DS-K1T681 Series Face Recognion Terminal
User Manual
Legal Informaon
©2023 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in
supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K1T681 Series Face Recognion Terminal User Manual
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data
protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the
eecveness of your
security controls.
DS-K1T681 Series Face Recognion Terminal User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-K1T681 Series Face Recognion Terminal User Manual
iii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the
instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the
separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired
operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K1T681 Series Face Recognion Terminal User Manual
iv
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
DS-K1T681 Series Face Recognion Terminal User Manual
v
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The
precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●
CAUTION: To reduce the risk of re, replace only with the same type and rang of fuse.
●
CAUTION: This equipment is for use only with Hikvision’s bracket. Use with other (carts, stands,
or carriers) may result in instability causing injury.
●
To prevent possible hearing damage, do not listen at high volume levels for long periods.
●
Please use the power adapter, which is provided by normal company. The power
consumpon
cannot be less than the required value.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or
re hazard.
●
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●
When the product is installed on wall or ceiling, the device shall be
rmly xed.
●
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●
If the product does not work properly, please contact your dealer or the nearest service center.
Never
aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauons:
●
+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
+
idenes the negave terminal(s) of equipment which is used with, or generates direct
current.
●
No naked ame sources, such as lighted candles, should be placed on the equipment.
●
The USB port of the equipment is used for
connecng to a USB ash drive only.
●
The serial port of the equipment is used for debugging only.
DS-K1T681 Series Face Recognion Terminal User Manual
vi
●
Burned ngers when handling the ngerprint sensor metal. Wait one-half hour aer switching
o before handling the parts.
●
Install the equipment according to the instrucons in this manual. To prevent injury, this
equipment must be securely
aached to the oor/wall in accordance with the installaon
instrucons.
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same
me.
●
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●
Please use a
so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Please keep all wrappers
aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to
addional costs.
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the
baery manufacturer.
●
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use
mulple authencaon modes.
●
Please make sure that the biometric recognion accuracy will be aected by the collected
pictures' quality and the light in the environment, which cannot be completely correct.
DS-K1T681 Series Face Recognion Terminal User Manual
vii
Available Models
Product Name Model
Face Recognion Terminal DS-K1T681DBX
DS-K1T681DBWX
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
ADS-26FSG-12 12024EPG Shenzhen Honor Electronic
Co.,Ltd
PG
MSA-C2000IC12.0-24P-DE MOSO Technology Co.,Ltd PDE
ADS-26FSG-12 12024EPB Shenzhen Honor Electronic
Co.,Ltd
PB
ADS-26FSG-12 12024EPCU/EPC Shenzhen Honor Electronic
Co.,Ltd
PCU
ADS-26FSG-12 12024EPI-01 Shenzhen Honor Electronic
Co.,Ltd
PI
ADS-26FSG-12 12024EPBR Shenzhen Honor Electronic
Co.,Ltd
PBR
DS-K1T681 Series Face Recognion Terminal User Manual
viii
Contents
Chapter 1 How to Customize My Manual .................................................................................... 1
Chapter 2 Overview .................................................................................................................... 4
2.1 Overview ................................................................................................................................ 4
2.2 Features ................................................................................................................................. 4
Chapter 3 Appearance ................................................................................................................ 6
Chapter 4 Installaon ................................................................................................................. 8
4.1 Installaon Environment ........................................................................................................ 8
4.2 Flush Mounng with Gang Box .............................................................................................. 8
4.3 Mount With Cylinder Bracket .............................................................................................. 11
4.3.1
Preparaon before Mounng with Bracket ................................................................ 11
4.3.2 Cylinder Bracket Mounng ......................................................................................... 13
Chapter 5 Wiring ...................................................................................................................... 19
5.1 Terminal
Descripon ............................................................................................................ 19
5.2 Wire Normal Device ............................................................................................................. 21
5.3 Wire Secure Door Control Unit ............................................................................................ 22
5.4 Wire Fire Module ................................................................................................................. 23
5.4.1 Wiring Diagram of Door Open When Powering
O .................................................... 23
5.4.2 Wiring Diagram of Door Locked When Powering
O .................................................. 24
Chapter 6 Acvaon ................................................................................................................. 25
6.1 Acvate via Device ............................................................................................................... 25
6.2
Acvate via Web Browser .................................................................................................... 27
6.3 Acvate via SADP ................................................................................................................. 27
6.4 Acvate Device via iVMS-4200 Client Soware ................................................................... 29
Chapter 7 Quick
Operaon ....................................................................................................... 30
7.1 Select Language ................................................................................................................... 30
7.2 Set Password Change Type ................................................................................................... 30
DS-K1T681 Series Face Recognion Terminal User Manual
ix
7.3 Set Network Parameters ...................................................................................................... 32
7.4 Access to Plaorm ............................................................................................................... 33
7.5 Set Administrator ................................................................................................................. 35
7.6 Status
Descripon and Control Center ................................................................................ 37
Chapter 8 Basic Operaon ........................................................................................................ 38
8.1 Login .................................................................................................................................... 38
8.1.1 Login by Administrator ................................................................................................ 38
8.1.2 Login by Acvaon Password ...................................................................................... 41
8.1.3 Forgot Password .......................................................................................................... 42
8.2 Communicaon Sengs ...................................................................................................... 44
8.2.1 Set Wired Network Parameters .................................................................................. 44
8.2.2 Set Wi-Fi Parameters ................................................................................................... 46
8.2.3 Set RS-485 Parameters ................................................................................................ 48
8.2.4 Set Wiegand Parameters ............................................................................................. 50
8.2.5 Set ISUP Parameters .................................................................................................... 50
8.2.6 Plaorm Access ........................................................................................................... 52
8.2.7 Enable Mobile Network .............................................................................................. 53
8.3 User Management ............................................................................................................... 53
8.3.1 Add Administrator ....................................................................................................... 53
8.3.2 Add Face Picture ......................................................................................................... 55
8.3.3 Add Fingerprint ........................................................................................................... 57
8.3.4 Add Card ..................................................................................................................... 58
8.3.5 View PIN code ............................................................................................................. 59
8.3.6 Set
Authencaon Mode ............................................................................................ 60
8.3.7 Search and Edit User ................................................................................................... 60
8.4 Data Management ............................................................................................................... 61
8.4.1 Delete Data ................................................................................................................. 61
8.4.2 Import Data ................................................................................................................. 61
DS-K1T681 Series Face Recognion Terminal User Manual
x
8.4.3 Export Data ................................................................................................................. 62
8.5 Identy Authencaon ........................................................................................................ 62
8.5.1
Authencate via Single Credenal .............................................................................. 63
8.5.2 Authencate via Mulple Credenal .......................................................................... 63
8.6 Basic Sengs ....................................................................................................................... 64
8.7 Password Management ....................................................................................................... 66
8.8 Set Biometric Parameters .................................................................................................... 66
8.8.1 Set Face Liveness Level ............................................................................................... 66
8.8.2 Set Face Recognion Distance .................................................................................... 67
8.8.3 Set Face Recognion Interval ...................................................................................... 67
8.8.4 Set Wide Dynamic Range ............................................................................................ 67
8.8.5 Set Face 1:1/1:N Security Level ................................................................................... 67
8.8.6 Set ECO Mode ............................................................................................................. 68
8.8.7 Set Face with Mask Detecon ..................................................................................... 68
8.8.8 Set Mulple Faces Authencaon .............................................................................. 69
8.9 Set Access Control Parameters ............................................................................................ 69
8.9.1 Set Terminal
Authencaon Mode ............................................................................. 69
8.9.2 Set Card Reader Authencaon Mode ....................................................................... 70
8.9.3 Enable NFC Card .......................................................................................................... 71
8.9.4 Enable M1 Card and M1 Car d
Encrypon .................................................................. 72
8.9.5 Set Door Contact Parameters ...................................................................................... 74
8.9.6 Set Door Open Duraon .............................................................................................. 75
8.9.7 Set
Authencaon Interval ......................................................................................... 76
8.10 Time and Aendance Status Sengs ................................................................................ 77
8.10.1 Disable Aendance Mode via Device ....................................................................... 78
8.10.2 Set Manual
Aendance via Device ........................................................................... 79
8.10.3 Set Auto Aendance via Device ................................................................................ 81
8.10.4 Set Manual and Auto
Aendance via Device ............................................................ 83
DS-K1T681 Series Face Recognion Terminal User Manual
xi
8.11 Preference Sengs ............................................................................................................ 85
8.11.1 Set Interface Style ..................................................................................................... 85
8.11.2 Set Theme Mode ....................................................................................................... 86
8.11.3 Set
Authencaon Page Shortcut ............................................................................. 88
8.11.4 Set Control Center Displayed Items .......................................................................... 90
8.12 System Maintenance .......................................................................................................... 90
8.12.1 View System Informaon .......................................................................................... 90
8.12.2 View Device Capacity ................................................................................................ 90
8.12.3 Upgrade .................................................................................................................... 91
8.12.4 View User Manual ..................................................................................................... 91
8.12.5 Restore Parameters ................................................................................................... 91
8.12.6 Reboot ...................................................................................................................... 91
8.12.7 Advanced
Sengs ..................................................................................................... 92
8.13 Video Intercom .................................................................................................................. 92
8.13.1 Call Client
Soware from Device ............................................................................... 93
8.13.2 Call Center from Device ............................................................................................ 93
8.13.3 Call Device from Client
Soware ............................................................................... 94
8.13.4 Call Room from Device .............................................................................................. 94
8.13.5 Call Mobile Client from Device .................................................................................. 95
8.13.6 Doorbell Call .............................................................................................................. 95
Chapter 9 Quick
Operaon via Web Browser ............................................................................ 96
9.1 Select Language ................................................................................................................... 96
9.2 Time
Sengs ........................................................................................................................ 96
9.3 Privacy Sengs .................................................................................................................... 96
9.4 Administrator Sengs ......................................................................................................... 97
9.5 No. and System Network ..................................................................................................... 98
Chapter 10
Operaon via Web Browser .................................................................................... 99
10.1 Login .................................................................................................................................. 99
DS-K1T681 Series Face Recognion Terminal User Manual
xii
10.2 Forgot Password ................................................................................................................. 99
10.3 Live View ............................................................................................................................ 99
10.4 Person Management ........................................................................................................ 101
10.4.1 Add Person Basic
Informaon ................................................................................. 101
10.4.2 Set Permission Duraon .......................................................................................... 103
10.4.3 Add Face Picture ..................................................................................................... 105
10.4.4 Add Card ................................................................................................................. 107
10.4.5 Add Fingerprint ....................................................................................................... 109
10.4.6 Add Room No. ......................................................................................................... 111
10.4.7 Set Authencaon Type .......................................................................................... 113
10.5 Search Event .................................................................................................................... 115
10.6 Device Management ........................................................................................................ 115
10.7
Conguraon ................................................................................................................... 116
10.7.1 View Device
Informaon ......................................................................................... 116
10.7.2 Set Time .................................................................................................................. 116
10.7.3 Change Administrator's Password ........................................................................... 117
10.7.4 Account Security
Sengs ........................................................................................ 117
10.7.5 View Device Arming/Disarming Informaon .......................................................... 117
10.7.6 Network Sengs ..................................................................................................... 117
10.7.7 Set Video and Audio Parameters ............................................................................ 122
10.7.8 Set Image Parameters ............................................................................................. 123
10.7.9 Alarm
Sengs ......................................................................................................... 124
10.7.10 Access Control
Sengs ......................................................................................... 125
10.7.11 Video Intercom Sengs ........................................................................................ 139
10.7.12 Card Sengs ......................................................................................................... 142
10.7.13
Plaorm Aendance ............................................................................................. 143
10.7.14 Set Privacy Parameters .......................................................................................... 145
10.7.15 Set Biometric Parameters ..................................................................................... 146
DS-K1T681 Series Face Recognion Terminal User Manual
xiii
10.7.16 Set Open Plaorm ................................................................................................. 151
10.7.17 Preference Sengs ............................................................................................... 153
10.7.18 Upgrade and Maintenance ................................................................................... 155
10.7.19 Device Debugging ................................................................................................. 156
10.7.20 Log Query .............................................................................................................. 157
10.7.21 Security Mode
Sengs ......................................................................................... 157
10.7.22 Cercate Management ....................................................................................... 157
Chapter 11 Other Plaorms to Congure ................................................................................ 159
Appendix A. Tips for Scanning Fingerprint ............................................................................... 160
Appendix B. Tips When Collecng/Comparing Face Picture .................................................... 162
Appendix C. Tips for Installaon Environment ........................................................................ 164
Appendix D. Dimension .......................................................................................................... 165
Appendix E.
Funcon Dierences ........................................................................................... 166
DS-K1T681 Series Face Recognion Terminal User Manual
xiv
Chapter 1 How to Customize My Manual
This document provides the content customizaon funcon to help you quickly get the informaon
that you need. On the Customize User Manual pane, you can select or check opon(s) to lter
contents and customize your own manual by dierent categories, including the product model,
funcon, applicaon, and scene.
Note
●
This funcon is only available when you view the online documentaon. If you have downloaded
the PDF documentaon for viewing, please ignore this chapter.
●
Opons and contents in videos and pictures below are for examples only, please subject to the
actual
informaon.
Customize Manual by Product Model
Figure 1-1 Customize User Manual Pane (by Product Model)
On the Customize User Manual pane, click the input eld of the Model category to unfold the
drop-down list, select a model from the list, and then click Filter. The result is shown below.
DS-K1T681 Series Face Recognion Terminal User Manual
1
Figure 1-2 Result of Customizing Manual by Product Model
You can view the video below to get more details about the customizaon process.
Customize Manual by
Applicaon
Note
Due to the similarity among processes of customizing by Funcon, Applicaon, and Scene
categories, here we only take the process of customizing by applicaon as an example.
