Important Safe Operation Practices • Assembly • Operation • Service and Maintenance
OPERATOR’S MANUAL
WARNING
California Proposition 65
Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to State of
California to cause cancer and birth defects or other reproductive harm.
Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of
California to cause cancer and reproductive harm. Wash hands after handling.
WARNING
Read and follow all safety rules and instructions in this manual before attempting to operate this machine.
Failure to comply with these instructions may result in personal injury.
Record Product Information
Before setting up and operating your new equipment,
please locate the model plate on the equipment and
record the information in the provided area to the right.
You can locate the model plate by lifting up the seat
and looking under the seat pan. This information will be
necessary, should you seek technical support via our web
site or with your local authorized service dealer.
MODEL NUMBER
SERIAL NUMBER
Form No. 769-21130A
(September 6, 2019)
Important Safe Operation Practices ..................... 2
Assembly .................................................................. 7
Operation ................................................................10
Service and Maintenance ......................................14
Troubleshooting .................................................... 20
Parts/Warranty .............. See Separate Supplement
Table of Contents
NOTE: This Operator’s Manual covers several models. Features may vary by model. Not all features in this manual are applicable to all
models and the model depicted may differ from yours.
Front Engine Lawn Tractor
