppers and lock
rings of both doors.
b. Take out the left door lock ring
from the accessory bag, and
install it to the left corners of
each door with the stoppers and
hinge sleeves.
c. Take out the hole plug and
hinge sleeve on the tops of each
door and install them on the
opposite side.
8. Lower the refrigerator door
in the open position onto the
bottom hinge.
B
C
B
A
A
B
A
9. a. Install the center hinge with
the hinge screws and hinge
plug on the left side. Tighten
the screws.
b. Insert the plug pins and the
center screw and cap on the
right side.
B
C
A
10. a. Locate the top hinge. Remove
the hinge pin from the right side
and place it on the left side.
b.
Replace the upper hinge, cover
and hinge screws on the left side.
c. Replace the hinge cover on the
right side.
1
2
10
WATER SUPPLY CONNECTION
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the refrigerator from elec-
trical power before connecting a water
supply line to the refrigerator.
CAUTION
To Avoid Property Damage:
• Use stainless steel braided tubing
for the water supply line. Do not
use water supply tubing made of
¼" plastic. Plastic tubing greatly
increases the potential for water
leaks, and the manufacturer will not
be responsible for any damage if you
use plastic tubing for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
softener can damage the ice maker.
If the ice maker is connected to soft
water, ensure that the softener is
maintained and working properly.
IMPORTANT
Ensure your water supply line connections
comply with all local plumbing codes.
NOTE
Check with your local building authority
for recommendations on water lines and
associated materials prior to installing
your new refrigerator. Depending on
your local/state building codes, we
recommend for homes with existing
valves Smart Choice
®
water line kit
5304437642 (with a 6' Stainless Steel
Water Line), and for homes without an
existing valve, we recommend Smart
Choice
®
water line kit 5304493869 (with
a 6’ Polyline Waterline). Please refer to
Frigidaire.com for more information.
Before Installing The Water Supply Line,
You Will Need:
• Basic Tools: adjustable wrench,
flat-blade screwdriver, and Phillips
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100 psi.
• A water supply line made of stainless
steel tubing. To determine the length
of tubing needed, measure the dis-
tance from the ice maker inlet valve
at the back of the refrigerator to your
cold water pipe, so the refrigerator
can be moved out for cleaning.
• A shuto valve to connect the water
supply line to your household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
Ice Maker Models Only
NOTE
Automatic ice makers are optional ac-
cessories you may install in most models
at any time. Visit Frigidaire.com for infor-
mation about Ice Maker Kit IM1900MD.
11
To Connect the Water Supply Line To the
Ice Maker Inlet Valve
1. Disconnect the refrigerator from the
electrical power source.
2. Place the end of water supply line
into a sink or bucket. Turn ON the
water supply and flush the supply
line until the water is clear. Turn OFF
the water supply at the shuto valve.
3. Remove the plastic cap from the wa-
ter valve inlet and discard the cap.
4. If you use copper tubing, slide brass
compression nut, and then the fer-
rule (sleeve) onto the water supply
line. Push the water supply line into
the water valve inlet as far as it will
go (¼" / 6.4 mm). Slide the ferrule
(sleeve) into valve inlet and finger
tighten the compression nut onto
the valve. Tighten another ½ turn
with a wrench; DO NOT overtighten.
See below.
If you use braided flexible stain-
less steel tubing, the nut is already
assembled on the tubing. Slide the
nut onto the valve inlet and finger
tighten the nut onto valve. Tighten
another ½ turn with a wrench; DO
NOT overtighten. See below.
5. With the steel clamp and screw,
secure the water supply line (copper
tubing only) to the rear panel of
refrigerator as shown.
6. Coil the excess water supply line
(copper tubing only), about 2½
turns, behind the refrigerator as
shown and arrange the coils so they
do not vibrate or wear against any
other surface.
7. To turn the ice maker on, press the
ice maker’s On/O power switch.
8. Turn ON the water supply at the
shuto valve and tighten any con-
nections that leak.
9. Reconnect the refrigerator to the
electrical power source.
WATER SUPPLY CONNECTION
Water Valve
Bracket
Valve Inlet
Water Valve
6 ft minimum (1.8 m)
braided flexible stainless steel
water line from household water supply
Plastic Water
Tubing to Ice
Maker Fill Tube
(Include enough tubing in to allow
moving refrigerator out for cleaning.)
½" Clamp
Units with access cover
Water Valve
Bracket
Valve Inlet
Water Valve
6 ft minimum (1.8 m)
braided flexible stainless steel
water line from household water supply
Plastic Water Tubing
to Ice Maker
Fill Tube
(Include enough tubing to allow
moving refrigerator out for cleaning.)
½" Clamp
Units without access cover
12
ICE PRODUCTION: WHAT
TO EXPECT
The ice maker produces 2 to 2.5 pounds
of ice every 24 hours depending on usage
conditions. Ice is produced at a rate of 10
cubes every 100 to 160 minutes.