Figure 1-3 Customize User Manual Pane (by Applicaon)
DS-K1T681 Series Face Recognion Terminal User Manual
2
On the Customize User Manual pane, check one or mulple opons under the Applicaon
category, and then click Filter. The result is shown below.
Figure 1-4 Result of Customizing Manual by Applicaon
You can view the video below to get more details about the customizaon process.
DS-K1T681 Series Face Recognion Terminal User Manual
3
Chapter 2 Overview
2.1 Overview
Face recognion terminal is a kind of access control device for face recognion, which is mainly
applied in security access control systems, such as logisc centers, airports, university campuses,
alarm centrals, dwellings, etc.
2.2 Features
●
8-inch touch screen with bezel-less design
●
Presents card on the screen to authencate card permission.
●
2 MP wide-angle dual-lens
●
Face
an-spoong
●
Face recognion distance: 0.3 m to 3 m
●
Deep learning algorithm
●
Up to 100,000 face capacity, 500,000 card capacity, and 500,000 event capacity
●
Face
recognion duraon ＜ 0.2 s/User; face recognion accuracy rate ≥ 99%
●
Capture linkage and captured pictures storage
●
Transmits card and user data from or to the client
soware via TCP/IP protocol and saves the
data on the client
soware
●
Imports pictures from the USB ash drive to the device or export pictures, events, from the
device to the USB
ash drive
●
Stand-alone operaon
●
Supports Wi-Fi in the 2.4G frequency band.
Note
Only devices that support Wi-Fi support this funcon.
●
Manage, search and set device data
aer logging in the device locally
●
Connects to one external card reader via RS-485 protocol
●
Connects to secure door control unit via RS-485 protocol to avoid the door opening when the
terminal is destroyed
●
Connects to external access controller or Wiegand card reader via Wiegand protocol
●
Two-way audio with indoor
staon and main staon
●
Supports 6 aendance status, including check in, check out, break in, break out, overme in,
overme out
●
Conguraon via the web client
●
Remotely opens door and starts live view via Hik-Connect
●
Supports ISAPI and ISUP 5.0 protocol
DS-K1T681 Series Face Recognion Terminal User Manual
4
●
Supports mulple languages: English, Thai, Portuguese, Russian, Spanish, Arabic, Japanese,
Ukrainian, and Indonesian
●
Self-dened voice prompt of authencaon result
DS-K1T681 Series Face Recognion Terminal User Manual
5
Chapter 3 Appearance
Refer to the following contents for detailed informaon of the face recognion terminal:
Figure 3-1 Face Recognion Terminal Diagram
Table 3-1
Descripon of Face Recognion Terminal
No. Descripon
1 USB Type C Interface
2 IR Light
3 IR Light
4 Camera
5 Touch Screen
6 Card Presenng Area
7 USB Interface
8 Wiring Terminals
DS-K1T681 Series Face Recognion Terminal User Manual
6
No. Descripon
9 Debugging Port
10 SD Card Slot (Reserved)
11 SIM Card Slot (Reserved)
12 TAMPER
13 Network Interface
DS-K1T681 Series Face Recognion Terminal User Manual
7
Chapter 4 Installaon
4.1 Installaon Environment
●
Avoid backlight, direct sunlight, and indirect sunlight.
●
For
beer recognion, there should be light source in or near the installaon environment.
●
If you have to install the device outdoors, you should install a
protecve shield (oponal) for the
device.
Note
For details about installaon environment, see Tips for Installaon Environment.
4.2 Flush Mounng with Gang Box
Steps
Note
The gang box is oponal. You should purchase it separately.
1.
Make sure the gang box is on the wall.
DS-K1T681 Series Face Recognion Terminal User Manual
8
Figure 4-1 The Gang Box on the Wall
2.
Secure the mounng plate on the gang box with the four supplied screws (SC-KA4X22). Remove
the back cover and route the cable through the cable hole, wire the cables and insert the cables
in the gang box.
Note
Apply Silicone sealant among the cable wiring area to keep the raindrop from entering.
DS-K1T681 Series Face Recognion Terminal User Manual
9
Figure 4-2 Secure the Mounng Plate and Wire the Cable
3.
Align the device with the mounng plate, and secure the device on the mounng plate with 2
supplied screw (SC-KM3X8T10-SUS-NL).
DS-K1T681 Series Face Recognion Terminal User Manual
10
Figure 4-3 Align the Device
4.3 Mount With Cylinder Bracket
4.3.1 Preparaon before Mounng with Bracket
Make sure you have drilled holes on the turnsle. If not, follow the steps below to drill holes.
Steps
1.
Use 4 screws (M3 or M4), secured by ange nuts, to install the reinforcing board on the inner
surface of the turnsle.
Note
The distance between the turnsle and the edge should be no longer than 10 mm.
2.
Drill holes on the turnsle's inner surface according to the gure displayed below. And install
water-proof nut.
Note
Solder aer pressing rivets to avoid water from entering.
DS-K1T681 Series Face Recognion Terminal User Manual
11
Figure 4-4 Drill Holes on Turnsle
3.
Solder the other four holes, polish the surface, and implement wire drawing.
4.
Solder circular tubes on the
turnsle’s inner surface to avoid water from entering.
DS-K1T681 Series Face Recognion Terminal User Manual
12
Figure 4-5 Solder Tubes
4.3.2 Cylinder Bracket
Mounng
Steps
1.
Take o the 3 screws shown in the following gure.
DS-K1T681 Series Face Recognion Terminal User Manual
13
Figure 4-6 Adjust Bracket Angle
2.
Rotate the xed part by 180°, and install the 3 screws back.
DS-K1T681 Series Face Recognion Terminal User Manual
14
Figure 4-7 Adjust Bracket Angle
3.
Pass face recognion terminal cables through the cable hole, and insert them into the inner
turnsle.Pass the bracket boom through the turnsle and x it into the turnsle with self-
contained nut. Adjust the bracket to the suitable angle, and x the nut ghtly by the wrench.
DS-K1T681 Series Face Recognion Terminal User Manual
15
Figure 4-8 Fix the Bracket
4.
Fix the mounng plate into the bracket by 4 SC-K1M4X6-SUS screws.
DS-K1T681 Series Face Recognion Terminal User Manual
16
Figure 4-9 Fix the Mounng Plate
5.
Fix the face recognion terminal into the mounng plate with 1 SC-KM3X8-T10-SUS-NL screws.
DS-K1T681 Series Face Recognion Terminal User Manual
17
Figure 4-10 Fix the Device
DS-K1T681 Series Face Recognion Terminal User Manual
18
Chapter 5 Wiring
The device supports connecng to the RS-485 terminal, the door lock, the exit buon, the alarm
output/input devices, the Wiegand card reader, the access controller, and the power supply. You
can wire the peripherals according to the
descripons below.
If connect the Wiegand card reader with the access controller, the face recognion terminal can
transmit the
authencaon informaon to the access controller and the access controller can
judge whether to open the door or not.
Note
●
If the cable size is 19 AWG, you should use a 12 V or 24 V switched-mode power supply. If you
use a 12 V switched-mode power supply, the distance between the power supply and the device
should be no more than 5 m. If you use a 24 V switched-mode power supply, the distance
between the power supply and the device should be no more than 40 m.
If the cable size is 18 AWG, you should use a 12 V switched-mode power supply. And the
distance between the power supply and the device should be no more than 10 m.
●
If the cable size is 16 AWG, you should use a 12 V switched-mode power supply. And the
distance between the power supply and the device should be no more than 15 m.
5.1 Terminal Descripon
The terminals contains power input, alarm input, alarm output, RS-485, Wiegand output, and door
lock.
The terminal's diagram is as follows:
DS-K1T681 Series Face Recognion Terminal User Manual
19
Figure 5-1 Terminal Diagram
The descripons of the terminals are as follows:
Table 5-1 Terminal
Descripons
Group No. Funcon Color Name Descripon
Group A A1 Power Input Red +12 ~ 24 VDC,
3~1.5 A
Power Supply
A2 Black GND Ground
DS-K1T681 Series Face Recognion Terminal User Manual
20
Group No. Funcon Color Name Descripon
Group B B1 Alarm Input Yellow/Blue IN1 Alarm Input 1
B2 Black GND Ground
B3 Yellow/Orange IN2 Alarm Input 2
B4 Alarm Output Yellow/Purple NC Alarm Output
Wiring
B5 Yellow/Brown COM
B6 Yellow/Red NO
Group C C1 RS-485 Yellow 485+ RS-485 Wiring
C2 Blue 485-
C3 Black GND Ground
C4 Wiegand Green W0 Wiegand
Wiring 0
C5 White W1 Wiegand
Wiring 1
C6 Black GND Ground
Group D D1 Door Lock White/Purple NC Lock Wiring
(NC)
D2 White/Yellow COM Common
D3 White/Red NO Lock Wiring
(NO)
D4 Yellow/Green SENSOR Door Contact
D5 Black GND Ground
D6 Yellow/Gray BTN Exit Door
Wiring
5.2 Wire Normal Device
You can connect the terminal with normal peripherals.
DS-K1T681 Series Face Recognion Terminal User Manual
21
Figure 5-2 Device Wiring
Note
●
You should set the face recognion terminal's Wiegand direcon as Input to connect to a
Wiegand card reader. If connects to an access controller, you should set the Wiegand direcon as
Output to transmit authencaon informaon to the access controller.
●
For details about Wiegand
direcon sengs, see Set Wiegand Parameters .
●
Do not wire the device to the electric supply directly.
5.3 Wire Secure Door Control Unit
You can connect the terminal with the secure door control unit.
The wiring diagram is as follows.
DS-K1T681 Series Face Recognion Terminal User Manual
22
Figure 5-3 Secure Door Control Unit Wiring
Note
●
The secure door control unit should connect to an external power supply separately. The
suggested external power supply is 12V, 0.5A.
●
For scenarios with high safety requirement, use the secure door control unit wiring rst.
●
You can ask the technical support to purchase for the secure door control unit separately.
●
The picture here are parts of the wiring. For details, see the secure door control unit’s user
manual.
5.4 Wire Fire Module
5.4.1 Wiring Diagram of Door Open When Powering O
Lock Type: Anode Lock, Magnec Lock, and Electric Bolt (NO)
Security Type: Door Open When Powering O
Scenario: Installed in Fire Engine Access
Note
The re system (NO and COM, normally open when powering o) is connected with the lock and
the power supply in series. When an re alarm is triggered, the door remains open. In normal
mes, NO and COM are closed.
DS-K1T681 Series Face Recognion Terminal User Manual
23
5.4.2 Wiring Diagram of Door Locked When Powering O
Lock Type: Cathode Lock, Electric Lock, and Electric Bolt (NC)
Security Type: Door Locked When Powering
O
Scenario: Installed in Entrance/Exit with Fire Linkage
Note
●
The Uninterpretable Power Supply (UPS) is required.
●
The re system (NC and COM, normally closed when powering o) is connected with the lock
and the power supply in series. When an re alarm is triggered, the door remains open. In
normal
mes, NC and COM are open.
DS-K1T681 Series Face Recognion Terminal User Manual
24
Chapter 6 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
●
The default IP address: 192.0.0.64
●
The default port No.: 8000
●
The default user name: admin
6.1
Acvate via Device
If the device is not acvated, you can acvate the device aer it is powered on.
On the Acvate Device page, create a password and conrm the password. Tap Acvate and the
device will acvated.
DS-K1T681 Series Face Recognion Terminal User Manual
25
Figure 6-1 Acvaon Page
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change your
password regularly, especially in the high security system, changing the password monthly or
weekly can
beer protect your product.
DS-K1T681 Series Face Recognion Terminal User Manual
26
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
Aer
acvaon, you should select language, set password change type, set applicaon mode, set
network, set plaorm parameters, set privacy parameters, and set administrator.
6.2 Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press
Enter.
Note
Make sure the device IP address and the computer's should be in the same IP segment.
2.
Create a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
3.
Click Acvate.
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client
soware.
6.3
Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
●
The device and the PC that runs the SADP tool should be within the same subnet.
DS-K1T681 Series Face Recognion Terminal User Manual
27
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP
soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
4.
Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to
acvate your IP address modicaon.
DS-K1T681 Series Face Recognion Terminal User Manual
28
6.4 Acvate Device via iVMS-4200 Client Soware
For some devices, you are required to create the password to acvate them before they can be
added to the iVMS-4200 soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and select an
inacve device.
5.
Click
Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the password.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
7.
Click OK to acvate the device.
DS-K1T681 Series Face Recognion Terminal User Manual
29
Chapter 7 Quick Operaon
7.1 Select Language
Aer acvaon, you should select a language.
Steps
1.
Select a language according to the actual needs.
2.
Click Next.
7.2 Set Password Change Type
Aer acvang the device, you can set the password change type as reserved email address or
security
quesons. Once you forgot the device password, you can change the password via the
selected change type.
Change Password via Email Address
If you need to change password via reserved email, you can enter an email address, and tap Next.
DS-K1T681 Series Face Recognion Terminal User Manual
30
Figure 7-1 Password Change Page
Change via Security
Quesons
If you need to change password via security quesons, you can tap Change to Security Quesons
on the right corner. Select the security quesons and enter the answers. Click Next.
Note
You can only select one type to change password. If you need, you can enter the web page to set
both of the changing types.
DS-K1T681 Series Face Recognion Terminal User Manual
31
7.3 Set Network Parameters
Aer acvaon and select applicaon mode, you can set the network for the device
Steps
1.
When you enter the Select Network page, tap Wired Network or Wi-Fi for your actual needs.
Figure 7-2 Select Network
DS-K1T681 Series Face Recognion Terminal User Manual
32
Note
Disconnect the wired network before connecng a Wi-Fi.
2.
Tap Next.
Wired Network
Note
Make sure the device has connected to a network.
If enable DHCP, the system will assign the IP address and other parameters automacally.
If disable DHCP, you should set the IP address, the subnet mask, and the gateway.
Note
IP address of 192.168.1.64, and 192.168.1.7 are not suggested to use.
