Hikvision DS-K1T502DBWX Access Control Terminal User Manual

DS-K1T502 Series Access Control Terminal

User Manual

Legal Informaon

About this Document

●

This Document includes instrucons for using and managing the Product. Pictures, charts,

images and all other

informaon hereinaer are for descripon and explanaon only.

●

The

informaon contained in the Document is subject to change, without noce, due to

rmware updates or other reasons. Please nd the latest version of the Document at the

Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision

Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no

warranes, express or implied.

●

Please use the Document with the guidance and assistance of professionals trained in

supporng the Product.

About this Product

●

This product can only enjoy the aer-sales service support in the country or region where the

purchase is made.

●

If the product you choose is a video product, please scan the following QR code to obtain the

"Iniaves on the Use of Video Products", and read it carefully.

Acknowledgment of Intellectual Property Rights

●

Hikvision owns the copyrights and/or patents related to the technology embodied in the

Products described in this Document, which may include licenses obtained from third pares.

●

Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part

of this Document may be excerpted, copied, translated, or modied in whole or in part by any

means without

wrien permission.

●

and other Hikvision's trademarks and logos are the properes of Hikvision in

various

jurisdicons.

●

Other trademarks and logos menoned are the properes of their respecve owners.

LEGAL DISCLAIMER

●

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE

PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS

IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR

DS-K1T502 Series Access Control Terminal User Manual

IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR

FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.

IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,

INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF

BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR

LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING

NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE

PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR

LOSS.

●

YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY

RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,

VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE

TIMELY TECHNICAL SUPPORT IF REQUIRED.

●

YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE

SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.

ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT

INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF

PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY

RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT

RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF

HUMAN RIGHTS ABUSES.

●

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE

LATTER PREVAILS.

Data

Protecon

●

To protect data, the development of Hikvision Products incorporates privacy by design

principles. For example, for Products with facial

recognion features, biometrics data is stored in

your Products with encrypon method; for ngerprint Products, only ngerprint template will be

saved, which is impossible to reconstruct a

ngerprint image.

●

As a data controller/processor, you may process personal data, including collecon, storage, use,

processing, disclosure,

deleon, etc. You are advised to pay aenon to and comply with

applicable laws and regulaons related to the protecon of personal data, including without

limitaon, conducng security controls to safeguard personal data, such as, implemenng

reasonable administrave and physical security controls, conduct periodic reviews and the

assessments of the

eecveness of your security controls.

DS-K1T502 Series Access Control Terminal User Manual

Symbol Convenons

The symbols that may be found in this document are dened as follows.

Symbol Descripon

Danger

Indicates a hazardous situaon which, if not avoided, will or could

result in death or serious injury.

Cauon

Indicates a potenally hazardous situaon which, if not avoided, could

result in equipment damage, data loss, performance degradaon, or

unexpected results.

Note

Provides addional informaon to emphasize or supplement

important points of the main text.

DS-K1T502 Series Access Control Terminal User Manual

iii

Regulatory Informaon

FCC Informaon

Please take aenon that changes or modicaon not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable

protecon against harmful interference in a residenal installaon. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the

instrucons, may cause harmful interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular installaon. If this equipment does

cause harmful interference to radio or television

recepon, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the

separaon between the equipment and receiver.

—Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help

This equipment should be installed and operated with a minimum distance 20cm between the

radiator and your body.

FCC

Condions

This device complies with part 15 of the FCC Rules. Operaon is subject to the following two

condions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired

operaon.

DS-K1T502 Series Access Control Terminal User Manual

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

under the EMC Direcve 2014/30/EU, the RoHS Direcve 2011/65/EU

2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment,

or dispose of it at designated

collecon points. For more informaon see:

www.recyclethis.info

2006/66/EC (baery direcve): This product contains a baery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentaon for specic baery informaon. The baery is marked with this

symbol, which may include

leering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the

baery to your supplier or to a designated

collecon point. For more informaon see:www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.

This device complies with Industry Canada licence-exempt RSS standard(s).

Operaon is subject to

the following two condions:

1. this device may not cause interference, and

2. this device must accept any interference, including interference that may cause undesired

operaon of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils

radioexempts de licence.

L'exploitaon est autorisée aux deux condions suivantes :

1. l'appareil ne doit pas produire de brouillage, et

l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage

est

suscepble d'en compromere le fonconnement.

Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a

type and maximum (or lesser) gain approved for the

transmier by Industry Canada. To reduce

potenal radio interference to other users, the antenna type and its gain should be so chosen that

the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful

communicaon.

Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner

avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par

Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des

autres

ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope

DS-K1T502 Series Access Control Terminal User Manual

rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une

communicaon sasfaisante.

This equipment should be installed and operated with a minimum distance 20cm between the

radiator and your body.

Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et

votre corps.

DS-K1T502 Series Access Control Terminal User Manual

Safety Instrucon

These instrucons are intended to ensure that user can use the product correctly to avoid danger

or property loss.

The

precauon measure is divided into Dangers and Cauons:

Dangers: Neglecng any of the warnings may cause serious injury or death.

Cauons: Neglecng any of the cauons may cause injury or equipment damage.

Dangers: Follow these safeguards to prevent

serious injury or death.

Cauons: Follow these precauons to prevent

potenal injury or material damage.

Dangers

●

All the electronic operaon should be strictly compliance with the electrical safety regulaons,

re prevenon regulaons and other related regulaons in your local region.

●

Please use the power adapter, which is provided by normal company. The power consumpon

cannot be less than the required value.

●

Do not connect several devices to one power adapter as adapter overload may cause over-heat

re hazard.

●

Please make sure that the power has been disconnected before you wire, install or dismantle the

device.

●

When the product is installed on wall or ceiling, the device shall be

rmly xed.

●

If smoke, odors or noise rise from the device, turn

o the power at once and unplug the power

cable, and then please contact the service center.

●

Do not ingest baery, Chemical Burn Hazard.

This product contains a

coin/buon cell baery. If the coin/buon cell baery is swallowed, it

can cause severe internal burns in just 2 hours and can lead to death.

Keep new and used

baeries away from children. If the baery compartment does not close

securely, stop using the product and keep it away from children. If you think baeries might have

been swallowed or placed inside any part of the body, seek immediate medical

aenon.

●

If the product does not work properly, please contact your dealer or the nearest service center.

Never

aempt to disassemble the device yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

Cauons

●

This equipment is not suitable for use in locaons where children are likely to be present.

●

Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places

subject to shock (ignorance can cause equipment damage).

DS-K1T502 Series Access Control Terminal User Manual

vii

●

Do not place the device in extremely hot (refer to the specicaon of the device for the detailed

operang temperature), cold, dusty or damp locaons, and do not expose it to high

electromagnec radiaon.

●

The device cover for indoor use shall be kept from rain and moisture.

●

Exposing the equipment to direct sun light, low venlaon or heat source such as heater or

radiator is forbidden (ignorance can cause

re danger).

●

Do not aim the device at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a

malfuncon however), and aecng the endurance of sensor at the

same

me.

●

Please use the provided glove when open up the device cover, avoid direct contact with the

device cover, because the acidic sweat of the ngers may erode the surface coang of the device

cover.

●

Please use a

so and dry cloth when clean inside and outside surfaces of the device cover, do

not use alkaline detergents.

●

Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you

need to return the device to the factory with the original wrapper.

Transportaon without the

original wrapper may result in damage on the device and lead to addional costs.

●

Improper use or replacement of the

baery may result in hazard of explosion. Replace with the

same or equivalent type only. Dispose of used baeries according to the instrucons provided by

the

baery manufacturer.

●

You can view the device License via the website: hp://opensource.hikvision.com/Home/List?

id=46

DS-K1T502 Series Access Control Terminal User Manual

viii

Available Models

The access control terminal contains the following models:

Product Name Model Wireless

Access Control Terminal DS-K1T502DBWX-C 13.56 MHz Card Presenng

Frequency, Wi-Fi,

2.4G,Bluetooth

DS-K1T502DBFWX-C 13.56 MHz Card Presenng

Frequency, Wi-Fi,

2.4G,Bluetooth

DS-K1T502DBFWX 13.56 MHz Card Presenng

Frequency, Wi-Fi,

2.4G,Bluetooth

DS-K1T502DBWX 13.56 MHz Card Presenng

Frequency, Wi-Fi,

2.4G,Bluetooth

Table 1-1 Available Mobile Web Browsers

Operaon System Browser Version Available

Android Xiaomi 12, default

browser

16.6.6 Yes

Huawei P30, default

browser

12.1.1.321 Yes

Xiaomi 5s plus, default

browser

14.2.22 Yes

Huawei P30 Pro,

default browser

12.1.2.301 Yes

Redmi k40, default

browser

16.5.12 Yes

IOS Safari 15.4 Yes

DS-K1T502 Series Access Control Terminal User Manual

Contents

Chapter 1 Overview .................................................................................................................... 1

1.1 Overview ................................................................................................................................ 1

1.2 Features ................................................................................................................................. 1

1.3 Appearance Descripon ......................................................................................................... 1

Chapter 2 Installaon ................................................................................................................. 4

2.1 Installaon Environment ........................................................................................................ 4

2.2 Install without Gang Box ........................................................................................................ 4

Chapter 3 Device Wiring ............................................................................................................. 8

3.1 Terminal

Descripon .............................................................................................................. 8

3.2 External Device Wiring ........................................................................................................... 9

3.3 Wire Secure Door Control Unit ............................................................................................ 10

Chapter 4

Acvaon ................................................................................................................. 12

4.1 Acvate via Mobile Web ...................................................................................................... 12

4.2 Acvate via Web Browser .................................................................................................... 13

4.3

Acvate via SADP ................................................................................................................. 13

4.4 Acvate Device via iVMS-4200 Client Soware ................................................................... 14

Chapter 5 Identy Authencaon ............................................................................................ 16

