Thermographic Cube Camera
User Manual
Legal Informaon
©2023 Hangzhou Microimage Soware Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the HIKMICRO website ( hp://
www.hikmicrotech.com ).
Please use this Manual with the guidance and assistance of professionals trained in
supporng the
Product.
Trademarks
and other HIKMICRO's trademarks and logos are the properes of
HIKMICRO in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKMICRO MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKMICRO
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKMICRO SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKMICRO WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Thermographic Cube Camera User Manual
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Thermographic Cube Camera User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Thermographic Cube Camera User Manual
iii
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
Laws and Regulaons
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
Transportaon
●
Keep the device in original or similar packaging while
transporng it.
●
Keep all wrappers
aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportaon without the original
wrapper may result in damage on the device and the company shall not take any
responsibilies.
●
DO NOT drop the product or subject it to physical shock. Keep the device away from magnec
interference.
Power Supply
●
Check the input voltage before powering on the device to avoid damage.
●
CAUTION: If the fuse of the device can be replaced, replace it only with the same model to
reduce the risk of
re or electric shock.
●
If a fuse is connected to the neutral wire and a double pole/neutral fusing occurs, parts of the
device that remain energized might represent a hazard during servicing
aer operaon of the
fuse.
●
If the device uses a 3-prong power supply plug, it must be connected to an earthed mains
socket-outlet properly.
●
Do not touch the bare components (such as the metal contacts of the inlets) and wait for at least
5 minutes, since electricity may
sll exist aer the device is powered o.
●
For the permanently connected device without a disconnect equipment, a readily accessible
disconnect equipment shall be incorporated into the electrical installaon of the connected
building.
●
For the permanently connected device without an overcurrent
protecon equipment, an
overcurrent
protecon equipment shall be incorporated into the electrical installaon of the
connected building. The specicaons of the overcurrent protecon equipment shall not exceed
that of the building.
●
For the permanently connected device without an all-pole mains switch, an all-pole mains switch
shall be incorporated into the electrical
installaon of the connected building.
●
If the device is powered by terminals connected to the power cord, ensure correct voltage and
wiring of the terminals for connecon to mains supply.
Thermographic Cube Camera User Manual
iv
●
Please purchase the charger by yourself. Input voltage should meet the Limited Power Source
(12 VDC) according to the IEC62368 standard. Please refer to technical specicaons for detailed
informaon.
●
Make sure the plug is properly connected to the power socket.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
DO NOT connect mulple devices to one power adapter, to avoid over-heang or re hazards
caused by overload.
●
DO NOT touch the bare metal contacts of the inlets
aer the circuit breaker is turned o.
Electricity sll exists.
●
+
idenes the posive terminal(s) of equipment which is used with, or generates direct current.
-
idenes the negave terminal(s) of equipment which is used with, or generates direct current.
Baery
●
Risk of explosion if the baery is replaced by an incorrect type. Dispose of used baeries
according to the instrucons.
●
The built-in
baery cannot be dismantled. Please contact the manufacture for repair if
necessary.
●
For long-term storage of the
baery, make sure it is fully charged every half year to ensure the
baery quality. Otherwise, damage may occur.
●
This equipment is not suitable for use in
locaons where children are likely to be present.
●
Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
●
DO NOT dispose of the
baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
●
DO NOT leave the
baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of ammable liquid or gas.
●
DO NOT subject the
baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
Installaon
●
This device is suitable for use above 2 m only.
●
Install the device according to the
instrucons in Quick Start Guide. To prevent injury, this device
must be securely aached to the installaon surface in accordance with the installaon
instrucons.
●
Never place the device in an unstable locaon. The device may fall, causing serious personal
injury or death.
●
The
addional force shall be equal to three mes the weight of the device but not less than 50
N. The device and its associated mounng means shall remain secure during the installaon.
Aer
the installaon, the device, including any associated mounng plate, shall not be damaged.
●
Never place the equipment in an unstable locaon. The equipment may fall, causing serious
personal injury or death.
●
This equipment is for use only with corresponding brackets. Use with other (carts, stands, or
carriers) may result in instability causing injury.
Thermographic Cube Camera User Manual
v
●
The interface varies with the models. Please refer to the product datasheet for details.
●
If the device needs to be wired by yourself, select the corresponding wire to supply power
according to the electric parameters labeled on the device. Strip o wire with a standard wire
stripper at corresponding
posion. To avoid serious consequences, the length of stripped wire
shall be appropriate, and conductors shall not be exposed.
●
Make sure that the power has been disconnected before you wire, install, or disassemble the
device.
System Security
●
You acknowledge that the nature of Internet provides for inherent security risks, and our
company shall not take any responsibilies for abnormal operaon, privacy leakage or other
damages
resulng from cyber aack, hacker aack, however, our company will provide mely
technical support if required.
●
Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Please contact us when the device might exist network security risks.
●
Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Maintenance
●
If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●
A few device components (e.g.,
electrolyc capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●
Wipe the device gently with a clean cloth and a small
quanty of ethanol, if necessary.
●
If the equipment is used in a manner not specied by the manufacturer, the protecon provided
by the device may be impaired.
●
To reduce the risk of
re, replace only with the same type and rang of fuse.
●
The serial port of the equipment is used for debugging only.
Using Environment
●
Make sure the running environment meets the requirement of the device. The operang
temperature shall be -20°C to 50°C (-4°F to 122°F), and the operang humidity shall be 95% or
less.
●
DO NOT expose the device to high
electromagnec radiaon or dusty environments.
●
DO NOT aim the lens at the sun or any other bright light.
●
The equipment shall not be exposed to dripping or splashing and that no objects
lled with
liquids, such as vases, shall be placed on the equipment.
●
No naked
ame sources, such as lighted candles, should be placed on the equipment.
●
For the device with venlaon openings, the venlaon openings should not be impeded by
covering the
venlaon openings with items, such as newspapers, table-cloths, and curtains.
Thermographic Cube Camera User Manual
vi
The openings shall never be blocked by placing the device on a bed, sofa, rug, or other similar
surface.
●
Keep a proper distance around the device for sucient venlaon.
●
This device is suitable for
mounng on concrete or other non-combusble surface only to avoid
re hazard.
●
This equipment is not suitable for use in locaons where children are likely to be present.
●
Provide a surge suppressor at the inlet opening of the equipment under special
condions such
as the mountain top, iron tower, and forest.
●
Burned ngers when handling the parts with symbol . Wait one-half hour aer switching o
before handling the parts.
Emergency
●
If smoke, odor, or noise arises from the device, immediately turn
o the power, unplug the
power cable, and contact the service center.
COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various
countries or regions, including without
limitaon, the United States, European Union, United
Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local government
authories for any necessary export
license requirements if you intend to transfer, export, re-export the thermal series products
between
dierent countries.
Thermographic Cube Camera User Manual
vii
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Brief Descripon .................................................................................................................... 1
1.2 Funcon ................................................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 2
2.1 Acvate the Device via HIKMICRO Studio .............................................................................. 2
2.2 Acvate the Device via Browser ............................................................................................. 2
2.3 Login ...................................................................................................................................... 3
2.3.1 Plug-in Installaon ........................................................................................................ 3
2.3.2 Illegal Login Lock ........................................................................................................... 4
Chapter 3 Temperature Measurement ........................................................................................ 5
3.1
Noce ..................................................................................................................................... 5
3.2 Thermometry Flow Chart ....................................................................................................... 5
3.3
Automac Thermography ...................................................................................................... 6
3.3.1 Set Thermometry Parameters ....................................................................................... 7
3.3.2 Set Normal Mode .......................................................................................................... 8
3.3.3 Set Expert Mode ......................................................................................................... 10
3.3.4 Set Thermography Rule ............................................................................................... 11
3.4 Manual Thermography ........................................................................................................ 14
3.5
Integraon ........................................................................................................................... 14
3.5.1 Pixel-to-Pixel Thermometry ........................................................................................ 14
3.5.2 Persistent
Connecon Management ........................................................................... 15
Chapter 4 Event and Alarm ....................................................................................................... 16
4.1 Set Video Tampering Alarm ................................................................................................. 16
4.2 Set Alarm Input .................................................................................................................... 17
4.3 Set
Excepon Alarm ............................................................................................................. 18
Chapter 5 Arming Schedule and Alarm Linkage ......................................................................... 19
Thermographic Cube Camera User Manual
viii
5.1 Set Arming Schedule ............................................................................................................ 19
5.2 Linkage Method Sengs ...................................................................................................... 19
5.2.1 Trigger Alarm Output .................................................................................................. 19
5.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 20
5.2.3 Send Email .................................................................................................................. 21
5.2.4
Nofy Surveillance Center .......................................................................................... 22
5.2.5 Trigger Recording ........................................................................................................ 22
5.2.6 Set Audible Alarm Output ........................................................................................... 22
Chapter 6 Live View .................................................................................................................. 23
6.1 Live View Parameters ........................................................................................................... 23
6.1.1 Window Proporon .................................................................................................... 23
6.1.2 Live View Stream Type ................................................................................................ 23
6.1.3 Enable and Disable Live View ...................................................................................... 23
6.1.4 Start Digital Zoom ....................................................................................................... 23
6.2 View Previous/Next Page ..................................................................................................... 24
6.3 Full Screen ............................................................................................................................ 24
6.4 Quick Set Live View .............................................................................................................. 24
6.5 Set Transmission Parameters ............................................................................................... 24
Chapter 7 Video and Audio ....................................................................................................... 26
7.1 Video
Sengs ...................................................................................................................... 26
7.1.1 Stream Type ................................................................................................................ 26
7.1.2 Video Type .................................................................................................................. 26
7.1.3
Resoluon ................................................................................................................... 26
7.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 27
7.1.5 Video Quality .............................................................................................................. 27
7.1.6 Frame Rate .................................................................................................................. 27
7.1.7 Video Encoding ........................................................................................................... 27
7.1.8 Smoothing ................................................................................................................... 28
Thermographic Cube Camera User Manual
ix
7.1.9 Display VCA Info .......................................................................................................... 29
7.1.10 Set ROI ...................................................................................................................... 29
7.1.11 Metadata .................................................................................................................. 30
7.2 Display
Sengs .................................................................................................................... 30
7.2.1 Image Adjustment ....................................................................................................... 30
7.2.2 Image Adjustment (Thermal Channel) ........................................................................ 30
7.2.3 Exposure Sengs ........................................................................................................ 31
7.2.4 Day/Night Switch ........................................................................................................ 31
7.2.5 Set Supplement Light .................................................................................................. 31
7.2.6 BLC .............................................................................................................................. 32