Wi-Fi
Select a Wi-Fi and enter the Wi-Fi's password to get connected.
Or tap Add Wi-Fi and enter the Wi-Fi's name and the password to get connected.
3.
Oponal: Tap Skip to skip network sengs.
7.4 Access to
Plaorm
Enable the funcon and the device can communicate via Hik-Connect. You can add the device to
Hik-Connect modile client and so on.
Steps
1.
Enable Access to Hik-Connect, and set the server IP and
vericaon code.
DS-K1T681 Series Face Recognion Terminal User Manual
33
Figure 7-3 Access to Hik-Connect
2.
Tap Next.
3.
Oponal: Tap Skip to skip the step.
4.
Oponal: Tap Previous to go to the previous page.
Note
If you tap Previous to return to the Wi-Fi conguraon page, you need to tap the connected Wi-
Fi or connect another Wi-Fi to enter the plaorm page again.
DS-K1T681 Series Face Recognion Terminal User Manual
34
7.5 Set Administrator
Aer device acvaon, you can add an administrator to manage the device parameters.
Before You Start
Acvate the device and select an applicaon mode.
Steps
1.
Oponal: Tap Skip to skip adding administrator if required.
2.
Enter the administrator's name
(oponal) and tap Next.
DS-K1T681 Series Face Recognion Terminal User Manual
35
Figure 7-4 Add Administrator Page
3.
Select a credenal to add.
Note
Up to one credenal should be added.
-
: Face forward at the camera. Make sure the face is in the face recognion area. Click to
capture and click to conrm.
-
: Press your nger according to the instrucons on the device screen. Click to conrm.
-
: Enter the card No. or present card on the card presenng area. Click OK.
4.
Click OK.
DS-K1T681 Series Face Recognion Terminal User Manual
36
You will enter the authencaon page.
7.6 Status Descripon and Control Center
On the authencaon page, you can view the device status at the upper right corner of the device
interface. You can also use nger to pull down the authencaon page to enter the control center.
Control Center
Use
nger to pull down the authencaon page to enter the control center.
Status Icon Descripon
/
Device is armed/not armed.
/
Hik-Connect is enabled/disabled.
/ /
The device wired network is connected/not connected/connecng failed.
/ /
The device' Wi-Fi is enabled and connected/not connected/enabled but not connected.
3G/4G is enabled.
Shortcut Keys Descripon
Note
You can congure those shortcut keys displayed on the screen. For details, see Basic Sengs .
Scan QR code to authencate.
Note
The QR code can be obtained from the visitor terminal.
●
Enter the device room No. and tap OK to call.
●
Tap to call the center.
Note
The device should be added to the center, or the calling operaon will be failed.
Enter password to authencate.
DS-K1T681 Series Face Recognion Terminal User Manual
37
Chapter 8 Basic Operaon
8.1 Login
Login the device to set the device basic parameters.
8.1.1 Login by Administrator
If you have added an administrator for the device, only the administrator can login the device for
device
operaon.
Steps
1.
Long tap on the inial page and slide to the le/right by following the gesture to enter the
admin login page.
DS-K1T681 Series Face Recognion Terminal User Manual
38
Figure 8-1 Admin Login
2.
Authencate the administrator's face or card to enter the home page.
DS-K1T681 Series Face Recognion Terminal User Manual
39
Figure 8-2 Home Page
Note
●
The device will be locked for 30 minutes aer 5 failed ngerprint or card aempts.
●
Aer login to the main page, you can search funcon in the searching bar which locates on
the top of the main page.
3.
Oponal: Tap and you can enter the device acvaon password for login.
4.
Oponal: Tap and you can exit the admin login page.
DS-K1T681 Series Face Recognion Terminal User Manual
40
8.1.2 Login by Acvaon Password
You should login the system before other device operaons. If you do not congure an
administrator, you should follow the
instrucons below to login.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
password entering page.
2.
Enter the password.
-
If you have added an administrator for the device, tap
and enter the password.
-
If you haven't added an administrator for the device, enter the password.
3.
Tap OK to enter the home page.
Note
The device will be locked for 30 minutes aer 5 failed password aempts.
DS-K1T681 Series Face Recognion Terminal User Manual
41
Figure 8-3 Home Page
8.1.3 Forgot Password
If you forget the password during authencaon, you can change the password.
Steps
1.
Hold the inial page for 3 s and slide to the le/right by following the gesture and log in the
page.
2.
Oponal: If you have set an administrator, tap in the pop-up admin authencaon page.
DS-K1T681 Series Face Recognion Terminal User Manual
42
Figure 8-4 Password Authencaon Page
3.
Tap Forgot Password.
4.
Answer the security
quesons that congured when acvaon.
5.
Create a new password and conrm it.
6.
Tap OK.
DS-K1T681 Series Face Recognion Terminal User Manual
43
8.2 Communicaon Sengs
You can set the network parameters, the Wi-Fi parameter, the RS-485 parameters, the Wiegand
parameters, and enable 3G/4G on the communicaon sengs page.
8.2.1 Set Wired Network Parameters
You can set the device wired network parameters, including the IP address, the subnet mask, the
gateway, and DNS parameters.
Steps
1.
Tap Comm.
(Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the
Communicaon Sengs page, tap Wired Network.
DS-K1T681 Series Face Recognion Terminal User Manual
44
Figure 8-5 Wired Network Sengs
3.
Set IP Address, Subnet Mask, and Gateway.
-
Enable DHCP, and the system will assign IP address, subnet mask, and gateway automacally.
-
Disable DHCP, and you should set the IP address, subnet mask, and gateway manually.
Note
●
The device's IP address and the computer IP address should be in the same IP segment.
●
IP address of 192.168.1.64, and 192.168.1.7 are not suggested to use.
4.
Set the DNS parameters. You can enable Auto Obtain DNS, set the preferred DNS server and the
alternate DNS server.
DS-K1T681 Series Face Recognion Terminal User Manual
45
8.2.2 Set Wi-Fi Parameters
You can enable the Wi-Fi funcon and set the Wi-Fi related parameters.
Steps
Note
The funcon should be supported by the device.
1.
Tap Communicaon on the Home page to enter the Communicaon Sengs page.
2.
On the
Communicaon Sengs page, tap Wi-Fi to enter the page of Wi-Fi.
DS-K1T681 Series Face Recognion Terminal User Manual
46
Figure 8-6 Wi-Fi Sengs
3.
Enable the Wi-Fi funcon.
4.
Congure the Wi-Fi parameters.
-
Select a Wi-Fi from the list, and enter the Wi-Fi's password. Tap OK.
-
If the target Wi-Fi is not in the list,tap Add Wi-Fi. Enter the Wi-Fi's name and password. And
tap OK.
Note
Only digits, leers, and special characters are allowed in the password.
5.
Set the Wi-Fi's parameters.
DS-K1T681 Series Face Recognion Terminal User Manual
47
-
By default, DHCP is enable. The system will allocate the IP address, the subnet mask, and the
gateway automacally.
-
If disable DHCP, you should enter the IP address, the subnet mask, and the gateway manually.
6.
Tap OK to save the sengs and go back to the Wi-Fi tab.
7.
Tap
to save the network parameters.
8.2.3 Set RS-485 Parameters
The face recognion terminal can connect external access controller, secure door control unit or
card reader via the RS-485 terminal.
Steps
1.
Tap Comm.
(Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap RS-485 to enter the RS-485 tab.
DS-K1T681 Series Face Recognion Terminal User Manual
48
Figure 8-7 Set RS-485 Parameters
3.
Enable RS-485 Sengs.
4.
Select an peripheral type according to your actual needs.
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
5.
Tap the back icon at the upper le corner and you should reboot the device if you change the
parameters.
DS-K1T681 Series Face Recognion Terminal User Manual
49
8.2.4 Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
1.
Tap Communicaon on the Home page to enter the Communicaon Sengs page.
2.
On the
Communicaon Sengs page, tap Wiegand to enter the Wiegand tab.
3.
Enable the Wiegand funcon.
4.
Select a transmission direcon.
●
Output: A face recognion terminal can connect an external access controller. And the two
devices will transmit the card No. via Wiegand 34.
●
Input: A face recognion terminal can connect a Wiegand card reader.
5.
Tap to save the network parameters.
Note
If you change the external device, and aer you save the device parameters, the device will
reboot automacally.
8.2.5 Set ISUP Parameters
Set ISUP parameters and the device can upload data via ISUP protocol.
Before You Start
Make sure your device has connect to a network.
Steps
1.
Tap Comm. → ISUP .
DS-K1T681 Series Face Recognion Terminal User Manual
50
Figure 8-8 ISUP Sengs
2.
Enable the ISUP funcon and set the ISUP server parameters.
ISUP Version
Set the ISUP version according to your actual needs.
Central Group
Enable central group and the data will be uploaded to the center group.
Main Channel
Support N1 or None.
DS-K1T681 Series Face Recognion Terminal User Manual
51
ISUP
Enable ISUP funcon and the data will be uploaded via ISUP protocol.
Address Type
Select an address type according to your actual needs.
IP Address
Set the ISUP server's IP address.
Port No.
Set the ISUP server's port No.
Note
Port No. Range: 0 to 65535.
Device ID
Set device serial no.
ISUP Key
If you choose V5.0, you should create an account and ISUP key. If you choose other version,
you should create an ISUP account only.
Note
●
Remember the ISUP account and ISUP key. You should enter the account name or the key
when the device should communicate with other plaorms via ISUP protocol.
●
ISUP key range: 8 to 32 characters.
8.2.6 Plaorm Access
You can change the device vericaon code and set the server address before you add the device
to the Hik-Connect mobile client.
Before You Start
Make sure your device has connected to a network.
Steps
1.
Tap Comm.
(Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the
Communicaon Sengs page, tap Hik-Connect.
3.
Enable Hik-Connect
4.
View
connecon status.
5.
Enter IP Address.
6.
Create the Vericaon Code, and you need to enter the vericaon code when you manage the
devices via Hik-Connect.
DS-K1T681 Series Face Recognion Terminal User Manual
52
8.2.7 Enable Mobile Network
You can enable Mobile Networkfuncon to connect the mobile network .
Note
You can set mobile network when the device supports this funcon.
Tap
Communicaon Sengs on the main page to enter the Communicaon Sengs page, and
enable Mobile Network.
8.3 User Management
On the user management interface, you can add, edit, delete and search the user.
8.3.1 Add Administrator
The administrator can log in the device backend and congure the device parameters.
Steps
1.
Long tap on the inial page and log in the backend.
2.
Tap User → + to enter the Add User page.
DS-K1T681 Series Face Recognion Terminal User Manual
53
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T681 Series Face Recognion Terminal User Manual
54
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
Up to 32 characters are allowed in the user name.
5.
Oponal: Add a face picture, ngerprints, or cards for the administrator.
Note
●
For details about adding a face picture, see Add Face Picture .
●
Note
For details about adding a ngerprint, see Add Fingerprint .
●
For details about adding a card, see Add Card .
6.
Oponal: Set the administrator's authencaon type.
Note
For details about seng the authencaon type, see Set Authencaon Mode .
7.
Enable the Administrator Permission funcon.
Enable Administrator Permission
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate
aer authencang the permission.
8.
Tap to save the sengs.
8.3.2 Add Face Picture
Add user's face picture to the device. And the user can use the face picture to authencate.
Steps
1.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T681 Series Face Recognion Terminal User Manual
55
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the Face Picture eld to enter the face picture adding page.
Figure 8-9 Add Face Picture
6.
Look at the camera.
DS-K1T681 Series Face Recognion Terminal User Manual
56
Note
●
Make sure your face picture is in the face picture outline when adding the face picture.
●
Make sure the captured face picture is in good quality and is accurate.
●
For details about the instrucons of adding face pictures, see Tips When Collecng/
Comparing Face Picture .
Aer completely adding the face picture, a captured face picture will be displayed at the upper
right corner of the page.
7.
Tap Save to save the face picture.
8.
Oponal: Tap Try Again and adjust your face posion to add the face picture again.
9.
Set the user role.
Administrator
The user is the administrator. Except for the normal
aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
10.
Tap
to save the sengs.
8.3.3 Add Fingerprint
Add a ngerprint for the user and the user can authencate via the added ngerprint.
Steps
Note
●
Devices with ngerprint module support ngerprint funcon.
●
Up to 10,000 ngerprints can be added.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and enter
the device backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID.
eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not start with 0 and should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T681 Series Face Recognion Terminal User Manual
57
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the Fingerprint eld to enter the Add Fingerprint page.
6.
Follow the instrucons to add a ngerprint.
Note
●
The same ngerprint cannot be repeatedly added.
●
Up to 10 ngerprints can be added for one user.
●
You can also use the client soware or the ngerprint recorder to record ngerprints.
For details about the instrucons of scanning ngerprints, see Tips for Scanning Fingerprint .
7.
Set the user role.
Administrator
The user is the administrator. Except for the normal
aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
8.
Tap to save the sengs.
8.3.4 Add Card
Add a card for the user and the user can authencate via the added card.
Steps
1.
Long tap on the inial page and slide to the le/right by following the gesture and log in the
backend.
2.
Tap User → + to enter the Add User page.
3.
Connect an external card reader according to the wiring diagram.
4.
Tap the Employee ID.
eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
5.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T681 Series Face Recognion Terminal User Manual
58
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 128 characters.
6.
Tap the Card eld and tap +.
7.
Congure the card No.
-
Enter the card No. manually.
-
Present the card over the card
presenng area to get the card No.
Note
●
The card No. cannot be empty.
●
Up to 20 characters are allowed in the card No.
●
The card No. cannot be duplicated.
8.
Congure the card type.
9.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
10.
Tap to save the sengs.
8.3.5 View PIN code
Add a PIN code for the user and the user can authencate via the PIN code.
Steps
1.
Long tap on the inial page and slide to the le/right by following the gesture and log in the
backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID.
eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T681 Series Face Recognion Terminal User Manual
59
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 128 characters.