5.1

Authencate via Single Credenal ....................................................................................... 16

5.2 Authencate via Mulple Credenal ................................................................................... 16

Chapter 6 Call and Video Intercom ............................................................................................ 18

Chapter 7 Quick

Operaon via Web Browser ............................................................................ 19

7.1 Set Security Queson ........................................................................................................... 19

7.2 Select Language ................................................................................................................... 19

7.3 Time

Sengs ........................................................................................................................ 19

7.4 Privacy Sengs .................................................................................................................... 20

7.5 Administrator Sengs ......................................................................................................... 20

DS-K1T502 Series Access Control Terminal User Manual

7.6 No. and System Network ..................................................................................................... 20

Chapter 8 Operaon via Web Browser ...................................................................................... 22

8.1 Login .................................................................................................................................... 22

8.2 Forget Password ................................................................................................................... 22

8.3 Overview .............................................................................................................................. 22

8.4 Person Management ............................................................................................................ 24

8.5 Search Event ........................................................................................................................ 25

8.6

Conguraon ....................................................................................................................... 26

8.6.1 Set Local Parameters ................................................................................................... 26

8.6.2 View Device Informaon ............................................................................................. 27

8.6.3 Set Time ...................................................................................................................... 27

8.6.4 Set DST ........................................................................................................................ 27

8.6.5 Change Administrator's Password ............................................................................... 28

8.6.6 Account Security Sengs ............................................................................................ 28

8.6.7 Online Users ................................................................................................................ 29

8.6.8 View Device Arming/Disarming Informaon .............................................................. 29

8.6.9 Network

Sengs ......................................................................................................... 29

8.6.10 Set Audio Parameters ............................................................................................... 34

8.6.11 Set Image Parameters ............................................................................................... 35

8.6.12

Moon Detecon ...................................................................................................... 35

8.6.13 Event Linkage ............................................................................................................ 36

8.6.14 Access Control Sengs ............................................................................................. 37

8.6.15 Video Intercom

Sengs ............................................................................................ 42

8.6.16 Card Sengs ............................................................................................................. 45

8.6.17 Set Privacy Parameters .............................................................................................. 46

8.6.18 Password Mode ........................................................................................................ 47

8.6.19 Time and

Aendance Sengs .................................................................................. 47

8.6.20 Set Smart Parameters ............................................................................................... 49

DS-K1T502 Series Access Control Terminal User Manual

8.6.21 Upgrade and Maintenance ....................................................................................... 50

8.6.22 Device Debugging ..................................................................................................... 51

8.6.23 Log Query .................................................................................................................. 51

8.6.24 Security Mode

Sengs ............................................................................................. 51

8.6.25 Cercate Management ........................................................................................... 51

Chapter 9 Congure the Device via the Mobile Browser ........................................................... 54

9.1 Login .................................................................................................................................... 54

9.2 Overview .............................................................................................................................. 54

9.3 Forget Password ................................................................................................................... 55

9.4 Conguraon ....................................................................................................................... 55

9.4.1 View Device Informaon ............................................................................................. 55

9.4.2 Time Sengs ............................................................................................................... 55

9.4.3 Set DST ........................................................................................................................ 56

9.4.4 User Management ...................................................................................................... 57

9.4.5 Network Sengs ......................................................................................................... 57

9.4.6 User Management ...................................................................................................... 61

9.4.7 Set Audio ..................................................................................................................... 63

9.4.8 Search Event ................................................................................................................ 63

9.4.9 Access Control

Sengs ............................................................................................... 64

9.4.10 Intercom .................................................................................................................... 70

9.4.11 Set Privacy Parameters .............................................................................................. 72

9.4.12 Password Mode ........................................................................................................ 73

9.4.13 Fingerprint Parameters

Sengs ................................................................................ 73

9.4.14 Upgrade and Maintenance ....................................................................................... 74

9.4.15 View Online Document ............................................................................................. 74

9.4.16 View Open Source

Soware License ......................................................................... 74

Chapter 10 Other Plaorms to Congure .................................................................................. 75

Appendix A. Tips for Scanning Fingerprint ................................................................................ 76

DS-K1T502 Series Access Control Terminal User Manual

xii

Appendix B. Dimension ............................................................................................................ 78

DS-K1T502 Series Access Control Terminal User Manual

xiii

Chapter 1 Overview

1.1 Overview

Access control terminal is a kind of access control terminal for authencaon. It supports two-way

audio, remote live view, picture capture, video recording through NVR, and so on.

1.2 Features

●

Manage access control, video intercoms, and video security with one device

●

IP65 & IK09 protecons, as well as increased stability with zinc alloy materials

●

Mulple authencaon methods, including ngerprint, card, etc.

Note

Fingerprint funcon is supported by parts of the device modules.

●

Remote control via the Hik-Connect mobile app

●

Connects to external access controller via Wiegand protocol

●

Two-way audio via SIP 2.0 protocol

●

RS-485

communicaon for connecng external card reader

●

Supports network

connecon via AP

●

Supports H.265 video encoding format

1.3 Appearance

Descripon

View the device appearance descripon.

DS-K1T502 Series Access Control Terminal User Manual

Note

The pictures here are for reference only.

Table 1-1 Appearance Descripon

No. Descripon

1 Loudspeaker

2 Camera (Supported by parts of Device Models)

3 Fingerprint Module (Supported by parts of Device Models)

4 Card Presenng Area

5 MIC

6 Tamper

7 Network Interface

8 SD Card Slot

9 Wiring Terminal for Alarm Input/ Output

DS-K1T502 Series Access Control Terminal User Manual

No. Descripon

10 Wiring Terminal

11 Debugging Port (For debugging only)

DS-K1T502 Series Access Control Terminal User Manual

Chapter 2 Installaon

2.1 Installaon Environment

●

Install the device at least 2 meters away from the light, and at least 3 meters away from the

window or the door.

●

Make sure the environment

illuminaon is more than 100 Lux.

Note

For details about installaon environment, see Tips for Installaon Environment.

2.2 Install without Gang Box

Steps

Note

The addional force shall be equal to three mes the weight of the equipment. The equipment ad

its associated mounng means shall remain secure during the installaon. Aer the installaon,

the equipment, including any associated mounng plate, shall not be damaged.

Secure the mounng plate on the wall with 4 supplied screws (SC-KA4X25-SUS).

DS-K1T502 Series Access Control Terminal User Manual

Figure 2-1 Secure Mounng Plate

Route the cable through the cable hole of the mounng plate, and connect to corresponding

external devices' cables.

Apply Silicone sealant among the joints between the device rear panel and the wall (except the

lower side) to keep the raindrop from entering.

DS-K1T502 Series Access Control Terminal User Manual

Figure 2-2 Apply Silicone Sealant on the Side

Align the device with the mounng plate, and secure the device on the mounng plate with 1

supplied screw (SC-KM3X6-T10-SUS).

DS-K1T502 Series Access Control Terminal User Manual

Figure 2-3 Secure Device

DS-K1T502 Series Access Control Terminal User Manual

Chapter 3 Device Wiring

3.1 Terminal Descripon

The terminals contains power input, alarm input, alarm output, RS-485, Wiegand output, and door

lock.

The terminal's diagram is as follows:

Figure 3-1 Terminal Diagram

The descripons of the terminals are as follows:

Table 3-1 Terminal

Descripons

Group No. Funcon Color Name Descripon

Group A A1 Power Input Red +12 V 12 VDC Power

Supply

A2 Black GND Ground

Group B B1 RS-485 Yellow 485+ RS-485 Wiring

B2 Blue 485-

B3 Black GND Ground

Group C C1 Wiegand Green W0 Wiegand

Wiring 0

C2 White W1 Wiegand

Wiring 1

C3 Black GND Ground

DS-K1T502 Series Access Control Terminal User Manual

Group No. Funcon Color Name Descripon

Group D D1 Door Lock White/Purple NC Lock Wiring

(NC)

D2 White/Yellow COM Common

D3 White/Red NO Lock Wiring

(NO)

D4 Yellow/Green SENSOR Door Contact

D5 Black GND Ground

D6 Yellow/Gray BTN Exit Door

Wiring

3.2 External Device Wiring

Wire the external device.

The wiring diagram is as follows.

DS-K1T502 Series Access Control Terminal User Manual

Figure 3-2 External Device Wiring

3.3 Wire Secure Door Control Unit

You can connect the terminal with the secure door control unit.

The wiring diagram is as follows.

DS-K1T502 Series Access Control Terminal User Manual

Figure 3-3 Secure Door Control Unit Wiring

Note

●

The secure door control unit should connect to an external power supply separately. The

suggested external power supply is 12V, 0.5A.

●

For scenarios with high safety requirement, use the secure door control unit wiring rst.

●

You can ask the technical support to purchase for the secure door control unit separately.

●

The picture here are parts of the wiring. For details, see the secure door control unit's user

manual.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 4 Acvaon

You should acvate the device before the rst login. Aer powering on the device, the system will

switch to Device

Acvaon page.

Acvaon via the device, SADP tool and the client soware are supported.

The default values of the device are as follows:

●

The default IP address: 192.0.0.64

●

The default port No.: 80

●

The default user name: admin

4.1

Acvate via Mobile Web

You can acvate the device via mobile web.

Steps

Note

Aer powering on the device for the rst me, the hotspot funcon is enabled by default.

Enable the mobile phone's Wi-Fi funcon. Search and add the device hotspot (hotspot name:

AP_Serial No.).

Note

●

Hotspot name/password: AP_Serial No.

●

Hold key 5 on the device keypad for 10 s to enable/disable the hotspot funcon.

●

Aer 30 min aer device powering on, the hotspot funcon will be disabled automacally.

●

Aer device acvaon, the hotspot password will be changed to the device acvaon

password.

The mobile phone will jump to the web browser page. Create a new password (admin password)

and

conrm the password.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

DS-K1T502 Series Access Control Terminal User Manual

Click Acvate.