7.2.7 White Balance ............................................................................................................. 32
7.2.8 DNR ............................................................................................................................. 32
7.2.9 Gray Scale .................................................................................................................... 33
7.2.10 Set Palee ................................................................................................................. 33
7.2.11 Set Target Enhancement ........................................................................................... 34
7.2.12 Set Palee Range ...................................................................................................... 34
7.2.13 Mirror ........................................................................................................................ 34
7.2.14 Video Standard ......................................................................................................... 35
7.2.15 Digital Zoom .............................................................................................................. 35
7.2.16 Local Output .............................................................................................................. 35
7.3 OSD ...................................................................................................................................... 35
7.4 Set Privacy Mask .................................................................................................................. 36
7.5 Overlay Picture ..................................................................................................................... 36
7.6 Set Picture in Picture ............................................................................................................ 36
7.7 Set Manual DPC
(Defecve Pixel Correcon) ....................................................................... 37
7.8 VCA Rule Display
Sengs .................................................................................................... 37
Chapter 8 Video Recording and Picture Capture ........................................................................ 38
8.1 Storage
Sengs ................................................................................................................... 38
Thermographic Cube Camera User Manual
x
8.1.1 Set Memory Card ........................................................................................................ 38
8.1.2 Set NAS ....................................................................................................................... 38
8.1.3 Set FTP ........................................................................................................................ 39
8.1.4 Set Cloud Storage ........................................................................................................ 39
8.2 Video Recording ................................................................................................................... 40
8.2.1 Record
Automacally .................................................................................................. 40
8.2.2 Playback and Download Video .................................................................................... 42
8.2.3 Record Manually ......................................................................................................... 42
8.3 Capture Conguraon .......................................................................................................... 42
8.3.1 Capture Automacally ................................................................................................ 43
8.3.2 Capture Manually ........................................................................................................ 43
8.3.3 View and Download Picture ........................................................................................ 43
Chapter 9 Network
Sengs ...................................................................................................... 45
9.1 TCP/IP ................................................................................................................................... 45
9.1.1
Mulcast Discovery ..................................................................................................... 46
9.2 Port ...................................................................................................................................... 46
9.3 Port Mapping ....................................................................................................................... 47
9.3.1 Set Auto Port Mapping ................................................................................................ 47
9.3.2 Set Manual Port Mapping ........................................................................................... 48
9.3.3 Set Port Mapping on Router ....................................................................................... 48
9.4
Mulcast .............................................................................................................................. 49
9.5 SNMP ................................................................................................................................... 50
9.6 Access to Device via Domain Name ..................................................................................... 50
9.7 Access to Device via PPPoE Dial Up
Connecon .................................................................. 51
9.8 Enable Hik-Connect Service on Camera ............................................................................... 51
9.8.1 Enable Hik-Connect Service via Web Browser ............................................................ 52
9.8.2 Access Camera via Hik-Connect .................................................................................. 52
9.9 Set ISUP ................................................................................................................................ 52
Thermographic Cube Camera User Manual
xi
9.10 Set Open Network Video Interface .................................................................................... 53
9.11 Set Alarm Server ................................................................................................................ 53
9.12 Set SRTP ............................................................................................................................. 54
9.13 Set Network Service ........................................................................................................... 54
9.14 Modbus
Communicaon ................................................................................................... 54
9.14.1 Set Modbus Main Mode ........................................................................................... 55
9.14.2 Set Modbus Subordinate Mode ................................................................................ 57
9.14.3 Modbus Error Code Descripon ............................................................................... 58
Chapter 10 System and Security ................................................................................................ 60
10.1 View Device Informaon .................................................................................................... 60
10.2 Search and Manage Log ..................................................................................................... 60
10.3 Import and Export Conguraon File ................................................................................ 60
10.4 Export Diagnose
Informaon ............................................................................................. 61
10.5 Reboot ............................................................................................................................... 61
10.6 Restore and Default ........................................................................................................... 61
10.7 Upgrade ............................................................................................................................. 61
10.8 View Open Source
Soware License .................................................................................. 62
10.9 Time and Date .................................................................................................................... 62
10.9.1 Synchronize Time Manually ...................................................................................... 62
10.9.2 Set NTP Server .......................................................................................................... 62
10.9.3 Set DST ...................................................................................................................... 63
10.10 Set RS-232 ........................................................................................................................ 63
10.11 Set RS-485 ........................................................................................................................ 63
10.12 Set Same Unit .................................................................................................................. 64
10.13 Security ............................................................................................................................ 64
10.13.1
Authencaon ........................................................................................................ 64
10.13.2 Security Audit Log ................................................................................................... 64
10.13.3 Set IP Address Filter ................................................................................................ 65
Thermographic Cube Camera User Manual
xii
10.13.4 Cercate Management ......................................................................................... 65
10.13.5 Control Timeout Sengs ........................................................................................ 68
10.13.6 Set HTTPS ................................................................................................................ 68
10.13.7 Set IEEE 802.1X ....................................................................................................... 68
10.13.8 Set QoS .................................................................................................................... 68
10.14 User and Account ............................................................................................................. 69
10.14.1 Set User Account and Permission ........................................................................... 69
10.14.2 Online Users ............................................................................................................ 70
Chapter 11 Appendix ................................................................................................................ 71
11.1 Common Material Emissivity Reference ............................................................................ 71
Thermographic Cube Camera User Manual
xiii
Chapter 1 Overview
1.1 Brief Descripon
The Thermographic Cube Camera is a temperature measurement device which is equipped with a
thermal lens.
It is equipped with high-sensivity IR detector and high-performance sensor. The device is able to
measure object's temperature at a high accuracy in real me. It is applied to electric system, and
industrial automaon, etc, for re prevenon. The pre-alarm system helps you discover
unexpected events immediately and protects your property.
1.2
Funcon
This secon introduces main funcons of the device.
Temperature Measurement
Device detects the real-me temperature all the day, and display it on live view.
Fusion
Device can display fusion of thermal view and opcal view.
Audible Alarm
Device outputs audible alarm when the temperature is higher than the seng alarm threshold
value.
Image Adjustment
Device can correct the nonuniformity of the image and improve the image quality.
Thermographic Cube Camera User Manual
1
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to
acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate the Device via HIKMICRO Studio
Search and acvate the online devices via HIKMICRO Studio soware.
Before You Start
Access www.hikmicrotech.com to get HIKMICRO Studio
soware to install.
Steps
1.
Connect the device to network using the network cable.
2.
Run the soware, and create super user name and password to log in.
3.
Go to Device Management → Device → Online Device to search the online devices.
4.
Check Security Level from the device list, and select the device to be
acvated.
5.
Create and input the new password in the password eld, and conrm the password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case leers, lower case leers, numbers, and special characters) in
order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system,
reseng the password monthly or weekly can
beer protect your product.
6.
Click OK.
Security Level changes into Acve.
7.
Oponal: Change the network parameters of the device in Modify Nenfo.
Note
For detailed operaon, please refer to the user manual of HIKMICRO Studio .
2.2 Acvate the Device via Browser
You can access and acvate the device via the browser.
Thermographic Cube Camera User Manual
2
Steps
1.
Connect the device to the PC using the network cables.
2.
Change the IP address of the PC and device to the same segment.
Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3.
Input 192.168.1.64 in the browser.
4.
Set device
acvaon password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
5.
Click OK.
6.
Input the acvaon password to log in to the device.
7.
Oponal: Go to Conguraon → Network → Basic → TCP/IP to change the IP address of the
device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in
Installaon
Certain operaon systems and web browser may restrict the display and operaon of the device
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang
System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Google Chrome 57+
Mozilla Firefox 52+
Click to
download and install plug-in.
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
Thermographic Cube Camera User Manual
3
Operang System Web Browser Operaon
WebSocket or WebSockets for
normal view if plug-in
installaon is not required.
Display and
operaon of
certain
funcons are restricted.
For example, Playback and
Picture are not available. For
detailed restricted
funcon,
refer to the actual device.
Mac OS 10.13+ Mac Safari 12+ Plug-in installaon is not
required.
Go to Conguraon →
Network → Advanced
Sengs
→ Network Service to enable
WebSocket or WebSockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted
funcon, refer to the
actual device.
Note
The device only supports Windows and Mac OS system and does not support Linux system.
2.3.2 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to
Conguraon → System → Security → Security Service , and enable Enable Illegal Login
Lock. Illegal Login Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Thermographic Cube Camera User Manual
4
Chapter 3 Temperature Measurement
When you enable this funcon, the device measures the actual temperature of the scene. It alarms
when temperature exceeds the temperature threshold value.
3.1 Noce
This part introduces the noces of conguring temperature measurement funcon.
●
The target surface should be as vercal to the opcal axis as possible. It is recommended that
the angle of oblique image plane should be less than 45°.
●
The target image pixels should be more than 5 × 5.
●
Please select line thermography or area thermography for a certain area temperature
measurement. The point thermography is not recommended in case of deviaon occurred
during device movement to aect the accuracy of temperature measurement.
3.2 Thermometry Flow Chart
This part introduces the process of conguring temperature measurement.
Thermographic Cube Camera User Manual
5
Figure 3-1 Thermometry Flow Chart
3.3
Automac Thermography
Congure the temperature measurement parameters and temperature measurement rules. The
device can measure the actual temperature and output alarms when temperature exceeds the
alarm threshold value.
Thermographic Cube Camera User Manual
6
3.3.1 Set Thermometry Parameters
Congure the parameters of temperature measurement.
Steps
1.
Go to Conguraon → Local , enable Display Temperature Info. .
Display Temperature Info.
Select Yes to display temperature
informaon on live view.
Enable Rules to display the rules informaon on live view.
2.
Click Save.
3.
Go to
Conguraon → Temperature Measurement → Basic Sengs to congure parameters.
Enable Temperature Measurement
Check to enable temperature measurement funcon.
Enable Color-Temperature
Check to display Temperature-Color Ruler in live view.
Display Temperature Info. on Stream
Check to display temperature informaon on the stream.
