T-REX VHWWODTR8MFA 80L Mobile Waste Oil Drainer Tank User Manual

User Manual

[Revision 2.0 February 2024]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY

VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,

assembly, inclusions, specifications, description, and packaging.

TRD-8MF Mobile Waste Oil Drainer

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases, or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

•

Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

•

Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol, or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory, or

mental capabilities.

General Fuel Safety

•

Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start, or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

•

Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors, and

vents.

General Equipment Use and Care

•

The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage, or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases, or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids, or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

General Electrical Safety

•

Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

•

Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

•

The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories, or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service-related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

Oil Drainer Safety

•

The device should only be operated by a trained, qualified person.

• Never smoke or start fires near the device.

• The suitable temperature range of the waste engine oil being pumped by the device should be between 60 – 100°C. The density of the engine oil

between these temperature range is about 1.3 times more than water, so the flow velocity of oil is slower than water. Cases such as failure of the

pumping action or slow flow rate are possible in case the temperature is lower than the specified range mentioned earlier.

• Never use the device prior to understanding the information in this manual. The device can only be operated according to the prescribed

procedures in this manual.

• The output air pressure should be +10psi for the air compressor equipped with a pumping unit, and +8psi should be ensured at the nozzle of the

pumping unit after the conveying via channel. In case of lower than +8psi, cases such as failure of pumping action or slow airflow are possible

due to insufficient vacuum.

• The pumping pipe should be used according to its proper application. With a feature of straight flow channel, the large steel pipe has a capacity

of 1.8 litre/min, and 1.4 litre/min is available for small steel pipes. For plastic pipes, the flow channel can be bent. Large pipes have capacities of

1.8 litre/min, 0.8 litre/min for medium pipes, and 0. 4 litre/min for small pipes. Oil can be sucked out as long as the pumping pipe is 2-3cm longer

than the height from the dip stick of the vehicle to oil level. However, the pipe should not touch the bottom end, or the pipe may be bend upwards,

no oil can be sucked out if the pipe port is above oil level.

• Inspect the quick coupler if it’s loose after the pumping pipe had been used for an extended time. Air leakage can be detected by blocking one

end of the pipe and pumping air at the other end. Oil will not be pumped in the event of an air leakage. Remove any foreign materials and debris

or replace the pipe if needed.

• For some car models, the dip stick is placed above the engine and the pumping pipe cannot be inserted in. the pipe cannot be drawn out even

though it has been inserted in, or the pipe may be damaged. To avoid loss due to reasons above, it is optimal to use a drain oil plug instead.

• A mesh-type muffle is mounted on the cup of the pumping unit. Water or oil will be splashed out if there is water in the air compressor or

disoperation. The problem must be solved, or unexpected loss may be possible if user is affected by the splashing water.

• WARNING: Proper oil temperature should be observed while pumping. In case the oil temperature is higher than 70°C, we recommended the

drainer should be operated according to operating instructions in this manual. Wearing protective gloves and overalls is highly recommended.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases, or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases, or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing, and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp, or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Table of Contents

Safety ............................................................................................................................................................. 2

Safety Symbols ........................................................................................................................................................... 4

Parts Identification ....................................................................................................................................... 7

Assembly ....................................................................................................................................................... 8

Before Use .................................................................................................................................................................. 8

Operation ....................................................................................................................................................... 9

Maintenance ................................................................................................................................................ 10

Troubleshooting ......................................................................................................................................... 11

Specifications ............................................................................................................................................. 12

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Parts Identification

No. Name

1 Oil tank

2 Height adjustment knob

3 Air pressure gauge

4 Thread tape

5 Intake fixtures

6 Drain pipe

7 Oil collection pan

7

1

6

4

3

2

5

Spare parts available

for purchase, scan QR

code below:

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Assembly

Unpack the product and check the product is in perfect condition and that there are no visible damaged parts.

The packaging materials (Polyethylene bags, polystyrene etc.), must be disposed of in an appropriate refuse

collection container. These materials must not be left within the reach of children as they are potential sources of

danger. Assemble according to the exploded drawing, all connecting parts should be well sealed by tape or seal

glue, tighten all attachments.