Edit the device IP address. You can edit the IP address via the SADP tool, PC web browser and

the client soware.

4.2 Acvate via Web Browser

You can acvate the device via the web browser.

Steps

Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press

Enter.

Note

Make sure the device IP address and the computer's should be in the same IP segment.

Create a new password (admin password) and conrm the password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

Click Acvate.

Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the

client

soware.

4.3

Acvate via SADP

SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.

Before You Start

●

Get the SADP soware from the supplied disk or the ocial website hp://

www.hikvision.com/en/ , and install the SADP according to the prompts.

●

The device and the PC that runs the SADP tool should be within the same subnet.

The following steps show how to

acvate a device and modify its IP address. For batch acvaon

and IP addresses modicaon, refer to User Manual of SADP for details.

Steps

Run the SADP soware and search the online devices.

DS-K1T502 Series Access Control Terminal User Manual

Find and select your device in online device list.

Input new password (admin password) and conrm the password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

Click Acvate to start acvaon.

Status of the device becomes

Acve aer successful acvaon.

Modify IP address of the device.

1) Select the device.

2) Change the device IP address to the same subnet as your computer by either modifying the IP

address manually or checking Enable DHCP.

3) Input the admin password and click Modify to

acvate your IP address modicaon.

4.4

Acvate Device via iVMS-4200 Client Soware

For some devices, you are required to create the password to acvate them before they can be

added to the iVMS-4200

soware and work properly.

DS-K1T502 Series Access Control Terminal User Manual

Steps

Note

This funcon should be supported by the device.

Enter the Device Management page.

Click on the right of Device Management and select Device.

Click Online Device to show the online device area.

The searched online devices are displayed in the list.

Check the device status (shown on Security Level column) and select an

inacve device.

Click Acvate to open the Acvaon dialog.

Create a password in the password

eld, and conrm the password.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Note

Characters containing admin and nimda are not supported to be set as acvaon password.

Click OK to acvate the device.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 5 Identy Authencaon

Aer network conguraon, system parameters conguraon and user conguraon, you can go

back to the

inial page for identy authencaon. The system will authencate person according

to the congured authencaon mode.

5.1 Authencate via Single Credenal

Set the user authencaon type before authencaon. For details, see Set Authencaon

Parameters .

Authencate ngerprint, card, PIN, or QR code.

Fingerprint

Place the enrolled

ngerprint on the ngerprint module and start authencaon via ngerprint.

Card

Present the card on the card presenng area and start authencaon via card.

Note

The card can be normal IC card, or encrypted card.

QR Code

Put the QR code in front of the device camera to

authencate via QR code.

Note

Authencaon via QR code should be supported by the device.

Enter the PIN to

authencate via PIN.

authencaon completed, a prompt "Authencated" will pop up.

5.2

Authencate via Mulple Credenal

Before You Start

Set the user

authencaon type before authencaon. For details, see Set Authencaon

Parameters .

Steps

Authencate any credenal according to the instrucons on the live view page.

DS-K1T502 Series Access Control Terminal User Manual

Note

●

The card can be normal IC card, or encrypted card.

●

If the QR Code Scanning funcon is enabled, you can put the QR code in front of the device

camera to authencate via QR code.

Aer the previous credenal is authencated, connue authencate other credenals.

Note

For detailed informaon about scanning ngerprint, see Tips for Scanning Fingerprint.

If authencaon succeeded, the prompt "Authencated" will pop up.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 6 Call and Video Intercom

Set the SIP server IP, calling and video intercom between devices are available.

Set Device A as SIP server, and set Device A's IP as SIP server IP. For details, see

Session Sengs .

All other devices that need to call each other should be registered to the server.

Set device room number. For details, see Set Video Intercom Parameters .

On the device main page, enter the device room No. to call. When the other device is answered,

video intercom can be performed.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 7 Quick Operaon via Web Browser

7.1 Set Security Queson

If you forget the device acvaon password, you can change the password via security quesons.

Set the security quesons before conguraon.

Click in the top right of the web page to enter the Change Password page. You can click Skip to

skip the step. Or select three quesons to answer and click Next.

7.2 Select Language

You can select a language for the device system.

Click in the top right of the web page to enter the Device Language Sengs page. You can

select a language for the device system from the drop-down list.

By default, the system language is English.

Note

Aer you change the system language, the device will reboot automacally.

Click Next to complete the sengs.

7.3 Time

Sengs

Click in the top right of the web page to enter the wizard page. Aer seng device language,

you can click Next to enter the Time

Sengs page.

Time Zone

Select the device located me zone from the drop-down list.

Time Sync.

NTP

You should set the NTP server's IP address, port No., and interval.

Manual

By default, the device me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's me.

Server Address/NTP Port/Interval

You can set the server address, NTP port, and interval.

Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.

DS-K1T502 Series Access Control Terminal User Manual

7.4 Privacy Sengs

Set the picture uploading and storage parameters.

Click in the top right of the web page to enter the wizard page. Aer seng device language,

me and environment, you can click Next to enter the Privacy Sengs page.

Picture Uploading and Storage

Upload Picture Aer Linked Capture

Upload the pictures captured by linked camera to the plaorm automacally.

Save Pictures Aer Linked Capture

If you enable this funcon, you can save the picture captured by linked camera to the device.

Click Next to save the sengs and go to the next paramater. Or click Skip to skip privacy sengs.

7.5 Administrator

Sengs

Steps

Click in the top right of the web page to enter the wizard page. Aer seng device language,

me, environment and privacy, you can click Next to enter the Administrator Sengs page.

Enter the employee ID and name of the administrator.

Select a credenal to add.

Note

You should select at least one credenal.

1) Click Add Card to enter the Card No. and select the property of the card.

Note

Up to 5 cards can be supported.

2) Click Add Fingerprint to add ngerprints.

Note

Up to 10 ngerprints are allowed.

7.6 No. and System Network

Steps

Click in the top right of the web page to enter the wizard page. Aer previous sengs, you

can click Next to enter the No. and System Network sengs page.

Set the device type.

DS-K1T502 Series Access Control Terminal User Manual

If set the device type as Door Staon or Outer Door Staon, you can set the Community No.,

Building No., Unit No., Floor No., and Door Staon No.

If set the device type as Outer Door Staon, you can set outer door staon No., and community

No.

Set Registraon Password, Main Staon IP and Private Server IP.

Oponal: Click to Enable Protocol 1.0.

Click Complete to save the sengs aer the conguraon.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 8 Operaon via Web Browser

8.1 Login

You can login via the web browser or the remote conguraon of the client soware.

Note

Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon .

Enter the device IP address in the address bar of the web browser and press Enter to enter the

Enter the device user name and the password. Click Login.

Conguraon of Client Soware

Download and open the client soware. Aer adding the device, click to enter the Conguraon

page.

8.2 Forget Password

If you forget the password when logging in, you can change the password by email address or

security

quesons.

On the login page, click Forget Password.

Select

Vericaon Mode.

Security Queson Vericaon

Answer the security quesons.

E-mail Vericaon

1. Export the QR code and send it to pw_rec[email protected] as aachment.

2. You will receive a vericaon code within 5 minutes in your reserved email.

3. Enter the vericaon code into the vericaon code eld to verify your idencaon.

Click Next, create a new password and conrm it.

8.3 Overview

You can view the live video of the device,

real-me event, person informaon, network status,

basic

informaon, and device capacity.

DS-K1T502 Series Access Control Terminal User Manual

Figure 8-1 Overview Page

Funcon Descripons:

Door Status

Click to view the device live view.

Set the volume when starng live view.

Note

If you adjust the volume when starng two-way audio, you may hear a repeated sounds.

You can capture image when starng live view.

Select the streaming type when starng live view. You can select from the main stream and

the sub stream.

Full screen view.

/ / /

The door status is open/closed/remaining open/remaining closed.

Controlled Status

You can select open/closed/remaining open/remaining closed status according to your actual

needs.

Real-Time Event

DS-K1T502 Series Access Control Terminal User Manual

You can view the event Employee ID, Name, Card No., Event Type, Time, and Operaon. You can

also click View More to enter the search condions, including the event type, employee ID, the

name, the card No., the start me, and the end me, and click Search. The results will be

displayed on the right panel.

Person Informaon

You can view the added and not added informaon of person, card, and ngerprint.

Network Status

You can view the connected and registered status of wired network, wireless network,

bluetooth, ISUP, VoIP and cloud service.

Basic

Informaon

You can view the model, serial No. and rmware version.

Device Capacity

You can view the person, card, event and ngerprint capacity.

Note

Only devices supporng ngerprint funcon can display the ngerprint capacity.

You can click View More to view the event details.

8.4 Person Management

Click Add to add the person's informaon, including the basic informaon, cercate,

authencaon and sengs.

Add Basic

Informaon

Click Person Management → Add to enter the Add Person page.

Add the person's basic

informaon, including the employee ID, the person's name, and person

type.

If you select Visitor as the person type, you can set the visit

mes.

Click Save to save the sengs.

Set Permission Time

Click Person Management → Add to enter the Add Person page.

Enable Long-Term

Eecve User, or set Validity Period and the person can only has the permission

within the congured me period according to your actual needs.

Click Save to save the sengs.

Set Room No.

Click Person Management → Add to enter the Add Person page.

Click Add to add the Floor No. and Room No..

DS-K1T502 Series Access Control Terminal User Manual

Click to delete it.

Click Save to save the sengs.

Authencaon Sengs

Click Person Management → Add to enter the Add Person page.

Set the authencaon type.

Click Save to save the sengs.

Add Card

Click Person Management → Add to enter the Add Person page.

Click Add Card. Enter the Card No., or present the card on the device and click Read, and select the

Property. Click Save to add the card.

Click Save to save the

sengs.

Add Fingerprint

Note

Only devices supporng the ngerprint funcon can add the ngerprint.

Click Person Management → Add to enter the Add Person page.