Display Max./Min./Average Temperature
Check to display maximum/minimum/average temperature informaon on live view when
the temperature measurement rule is line or area.
Rule Name
Check to display the rule name in live view.
Posion of Thermometry Info
Select the posion of temperature informaon showed on the live view.
●
Near Target: display the informaon beside the temperature measurement rule.
●
Top
Le: display the informaon on the top le of screen.
Unit
Display temperature with Degree Celsius (°C)/Degree Fahrenheit (°F)/Degree Kelvin (K).
Temperature Range
Select the temperature measurement range.
Alarm Interval
Set the me interval of alarms.
Display Rule Info. on Alarm Picture
Select the rule informaon to be added on the alarm capture.
Alarm Mode
Thermographic Cube Camera User Manual
7
Select the desired alarm mode. In temperature measurement alarm mode, the device
outputs alarm if the detected temperature is higher than the alarm threshold. In interval
temperature measurement alarm mode, the device outputs alarm if the detected
temperature is within the set temperature range.
Normal Rule Color
If you select interval temperature measurement alarm as the alarm mode, you can set the
color for normal rules.
Opcal Transmissivity
Set the opcal transmissivity of external opcal material (e.g.: germanium window) to
improve the temperature measuring accuracy.
Calibraon Coecient
Check to enable it and set the value of calibraon coecient, which is to set the temperature
dierence between the external window or opcal material and the device cavity. The seng
range is 0 to 30.
Note
You can get the seng value from SDK soware.
External Opcs/Window Correcon
Set the temperature of the external window or opcal material (e.g.: germanium window) to
correct the measured temperature.
Version
View the version of current algorithm.
Calibraon File Version
View the version of calibraon le.
4.
Click Save.
3.3.2 Set Normal Mode
This funcon is used to measure the temperature of the whole scene and alarm.
Steps
1.
Go to Conguraon → Temperature Measurement → Basic Sengs , and check Enable
Temperature Measurement.
2.
Refer to
Set Thermometry Parameters to set the parameters.
3.
Go to
Conguraon → Temperature Measurement → Advanced Sengs , and select Normal.
4.
Congure the parameters of normal mode.
1) Congure the parameters in Temperature Measurement Alarm Mode
Thermographic Cube Camera User Manual
8
Note
Select Alarm Mode as Temperature Measurement Alarm rst in basic sengs.
Emissivity
Set the emissivity of your target. The emissivity of each object is dierent.
Distance
The distance between the target and the device.
Pre-Alarm Temperature
When the temperature of target exceeds the pre-alarm threshold, and this status keeps
more than Filtering Time, it triggers pre-alarm.
Alarm Temperature
When the temperature of target exceeds the alarm threshold, and this status keeps more
than Filtering Time, it triggers alarm.
Pre-Alarm Output and Alarm Output
Check Pre-Alarm Output and Alarm Output to link the pre-alarm or alarm with the
connected alarm device.
Temperature Sudden Change Alarm
When the temperature change exceeds the set sudden change alarm value within the set
cycle, the camera triggers an alarm.
2)
Congure the parameters in Interval Temperature Measurement Alarm Mode
Note
Select Alarm Mode as Interval Temperature Measurement Alarm rst in basic sengs.
Emissivity
Set the emissivity of your target. The emissivity of each object is dierent.
Distance
The distance between the target and the device.
Alarm Rule
Select the alarm rule for interval temperature measurement.
Alarm Type
If you select Temperature Range, the device triggers an alarm when the highest
temperature in the scene is lower than the max. temperature, or when the lowest
temperature in the scene is not lower than the min. temperature. If you select Out of
Temperature Range, the device triggers an alarm when the highest temperature in the
scene is higher than the max. temperature, or when the lowest temperature in the scene is
not higher than the min. temperature.
Name
Thermographic Cube Camera User Manual
9
Edit the interval name.
Temperature Range
The device outputs an alarm if the detected temperature is within the set temperature
range.
Alarm Rule Color
Set the rule color in alarm status.
Alarm Output
Select the alarm output channel.
5.
Refer to
Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
6.
Click Save.
The maximum and minimum temperature will be displayed on the live view.
Note
●
The funcon varies according to dierent camera models.
●
Go to Image → VCA Rules Display to adjust the fonts size and the temperature colour of
normal, alarm and pre-alarm.
3.3.3 Set Expert Mode
Select the temperature measurement rules from Point, Line, or Area and congure parameters,
the device alarms if the alarm rules are met.
Steps
1.
Go to
Conguraon → Temperature Measurement → Basic Sengs , check Enable
Temperature Measurement.
2.
Refer to
Set Thermometry Parameters to set the parameters.
3.
Go to Conguraon → Temperature Measurement → Advanced Sengs , select Expert.
4.
Select and enable the temperature measurement rules. Please refer to
Set Thermography Rule
for seng the rule.
5.
Oponal: Click Area's Temperature Comparison to set the alarm rules and the temperature.
6.
Refer to
Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
7.
Click Save.
The maximum temperature and thermography rules will be displayed on the live view.
Note
Go to Image → VCA Rules Display to adjust the font size and the temperature color of normal,
alarm and pre-alarm.
8.
Oponal: Call the preset and check if the rules are ecient.
9.
Enable the scan funcon of device, such as linear scan to monitor the scene.
Thermographic Cube Camera User Manual
10
3.3.4 Set Thermography Rule
Steps
1.
Customize the rule name.
2.
Select the rule type to Point, Line, or Area. Then draw a point, line, or area on the interface
where the
posion to be measured.
Point Please refer to Point Thermography for detailed conguraon.
Line Please refer to Line Thermography for detailed conguraon.
Area Please refer to Area Thermography for detailed conguraon.
3.
Congure the temperature measurement parameters.
Emissivity
Set the emissivity of the target. The emissivity of the surface of a material is its
eecveness
in eming energy as thermal radiaon. Dierent objects have dierent emissivity. Refer to
Common Material Emissivity Reference to search for the target emissivity..
Distance
The distance between the target and the device.
Reecve Temperature
If there is any object with high emissivity in the scene, check and set the reecve
temperature to correct the temperature. The reecve temperature should be set the same
as the temperature of the high emissivity object.
Area's Temperature Comparison
Select two areas and set the comparison rule, and set the temperature
dierence threshold.
The device alarms when the temperature dierence meets the seng value.
4.
Click
, and refer to Set Temperature Measurement in Expert Mode or Set Interval
Temperature Measurement in Expert Mode to set the Alarm Rule.
5.
Click Save.
Click Live View, and select thermal channel to view the temperature and rules
informaon on
live view.
Point Thermography
Congure the temperature measurement rule and click any point in live view to monitor the
temperature.
Steps
1.
Click in the live view and a cross cursor shows on the interface.
2.
Drag the cross cursor to desired
posion.
Go to Live View interface to view the temperature and rule of the point in thermal channel.
Thermographic Cube Camera User Manual
11
Line Thermography
Congure the temperature measurement rule and monitor the maximum temperature of the line.
Steps
1.
Click and drag the mouse to draw a line in the live view interface.
2.
Click and move the line to adjust the
posion.
3.
Click and drag the ends of the line to adjust the length.
Go to Live View interface to view the maximum temperature and rule of the line in thermal
channel.
Area Thermography
Congure the temperature measurement rule and monitor the maximum temperature of the area.
Steps
1.
Click and drag the mouse in the live view to draw the area and right click to nish drawing.
2.
Click and move the area to adjust the posion.
3.
Drag the corners of the area to adjust the size and shape.
Go to Live View interface to view the maximum temperature and rule of the area in thermal
channel.
Set Temperature Measurement in Expert Mode
In temperature measurement alarm mode, the device outputs alarm if the detected temperature is
higher than the threshold value.
Before You Start
Select Alarm Mode as Temperature Measurement Alarm rst in basic sengs.
Steps
1.
Set the parameters.
Alarm Temperature and Pre-Alarm Temperature
Set the alarm temperature and pre-alarm temperature. E.g., select Alarm Rule as Above
(Average Temperature), set the Pre-Alarm Temperature to 50 °C, and set the Alarm
Temperature to 55 °C. The device pre-alarms when its average temperature is higher than
50 °C and alarms when its average temperature is higher than 55 °C.
Filtering Time
It refers to the
duraon me aer the target temperature reaches or exceeds the pre-alarm
temperature/alarm temperature.
Tolerance Temperature
Thermographic Cube Camera User Manual
12
Set the tolerance temperature to prevent the constant temperature change to aect the
alarm. E.g., set tolerance temperature as 3°C, set alarm temperature as 55°C, and set pre-
alarm temperature as 50°C. The device sends pre-alarm when its temperature reaches 50°C
and it alarms when its temperature reaches 55°C and only when the device temperature is
lower than 52°C will the alarm be cancelled.
Area's Temperature Comparison
Select two areas and set the comparison rule, and set the temperature
dierence threshold.
The device alarms when the temperature dierence meets the seng value.
Temperature Sudden Change Alarm
Temperature Sudden Increase and OFF are selectable. When the temperature change value
in the drawn area exceeds the set alarm threshold, the device triggers an alarm.
Cycle
Set the recording period of the temperature change.
Sudden Change Alarm Value
Set the temperature change alarm threshold for the rule. When the
dierence between the
max. temperature and the min. temperature in the recording cycle exceeds the set alarm
value, the device triggers an alarm.
2.
Save the
sengs.
Set Interval Temperature Measurement in Expert Mode
In interval temperature measurement alarm mode, the device will output alarm when the
detected temperature triggers the set rule.
Before You Start
Select Alarm Mode as Interval Temperature Measurement Alarm
rst in basic sengs.
Steps
1.
Select the alarm rule for interval temperature measurement.
2.
Edit the interval name.
3.
Select an Alarm Rule and Alarm Type.
4.
Set the temperature range.
Note
If you select Temperature Range, the device triggers an alarm when the highest temperature in
the scene is lower than the max. temperature, or when the lowest temperature in the scene is
not lower than the min. temperature. If you select Out of Temperature Range, the device
triggers an alarm when the highest temperature in the scene is higher than the max.
temperature, or when the lowest temperature in the scene is not higher than the min.
temperature.
5.
Set the rule color in alarm status.
Thermographic Cube Camera User Manual
13
6.
Select the alarm output channel.
Note
The funcon varies according to dierent models.
