Axis 0878-003 FA54 Main Unit User Manual

AXISFA54MainUnit

UserManual

AXISFA54MainUnit

TableofContents

Systemoverview............................................3

Productoverview...........................................4

Aboutthesensorunits...........................................4

Howtoshortenthesensorunitcable...............................4

Setup.....................................................6

Howtoaccesstheproduct........................................6

Abouttheproduct'sbuilt-inhelp...................................7

Howtosetupcorridorformat.....................................7

Howtosetupamonitor..........................................8

Aboutoverlays..................................................8

Howtomaximizethedetailsintheimage...........................8

Howtoreducebandwidthandstorage..............................9

Aboutapplications..............................................9

Troubleshooting............................................10

Howtocheckthecurrentrmware.................................10

Howtoupgradethermware.....................................10

Technicalissues,cluesandsolutions................................11

Performanceconsiderations.......................................12

Technicalspecications......................................13

LEDIndicators..................................................13

SDcardslot....................................................13

Buttons.......................................................13

Connectors....................................................13

AXISFA54MainUnit

Systemoverview

AXISFA54MainUnit

Productoverview

StatusLED

RJ12connector(4x)

HDMI

Audioin(2x)

Audioout

I/Oconnector

Powerconnector

Networkconnector(DCinput)

Controlbutton

microSDcardslot

Aboutthesensorunits

Werecommendthatyouconnectthesensorunitstothemainunitbeforepoweringthemainunit.Ifyoudisconnectasensorunit,

andconnectadifferentsensorunit,itmaybenecessarytorestartthemainunit.

Howtoshortenthesensorunitcable

Note

•Thesensorunitcablecannotbeextendedorsplit.

•Whenroutingthesensorunitcable,theminimumbendingradiusis40mm.

Thesensorunitisdeliveredwithacable.Toshortenthecablefollowthesesteps:

1.Cutthecabletothedesiredlength.Measurefromthesensorunit.

2.Striptheplasticoutercoatingfromtheendofthecable.

3.Peelbacktheshield.

4.Flattenthecoloredwiresintheorderdescribedbelow.

Brown

White/brown

Notused

AXISFA54MainUnit

Productoverview

White/blue

Blue

5.Insertthewiresallthewayintoashielded6P6CRJ12connector.

NO NO

TICE TICE

TICE

Makesurethatthewiresstayinthecorrectorderandthatthecableshieldmakesgoodcontactwiththeconnectorshield.

6.Useacrimpingtooltofastentheconnectortothecable.

AXISFA54MainUnit

Setup

Howtoaccesstheproduct

AXISIPUtilityandAXISCameraManagementarerecommendedmethodsforndingAxisproductsonthenetworkandassigning

themIPaddressesinWindows®.Bothapplicationsarefreeandcanbedownloadedfromwww.axis.com/support

Theproductcanbeusedwiththefollowingbrowsers:

•Chrome

(recommended),Firefox

,Edge

,orOpera

withWindows

•Chrome

(recommended)orSafari

withOSX

•Chrome

orFirefox

withotheroperatingsystems.

Howtoaccesstheproductfromabrowser

1.Startawebbrowser.

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’saddresseld.

ToaccesstheproductfromaMaccomputer(OSX),gotoSafari,clickonBonjourandselecttheproductfromthe

drop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabout

howtodiscoverandassignanIPaddress,seethedocumentAssignanIPAddressandAccesstheVideoStreamonAxis

Supportwebatwww.axis.com/support

Note

ToshowBonjourasabrowserbookmark,gotoSafari>Preferences.

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe

congured.

4.Theproduct’sliveviewpageopensinyourbrowser.

Aboutsecurepasswords

Important

Whensettingtheinitialpassword,thepasswordissentincleartextoverthenetwork.Ifthereisariskofnetworksnifng,

rstsetupasecureandencryptedHTTPSconnectionbeforeresettingthepasswords.

Thedevicepasswordistheprimaryprotectionforthedataandservices.Axis’productsdonotimposeapasswordpolicyasproducts

maybeusedinvarioustypesofinstallations,buttoprotectyourdatadothefollowing:

•Don’tusethedefaultpasswordthatcomeswiththeproducts.

•Useapasswordwithatleast8characters,preferablyusingapasswordgenerator.