Click Add Fingerprint, and press your

nger on the ngerprint module of the device to add your

ngerprint.

Click Save to save the sengs.

Add Password

Note

●

Before conguring passwords, it is necessary to clarify whether the password is device-set

personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it can be

created and edited on Web and cannot be created and edited on the plaorm; If it is a plaorm-

applied

personal PIN, it needs to be congured on the plaorm and cannot be edited on the

Web.

●

Make sure Password Mode is selected as Device Password.

Click Person Management → Add to enter the Add Person page.

Enter the password.

8.5 Search Event

Click

Event Search to enter the Search page.

DS-K1T502 Series Access Control Terminal User Manual

Figure 8-2 Search Event

Enter the search condions, including the event type, the employee ID, the name, the card No., the

start me, and the end me, and click Search.

The results will be displayed on the right panel.

8.6

Conguraon

8.6.1 Set Local Parameters

Set the live view parameters, record le saving path, and captured pictures saving path.

Set Live View Parameters

Click Conguraon → Local to enter the Local page. Congure the stream type, the play

performance, auto start live view, and the image format and click Save.

Set Record File Saving Path

Click Conguraon → Local to enter the Local page. Select a record le size and select a saving

path from your local computer and click Save.

You can also click Open to open the

le folder to view details.

Set Captured Pictures Saving Path

Click Conguraon → Local to enter the Local page. Select a saving path from your local computer

and click Save.

You can also click Open to open the

le folder to view details.

DS-K1T502 Series Access Control Terminal User Manual

8.6.2 View Device Informaon

View the device name, bluetooth name, language, model, serial No., QR code, version, number of

channels, IO input number, IO output number, local RS-485, register number, number of alarm

output, device capacity, etc.

Click

Conguraon → System → System Sengs → Basic Informaon to enter the conguraon

page.

You can view the device name, bluetooth name, language, model, serial No., QR code, version,

number of channels, IO input number, IO output number, local RS-485, register number, number of

alarm output, device capacity, etc.

8.6.3 Set Time

Set the device's me zone, synchronizaon mode, server address, NTP port, and interval.

Click Conguraon → System → System Sengs → Time Sengs .

Click Save to save the sengs aer the conguraon.

Time Zone

Select the device located me zone from the drop-down list.

Time Sync.

NTP

You should set the NTP server's IP address, port No., and interval.

Manual

By default, the device me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's me.

Server Address Type/Server Address/NTP Port/Interval

You can set the server address type, server address, NTP port, and interval.

8.6.4 Set DST

Steps

Click Conguraon → System → System Sengs → Time Sengs .

DS-K1T502 Series Access Control Terminal User Manual

Figure 8-3 DST Page

Enable DST.

Set the DST start me, end me and bias me.

Click Save to save the sengs.

8.6.5 Change Administrator's Password

Steps

Click Conguraon → User Management .

Click .

Enter the old password and create a new password.

Conrm the new password.

Click OK.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

8.6.6 Account Security Sengs

You can change the security quesons and answers, or the email address for the device. Aer

change the sengs, once you forgot the device password, you should answer the new quesons or

use the new email address to reset the device password.

Steps

Click

Conguraon → System → User Management → Account Security Sengs .

DS-K1T502 Series Access Control Terminal User Manual

Change the security quesons or email address according your actual needs.

Enter the device password and click OK to conrm changing.

8.6.7 Online Users

The informaon of users logging into the device is shown.

Go to Conguraon → User Management → Online Users to view the list of online users.

8.6.8 View Device Arming/Disarming Informaon

View device arming type and arming IP address.

Go to

Conguraon → User Management → Arming/Disarming Informaon .

You can view the device arming/disarming informaon. Click Refresh to refresh the page.

8.6.9 Network

Sengs

Set TCP/IP, port, Wi-Fi parameters, ISUP, and plaorm access.

Note

Some device models do not support Wi-Fi or mobile data sengs. Refer to the actual products

when conguraon.

Set Basic Network Parameters

Click Conguraon → Network → Network Sengs → TCP/IP .

DS-K1T502 Series Access Control Terminal User Manual

Figure 8-4 TCP/IP Sengs Page

Set the parameters and click Save to save the sengs.

NIC Type

Select a NIC type from the drop-down list. By default, it is Auto.

DHCP

If uncheck the

funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default

gateway, IPv6 mode, IPv6 address, IPv6 subnet prex length, IPv6 default gateway, Mac address,

and MTU.

If you check the

funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4

default gateway, IPv6 mode, IPv6 address, IPv6 subnet prex length, and IPv6 default gateway

automacally.

DNS Server

Set the preferred DNS server and the Alternate DNS server according to your actual need.

DS-K1T502 Series Access Control Terminal User Manual

Set Wi-Fi Parameters

Set the Wi-Fi parameters for device wireless connecon.

Steps

Note

The funcon should be supported by the device.

Click Conguraon → Network → Network Sengs → Wi-Fi .

Figure 8-5 Wi-Fi Sengs Page

Check Wi-Fi.

Select a Wi-Fi

Click of a Wi-Fi in the list and enter the Wi-Fi password.

Click Add and enter a Wi-Fi's name, password, and

encrypon type. Click Connect. When the

Wi-Fi is connected, click OK.

Oponal: Set the WLAN parameters.

1) Set the IP address, subnet mask, and default gateway. Or enable DHCP and the system will

allocate the IP address, subnet mask, and default gateway

automacally.

Click Save.

Device Hotspot

Set the device hotspot.

Click

Conguraon → Network → Network Sengs → Device Hotspot .

Click Enable Device Hotspot to enable the funcon and view the device hotspot name.

DS-K1T502 Series Access Control Terminal User Manual

Note

By default, the hotspot name is the AP_Device Serial No.

Click Save.

Plaorm Access

Plaorm access provides you an opon to manage the devices via plaorm.

Steps

Click Conguraon → Network → Device Access → Hik-Connect to enter the sengs page.

Note

Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the

device, receive alarm nocaon and so on.

Check Enable to enable the funcon.

Oponal: Check the checkbox of Custom, and you can set the server address by yourself.

Enter the server IP address, and

vericaon code.

Note

●

6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use

a combinaon of no less than 8 leers or numbers.

●

The vericaon code cannot be 123456 or abcdef (case non-sensive0).

Set the Network Connecon Priority. You can enable Allow Access, and click the network and

drag it to adjust the network priority.

Click Save to enable the

sengs.

Set ISUP Parameters

Set the ISUP parameters for accessing device via ISUP protocol.

Steps

Note

The funcon should be supported by the device.

Click Conguraon → Network → Device Access → ISUP .

Check Enable.

Set the ISUP version, server address, device ID, and the ISUP status.

Note

If you select 5.0 as the version, you should set the Encrypon Key.

DS-K1T502 Series Access Control Terminal User Manual

Set the Network Connecon Priority. You can enable Allow Access, and click the network and

drag it to adjust the network priority.

Set the ISUP listening parameters, including ISUP alarm center IP address/domain name, ISUP

alarm center URL, and ISUP alarm center port.

Click Save.

Bluetooth Sengs

You can enable bluetooth funcon.

Click Conguraon → Network → Network Sengs → Bluetooth .

Open

Enable Open to enable the bluetooth funcon.

Device Name

You can edit the device name connected to the bluetooth.

Connecon Status

You can view the connecon status.

Open Door via Bluetooth

Aer enabling this funcon, you can open doors via HikCentral Connect or HikCentral Access

Control.

Note

You should add devices to the HCC or HCAC before opening door via bluetooth. Via HCAC, you

can also realize the auto door open funcon. for details, see the HCAC's user manual.

Set Port Parameters

Set the HTTP, HTTPS, HTTP Listening, RTSP and Server port parameters.

Click

Conguraon → Network → Network Service → HTTP(S) .

HTTP

It refers to the port through which the browser accesses the device. For example, when the

HTTP Port is

modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.

HTTPS

Set the HTTPS for accessing the browser. Cercate is required when accessing.

HTTP Listening

The device can send alarm informaon to the event alarm IP address or domain name via HTTP

protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and

protocol.

DS-K1T502 Series Access Control Terminal User Manual

Note

The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol

to receive the alarm informaon.

Click Conguraon → Network → Network Service → RTSP .

RTSP

It refers to the port of

real-me streaming protocol.

Click Conguraon → Network → Device Access → SDK Server .

SDK Server

It refers to the port through which the client adds the device.

Congure

SIP Parameters

Set the device's IP address and the SIP server's IP address. Aer seng the parameters, you can

communicate among the access control device, door staon, indoor staon, main staon, and the

plaorm.

Note

Only the access control device and other devices or systems (such as door staon, indoor staon,

main staon, plaorm) are in the same IP segment, the two-way audio can be performed.

Go to Conguraon → Network → VoIP .

Check Enable VOIP Gateway.

Set register user name,

registraon password, server address, expiry me, number, and display

user name.

Click Save.

8.6.10 Set Audio Parameters

Set the audio parameters.

Set the input volume, output volume and enable voice prompt according to your actual needs.

Click Save to save the

sengs aer the conguraon.

Note

The funcons vary according to dierent models. Refers to the actual device for details.

DS-K1T502 Series Access Control Terminal User Manual

8.6.11 Set Image Parameters

You can adjust the image parameters, video parameters, supplement parameters and capture

interval.

Steps

Click

Conguraon → Image .

Congure the parameters to adjust the image.

Video Adjust(Video Standard)

Set the video frame rate when performing live view remotely.

Aer changing the standard,

you should reboot the device to take eect.

PAL

25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East

countries, Europe countries, etc.

NTSC

30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the

Philippines, etc.

Image Adjustment

Drag the block or enter the value to adjust the live video's brightness, contrast,

saturaon,

and sharpness.

Supplement Light Parameters

Set the supplement light type, mode, start me and end me. You can also set the

brightness.

Capture Interval

You can select the capture interval according to your actual needs.

