SAFETY PRECAUTIONS
Q1: How does this product massage?
A1: This knee massager combines heating therapy for the knee area and
compression therapy(airbags inflated/deflated in different patterns) to
massage the surrounding areas. Helps to relaxmuscles, improve circulation
and relieve pain.
Q2: How many massage modes, and what's the difference?
A2: There are 2 airbags inside each knee wrap, one is below the knee and
another is above, and it has 3 massage modesof how the compression
therapy works.
Mode 1: Sequence Mode
below knee inflated - deflated - above knee inflated - deflated, this
pattern runs in repeat.
Mode 2: Circulation Mode
Below knee inflated - above knee inflated - all deflated, most of the time
this pattern runs in repeat and there are moments that the below airbag
or above airbag compress and release in a short and quick way.
Mode 3: Combination Mode
Mode 1 and mode 2 runs alternately in this mode.
Q3: Why can’t I feel the heat?
A3: The heat is optional and it’s off by default, you can press the heat
button “ ”to turn it on/off, please allow 2~5 minutes for heating up.
Warnings
1. Those with any of the following conditions or persons who are receiving
medical treatment should consult the doctor before using the product:
1) Using pacemaker or other medical devices which are susceptible to
electrical interference;
2) Suffering from malignant tumors;
3) Suffering from cardiac diseases;
4) Having serious peripheral neuropathy dysfunction or sensory disturbance
caused by diabetes;
5) Being unsuitable to do the massage because of traumas on the body;
2. Keep it out of the reach of infants, children, and people without the
ability to use it independently.
3. Don’t use another power adapter but the original one.
4. Don’t scratch, damage, process, excessively band, pull or twist the power
cord of power adapter. Otherwise, it may cause fire or electric shock.
5. It is not allowed to use when the power adapter dysfunctions or the
plug is loose.
6. Don’t plug or unplug the power adapter with wet hands.
7. It is forbidden to remodel, disassemble or repair the product without
permission.
CONTENTS
SAFETY PRECAUTIONS
FAQs
NAMES OF COMPONENTS
OPERATING INSTRUCTIONS
MAINTENANCE
STORAGE
DISPOSAL
TROUBLESHOOTING
SPECIFICATIONS
PACKAGE INCLUDES
CONTACT US
1
2
3
4-5
6
6
6
7
7
8
8
FAQs
Warnings
1. Stop using it immediately if you feel unwell. Don't use it again before
consulting the doctor.
2. Don't use it in the bathroom or other humid places.
3. Unplug the power adapter from the socket before you clean and
maintain it.
4. Unplug the power adapter when you are not using it.
01 02
Heating Area
Control Panel
Adapter
Velcro
Closures
Airbags
NAMES OF COMPONENTS
OPERATING INSTRUCTIONS
1.Unfold the wrap and wear it properly, make sure the control panel is in
the correct direction. Take Left leg as an example as below.
2.Fix the thigh part via velcro closure, check and adjust the position and
tightness as below, don’t wrap too tight.
Q4: What should I do when the temperature is too high or too low?
A4: There are 2 heating temperature levels, you can choose low or high,
if you think it’s too high even in the low setting, please turn off the heat,
or stop the massage and take off the wrap if needed. It is recommended
to wear pants for a better experience.
Q5: What should I do if I feel the massage strength is too light or too strong?
A5: This knee massager has 3 compression intensities available, please
choose the one comfort you most. You can also adjust the intensity by the
tightness of the wrap.
Q6: How long should I use it?
A6: It is suggested to use it once or twice a day, 20 minutes each time.
You can also use it longer if you feel too tired and wanna enjoy it more.
Q7: Can I use it only on one knee?
A7: Surely you can, each wrap has its own controller attached, which means
that each wrap is independently controlled, so you can use one wrap or
both at a time.
Q8: Sometimes it seems that the pressure is different. Why does it work
inconsistently?
A8: In generally, it works the same when you turn them on at the same time.
But since each wrap is independently controlled, there will be time difference.