•Don’texposethepassword.

•Changepasswordatarecurringinterval,atleastonceayear.

Setapasswordfortherootaccount

Important

Thedefaultadministratorusernamerootispermanentandcannotbedeleted.Ifthepasswordforrootislost,theproduct

mustberesettothefactorydefaultsettings.

AXISFA54MainUnit

Setup

Thedefaultrootaccounthasfullprivilegesandshouldbereservedforadministrativetasks.Alwayscreateauseraccountwithlimited

privilegesfordailyuse.Thisreducestheexposureoftheadministrativeaccount.

1.Makesuretofollowtheinstructionsaboutsecurepasswords,seeAboutsecurepasswordsonpage6.

2.Typeapasswordandthenretypeittoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

AXISInternetDynamicDNSService

AXISInternetDynamicDNSServiceassignsahostnameforeasyaccesstotheproduct.Formoreinformation,seewww.axiscam.net

ToregistertheAxisproductwithAXISInternetDynamicDNSService,gotoSystemOptions>Network>TCP/IP>Basic.Under

Services,clicktheAXISInternetDynamicDNSServiceSettingsbutton(requiresaccesstotheInternet).Thedomainnamecurrently

registeredatAXISInternetDynamicDNSservicefortheproductcanatanytimeberemoved.

Note

AXISInternetDynamicDNSServicerequiresIPv4.

Abouttheproduct'sbuilt-inhelp

Tosetuptheproduct,youneedtoaccesstheproduct’swebpage.Inthewebpageyoucanalsonddetailedinstructionsinthe

product’sbuilt-inhelp.

Howtosetupcorridorformat

Usecorridorformattobetterutilizethefulleldofviewinalongnarrowarea.Forexampleinstaircases,hallways,roads,tunnels,

andmanyothers.

AXISFA54MainUnit

Setup

1.Turnthecamera90°.

2.GototheStreamtabontheproduct’swebpageandrotatetheview90°.

Howtosetupamonitor

TheproductcanbeconnectedtoaHDMIdisplayandtransmitvideotothatdisplaywithouttheneedforanetworkconnection.The

displaycaneitherbeusedforsurveillanceorasapublicviewe.g.inastore.

1.ConnectanexternalmonitorusingtheHDMIconnector.

2.ChangetheHDMIsettingsunderSystem>HDMI.FormoreinformationaboutHDMIsettings,pleaseseetheonlinehelp

Aboutoverlays

Note

Theoverlayfeatureisnotsupportedforthequadstream,onlyfortheindividualvideostreams.

Note

ImageandtextoverlaywillnotbedisplayedonvideostreamoverHDMI.

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,

orduringproductinstallationandconguration.

Howtomaximizethedetailsintheimage

Important

Ifyoumaximizethedetailsintheimagethebitratebecomeshigherwhichinturnmightresultinreducedframerate.

•Makesuretoselectthecapturemodewiththehighestresolution.

AXISFA54MainUnit

Setup

•Setthecompressionassmallaspossible.

•SelectMJPEGstreaming.

•TurnofftheZipstreamfunctionality.

Howtoreducebandwidthandstorage

Important

Ifyoureducethebandwidthitcanresultinlessdetailsinthepicture.

1.GotoliveviewandselectH.264.

2.GototheStreamtab.

3.Dooneormoreofthefollowing:

-TurnontheZipstreamfunctionality.

-TurnontheGOPandsetahighGOPlengthvalue.

-Increasethecompression.

-TurnonthedynamicFPS.

Aboutapplications

AXISCameraApplicationPlatform(ACAP)isanopenplatformthatenablesthirdpartiestodevelopanalyticsandotherapplications

forAxisproducts.Forinformationaboutavailableapplications,downloads,trialsandlicenses,gotowww.axis.com/applications

TondtheusermanualsforAxisapplications,gotowww.axis.com

Note

•Severalapplicationscanrunatthesametimebutsomeapplicationsmightnotbecompatiblewitheachother.Certain

combinationsofapplicationsmightrequiretoomuchprocessingpowerormemoryresourceswhenruninparallel.Verify

thattheapplicationsworktogetherbeforedeployment.