Click Default to restore the parameters to the default

sengs.

8.6.12

Moon Detecon

Moon detecon detects the moving objects in the congured security area, and a series of

acons can be taken when the alarm is triggered.

Steps

Click Conguraon → Event → Event Detecon → Moon to enter the sengs page.

Enable Moon.

Click

and drag to draw a moon detecon area.

Clear Area

Click to clear all of the areas.

Move the slider to set the sensivity of the detecon.

Click Modify aer Schedule to edit the arming schedule.

Click Schedule and drag to select the

me period. Click Save to save the sengs.

DS-K1T502 Series Access Control Terminal User Manual

Clear Schedule Click Clear to delete the current arming schedule.

Set Linkage Sengs.

Nofy Security Center

Send an excepon or alarm signal to the remote management soware when an event

occurs.

HTTP

The device can send alarm informaon to the event alarm IP address or domain name via

HTTP protocol.

Click Save to enable the

sengs.

8.6.13 Event Linkage

Set linked acons for events.

Steps

Click Conguraon → Event → Event Detecon → Linkage Sengs to enter the page.

Set event source.

If you choose Linkage Type as Event Linkage, you need to select event types from the drop-

down list.

If you choose Linkage Type as Card Linkage, you need to enter the card No. and select the

card reader.

If you choose Linkage Type as Employee ID Linkage, you need to enter the employee ID and

select the card reader.

Set linked acon.

Linked Door

Enable Linked Door, check Door 1 or Door 2, and set the door status for the target event.

Linked Alarm Output

Enable Linked Alarm Output, check Alarm Output 1 or Alarm Output 2, and set the alarm

output status for the target event.

Capture Linkage

Enable Capture Linkage and select the card reader to capture for the target event.

Trigger Recording

Enable Trigger Recording. Click

Conguraon → Event → Basic Event → Recording → , you

can enable Record Audio When Recording, and set Pre-record and Post-record me.

Note

Equip the device with an SD card to use video recording funcon. To view the recorded videos,

see Search Event .

DS-K1T502 Series Access Control Terminal User Manual

8.6.14 Access Control Sengs

Set Authencaon Parameters

Click Conguraon → Access Control → Authencaon Sengs .

Note

The funcons vary according to dierent models. Refers to the actual device for details.

Figure 8-6 Set Authencaon Parameters

Click Save to save the sengs aer the conguraon.

Terminal

Select terminal for sengs.

Terminal Type/Terminal Model

Get terminal

descripon. They are read-only.

Enable Authencaon Device

Enable the authencaon funcon.

Authencaon

Select an authencaon mode according to your actual needs from the drop-down list.

Authencaon Interval

You can set the authencaon interval of the same person when authencang. The same

person can only authencate once in the congured interval. A second authencaon will be

failed.

Alarm of Max. Failed

Aempts

DS-K1T502 Series Access Control Terminal User Manual

Enable to report alarm when the card reading aempts reach the set value.

Communicaon with Controller Every

When the access control device cannot connect with the card reader for longer than the set

me, the card reader will turn oine automacally.

Max. Interval When Entering Password

When you entering the password on the card reader, if the interval between pressing two digits

is longer than the set value, the digits you pressed before will be cleared automacally.

OK LED Polarity/Error LED Polarity

Set OK LED Polarity/Error LED Polarity of the access control device according to the card reader

parameters. Generally, adopts the default sengs.

Enable Tampering Detecon

Enable the an-tamper detecon for the card reader.

Enable Card No. Reversing

The card No. will be in reverse sequence aer enabling the funcon.

QR Code

Enable the funcon and the user can use QR code to open the door.

Note

●

Disable the IR light if enabling the QR code funcon. For details, see Set Image Parameters .

The picture in low illuminaon environment may be aected due to disabling the IR light.

●

Set QR code funcon via HCC or HCEC, you should select compable to 1.0 or 2.0. 2.0 is

recommended.

Set Door Parameters

Click Conguraon → Access Control → Door Parameters .

DS-K1T502 Series Access Control Terminal User Manual

Figure 8-7 Door Parameters Sengs Page

Click Save to save the

sengs aer the conguraon.

Door No.

Select the device corresponded door No.

Name

You can create a name for the door.

Open Duraon

Set the door unlocking duraon. If the door is not opened for the set me, the door will be

locked.

Door Open Timeout Alarm

An alarm will be triggered if the door has not been closed within the congured me duraon.

Door Contact

You can set the door contact as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Closed.

Exit Buon Type

You can set the exit buon as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Open.

Door Lock Powering

O Status

You can set the door lock status when the door lock is powering o. By default, it is Remain

Closed.

Extended Open Duraon

DS-K1T502 Series Access Control Terminal User Manual

The door contact can be enabled with appropriate delay aer person with extended access

needs swipes her/his card.

Door Remain Open Duraon with First Person

Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows

mulple persons access the door or other authencaon acons.

Duress Code

The door can open by

inpung the duress code when there is duress. At the same me, the

client can report the duress event.

Super Password

The specic person can open the door by inpung the super password.

Note

The duress code and the super code should be dierent.

Set Terminal Parameters

You can set terminal parameters for accessing.

Click

Conguraon → Access Control → Terminal Parameters .

You can set Working Mode as Access Control Mode. The access control mode is the device normal

mode. You should

authencate your credenal for accessing.

Click Save to save the sengs aer the conguraon.

Set RS-485 Parameters

You can set the RS-485 parameters including the peripheral, address, baud rate, etc.

Click Conguraon → Access Control → RS-485 .

Check Enable, and set the parameters.

Peripheral Type

Select a peripheral from the drop-down list according the actual

situaon. You can select from

Card Reader, Extension Module, or Access Controller.

Note

Aer the peripheral is changed and saved, the device will reboot automacally.

RS-485 Address

Set the RS-485 Address according to your actual needs.

DS-K1T502 Series Access Control Terminal User Manual

Note

If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set

the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address

according to the door No.

Baud Rate

The baud rate when the devices are communicang via the RS-485 protocol.

Output Type

If you select Access Controller as the peripheral type, you should set the parameter. The device

will output the card No. or the employee ID to the access controller.

Click Save to save the

sengs.

Set Wiegand Parameters

You can set the Wiegand transmission direcon.

Steps

Note

Some device models do not support this funcon. Refer to the actual products when conguraon.

Click Conguraon → Access Control → Wiegand Sengs .

Check Wiegand to enable the Wiegand funcon.

Set a transmission direcon.

Output

The can connect an external access controller. And the two devices will transmit the card No.

via Wiegand 26 or 34.

Drag the block to set the

me interval and pulse width.

Note

●

The me interval ranges from 1 ms to 20 ms.

●

The pulse width ranges from 1 us to 100 us.

Click Save to save the sengs.

Note

If you change the peripheral, and aer you save the device parameters, the device will reboot

automacally.

DS-K1T502 Series Access Control Terminal User Manual

8.6.15 Video Intercom Sengs

Set Video Intercom Parameters

The device can be used as a door staon, or outer door staon. You should set the device No.

before usage.

Click Conguraon → Intercom → Device No. .

If set the device type as Door

Staon, you can set the oor No., door staon No., and click More to

set Community No., Building No., and Unit No. You can press any digit buon to enter the calling

page, and enter the room No. and press call buon to call the resident.

Click Save to save the

sengs aer the conguraon.

Figure 8-8 Device No. Sengs

Device Type

The device can be used as a door staon or outer door staon. Select a device type from the

drop-down list.

Note

If you change the device type, you should reboot the device.

Floor No.

DS-K1T502 Series Access Control Terminal User Manual

Set the device installed oor No.

Door Staon No.

Set the device installed oor No.

Note

●

If you change the No., you should reboot the device.

●

The main door staon No. is 0, and the sub door staon No. ranges from 1 to 16.

Community No.

Set the device community No.

Building No.

Set the device building No.

Unit No.

Set the device unit No.

Note

If you change the No., you should reboot the device.

If set the device type as Outer Door Staon, you can set outer door staon No., and community

No. You can press call buon to enter the calling page, and enter 【Community No. + Building No. +

# + Unit No. + # + Room No.】 and press call

buon to call resident.

Outer Door Staon No.

If you select outer door staon as the device type, you should enter a number between 1 and

99.

Note

If you change the No., you should reboot the device.

Community No.

Set the device community No.

Session

Sengs

Enable the communicaon between door staon, main staon, and video intercom server.

Steps

Click Conguraon → Intercom → Session Sengs to enter the sengs page.

Set registraon password, main staon IP, private server IP and enable Protocol 1.0.

Registraon Password

Create a registraon password for communicaon via SIP

Main Staon IP

DS-K1T502 Series Access Control Terminal User Manual

IP address of the main staon.

Private Server IP

Enter the IP address of the device that need to communicate via SIP. The device will be the

SIP server. Other devices should register to the SIP server, or the video intercom between

devices will be failed.

Enable Protocol 1.0

Aer enabling, the device is registered to the main staon through the previous protocol. If

disabled, the device is registered to the main

staon through the new protocol.

Click Save.

Time Duraon Sengs

Set the Max. call duraon.

Go to Conguraon → Intercom → Call Sengs .

Drag the block to set the Max. call duraon. Click Save.

Note

The Max. call duraon range is 90 s to 120 s.

Number Sengs

You can call the room SIP to call the room.

Steps

Click

Conguraon → Intercom → Number Sengs to enter the sengs page.

Click + Add, enter the Room No. and SIP.

Click Save.

Press

Buon to Call

Steps

Click

Conguraon → Intercom → Press Buon to Call to enter the sengs page.

Check Call Indoor Staon, Call Specied Indoor Staon, Call Management Center or APP at

your needs.

Note

If you check Call Specied Indoor Staon, you need to enter the number of the indoor staon.

Click Save.

DS-K1T502 Series Access Control Terminal User Manual

8.6.16 Card Sengs

Set Card Security

Click Conguraon → Card Sengs → Card Type to enter the sengs page.

