LEAD LIGHT 5W SMD LED 230V
MODEL NO: ML9230V
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using.
9 Inspect power supply leads, plugs and all electrical connections for wear and damage.
9 Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
9 If the light is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable Appliance
Test) tested.
9 Electrical safety information, it is important that the following information is read and understood.
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
IMPORTANT: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the
correct fuse - see fuse rating in these instructions.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable. Remove the plug from the socket by maintaining a rm grip on the plug.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or replaced immediately by a
qualied electrician.
9 This product is tted with a BS1363/A 3 pin plug.
9 If the cable or plug is damaged during use, switch the electricity supply and remove from use.
9 Replace a damaged plug with a BS1363/A 3 pin plug. If in doubt contact a qualied electrician.
9 Class II products are wired with live (brown) and neutral (blue) only are marked with the Class II symbol;
A) Connect the BROWN live wire to the live terminal ‘L’.
B) Connect the BLUE neutral wire to the neutral terminal ‘N’.
C) After wiring, check that there are no bare wires and ensure that all wires have been correctly connected.
9 Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
8 DO NOT connect either wire to the earth terminal.
9 Sealey recommend that repairs are carried out by a qualied electrician.
1.2. GENERAL SAFETY
WARNING! Disconnect light from mains power before performing any maintenance.
8 DO NOT shine light directly into your, other person’s or animal’s eyes.
8 DO NOT allow children to use the light.
9 Maintain the light in good condition.
8 DO NOT use the light if the light if damaged.
9 When not in use store the light in a safe, dry, childproof location.
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using this light.
9 Wear eye protection. A full range of safety equipment is available from your Sealey stockist.
9 Wear suitable clothing to avoid snagging.
8 DO NOT wear jewellery and tie back long hair.
9 Account for all tools being used and DO NOT leave them in or near the engine.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that common sense and caution are factors which must be applied by the
operator.
2. INTRODUCTION
High output illumination with even spread of light. SMD LEDs lower power consumption, saving on energy costs, and have a high shock
resistance and life span. Supplied with 5m cable.
Refer to
instruction
manual
Wear eye
protection
Recommended fuse rating
3 Amp
ML9230V Issue 2 (ALL) 20/06/23
Original Language Version
© Jack Sealey Limited
3. SPECIFICATION
Model No: ........................................................ML9230V
Colour Temperature:..............................................6500K
Fuse Rating: ................................................................3A
IP Rating: .................................................................IP54
LED Type: ...............................................................SMD
Length: ................................................................400mm
Lumen Output: ...................................................... 420lm
Power: ........................................................................5W
Supply: ....................................................................230V
4. OPERATION
4.1. Plug into a mains supply.
4.2. Press button on handle to turn on.
5. MAINTENANCE
WARNING! Disconnect from the mains supply before performing any maintenance.
9 Keep the light clean with a moistened cloth.
8 DO NOT use solvents as these could damage the surface of the light.
ML9230V Issue 2 (ALL) 20/06/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
