VERTUO
LATTISSIMA
INSTALLATION
1. Machine overview 3
2. Package content 7
3. Connectivity 7
4. Water hardness seing 8
5. Open/close 10
6. Disassembling the milk carafe 10
7. Assembling the milk carafe 11
8. Cleaning the milk carafe 12
9. First use 13
USE
10. Coee Preparation 15
11. Milk Preparation & Daily rinsing 17
12. Milk recipes 22
SETTINGS
13. Energy saving 25
14. Seing the coee volume 26
15. Reset to factory seings 26
16. Turn on/o Bluetooth & Wi-Fi 27
MAINTENANCE
17. Emptying the system before a period of non-use 28
18. Aer a long period of non-use 30
19. Cleaning cycle 32
20. Descaling 35
21. Troubleshooting 38
TECHNICAL SPECIFICATIONS
22. Specifications 41
23. Disposal and environmental protection 41
2
1
1
3
9
10
5
6
8
4
7
11
1
OVERVIEW
1 Water tank and lid
2 Descale mark
3 Maximum level mark
4 Milk carafe connector hatch
5 Coee outlet
6 Descaling pipe
7 Descaling pipe cover
8 Used capsule container
9 Drip tray
10 Drip grid
11 Adjustable cup support
Overview of machine
4
12
14
15
16
18
17
13
12 Coee buon - ON/OFF
13 Locking / Unlocking lever
14 Descale alert
15 Rinse alert
16 Hot foam buon
17 Lae macchiato buon
18 Cappuccino buon
Refer to “Descaling”
section
See recipes on page 23
Refer to “Milk
preparation” section
Unboxing: some dust may be present on the surface of the machine due
to the recycled materials used in the packaging. This is not a hazard, sim-
ply clean it with a so, clean damp cloth.
Overview of display
5
25
26
21
29
19
22
27 28
23
20
24
19 Milk carafe
20 Milk carafe lid
21 Milk spout
22 Milk action knob
23 Milk carafe connector
24 Connector housing
25 Milk aspiration tube
26 Lid removal buon
27 “Remove to clean” position
28 Rinse position
29 Milk recipe position
Overview of milk carafe
6
HELP
www.nespresso.com/help
SAFETY
CAUTION: Before operating your coee machine, please refer to the
safety instructions leaflet to avoid possible injury and damage.
THANK YOU FOR CHOOSING
NESPRESSO.
FOLLOW THESE INSTRUCTIONS OR GO ONLINE FOR THE FULL USER
MANUAL AT WWW.NESPRESSO.COM/HELP
.
*
**
7
1. Download the Nespresso App.
2. Launch the App on your smartphone or tablet.
3. Click on the Machine icon.
4. Follow the instructions via the App.
3
2
Connectivity
BENEFITS OF CONNECTING YOUR MACHINE
Smart Coee: Enjoy the latest coee innovations from Nespresso by always
keeping your machine soware up to date.
Expert advice: Receive tips in real-time, thanks to step-by-step instructions
for descaling, rinsing, & cleaning your machine, and other features.
Machine care: Get support and tutorials for your machine care via your
smartphone.
How to connect your machine:
Package content
1. Coee machine
2. Nespresso welcome material
3. Nespresso capsules box
4. Safety instructions
5. Quick start guide + Water hardness test strip
6. Warranty
Smart
coee
Expert
advice
Machine
care
* AppStore
®
is a trademark of Apple Inc., registered in the U.S. and other
countries.
** Google Play and the Google Play logo are trademarks of Google LLC.
8
4
1. Take the water hardness test strip in the quick start guide and place it un-
der water for 1 second. Wait about one minute before reading the test
result.
2. The number of red squares indicates the water hardness.
1s
1.
0
1.
1
1. 2
1. 3
1.
4
3.
Water hardness seing
9
10. The buons blink three times rapidly to confirm new seing.
11. The machine is now reprogrammed with the new water hardness seing
and turns automatically in ready mode.
3. Plug in the power cord.
4. Make sure that no accessory (milk carafe or descaling pipe) is connected
to the milk carafe connector hatch.