Set the parameters and click Save.

Enable NFC Card

In order to prevent the mobile phone from geng the data of the access control, you can

enable NFC card to increase the security level of the data.

Enable M1 Card

Enable M1 card and

authencang by presenng M1 card is available.

M1 Card Encrypon

Sector

M1 card encrypon can improve the security level of authencaon.

Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is

recommended to encrypt sector 13.

Enable EM Card

Enable EM card and

authencang by presenng EM card is available.

Note

If the peripheral card reader supports presenng EM card, the funcon is also supported to

enable/disable the EM card funcon.

Enable DESFire Card

The device can read the data from DESFire card when enabling the DESFire card funcon.

DESFire Card Read Content

Aer enable the DESFire card content reading funcon, the device can read the DESFire card

content.

Enable FeliCa Card

The device can read the data from FeliCa card when enabling the FeliCa card funcon.

Set Card No.

Authencaon Parameters

Set the card reading content when authencate via card on the device.

Go to Conguraon → Card Sengs → Card No. Authencaon Sengs .

Select a card

authencaon mode and click Save.

Full Card No.

DS-K1T502 Series Access Control Terminal User Manual

All card No. will be read.

Wiegand 26 (3 bytes)

The device will read card via Wiegand 26 protocol (read 3 bytes).

Wiegand 34 (4 bytes)

The device will read card via Wiegand 34 protocol (read 4 bytes).

8.6.17 Set Privacy Parameters

Set the event storage type, picture upload and storage parameters, and the picture clearing

parameters.

Go to

Conguraon → Security → Privacy Sengs

Event Storage

Sengs

Select a method to delete the event. You can select from Delete Old Events Periodically, Delete

Old Events by

Specied Time, or Overwring.

Delete Old Events Periodically

Drag the block or enter number to set the period for event deleng. All events will be deleted

according to the congured me duraon.

Delete Old Events by Specied Time

Set a

me and all events will be deleted on the congured me.

Overwring

The earliest 5% events will be deleted when the system detects the stored events has been over

95% of the full space.

Picture Uploading and Storage

Upload Picture Aer Linked Capture

Upload the pictures captured by linked camera to the plaorm automacally.

Save Pictures Aer Linked Capture

If you enable this funcon, you can save the picture captured by linked camera to the device.

Clear All Pictures in Device

Note

All pictures cannot be restored once they are deleted.

Clear Captured Pictures

All captured pictures in the device will be deleted.

DS-K1T502 Series Access Control Terminal User Manual

8.6.18 Password Mode

Before conguring passwords, it is necessary to clarify whether the password is device-set personal

PIN or a

plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created and

edited on Web and cannot be created and edited on the plaorm; If it is a plaorm-applied

personal PIN, it needs to be congured on the plaorm and cannot be edited on the Web.

Steps

Click

Conguraon → Security → Password Mode .

Select Password Mode.

Plaorm Password

It needs to be congured on the plaorm. It cannot be edited on the Web.

Device Password

It can be created and edited on the Web. It cannot be created and edited on the plaorm.

8.6.19 Time and

Aendance Sengs

If you want to track and monitor when the persons start/stop work and monitor their working

hours and late arrivals, early departures, me taken on breaks, and absenteeism, you can add the

person to the

shi group and assign a shi schedule (a rule for the aendance dening how the

schedule repeats, the shi type, break sengs, and the card swiping rule.) to the shi group to

dene the aendance parameters for the persons in the shi group.

Disable

Aendance Mode via Web

Disable the aendance mode and the system will not display the aendance status on the inial

page.

Steps

Click Conguraon → T&A Status to enter the sengs page.

Disable the Time and Aendance.

Result

You will not view or congure the aendance status on the inial page. And the system will follow

the aendance rule that congured on the plaorm.

Time

Sengs

Steps

Click Conguraon → T&A Status to enter the sengs page.

Select Schedule Template.

DS-K1T502 Series Access Control Terminal User Manual

Drag mouse to set the schedule.

Note

Set the schedule from Monday to Sunday according to the actual needs.

You can enable On/o Work, Break, Overme according to your actual needs and set the

custom name.

Oponal: Select a meline and click Delete. Or click Delete All to clear the sengs.

Click Save.

Set Manual Aendance via Web

Set the aendance mode as manual, and you should select a status manually when you take

aendance.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Click Conguraon → T&A Status to enter the sengs page.

Set the

Aendance Mode as Manual.

Enable the Aendance Status Required and set the aendance status lasts duraon.

Enable a group of aendance status.

Note

The Aendance Property will not be changed.

Oponal: Select an status and change its name if required.

Result

You should select an

aendance status manually aer authencaon.

Note

If you do not select a status, the authencaon will be failed and it will not be marked as a valid

aendance.

Set Auto Aendance via Web

Set the aendance mode as auto, and you can set the aendance status and its available schedule.

The system will automacally change the aendance status according to the congured schedule.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Click Conguraon → T&A Status to enter the sengs page.

DS-K1T502 Series Access Control Terminal User Manual

Set the Aendance Mode as Auto.

Enable the Aendance Status Required funcon.

Enable a group of aendance status.

Note

The Aendance Property will not be changed.

Oponal: Select an status and change its name if required.

Set the status' schedule. Refers to

Time Sengs for details.

Set Manual and Auto Aendance via Web

Set the aendance mode as Manual and Auto, and the system will automacally change the

aendance status according to the congured schedule. At the same me you can manually

change the

aendance status aer the authencaon.

Before You Start

Add at least one user, and set the user's authencaon mode. For details, see User Management.

Steps

Click

Conguraon → T&A Status to enter the sengs page.

Set the Aendance Mode as Manual and Auto.

Enable the

Aendance Status Required funcon.

Enable a group of aendance status.

Note

The Aendance Property will not be changed.

Oponal: Select an status and change its name if required.

Set the status' schedule. Refers to

Time Sengs for details.

Result

On the

inial page and authencate. The authencaon will be marked as the congured

aendance

status according to the schedule. If you tap the edit icon on the result tab, you can

select a status to take aendance manually, the authencaon will be marked as the edited

aendance status.

Example

If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's

authencaon from Monday 11:00 to 12:00 will be marked as break.

8.6.20 Set Smart Parameters

DS-K1T502 Series Access Control Terminal User Manual

Set Basic Parameters

Click Conguraon → Smart → Smart .

Select Fingerprint Security Level according to your actual needs.

8.6.21 Upgrade and Maintenance

Reboot device, restore device parameters, and upgrade device version.

Reboot Device

Click

Maintenance and Security → Maintenance → Restart .

Click Restart to reboot the device.

Upgrade

Click Maintenance and Security → Maintenance → Upgrade .

Select an upgrade type from the drop-down list. Click and select the upgrade le from your

local PC. Click Upgrade to start upgrading.

If the device has been connected to Hik-Connect and network, when there is a new installaon

package in Hik-Connect, you can click Upgrade aer Online Update to upgrade the device system.

Note

Do not power o during the upgrading.

Restore Parameters

Click Maintenance and Security → Maintenance → Backup and Reset .

Restore All

All parameters will be restored to the factory sengs. You should acvate the device before

usage.

Restore

The device will restore to the default

sengs, except for the device IP address and the user

informaon.

Import and Export Parameters

Click Maintenance and Security → Maintenance → Backup and Reset .

Export

Click Export to export the device parameters.

Note

You can import the exported device parameters to another device.

Import

DS-K1T502 Series Access Control Terminal User Manual

Click and select the le to import. Click Import to start import conguraon le.

8.6.22 Device Debugging

You can set device debugging parameters.

Steps

Click Maintenance and Security → Maintenance → Device Debugging .

You can set the following parameters.

Enable SSH

To raise network security, disable SSH service. The

conguraon is only used to debug the

device for the professionals.

8.6.23 Log Query

You can search and view the device logs.

Go to Maintenance and Security → Maintenance → Log .

Set the major and minor type of the log type. Set the start

me and end me for searching, and

click Search.

The results will be displayed below, which including the No.,

me, the major type the minor type,

the channel No., the local/remote user informaon, the remote host IP, etc.

8.6.24 Security Mode

Sengs

Set the security mode for logging in the client soware.

On the Device for Management page, click Conguraon → System → Security .

You can also enable SSH to get a more secure network.

Select a security mode from the drop-down list, and click Save.

Security Mode

High security level for user

informaon vericaon when logging in the client soware.

Compable Mode

The user informaiton vericaon is compable with the old client soware version when

logging in.

8.6.25

Cercate Management

It helps to manage the server/client cercates and CA cercate.

DS-K1T502 Series Access Control Terminal User Manual

Note

The funcon is only supported by certain device models.

Create and Install Self-signed Cercate

Steps

Go to Maintenance and Security → Security → Cercate Management .

In the Cercate Files area, select a Cercate Type from the drop-down list.

Click Create.

Input

cercate informaon.

Click OK to save and install the cercate.

The created cercate is displayed in the Cercate Details area.

The cercate will be saved automacally.

Download the cercate and save it to an asking le in the local computer.

Send the asking le to a cercaon authority for signature.

Import the signed cercate.

1) Select a cercate type in the Import Passwords area, and select a cercate from the local,

and click Install.

2) Select a

cercate type in the Import Communicaon Cercate area, and select a cercate

from the local, and click Install.

Install Other Authorized

Cercate

If you already has an authorized cercate (not created by the device), you can import it to the

device directly.

Steps

Go to Maintenance and Security → Security →

Cercate Management .

In the Import Passwords and Import Communicaon Cercate areas, select cercate type

and upload

cercate.

Click Install.

Install CA

Cercate

Before You Start

Prepare a CA cercate in advance.

Steps

Go to Maintenance and Security → Security →

Cercate Management .

Create an ID in the Import CA Cercate area.

DS-K1T502 Series Access Control Terminal User Manual

Note

The input cercate ID cannot be the same as the exisng ones.