Before Use

Prior to each use, conduct a visual inspection by checking for abnormal conditions, such as cracked joins and

damaged, loose, or missing parts.

Air Supply:

WARNING! To prevent explosions, use only clean, dry, regulated, compressed air to operate this tool.

Do not use oxygen, carbon dioxide, combustible gases, or any other bottled gas as a power source for

this tool.

NOTE: Air flow, and therefore tool performance, can be hindered by undersized air supply components. The

compressor air hose must be long enough to reach the work area.

Before connecting the air compressor to pressurise the Oil Drainer, run the air compressor to make sure it is in

good working order.

1. Turn ON the air compressor according to the manufacturer’s directions and allow it to build up pressure until

it cycles off.

2. Adjust the air compressor’s pressure regulator so that the air output is enough to properly power the tool, but

the output will not exceed the tool’s maximum air pressure at any time. Turn the knob clockwise to increase

the pressure and counter clockwise to decrease pressure. Adjust the pressure gradually, while checking the

air output gauge to set the pressure.

3. If the Air Compressor supplies air pressure more than 0.5 Bar, an inline air regulator must be used to

maintain air pressure at 0.5 Bar.

4. Inspect the air connections for leaks. Repair any leaks found.

5. If the compressor will not be used at this time, turn off the air supply and safely discharge any residual air

pressure to prevent accidental operation.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Operation

Pumping waste oil into the oil tank

1. Connect a carefully selected suction pipe with the pumping pipe, then insert the suction pipe into the sight

hole for the engine’s lubrication oil and shut off the switched-on pumping pipe.

2. Screw downward to open the switch connecting to the measuring glass to the oil tank and shut off the oil

drain switch to elbow and quick coupler switch on the top of the oil tank.

3. Connect the vacuum generator with the compressed air flexible pipe, and open the compressed air switch,

then pressure changes will be indicated on the vacuum gauge.

4. Open the switched-on pumping pipe when the vacuum pressure goes down to -0.5psi. Waste oil will be

drawn out from the engine and will flow into the pumping unit quickly via the pumping pipe.

Pumping waste oil into the transparent measuring glass

1. Connect a carefully selected suction pipe with the pumping pipe, then insert the suction pipe into the sight

hole for the engine’s lubrication oil and shut off the switched-on pumping pipe.

2. Screw upward to open the switch connecting measuring glass to the oil tank.

3. Connect the quick coupler at the top of the measuring glass to the compressed air flexible pipe and open the

compressed air switch. Pressure changes will be indicated on the vacuum gauge.

4. Open the switched-on pumping pipe when vacuum pressure goes down to -0.5psi. Waste oil will be drawn

out from the engine and will flow into the pumping unit quickly the via pumping pipe.

Collecting waste oil into the oil collecting pan

1. Lift the vehicle with an appropriate lifter, then push the pumping unit below the engine of the vehicle and

unscrew the oil drain plug.

2. Open the drain ball valve of the oil collecting pan, then pen the upper ball valve on the pumping drum. Waste

oil will flow into the oil drum from the oil collecting pan.

Draining waste oil into the oil tank from the measuring glass

Screw downward to open the switch connecting the measuring glass to the oil tank. Waste oil will drain into the

oil tank from the measuring glass.

Draining the waste oil from the oil tank

1. Shut off the switch between the measuring glass and the oil tank.

NOTE: It’s important to shut off the switch, otherwise the pressure can damage the measuring glass).

2. Unscrew to open the switch connecting to the elbow, elbow hangs waste oil drum.

3. Connect the quick coupler on the top of the oil tank with the compressed air flexible pipe and open the switch

for compressed air

NOTE: The switch for the compressed air switch can be shut off once the safety valve has been exhausted.

Waste oil will be drained via the elbow.

NOTE: For the following reasons, air pressure should be increased step by step: (1) Reducing air loss, (2)

Accelerating pressure is dropping, (3) Accelerating oil pumping.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Maintenance

•

Periodically check the unit and check for any leakages. Contact an authorised technician or service centre in

the event of any leakages.

•

Regularly check the tightness of the pipes’ connections.