CAUTION
Do Not place the ice container in
your dishwasher.
ICE MAKER
If your refrigerator has an automatic ice
maker, it will produce minimal ice during
the first 24 hours of operation. Air in new
plumbing lines may cause the ice maker to
cycle 2 or 3 times before making a full tray
of ice. With no usage, it will take approxi-
mately 1 to 2 days to fill the ice container.
New plumbing connections may cause
the first production of ice cubes to be
discolored or have an odd flavor. Discard
ice made during the first 24 hours.
Turning your Ice Maker On
After completely connecting the
plumbing, you must open the water
supply valve. Place the ice container
under the ice maker, pushing it as far back
as possible. Press the ice maker’s On/O
button.
Turning your Ice Maker O
To stop the ice maker, press the ice mak-
er’s On/O button. The ice maker regu-
lates the ice production and stops making
ice when full and starts again when ice is
low in the ice container.
IMPORTANT
The ice maker is shipped in the On
position. To ensure proper function for
your ice maker, hook up the water sup-
ply immediately or turn the ice maker
O. If the ice maker is on and the water
supply is not connected, the water
valve will make a loud chattering noise.
NOTE
Automatic ice makers are optional ac-
cessories you may install in most models
at any time. Visit Frigidaire.com for infor-
mation about Ice Maker Kit IM1900MD.
NOTE
Set the freezer to a colder setting to in-
crease the output of the ice maker. Allow
24 hours for the temperature to stabilize.
13
CONTROLS AND SETTINGS
1
2
Refrigerator Temperature
Adjustment
You can leave the refrigerator control at
the factory pre-set (Recommended) or
adjust as desired to any of the 5 positions.
• Adjusting the temperature
control knob to Cold elevates the
temperature inside the refrigerator.
• Adjusting the temperature control
knob to Coldest lowers the
temperature inside the refrigerator.
• The settings do not specifically refer
to a certain temperature.
Freezer Temperature Adjustment
You can leave the freezer control at the
factory pre-set (Recommended) or adjust
as desired.
• Adjusting the temperature
control knob to Cold elevates the
temperature inside the freezer.
• Adjusting the temperature control
knob to Coldest lowers the
temperature inside the freezer.
• The settings do not specifically refer
to a certain temperature.
NOTE
Allow 24 hours for the temperature to stabilize after each adjustment.
14
STORAGE FEATURES
Shelves
The shelves are easy to adjust to suit
individual needs. Before adjusting the
shelves, remove all food.
To remove the shelves:
1. Use one hand to tilt the front of the
shelf up.
2. Use your other hand to lift the shelf
out from the liner.
Door Storage
Door bins and shelves conveniently store
jars, bottles, and cans, so you can quickly
select frequently used items.
Door Bins
Door bins can accommodate gallon-sized
plastic drink containers and econo-
my-sized jars and containers.
To remove the door bin:
1. Use both hands to squeeze the sides
of the bin.
2. Lift the bin up to remove it.
CAUTION
Do not clean glass shelves or covers
with warm water when they are cold.
Shelves and covers may break if ex-
posed to sudden temperature changes
or impact, such as bumping. Tempered
glass is designed to shatter into many
small, pebble-size pieces. This is nor-
mal. Glass shelves and covers are heavy.
Use both hands when removing them
to avoid dropping.
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to sud-
den temperature change.
CAUTION
When reinstalling the shelf, ensure the
shelf clip is attached to the liner and
holds it in place.
Crisper
The crisper humidity control, present on
the crispers of some models, allows you to
adjust the humidity within the crisper. This
can extend the life of fresh vegetables that
keep best in high humidity.
To remove the crisper:
1. Remove the contents of the crisper.
2. Hold the handle, and lift the drawer
to completely pull the crisper out.
15
CARE AND CLEANING
Protecting your investment
Keeping your refrigerator clean maintains
appearance and prevents odor build-up.
Wipe up any spills immediately and clean
the freezer and refrigerator compartments
at least twice a year. When cleaning, take
the following precautions:
• Never use CHLORIDE or cleaners with
bleach to clean stainless steel.
• Do not wash any removable parts in
a dishwasher.
• Always unplug the electrical power cord
from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do
not use razor blades or other sharp
instruments which can scratch the
appliance surface.
• Do not remove the serial plate.
Do not use abrasive cleaners such as win-
dow sprays, scouring cleansers, brushes,
flammable fluids, cleaning waxes, concen-
trated detergents, bleaches or cleansers
containing petroleum products on plastic
parts, interior doors, gaskets or cabinet
liners. Do not use paper towels, metallic
scouring pads, or other abrasive cleaning
materials or strong alkaline solutions.