3.4 Manual Thermography
Aer enable the manual thermography funcon of the device, you can click any posion on the
live view to show the real temperature.
Steps
1.
Go to
Conguraon → Local and select Display Temperature Info. as Yes.
2.
Go to Conguraon → Temperature Measurement → Basic Sengs .
3.
Check Enable Temperature Measurement.
4.
Click Save.
5.
Go to live view interface and select thermal channel, click
. Click any posion on the interface
to show the real temperature.
3.5
Integraon
Users can obtain the pixel-to-pixel thermometry data of the device through the persistent
connecon management. The data can be used for secondary development and integraon.
3.5.1 Pixel-to-Pixel Thermometry
Users can congure general thermometry and data upload parameters to obtain pixel-to-pixel
thermometry data, thermometry rule
informaon, and pictures. This funcon can be used for
secondary integraon.
Steps
1.
Go to Conguraon → Temperature Measurement → Integraon → Pixel-to-Pixel
Thermometry .
2.
Congure the parameters.
Emissivity
Set the emissivity of your target. The emissivity of each object is
dierent.
Distance
The distance between the target and the device.
Reecve Temperature
If there is any object reecng to the target, e.g., a mirror, enter the background temperature
value/the reecng object's temperature value. If not, skip the sengs.
Thermographic Cube Camera User Manual
14
Data Length
It stands for the data length of the detected temperature informaon of every pixel. 2 means
the temperature informaon type of every pixel is "short", and 4 means the type is "oat".
Max. Frame Rate
The max. frame rate of upload stream for further integraon. High frame rate requires more
upload bandwidth.
Refreshing Interval of Temperature Mapping Table
It stands for the frame interval of refreshing the temperature mapping table. Temperature
mapping table tells the
relaon between detected data and the temperature of a pixel For
example, if you set it as 50 (means every 50 frames), and the frame rate as 25 fps, then the
table refreshes every 2 seconds, which also means the displayed temperature data refreshes
every 2 seconds.
Upload Thermal Picture
Check this
funcon, then the thermal picture is uploaded together with the pixel-to-pixel
thermometry data.
Note
The parameters above such as Emissivity, Distance, Reecve Temperature, etc. are only applied
in integraon, which will not aect the conguraon in thermometry parameters and rules.
3.
Click Save.
3.5.2 Persistent
Connecon Management
This funcon shows the maximum connecons that the device supported for real-me pixel-to-
pixel thermometry data uploading and real-me rule thermometry data uploading, and the
currently established
connecons and their parameters. The real-me pixel-to-pixel thermometry
data is uploaded using SDK or RTSP protocol, and the real-me rule thermometry data is uploaded
using SDK or ISAPI protocol. The
real-me rule thermometry data uploaded includes the
thermometry rule and the thermometry result.
Steps
1.
Go to Conguraon → Temperature Measurement → Integraon → Persistent Connecon
Management .
2.
Click Refresh to obtain the latest connecon status of the device.
Thermographic Cube Camera User Manual
15
Chapter 4 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm. Certain events may not be supported by certain device models.
4.1 Set Video Tampering Alarm
When the
congured area is covered and cannot be monitored normally, the alarm is triggered and
the device takes certain alarm response acons.
Steps
1.
Go to
Conguraon → Event → Basic Event → Video Tampering .
2.
Select the channel number.
3.
Check Enable.
4.
Set the
Sensivity. The higher the value is, the easier to detect the area covering.
5.
Click Draw Area and drag the mouse in the live view to draw the area.
Stop Drawing Finish drawing.
Clear All Delete all the drawn areas.
Thermographic Cube Camera User Manual
16
Figure 4-1 Set Video Tampering Area
6.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
7.
Click Save.
4.2 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Make sure the external alarm device is connected. See Quick Start Guide for cable connecon.
Steps
1.
Go to
Conguraon → Event → Basic Event → Alarm Input .
2.
Check Enable Alarm Input Handling.
3.
Select Alarm Input NO. and Alarm Type from the dropdown list. Edit the Alarm Name.
Thermographic Cube Camera User Manual
17
4.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.
Click Copy to... to copy the sengs to other alarm input channels.
6.
Click Save.
4.3 Set Excepon Alarm
Excepon such as network disconnecon can trigger the device to take corresponding acon.
Steps
1.
Go to Conguraon → Event → Basic Event → Excepon .
2.
Select
Excepon Type.
HDD Full The HDD storage is full.
HDD Error Error occurs in HDD.
Network Disconnected The device is oine.
IP Address Conicted The IP address of current device is same as that of other device in
the network.
Illegal Login Incorrect user name or password is entered.
3.
Refer to Linkage Method Sengs for seng linkage method.
4.
Click Save.
Thermographic Cube Camera User Manual
18
Chapter 5 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled
me.
5.1 Set Arming Schedule
Set the valid
me of the device tasks.
Steps
1.
Click Arming Schedule.
2.
Drag the
me bar to draw desired valid me.
Note
Up to 8 periods can be congured for one day.
3.
Adjust the me period.
-
Click on the selected me period, and enter the desired value. Click Save.
-
Click on the selected
me period. Drag the both ends to adjust the me period.
-
Click on the selected me period, and drag it on the me bar.
4.
Oponal: Click Copy to... to copy the same sengs to other days.
5.
Click Save.
5.2 Linkage Method
Sengs
You can enable the linkage funcons when an event or alarm occurs.
5.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is triggered.
Steps
1.
Go to
Conguraon → Event → Basic Event → Alarm Output .
2.
Select the Alarm Type as NO(Normally Open) or NC(Normally Closed).
3.
Set alarm output parameters.
Automac
Alarm For the informaon about the conguraon, see Automac Alarm .
Manual Alarm For the informaon about the conguraon, see Manual Alarm .
4.
Click Save.
Thermographic Cube Camera User Manual
19
Automac Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Steps
1.
Set
automac alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the
me duraon that the alarm output remains aer an alarm occurs.
2.
Set the alarming schedule. For the informaon about the sengs, see Set Arming Schedule .
3.
Click Copy to… to copy the parameters to other alarm output channels.
4.
Click Save.
Manual Alarm
You can trigger an alarm output manually.
Steps
1.
Set the manual alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Edit a name for the alarm output.
Delay
Select Manual.
2.
Click Manual Alarm to enable manual alarm output.
3.
Oponal: Click Clear Alarm to disable manual alarm output.
5.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm
informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Thermographic Cube Camera User Manual
20
Refer to Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set Memory Card for memory card storage conguraon.
5.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated receivers if an alarm event is detected.
Before You Start
Set the DNS server before using the Email
funcon. Go to Conguraon → Network → Basic
Sengs → TCP/IP for DNS sengs.
Steps
1.
Go to email
sengs page: Conguraon → Network → Advanced Sengs → Email .
2.
Set email parameters.
1) Input the sender's email
informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2)
Oponal: If your email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail
Encrypon.
●
When you select SSL or TLS, and disable STARTTLS, emails are sent aer encrypted by SSL or
TLS. The SMTP port should be set as 465.
●
When you select SSL or TLS and Enable STARTTLS, emails are sent
aer encrypted by
STARTTLS, and the SMTP port should be set as 25.
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email server.
If you check the Enable STARTTLS while the protocol is not supported by your email sever,
your email is sent with no encrypon.
4) Oponal: If you want to receive nocaon with alarm pictures, check Aached Image. The
nocaon email has 3 aached alarm pictures about the event with congurable image
capturing interval.
5) Input the receiver's
informaon, including the receiver's name and address.
6) Click Test to see if the funcon is well congured.
3.
Click Save.
Thermographic Cube Camera User Manual
21
5.2.4 Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
5.2.5 Trigger Recording
The video will be recorded when the congured acon/event is detected.
Related recording sengs should be done in advance.
Go to Conguraon → Storage → Schedule Sengs → Record Schedule to complete
conguraon.
5.2.6 Set Audible Alarm Output
For device that supports audible warning as a linkage method, opons are open to congure
audible alarm parameters.
Steps
Note
The funcon is only supported by certain camera models.
1.
Go to the seng page: Conguraon → Event → Basic Event → Audible Alarm Output .
2.
Select desired alarm sound type and alarm mes.
3.
Set arming schedule for audible alarm. Refer to Set Arming Schedule
4.
Click Save.
Thermographic Cube Camera User Manual
22
Chapter 6 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
6.1 Live View Parameters
The supported funcons vary depending on the model.
Note
For mulchannel devices, select the desired channel rst before live view sengs.
6.1.1 Window Proporon
●
refers to the window size is 16 : 9.
●
refers to the window size is 4 : 3.
●
refers to original window size.
●
refers to self-adapve window size.
6.1.2 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
6.1.3 Enable and Disable Live View
This funcon is used to quickly enable or disable live view of all channels.
●
Click to start live view of all channels.
●
Click
to stop live view of all channels.
6.1.4 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
Steps
1.
Click to enable the digital zoom.
2.
In live view image, drag the mouse to select the desired region.
3.
Click in the live view image to back to the original image.
Thermographic Cube Camera User Manual
23
6.2 View Previous/Next Page
When the number of channels surpasses that of live view window division, this funcon can switch
live view among mulple channels.
Click to switch live view among mulple channels.
6.3 Full Screen
This funcon is used to view the image in full screen mode.
Click to start full screen mode and press ESC buon to exit.
6.4 Quick Set Live View
It oers a quick setup of display sengs, OSD, video/audio and VCA resource sengs on live view
page.
Steps
1.
Click
to show quick setup page.
2.
Set display sengs, OSD, video/audio and VCA resource parameters.
-
For display
sengs, see Display Sengs .
-
For OSD sengs, see OSD .
-
For audio and video
sengs, see Video and Audio .
-
For VCA sengs, see Temperature Measurement .
Note
The funcon is only supported by certain models.
6.5 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1.
Go to Conguraon → Local .
2.
Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and
beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
Thermographic Cube Camera User Manual
24
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
MULTICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
HTTP
HTTP is suitable for the
situaon that the third-party needs to get the stream from the
device.
Play Performance
Shortest Delay
The device takes the
real-me video image as the priority over the video uency.
Balanced
The device ensures both the real-me video image and the uency.
Fluent
The device takes the video
uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Auto Start Live View
●
Yes means the live view is started automacally. It requires a high performance monitoring
device and a stable network environment.
●
No means the live view should be started manually.
3.
Click OK.