•

Do not store waste engine oil inside the pumping drum for extended time periods to prevent the drum from

corroding.

•

Wipe the surface of the unit regularly with a clean cloth. Store it in a cool, dark place away from direct

sunlight when not in use.

•

This Oil Drainer should always be stored in a dry location on a level surface. Disconnect air supply and

empty fluid.

•

Disconnect the air supply prior to any maintenance.

•

Always disconnect this product from its air supply and release all compressed air from the system before

performing any cleaning, servicing, or maintenance.

•

Inspect the general condition of the Oil Drainer:

− Before each use, examine the general condition of the entire oil extractor system. Inspect air hoses for

damage. Check for loose screws, misalignment, binding of moving parts, improper mounting, broken

parts, and any other condition that may affect is safe operation. If abnormal noise or vibration occurs,

turn OFF the air compressor immediately and have the problem corrected before further use.

− Keep the outside of the equipment free of oil or grease. Only use a mild soap and damp cloth when

cleaning. Do not use a flammable or combustible solvent.

− Before and during each use, inspect the oil indicator tube. Do not allow the used oil level to surpass the

holding capacity.

Service and Repair:

Any Oil Drainer found damaged in any way or found to be worn or operates abnormally should be removed from

service until repaired by an authorised service agent. Owners and /or operators should be aware that repair of

this product may require specialised equipment and knowledge. Only authorised parts, labels and decals shall

be used on this equipment. Annual inspection of the Oil Drainer is recommended and can be made by an

authorised repair facility to ensure that your equipment is in optimum condition and that the equipment has the

correct decals and safety labels specified by the manufacturer.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Troubleshooting

Resolution for when vacuum gauge pressure drops:

1. Check if the input air pressure is 8-10bar, and air capacity is 200 LMIN (for pipe diameter = 6mm).

2. Check if any closed valves had been shut off properly.

3. Check if the seal between the measuring glass and the oil tank is in good condition.

Resolution for failure of the oil pumping/suction and proper pressure is dropping, as

indicated on the vacuum gauge:

1. Check if the seal between the pumping pipe and the suction pipe is tight and secure.

2. Check if the temperature of the waste oil is too low.

3. Check if the switch on the pumping pipe is not open.

4. Check if the pumping pipe is blocked or is in contact with the bottom of the oil tank.

PROBLEMS POSSIBLE CAUSES POSSIBLE SOLUTIONS

Degree of vacuum doesn’t meet

requirement.

1. Air is leaking.

2. Steel ball corroded

1. Test the degree of vacuum in the

transparent recovery chamber. If

the chamber passes test, it will

show no signs of leaking. Check

tank seal tape and seal glue.

2. Replace the steel ball and the

upper cover.

3. Check all valves are turned off.

The pointer of vacuum gauge flow

down quickly after vacuum.

Air is leaking Same as above.

Vacuum gauge has pressure drop

but cannot suck oil.

1. The oil temperature is too low.

2. The suction plug seal has worn

out.

3. The oil suction probe cover is

distorted.

4. Check the valve of oil suction

turning is not worn out.

5. Check the oil suction pipe is not

jammed or touching the bottom of

the tank.

1. Let the oil reach normal

temperature and retry.

2. Replace the seal ring of the

suction plug.

3. Change the oil suction probe

cover.

4. Turn on valve of oil suction pipe.

5. Clean oil suction pipe.

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

TRD-8MF Mobile Waste Oil Drainer

Specifications

Tank Capacity 80L

Medium Engine oil and gear oil

Air Pressure 1-2.5bar

Max air pressure 3bar / 45PSI

Height range 98-140cm

Hose 1.5m discharge hose

Wheels 3” 360°, 5” fixed

Degree of vacuum 0-0.8Pa

Note: Assembly Required

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX `

TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX TREX

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business,

or employee, or financially affect the user, business, or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

T-REX VHWWODTR8MFA 80L Mobile Waste Oil Drainer Tank Pneumatic Telescopic Extractor Probes Workshop Tool

Product's Documents

Product manual

Specifications

T-REX VHWWODTR8MFA Questions and Answers