5. Turn the machine on.
NOTE: Programming the machine according to the actual hardness of the
local water supply ensures a longer lifetime for the appliance, as well as opti-
mizing the descaling process.
1x
6. Press hot foam buon for three seconds to enter the menu mode.
7. Clean and descale alerts blink together.
8. Press cappuccino buon , the system proposes one out of the five
combinations. If the selection is not done within 15 sec., it exits automati-
cally.
9. Set the hardness level by pressing the corresponding buon in below ta-
ble (within 15 seconds).
Water hardness Buon to press fH dH CaCO3
< 5 < 3 < 50mg/l
> 7 > 4 > 70mg/l
> 13 > 7 > 130mg/l
+
> 25 > 14 > 250mg/l
+
> 38 > 21 > 380mg/l
10
1. Press lid buon to remove the lid from the milk carafe. Disconnect the
aspiration tube. Turn the milk spout counterclockwise and gently tug to
remove it.
2. Turn the milk carafe connector towards the unlocked position and ex-
tract it. Turn the knob to “remove to clean” position and pull it out.
5
Open/close
6
Disassembling the milk carafe
11
1. Carefully insert the milk carafe connector in the milk carafe lid and turn it
clockwise towards the locked position . Insert the milk spout. Insert the
knob and turn it to the “milk” position.
7
Assembling the milk carafe
2. Insert the aspiration tube so that its circular lip touches the boom of the
carafe lid. Plug the milk carafe lid to the milk carafe.
12
1. Disassemble the milk carafe. Refer to section “Disassembling the milk ca-
rafe”.
2. If a dishwasher is available: place all milk carafe components in the upper
part of your dishwasher.
If a dishwasher is not available: soak all components in hot potable water
(50°C / 122°F) together with a mild detergent for at least 30 minutes; then
rinse thoroughly with hot potable water (50°C / 122°F). Do not use scented
detergents.
8
Cleaning the milk carafe
This procedure must be performed aer each use. Dishwashing is recom-
mended. When a dishwasher is not available, the milk carafe components can be
washed by hand.
*
3. Clean the interior of the milk carafe, the milk spout and the knob with a mild
detergent and rinse with hot potable water.
* Make sure the Air inlet is clean, this will ensure beverage quality cup aer
cup.
Do not use abrasive material that might damage the surface of the equipment.
4. Dry all six components with a clean cloth and reassemble. Refer to section
“Assembling the milk carafe”.
Aer cleaning the milk carafe, if the milk frothing performance is still not to
your satisfaction, proceed with a second rinsing cycle by turning the knob to the
rinse position.
or
13
9
First use
4. Press the coee buon three times within 2 seconds.
1. Rinse the water tank before filling it with fresh potable water only, up to
the maximum level.
2. Put the water tank back in position. Plug in the power cord and position a
container under the coee outlet. Ensure the lever is in the locked position
.
3. Turn on your machine.
1x
14
7. Then reassemble all six dried components and re-aach the milk carafe to
the machine (refer to "Assembling / Disassembling the milk carafe" sec-
tion).
8. Your machine is now ready to use.
5. The machine will start rinsing. The cleaning procedure will run automati-
cally for 5 minutes.
NOTE: water may accumulate inside the machine’s head during cleaning.
If this happens, dry the visible parts with a clean cloth.
6. Disassemble the milk carafe and clean all six components in the top rack
of your dishwasher. If a dishwasher is not available, refer to "Cleaning the
milk carafe" section.
Caution: first read the safety precautions to avoid risks of fatal electrical
shock and fire. Please ensure ground continuity when plugging the machine
in the power outlet.
NOTE: to turn o the machine, press and hold the ON-OFF/Coee buon
until it switches o.
When unpacking the machine, remove the plastic film, water tank and cup
support. Adjust the cable length and store the excess in the cable guide un-
der the machine.
2. Turn the lever towards the unlocked position (1) and insert a capsule
(2).
3. Close the machine by turning the lever (1) to the locked position (2).
Place a cup on the support (3). Cup support height can be adjusted to
accommodate your cup size.