Thermographic Cube Camera User Manual
25
Chapter 7 Video and Audio
This part introduces the conguraon of video and audio related parameters.
7.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
Note
For device with mulple camera channels, select a channel before other sengs.
7.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually oers the
best
resoluon and frame rate the device can do. But high resoluon and frame rate usually
mean larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually oers comparavely low resoluon opons, which consumes less bandwidth
and storage space.
7.1.2 Video Type
Select the content (video audio) that should be contained in the stream.
Video
Only video content is contained in the stream.
7.1.3
Resoluon
Select video resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
Thermographic Cube Camera User Manual
26
7.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device
automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
7.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
7.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
7.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression rao and reduces the size of video le than
MJPEG or MPEG-4 Part 2.
Thermographic Cube Camera User Manual
27
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it
oers beer video compression at the same resoluon, frame
rate and image quality.
Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
The
objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and
reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward
compability for older hardware: the same bitstream can be consumed by
basic hardware which can only decode a
low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
7.1.8 Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not
uent.
Thermographic Cube Camera User Manual
28
7.1.9 Display VCA Info
VCA informaon can be displayed by Player and Video.
Player
Player means the VCA info can be displayed by the dedicated player provided by the
manufacturer.
Video
Video means the VCA info can be displayed by any general video player.
7.1.10 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest,
thus to increase the quality of the ROI whereas the background informaon is less focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to
Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select the channel No. according to your need.
4.
Select Stream Type.
5.
Select Region No. in Fixed Region to draw ROI region.
1) Click Draw Area.
2) Click and drag the mouse on the view screen to draw the
xed region.
3) Click Stop Drawing.
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
6.
Input the Region Name and ROI Level.
7.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
8.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
Thermographic Cube Camera User Manual
29
7.1.11 Metadata
Metadata is the raw data that the device collects before algorithm processing. It is oen used for
the third party
integraon.
Go to Conguraon → Video/Audio → Metadata Sengs to enable metadata uploading of the
desired funcon for the camera channels.
7.2 Display Sengs
It oers the parameter sengs to adjust image features.
Go to Conguraon → Image → Display Sengs .
For device that supports mulple channels, display sengs of each channel is required. The
sengs for dierent channels may be dierent. This part introduces all possible parameters among
the channels.
Click Default to restore sengs.
7.2.1 Image Adjustment
By adjusng the Brightness, and Contrast, the image can be best displayed.
7.2.2 Image Adjustment (Thermal Channel)
You can opmize the image display eect of thermal channel by seng background correcon and
manual correcon.
Background Correcon
Fully cover the lens with an object of uniform temperature in front of the lens, such as foam
board or paperboard. When you click Correct, the device will take the uniform object as the
standard and
opmize the image once.
Manual Correcon
Click Correct to opmize the image once.
Note
It is a normal phenomenon that short video freezing might occur during the process of Background
Correcon and Manual Correcon.
Thermal AGC Mode
Choose the AGC mode according to dierent scenes to balance and improve the image quality.
Thermographic Cube Camera User Manual
30
●
Histogram: Choose for scene with obvious WDR and high temperature dierence, can
improve image contrast and enhance image. E.g. the scene contains both indoor and outdoor
scenes.
●
Linear: Choose for scene with low temperature dierence and the target is not obvious, can
improve image contrast and enhance image. E.g. the bird in forest.
7.2.3 Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and photo sensibility. You can adjust
image eect by seng exposure parameters.
In manual mode, you need to set Exposure Time, Gain and Slow
Shuer.
7.2.4 Day/Night Switch
Day/Night Switch funcon can provide color images in the day mode and turn on ll light in the
night mode. Switch mode is
congurable.
Day
The image is always in color.
Night
The supplement light will be enabled to ensure clear live view image at night.
Auto
The camera switches between the day mode and the night mode according to the illuminaon
automacally.
The higher the Sensivity is, the easier the mode switches. The Filtering Time
refers to the me interval between the mode switches.
Scheduled-Switch
Set the Start Time and the End Time to dene the duraon for day mode.
Note
Day/Night Switch funcon varies according to models.
7.2.5 Set Supplement Light
Steps
1.
Go to Conguraon → Maintenance → System Service .
2.
Check Enable Supplement Light.
3.
Click Save.
4.
Go to
Conguraon → Image → Display Sengs → Day/Night Switch to set supplement light
parameters.
Smart Supplement Light
Thermographic Cube Camera User Manual
31
This feature uses smart image processing technology to reduce overexposure caused by
supplement light.
Smart Supplement Light Mode
Enable or disable the smart supplement light.
Brightness Limit
Adjust the upper limit of supplement light power.
Light Brightness Control
Manual
You can drag the slider or set value to adjust the brightness.
Note
The funcon varies according to device models.
7.2.6 BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backlight compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
7.2.7 White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
Figure 7-1 White Balance
7.2.8 DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Thermographic Cube Camera User Manual
32
Set the DNR level to control the noise reducon degree. The higher level means stronger
reducon degree.
Expert
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger reducon degree.
Figure 7-2 DNR
7.2.9 Gray Scale
This secon intrduces the gray scale funcon in opcal channel.
You can choose the range of the grey scale as [0-255] or [16-235].
7.2.10 Set
Palee
You can select the palee mode to display the thermal grayscale image to colored image.
Steps
1.
Go to
Conguraon → Image → Display Sengs .
2.
Select the thermal channel.
3.
Select a palee mode in Image Enhancement according to your need.
Result
The live view displays the image with palee.
Thermographic Cube Camera User Manual
33
7.2.11 Set Target Enhancement
You can set the color of the targets in dierent temperature ranges to idenfy the target quickly.
Steps
1.
Go to Conguraon → Image → Display Sengs .
2.
Select the thermal channel.
3.
Click Image Enhancement, select
Palee as White Hot or Black Hot.
4.
Set the temperature value and color of High Temperature, Interval Temperature, or Low
Temperature targets.
Above (be colored)
When the target of high temperature needs to be colored, you can set the high temperature
color. Target above the
seng temperature will be displayed in seng color.
Between (be colored)
When the target of an interval temperature needs to be colored, you can set the interval
temperature color. Target between the minimum and the maximum temperatures will be
displayed in seng color.
Below (be colored)
When the target of low temperature needs to be colored, you can set the low temperature
color. Target below the
seng temperature will be displayed in seng color.
5.
Click Save.
7.2.12 Set
Palee Range
The live view can display the palees eect of the specied temperature range.
Select Manual or Auto from By Temp. Range drop down list.
Auto
The device detects the max. temperature and min. temperature of the scene automacally and
display image of the whole scene with palees.
Manual
In this mode, you can enter the temperature upper limit and lower limit manually. And the live
view shows the
palees eect of the desired temperature secon more detailed.
7.2.13 Mirror
When the live view image is the reverse of the actual scene, this funcon helps to display the
image normally.
Select the mirror mode as needed.
Thermographic Cube Camera User Manual
34
Note
The video recording will be shortly interrupted when the funcon is enabled.
7.2.14 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
colors that are shown and the resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are
transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country/region.
7.2.15 Digital Zoom
You can zoom in the image. The larger the zoom size is, the more blurred the image is.
7.2.16 Local Output
Enter a short descripon of your concept here (oponal).
Some camera models support CVBS, SDI, or HDMI output. Set the local output ON or OFF
according to the actual device.This is the start of your concept.
7.3 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
color, and text overlay displayed on video stream.
Go to OSD
seng page: Conguraon → Image → OSD Sengs .
Select a channel.
Set the corresponding parameters, and click Save to take
eect.
Character Set
Select character set for displayed informaon. If Korean is required to display on screen, select
EUC-KR. Otherwise, select GBK.
Displayed
Informaon
Set camera name, date, week, and their related display format.
Text Overlay
Set customized overlay text on image.
Thermographic Cube Camera User Manual
35
OSD Parameters
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
7.4 Set Privacy Mask
The funcon blocks certain areas in the live view to protect privacy. No maer how the device
moves, the blocked scene will never be seen.
Steps
1.
Go to privacy mask
seng page: Conguraon → Image → Privacy Mask .
2.
Select the channel No.
3.
Check Enable Privacy Mask.
4.
Click Draw Area. Drag the mouse in the live view to draw a closed area.
Drag the corners of the area Adjust the size of the area.
Drag the area Adjust the posion of the area.
Click Clear All Clear all the areas you set.
5.
Click Stop Drawing.
6.
Click Save.
7.5 Overlay Picture
Overlay a customized picture on live view.
Before You Start
The picture to overlay has to be in BMP format with 24-bit, and the maximum picture size is 128 ×
128 pixel.
Steps
1.
Go to picture overlay seng page: Conguraon → Image → Picture Overlay .
2.
Select a channel to overlay picture.
3.
Click Browse to select a picture, and click Upload.
The picture with a red rectangle will appear in live view
aer successfully uploading.
4.
Check Enable Picture Overlay.
5.
Drag the picture to adjust its
posion.
6.
Click Save.
7.6 Set Picture in Picture
You can overlay the images of two channels and view the image of two channels at the same me.
Thermographic Cube Camera User Manual
36
Steps
1.
Select a channel number.
2.
Select the picture in picture mode.
Normal Mode Disable picture in picture mode.
Details Overlay
Mode
Enable picture in picture mode. You can overlay the image of another
channel in the current channel.
3.
Click Save.
7.7 Set Manual DPC (Defecve Pixel Correcon)
If the amount of defecve pixels in the image is comparavely small and accurate correcon is
needed, you can correct these pixels manually.
Steps
1.
Go to
Conguraon → Image → DPC .
2.
Select the thermal channel.
3.
Select manual mode.
4.
Click the
defecve pixel on the image, then a cursor shows on the live view.
5.
Click Up, Down,
Le, Right to adjust the cursor posion to the defecve pixel posion.
6.
Click , then click to correct defecve pixel.
Note
●
If mulple defecve pixels need to be corrected, click aer locang a defecve pixel. Then
aer locang other pixels, click to correct them simultaneously.
●
This funcon is only supported by certain camera models.
7.
Oponal: Click to cancel defecve pixel correcon.
7.8 VCA Rule Display
Sengs
The VCA rule display refers to the funcon that you can customize the displayed overlay
informaon of the VCA rule, which includes the font size and line and frame color.