5.
Tap the PIN code to view the PIN code.
Note
The PIN code cannot be edited. It can only be applied by the plaorm.
6.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
7.
Tap
to save the sengs.
8.3.6 Set
Authencaon Mode
Aer adding the user's face picture, password, or other credenals, you should set the
authencaon mode and the user can authencate his/her identy via the congured
authencaon mode.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → Add User/Edit User →
Authencaon Mode .
3.
Select Device or Custom as the
authencaon mode.
Device
If you want to select device mode, you should set the terminal authencaon mode in Access
Control
Sengs page rst. For details see Seng Access Control Parameters.
Custom
You can combine dierent authencaon modes together according to your actual needs.
4.
Tap to save the sengs.
8.3.7 Search and Edit User
Aer adding the user, you can search the user and edit it.
DS-K1T681 Series Face Recognion Terminal User Manual
60
Search User
On the User Management page, Tap the search area to enter the Search User page. Tap Card on
the le of the page and select a search type from the drop-down list. Enter the employee ID, card
No., or the user name for search. Tap
to search.
Edit User
On the User Management page, select a user from the user list to enter the Edit User page. Follow
the steps in User Management to edit the user parameters. Tap to save the sengs.
Note
The employee ID cannot be edited.
8.4 Data Management
You can delete data, import data, and export data.
8.4.1 Delete Data
Delete user data.
On the Home page, tap Data → Delete Data → User Data . All user data added in the device will be
deleted.
8.4.2 Import Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, tap Data → Import Data .
Note
Aer insert the USB ash driver, you can tap Import Data on the Data page.
3.
Tap User Data, Face Data or Access Control Parameters .
Note
The imported access control parameters are conguraon les of the device.
4.
Enter the created password when you exported the data. If you do not create a password when
you exported the data, leave a blank in the input box and tap OK immediately.
Note
●
If you want to transfer all user informaon from one device (Device A) to another (Device B),
you should export the informaon from Device A to the USB ash drive and then import from
DS-K1T681 Series Face Recognion Terminal User Manual
61
the USB ash drive to Device B. In this case, you should import the user data before imporng
the prole photo.
●
The supported USB ash drive format is FAT32.
●
The imported pictures should be saved in the folder (named enroll_pic) of the root directory
and the picture's name should be follow the rule below:
Card No._Name_Department_Employee ID_Gender.jpg
●
If the folder enroll_pic cannot save all imported pictures, you can create another folders,
named enroll_pic1, enroll_pic2, enroll_pic3, enroll_pic4, under the root directory.
●
The employee ID should be less than 32 characters. It can be a combinaon of lower leers,
upper leers, and numbers. It should not be duplicated, and should not start with 0.
●
Requirements of face picture should follow the rules below: It should be taken in full-face
view, directly facing the camera. Do not wear a hat or head covering when taking the face
picture. The format should be JPEG or JPG. The resoluon should be 640 × 480 pixel or more
than of 640 × 480 pixel. The picture size should be between 60 KB and 200 KB.
8.4.3 Export Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, tap Data → Export Data .
Note
Aer insert the USB ash driver, you can tap Export Data on the Data page.
3.
Tap Face Data, Event Data, User Data, or Access Control Parameters.
Note
The exported access control parameters are conguraon les of the device.
4.
Oponal: Create a password for exporng. When you import those data to another device, you
should enter the password.
Note
●
The supported USB ash drive format is DB.
●
The system supports the USB ash drive with the storage of 1G to 32G. Make sure the free
space of the USB ash drive is more than 512M.
●
The exported user data is a DB
le, which cannot be edited.
8.5 Identy Authencaon
Aer network conguraon, system parameters conguraon and user conguraon, you can go
back to the
inial page for identy authencaon. The system will authencate person according
to the congured authencaon mode.
DS-K1T681 Series Face Recognion Terminal User Manual
62
You can authencate identy via 1:1 matching or 1:N matching.
1:N Matching
Compare the captured face picture with all face pictures stored in the device.
1: 1 Matching
Compare the captured face picture with the linked face picture.
8.5.1 Authencate via Single Credenal
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Authencate face, ngerprint, card or QR code.
Face
Face forward at the camera and start
authencaon via face.
Fingerprint
Place the enrolled ngerprint on the ngerprint module and start authencaon via ngerprint.
Card
Present the card on the card presenng area and start authencaon via card.
Note
The card can be normal IC card, or encrypted card.
QR Code
Put the QR code in front of the device camera to authencate via QR code.
Note
●
Authencaon via QR code should be supported by the device.
●
The dimension of the recognized QR code picture should be larger than 6 cm × 6 cm.
Password
Enter the password to authencate via password.
If authencaon completed, a prompt "Authencated" will pop up.
8.5.2
Authencate via Mulple Credenal
Before You Start
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Steps
1.
If the authencaon mode is Card and Face, Password and Face, Card and Password, Card and
Face and Fingerprint,
authencate any credenal according to the instrucons on the live view
page.
DS-K1T681 Series Face Recognion Terminal User Manual
63
Note
●
Aer enabling Control Inial Authencaon Typeon the web client, the inial authencaon
type will be xed.
●
The card can be normal IC card, or encrypted card.
●
The card can be normal IC card, or encrypted card.
●
If the QR Code Scanning funcon is enabled, you can put the QR code in front of the device
camera to
authencate via QR code.
●
The dimension of the recognized QR code picture should be larger than 6 cm × 6 cm.
●
The dimension of the recognized QR code picture should be larger than 6 cm × 6 cm.
2.
Aer the previous credenal is authencated, connue authencate other credenals.
If authencaon succeeded, the prompt "Authencated" will pop up.
8.6 Basic
Sengs
You can set the voice sengs, me sengs, sleeping (s), language, community No., building No.,
Unit No., and beauty.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture and login the
device home page. Tap Basic.
DS-K1T681 Series Face Recognion Terminal User Manual
64
Figure 8-10 Basic Sengs Page
Sound Sengs
You can enable/disable the voice prompt funcon and adjust the voice volume.
Note
You can set the voice volume between 0 and 10.
Time Sengs
Set the me zone, the device me and the DST.
DS-K1T681 Series Face Recognion Terminal User Manual
65
Sleeping Duraon
Set the device sleeping waing me (minute). When you are on the inial page and if you set
the sleeping
me to 30 min, the device will sleep aer 30 min without any operaon.
Select Language
Select the language according to actual needs.
Set No.
Set the Community No., Building No. and Unit No.
8.7 Password Management
You can change device password.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login
the device home page. Tap Basic → Password .
2.
Tap Change Password. Enter the old password.
3.
Enter the new password and
conrm it.
4.
Tap OK.
Note
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
two kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
8.8 Set Biometric Parameters
You can customize the face parameters to improve the face recognion performance. The
congurable parameters includes applicaon mode, face liveness level, face recognion distance,
face
recognion interval, wide dynamic, face 1:N security level, face 1:1 security level, ECO
sengs, face with mask detecon and mulple faces authencaon.
8.8.1 Set Face Liveness Level
Set the matching security level when performing face an-spoong authencaon
DS-K1T681 Series Face Recognion Terminal User Manual
66
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Aer enabling face an-spoong funcon, you can set the matching security level when
performing face
an-spoong authencaon. The higher the level, the more strict of the
recognion.
8.8.2 Set Face Recognion Distance
Set the valid distance between the person and the device camera.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Set the valid distance between the person and the device camera when
authencang.
8.8.3 Set Face
Recognion Interval
You can set the me interval between 2 connuous face recognions when authencang.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Set the me interval between 2 connuous face recognions when authencang.
Note
You can input the number from 1 to 10.
8.8.4 Set Wide Dynamic Range
When there are both very bright and very dark areas simultaneously in the view, you can enable
the WDR funcon.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Note
It is suggested to enable the WDR funcon if installing the device outdoors.
When there are both very bright and very dark areas simultaneously in the view, you can enable
the WDR
funcon to balance the brightness of the whole image and provide clear images with
details.
8.8.5 Set Face 1:1/1:N Security Level
Set the face recognion threshold.
DS-K1T681 Series Face Recognion Terminal User Manual
67
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Set the parameters.
Face 1:1 Security Level
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false
rejecon rate.
Face 1:N Security Level
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
8.8.6 Set ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment. And you can set the ECO mode threshold, ECO mode (1:N), and ECO
mode (1:1).
ECO Threshold
When enabling the ECO mode, you can set the ECO mode’s threshold. The larger the value, the
easier the device entering the ECO mode.
ECO Mode (1:1)
Set the matching threshold when
authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false
rejecon rate.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate
8.8.7 Set Face with Mask
Detecon
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Aer enabling the face with mask detecon, the system will recognize the captured face with mask
picture. You can set face with mask & face 1:N level and the strategy.
Reminder of Wearing
DS-K1T681 Series Face Recognion Terminal User Manual
68
If the person do not wear a face mask when authencang, the device prompts a nocaon
and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the device prompts a nocaon
and the door keeps closed.
8.8.8 Set Mulple Faces Authencaon
You can authencate mulple faces at the same me.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Biometric.
Aer mulple faces authencaon is enabled, mulple faces authencaon is supported.
8.9 Set Access Control Parameters
You can set the access control permissions, including the funcons of authencaon mode, enable
NFC card, enable M1 card, door contact, open
duraon(s) and authencaon interval(s).
8.9.1 Set Terminal
Authencaon Mode
Set the device's authencaon mode. You can also customize the authencaon mode. if
authencang on the device, you should follow the device's authencaon mode.
On the Home page, tap ACS (Access Control Sengs) to enter the Access Control Sengs page.
Select the face
recognion terminal's authencaon mode. You can also customize the
authencaon mode.
Note
●
Only the device with the ngerprint module supports the ngerprint related funcon.
●
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
●
If you adopt
mulple authencaon modes, you should authencate other methods before
authencang face.
DS-K1T681 Series Face Recognion Terminal User Manual
69
Figure 8-11 Access Control Parameters
8.9.2 Set Card Reader
Authencaon Mode
Set the card reader's authencaon mode and if authencang on the card reader, you should
follow the card reader's authencaon mode.
On the Home page, tap ACS (Access Control Sengs) to enter the Access Control Sengs page.
Select Reader's Auth. Mode (card reader's
authencaon mode). If authencang on the card
reader, you should follow the card reader's authencaon mode.
DS-K1T681 Series Face Recognion Terminal User Manual
70
Figure 8-12 Access Control Parameters
8.9.3 Enable NFC Card
Enable NFC card funcon and you can present NFC card on the device to authencate.
Steps
1.
On the Home page, tap ACS (Access Control
Sengs) to enter the Access Control Sengs page.
DS-K1T681 Series Face Recognion Terminal User Manual
71
Figure 8-13 Access Control Parameters
2.
Enable the funcon and you can present the NFC card to authencate.
8.9.4 Enable M1 Card and M1 Car d
Encrypon
Enable M1 card funcon and you can present M1 card on the device to authencate. M1 card
encrypon can improve the security level of authencaon.
Steps
1.
On the Home page, tap ACS (Access Control
Sengs) to enter the Access Control Sengs page.
DS-K1T681 Series Face Recognion Terminal User Manual
72
Figure 8-14 Access Control Parameters
2.
Set the M1 card funcon.
Enable M1 Card
Enable the funcon and you can present the M1 card to authencate.
M1 Card Encrypon
Enable the funcon and set the sector ID.
DS-K1T681 Series Face Recognion Terminal User Manual
73
Note
●
The sector ID ranges from 1 to 100.
●
By default, Sector 13 is encrypted. It is recommended to encrypt sector 13.
8.9.5 Set Door Contact Parameters
If connecng a door contact, you should conrm the NO or NC connecon method. Select remain
open or remain closed according to actual NO/NC connecon method.
On the Home page, tap ACS (Access Control
Sengs) to enter the Access Control Sengs page.
You can select "Remain Open" or "Remian Closed" according to your actual needs. By default, it is
Remian Closed.
DS-K1T681 Series Face Recognion Terminal User Manual
74
Figure 8-15 Access Control Parameters
8.9.6 Set Door Open
Duraon
Set the door unlocking duraon.
On the Home page, tap ACS (Access Control Sengs) to enter the Access Control Sengs page.
Set the door unlocking duraon. If the door is not opened for the set me, the door will be locked.
Available door locked
me range: 1 to 255s.
DS-K1T681 Series Face Recognion Terminal User Manual
75
Figure 8-16 Access Control Parameters
8.9.7 Set
Authencaon Interval
Set the authencaon interval between 2 authencaons. Within the interval, the same person
can authencate only once.
On the Home page, tap ACS (Access Control Sengs) to enter the Access Control Sengs page.
Set the
authencaon interval between 2 authencaons. Within the interval, the same person
can authencate only once. Available authencaon interval range: 0 to 65535.
DS-K1T681 Series Face Recognion Terminal User Manual
76
Figure 8-17 Access Control Parameters
8.10 Time and
Aendance Status Sengs
You can set the aendance mode as check in, check out, break out, break in, overme in, and
overme out according to your actual situaon.
DS-K1T681 Series Face Recognion Terminal User Manual
77
Note
The funcon should be used cooperavely with me and aendance funcon on the client
soware.
8.10.1 Disable Aendance Mode via Device
Disable the aendance mode and the system will not display the aendance status on the inial
page.
Tap
Aendance Status to enter the Aendance Status page.
DS-K1T681 Series Face Recognion Terminal User Manual
78
Figure 8-18 Disable Aendance Mode
Set the Aendance Mode as Disable.
You will not view or
congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
8.10.2 Set Manual
Aendance via Device
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
DS-K1T681 Series Face Recognion Terminal User Manual
79
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap
Aendance Status to enter the Aendance Status page.
2.
Set the Aendance Mode as Manual.
Figure 8-19 Manual Aendance Mode
3.
Enable the Aendance Status Required.
4.
Enable a group of
aendance status.