15
10
1. Fill the water tank with fresh potable water only.
Coee preparation
4. The coee buon starts blinking, and as soon as light is steady white,
press the coee buon to start the brewing process.
16
5. When the coee stops brewing, turn the lever towards the unlocked posi-
tion to open the machine and eject the capsule. Then close it.
1x
17
WARNING: Plant-based beverages contain allergens (gluten, almond,
soy) and should be handled carefully by people suering from food allergies.
The volume of froth depends on the nature of the beverage used, and its
temperature.
For a perfect milk froth, use fresh partly skimmed, pasteurized cow milk
at refrigerator temperature (about 4°C). It is recommended to clean the milk
carafe aer each use.
WARNING: Do not use liquids other than cow milk and plant-based
beverages.
2. Fill the milk carafe up to the “MAX” level, do not overfill. Reassemble the
milk carafe.
1. Fill the water tank with fresh potable water only, up to the “MAX” level
before preparing a coee or a milk recipe.
max
11
Milk Preparation & Daily Rinsing
18
5. Open the steam connector hatch by sliding it down. Connect the milk ca-
rafe to the machine.
3. Turn the lever to the unlocked position and insert the capsule. Close the
machine and then push the lever towards the locked position . The ma-
chine heats up for approximately 30 seconds (fading coee buon).
4. Turn the knob to the milk position.
19
7. Wait until cappuccino buon , lae macchiato buon and hot
foam buon light up.
8. Press the cappuccino or lae macchiato buon . The preparation
starts aer approx. 30 seconds (for a cappuccino first coee then milk; for
a lae macchiato first milk then coee) and will stop automatically.
9. At the end of the preparation, the rinse alert lights up to indicate that
a rinse cycle of the milk carafe is required.
6. Place a cappuccino cup or a lae macchiato glass under the coee outlet
and adjust milk spout position by rotating it up to the center of the cup.
Refer to section 12 for cup size selection according to recipe style and cap-
sule selected.
20
WARNING: the rinsing system does not remove the allergens. Disassem-
ble and clean the milk carafe, preferably in the dishwasher, before replacing
the milk,. If a dishwasher is not available, wash by hand.
Aer each milk or plant-based preparation, we recommend running the
carafe rinse cycle.
11. When the rinsing process is finished, the rinse alert turns o. Turn the knob
back to the milk seing .
10. Place a container (minimum 200 ml) under the milk spout. Turn the knob
to rinse position. The milk system rinsing process starts and hot wa-
ter combined with steam flows through the milk spout. The rinse process
stops automatically.
21
12. If there is milk le in the milk carafe: Detach the milk carafe from the
machine immediately and place it in the refrigerator. Close the machine
steam connector hatch by pulling it up.
CAUTION: aer rinsing, place the carafe in the refrigerator respecting the
storage instructions on the milk package. If the milk carafe is le outside the
refrigerator for longer than 30 min, disassemble it and clean all components
(refer to "Cleaning the milk carafe" section).
13. If the milk carafe is empty or has been stored for more than 24 hours in
the fridge; before refilling it, disassemble all six milk carafe components
and clean them in the upper rack of your dishwasher. If a dishwasher is not
available, refer to section “Cleaning the milk carafe”.
NOTE: refer to the section “Disassembling the milk carafe”.
NOTE: When the preparation is complete, turn the lever towards the un-
locked position to open the machine and eject the capsule. Then, close
the machine.
22
A cappuccino is characterized by a coee topped by a thick layer of milk froth.
CAPPUCCINO:
TIPS:
The milk froth quality and appearance may be aected by the type, freshness
and temperature of the milk (ideally stored at 4°C).