You can go to Conguraon → Image → VCA Rule Display to select the desired font size, and set
the line and frame color.
Thermographic Cube Camera User Manual
37
Chapter 8 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured
les.
8.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
8.1.1 Set Memory Card
If you choose to store the les to memory card, make sure you insert and format the memory card
in advance.
Before You Start
Insert the memory card to the camera. For detailed installaon, refer to Quick Start Guide of the
camera.
Steps
1.
Go to storage management
seng page: Conguraon → Storage → Storage Management →
HDD Management .
2.
Select the memory card, and click Format to start
inializing the memory card.
The Status of memory card turns to Normal from Uninialized, which means the memory card
can be used normally.
3.
Oponal: Dene the Quota of the memory card. Input the quota percentage for dierent
contents according to your need.
4.
Click Save.
8.1.2 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Before You Start
Get the IP address of the network disk
rst.
Steps
1.
Go to NAS
seng page: Conguraon → Storage → Storage Management → Net HDD .
2.
Click HDD No.. Enter the server address and le path for the disk.
Server Address
The IP address of the network disk.
File Path
Thermographic Cube Camera User Manual
38
The saving path of network disk les.
Mounng Type
Select le system protocol according to the operaon system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is
selected.
3.
Click Test to check whether the network disk is available.
4.
Click Save.
8.1.3 Set FTP
You can congure the FTP server to save images which are captured by events or a med snapshot
task.
Before You Start
Get the FTP server address
rst.
Steps
1.
Go to
Conguraon → Network → Advanced Sengs → FTP .
2.
Congure FTP sengs.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
to hide your device
informaon during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
3.
Click Upload Picture to enable uploading snapshots to the FTP server.
4.
Click Test to verify the FTP server.
5.
Click Save.
8.1.4 Set Cloud Storage
It helps to upload the captured pictures and data to the cloud. The plaorm requests picture
directly from the cloud for picture and analysis. The funcon is only supported by certain models.
Steps
Cauon
If cloud storage is enabled, the pictures are stored in the cloud video manager preferenally.
Thermographic Cube Camera User Manual
39
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
2.
Check Enable Cloud Storage.
3.
Set basic parameters.
Protocol Version The protocol version of the cloud video manager.
Server IP The IP address of the cloud video manager. It supports IPv4 address.
Serve Port The port of the cloud video manager. 6001 is the default port and you
are not recommended to edit it.
AccessKey The key to log in to the cloud video manager.
SecretKey The key to encrypt the data stored in the cloud video manager.
User Name and
Password
The user name and password of the cloud video manager.
Picture Storage
Pool ID
The ID of the picture storage region in the cloud video manager. Make
sure storage pool ID and the storage region ID are the same.
4.
Click Test to test the congured sengs.
5.
Click Save.
8.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
downloading recorded les.
8.2.1 Record
Automacally
This funcon can record video automacally during congured me periods.
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See Event and
Alarm for details.
Steps
Note
The funcon varies according to dierent models.
1.
Go to Conguraon → Storage → Schedule Sengs → Record Schedule .
2.
Select channel No.
3.
Check Enable.
4.
Select a record type.
Thermographic Cube Camera User Manual
40
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When moon detecon is enabled and trigger recording is selected as linkage method, object
movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded
aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
5.
Set schedule for the selected record type. Refer to
Set Arming Schedule for the seng
operaon.
6.
Click Advanced to set the advanced sengs.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The
me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Stream Type
Select the stream type for recording.
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
post-record may be less than the set value.
Recording Expiraon
Thermographic Cube Camera User Manual
41
The recordings are deleted when they exceed the expired me. The expired me is
congurable. Note that once the recordings are deleted, they can not be recovered.
7.
Click Save.
8.2.2 Playback and Download Video
You can search, playback and download the videos stored in the local storage or network storage.
Steps
1.
Click Playback.
2.
Select channel No.
3.
Set search condion and click Search.
The matched video
les showed on the ming bar.
4.
Click to play the video les.
-
Click to clip video les.
-
Click to play video les in full screen. Press ESC to exit full screen.
Note
Go to Conguraon → Local , click Save clips to to change the saving path of clipped video les.
5.
Click on the playback interface to download les.
1) Set search condion and click Search.
2) Select the video
les and then click Download.
Note
Go to Conguraon → Local , click Save downloaded les to to change the saving path of
downloaded video les.
8.2.3 Record Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Record File Size and saving path to for recorded les.
3.
Click Save.
4.
Click in the live view interface to start recording. Click to stop recording.
8.3 Capture
Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
path. You can view and download the snapshots.
Thermographic Cube Camera User Manual
42
8.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Capture → Capture Parameters .
2.
Select a channel to set capture parameters.
3.
Set the capture type.
Timing
Capture a picture at the
congured me interval.
Event-Triggered
Capture a picture when an event is triggered. You should congure related linkage methods in
event sengs rst. Refer to Event and Alarm for event sengs.
4.
Set the Format, Resoluon, Quality, Interval, and Capture Number.
5.
Refer to
Set Arming Schedule for conguring schedule me.
6.
Click Save.
8.3.2 Capture Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is
comparavely small, which is beer for network
transmission.
BMP
The picture is compressed with good quality.
3.
Click Save.
4.
Click
near the live view or play back window to capture a picture manually.
8.3.3 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
Steps
1.
Click Picture.
2.
Select channel No.
3.
Set search
condion and click Search.
The matched pictures showed in the
le list.
4.
Select the pictures then click Download to download them.
Thermographic Cube Camera User Manual
43
Note
Go to Conguraon → Local , click Save snapshots when playback to change the saving path of
pictures.
Thermographic Cube Camera User Manual
44
Chapter 9 Network Sengs
9.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Network → Basic Sengs → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device
automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use HIKMICRO Studio to get
the device IP address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route
Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Thermographic Cube Camera User Manual
45
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer
transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some
applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
Dynamic Domain Name
Check Enable Dynamic Domain Name and input Register Domain Name. The device is
registered under the register domain name for easier management within the local area
network.
Note
DHCP should be enabled for the dynamic domain name to take eect.
9.1.1 Mulcast Discovery
Check the Enable Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
9.2 Port
The device port can be modied when the device cannot access the network due to port conicts.
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Go to Conguraon → Network → Basic Sengs → Port for port sengs.
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
RTSP Port
It refers to the port of real-me streaming protocol.
HTTPS Port
Thermographic Cube Camera User Manual
46
It refers to the port through which the browser accesses the device with cercate. Cercate
vericaon is required to ensure the secure access.
Server Port
It refers to the port through which the client adds the device.
WebSocket Port
TCP-based full-duplex communicaon protocol port for plug-in free preview.
WebSockets Port
TCP-based full-duplex
communicaon protocol port for plug-in free preview. Cercate
vericaon is required to ensure the secure access.
Note
●
WebSocket Port and WebSockets Port are only supported by certain models.
●
For device models that support that funcon, go to Conguraon → Network → Advanced
Sengs → Network Service to enable it.
9.3 Port Mapping
By seng port mapping, you can access devices through the specied port.
Before You Start
When the ports in the device are the same as those of other devices in the network, refer to Port
to modify the device ports.
Steps
1.
Go to
Conguraon → Network → Basic Sengs → NAT .
2.
Select the port mapping mode.
Auto Port Mapping
Refer to Set Auto Port Mapping for detailed informaon.
Manual Port Mapping Refer to Set Manual Port Mapping for detailed informaon.
3.
Click Save.
9.3.1 Set Auto Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default
name.
2.
Select the port mapping mode to Auto.
3.
Click Save.
Note
UPnP™ funcon on the router should be enabled at the same me.
Thermographic Cube Camera User Manual
47
9.3.2 Set Manual Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the device, or you can use the default
name.
2.
Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3.
Click Save.
What to do next
Go to the router port mapping
sengs interface and set the port number and IP address to be the
same as those on the device. For more
informaon, refer to the router user manual.
9.3.3 Set Port Mapping on Router
The following sengs are for a certain router. The sengs vary depending on dierent models of
routers.
Steps
1.
Select the WAN
Connecon Type.
2.
Set the IP Address, Subnet Mask and other network parameters of the router.
3.
Go to Forwarding → Virtual Severs , and input the Port Number and IP Address.
4.
Click Save.
Example
When the cameras are connected to the same router, you can
congure the ports of a camera as
80, 8000, and 554 with IP address 192.168.1.23, and the ports of another camera as 81, 8001, 555,
8201 with IP 192.168.1.24.
Thermographic Cube Camera User Manual
48
Figure 9-1 Port Mapping on Router
Note
The port of the network camera cannot conict with other ports. For example, some web
management port of the router is 80. Change the camera port if it is the same as the management
port.
9.4 Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously.
Go to Conguraon → Network → Basic Sengs → Mulcast for the mulcast sengs.
For a device with more than one channel, mulcast can be set independently for each channel.
IP Address
It stands for the address of mulcast host.
Stream Type
The stream type as the mulcast source.
Video Port
The video port of the selected stream.
Thermographic Cube Camera User Manual
49
9.5 SNMP
You can set the SNMP network management protocol to get the alarm event and excepon
messages in network transmission.
Before You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device
informaon via SNMP port.
Steps
1.
Go to the sengs page: Conguraon → Network → Advanced Sengs → SNMP .
2.
Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
The SNMP version you select should be the same as that of the SNMP soware.
And you also need to use the dierent version according to the security level required. SNMP v1
is not secure and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3.
Congure the SNMP sengs.
4.
Click Save.
9.6 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
Steps
1.
Refer to
TCP/IP to set DNS parameters.
2.
Go to the DDNS sengs page: Conguraon → Network → Basic Sengs → DDNS .
3.
Check Enable DDNS and select DDNS type.
DynDNS
Dynamic DNS server is used for domain name
resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
4.
Input the domain name informaon, and click Save.
5.
Check the device ports and complete port mapping. Refer to
Port to check the device port , and
refer to Port Mapping for port mapping sengs.
6.
Access the device.
By Browsers
Enter the domain name in the browser address bar to access the device.
Thermographic Cube Camera User Manual
50
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
9.7 Access to Device via PPPoE Dial Up Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up
aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1.
Go to
Conguraon → Network → Basic Sengs → PPPoE .
2.
Check Enable PPPoE.
3.
Set the PPPoE parameters.
Dynamic IP
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name for dial-up network access.
Password
Password for dial-up network access.