Upload a cercate le from the local.

Click Install.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 9 Congure the Device via the Mobile

Browser

9.1 Login

You can login via mobile browser.

Note

●

Parts of the model supports Wi-Fi sengs.

●

Make sure the device is acvated.

●

Make sure the device and the mobile phone are in the same Wi-Fi.

Enter the device IP address in the address bar of the mobile browser and press Enter to enter the

Enter the device user name and the password. Tap Login.

9.2 Overview

You can view the door status, network status and basic informaon, and set person management,

smart

sengs, authencaon sengs, and door parameters via shortcut entry.

Funcon Descripons:

Door Status

/ / /

The door status is open/closed/remaining open/remaining closed. You can tap to select

open/closed/remaining open/remaining closed status according to your actual needs.

Shortcut Entry

You can set person management, smart sengs, authencaon sengs, and door parameters

via shortcut entry.

Network Status

You can view the connected and registered status of wired network, wireless network,

bluetooth, ISUP and Hik-Connect.

Basic

Informaon

You can view the model, serial No. and rmware version.

DS-K1T502 Series Access Control Terminal User Manual

9.3 Forget Password

If you forget the password when logging in, you can change the password by email address or

security quesons.

On the login page, tap Forget Password.

Select

Vericaon Mode.

Security Queson Vericaon

Answer the security quesons.

E-mail Vericaon

1. Export the QR code and send it to pw_rec[email protected] as aachment.

2. You will receive a vericaon code within 5 minutes in your reserved email.

3. Enter the

vericaon code into the vericaon code eld to verify your idencaon.

Click Next, create a new password and conrm it.

9.4

Conguraon

9.4.1 View Device Informaon

View the device name, language, model, serial No., version, IO input number, local RS-485 number,

number of alarm output, register number, Mac address, and device capacity, etc.

Tap

→ System Sengs → Basic Informaon to enter the conguraon page.

You can view the device name, language, model, serial No., version, IO input number, local RS-485

number, number of alarm output, register number, Mac address, and device capacity, etc.

9.4.2 Time

Sengs

Set the me zone, me sync. mode, and displayed me.

Tap → System Sengs → Time Sengs to enter the sengs page.

DS-K1T502 Series Access Control Terminal User Manual

Figure 9-1 Time Sengs

Tap Save to save the sengs.

Time Zone

Select the me zone where the device is located from the drop-down list.

Time Sync. Mode

Manual

By default, the device me should be synchronized manually. You can set the device me

manually.

NTP

Set the NTP server's IP address, port No., and interval.

9.4.3 Set DST

Steps

Tap

→ System Sengs → Time Sengs , to enter the sengs page.

DS-K1T502 Series Access Control Terminal User Manual

Figure 9-2 DST

Tap Enable DST.

Set the start

me, end me, and DST bias.

Tap Save.

9.4.4 User Management

Steps

Tap → User Management → User Management → admin to enter the seng page.

Enter the old password and create a new password.

Conrm the new password.

Tap Save.

Note

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using 8-16 characters, including at least two kinds

of following categories: upper case leers, lower case leers, numbers, and special characters)

in order to increase the security of your product. And we recommend you change your password

regularly, especially in the high security system, changing the password monthly or weekly can

beer protect your product.

9.4.5 Network Sengs

You can set the wired network, Wi-Fi parameters and device port.

Wired Network

Set wired network.

DS-K1T502 Series Access Control Terminal User Manual

Tap → Communicaon Sengs → Wired Network to enter the conguraon page.

DHCP

If you disable the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default

gateway, IPv6 mode, IPv6 address, IPv6 subnet prex length, IPv6 default gateway, Mac address,

and MTU, Mac address, MTU.

If you enable the

funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4

default gateway, IPv6 mode, IPv6 address, IPv6 subnet prex length, and IPv6 default gateway

automacally.

DNS Server

Set the preferred DNS server and the Alternate DNS server according to your actual need.

Set Wi-Fi Parameters

Set the Wi-Fi parameters for device wireless connecon.

Steps

Note

The funcon should be supported by the device.

Tap → Communicaon Sengs → Wi-Fi to enter the sengs page.

Enable Wi-Fi.

DS-K1T502 Series Access Control Terminal User Manual

Figure 9-3 Wi-Fi

DS-K1T502 Series Access Control Terminal User Manual

Add Wi-Fi.

1) Tap Add Wi-Fi.

2) Enter Wi-Fi Name and Wi-Fi Password, and select Encrypon Type.

3) Tap Save.

Select the Wi-Fi name, and tap Connect.

Enter the password and tap Save.

Set Device Hotspot

Set the device hotspot, and mobile phone can connect to the device to enter the mobile browser.

Steps

Tap → Communicaon Sengs → Device Hotspot .

You can enable device hotspot and view the hotspot name.

Note

By default, the hotspot name is the AP_Device Serial No.

Tap Save.

Set Port Parameters

You can set the HTTP and HTTPS according to actual needs when accessing the device via network.

Tap → Network Service → HTTP(S) , to enter the seng page.

HTTP

It refers to the port through which the browser accesses the device. For example, when the

HTTP Port is

modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.

HTTPS

Set the HTTPS for accessing the browser. Cercate is required when accessing.

Plaorm

Access

Plaorm access provides you an opon to manage the devices via plaorm.

Steps

Tap → Device Access → Hik-Connect to enter the sengs page.

Note

Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the

device, receive alarm nocaon and so on.

Check Enable to enable the funcon.

You can enable Custom to enter the server address.

DS-K1T502 Series Access Control Terminal User Manual

Note

●

6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use

a combinaon of no less than 8 leers or numbers.

●

The vericaon code cannot be 123456 or abcdef (case non-sensive0).

You can view Register Status and Binding Status.

You can tap Bind An Account → View QR Code , scan the QR code to bind an acount.

Tap Save to enable the sengs.

Set ISUP Parameters

Set the ISUP parameters for accessing device via ISUP protocol.

Steps

Note

The funcon should be supported by the device.

Tap → Device Access → ISUP to enter the sengs page.

Enable ISUP.

Set the ISUP version, server Address, port, device ID and

encrypon key.

Note

If you select 5.0 as the version, you should set the encrypon key as well.

Tap Save to save the sengs.

SIP

Sengs

Tap → Device Access → VoIP to enter the sengs page.

Tap to Enable VoIP Gateway.

Set VoIP parameters and tap Save to save the parameters.

9.4.6 User Management

You can add, edit, delete, and search users via mobile Web browser.

Steps

Tap → Person Management to enter the sengs page.

Add user.

1) Tap+.

DS-K1T502 Series Access Control Terminal User Manual

Figure 9-4 Add User

2) Set the following parameters.

Employee ID

Enter the employee ID. The Employee ID cannot be 0 or exceed 32 characters. It can be a

combinaon of uppercase, lowercase leers and numbers.

Name

Enter your name. The name supports numbers, uppercase and lowercase English, and

characters. The name is recommended to be within 32 characters.

Floor No./Room No.

Enter the oor No./room No.

Long-Term Eecve

Set the user permission as long-term eecve.

Start Date/End Date

DS-K1T502 Series Access Control Terminal User Manual

Set Start Date and End Date of user permission.

Administrator

If the user needs to be set as administrator, you can enable Administrator.

User Role

Select your user role.

Fingerprint

Add ngerprint. Tap Fingerprint, then tap +, and add ngerprint via the ngerprint module.

Card

Add card. Tap Add Card. Enter the Card No., or present the card on the device and tap

Read, and select the Property. Tap Save to add the card.

Password

Note

●

Before conguring passwords, it is necessary to clarify whether the password is device-

set personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it

can be created and edited on Web and cannot be created and edited on the plaorm; If

it is a

plaorm-applied personal PIN, it needs to be congured on the plaorm and

cannot be edited on the Web.

●

Make sure Password Mode is selected as Device Password.

Tap Person Management → Add to enter the Add Person page.

Enter the password.

3) Tap Save.

Tap the user that needs to be edited in the user list to edit the

informaon.

Tap the user that needs to be deleted in the user list, and tap to delete the user.

You can search the user by entering the employee ID or name in the search bar.

9.4.7 Set Audio

Set the device volume.

Steps

Tap → Audio to enter the sengs page.

You can adjust the device input and output volume according to your actual needs.

You can enable voice prompt according to your actual needs.

9.4.8 Search Event

Tap Search to enter the Search page.

DS-K1T502 Series Access Control Terminal User Manual

Enter the search condions, including the employee ID, the name, the card No., the start me, and

the end me, and tap Search.

Note

Support searching for names within 32 digits.

9.4.9 Access Control Sengs

Set Authencaon Parameters

Set Authencaon Parameters.

Steps

Tap → Access Control → Authencaon Sengs .

DS-K1T502 Series Access Control Terminal User Manual

Figure 9-5 Authencaon Sengs

Tap Save.

Terminal

Main Card Reader

You can

congure the device card reader's parameters. If you select main card reader, you

need to congure the following parameters: Terminal Type, Terminal Model, Enable Card

Reader,

Authencaon, Recognion Interval (s), Minimum Card Swiping Interval (s),

Max. Authencaon Failed Aempts Alarm/Alarm of Max. Failed Aempts, Enable

Tampering

Detecon and Enable Card No. Reversing.

Card Reader Type

Get card reader type.

DS-K1T502 Series Access Control Terminal User Manual

Card Reader Descripon

Get card reader descripon. It is read-only.

Enable Card Reader

Enable the card reader's funcon.

Authencaon

Select an authencaon mode according to your actual needs from the drop-down list.

Authencaon Interval

You can set the

authencaon interval of the same person when authencang. The same

person can only authencate once in the congured interval. A second authencaon will be

failed.

Max. Authencaon Failed Aempts Alarm/Alarm of Max. Failed Aempts

Enable to report alarm when the card reading aempts reach the set value.