ESPRESSO RANGE CAPSULES
CHOICE OF COFFEE CHOICE OF CUP
S 25 ml / 0.84 fl oz Min 180 ml / 6 fl oz
M 40 ml / 1.35 fl oz Min 270 ml / 9 fl oz
L
80 ml / 2.7 fl oz Min 390 ml / 13 fl oz
Milk foam
Coee
12
Milk recipes
23
CHOICE OF COFFEE CHOICE OF CUP
S 25 ml / 0.84 fl oz Min 270 ml / 9 fl oz
M 40 ml / 1.35 fl oz Min 390 ml / 13 fl oz
L
80 ml / 2.7 fl oz Min 590 ml / 20 fl oz
A lae macchiato is a recipe in which coee is poured over a glass of frothy
milk.
LATTE MACCHIATO:
TIPS:
The milk froth quality and appearance may be aected by the type, freshness
and temperature of the milk (ideally stored at 4°C).
ESPRESSO RANGE CAPSULES
Milk foam
Coee
24
HOT FOAM:
CHOICE OF CUP:
M Min 270ml / 9fl oz
Use the hot foam function to tailor your perfect milk beverage: simply top up
your existing milk beverage with more foam, or experience maximum flexibil-
ity to create your own milk beverage or just to enjoy a cup of frothy hot milk.
A) Press the hot foam buon, and when the default/programmed volume is
reached the machine will automatically stop.
B) To obtain more hot foam, press the buon again, and when the desired
quantity is reached stop the process by pressing the buon once more.
stop
1x
start
1x
1x
13
200 ml /
6.75 fl oz
Milk
3 s
25
13
The machine can be turned “OFF” at any time (when not in use) by holding
the coee buon for three seconds.
Automatic “OFF” Mode: the machine will turn o automatically
aer 2 minutes of non-use.
Energy saving
Note:
• During the hot foam function it is possible to program a coee. When the
coee buon lights up, press it. When the milk beverage is completed, the
coee will automatically start brewing. Make sure a capsule has been insert-
ed.
• During the coee brewing, it is also possible program the hot foam function.
When the hot foam buon is lights up, press it. When the coee has finished
brewing, the milk will automatically start to flow. Make sure the milk carafe
has been inserted.
C) PROGRAMMING THE HOT FOAM VOLUME
1. Press and hold the hot foam buon for three seconds, until it starts flashing.
2. Once the desired quantity is reached, press again the hot foam buon to
save the new programmed volume. The volume can be reprogrammed from
80ml minimum to 200mL maximum.
Note: If you wish to return to the default factory seings (200ml), see the para-
graph “Reset to factory seings”.
1x
26
14
Seing the coee volume
1. The programming of the coee volume is specific to each capsule type:
Espresso, Double Espresso, Gran Lungo, Mug or Carafe.
2. Open the machine, insert the capsule you want to program; close the ma-
chine; turn the lever towards the locked position . The light will blink
while the machine is heating up. A steady light indicates that the machine
is ready.
3. Then press and hold the buon until the desired volume is reached.
4. The new coee volume is now stored for the capsule type used during the
seing.
Note: once a customer-specific volume is programmed by the user, every
time that capsule type is inserted in the machine, the preparation will keep to
the user-programmed cup size.
Note: if you wish to return to the default parameters see the paragraph
“Reset to factory seings”.
15
Reset to factory seings
1. Plug in the power cord.
2. Make sure that no accessory (milk carafe or descaling pipe) is connected
to the milk carafe connector hatch. Turn on your machine.
1x
27
3. Press and hold the hot foam buon until the descale and rinse alerts
both blink (enter menu mode).
4. Press the hot foam buon to enter reset mode. If the selection is not
done within 15 sec., it exits automatically.
5. Only the hot foam buon will blink.
6. Press the hot foam buon to reset to factory seings; all 3 milk recipe
leds blink three times to confirm factory reset (within 15 seconds).
7. The machine is now programmed with the factory seings and reverts au-
tomatically to the ready mode.
16
Turn on/o Bluetooth & Wi-Fi
1. Unplug the machine
3. Selected operation:
-
TURN ON: the coee buon remains steady blue for a few seconds .
- TURN OFF: the coee buon remains orange for a few seconds .
4. Machine returns to ready mode .
2. Make sure the lever is in the middle position. Press and hold the coee
buon while plugging in.
10 s
1
2
28
6. Close the machine and turn the lever le to the locked position and
place a container (1L) under the coee outlet.