Conrm
Input your dial-up password again.
4.
Click Save.
5.
Access the device.
By Browsers
Enter the WAN dynamic IP address in the browser address bar to access
the device.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
client manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer reboong the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g. DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
9.8 Enable Hik-Connect Service on Camera
Hik-Connect service should be enabled on your camera before using the service.
You can enable the service through Web browser.
Thermographic Cube Camera User Manual
51
9.8.1 Enable Hik-Connect Service via Web Browser
Follow the following steps to enable Hik-Connect Service via Web Browser.
Before You Start
You need to acvate the camera before enabling the service.
Steps
1.
Access the camera via web browser.
2.
Enter
plaorm access conguraon interface. Conguraon → Network → Advanced Sengs
→ Plaorm Access
3.
Select Hik-Connect as the Plaorm Access Mode.
4.
Check Enable.
5.
Click and read "Terms of Service" and "Privacy Policy" in pop-up window.
6.
Create a
vericaon code or change the old vericaon code for the camera.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
7.
Save the sengs.
9.8.2 Access Camera via Hik-Connect
Hik-Connect is an applicaon for mobile devices. Using the App, you can view live image, receive
alarm
nocaon and so on.
Before You Start
Connect the camera to network with network cables.
Steps
1.
Download Hik-Connect from hps://www.hik-connect.com and install it on your mobile device.
2.
Start the
applicaon and register for a Hik-Connect user account.
3.
Log in aer registraon.
4.
In the app, tap "+" on the upper-right corner and then scan the QR code of the camera to add
the camera. You can
nd the QR code on the package.
5.
Follow the prompts to set the network connecon and add the camera to your Hik-Connect
account.
For detailed
informaon, refer to the user manual of the Hik-Connect app.
9.9 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the device, transmit data, and forward alarm
informaon over public network.
Thermographic Cube Camera User Manual
52
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Plaorm Access .
2.
Select ISUP as the plaorm access mode.
3.
Select Enable.
4.
Select a protocol version and input related parameters.
5.
Click Save.
Register status turns to Online when the
funcon is correctly set.
9.10 Set Open Network Video Interface
If you need to access the device through Open Network Video Interface protocol, you can
congure the user sengs to enhance the network security.
Steps
1.
Go to
Conguraon → Network → Advanced Sengs → Integraon Protocol .
2.
Check Enable Open Network Video Interface.
3.
Click Add to
congure the Open Network Video Interface user.
Delete Delete the selected Open Network Video Interface user.
Modify Modify the selected Open Network Video Interface user.
4.
Click Save.
5.
Oponal: Repeat the steps above to add more Open Network Video Interface users.
9.11 Set Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The desnaon IP address or host name should support HTTP, HTTP, or ISUP data
transmission.
Steps
1.
Go to
Conguraon → Network → Advanced Sengs → Alarm Server .
2.
Enter Desnaon IP or Host Name, URL, and Port.
3.
Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
4.
Click Test to check if the IP or host is available.
5.
Click Save.
Thermographic Cube Camera User Manual
53
9.12 Set SRTP
The Secure Real-me Transport Protocol (SRTP) is a Real-me Transport Protocol (RTP) internet
protocol, intended to provide encrypon, message authencaon and integrity, and replay aack
protecon to the RTP data in both unicast and mulcast applicaons.
Steps
1.
Go to
Conguraon → Network → Advanced Sengs → SRTP .
2.
Select Server Cercate.
3.
Select Encrypted Algorithm.
4.
Click Save.
Note
Only certain device models support this funcon.
9.13 Set Network Service
You can control the ON/OFF status of certain protocol as desired.
Steps
Note
This funcon varies according to dierent models.
1.
Go to Conguraon → Network → Advanced Sengs → Network Service .
2.
Set network service.
WebSocket & WebSockets
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its
above version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live
view, image capture, and digital zoom
funcon cannot be used.
If the device uses HTTP, enable WebSocket.
If the device uses HTTPS, enable WebSockets.
TLS (Transport Layer Security)
The device
oers TLS1.1 and TLS1.2. Enable one or more protocol versions according to your
need.
3.
Click Save.
9.14 Modbus
Communicaon
During communicang with Modbus protocol, the Camera can funcon as the main or the
subordinate for
transming temperature measurement and temperature measurement alarm
Thermographic Cube Camera User Manual
54
data, or responding to temperature measurement parameter conguraon requests from the
main.
Please select the device mode and congure the communicaon rules and parameters according
to the demand to ensure the security of data transmission under the premise of
sasfying the data
access of the device.
Go to Conguraon → Network → Advanced Conguraon → Modbus , to congure the Modbus.
9.14.1 Set Modbus Main Mode
Congure the device as the main server that acvely uploads data to the subordinate according to
set rules, without sending requests.
Steps
1.
Select the Device Mode as Main.
Figure 9-2 Main Mode Conguraon
2.
Check to enable the funcon of transming data via Modbus.
3.
Click Add to
congure the transmission parameters between the device and the subordinate.
Subordinate Name
Customized subordinate for disnguishing between dierent subordinates.
Connecon type
Note
Only when System → System Conguraon → RS-485 is selected as main mode, the RS-485
connecon type can be supported.
TCP
When connecng the device and the subordinate via the RJ45 interface, the TCP
connecon type can be selected. Mulple connecons can be implemented through the
Thermographic Cube Camera User Manual
55
TCP type, but the IP/decoding address and port of the TCP connecon cannot be
duplicated.
RS-485
Before selecng an RS-485 connecon, make sure that the connecon between the device
and the subordinate has been established through the RS-485 connector on the body. And
only 1 RS-485 connecon can be supported.
Response Timeout(s)
When the response
meout occurs, the device displays the error code 11, then it will resend
the data, and when the response meout occurs for three consecuve mes, it will discard
the current data and send the next data.
Upload Interval(s)
The
me interval during the device uploads data to the subordinate.
4.
Click OK to view the status.
5.
Click to refresh the status.
Note
●
If the connecon status displays online, the device is connected to the subordinate normally;
if it displays oine, the device is disconnected from the subordinate, which may be caused by
the subordinate not being online. If the status shows Error, refer to the contents of the error
code
descripon below to diagnose the connecon problem.
●
Click Edit or Delete to re-edit the subordinate parameters or delete the added subordinate.
6.
Congure the contents to be uploaded to the registers of subordinate.
1) Click Add.
2) Check the contents to be uploaded.
3) Select the Rule ID to be uploaded, and the device uploads the temperature measurement
informaon corresponding to the expert temperature measurement rule.
4) Enter the register
starng address and register ending address.
Note
In a single subordinate conguraon, all register addresses cannot be duplicated or conicted.
5) Click OK.
Thermographic Cube Camera User Manual
56
Figure 9-3 Register Conguraon
7.
Click Save.
9.14.2 Set Modbus Subordinate Mode
Congure the device as the subordinate server, the main can read the temperature measurement
data of the device or write the temperature measurement parameters of the device. The form of
authorized access can improve data
communicaon security.
Steps
Note
You can set the Modbus TCP port, go to Conguraon → Network → Basic Sengs → Port .
1.
Go to Conguraon → Network → Advanced Sengs → Modbus .
2.
Select Modbus TCP mode.
Device Mode
The device is set as subordinate, which means that the device operates as a Modbus server
processing the request from the client.
Register Mode
In Read Only, the client can only read all the register data. In Read/Write, the client can read
while
congure the device using the Modbus TCP protocol.
Thermographic Cube Camera User Manual
57
3.
Check Enable Authorized IP Addresses and click Add to add IP addresses that are allowed to
access to the device.
Note
With regard to the network security risk, it is recommended to limit permission only to trusted
IP addresses.
9.14.3 Modbus Error Code Descripon
If communicaon of Modbus is abnormal, an error code will be returned. Please refer to the
following table to check the meaning of the error code to help troubleshoot Modbus
communicaon problems.
Table 9-1 Modbus Error Code Descripon
Error Code Name Descripon
01 Illegal Funcon The funcon code received in the query is not an
allowable acon for the server. This may be because the
funcon code is only applicable to newer devices, and
was not implemented in the unit selected. It could also
indicate that the server is in the wrong state to process
a request of this type, for example because it is
uncongured and is being asked to return register
values.
02 Illegal Data Address The data address received in the query is not an
allowable address for the server. More specically, the
combinaon of reference number and transfer length is
invalid. For a controller with 100 registers, the PDU
addresses the rst register as 0, and the last one as 99.
If a request is
submied with a starng register address
of 96 and a quanty of registers of 4, then this request
will successfully operate (address-wise at least) on
registers 96, 97, 98, 99. If a request is
submied with a
starng register address of 96 and a quanty of
registers of 5, then this request will fail with
Excepon
Code 0x02 “Illegal Data Address” since it aempts to
operate on registers 96, 97, 98, 99 and 100, and there is
no register with address 100.
03 Illegal Data Value A value contained in the query data eld is not an
allowable value for server. This indicates a fault in the
structure of the remainder of a complex request, such
Thermographic Cube Camera User Manual
58
Error Code Name Descripon
as that the implied length is incorrect. It specically
does NOT mean that a data item submied for storage
in a register has a value outside the expectaon of the
applicaon program, since the Modbus protocol is
unaware of the
signicance of any parcular value of
any
parcular register.
04 Server Device Failure An unrecoverable error occurred while the server was
aempng to perform the requested acon.
05 Acknowledge Specialized use in conjuncon with programming
commands. The server has accepted the request and is
processing it, but a long duraon of me will be
required to do so. This response is returned to prevent a
meout error from occurring in the client. The client
can next issue a Poll Program Complete message to
determine if processing is completed.
06 Server Device Busy Specialized use in conjuncon with programming
commands. The server is engaged in processing a long–
duraon program command. The client should
retransmit the message later when the server is free.
08 Memory Parity Error Specialized use in conjuncon with funcon codes 20
and 21 and reference type 6, to indicate that the
extended le area failed to pass a consistency check.
The server
aempted to read record le, but detected a
parity error in the memory. The client can retry the
request, but service may be required on the server
device.
10 Gateway Path Unavailable Specialized use in conjuncon with gateways, indicates
that the gateway was unable to allocate an intern
communicaon path from the input port to the output
port for processing the request. Usually means that the
gateway is miscongured or overload.
11 Gateway Target Device
Failed to Response
Specialized use in conjuncon with gateways, indicates
that no response was obtained from the target device.