DS-K1T681 Series Face Recognion Terminal User Manual
80
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the
authencaon result page.
Result
You should select an aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
8.10.3 Set Auto Aendance via Device
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap Aendance Status to enter the Aendance Status page.
2.
Set the
Aendance Mode as Auto.
DS-K1T681 Series Face Recognion Terminal User Manual
81
Figure 8-20 Auto Aendance Mode
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Tap
Aendance Schedule.
DS-K1T681 Series Face Recognion Terminal User Manual
82
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Tap Conrm.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
When you
authencate on the inial page, the authencaon will be marked as the congured
aendance
status according to the congured schedule.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
8.10.4 Set Manual and Auto
Aendance via Device
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the
aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's
authencaon mode. For details, see User Management.
Steps
1.
Tap Aendance Status to enter the Aendance Status page.
2.
Set the Aendance Mode as Manual and Auto.
DS-K1T681 Series Face Recognion Terminal User Manual
83
Figure 8-21 Manual and Auto Mode
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Tap
Aendance Schedule.
DS-K1T681 Series Face Recognion Terminal User Manual
84
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Tap OK.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
On the
inial page and authencate. The authencaon will be marked as the congured
aendance
status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
8.11 Preference
Sengs
Set interface style, theme, shortcut and control center.
8.11.1 Set Interface Style
You can congure the device interface to light or dark mode.
Steps
1.
Tap Preference to enter the preference
sengs page.
DS-K1T681 Series Face Recognion Terminal User Manual
85
Figure 8-22 Preference Sengs
2.
You can set the interface style of the device as Light Mode or Dark Mode.
8.11.2 Set Theme Mode
You can set the theme mode to recognion or adversement mode.
Steps
1.
Tap Preference to enter the preference sengs page.
DS-K1T681 Series Face Recognion Terminal User Manual
86
Figure 8-23 Preference Sengs
2.
You can set the theme of the prompt window on the authencaon page. You can select Theme
Mode as
Recognion Mode, or Adversement Mode.
Recognion Mode
The device authencaon page will display the live view page. And the person's name,
employee ID, face pictures will all be displayed
aer authencaon.
Adversement Mode
DS-K1T681 Series Face Recognion Terminal User Manual
87
Aer selecng this mode, the adversing area and idencaon authencaon area of the
device will be displayed on separate screens. Video and adversing informaon playback,
welcome speech display are supported.
8.11.3 Set Authencaon Page Shortcut
You can set the displayed shortcuts on authencaon mode.
Steps
1.
Tap Preference to enter the preference sengs page.
DS-K1T681 Series Face Recognion Terminal User Manual
88
Figure 8-24 Preference Sengs
2.
Choose the shortcut key that displayed on the authencaon page, including the call funcon,
call type, and the password entering funcon.
Call
Aer enabling this funcon, you can select Call Type from the list of Call Menu, Call Center
and Call
Specic Room according to your needs.
QR Code
You can use the QR code scanning funcon on the authencaon interface. The device will
upload the informaon associated with the obtained QR code to the plaorm.
DS-K1T681 Series Face Recognion Terminal User Manual
89
Open Door via Password
Enable this funcon and you can enter the PIN code to open the door.
8.11.4 Set Control Center Displayed Items
You can set the items that displayed in the control center.
Steps
1.
Tap Preference to enter the preference sengs page.
2.
Set the control items displayed in the control center.
On the
authencaon page, use nger to pull down to enter the control center page to view the
control items.
8.12 System Maintenance
You can view the system informaon and the capacity. You can also upgrade the device, restore to
factory sengs, restore to default sengs, and reboot the device.
8.12.1 View System
Informaon
You can view the device system informaon.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Maint. → System
Informaon .
You can view the device model, serial No., versions, address, producon data, and open source
code license.
Note
The page may vary according to dierent device models. Refers to the actual page for details.
8.12.2 View Device Capacity
You can view the number of user, face picture, card, event and ngerprint.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Maint. → Capacity .
You can view the number of user, face picture, card, event and ngerprint.
Note
Parts of the device models support displaying the ngerprint number. Refers to the actual page for
details.
DS-K1T681 Series Face Recognion Terminal User Manual
90
8.12.3 Upgrade
Choose online upgrading or upgrading via the USB ash drive.
Long tap on the
inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Maint. → Upgrade .
Choose one of the following upgrade methods to upgrade.
Online Update
If the device has been connected to Hik-Connect and network, when there is a new
installaon
package in Hik-Connect, you can tap Device Upgrade → Online Update to upgrade the device
system.
Update via USB
Plug the USB
ash drive in the device USB interface. Tap Device Upgrade → Update via USB ,
and the device will read the digicap.dav le in the USB ash drive to start upgrading.
8.12.4 View User Manual
View the device user manual.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Maint. → User Manual .
Scan the QR code to obtain and view the user manual.
8.12.5 Restore Parameters
Restore to default sengs or restore to factory sengs.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Maint..
Restore to default
sengs or restore to factory sengs.
Restore to Default Sengs
All parameters, except for the communicaon sengs, remotely imported user informaon, will
be restored to the default sengs. The system will reboot to take eect.
Restore to Factory Sengs
All parameters will be restored to the factory sengs. The system will reboot to take eect.
8.12.6 Reboot
Reboot device if needed.
DS-K1T681 Series Face Recognion Terminal User Manual
91
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and tap
Maint..
Reboot the device.
8.12.7 Advanced Sengs
You can set face parameters and view device version.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture. Login and
tap Maint. → System Informaon . Long tap ? on the right upper corner.
2.
Enter the admin password.
3.
Tap Face Parameters.
Face Parameter
Custom
An-Spoong Detecon
Face Liveness Level
Aer enabling face an-spoong funcon, you can set the matching security level when
performing live face
authencaon.
An-Spoong Detecon Threshold
The larger the value, the smaller the false accept rate and the larger the false rejecon
rate. The smaller the value, the larger the false accept rate and the smaller the false
rejecon rate.
Lock Face for An-Spoong Protecon
Aer enabling this funcon, the device will lock automacally when an-spoong
detecon failed.
Lock Duraon
The lock duraon aer enabling Lock Face for An-Spoong Protecon when an-
spoong
detecon failed.
4.
Tap Version Informaon to view device version.
8.13 Video Intercom
Aer adding the device to the client soware, you can call the device from the client soware, call
the main
staon from the device, call the client soware from the device, call the indoor staon
from the device, or call the specic room from the device.
DS-K1T681 Series Face Recognion Terminal User Manual
92
8.13.1 Call Client Soware from Device
Steps
1.
Get the client
soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the device to the client
soware.
Note
For details about adding device, see Add Device.
5.
Call the client soware.
1) Tap on the device inial page.
2) Enter 0 in the pop-up window.
3) Tap
to call the client soware.
6.
Tap Answer on the pop-up page of the client soware and you can start two-way audio between
the device and the client
soware.
Note
If the device is added to mulple client sowares and when the device is calling the client
soware, only the rst client soware added the device will pop up the call receiving window.
8.13.2 Call Center from Device
Steps
1.
Get the client soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the main
staon and the device to the client soware.
Note
For details about adding device, see Add Device.
5.
Set the main staon's IP address and SIP address in the remote conguraon page.
Note
For details about the operaon, see the user manual of the main staon.
6.
Call the center.
-
If you have congured to call center in the Basic Sengs , you can tap to call the center.
-
If you have not
congured to call center in the Basic Sengs , you should tap → to call
the center
7.
Answers the call via the main
staon and starts two-way audio.
DS-K1T681 Series Face Recognion Terminal User Manual
93
Note
The device will call the main staon in priority.
8.13.3 Call Device from Client Soware
Steps
1.
Get the client soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management page.
4.
Add the device to the client
soware.
Note
For details about adding device, see Add Device.
5.
Enter the Live View page and double-click the added device to start live view.
Note
For details about operaons in the Live View page, see Live View in the user manual of the client
soware.
6.
Right click the live view image to open the right-click menu.
7.
Click Start Two-Way Audio to start two-way audio between the device and the client soware.
8.13.4 Call Room from Device
Steps
1.
Get the client
soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the indoor
staon and the device to the client soware.
Note
For details about adding device, see Add Device.
5.
Link a user to an indoor staon and set a room No. for the indoor staon.
6.
Call the room.
-
If you have
congured a specied room No. in the Basic Sengs , you can tap to call the
room.
-
If you have not congured a specied room No. in the Basic Sengs , you should tap on
the
authencaon page of the device. Enter the room No. on the dial page and tap to call
the room.
7.
Aer the indoor staon answers the call, you can start two-way audio with the indoor staon.
DS-K1T681 Series Face Recognion Terminal User Manual
94
8.13.5 Call Mobile Client from Device
Steps
1.
Get the mobile mobile client from the supplied disk or the
ocial website, and install the
soware according to the prompts.
2.
Run the mobile client and add the device to the mobile client.
Note
For details, see the user manual of the mobile client.
3.
Enter Basic Sengs → Shortcut Key and enable Call APP.
4.
Go back to the
inial page and call the mobile client.
1) Tap on the device inial page.
2) Tap to call the mobile client.
8.13.6 Doorbell Call
Steps
1.
Get the client
soware from the supplied disk or the ocial website, and install the soware
according to the prompts.
2.
Run the client
soware and the control panel of the soware pops up.
3.
Click Device Management to enter the Device Management interface.
4.
Add the device to the client
soware.
Note
For details about adding device, see Add Device.
5.
Tap doorbell buon to call.
1) Tap on the device inial page.
2) Tap
to call.
DS-K1T681 Series Face Recognion Terminal User Manual
95
Chapter 9 Quick Operaon via Web Browser
9.1 Select Language
You can select a language for the device system.
Click in the top right of the web page to enter the Device Language Sengs page. You can
select a language for the device system from the drop-down list.
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
Click Next to complete the sengs.
9.2 Time
Sengs
Click in the top right of the web page to enter the wizard page. Aer seng device language,
you can click Next to enter the Time Sengs page.
Time Zone
Select the device located
me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server Address/NTP Port/Interval
You can set the server address, NTP port, and interval.
Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.
9.3 Privacy
Sengs
Set the picture uploading and storage parameters.
Click
in the top right of the web page to enter the wizard page. Aer previous sengs, you can
click Next to enter the Privacy Sengs page.
DS-K1T681 Series Face Recognion Terminal User Manual
96
Picture Uploading and Storage
Save Picture When Authencang
Save picture when authencang automacally.
Upload Picture When Authencang
Upload the pictures when authencang to the plaorm automacally.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Click Next to complete the sengs.
9.4 Administrator
Sengs
Steps
1.
Click in the top right of the web page to enter the wizard page. Aer seng device language,
me, environment and privacy, you can click Next to enter the Administrator Sengs page.
2.
Enter the employee ID and name of the administrator.
3.
Select a
credenal to add.
Note
You should select at least one credenal.
1) Click Add Face to upload a face picture from local storage.
Note
The uploaded picture should be within 200 K, in JPG、JPEG、PNG format.
2) Click Add Card to enter the Card No. and select the property of the card.
Note
Up to 5 cards can be supported.
Click Next to save the sengs and go to the next paramater. Or click Skip to skip administrator
sengs.
DS-K1T681 Series Face Recognion Terminal User Manual
97
9.5 No. and System Network
Steps
1.
Click in the top right of the web page to enter the wizard page. Aer previous sengs, you
can click Next to enter the No. and System Network sengs page.
2.
Set the device type.
If set the device type as Door
Staon or Outer Door Staon, you can set the Community No.,
Building No., Unit No., Floor No., and Door Staon No.
If set the device type as Outer Door
Staon, you can set outer door staon No., and community
No.
3.
Set
Registraon Password, Main Staon IP and Private Server IP.
4.
Oponal: Click to Enable Protocol 1.0.
5.
Click Complete to save the sengs aer the conguraon.
DS-K1T681 Series Face Recognion Terminal User Manual
98
Chapter 10 Operaon via Web Browser
10.1 Login
You can login via the web browser or the remote conguraon of the client soware.
Note
Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon .
Login via Web Browser
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
Login via Remote
Conguraon of Client Soware
Download and open the client soware. Aer adding the device, click to enter the Conguraon
page.
10.2 Forgot Password
If you forget the device password, you can change the device password via security quesons.
Steps
Note
You can change the device password via PC web.
1.
ClickForgot Password on the login page.
2.
Select the
vericaon method.
3.
Answer the reserved security quesons.
Note
The answers are congured when you rst acvate the device.
4.
Create a new password and conrm the password.
5.
Click Next to save the
sengs.
10.3 Live View
You can view the live video of the device, linked device, person informaon, network status, basic
informaon, and device capacity.
DS-K1T681 Series Face Recognion Terminal User Manual
99
Figure 10-1 Live View Page
Funcon Descripons:
Real-Time Event
You can view the event Employee ID, Name, Card No., Event Type, Time, and
Operaon. You can
also click View More to enter the page of Event Search. You can select event types, enter the
employee ID, the name, the card No., the start me, and the end me, and click Search. The
results will be displayed on the right panel.
Door Status
Click
to view the device live view.
Set the volume when starng live view.
Note
If you adjust the volume when starng two-way audio, you may hear a repeated sounds.
You can capture image when starng live view.
Select the streaming type when starng live view. You can select from the main stream, sub
stream or third stream.
Full screen view.
DS-K1T681 Series Face Recognion Terminal User Manual
100
You can record when starng live view.
/ / /
The door status is open/closed/remaining open/remaining closed.
Controlled Status
You can control the door to be opened, closed, remaining open or remaining closed
according to your actual needs.
Link Device
You can view the
quanty and status of linked devices.
Note
You can click View More to Device Management .
Person Informaon
You can view the added and not added informaon of person face and card.
Network Status
You can view the connected and registered status of wired network, wireless network, Hik-
Connect, ISUP, and SIP.
Basic
Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, face, ngerprint, card, and event capacity.
10.4 Person Management
Add person's basic informaon, permission, credenals, room No., and authencaon type.