5. Empty the capsule container, the drip tray and the cup support.
1. Plug in the power cord.
2. Make sure that no accessory (milk carafe or descaling pipe) is connected
to the milk carafe connector hatch.
3. Empty the water tank and put it back in place.
Emptying the system before a period of
non-use, for frost protection or before a
repair
4. Open the machine by turning the lever to the unlocked position to re-
move the capsule.
17
29
7. The light will blink while the machine is heating up. A steady light indi-
cates that the machine is ready.
8. Press and hold the hot foam buon until both the rinse and descale
alerts flash (menu mode entry)
9. Press hot foam and lae macchiato simultaneously to enter the
emptying mode. If the selection is not done within 15 sec., it exits auto-
matically.
10. The hot foam buon blinks.
11. Press the hot foam buon to start the emptying process (within 15
seconds).
12. When the process is finished, the machine switches o.
CAUTION: Small quantities of steam may escape from the machine as it
drains the remaining liquids.
3. Turn on your machine.
1x
30
18
4. Press the coee buon three times within 2 seconds.
1. Rinse the water tank before filling it up to the maximum level with fresh
potable water.
2. Put the water tank back in its lodging. Plug in the power cord and position
a container under the coee outlet.
Aer a long period of non-use
31
7. Then reassemble all six dried components and re-aach the milk carafe to
the machine (refer to "Assembling / Disassembling the milk carafe" sec-
tion).
8. Your machine is now ready to use.
NOTE: water may accumulate inside the machine’s head during cleaning.
If this happens, dry the visible parts with a clean cloth.
5. The machine will start rinsing. The cleaning procedure will run automati-
cally for 5 minutes.
6. Disassemble the milk carafe and clean all six components in the top rack
of your dishwasher. If a dishwasher is not available, refer to "Cleaning the
milk carafe" section.
19
32
1. Rinse and clean the water tank and the lid before filling it with fresh pota-
ble water. Put the water tank in its lodging.
The machine has a predefined cleaning procedure that can be launched at
user discretion.
2. Take out the cup support and clean it. Wash with hot water and mild un-
scented detergent.
3. Place a container of at least 1 L under the coee outlet.
Cleaning cycle
6. The light will blink while the machine is heating up. A steady light indi-
cates that the machine is ready.
33
Before running the cleaning cycle, make sure that no capsule has been le
in the machine.
5. Close the machine and turn the lever le toward the locked position .
4. Open the machine to eject the used capsule. Empty and rinse the capsule
container and the drip tray.
7. Press the coee buon three times within 2 seconds.
8. The machine will start rinsing. The cleaning procedure will run automati-
cally for 5 minutes.
9. The procedure can be stopped at any time by pushing the coee buon
which automatically restores the ready mode.
CAUTION: do not use any strong or abrasive cleaning agent or solvent
cleaner. Do not use a dishwasher. Never immerse the appliance or part of it in
water. Wipe the coee outlet regularly with a clean damp cloth. A clean, lint-
free cloth and fresh water are essential for keeping your coee machine in top
condition
NOTE: water may accumulate inside the machine’s head during cleaning.
If this happens, dry the visible parts with a clean cloth.
34
20
35
20
To ensure the proper functioning of your machine over its lifetime, making
your coee experience as perfect as it was the first day, follow the process
below:
1. When the descaling alert starts to blink, it is time to descale your ma-
chine. The descaling process takes approximately 20 minutes.
2. Open the machine to eject the used capsule.
Descaling alert
Blinks orange Your machine must be descaled.
Fast-blinking orange
Only few recipes before geing your machine
blocked. Proceed immediately to descaling.
Steady light
Your machine is blocked to prevent any damages.
Descale now.
Descaling
36
5. Take out the descaling pipe located at the back of the machine and plug
it into the milk carafe connector. Put the water tank back on the machine.
3. Close the machine and turn the lever toward the locked position .
4. Empty the drip tray, used capsule container, and cup support. Fill the wa-
ter tank with two units of Nespresso descaling agent. Add water up to the
“descale” mark on the water tank (~ 1000 ml / 1l / 33.81 fl oz).