AXISFA54MainUnit

Troubleshooting

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultresetsallsettings,includingtheIPaddress,to

thefactorydefaultvalues.

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonwhilereconnectingpower.SeeProductoverview.

3.Keepthecontrolbuttonpressedfor15–30secondsuntilthestatusLEDindicatorashesamber.

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset

tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90

5.UsetheinstallationandmanagementsoftwaretoolstoassignanIPaddress,setthepassword,andaccessthevideostream.

Theinstallationandmanagementsoftwaretoolsareavailablefromthesupportpagesonwww.axis.com/support

Howtocheckthecurrentrmware

Firmwareisthesoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootinga

problemshouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticular

problem.

Tocheckthecurrentrmware:

1.Gototheproduct’swebpage.

2.Clickonthehelpmenu.

3.ClickAbout.

Howtoupgradethermware

Important

Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providedthatthefeaturesareavailablein

thenewrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

Note

Whenyouupgradetheproductwiththelatestrmware,theproductreceivesthelatestfunctionalityavailable.Alwaysread

theupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgradingthermware.Tondthelatest

rmwareandthereleasenotes,gotowww.axis.com>product>Support&Documentation.

1.Downloadthelatestrmwareletoyourcomputer,availablefreeofchargeatwww.axis.com/support/rmware

2.Logintotheproductasanadministrator.

3.GotoSettings>System>Maintenanceintheproduct’swebpageandfollowtheinstructions.

4.Theupgradetakesawhile,don'tbreakthepowertotheproduct.Whentheupgradeisnished,theproductrestarts

automatically.

AXISCameraManagementcanbeusedformultipleupgrades,seewww.axis.com/products/axis-camera-managementformore

information.

AXISFA54MainUnit

Troubleshooting

Technicalissues,cluesandsolutions

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionatwww.axis.com/support

Problemsupgradingthermware

FirmwareupgradefailureIfthermwareupgradefails,theproductreloadsthepreviousrmware.Themostcommonreason

isthatthewrongrmwarelehasbeenuploaded.Checkthatthenameofthermwarele

correspondstoyourproductandtryagain.

ProblemssettingtheIPaddress

Theproductislocatedona

differentsubnet

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe

productarelocatedondifferentsubnets,youcannotsettheIPaddress.Contactyournetwork

administratortoobtainanIPaddress.

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisproductfromthenetwork.Runthepingcommand(inaCommand/DOS

window,typepingandtheIPaddressoftheproduct):

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingtheproduct.

Theproductcannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,theproductmustberesettothefactorydefaultsettings.

See.

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshas

beenchanged,useAXISIPUtilityorAXISCameraManagementtolocatetheproductonthe

network.Identifytheproductusingitsmodelorserialnumber,orbytheDNSname(ifthename

hasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,goto

www.axis.com/support.

Certicateerrorwhenusing

IEEE802.1X

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductmustbe

synchronizedwithanNTPserver.GotoSettings>System>Dateandtime

Theproductisaccessiblelocallybutnotexternally

Routerconguration

CheckthatyourrouterallowsincomingdatatrafctotheAxisproduct.Theroutermustsupport

UPnP

Firewallprotection

ChecktheInternetrewallwithyournetworkadministrator.

Problemswithstreaming

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

AXISFA54MainUnit

Troubleshooting

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

PoorrenderingofH.264

images

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Gototheadapter’sdocumentationformore

information.

Lowerframeratethan

expected

•SeePerformanceconsiderationsonpage12.

•Reducethenumberofapplicationsrunningontheclientcomputer.

•Limitthenumberofsimultaneousviewers.

•Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

•Lowertheimageresolution.

•Intheproduct’swebpage,setacapturemodethatprioritizesframerate.Changingthe

capturemodetoprioritizeframeratemightlowerthemaximumresolutiondepending

ontheproductusedandcapturemodesavailable.

•Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)of

theAxisproduct.

Performanceconsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationsaffecttheperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thisalsoaffectstheframerate.

Thefollowingfactorsarethemostimportanttoconsider:

•Highimageresolutionorlowercompressionlevelsresultinimagescontainingmoredatawhichinturnaffectsthe

bandwidth.

•AccessbylargenumbersofMotionJPEGorunicastH.264clientsaffectsthebandwidth.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclientsaffectsbothframerateand

bandwidth.