Enable Tampering Detecon

Enable the an-tamper detecon for the card reader.

Enable Card No. Reversing

The card No. will be in reverse sequence aer enabling the funcon.

QR Code

Enable the funcon and the user can use QR code to open the door.

Note

●

Disable the IR light if enabling the QR code funcon. For details, see Set Image

Parameters . The picture in low illuminaon environment may be aected due to disabling

the IR light.

●

Set QR code

funcon via HCC or HCEC, you should select compable to 1.0 or 2.0. 2.0 is

recommended.

Set Door Parameters

Tap → Access Control → Door Parameters .

DS-K1T502 Series Access Control Terminal User Manual

Figure 9-6 Door Parameters Sengs Page

Tap Save to save the sengs aer the conguraon.

Name

You can create a name for the door.

Open Duraon

Set the door unlocking duraon. If the door is not opened for the set me, the door will be

locked.

Exit

Buon Type

You can set the exit buon as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Open.

Door Remain Open Duraon with First Person (min)

DS-K1T502 Series Access Control Terminal User Manual

Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows

mulple persons access the door or other authencaon acons.

Door Open Timeout Alarm

An alarm will be triggered if the door has not been closed within the congured me duraon.

Door Contact

You can set the door contact as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Closed.

Extended Open

Duraon

The door contact can be enabled with appropriate delay aer person with extended access

needs swipes her/his card.

Duress Code

The door can open by inpung the duress code when there is duress. At the same me, the

client can report the duress event.

Super Password

The specic person can open the door by inpung the super password.

Unlock Password

The specic person can open the door by inpung the unlock password.

Note

The duress code and the super code should be dierent. And the digit ranges from 4 to 8.

Terminal Parameters

You can set terminal parameters for accessing.

Tap → Access Control → Terminal Parameters .

You can set Working Mode as Access Control Mode. The access control mode is the device normal

mode. You should

authencate your credenal for accessing.

Tap Save to save the sengs aer the conguraon.

Set Card Security

Tap

→ Access Control → Card Security to enter the conguraon page.

Set the parameters and tap Save.

Enable NFC Card

In order to prevent the mobile phone from

geng the data of the access control, you can

enable NFC card to increase the security level of the data.

Enable M1 Card

DS-K1T502 Series Access Control Terminal User Manual

Enable M1 card and authencang by presenng M1 card is available.

M1 Card Encrypon

Sector

M1 card encrypon can improve the security level of authencaon.

Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is

recommended to encrypt sector 13.

Enable EM Card

Enable EM card and

authencang by presenng EM card is available.

Note

EM card is supported when the device connects a peripheral card reader that supports

presenng EM card.

Enable DESFire Card

The device can read the data from DESFire card when enabling the DESFire card funcon.

DESFire Card Read Content

Aer enable the DESFire card content reading funcon, the device can read the DESFire card

content.

Enable FeliCa Card

The device can read the data from FeliCa card when enabling the FeliCa card funcon.

Set RS-485 Parameters

You can set the RS-485 parameters including the peripheral, address, baud rate, etc.

Tap → Access Control → RS-485 .

Tap Save to save the

sengs aer the conguraon.

Peripheral Type

Select a peripheral from the drop-down list according the actual situaon. You can select from

Card Reader, Extension Module, or Access Controller.

Note

Aer the peripheral is changed and saved, the device will reboot automacally.

RS-485 Protocol

Private

The device can connect with the third party device via RS-485.

OSDP

Standard RS-485 protocol.

DS-K1T502 Series Access Control Terminal User Manual

RS-485 Address

Set the RS-485 Address according to your actual needs.

Note

If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set

the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address

according to the door No.

Baud Rate

The baud rate when the devices are communicang via the RS-485 protocol.

Data Bit

The data bit when the devices are communicang via the RS-485 protocol.

Stop Bit

The stop bit when the devices are communicang via the RS-485 protocol.

Parity/Flow Ctrl/Communicaon Mode

Enabled by default.

Output Type

Set the output type according to your actual needs.

9.4.10 Intercom

Device ID Sengs

The device can be used as a door staon, or outer door staon. You should set the device No.

before usage.

Steps

Tap

→ Intercom → Device ID Sengs .

Set the following parameters.

Device Type

The device can be used as a door

staon or outer door staon. Select a device type from the

drop-down list.

Note

If you change the device type, you should reboot the device.

Period No.

Set the device period No.

Building No.

DS-K1T502 Series Access Control Terminal User Manual

Set the device building No.

Unit No.

Set the device unit No.

Note

If you change the No., you should reboot the device.

Floor No.

Set the device installed oor No.

Door Staon No.

Set the device installed oor No.

Note

●

If you change the No., you should reboot the device.

●

The main door staon No. is 0, and the sub door staon No. ranges from 1 to 16.

If set the device type as Outer Door Staon, you can set outer door staon No., and community

No.

Outer Door

Staon No.

If you select outer door staon as the device type, you should enter a number between 1 and

99.

Note

If you change the No., you should reboot the device.

Period No.

Set the device period No.

Session

Sengs

Enable the communicaon between door staon, main staon, and video intercom server.

Steps

Tap → Intercom → Session Sengs .

Set registraon password, main staon IP, private server IP and enable Protocol 1.0.

Registraon Password

Acvaon password of the main staon.

Main Staon IP

IP address of the main staon.

Private Server IP

IP address of the private server.

DS-K1T502 Series Access Control Terminal User Manual

Enable Protocol 1.0

Aer enabling, the device is registered to the main staon through the previous protocol. If

disabled, the device is registered to the main staon through the new protocol.

Tap Save.

Time Duraon Sengs

Set the Max. call duraon.

Tap → Intercom → Call Sengs .

Set the Max.

communicaon me. Tap Save.

Note

The Max. call duraon range is 90 s to 120 s.

Number Sengs

You can call the room SIP to call the room.

Steps

Tap → Intercom → Number Sengs .

Tap +, enter the Room No. and SIP Number.

Tap Save.

Press

Buon to Call

Steps

Tap

→ Intercom → Press Buon to Call .

Select the No. Select Call Indoor Staon, Call Specied Indoor Staon, Call Management Center

or APP at your needs.

Note

If you check Call Specied Indoor Staon, you need to enter the number of the indoor staon.

9.4.11 Set Privacy Parameters

Set picture upload and storage parameters.

Tap

→ Security → Privacy Sengs to enter the sengs page.

Picture Uploading and Storage

Upload Picture Aer Linked Capture

DS-K1T502 Series Access Control Terminal User Manual

Upload the pictures captured by linked camera to the plaorm automacally.

Save Pictures Aer Linked Capture

If you enable this funcon, you can save the picture captured by linked camera to the device.

9.4.12 Password Mode

Before conguring passwords, it is necessary to clarify whether the password is device-set personal

PIN or a

plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created and

edited on the local device and cannot be created and edited on the Web; If it is a

plaorm-applied

personal PIN, it needs to be congured on the Web and cannot be edited on the local device.

Tap → Security → Password Mode to enter the sengs page.

Plaorm Password

It needs to be congured on the Web. It cannot be edited on the local device.

Device Password

It can be created and edited on the local device. It cannot be created and edited on the Web.

9.4.13 Fingerprint Parameters

Sengs

Set ngerprint security level.

Tap → Smart .

Figure 9-7 Fingerprint Security Level

Note

The funcons vary according to dierent models. Refers to the actual device for details.

Select the security level according to actual needs. Tap Save to save the sengs.

DS-K1T502 Series Access Control Terminal User Manual

9.4.14 Upgrade and Maintenance

Restart device, restore device parameters, and upgrade device version.

Restart Device

Tap → Restart Device .

Tap Restart to restart the device.

Upgrade

Tap → Upgrade .

Tap Upgrade to upgrade the device.

Note

Do not power o during the upgrading.

Restore Parameters

Tap → Default .

Restore to Default Sengs

The device will restore to the default sengs, except for the device IP address and the user

informaon.

Restore to Factory Sengs

All parameters will be restored to the factory sengs. You should acvate the device before

usage.

9.4.15 View Online Document

Tap → View Online Document . Tap View Online Document, you can scan the QR code with

your mobile phone for details.

9.4.16 View Open Source

Soware License

Tap → Open Source Soware License , and tap Open Source Soware License to view the

device license.

DS-K1T502 Series Access Control Terminal User Manual

Chapter 10 Other Plaorms to Congure

You can also congure the device via iVMS-4200 Client Soware or HikCentral Access Control. For

details, see the

plaorms' user manual.

iVMS-4200 Client Soware

Click/tap the link to view the client soware's user manual.

hp://enpinfodata.hikvision.com/analysisQR/showQR/ca930247

HikCentral Access Control (HCAC)

Click/tap the link to view the HCAC's user manual.

hp://enpinfodata.hikvision.com/analysisQR/showQR/f2f6cf42

DS-K1T502 Series Access Control Terminal User Manual

Appendix A. Tips for Scanning Fingerprint

Recommended Finger

Forenger, middle nger or the third nger.

Correct Scanning

The gure displayed below is the correct way to scan your nger:

You should press your nger on the scanner horizontally. The center of your scanned nger should

align with the scanner center.

Incorrect Scanning

The gures of scanning ngerprint displayed below are incorrect:

DS-K1T502 Series Access Control Terminal User Manual

Environment

The scanner should avoid direct sun light, high temperature, humid condions and rain.

When it is dry, the scanner may not recognize your

ngerprint successfully. You can blow your

nger and scan again.

Others

If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other

authencaon methods.

If you have injuries on the scanned nger, the scanner may not recognize. You can change another

nger and try again.

DS-K1T502 Series Access Control Terminal User Manual

Appendix B. Dimension

Dimension of Device

DS-K1T502 Series Access Control Terminal User Manual

UD29355B-C

Hikvision DS-K1T502DBWX Access Control Terminal

Product's Documents

User Manual

Specifications

Hikvision DS-K1T502DBWX Questions and Answers