Usually means that device is not present on the
network.
Thermographic Cube Camera User Manual
59
Chapter 10 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
10.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
10.2 Search and Manage Log
Log helps locate and troubleshoot problems.
Steps
1.
Go to
Conguraon → System → Maintenance → Log .
2.
Set search condions Major Type, Minor Type, Start Time, and End Time.
3.
Click Search.
The matched log
les will be displayed on the log list.
4.
Oponal: Click Export to save the log les in your computer.
10.3 Import and Export
Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Steps
1.
Export conguraon le.
1) Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2) Click Device Parameters and input the
encrypon password to export the current
conguraon le.
3) Set the saving path to save the conguraon le in local computer.
2.
Import conguraon le.
1) Access the device that needs to be congured via web browser.
2) Click Browse to select the saved conguraon le.
3) Input the encrypon password you have set when exporng the conguraon le.
4) Click Import.
Thermographic Cube Camera User Manual
60
10.4 Export Diagnose Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Diagnose
Informaon to export diagnose informaon of the device.
10.5 Reboot
You can reboot the device via browser.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Reboot.
10.6 Restore and Default
Restore and Default helps restore the device parameters to the default sengs.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Click Restore or Default according to your needs.
Restore
Reset device parameters, except user informaon, IP parameters and video format
to the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer reseng to the factory default, all the
parameters are reset to the default sengs.
10.7 Upgrade
Before You Start
You need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device reboots automacally aer upgrade.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Choose one method to upgrade.
Firmware
Locate the exact path of the upgrade le.
Thermographic Cube Camera User Manual
61
Firmware Directory Locate the directory which the upgrade le belongs to.
3.
Click Browse to select the upgrade le.
4.
Click Upgrade.
10.8 View Open Source Soware License
Go to Conguraon → System → System Sengs → About , and click View Licenses.
10.9 Time and Date
You can
congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
10.9.1 Synchronize Time Manually
Steps
1.
Go to
Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click Manual Time Sync..
4.
Choose one
me synchronizaon method.
-
Select Set Time, and manually input or select date and
me from the pop-up calendar.
-
Check Sync. with computer me to synchronize the me of the device with that of the local
PC.
5.
Click Save.
10.9.2 Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Before You Start
Set up a NTP server or obtain NTP server informaon.
Steps
1.
Go to
Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click NTP.
4.
Set Server Address, NTP Port and Interval.
Note
Server Address is NTP server IP address.
5.
Click Test to test server connecon.
Thermographic Cube Camera User Manual
62
6.
Click Save.
10.9.3 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to Conguraon → System → System Sengs → DST .
2.
Check Enable DST.
3.
Select Start Time, End Time and DST Bias.
4.
Click Save.
10.10 Set RS-232
RS-232 can be used to debug device or access peripheral device. RS-232 can realize communicaon
between the device and computer or terminal when the communicaon distance is short.
Before You Start
Connect the device to computer or terminal with RS-232 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-232 .
2.
Set RS-232 parameters to match the device with computer or terminal.
3.
Click Save.
10.11 Set RS-485
RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data
between the device and the computer or terminal when the communicaon distance is too long.
Before You Start
Connect the device and computer or termial with RS-485 cable.
Steps
1.
Go to
Conguraon → System → System Sengs → RS-485 .
2.
Set the RS-485 parameters.
Note
You should keep the parameters of the device and the computer or terminal all the same.
3.
Click Save.
Thermographic Cube Camera User Manual
63
10.12 Set Same Unit
Set the same temperature unit and distance unit. When you enable this funcon, the unit cannot
be congured separately in other seng pages
Steps
1.
Go to Conguraon → System → System Sengs → Unit Sengs .
2.
Check Use Same Unit.
3.
Set the temperature unit and distance unit.
4.
Click Save.
10.13 Security
You can improve system security by seng security parameters.
10.13.1
Authencaon
You can improve network access security by seng RTSP and WEB authencaon.
Go to Conguraon → System → Security → Authencaon to choose authencaon protocol
and method according to your needs.
RTSP Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
RTSP request is sent to the device. If you select digest/basic, it means the device supports
digest or basic
authencaon. If you select digest, the device only supports digest
authencaon.
WEB Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
WEB request is sent to the device. If you select digest/basic, it means the device supports digest
or basic
authencaon. If you select digest, the device only supports digest authencaon.
Note
Refer to the specic content of protocol to view authencaon requirements.
10.13.2 Security Audit Log
The security audit logs refer to the security operaon logs. You can search and analyze the security
log
les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you can also save the logs on a log server.
Thermographic Cube Camera User Manual
64
Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Steps
Note
This funcon is only supported by certain camera models.
1.
Go to Conguraon → System → Maintenance → Security Audit Log .
2.
Select log types, Start Time, and End Time.
3.
Click Search.
The log
les that match the search condions will be displayed on the Log List.
4.
Oponal: Click Export to save the log les to your computer.
10.13.3 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Steps
1.
Go to
Conguraon → System → Security → IP Address Filter .
2.
Check Enable IP Address Filter.
3.
Select the type of IP address
lter.
Forbidden
IP addresses in the list cannot access the device.
Allowed Only IP addresses in the list can access the device.
4.
Edit the IP address lter list.
Add
Add a new IP address to the list.
Modify Modify the selected IP address in the list.
Delete Delete the selected IP address in the list.
5.
Click Save.
10.13.4
Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an alarm if the
cercates are close to expiry date, or are expired/abnormal.
Thermographic Cube Camera User Manual
65
Note
The funcon is only supported by certain device models.
Create Self-signed Cercate
Steps
1.
Click Create Self-signed Cercate.
2.
Follow the prompt to enter Cercate ID, Country/Region, Hostname/IP, Validity and other
parameters.
Note
The cercate ID should be digits or leers and be no more than 64 characters.
3.
Click OK.
4.
Oponal: Click Export to export the cercate, or click Delete to delete the cercate to
recreate a cercate, or click Cercate Properes to view the cercate details.
Create
Cercate Request
Before You Start
Select a self-signed cercate.
Steps
1.
Click Create Cercate Request.
2.
Enter the related
informaon.
3.
Click OK.
Import
Cercate
Steps
1.
Click Import.
2.
Click Create
Cercate Request.
3.
Enter the Cercate ID.
4.
Click Browser to select the desired server/client
cercate.
5.
Select the desired import method and enter the required informaon.
6.
Click OK.
7.
Oponal: Click Export to export the cercate, or click Delete to delete the cercate to
recreate a cercate, or click Cercate Properes to view the cercate details.
Thermographic Cube Camera User Manual
66
Note
●
Up to 16 cercates are allowed.
●
If certain funcons are using the cercate, it cannot be deleted.
●
You can view the funcons that are using the cercate in the funcons column.
●
You cannot create a
cercate that has the same ID with that of the exisng cercate and
import a
cercate that has the same content with that of the exisng cercate.
Server Cercate/Client Cercate
Note
The device has default self-signed server/client cercate installed. The cercate ID is default.
Install CA Cercate
Steps
1.
Click Import.
2.
Enter the
Cercate ID.
3.
Click Browser to select the desired server/client
cercate.
4.
Select the desired import method and enter the required informaon.
5.
Click OK.
Note
Up to 16 cercates are allowed.
Enable Cercate Expiraon Alarm
Steps
1.
Check Enable Cercate Expiraon Alarm. If enabled, you will receive an email or the camera
links to the surveillance center that the
cercate will expire soon, or is expired or abnormal.
2.
Set the Remind Me Before Expiraon (day), Alarm Frequency (day) and Detecon Time (hour).
Note
●
If you set the reminding day before expiraon to 1, then the camera will remind you the day
before the expiraon day. 1 to 30 days are available. Seven days is the default reminding days.
●
If you set the reminding day before expiraon to 1, and the detecon me to 10:00, and the
cercate will expire in 9:00 the next day, the camera will remind you in 10:00 the rst day.
3.
Click Save.
Thermographic Cube Camera User Manual
67
10.13.5 Control Timeout Sengs
If this funcon is enabled, you will be logged out when you make no operaon (not including
viewing live image) to the device via web browser within the set
meout period.
Go to Conguraon → System → Security → Advanced Security to complete sengs.
10.13.6 Set HTTPS
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1.
Go to
Conguraon → Network → Advanced Sengs → HTTPS .
2.
Check Enable.
3.
Oponal: Check HTTPS Browsing to access the device only via HTTPS protocol.
4.
Select a server
cercate.
Note
●
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
5.
Click Save.
10.13.7 Set IEEE 802.1X
You can authencate user permission of the connected device by seng IEEE 802.1X.
Go to
Conguraon → Network → Advanced Sengs → 802.1X , and enable the funcon.
Select protocol and version according to router informaon. User name and password of server are
required.
Note
●
If you set the Protocol to EAP-TLS, select the Client Cercate and CA Cercate.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
10.13.8 Set QoS
QoS (Quality of Service) can help improve the network delay and network congeson by seng
the priority of data sending.
Thermographic Cube Camera User Manual
68
Note
QoS needs support from network device such as router and switch.
Steps
1.
Go to Conguraon → Network → Advanced Conguraon → QoS .
2.
Set Video/Audio DSCP, Alarm DSCP and Management DSCP.
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. You need to set the same value in router while conguraon.
3.
Click Save.
10.14 User and Account
10.14.1 Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1.
Go to Conguraon → System → User Management → User Management .
2.
Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all
operaons and can add users and operators and
assign permission.
User
Users can be assigned permission of viewing live video,
seng PTZ parameters, and changing
their own passwords, but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify
Select a user and click Modify to change the password and permission.
Thermographic Cube Camera User Manual
69
Delete Select a user and click Delete.
Note
The administrator can add up to 31 user accounts.
3.
Click OK.
10.14.2 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
Thermographic Cube Camera User Manual
70
Chapter 11 Appendix
11.1 Common Material Emissivity Reference
Material Emissivity
Human Skin 0.98
Printed Curcuit Board 0.91
Concrete 0.95
Ceramic 0.92
Rubber 0.95
Paint 0.93
Wood 0.85
Pitch 0.96
Brick 0.95
Sand 0.90
Soil 0.92
Cloth 0.98
Hard Paperboard 0.90
White Paper 0.90
Water 0.96
Thermographic Cube Camera User Manual
71
UD34871B