10.4.1 Add Person Basic
Informaon
Add the person's basic informaon, including the employee ID, the person's name, the gender,
person type and the person's organizaon.
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
101
Figure 10-2 Add Person
DS-K1T681 Series Face Recognion Terminal User Manual
102
2.
Add the person's basic informaon, including the employee ID, the person's name, person type,
the person's organizaon, etc.
3.
Oponal: If you select Visitor as the person type, you can set the visit mes.
4.
Click Save.
10.4.2 Set Permission Duraon
Set the person's permission duraon.
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
103
Figure 10-3 Add Person
DS-K1T681 Series Face Recognion Terminal User Manual
104
2.
Enable Long-Term Eecve User and the person will have the congured permission
permanently. Or set Validity Period and the person can only has the permission within the
congured me period according to your actual needs.
3.
Click Save.
10.4.3 Add Face Picture
Add face picture for a person.
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
105
Figure 10-4 Add Person
2.
Click + on the right to upload a face picture from the local PC.
DS-K1T681 Series Face Recognion Terminal User Manual
106
Note
The picture format should be JPG or JPEG or PNG, and the size should be less than 200 K.
3.
Click Save.
10.4.4 Add Card
Enter a short descripon of your task here (oponal).
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
107
Figure 10-5 Add Person
2.
Click Add Card.
DS-K1T681 Series Face Recognion Terminal User Manual
108
3.
Enter Card No. and select a Property.
4.
Click OK to add the card.
Note
Up to 5 cards can be added.
5.
Click Save.
10.4.5 Add Fingerprint
Add ngerprint for a person.
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
109
Figure 10-6 Add Person
DS-K1T681 Series Face Recognion Terminal User Manual
110
2.
Click Add Fingerprint, and press your nger on the ngerprint module of the device to add your
ngerprint.
Note
Only devices supporng the ngerprint funcon can add the ngerprint.
3.
Click Save.
10.4.6 Add Room No.
Add a room No. for the person.
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
111
Figure 10-7 Add Person
2.
Click Add to add a device. Enter the Room No. and Floor No. of the device.
DS-K1T681 Series Face Recognion Terminal User Manual
112
Note
Take oor 1, room 1 as an example, the room No. should be 1-1-1-1 (Community-Building-Unit-
Room).
3.
Click Save.
10.4.7 Set Authencaon Type
Set the person's authencaon type as same as device or custom. If you set as Same as Device,
the person will follow the device's
authencaon mode. If you set as Custom, the person will
follow his/her own authencaon mode.
Steps
1.
Click Person Management → Add to enter the Add Person page.
DS-K1T681 Series Face Recognion Terminal User Manual
113
Figure 10-8 Add Person
2.
Set Authencaon Type as Same as Device or Custom.
DS-K1T681 Series Face Recognion Terminal User Manual
114
Same as Device
If you want to select Same as Device, you should set the terminal authencaon mode rst.
For details, see Set Authencaon Mode .
Custom
You can select an authencaon mode according to your actual needs.
3.
Click Save.
10.5 Search Event
Click
Event Search to enter the Search page.
Enter the search
condions, including the event type, the employee ID, the name, the card No., the
start me, and the end me, and click Search.
The results will be displayed on the right panel.
10.6 Device Management
You can manage the linked device on the page.
Steps
1.
Click Device Management to enter the sengs page.
Figure 10-9 Device Management
2.
Click Add to add the indoor staon or sub door staon. Enter the parameters and click Sav to
add.
3.
Click Import to download the template. Enter the
informaon of the device in the template and
click to import the template.
4.
Click Export to export the informaon to the PC.
5.
Select the device and click Delete to remove the selected device from the list.
6.
Click Refresh to get the device
informaon.
DS-K1T681 Series Face Recognion Terminal User Manual
115
7.
Oponal: Set Device Informaon.
Edit Device Informaon Click to edit device informaon.
Delete Device Informaon Click to delete device informaon from the list.
Search Devices Select Status and Device Type to search devices.
10.7 Conguraon
10.7.1 View Device Informaon
View the device name, language, model, serial No., version, IO input, IO OUTput, Lock, Local
RS-485, register number, alarm input, alarm output, and device capacity, etc.
Click
Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view device name, language, model, serial No., version, IO input, IO output, Lock, Local
RS-485, register number, alarm input, alarm output, and device capacity, etc.
10.7.2 Set Time
Set the device's me, me zone, synchronizaon mode, server address, NTP port, and interval.
Click
Conguraon → System → System Sengs → Time Sengs .
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's
me.
Server Address Type/Server Address/NTP Port/Interval
You can set the server address type, server address, NTP port, and interval.
DS-K1T681 Series Face Recognion Terminal User Manual
116
10.7.3 Change Administrator's Password
Steps
1.
Click
Conguraon → System → User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
10.7.4 Account Security Sengs
You can change the security quesons and answers, or the email address for the device. Aer
change the sengs, once you forgot the device password, you should answer the new quesons or
use the new email address to reset the device password.
Steps
1.
Click Conguraon → System → User Management → Account Security Sengs .
2.
Change the security
quesons or email address according your actual needs.
3.
Enter the device password and click OK to conrm changing.
10.7.5 View Device Arming/Disarming
Informaon
View device arming type and arming IP address.
Click Conguraon → System → User Management → Arming/Disarming Informaon .
You can view the device arming/disarming
informaon. Click Refresh to refresh the page.
10.7.6 Network
Sengs
Set TCP/IP, port, Wi-Fi parameters, ISUP, and plaorm access.
DS-K1T681 Series Face Recognion Terminal User Manual
117
Note
Some device models do not support Wi-Fi or mobile data sengs. Refer to the actual products
when conguraon.
Set Basic Network Parameters
Click Conguraon → Network → Network Sengs → TCP/IP .
Figure 10-10 TCP/IP Sengs Page
Set the parameters and click Save to save the sengs.
NIC Type
Select a NIC type from the drop-down list. By default, it is Self-Adapve.
DHCP
If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask and IPv4 default
gateway.
If you check the
funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4
default gateway automacally.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless
connecon.
DS-K1T681 Series Face Recognion Terminal User Manual
118
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Network Sengs → Wi-Fi .
Figure 10-11 Wi-Fi Sengs Page
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click Connect of a Wi-Fi in the list and enter the Wi-Fi password.
-
Click Manual Add and enter a Wi-Fi's SSID, working mode, security mode, and password. Click
OK.
4.
Set the WLAN parameters.
1) Set the IP address, subnet mask, and default gateway. Or enable DHCP and the system will
allocate the IP address, subnet mask, and default gateway
automacally.
5.
Set the DNS server. Set the preferred DNS server and alternate DNS server. Or enable DHCP and
the system will allocate the preferred DNS server and alternate DNS server automacally.
6.
Click Save.
Set Mobile Data
Set the mobile data parameters for the device .
Note
The funcon should be supported by the device models.
Click Conguraon → Network → Network Sengs → Mobile Data .
Enable Mobile Data
DS-K1T681 Series Face Recognion Terminal User Manual
119
If the device supports mobile data funcon, you can enable it.
Dialing Mode/Dialing No.
Select the dialing mode as Manual. And set the dialing No.
User Name/Password/APN
If you need, you can set the user name, password and APN for mobile number.
Bluetooth Sengs
You can enable bluetooth funcon.
Open
Enable Open to enable the bluetooth funcon.
Device Name
You can edit the device name connected to the bluetooth.
Open Door via Bluetooth
Aer enabling this funcon, you can open doors via Hik-Connect app.
Set Port Parameters
Set the HTTP, HTTPS, HTTP Listening, RTSP and Server port parameters.
Click
Conguraon → Network → Network Service → HTTP(S) .
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is
modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
HTTP Listening
The device can send alarm informaon to the event alarm IP address or domain name via HTTP
protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and
protocol.
Note
The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol
to receive the alarm informaon.
Click Conguraon → Network → Network Service → RTSP .
RTSP
It refers to the port of real-me streaming protocol.
DS-K1T681 Series Face Recognion Terminal User Manual
120
Click Conguraon → Network → Device Access → SDK Server .
SDK Server
It refers to the port through which the client adds the device.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click Conguraon → Network → Device Access → Hik-Connect to enter the sengs page.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
2.
Check Enable to enable the funcon.
3.
Oponal: Check the checkbox of Custom, and you can set the server address by yourself.
4.
Enter the server IP address, and vericaon code.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
5.
Enable Video Encrypon, and create the password and conrm it.
Note
Aer adding the device to APP, you need to enter the video encrypon password to live view the
device.
6.
Oponal: Click View to view the device QR code. Scan the QR code to account.
Note
Scan the QR code before it loses ecacy.
7.
Oponal: Click More to set the network connecon priority.
1) Enable WLAN or Wired Network according to your actual needs.
1) Hold and drag
to adjust the access priority.
8.
Click Save to enable the
sengs.
Set ISUP Parameters
Set the ISUP parameters for accessing device via ISUP protocol.
DS-K1T681 Series Face Recognion Terminal User Manual
121
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Device Access → ISUP .
2.
Check Enable.
3.
Select the ISUP version and Server IP Address, Port, Device ID, and you can view the Register
status.
Note
If you select 5.0 as the version, you should set the Encrypon Key and Network Connecon
Priority as well. You can click More and check WLAN or Wired Network to adjust the network
priority.
4.
Set the ISUP listening parameters, including ISUP alarm center IP address/domain name, ISUP
alarm center URL, and ISUP alarm center port.
5.
Click Save.
SIP
Seng
Steps
1.
Click Conguraon → Network → Device Access → SIP to enter the sengs page.
2.
Check Enable VOIP Gateway.
3.
Congure the SIP parameters.
4.
Click Save to enable the
sengs.
10.7.7 Set Video and Audio Parameters
Set the image quality and resoluon.
Set Video Parameters
Click Conguraon → Video/Audio → Video .
DS-K1T681 Series Face Recognion Terminal User Manual
122
Figure 10-12 Video Sengs Page
Set the stream type, the video type, the resoluon, the bitrate type, the Max. bitrate, and I Frame
Interval.
Click Save to save the
sengs aer the conguraon.
Figure 10-13 Audio Sengs
Set the stream type, input volume, output volume and enable voice prompt according to your
actual needs.
Click Save to save the
sengs.
10.7.8 Set Image Parameters
You can adjust the image parameters, video parameters, supplement parameters, backlight, image
fusion and capture interval.
Steps
1.
Click
Conguraon → Image .
2.
Congure the parameters to adjust the image.
DS-K1T681 Series Face Recognion Terminal User Manual
123
Video Adjust(Video Standard)
Set the video frame rate when performing live view remotely. Aer changing the standard,
you should reboot the device to take eect.
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
Image Adjustment
Drag the block or enter the value to adjust the live video's brightness, contrast,
saturaon,
and sharpness.
LED Light Parameters
Set the supplement light type, mode, start me and end me. You can also set the
brightness.
Backlight
Enable or disable the WDR funcon.
When there are both very bright and very dark areas simultaneously in the view, WDR
balances the brightness level of the whole image and provide clear images with details.
Image Fusion
Wen the environment is dark, you can select
Automac to enable the image fusion funcon.
The live view page will display the fusion image. And you can also set the sensivity.
Select Disable to disable the funcon.
Capture Interval
You can select the capture interval according to your actual needs.
3.
Click Restore Default Sengs to restore the parameters to the default sengs.
10.7.9 Alarm
Sengs
Set the alarm output parameters.
Steps
1.
Click Conguraon → Event → Alarm Sengs → Alarm Output .
2.
Set Alarm Name and Output Delay.
DS-K1T681 Series Face Recognion Terminal User Manual
124
10.7.10 Access Control Sengs
Set Authencaon Parameters
Set authencaon related parameters, such as enable authencaon funcon, select
authencaon mode, etc.
View Device Informaon
View the device or the card reader's informaon.
Steps
1.
Click
Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select 1 or 2 to view the terminal type and model. They are read-only.
Note
1 refers to the device and 2 refers to the connected card reader.
Set Authencaon Mode
Select an authencaon mode for the device or the connected card reader according to your
actual needs. People will authencate follow the conguraon.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1 or Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Select an authencaon mode from the drop-down list. The device (terminal 1) or the card
reader (terminal 2) will apply the congured authencaon mode. People authencaon should
follow the
congured authencaon mode.
5.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
125
Set Mulple People Authencaon
Mulple people can be authencated at the same me.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Enable Mulple People Authencaon. Mulple people can be authencated at the same me.
5.
Click Save.
Set
Authencaon Interval
Set the device's authencaon interval of the same person when authencang.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Set the authencaon interval of the same person when authencang. The same person can
only authencate once in the congured interval. A second authencaon will be failed.
5.
Click Save.
Set Alarm of Max. Failed
Aempts
The device will report alarm when the authencaon aempts reach the set value.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
DS-K1T681 Series Face Recognion Terminal User Manual
126
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Enable Alarm of Max. Failed Aempts and set the Max. value. The device will report alarm
when the authencaon aempts reach the set value.
5.
Click Save.
Enable Tampering
Detecon
Enable the an-tamper detecon for the device or the connected card reader. The device will
report alarm if an tampering event is triggered.
Steps
1.
Click
Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1 or Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Enable Tampering Detecon. The device will report alarm if an tampering event is triggered.
5.
Click Save.
Set Card No. Reversing
The device's or the connected card reader's reading sequence of card No. will be in reverse
sequence
aer enabling the funcon.
Steps
1.
Click
Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1 or Terminal 2.
DS-K1T681 Series Face Recognion Terminal User Manual
127
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Set Card No. Reversing. The read card No. will be in reverse sequence aer enabling the
funcon.
5.
Click Save.
Set Sub Card Reader Posion
If the device has connected to a card reader, you can select sub card reader posion as dierent or
same side as the main device.
Steps
1.
Click
Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Select sub card reader posion as dierent or same side as the main card reader.
5.
Click Save.