2 x ~1 L
37
8. Press cappuccino buon .The descaling product flows alternately
through the coee outlet, descaling pipe, and drip tray. When the des-
caling cycle is finished
(the water tank runs empty), the lae macchiato
buon lights up.
9. Empty the drip tray, used capsule container, cup support and container.
Rinse and fill water tank up to “ Max” level with fresh potable water.
Empty the 1L container and put it back under both outlets.
6. The machine automatically enters descaling mode. The “descale” alert
blinks orange during the entire descaling process. The cappuccino buon
lights up.
7. Place a container with a minimum of 1L capacity under the coee and des-
caling pipe nozzle.
10. Press the lae macchiato buon . The rinse cycle continues through
the coee outlet, descaling pipe and drip tray until the water tank is emp-
ty.
11. Once the rinsing process is finished, the machine returns to ready mode.
Remove the descaling pipe and store it. Empty the drip tray and used cap-
sules container. Fill the water tank with fresh potable water.
NOTE: water may accumulate inside the machine’s head during cleaning.
If this happens, dry the visible parts with a clean cloth.
38
21
NOTE: Always respect descaling agent and water volumes in the tank to
ensure completion of the cycles.
The machine can still prepare several milk beverages before it is blocked
preventively. The blockage prevents any damage to the machine and ensures
its proper functioning over its lifetime.
If the machine is blocked, descale it. Please make sure the entire descaling pro-
cedure is completed. If it is not completed, the machine will remain blocked.
Troubleshooting
Buon does not light up. • The machine has turned OFF automatically; push the buon or
“UNLOCK” the machine.
• Check the mains, plug, voltage, and fuse.
No coee, no water, no milk. • Check that the water tank is filled.
• Check that a fresh capsule is inserted in the correct position and
that the handle is properly locked, and then push the buon
to start.
• Descale if necessary.
• Open the machine to eject the used capsule.. Then perform
cleaning as described in the cleaning section.
• Check if the milk carafe is inserted and filled.
Coee comes out very slowly. • Flow speed depends on the coee variety.
Coee is not hot enough. • Preheat cup with hot drinking water from the tap.
• Descale if necessary.
Leakage or unusual coee flow. • Check that the water tank is well positioned. Empty the drip
tray.
Machine turns to “OFF mode”. • To save energy the machine will turn o aer 2 minutes of non-
use.
• See paragraph on “Energy Saving”.
There are coee grounds in the
cup.
• Perform the cleaning procedure twice.
• See the “Cleaning cycle” section.
The machine doesn’t start and
lights are steady on. If blinking,
see the following points.
• Check that handle is properly locked.
• If you want to brew a Coee or Espresso, check that a fresh cap-
sule is inserted in correct position, that the handle is properly
locked and push the buon to start.
• If you are cleaning, descaling or emptying the system, check
that no capsule has been le inside, lock the machine and push
the buon to start one of these operations.
39
The machine doesn’t start and the
lights blink irregularly.
• Fill the water tank and push the buon to start.
• Check that handle is properly locked.
Lights blink while machine is run-
ning.
• If coee or milk is flowing normally, this indicates the machine
is working properly.
• If only water is flowing, the machine is executing a user request
for either cleaning, descaling or emptying the system. Refer to
the corresponding section in this user manual.
Lights blink and the machine is not
running.
• It takes some time before the coee flow comes out (due to
code reading and pre-weing the coee).
• Check that a fresh capsule is inserted in the correct position and
that the handle is properly locked, and then push the buon
to start.
• Fill the water tank and push the buon to start.
• Turn the machine to “OFF mode” by pushing the coee buon
for 3 seconds and then push it again to turn the machine ON.
Now wait approximately 20 minutes to allow the machine to
cool down aer extensive use.
Lights blink irregularly.
Machine is not running.
• During regular Coee/Espresso preparation: 1) Unlock the han-
dle and open the machine head to check that a fresh undam-
aged capsule is inserted in the correct position. 2) Check that
the handle is in “LOCKED” position. 3) Check that the water
tank is filled.
