Metal Garden Bench
HW66421
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
2
Before You Start
Read each step carefully before starting. It is very important
to ensure each step followed in correct order, otherwise
assembly difficulties may occur.
Most of board parts are labeled or stamped on the raw
edges. Have a check to make sure all parts are included.
Work in a spacious area, preferably on a carpet close to
where the unit will be used.
Keep the handtools close at hand. Do not use power tools to
assemble your furniture. They may scratch or damage the
parts.
3
Back x 1
Arms x 2
Seat slats x 6
Not actual size
Board Identification
4
Not actual size
Board Identification
B
C
B
A
5
Actual size
Hardware List
M6 x 35mm
M6 x 55mm
BOLT BOLT
M6
WASHER
4 x 4
ALLEN WRENCH
D
x 12
E
x 4
G
x 1
F
x 16
PRODUCT ASSEMBLY
B
B
D
F
C
C
STEP 1
6
IMPORTANT: Do not tighten completely until
assembly is completed.
Attach the seat slat C to the arm B by bolts D
with washers F through the pre-drilled holes on
the arm into the pre-welded nuts on the seat slat.
Repeat step for the other side arm B .
PRODUCT ASSEMBLY
B
F
E
A
A
STEP 2
7
Attach the back A to the arm B by inserting bolts
E with washers F through the pre-drilled holes
on the arm into the pre-welded nuts on the back.
Repeat step for the other side arm B .
8
Tighten all the bolts with the allen wrench ,
and turn the bench to the upright position.
Your bench is now ready for use, so relax & enjoy!
PRODUCT ASSEMBLY
STEP 3
9
Maximum Loads
250 lbs
250 lbs
PRODUCT ASSEMBLY
STEP 4
This item is only suitable within the specified maximum load-bearing. Heavier loads than
the indicated load capacity may cause instability, resulting in possible injuries.
10
Care and Maintenance
Use a soft, clean cloth that will not scratch the surface when dusting.
Use of furniture polish is not necessary.
Should you choose to use polish, test first in an inconspicuous area.
Using solvents of any kind on your furniture may damage the finish.
Never use water to clean your furniture as it may cause damage to the
finish.
Liquid spills should be removed immediately. Using a soft clean cloth, blot
the spill gently. Avoid rubbing.
Check bolts/screws periodically and tighten them if necessary.
It is best to keep your furniture in a climate-controlled environment.
Extreme temperature and humidity changes can cause fading, warping,
shrinking and splitting of wood.
It is advised to keep furniture away from direct sunlight as sun may
damage the finish.
Proper care and cleaning at home will extend the life of your purchase.
Following these important and helpful tips will enhance your furniture as it
ages.
Further advice about wood
furniture care
Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us !
Do NOT return this item.