Set Face
Recognion Interval
You can set the interval between 2 connuous recognion of a same person during the
authencaon.
Steps
1.
Click
Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 1 or Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Set Connuous Face Recognion Interval. You can set the interval between 2 connuous
recognion
of a same person during the authencaon. In the congured interval, Person A can
DS-K1T681 Series Face Recognion Terminal User Manual
128
only recognized once. If another person (Person B) has recognized during the interval, Person A
can recognized again.
5.
Click Save.
Set Communicaon Duraon between Device and Card Reader
When the access control device cannot connect with the card reader for longer than the set me,
the card reader will turn oine automacally.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Set Communicaon with Controller Every. When the device cannot connect with the card
reader for longer than the set me, the card reader will turn oine automacally.
5.
Click Save.
Set Max. Interval When Entering Password
Set Max. interval when entering password. When you entering the password on the card reader, if
the interval between pressing 2 digits is longer than the set value, the digits you pressed before
will be cleared
automacally.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Set Max. Interval When Entering Password. When you entering the password on the card
reader, if the interval between pressing 2 digits is longer than the set value, the digits you
pressed before will be cleared
automacally.
5.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
129
Set OK LED Polarity/Error LED Polarity
Set OK LED Polarity/Error LED Polarity of the connected card reader according to the actual card
reader parameters. Generally, adopts the default
sengs.
Steps
1.
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select Terminal 2.
Note
1 refers to the device and 2 refers to the connected card reader.
3.
Enable Enable Authencaon Device to enable the authencaon funcon.
4.
Set OK LED Polarity/Error LED Polarity of the access control device according to the actual card
reader parameters. Generally, adopts the default sengs.
5.
Click Save.
Set Door Parameters
Set door related parameters.
Set Door No. and Name
If the device has connected to dierent door locks, you can select the door No. and set door name
to
disnguish.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
DS-K1T681 Series Face Recognion Terminal User Manual
130
Figure 10-14 Door Parameters Sengs Page
2.
Select the device corresponded door No. and create a name for the door.
3.
Click Save.
Set Door Open
Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be locked.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
Figure 10-15 Door Parameters Sengs Page
2.
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
3.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
131
Set Door Open Timeout Alarm
Set door open meout alarm and an alarm will be triggered if the door has not been closed within
the
congured me duraon.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
Figure 10-16 Door Parameters Sengs Page
2.
Set door open meout alarm and an alarm will be triggered if the door has not been closed
within the congured me duraon.
3.
Click Save.
Set Door Contact
If the device has connected with door contact, you can set the door contact to remain open or
closed according to actual wiring.
Steps
1.
Click
Conguraon → Access Control → Door Parameters .
DS-K1T681 Series Face Recognion Terminal User Manual
132
Figure 10-17 Door Parameters Sengs Page
2.
Set Door Magnec Sensor Type. You can set the door contact as Remain Open or Remain
Closed according to your actual needs. By default, it is Remain Closed.
3.
Click Save.
Set Exit
Buon Type
If the device has connected to an exit buon, you can set the exit buon as remain open or closed
according to actual wiring.
Steps
1.
Click
Conguraon → Access Control → Door Parameters .
Figure 10-18 Door Parameters Sengs Page
2.
Set Exit Buon Type. You can set the exit buon as Remain Open or Remain Closed according
to your actual needs. By default, it is Remain Open.
3.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
133
Set Door Lock Powering O Status
You can set the door lock status when the door lock is powering o. By default, it is Remain Closed.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
Figure 10-19 Door Parameters Sengs Page
2.
Set Door Lock Powering O Status. You can set the door lock status when the door lock is
powering
o. By default, it is Remain Closed.
3.
Click Save.
Set Extended Open
Duraon
The door contact can be enabled with appropriate delay aer person with extended access needs
authencang her/his credenals.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
DS-K1T681 Series Face Recognion Terminal User Manual
134
Figure 10-20 Door Parameters Sengs Page
2.
Set Extended Open Duraon. The door contact can be enabled with appropriate delay aer
person with extended access needs authencang her/his credenals.
3.
Click Save.
Set Door Remain Open
Duraon with First Person
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Steps
1.
Click
Conguraon → Access Control → Door Parameters .
Figure 10-21 Door Parameters Sengs Page
2.
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
3.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
135
Set Duress Code/Super Password
The door can open by inpung the duress code when there is duress. And the specic person can
open the door by
inpung the super password.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
Figure 10-22 Door Parameters Sengs Page
2.
Set duress code or super password.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The
specic person can open the door by inpung the super password.
3.
Click Save.
Set RS-485 Parameters
You can set the RS-485 parameters including the peripheral, address, baud rate, etc.
Click Conguraon → Access Control → RS-485 Sengs .
Check Enable RS-485, and set the parameters.
Click Save to save the
sengs aer the conguraon.
No.
Set the RS-485 No.
Peripheral Type
DS-K1T681 Series Face Recognion Terminal User Manual
136
Select a peripheral from the drop-down list according the actual situaon. You can select from
Card Reader, Extension Module, Access Controller, or Disable.
Note
Aer the peripheral is changed and saved, the device will reboot automacally.
RS-485 Address
Set the RS-485 Address according to your actual needs.
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
Baud Rate
The baud rate when the devices are communicang via the RS-485 protocol.
Data Bit/Stop Bit/Parity/Flow Control/Communicaon Mode
Set the paramters according to your actual needs.
Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
Note
Some device models do not support this funcon. Refer to the actual products when conguraon.
1.
Click Conguraon → Access Control → Wiegand Sengs .
2.
Check Wiegand to enable the Wiegand
funcon.
3.
Set a transmission direcon.
Input
The device can connect a Wiegand card reader.
Output
The can connect an external access controller. And the two devices will transmit the card No.
via Wiegand 26 or 34.
4.
Click Save to save the
sengs.
Note
If you change the peripheral, and aer you save the device parameters, the device will reboot
automacally.
DS-K1T681 Series Face Recognion Terminal User Manual
137
Elevator Control
Steps
1.
Click
Conguraon → Access Control → Elevator Control Parameters .
Figure 10-23 Access Control and Elevator Control
2.
Click to enable Elevator Control.
3.
Set the elevator parameters.
Elevator No.
Select an elevator No.
Main Elevator Controller Model
Select an elevator controller.
Interface Type
If you select RS-485, make sure you have connected the device to the elevator controller with
RS-485 wire.
If you select Network Interface, enter the elevator controller's IP address, port No., user
name, and password for
communicaon.
Negave Floor Capacity
Set the negave oor number.
Note
●
Up to 4 elevator controllers can be connected to 1 device.
●
Up to 10 negave oors can be added.
●
Make sure the interface types of elevator controllers, which are connected to the same
device, are consistent.
Set Terminal Parameters
You can set terminal parameters for accessing.
Click Conguraon → Access Control → Terminal Parameters .
DS-K1T681 Series Face Recognion Terminal User Manual
138
You can set Working Mode as Access Control Mode. The access control mode is the device normal
mode. You should authencate your credenal for accessing.
You can enable Remote Vericaon according to your actual needs. Aer enabling, you can verify
remotely.
Click Save to save the sengs aer the conguraon.
10.7.11 Video Intercom Sengs
Set Video Intercom Parameters
The device can be used as a door staon, or outer door staon. You should set the device No.
before usage.
Click
Conguraon → Intercom → Device No. .
If set the device type as Door
Staon, you can set the oor No., door staon No., and click More to
set Community No., Building No., and Unit No. You can press any digit buon to enter the calling
page, and enter the room No. and press call buon to call the resident.
Click Save to save the
sengs aer the conguraon.
Figure 10-24 Device No. Sengs
Device Type
DS-K1T681 Series Face Recognion Terminal User Manual
139
The device can be used as a door staon or outer door staon. Select a device type from the
drop-down list.
Note
If you change the device type, you should reboot the device.
Floor No.
Set the device installed oor No.
Door Staon No.
Set the device installed oor No.
Note
●
If you change the No., you should reboot the device.
●
The main door staon No. is 0, and the sub door staon No. ranges from 1 to 16.
Community No.
Set the device community No.
Building No.
Set the device building No.
Unit No.
Set the device unit No.
Note
If you change the No., you should reboot the device.
If set the device type as Outer Door Staon, you can set outer door staon No., and community
No. You can press call buon to enter the calling page, and enter 【Community No. + Building No. +
# + Unit No. + # + Room No.】 and press call
buon to call resident.
Outer Door Staon No.
If you select outer door staon as the device type, you should enter a number between 1 and
99.
Note
If you change the No., you should reboot the device.
Community No.
Set the device community No.
Session
Sengs
Enable the communicaon between door staon, main staon, and video intercom server.
DS-K1T681 Series Face Recognion Terminal User Manual
140
Steps
1.
Click Conguraon → Intercom → Session Sengs to enter the sengs page.
2.
Set registraon password, main staon IP, private server IP and enable Protocol 1.0.
Registraon Password
Create a
registraon password for communicaon via SIP
Main Staon IP
IP address of the main
staon.
Private Server IP
Enter the IP address of the device that need to communicate via SIP. The device will be the
SIP server. Other devices should register to the SIP server, or the video intercom between
devices will be failed.
Enable Protocol 1.0
Aer enabling, the device is registered to the main staon through the previous protocol. If
disabled, the device is registered to the main staon through the new protocol.
3.
Click Save.
Time
Duraon Sengs
Set the Max. call duraon.
Go to Conguraon → Intercom → Call Sengs .
Drag the block to set the Max. call duraon. Click Save.
Note
The Max. call duraon range is 90 s to 120 s.
Press Buon to Call
Steps
1.
Click Intercom → Press Buon to Call to enter the sengs page.
2.
Set the parameters.
-
Check Call Management Center，Specied Indoor Staon，Indoor Staon or APP to set the
buon.
Note
If you check Call Specied Indoor Staon, you should enter the specied indoor staon No.
Number Sengs
You can call the room SIP to call the room.
DS-K1T681 Series Face Recognion Terminal User Manual
141
Steps
1.
Click Conguraon → Intercom → Number Sengs to enter the sengs page.
2.
Click + Add, enter the Room No. and SIP.
3.
Click Save.
10.7.12 Card Sengs
Set Card Security
Click Conguraon → Card Sengs → Card Type to enter the sengs page.
Set the parameters and click Save.
Enable NFC Card
In order to prevent the mobile phone from
geng the data of the access control, you can
enable NFC card to increase the security level of the data.
Enable M1 Card
Enable M1 card and authencang by presenng M1 card is available.
M1 Card Encrypon
Sector
M1 card encrypon can improve the security level of authencaon.
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable EM Card
Enable EM card and
authencang by presenng EM card is available.
Enable DESFire Card
The device can read the data from DESFire card when enabling the DESFire card funcon.
DESFire Card Read Content
The device can read the DESFire card content.
Enable FeliCa Card
The device can read the data from FeliCa card when enabling the FeliCa card funcon.
Set Card No.
Authencaon Parameters
Set the card reading content when authencate via card on the device.
Go to Conguraon → Card Sengs → Card No. Authencaon Sengs .
Select a card
authencaon mode and click Save.
Full Card No.
DS-K1T681 Series Face Recognion Terminal User Manual
142
All card No. will be read.
Wiegand 26 (3 bytes)
The device will read card via Wiegand 26 protocol (read 3 bytes).
Wiegand 34 (4 bytes)
The device will read card via Wiegand 34 protocol (read 4 bytes).
10.7.13 Plaorm Aendance
If you want to track and monitor when the persons start/stop work and monitor their working
hours and late arrivals, early departures,
me taken on breaks, and absenteeism, you can add the
person to the shi group and assign a shi schedule (a rule for the aendance dening how the
schedule repeats, the
shi type, break sengs, and the card swiping rule.) to the shi group to
dene the aendance parameters for the persons in the shi group.
Set Manual
Aendance via Web
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Set the
Aendance Mode as Manual.
3.
Enable the Aendance Status Required and set the aendance status lasts duraon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
Result
You should select an
aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
DS-K1T681 Series Face Recognion Terminal User Manual
143
Set Auto Aendance via Web
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will
automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Auto.
3.
Enable the Aendance Status Required funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to for details.
Set Manual and Auto
Aendance via Web
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the
aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Set the
Aendance Mode as Manual and Auto.
3.
Enable the Aendance Status Required funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to for details.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance
status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
DS-K1T681 Series Face Recognion Terminal User Manual
144
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
10.7.14 Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
Go to Conguraon → Security → Privacy Sengs
Event Storage Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by
Specied Time, or Overwring.
Delete Old Events Periodically
Drag the block or enter number to set the period for event deleng. All events will be deleted
according to the
congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Authencaon
Sengs
Display Authencaon Result
You can check Face Picture, Name, and Employee ID, to display the authencaon result.
Name De-idencaon
You can check Name De-idencaon, and the whole name will not be displayed.
Picture Uploading and Storage
Save Picture When Authencang
Save picture when authencang automacally.
Upload Picture When Authencang
Upload the pictures when authencang to the plaorm automacally.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
DS-K1T681 Series Face Recognion Terminal User Manual
145
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Clear All Pictures in Device
Note
All pictures cannot be restored once they are deleted.
Clear Registered Face Pictures
All registered pictures in the device will be deleted.
Clear Captured Pictures
All captured pictures in the device will be deleted.
10.7.15 Set Biometric Parameters
Set face parameters of the device, such as enable face an-spoong, set live face security level,
recognion distance, etc.
Enable Face
An-spoong
Enable the face an-spoong funcon, and the device can recognize whether the person is a live
one or not.
Steps
1.
Click
Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Enable or disable the face an-spoong funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
3.
Click Save.
Set Live Face
Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Steps
1.
Click Conguraon → Smart → Smart .
DS-K1T681 Series Face Recognion Terminal User Manual
146
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face
authencaon. The higher the level, the more strict the authencaon.
3.
Click Save.
Face Duplicate Check
You can check face duplicate when you import face data.
Steps
1.