Also, it may be different because the tightness of the wrap is different
when you wear it. It is a normal phenomenon and will not affect how the
device works or experience.
Power Button
Mode Button
Intensity Button
Heat Button
Power Jack
0403
Indicators
Power Mode Heat Intensity
3.Fix the calf part, check and adjust the tightness, don’t wrap too tight.
4.Plug the adapter into the outlet and connect it with the control panel.
Note: Please plug it in tighter.
5.Press the“ ”button to start the massage, power indicator is in blue
and it will begin with Mode 1 / Low intensity / Heat off by default.
6.Press the“ ”button tochange between 3 massage modes, see the
difference of the modes in FAQs/ Q2.
- Sequence Mode - Circulation Mode - Combination Mode● ● ●
7.Press the“ ”button toadjust the intensity, 3 levels available:
low/mid/high, we suggest starting with the lowest level then build up as
needed after you get used to it.
Tips: You can also change the tightness of the wrap to adjust the intensity.
- Low - Mid - High● ● ●
8.Press the“ ”buttonto turn on / off the heat , or to select between 2
temperatures: low / high.
- Low - High● ●
9. After use, please disconnect the adapter and fold the wrap into the
storage bag or the original package.
05
Note:
1.The heat is optional, you can turn it on or off anytime during the massage
2.Each wrap has its control panel, you can use only one or both at the same
time
3.The massager will automatically shut off after 20 minutes’operating, you
can press the power button to reset or end the experience earlier.
MAINTENANCE
Make sure to cut off the power before you clean the device
1. If dirty, please wipe with a soft clothmoistened by soap solution.
2. Don’t use gasoline, alcohol, diluent,and other irritating liquid to wipe
themachine in case it causes malfunction or the components are damaged
or discolored.
3. Do not hold the device under running water, do not submerge it in water
or other liquids.
4. Toothpicks can be used to remove the hair or chippings attached tothe
Velcros.
5. Don't dissemble the machine by yourself.
STORAGE
1.Keep it out of the reach of children.
2.Don't place it in high temperature and humidity conditions.
3.Avoid direct sunlight.
4.Avoid needles puncture the airbags.
5.Don't place heavy stuff on it.
DISPOSAL
Please adhere to the local regulations when you dispose of the wasted
06
TROUBLESHOOTING
Problems Causes & Solutions
1. Make sure the adapter is connected well.
2. Check if the cord is damaged, in this
case, please contact our after-sales team.
3. Press the power button to start
Doesn’t work and the
indicator light is off
1. Check if the adapter is loose orfallsoff.
2. It will shut off automatically after 20
minutes using,press the power button
to restart.
Break off during operation
SPECIFICATIONS
Product Name
Model No
Rated Voltage
Rated Power
Weight
Dimension
Heating
Temperature
Operating
Conditions
Storage
Conditions
Knee Massager
CM-066K
AC 100~240V 50~60Hz , DC12V/2A
24W
1.22kg / 2.69lb
220x175x145mm / 8.66x6.89x5.71in
Temperature: +5°C to 40°C ;
Humidity : 5% to 90% non-condensing;
Atmospheric Pressure : 75 kPa to 106 kPa
Temperature: -20°C to 55°C ;
Humidity : 5% to 90% non-condensing;
Atmospheric Pressure : 75 kPa to 106 kPa;
Keep dry and avoid direct sunlight.
PACKAGE INCLUDES
● 2x Knee Massage Wraps
● 1x Adapter
● 1x Portable Mesh Bag
● 1x User Manual
CONTACT US
We provide a 2-year warranty and lifelong after-sale service. If you have
any problems during using this product, please feel free to contact us.
Our professional customer service team will help you!
E-mail: [email protected]
Note: Please include the order number along with the problems you meet
in the mail, videos & pictures are welcomed for better and faster service.
0807
Low level: 40 ± 3℃ / 98.6~109.4℉
High level: 45 ± 3℃/ 107.6~118.4℉