Defrosting
The unit defrosts automatically due to
air cooling. You can remove frost by first
disconnecting the appliance from the
electrical power source, and wipe it with
a dry towel.
CAUTION
Pull the refrigerator straight out to
move it. Shifting it from side to side
may damage flooring. Be careful not to
move the refrigerator beyond the
plumbing connections.
IMPORTANT
If you store or move your refrigerator in
freezing temperatures, be sure to com-
pletely drain the water supply system.
Failure to do so could result in water
leaks when the refrigerator is put back
into service. Contact a service repre-
sentative to perform this operation.
NOTE
If you set your temperature controls
to turn o cooling, power to lights and
other electrical components will con-
tinue until you unplug the power cord
from the wall outlet.
16
Care and Cleaning Tips
Part What To Use Tips and Precautions
Interior
& Door
Liners
• Soap and water
• Baking soda
and water
Use 2 tbsp of baking soda in 1 qt of warm
water. Be sure to wring excess water out
of sponge or cloth before cleaning around
controls, light bulb or any electrical part.
Door
Gaskets
• Soap and water Wipe gaskets with a clean soft cloth.
Drawers &
Bins
• Soap and water Use a soft cloth to clean drawer runners
and tracks.
Glass
Shelves
• Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature
before immersing in warm water.
Replacing
Light
Bulbs
• Unplug appliance
• Wear gloves
• Remove light cover
• Replace old bulb
• Replace light cover
• Plug in the appliance
CAUTION: Wear gloves when replacing the AC
LED light bulbs to avoid getting cut. Use same
wattage when replacing bulb.
CAUTION: Use only a 5-watt or less AC LED
light bulb.
CARE AND CLEANING
17
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
TROUBLESHOOTING
Common Occurences
Refrigerator does not run. • Ensure the plug is tightly pushed into an
electrical outlet.
• Check/replace the fuse with a 15-amp time-delay
fuse. Reset the circuit breaker.
• The refrigerator control is turned to OFF.
• Refrigerator may be in defrost cycle. Wait 20
minutes and check again.
Freezer temperature is colder
than preferred. Refrigerator
temperature is satisfactory.
• Set the auxiliary freezer control to a warmer
setting until the freezer temperature is satisfactory.
Allow 24 hours for the temperature to stabilize.
Refrigerator temperature is
too cold. Freezer temperature
is satisfactory.
• Set the refrigerator control to a warmer setting.
Allow 24 hours for the temperature to stabilize. Then
check the freezer temperature and adjust as needed.
Freezer temperature is
warmer than preferred.
Refrigerator temperature
is satisfactory.
• Set the auxiliary freezer control to a colder setting
until the freezer temperature is satisfactory. Allow
24 hours for the temperature to stabilize.
Refrigerator temperature
is too warm. Freezer
temperature is satisfactory.
• Set the refrigerator control to a colder setting. Allow
24 hours for temperature to stabilize. Then check
refrigerator temperature and adjust as needed.
Refrigerator is noisy
or vibrates.
• The cabinet is not level.
• Floor is weak.
Odors in the refrigerator. • The interior needs to be cleaned.
• Foods that produce odors should be covered or
wrapped.
Cabinet light is not working. • Replace with only a 5-watt or less AC LED light bulb.
• Ensure the plug is tightly pushed into an
electrical outlet.
• The light switch may be stuck. Push in the light
switch, located on the refrigerator side wall, to release.
Automatic ice maker is not
working (some models)
• Ensure the ice maker is on.
• The ice maker should produce 2 to 2.5 pounds of
ice in a 24 hour period.
• Ensure the water supply is turned on.
• The water pressure may be too low.
• The freezer may not be cold enough.
Ice Maker is not making
enough ice (some models)
• Set the freezer control to a colder setting to
improve the performance of the ice maker. Allow
24 hours for the temperature to stabilize.
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
18
LIMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your date of
delivery, Electrolux will pay all costs for repairing or replacing any parts of this appliance that
prove to be defective in materials or workmanship when such appliance is installed, used and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be
readily determined.
2. Product that has been transferred from its original owner to another party or removed outside
the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or
for appliances not in ordinary household use or used other than in accordance with the
provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use
your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables,
or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls,
tolls, ferry trip charges, or mileage expense for service calls to remote areas, including the state
of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not
limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other
than genuine Electrolux parts or parts obtained from persons other than authorized service
companies; or external causes such as abuse, misuse, inadequate power supply, accidents, fires,
or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED
WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT
LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY
BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND
PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted
by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In
Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person
to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product
features or specifications as described or illustrated are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Frigidaire.com
1-800-374-4432
Frigidaire.ca
1-800-265-8352
owner support
accessories
service
Our home is your home. Visit us if you
need help with any of these things:
registration
(See your registration card
for more information.)
welcome home