Click Conguraon → Smart → Smart
2.
Enable Face Duplicate Check.
Aer enabling this funcon, you can check face duplicate when
you import face data.
Set
Recognion Distance
Select the distance between the authencang user and the device camera.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Select the distance between the authencang user and the device camera.
3.
Click Save.
Set Face Pitch Angle
Set the maximum pitch angle when starng face authencaon.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
The maximum pitch angle when starng face authencaon.
3.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
147
Set Yaw Angle
The maximum yaw angle when starng face authencaon.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Set the maximum yaw angle when starng face authencaon.
3.
Click Save.
Set Face Picture Quality Grade for Applying
Set face picture quality grade for applying according to your needs.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Set face picture quality grade for applying according to your needs. The higher the threshold, the
higher the requirement for image quality. If the image applying fails, the threshold or image
quality can be adjusted according to actual needs.
3.
Click Save.
Set 1: 1 Face Picture Grade Threshold
Set 1: 1 face picture grade threshold according to your needs.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Set 1: 1 face picture grade threshold according to your needs. The higher the threshold, the
higher the quality requirement for the captured images of the front facing camera, and it is easy
to prompt
authencaon failure.
Note
The default threshold is 0, which can be used. Seng the threshold too high will intercept
images and cause authencaon failure.
3.
Click Save.
DS-K1T681 Series Face Recognion Terminal User Manual
148
Set Face 1:1/1:N Threshold
Set the face matching threshold when authencang via 1:1 or 1:N matching mode. The larger the
value, the smaller the false accept rate and the larger the false
rejecon rate.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Set the face matching threshold when authencang via 1:1 or 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
3.
Click Save.
Set Face
Recognion Timeout Value
Set the meout value when face recognizing. If the face recognion me is longer than the
congured value, the system will pop up a prompt.
Steps
1.
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Set the meout value when face recognizing. If the face recognion me is longer than the
congured value, the system will pop up a prompt.
3.
Click Save.
Set ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment.
Steps
1.
Click
Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Enable ECO Mode and the device will use the IR camera to authencate faces in the low light or
dark environment. And you can set the ECO mode threshold, ECO mode (1:N), and ECO mode
(1:1).
ECO Mode Threshold
DS-K1T681 Series Face Recognion Terminal User Manual
149
The larger the value, the device enter the ECO Mode easier.
ECO Mode (1:1)
Set the matching threshold when authencang via ECO mode 1:1 matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate
3.
Click Save.
Set Face without Mask Detecon
Aer enabling the face without mask detecon, the system will recognize the face with mask or
not.
Steps
1.
Click
Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Aer enabling the face without mask detecon, the system will recognize the face with mask or
not. You can set face with mask1:N matching threshold, it's ECO mode, and the strategy.
Face without Mask
Detecon
None
The funcon is disabled. The device will not detect whether a person is wearing a face
mask or not.
Reminder of Wearing Face Mask
If the person do not wear the face mask when
authencang, the device will pop up a
prompt and the door will open.
Must Wear Face Mask
If the person do not wear the face mask when authencang, the device will pop up a
prompt and the door will keep closed.
Face with Mask & Face (1:1)
Set the matching value when
authencang with face mask via 1:1 matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold
Set the matching threshold when authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false
rejecon rate.
Face with Mask & Face (1:1 ECO)
DS-K1T681 Series Face Recognion Terminal User Manual
150
Set the matching value when authencang with face mask via ECO mode 1:1 matching
mode. The larger the value, the smaller the false accept rate and the larger the false rejecon
rate.
Face with Mask 1:N Matching Threshold (ECO Mode)
Set the matching threshold when authencang with face mask via ECO mode 1:N matching
mode. The larger the value, the smaller the false accept rate and the larger the false rejecon
rate.
3.
Click Save.
Set Recognion Area
Set the recognion area on the device screen.
Steps
1.
Click Conguraon → Smart → Area Conguraon .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
2.
Drag the yellow frame in the live video or enter values for the le, right, top, and boom margin
to adjust the recognion area. Only the face within the area can be recognized by the system.
3.
Click Save.
10.7.16 Set Open
Plaorm
If the device supports HEOP protocol, you can upload the third-party applicaon to the device from
this page.
Before You Start
Make sure the device contains the HEOP program.
Steps
1.
Click
Conguraon → Open Plaorm .
2.
If it is the
rst me to use the funcon, you should read the Disclaimer and make sure that the
applicaon you want to install t the following condions.
●
Each applicaon has its own exclusive name.
●
The FLASH memory space that the
applicaon takes up is less than the available FLASH
memory space of the device.
●
The memory and
compung power of the applicaon is less than that available memory and
compung power of the device.
3.
Oponal: You can enable Developer Mode.
DS-K1T681 Series Face Recognion Terminal User Manual
151
Note
Aer obtaining the license cercate, you can enable Developer Mode and import third-party
applicaons for ADB debugging.
4.
Click and select the imported applicaon package from your local computer.
5.
Click Import to complete the
installaon.
Figure 10-25 Open Plaorm
The installed applicaons and their related informaon are displayed in Applicaon List, such as
applicaon name, operaon, version, memory used, ash used, company, status and license.
6.
Import license.
-
If the applicaon package has a license, click the applicaon name on the navigaon on the
le. Click Browse and select the license le from your local computer. Click Import.
-
If the
applicaon package has a license, click → Browse and select a license le from your
local computer. Click Import.
-
If the applicaon package does not have a license, enter hps://partner.hikvision.com/tpp in
the web browser to get a license.
7.
Oponal: Set other funcons.
Enable or disable the
applicaon.
Export log.
Set permission.
DS-K1T681 Series Face Recognion Terminal User Manual
152
Delete the applicaon.
View and upload license.
10.7.17 Preference Sengs
Set the theme, noce publicaon, prompt schedule, custom prompt, and authencaon result
text.
Set Screen Display
You can set the display theme and the sleep me for the device.
Click
Conguraon → Preference → Screen Display .
Sleep
Enable Sleep and the device will enter the sleep mode when no operaon within the congured
sleep me.
Display Theme
You can select display theme for device authencaon. You can select Theme Mode as
Adversement or Authencate.
Noce
Publicaon
You can set the noce publicaon for the device.
Click Conguraon → Preference → Noce Publicaon .
Figure 10-26 Noce Publicaon
Theme Management
Click Media Library Management → + to upload the picture from the local PC.
DS-K1T681 Series Face Recognion Terminal User Manual
153
You can click +, and set Name and Type to create a theme. Aer creang the theme, click + in
the Theme Management panel to select pictures in the media library. Click OK to add pictures
to the theme.
Customize Audio Content
Customize the output audio content when authencaon succeeded and failed.
Steps
1.
Click Conguraon → Video/Audio → Prompt .
2.
Set the
appellaon.
3.
Enable the funcon.
4.
Set the me duraon when authencaon succeeded.
1) Click Add.
2) Set the
me duraon and the language.
Note
If authencaon is succeeded in the congured me duraon, the device will broadcast the
congured content.
3) Enter the audio content.
4) Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
5.
Set the me duraon when authencaon failed.
1) Click Add.
2) Set the
me duraon and the language.
Note
If authencaon is failed in the congured me duraon, the device will broadcast the
congured content.
3) Enter the audio content.
4)
Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
6.
Oponal: Import custom prompt.
1) Select Custom Type.
2) Select the
imporng path, and click Import.
7.
Click Save to save the sengs.
Customize Prompt Voice
You can customize prompt voices for the device.
Steps
1.
Click Conguraon → Preference → Custom Prompt .
DS-K1T681 Series Face Recognion Terminal User Manual
154
2.
Click → and import audio le from local PC according to your actual needs.
Note
The uploaded audio le should be less than 512 kb, in WAV format.
Congure Authencaon Result Text
Steps
1.
Go to Conguraon → Preference → Authencaon Result Text .
2.
Enable Customize Authencaon Result Text.
3.
Enter custom texts.
4.
Click Save.
10.7.18 Upgrade and Maintenance
Reboot device, restore device parameters, upgrade device version, and set advanced face
parameters.
Reboot Device
Click Maintenance and Security → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click Maintenance and Security → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
If the device has been connected to Hik-Connect and network, when there is a new
installaon
package in Hik-Connect, you can click Upgrade aer Online Update to upgrade the device system.
Note
Do not power o during the upgrading.
Restore Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Restore All
All parameters will be restored to the factory
sengs. You should acvate the device before
usage.
Restore
The device will restore to the default sengs, except for the device IP address and the user
informaon.
DS-K1T681 Series Face Recognion Terminal User Manual
155
Import and Export Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
Click Advanced Sengs, and enter the admin password.
Face Parameter
Custom
An-Spoong Detecon
Face Liveness Level
Aer enabling face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
An-Spoong Detecon Threshold
The larger the value, the smaller the false accept rate and the larger the false rejecon
rate. The smaller the value, the larger the false accept rate and the smaller the false
rejecon rate.
Lock Face for An-Spoong Protecon
Aer enabling this funcon, the device will lock automacally when an-spoong detecon
failed.
Lock Duraon
The lock duraon aer enabling Lock Face for An-Spoong Protecon when an-spoong
detecon failed.
Version Informaon
You can view the device informaon.
10.7.19 Device Debugging
You can set device debugging parameters.
Steps
1.
Click Maintenance and Security → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
DS-K1T681 Series Face Recognion Terminal User Manual
156
To raise network security, disable SSH service. The conguraon is only used to debug the
device for the professionals.
Print Log
You can click Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet Size, and click Start Capture to
capture.
10.7.20 Log Query
You can search and view the device logs.
Go to Maintenance and Security → Maintenance → Log .
Set the major and minor type of the log type. Set the start me and end me for searching, and
click Search.
The results will be displayed below, which including the No.,
me, the major type the minor type,
the channel No., the local/remote user
informaon, the remote host IP, etc.
10.7.21 Security Mode
Sengs
Set the security mode for logging in the client soware.
On the Device for Management page, click Maintenance and Security → Security → Security
Service .
Select a security mode, and click Save.
Security Mode
High security level for user
informaon vericaon when logging in the client soware.
Compable Mode
The user informaon vericaon is compable with the old client soware version when
logging in.
Illegal Login Lock
Aer enabling Illegal Login Lock, the device will be locked if it is logged in illegally.
10.7.22
Cercate Management
It helps to manage the server/client cercates and CA cercate.
Note
The funcon is only supported by certain device models.
DS-K1T681 Series Face Recognion Terminal User Manual
157
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security →
Cercate Management .
2.
In the Cercate Files area, select a Cercate Type from the drop-down list.
3.
Click Create.
4.
Input
cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The
cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed
cercate.
1) Select a cercate type in the Import Passwords area, and select a cercate from the local,
and click Install.
2) Select a
cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Install.
Install Other Authorized
Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
In the Import Passwords and Import
Communicaon Cercate areas, select cercate type
and upload cercate.
3.
Click Install.
Install CA
Cercate
Before You Start
Prepare a CA
cercate in advance.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Create an ID in the Import CA Cercate area.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Install.
DS-K1T681 Series Face Recognion Terminal User Manual
158
Chapter 11 Other Plaorms to Congure
You can also congure the device via iVMS-4200 Client Soware or HikCentral Access Control. For
details, see the
plaorms' user manual.
iVMS-4200 Client Soware
Click/tap the link to view the client soware's user manual.
hps://pinfo.hikvision.com/hkwsen/unzip/20230109110406_14606_doc/
UD31348B_iVMS-4200%20AC%20Client_User%20Manual_V1.9.0_PDF1-TEST_en-
US_20221226.PDF
HikCentral Access Control (HCAC)
Click/tap the link to view the HCAC's user manual.
hps://pinfo.hikvision.com/hkwsen/unzip/20230207191241_72415_doc/index.html
DS-K1T681 Series Face Recognion Terminal User Manual
159
Appendix A. Tips for Scanning Fingerprint
Recommended Finger
Forenger, middle nger or the third nger.
Correct Scanning
The gure displayed below is the correct way to scan your nger:
You should press your nger on the scanner horizontally. The center of your scanned nger should
align with the scanner center.
Incorrect Scanning
The gures of scanning ngerprint displayed below are incorrect:
DS-K1T681 Series Face Recognion Terminal User Manual
160
Environment
The scanner should avoid direct sun light, high temperature, humid condions and rain.
When it is dry, the scanner may not recognize your
ngerprint successfully. You can blow your
nger and scan again.
Others
If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other
authencaon methods.
If you have injuries on the scanned nger, the scanner may not recognize. You can change another
nger and try again.
DS-K1T681 Series Face Recognion Terminal User Manual
161
Appendix B. Tips When Collecng/Comparing Face
The
posion when collecng or comparing face picture is as below:
Posions (Recommended Distance: 0.5 m)
Expression
●
Keep your expression naturally when collecng or comparing face pictures, just like the
expression in the picture below.
●
Do not wear hat, sunglasses, or other accessories that can aect the facial recognion funcon.
●
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
Posture
In order to get a good quality and accurate face picture, posion your face looking at the camera
when collecng or comparing face pictures.
DS-K1T681 Series Face Recognion Terminal User Manual
162
Size
Make sure your face is in the middle of the collecng window.
DS-K1T681 Series Face Recognion Terminal User Manual
163
Appendix C. Tips for Installaon Environment
1. Light Source Illuminaon Reference Value
Candle: 10Lux
Bulb: 100~850Lux
Sunlight: More than 1200Lux
2. Avoid backlight, direct and indirect sunlight
DS-K1T681 Series Face Recognion Terminal User Manual
164
Appendix D. Dimension
Figure D-1 Dimension
DS-K1T681 Series Face Recognion Terminal User Manual
165
Appendix E. Funcon Dierences
Model DS-K1T681DBWX DS-K1T681DBX
Wi-Fi Support Not Support
PoE Not Support Not Support
3G/4G Not Support Not Support
DS-K1T681 Series Face Recognion Terminal User Manual
166
UD29945B-A
