ICE
MAKER
OIM-812A
Quick Start Guide
CONTROL BUTTONS LED DISPLAY
FRONT
Inlet Pipe
(9.8ft. / 3m)
Ice Scoop
This ice maker may have been tilted or placed upside down during transportation.
Please set it upright for at least 2 hours before initial use to allow the refrigerant
fluid to settle.
2h
Ice Bin
Control Panel
& Display
Water Tank
MAX Fill Line
Front Door
(with Transparent Window)
Ice Full Sensor
Water Filter
Water Level
Detector
REAR
Water Inlet
(for Automatic Refill)
Power Cord
Drain Plug
Drainpipe
(for water line)
Drainpipe
(for water tank)
Preset/Current
Time Setting
Self-cleaningON/Standby Time Adjustment
Ice Bin Full
Indicator stays solid on
when ice bin is full.
Remove ice in time.
Add Water
Indicator stays solid on
when tank is lack of water.
Add water in time.
Defrosting
Indicator stays solid on
during auto defrosting
(30-45mins). The buttons
are not responsive during
defrosting. Once completed,
the ice making cycle
will start automatically.
Current Time
(AM 12:00~11:59/
PM 12:00~11:59)
Preset Time 1
(AM 12:00~11:59)
Preset Time 2
(PM 12:00~11:59)
• Press to start
making ice or turn the
unit off (standby
mode).
• stays solid on
during ice making
cycle.
• Preset time setting
is available under
both ice making and
standby mode. When
pressing or
under standby mode,
the display will turn
off if no other
operation is done in
1min.
Hold 3 Sec
• Hold for 3s to start or
cancel self-cleaning cycle.
• For each cleaning
cycle, the ice maker
auto cleans for the first
3mins ( stays on).
After 3mins, will flash
quickly for 5mins to
confirm whether to
deep clean the unit. If
yes, press to
confirm. If no opera-
tions is done in 5mins,
the cleaning cycle will
stop automatically.
• Once cleaning is
done or cancelled, the
ice maker will enter
standby mode.
• After continuous
running for 100 hours,
will flash slowly for
30s to remind you to
clean the ice maker.
Hold for 3s to start
cleaning.
Hol d 3 Sec
Hol d 3 Sec
Hol d 3 Sec
• Press to enter
Current/Preset 1/
Preset 2 time setting.
With the time flash-
ing, press to
adjust the specific
time in 5s.
• The preset time is
the time that the ice
making cycle starts.
To cancel preset time
setting, hold for
3s.
• If power is
disconnected, the
current time will be
remembered for 90
days.
• After entering
preset/
current time setting,
press to adjust the
time period, hour or
minute.
• During preset time
setting, press until ----
displayed to cancel.
• If power is discon-
nected, the preset
time will always be
remembered.
Hol d 3 Sec