• During Descaling, Emptying and Cleaning: 1) Check that cap-
sule is ejected. 2) Check that the handle is in “LOCKED” posi-
tion.
• During Programming Volume: 1) Check if a capsule has been
well inserted. 2) Please refer to the corresponding chapter.
• If problem persists:
• 1. Unlock the handle and open machine head.
• 2. Replace capsule (if necessary).
• 3. Disconnect the power cord from the outlet and plug the ma-
chine back into outlet aer 10 seconds.
• 4. Close the machine and press the buon to turn it ON and
press again to start brewing. If problem persists, call Nespresso.
Descaling alert blinks or is fixed
orange.
• The machine triggers descaling alert according to your bever-
age consumption. Descale the machine. Refer to “Descaling”
section related to your beverage consumption.
Rinse alert blinks orange. • The milk carafe requires a rinse cycle; refer to section “Milk
Preparation & Daily rinsing”.
You cannot enter the Menu Mode
(Reset to factory seings/ Empty-
ing the system before a period of
non-use/Water hardness seing).
• Be sure to remove the milk carafe from the connector hatch.
• Be sure that the descaling pipe is not connected to the connec-
tor hatch.
• Press and hold hot foam buon
until descale and rinse
alerts blink.
40
22
23
Turn o the machine.
• Hold the coee buon
for three seconds. See “ Energy
Saving “ section.
The brewed quantity is not su-
cient.
• Check that the water tank is filled.
• Check that the milk carafe is filled.
• See the section on “Seing the coee volume“.
The lever does not close complete-
ly.
• Empty the capsule container. Make sure that no capsule is
blocked inside the capsule container.
The quality of the milk froth is
poor.
• Use partly skimmed cow milk at refrigerator temperature
(about 4° C).
• The milk action knob is on remove to clean
position. Turn it
to milk position.
• Rinse aer each milk preparation and ensure the air inlet of the
milk action knob is clean. See the section on “Cleaning the milk
carafe”.
• Descale the machine (refer to the “Descaling” section).
• Do not use either frozen milk or hot milk in the carafe.
• Ensure that all the components of the milk carafe are well as-
sembled. Refer to the section on “Assembling the milk carafe”.
The milk carafe cannot be disman-
tled.
• Press the buon on the side of the milk carafe to remove the
milk carafe lid.
• Refer to the section on ”Assembling / Disassembling the Milk
carafe”.
The milk carafe is inserted but the
milk buons are not enabled.
• The milk action knob is on the rinse
position. Turn it to the
milk position. Wait for the coee side to finish heating up.
• Make sure the carafe is properly inserted.
When the Hot foam , Lae
macchiato and Cappuccino
buons are blinking alternate-
ly.
• The machine is overheated: wait until it cools down.
When the Hot foam , Lae
macchiato and Cappuccino
buons are blinking together.
• The water tank is empty.
• Fill the tank.
→ INSTRUCTIONS ARE ALSO AVAILABLE AT
WWW.NESPRESSO.COM
41
22
23
Specifications
220-240 V, 50-60 Hz, 1300-1500 W
USA, CA: 120 V, 60 Hz, 1500 W
Frequency
2.402 - 2.480 GHz
Max Transmit Power 4dBm
Standby
0.5 W/h
6.3 kg / c. 14 lb
1.6 L / 1.7 qt
(WxDxH)
190 x 407 x 315 mm / c. 7.5 x 16 x 12.4 in. (with cup support and milk carafe)
Disposal and
environmental protection
This appliance complies with the EU Directive 2012/19/EC. The packaging materials and appliance
contain recyclable materials. Your appliance contains valuable materials that can be recovered or
can be recycled. Separation of the remaining waste materials into dierent types facilitates the re-
cycling of valuable raw materials. Leave the appliance at a collection point. You can obtain informa-
tion on disposal from your local authorities. To know more about Nespresso sustainability strategy,
go to www.nespresso.com/positive.
www.nespresso.com
57132C8439_00_0523