Useidenticalstreamswhereverpossibletomaintainahighframerate.Streamprolescanbeusedtoensurethat

streamsareidentical.

•AccessingMotionJPEGandH.264videostreamssimultaneouslyaffectsbothframerateandbandwidth.

•Heavyusageofeventsettingsaffectstheproduct’sCPUloadwhichinturnaffectstheframerate.

•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.

•Heavynetworkutilizationduetopoorinfrastructureaffectsthebandwidth.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformanceandaffectsframerate.

•RunningmultipleAXISCameraApplicationPlatform(ACAP)applicationssimultaneouslymayaffecttheframerateand

thegeneralperformance.

AXISFA54MainUnit

Technicalspeciﬁcations

Tondthelatestversionofthedatasheet,gotowww.axis.com>product>Support&Documentation.

LEDIndicators

StatusLED

Indication

GreenSteadygreenfornormaloperation.

Amber

Steadyduringstartup.Flasheswhenrestoringsettings.

RedFirmwareupgradefailure.

NetworkLEDIndication

Green

Steadyforconnectiontoa1Gbit/snetwork.Flashesfornetworkactivity.

Amber

Steadyforconnectiontoa10/100Mbit/snetwork.Flashesfornetworkactivity.

UnlitNonetworkconnection.

PowerLEDIndication

Green

Normaloperation.

Amber

Flashesgreen/amberduringrmwareupgrade.

SDcardslot

NO NO

TICE TICE

TICE

•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe

SDcard.Useyourngerstoinsertandremovethecard.

•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.Disconnectpoweror

unmounttheSDcardfromtheproduct’swebpagebeforeremoval.

ThisproductsupportsmicroSD/microSDHC/microSDXCcards(notincluded).

ForSDcardrecommendations,seewww.axis.com

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.See.

•ConnectingtoanAXISVideoHostingSystemservice.Toconnect,pressandholdthebuttonforabout3secondsuntilthe

statusLEDashesgreen.

Connectors

HDMIconnector

UsetheHDMI

connectortoconnectadisplayorpublicviewmonitor.

AXISFA54MainUnit

Technicalspeciﬁcations

Networkconnector

RJ45Ethernetconnector.

Audioconnector

TheAxisproducthasthefollowingaudioconnectors:

•Audioin–3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).

•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactive

speakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

3.5mmaudioconnectors

(stereo)

1Tip2Ring

3Sleeve

AudioInput

Microphone/Linein

Ground

AudioOutput

Lineout(mono)

Ground

I/Oconnectors

UsetheI/Oconnectorwithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,eventtriggering,

andalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

Digitaloutput-ForconnectingexternaldevicessuchasrelaysandLEDs.ConnecteddevicescanbeactivatedbytheVAPIX®

ApplicationProgrammingInterfaceorintheproduct’swebpage.

Digitalinput-Forconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,door/window

contacts,andglassbreakdetectors.

6-pincongurableterminalblock

FunctionPinNotes

Specications

0VDC(-)

DCground0VDC

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=50mA

Digitalinput–Connecttopin1toactivate,orleaveoating

(unconnected)todeactivate.

0tomax30VDC Congurable

(InputorOutput)

3–6

Digitaloutput–Connectedtopin1whenactivated,oating

(unconnected)whendeactivated.Ifusedwithaninductiveload,e.g.

arelay,adiodemustbeconnectedinparallelwiththeload,for

protectionagainstvoltagetransients.

0tomax30VDC,opendrain,

100mA

AXISFA54MainUnit

Technicalspeciﬁcations

0VDC(-)

DCoutput12V,max50mA

I/Oconguredasinput

I/Oconguredasoutput

Powerconnector

DCconnector.Usethesuppliedadapter.

RJ12Connector

TheRJ12connectorisusedforconnectingthesensorunittothemainunit.Forinformationonhowtoshortenthesensorunit

cableseeHowtoshortenthesensorunitcableonpage4.

UserManualVer.M2.3

AXISFA54MainUnit

Date:June2017

PartNo.1659322

Axis 0878-003 FA54 Main Unit

Product's Documents

Axis FA54 User Manual

Specifications

Axis 0878-003 Questions and Answers
